Quanta RM2 Schematic

1

http://hobi-elektronika.net

2

3

4

5

6

7

8

PWA : P835D
PWB : R983D
SCH : M854D

POWER

A A

AC/BATT CONNECTOR

BATT CHARGER

Subwoofer
CONN

B B

MIC

Internal Speaker

HP2

HP1

Camera + D-MIC

TV CONN

C C

USB CONN

USB/eSATA Combo

PG 35 & eSATA board

SATA-ODD

SATA-HDD

1394 CONN

PG 29 & 1394 board

CardReader
CONN

D D

RM2 MB PCB (rev F)RM2 MB PCB (rev F)

1

RM2 Paltrow Intel Discrete Block Diagram

PG 42

PG 42 & IB

PG 37 & DB

PG 42 & IB

PG 42 & IB

PG 37

PG 35

PG 42 & IB

PG 36

PG 36

PG 29

CLOCK

SLG8SP513V

PG 54

PG 47

(QFN-64)

DDR3-SODIMM1

DDR3-SODIMM2

Subwoofer AMP
MAXIM MAX9759

(16 Pin TQFN)

Amplifier

TI TPA6040A4

(32 Pin QFN)

Amplifier

TI TPA4411MRTJR

(20 Pin QFN)

PC Card/1394

RICOH R5C833T

(128 Pin TQFP)

14 x 14 mm

2

PG 17

PG 15

PG 16

PG 42

PG 41

PG 41

PG 28,29

FAN & THERMAL

EMC1423

(10P TSSOP)

PG 39

667 / 800 / 1066 MHz FSB

800 / 1066 MHZ DDR III

800 / 1066 MHZ DDR III

AUDIO

IDT 92HD73C

IHDA

(56 LQFP)

9 x 9 mm

PG 40

USB2.0 [11]

USB2.0 [9]

USB2.0 x 2 [0:1]

USB2.0 [8]
SATA2 [A5]
SATA2 [A1]
SATA2 [A0]
33MHz PCI

Debug Port
(Mini PCI)

PG 56

SPI ROM

2MB

(8 Pin SO8W)

3

PG 32

SPI

(478 Micro-FCPGA)

(1299 uFCBGA)

ITE ITE8512E

(128 Pin LQFP)

16 x 16 mm

Keyboard

PG 37 PG 32

4

VER : 3A

Penryn

PG 3,4

Cantiga

PG 5,6,7,8,9,10

DMI interface

ICH9-M

(676 BGA)

PG 11,12,13,14

LPC

SIO

PG 31

CIR Touchpad

PG 37 & DB

PS/2

SYSTEM POWER

REGULATOR

+1.5V_RUN/+1.05V_VCCP

DDR3 VR

+1.5V_DDR/+0.75V_DDR_VTT
+V_DDR_MCH_REF

Load Switch

+5V_SUS/+3.3V_SUS/+5V_RUN/+3.3V_RUN/+1.8V_RUN

PCIEx16

AMD M86ME-XT

PCI EXPRESS GFX

GDDR3 x 4 (512M)

PCIE [1]
USB2.0 [5]

WWAN MINI-CARD

PCIE [2]
USB2.0 [4]

WLAN Half MINI-CARD

PCIE [3]
USB2.0 [6]

UWB/BT MINI-CARD

PCIE [4]
USB2.0 [7]

PCIE [6]

Express Card

Broadcom BCM5784M

PAD &
SCREW &

SMBus [2]

SPRING

PG 46

Media Button

PG 37 & DB

5

PG 48

PG 49

(880 BGA)

PG 18,19,20,21,22,26

(136P FBGA)

LAN

(68P QFN)

System
Reset
Circuit

LED

PG 38

6

PG 45

RTC

PG 32

SYS VR

+5V_ALW2/+3.3V_ALW
+5V_ALW/+15V_ALW

CPU VR

+VCC_CORE

HDMI

DP

LVDS

VGA

PG 23,24

PG 34

PG 33

PG 34

PG 30

PG 43

To IO Board

(USB*2/ MIC/
HP2/ HP1/ LED)

Title

Title

Title

BLOCK DIAGRAM

BLOCK DIAGRAM

BLOCK DIAGRAM

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

RM2 3A

RM2 3A

RM2 3A

Date: Sheet

Date: Sheet

Date: Sheet

VGA Core

+VCC_GFX_CORE

PG 50

+1.1V_GFX_PCIE

REGULATOR

+1.8V_SUS

PG 51

PG 55

HDMI CONN.

DISPLAYPORT

Panel Connector

CRT CONN.

GPU THERMAL

ANALOG DEVICES ADM1032

(8 MSOP) 3 x 3 mm

Express Switch

RICOH R5538D001

(20 QFN) 4 x 4 mm

Magnetic RJ45

PG 44 PG 44

To Daughter Board

(Power Button/Speaker/
KB LED/Touch PAD/

PG 42

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

7

Media Button)

159Wednesday, August 06, 2008

159Wednesday, August 06, 2008

159Wednesday, August 06, 2008

PG 52

PG 53

8

PG 25

PG 25

PG 26

PG 27

PG 22

PG 30

PG 37

of

of

of

1

http://hobi-elektronika.net

2

3

4

5

6

7

8

Table of Contents Power States

PAGE DESCRIPTION

1

Block Diagram

2

Front Page

3-4

CPU (Penryn)

5-10

NB (Cantiga)

SB (ICH9-M)

A A

B B

C C

11-14

15-16

DDR3 SO-DIMM(204P)

Clock Generator

17

GPU (M86XT)

18-24

HDMI & DP

25

LCD connector

26

27

CRT

28

Card reader PCI interface

Card reader & 1394 CONN

29

30

Express card

SIO (IT8512)

31

Flash/RTC/CIR

32

WLAN

33

34

WWAN/WPAN

USB & eSATA & TV

35

SATA HDD & ODD

36

KB/CCD/UI

37

38

LED

39

FAN/Thermal

Audio/CONN/Subwoofer (92HD73C).

40-42

43-44

LAN/RJ45 (BCM5784M)

System Reset Circuit

45

PAD & SCREW & SPRING

46

47

CHARGER (MAX8731A)

48

1.05VCCP & 1.5VRUN

49

1.5_DDR/0.75(TPS51116)

50

3.3V/5V/15V (MAX17020)

CPU_POWER (ISL6262A) - 2 phase

51

VGA_M86 (MAX8632)

52

53

1.8V_SUS (TPS51117)

54

DCIN & Batt

Load Switch

55

56

Debug Port (Mini PCI)

57

SMBUS BLOCK

58

Power statu

59

Power Block Diagram

POWER PLANE

+PWR_SRC

+RTC_CELL

+3.3V_ALW

+5V_ALW

+15V_ALW

+3.3V_LAN

+5V_SUS

+3.3V_SUS

+1.8V_SUS

+0.9V_DDR_VTT

+5V_RUN

+3.3V_RUN

+1.8V_RUN

+1.5V_RUN

+1.25V_RUN

+1.05V_VCCP

+VCC_CORE

+LCDVCC

+5V_MOD

+5V_HDD

+5V_ALW2

10V~+19V

+3.0V~+3.3V

+3.3V

+5V

+15V

+3.3V

+5V

+3.3V

+1.8V

+0.9V

+5V

+3.3V

+1.8V

+1.5V

+1.25V

+1.05V

+0.7V~+1.5V

+3.3V

+5V

+5V

GND PLANE PAGE

8731AGND

AGND_0.9V

AGND_DC/DC

AGND_DC2

AGND_DDR

AGND_ISL6260

GND

46

49

52

48

49

51

ALL

4,26,32,34,48,49,50,51,52,55

11,14,31,32

3,13,26,31,32,34,36,37,38,44,46,49,52,53,54

35,36,46,48,49,52,53,54

26,36,37,52,53

42,43

14,38,50,51,53

3,11,12,13,14,20,30,37,38,43,48,49,50,51,53

6,8,9,15,48,49,50,53,55

16,49,53

14,20,25,27,36,37,38,39,40,41,53

6,8,9,11,12,13,14,15,17,19,20,22,25,26,27,28,
30,33,34,36,38,39,40,41,42,53,55

19,20,21,22,23,24,25,38,53

4,9,14,30,33,34,48,,53,55

6,9,14,49,53

3,4,5,6,8,9,11,14,37,48,55

4,51

26

36

36

37,38.52,53 LED power source+5V

DESCRIPTION

DESCRIPTION

MAIN POWER

RTC

8051 POWER

LCD/CHARGE POWER

LARGE POWER

LAN POWER

SLP_S5# CTRLD POWER

SLP_S5# CTRLD POWER

SODIMM POWER

SODIMM POWER

SLP_S3# CTRLD POWER

SLP_S3# CTRLD POWER

SDVO POWER

CALISTOGA/ICH8 POWER

CALISTOGA/ICH8 POWER

CPU/CALISTOGA/ICH8 POWER

CPU CORE POWER

LCD Power

Module Power

HDD Power

CONTROL
SIGNAL

ALWON

ALWON

+5V_ALW

AUX_ON

SUS_ON

3.3V_SUS_ON

DDR_ON

0.9V_DDR_VTT_ON

RUN_ON

3.3V_RUN_ON

RUN_ON

1.5V_RUN_ON

1.25V_RUN_ON

1.05V_RUN_ON

IMVP_VR_ON

LCDVCC_TST_EN
& ENVDD

MODC_EN#

HDDC_EN#

LDO output

ACTIVE INVOLTAGE PAGE

S0~S5

S0~S5

S0~S5

S0~S5

S0~S5

D D

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

FRONTPAGE

FRONTPAGE

FRONTPAGE

RM2 2A

RM2 2A

RM2 2A

7

of

of

of

259Tuesday, July 15, 2008

259Tuesday, July 15, 2008

259Tuesday, July 15, 2008

8

1

2

3

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

4

5

6

Date: Sheet

1

http://hobi-elektronika.net

2

3

4

5

6

7

8

H_A#[3..16](5)

A A

H_ADSTB#0(5)
H_REQ#[0..4](5)

H_A#[17..35](5)

B B

H_ADSTB#1(5)

H_A20M#(11)

H_FERR#(11)

H_IGNNE#(11)

H_STPCLK#(11)
H_INTR(11)
H_NMI(11)
H_SMI#(11)

C C

H_A#[3..16]

H_REQ#[0..4]

H_A#[17..35]

T18T18
T25T25

T14T14
T15T15
T21T21
T105T105
T27T27
T16T16
T17T17
T13T13
T12T12
T11T11
T104T104
T10T10

H_A#3
H_A#4
H_A#5
H_A#6
H_A#7
H_A#8
H_A#9
H_A#10
H_A#11
H_A#12
H_A#13
H_A#14
H_A#15
H_A#16

H_REQ#0
H_REQ#1
H_REQ#2
H_REQ#3
H_REQ#4

H_A#17
H_A#18
H_A#19
H_A#20
H_A#21
H_A#22
H_A#23
H_A#24
H_A#25
H_A#26
H_A#27
H_A#28
H_A#29
H_A#30
H_A#31
H_A#32
H_A#33
H_A#34
H_A#35

U27A

U27A

J4

A[3]#

L5

A[4]#

L4

A[5]#

K5

A[6]#

M3

A[7]#

N2

A[8]#

J1

A[9]#

N3

A[10]#

P5

A[11]#

P2

A[12]#

L2

A[13]#

P4

A[14]#

P1

A[15]#

R1

A[16]#

M1

ADSTB[0]#

K3

REQ[0]#

H2

REQ[1]#

K2

REQ[2]#

J3

REQ[3]#

L1

REQ[4]#

Y2

A[17]#

U5

A[18]#

R3

A[19]#

W6

A[20]#

U4

A[21]#

Y5

A[22]#

U1

A[23]#

R4

A[24]#

T5

A[25]#

T3

A[26]#

W2

A[27]#

W5

A[28]#

Y4

A[29]#

U2

A[30]#

V4

A[31]#

W3

A[32]#

AA4

A[33]#

AB2

A[34]#

AA3

A[35]#

V1

ADSTB[1]#

A6

A20M#

A5

FERR#

C4

IGNNE#

D5

STPCLK#

C6

LINT0

B4

LINT1

A3

SMI#

Quard Core Only

Quard Core Only

F6

TDI_1/RSV

D3

TDO_2/RSV

N5

BMP_1#[0]/RSV

M4

BMP_1#[1]/RSV

B2

BMP_1#[2]/RSV

AE8

BMP_1#[3]/VSS

D8

DCLKPH_1/VSS

F8

ACLKPH_1/VSS

D22

GTLREF_2/RSV

T2

THRMDA_1/RSV

V3

THRMDC_1/RSV

AA8

HFPLL_1/VSS

AC8

SPARE_1[4]/VSS

AA7

BR1#/VCC

Penryn_uFCPGA479

Penryn_uFCPGA479

Gur_0808: change U27 from
DGG^9000001 to DGG^9000002

ADDR GROUP 0 ADDR GROUP 1

ADDR GROUP 0 ADDR GROUP 1

ADS#
BNR#

BPRI#

DEFER#

DRDY#
DBSY#

BR0#

CONTROL XDP/ITP SIGNALS

CONTROL XDP/ITP SIGNALS

IERR#

INIT#

LOCK#

RESET#

RS[0]#
RS[1]#
RS[2]#

TRDY#

HIT#

HITM#

BPM[0]#
BPM[1]#
BPM[2]#
BPM[3]#

PRDY#
PREQ#

TCK

TDO
TMS

TRST#

DBR#

THERMAL

THERMAL

PROCHOT#

THERMDA
THERMDC

ICH

ICH

THERMTRIP#

H CLK

H CLK

BCLK[0]
BCLK[1]

RSVD[06]

TDI

H1
E2
G5

H5
F21
E1

F1

H_IERR#

D20
B3

H4

C1
F3
F4
G3
G2

G6
E4

AD4
AD3

Gur_0808: delete trace

AD1

of ITP_BPM#[0:5]

AC4
AC2
AC1

ITP_TCK

AC5

ITP_TDI

AA6

ITP_TDO

AB3

ITP_TMS

AB5

ITP_TRST#

AB6

ITP_DBRESET#

C20

R58 56R58 56

H_PROCHOT#

D21

H_THERMDA

A24

H_THERMDC

B25

H_THERM

C7

R59 56R59 56

A22
A21

D2

H_THERMDA H_THERMDC

C79

C79

*2200P_NC 50

*2200P_NC 50

R57 56R57 56

H_ADS# (5)
H_BNR# (5)
H_BPRI# (5)

H_DEFER# (5)
H_DRDY# (5)
H_DBSY# (5)

H_BR0# (5)

H_INIT# (11)

H_LOCK# (5)

H_RS#0 (5)
H_RS#1 (5)
H_RS#2 (5)
H_TRDY# (5)

H_HIT# (5)
H_HITM# (5)

ITP_DBRESET# (13)

+1.05V_VCCP

H_THERMDA (39)

H_THERMDC (39)

+1.05V_VCCP

CLK_CPU_BCLK (17)
CLK_CPU_BCLK# (17)

T19T19

+1.05V_VCCP

T26PAD T26PAD

+1.05V_VCCP

R56

R56
*51_NC

*51_NC

Gur_0808: 0 ohm
removal, delete R55

Layout Note:
Place voltage
divider within

0.5" of GTLREF
pin

+1.05V_VCCP

H_PROCHOT#

Layout Note:
Place R116
close to
CPU.

H_RESET# (5)

R432

R432
1K/F

1K/F

R431

R431
2K/F

2K/F

+1.05V_VCCP

2

Q6

Q6

*2N7002W-7-F_NC

*2N7002W-7-F_NC

H_D#[0..15](5)

H_DSTBN#0(5)
H_DSTBP#0(5)
H_DINV#0(5)

H_D#[16..31](5)

H_DSTBN#1(5)
H_DSTBP#1(5)
H_DINV#1(5)

CPU_MCH_BSEL0(6,17)
CPU_MCH_BSEL1(6,17)
CPU_MCH_BSEL2(6,17)

+3.3V_ALW

Voltage Le vel shift

R60

R60
*2.2K_NC

*2.2K_NC

31

H_D#[0..15] H_D#[32..47]

H_D#[16..31]

T24

T24

PAD

PAD

T20

T20

PAD

PAD

T23

T23

PAD

PAD

T106

T106

PAD

PAD

T9

PADT9PAD

T107

T107

PAD

PAD

T22

T22

PAD

PAD

H_D#0
H_D#1
H_D#2
H_D#3
H_D#4
H_D#5
H_D#6
H_D#7
H_D#8
H_D#9
H_D#10
H_D#11
H_D#12
H_D#13
H_D#14
H_D#15

H_D#16
H_D#17
H_D#18
H_D#19
H_D#20
H_D#21
H_D#22
H_D#23
H_D#24
H_D#25
H_D#26
H_D#27
H_D#28
H_D#29
H_D#30
H_D#31

V_CPU_GTLREF
CPU_TEST1
CPU_TEST2
CPU_TEST3
CPU_TEST4
CPU_TEST5
CPU_TEST6
CPU_TEST7

FSB

667

800

U27B

U27B

E22

D[0]#

F24

D[1]#

E26

D[2]#

G22

D[3]#

F23

D[4]#

G25

D[5]#

E25

D[6]#

E23

D[7]#

K24

D[8]#

G24

D[9]#

J24

D[10]#

J23

D[11]#

H22

D[12]#

F26

D[13]#

K22

D[14]#

H23

D[15]#

J26

DSTBN[0]#

H26

DSTBP[0]#

H25

DINV[0]#

N22

D[16]#

K25

D[17]#

P26

D[18]#

R23

D[19]#

L23

D[20]#

M24

D[21]#

L22

D[22]#

M23

D[23]#

P25

D[24]#

P23

D[25]#

P22

D[26]#

T24

D[27]#

R24

D[28]#

L25

D[29]#

T25

D[30]#

N25

D[31]#

L26

DSTBN[1]#

M26

DSTBP[1]#

N24

DINV[1]#

AD26

GTLREF

C23

TEST1

D25

TEST2

C24

TEST3

AF26

TEST4

AF1

TEST5

A26

TEST6

C3

TEST7

B22

BSEL[0]

B23

BSEL[1]

C21

BSEL[2]

Penryn_uFCPGA479

Penryn_uFCPGA479

Gur_0808: change U27 from
DGG^9000001 to DGG^9000002

BSEL2 BSEL1 BSEL0

BCLK

1166

0

200

DATA GRP 0

DATA GRP 0

DATA GRP 1

DATA GRP 1

MISC

MISC

D[32]#
D[33]#
D[34]#
D[35]#
D[36]#
D[37]#

DATA GRP 2

DATA GRP 2

D[38]#
D[39]#
D[40]#
D[41]#
D[42]#
D[43]#
D[44]#
D[45]#
D[46]#

D[47]#
DSTBN[2]#
DSTBP[2]#

DINV[2]#

D[48]#

D[49]#

D[50]#

D[51]#

D[52]#

DATA GRP 3

DATA GRP 3

D[53]#

D[54]#

D[55]#

D[56]#

D[57]#

D[58]#

D[59]#

D[60]#

D[61]#

D[62]#

D[63]#
DSTBN[3]#
DSTBP[3]#

DINV[3]#

COMP[0]
COMP[1]
COMP[2]
COMP[3]

DPRSTP#

DPSLP#

DPWR#

PWRGOOD

SLP#

PSI#

0011

Y22
AB24
V24
V26
V23
T22
U25
U23
Y25
W22
Y23
W24
W25
AA23
AA24
AB25
Y26
AA26
U22

AE24
AD24
AA21
AB22
AB21
AC26
AD20
AE22
AF23
AC25
AE21
AD21
AC22
AD23
AF22
AC23
AE25
AF24
AC20

R26
U26
AA1
Y1

E5
B5
D24
D6
D7
AE6

H_D#32
H_D#33
H_D#34
H_D#35
H_D#36
H_D#37
H_D#38
H_D#39
H_D#40
H_D#41
H_D#42
H_D#43
H_D#44
H_D#45
H_D#46
H_D#47

H_D#48
H_D#49
H_D#50
H_D#51
H_D#52
H_D#53
H_D#54
H_D#55
H_D#56
H_D#57
H_D#58
H_D#59
H_D#60
H_D#61
H_D#62
H_D#63

COMP0
COMP1
COMP2
COMP3

1066 0 0 0266

H_D#[48..63]

H_D#[32..47] (5)

H_DSTBN#2 (5)
H_DSTBP#2 (5)
H_DINV#2 (5)

H_D#[48..63] (5)

H_DSTBN#3 (5)
H_DSTBP#3 (5)
H_DINV#3 (5)

H_DPRSTP# (6,11,51)
H_DPSLP# (11)
H_DPWR# (5)
H_PWRGOOD (11)
H_CPUSLP# (5)
H_PSI# (51)

COMP0
COMP1
COMP2
COMP3

R53

R53

R54

R54

27.4/F

27.4/F

54.9/F

54.9/F

Comp0,2 connect with
Zo=27.4ohm,Comp1,3 connect with
Zo=55ohm, make those traces
length shorter than 0.5".Trace
should be at least 25 mils away
from any other toggling signal.

R433

R433

54.9/F

54.9/F

R434

R434

27.4/F

27.4/F

+3.3V_RUN

12

R64

R64
10M

10M

+1.05V_VCCP

R33

R33

R32

R32

54.9/F

54.9/F

*54.9/F_NC

54.9/F

54.9/F

ITP_TDI
ITP_TMS

D D

ITP_TDO

ITP_DBRESET#

ITP_TCK
ITP_TRST#

Layout note:
Place R32, R33, R35, R38, R40, R48 close t o CPU

1

*54.9/F_NC

R48 150R48 150

R40 54.9/FR40 54.9/F
R35 54.9/FR35 54.9/F

R38

R38

+3.3V_SUS

Gur_0808: depop
R38 to let ITP_TDO
"No connect" as
check list 2.0

2

Gur_0808: delete reserved IT P by
deleting JIT P1, C49, C50, R39, R42, R43

3

H_THERM

Q7

Q7

MMST3904-7-F

MMST3904-7-F

2

4

2

12

C83

C83

0.1U

0.1U

1 3

10

10

31

H_THERMTRIP# (50)

Q8

Q8
2N7002W-7-F

2N7002W-7-F

(28)

5

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

6

Date: Sheet

COMPUTER

Penryn (HOST BUS)

Penryn (HOST BUS)

Penryn (HOST BUS)

RM2 3A

RM2 3A

RM2 3A

7

of

of

of

359Friday, Au gust 08, 2008

359Friday, Au gust 08, 2008

359Friday, Au gust 08, 2008

8

1

http://hobi-elektronika.net

2

3

4

5

6

7

8

+VCC_CORE +VCC_CORE

+VCC_CORE

A A

+VCC_CORE

All use 10U 4V(+-20%,X6S,0805)Pb-Free.

C74

C75

C75
10U

10U

4

4
805

805

C57

C57
10U

10U

4

4
805

805

C74
10U

10U

4

4
805

805

C56

C56
10U

10U

4

4
805

805

C73

C73
10U

10U

4

4
805

805

C70

C70
10U

10U

4

4
805

805

C72

C72
10U

10U

4

4
805

805

C76

C76
10U

10U

4

4
805

805

C71

C71
10U

10U

4

4
805

805

C67

C67
10U

10U

4

4
805

805

8 inside cavity, north side, secondary layer.

+VCC_CORE

C58

C59

C60

C60
10U

10U

4

4
805

805

B B

+VCC_CORE

C80

C80
10U

10U

4

4
805

805

C59
10U

10U

4

4
805

805

C81

C81
10U

10U

4

4
805

805

C58
10U

10U

4

4
805

805

C53

C53
10U

10U

4

4
805

805

C61

C61
10U

10U

4

4
805

805

C54

C54
10U

10U

4

4
805

805

C55

C55
10U

10U

4

4
805

805

C62

C62
10U

10U

4

4
805

805

8 inside cavity, south side, secondary layer.

+VCC_CORE

C564

C563

C563
10U

10U

4

4
805

805

C564
10U

10U

4

4
805

805

C565

C565
10U

10U

4

4
805

805

C566

C566
10U

10U

4

4
805

805

C567

C567
10U

10U

4

4
805

805

C568

C568
10U

10U

4

4
805

805

6 inside cavity, north side, primary layer.

+VCC_CORE

C C

C570

C570
10U

10U

4

4
805

805

C571

C571
10U

10U

4

4
805

805

C572

C572
10U

10U

4

4
805

805

C573

C573
10U

10U

4

4
805

805

C574

C574
10U

10U

4

4
805

805

C575

C575
10U

10U

4

4
805

805

6 inside cavity, south side, primary layer.

+PWR_SRC

+1.05V_VCCP

+

+

C558

C558
100U

C66

C68

C69

C69

0.1U

0.1U

10

10

Layout out:

D D

Place these inside socket cavity on North side secondary.

C64

C64

0.1U

0.1U

10

10

C68

0.1U

0.1U

10

10

C66

0.1U

0.1U

10

10

C63

C63

0.1U

0.1U

10

10

C65

C65

0.1U

0.1U

10

10

100U

25

25

Layout Note:
Need to add 100uF cap on PWR_SRC for cap singing.
Place on PWR_SRC near +VCC_CORE.

U27C

U27C

A7

VCC[001]
VCC[002]
VCC[003]
VCC[004]
VCC[005]
VCC[006]
VCC[007]
VCC[008]
VCC[009]
VCC[010]
VCC[011]
VCC[012]
VCC[013]
VCC[014]
VCC[015]
VCC[016]
VCC[017]
VCC[018]
VCC[019]
VCC[020]
VCC[021]
VCC[022]
VCC[023]
VCC[024]
VCC[025]
VCC[026]
VCC[027]
VCC[028]
VCC[029]
VCC[030]
VCC[031]
VCC[032]
VCC[033]
VCC[034]
VCC[035]
VCC[036]
VCC[037]
VCC[038]
VCC[039]
VCC[040]
VCC[041]
VCC[042]
VCC[043]
VCC[044]
VCC[045]
VCC[046]
VCC[047]
VCC[048]
VCC[049]
VCC[050]

VCC[052]
VCC[053]
VCC[054]
VCC[055]
VCC[056]
VCC[057]
VCC[058]
VCC[059]
VCC[060]
VCC[061]
VCC[062]
VCC[063]
VCC[064]

VCCSENSE
VCC[065]
VCC[066]
VCC[067]

VSSSENSE

Penryn_uFCPGA479

Penryn_uFCPGA479

+PWR_SRC

VCC[068]
VCC[069]
VCC[070]
VCC[071]
VCC[072]
VCC[073]
VCC[074]
VCC[075]
VCC[076]
VCC[077]
VCC[078]
VCC[079]
VCC[080]
VCC[081]
VCC[082]
VCC[083]
VCC[084]
VCC[085]
VCC[086]
VCC[087]
VCC[088]
VCC[089]
VCC[090]
VCC[091]
VCC[092]
VCC[093]
VCC[094]
VCC[095]
VCC[096]
VCC[097]
VCC[098]
VCC[099]
VCC[100]

VCCP[01]
VCCP[02]
VCCP[03]
VCCP[04]
VCCP[05]
VCCP[06]
VCCP[07]
VCCP[08]
VCCP[09]
VCCP[10]
VCCP[11]
VCCP[12]
VCCP[13]
VCCP[14]
VCCP[15]
VCCP[16]

VCCA[01]
VCCA[02]

VID[0]
VID[1]
VID[2]
VID[3]
VID[4]
VID[5]
VID[6]

A9
A10
A12
A13
A15
A17
A18
A20

B7

B9
B10
B12
B14
B15
B17
B18
B20

C9
C10
C12
C13
C15
C17
C18

D9
D10
D12
D14
D15
D17
D18

E7

E9
E10
E12
E13
E15
E17
E18
E20

F7

F9
F10
F12
F14
F15
F17
F18
F20

AA9

AA10
AA12
AA13
AA15
AA17
AA18
AA20

AB9

AC10
AB10
AB12
AB14
AB15
AB17
AB18

Gur_0808: change U27 from

DGG^9000001 to DGG^9000002

39

+

+

C557

C557
100U

100U

25

25

AB20
AB7
AC7
AC9
AC12
AC13
AC15
AC17
AC18
AD7
AD9
AD10
AD12
AD14
AD15
AD17
AD18
AE9
AE10
AE12
AE13
AE15
AE17
AE18
AE20
AF9
AF10
AF12
AF14
AF15
AF17
AF18
AF20

G21
V6
J6
K6
M6
J21
K21
M21
N21
N6
R21
R6
T21
T6
V21
W21

B26
C26

AD6
AF5
AE5
AF4
AE3
AF3
AE2

AF7

AE7

.

.

+

+

C562

C562
*100U_NC

*100U_NC

25

25

T91T91

+VCCSENSE

+VSSSENSE

T96T96

+1.05V_VCCP

T28T28

+

+

VID0 (51)
VID1 (51)
VID2 (51)
VID3 (51)
VID4 (51)
VID5 (51)
VID6 (51)

+VCCSENSE (51)

+VSSSENSE (51)

+

+

C576

C576
*100U_NC

*100U_NC

25

25

C577

C577
220U

220U

4

4

C77

C77

0.01U

0.01U

25

25

Layout Note:
Place C194 near PIN
B26.

+VCC_CORE

+VCCSENSE
+VSSSENSE

Route VCCSENSE and VSSSENSE
traces at 27.4ohms and
length matched to within 25
mil. Place PU and PD within
2 inch of CPU.

+1.5V_RUN

R52

R52
100/F

100/F

R51

R51
100/F

100/F

C78

C78
10U

10U

4

4

U27D

U27D

A4

VSS[001]

A8

VSS[002]

A11

VSS[003]

A14

VSS[004]

A16

VSS[005]

A19

VSS[006]

A23

VSS[007]

AF2

VSS[008]

B6

VSS[009]

B8

VSS[010]

B11

VSS[011]

B13

VSS[012]

B16

VSS[013]

B19

VSS[014]

B21

VSS[015]

B24

VSS[016]

C5

VSS[017]

C8

VSS[018]

C11

VSS[019]

C14

VSS[020]

C16

VSS[021]

C19

VSS[022]

C2

VSS[023]

C22

VSS[024]

C25

VSS[025]

D1

VSS[026]

D4

VSS[027]

D11

VSS[029]

D13

VSS[030]

D16

VSS[031]

D19

VSS[032]

D23

VSS[033]

D26

VSS[034]

E3

VSS[035]

E6

VSS[036]

E8

VSS[037]

E11

VSS[038]

E14

VSS[039]

E16

VSS[040]

E19

VSS[041]

E21

VSS[042]

E24

VSS[043]

F5

VSS[044]

F11

VSS[046]

F13

VSS[047]

F16

VSS[048]

F19

VSS[049]

F2

VSS[050]

F22

VSS[051]

F25

VSS[052]

G4

VSS[053]

G1

VSS[054]

G23

VSS[055]

G26

VSS[056]

H3

VSS[057]

H6

VSS[058]

H21

VSS[059]

H24

VSS[060]

J2

VSS[061]

J5

VSS[062]

J22

VSS[063]

J25

VSS[064]

K1

VSS[065]

K4

VSS[066]

K23

VSS[067]

K26

VSS[068]

L3

VSS[069]

L6

VSS[070]

L21

VSS[071]

L24

VSS[072]

M2

VSS[073]

M5

VSS[074]

M22

VSS[075]

M25

VSS[076]

N1

VSS[077]

N4

VSS[078]

N23

VSS[079]

N26

VSS[080]
VSS[081]P3VSS[162]

Penryn_uFCPGA479

Penryn_uFCPGA479

Gur_0808: change U27 from
DGG^9000001 to DGG^9000002

VSS[082]
VSS[083]
VSS[084]
VSS[085]
VSS[086]
VSS[087]
VSS[088]
VSS[089]
VSS[090]
VSS[091]
VSS[092]
VSS[093]
VSS[094]
VSS[095]
VSS[096]
VSS[097]
VSS[098]
VSS[099]
VSS[100]
VSS[101]
VSS[102]
VSS[103]
VSS[104]
VSS[105]
VSS[106]
VSS[107]
VSS[108]
VSS[109]
VSS[110]

VSS[112]
VSS[113]
VSS[114]
VSS[115]
VSS[116]
VSS[117]
VSS[118]
VSS[119]
VSS[120]
VSS[121]
VSS[122]
VSS[123]
VSS[124]
VSS[125]
VSS[126]
VSS[127]
VSS[128]

VSS[130]
VSS[131]
VSS[132]
VSS[133]
VSS[134]
VSS[135]
VSS[136]
VSS[137]
VSS[138]
VSS[139]
VSS[140]
VSS[141]
VSS[142]
VSS[143]
VSS[144]
VSS[145]
VSS[146]

VSS[148]
VSS[149]
VSS[150]
VSS[151]
VSS[152]
VSS[153]
VSS[154]
VSS[155]
VSS[156]
VSS[157]
VSS[158]
VSS[159]
VSS[160]
VSS[161]

VSS[163]

P6
P21
P24
R2
R5
R22
R25
T1
T4
T23
T26
U3
U6
U21
U24
V2
V5
V22
V25
W1
W4
W23
W26
Y3
Y6
Y21
Y24
AA2
AA5

AA11
AA14
AA16
AA19
AA22
AA25
AB1
AB4
AB8
AB11
AB13
AB16
AB19
AB23
AB26
AC3
AC6

AC11
AC14
AC16
AC19
AC21
AC24
AD2
AD5
AD8
AD11
AD13
AD16
AD19
AD22
AD25
AE1
AE4

AE11
AE14
AE16
AE19

.

.

AE23
AE26
A2
AF6
AF8
AF11
AF13
AF16
AF19
AF21
A25
AF25

1

2

3

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

4

5

6

Date: Sheet

COMPUTER

Penryn (POWER/NC)

Penryn (POWER/NC)

Penryn (POWER/NC)

RM2 3A

RM2 3A

RM2 3A

7

of

of

of

459Friday, August 08, 2008

459Friday, August 08, 2008

459Friday, August 08, 2008

8

1

http://hobi-elektronika.net

A A

B B

C C

+1.05V_VCCP

12

R442

R442
221/F

221/F

H_SWING

12

R441

R441
100/F

100/F

12

R71

R71

24.9/F

24.9/F

Layout Note:
H_RCOMP trace should be
10-mil wide with 20-mil
spacing.

H_RCOMP

2

Layout Note:

C590

C590

0.1uF place close

0.1U/10V

0.1U/10V

1 2

to pin C5

H_D#[0..63](3)

+1.05V_VCCP

1 2

12

R443

R443
1K/F

1K/F

R445

R445
2K/F

2K/F

3

Gur_0808: 0 ohm
removal, delete R81

H_RESET#(3)

H_CPUSLP#(3)

H_REF

12

C597

C597

0.1U/10V

0.1U/10V

H_D#0
H_D#1
H_D#2
H_D#3
H_D#4
H_D#5
H_D#6
H_D#7
H_D#8
H_D#9
H_D#10
H_D#11
H_D#12
H_D#13
H_D#14
H_D#15
H_D#16
H_D#17
H_D#18
H_D#19
H_D#20
H_D#21
H_D#22
H_D#23
H_D#24
H_D#25
H_D#26
H_D#27
H_D#28
H_D#29
H_D#30
H_D#31
H_D#32
H_D#33
H_D#34
H_D#35
H_D#36
H_D#37
H_D#38
H_D#39
H_D#40
H_D#41
H_D#42
H_D#43
H_D#44
H_D#45
H_D#46
H_D#47
H_D#48
H_D#49
H_D#50
H_D#51
H_D#52
H_D#53
H_D#54
H_D#55
H_D#56
H_D#57
H_D#58
H_D#59
H_D#60
H_D#61
H_D#62
H_D#63

H_SWING
H_RCOMP

4

M11

N12

P13

N10

AD14

Y10
Y12
Y14

AA8

AA13

AA9
AA11
AD11
AD10
AD13
AE12

AE9

AA2

AD8

AA3

AD3

AD7
AE14

AF3

AC1

AE3

AC3
AE11

AE8

AG2

AD6

C12

E11

A11
B11

F2

G8

F8

E6
G2
H6
H2

F6
D4
H3
M9

J1

J2

J6

P2

L2
R2
N9

L6
M5

J3
N2
R1
N5
N6

N8

L7

M3

Y3

Y6

Y7

W2

Y9

C5

E3

U30A

U30A

H_D#_0
H_D#_1
H_D#_2
H_D#_3
H_D#_4
H_D#_5
H_D#_6
H_D#_7
H_D#_8
H_D#_9
H_D#_10
H_D#_11
H_D#_12
H_D#_13
H_D#_14
H_D#_15
H_D#_16
H_D#_17
H_D#_18
H_D#_19
H_D#_20
H_D#_21
H_D#_22
H_D#_23
H_D#_24
H_D#_25
H_D#_26
H_D#_27
H_D#_28
H_D#_29
H_D#_30
H_D#_31
H_D#_32
H_D#_33
H_D#_34
H_D#_35
H_D#_36
H_D#_37
H_D#_38
H_D#_39
H_D#_40
H_D#_41
H_D#_42
H_D#_43
H_D#_44
H_D#_45
H_D#_46
H_D#_47
H_D#_48
H_D#_49
H_D#_50
H_D#_51
H_D#_52
H_D#_53
H_D#_54
H_D#_55
H_D#_56
H_D#_57
H_D#_58
H_D#_59
H_D#_60
H_D#_61
H_D#_62
H_D#_63

H_SWING
H_RCOMP

H_CPURST#
H_CPUSLP#

H_AVREF
H_DVREF

CANTIGA_verB3

CANTIGA_verB3

5

H_ADSTB#_0
H_ADSTB#_1

HOST

HOST

H_DSTBN#_0
H_DSTBN#_1
H_DSTBN#_2
H_DSTBN#_3

H_DSTBP#_0
H_DSTBP#_1
H_DSTBP#_2
H_DSTBP#_3

H_A#_3
H_A#_4
H_A#_5
H_A#_6
H_A#_7
H_A#_8

H_A#_9
H_A#_10
H_A#_11
H_A#_12
H_A#_13
H_A#_14
H_A#_15
H_A#_16
H_A#_17
H_A#_18
H_A#_19
H_A#_20
H_A#_21
H_A#_22
H_A#_23
H_A#_24
H_A#_25
H_A#_26
H_A#_27
H_A#_28
H_A#_29
H_A#_30
H_A#_31
H_A#_32
H_A#_33
H_A#_34
H_A#_35

H_ADS#

H_BNR#

H_BPRI#

H_BREQ#

H_DEFER#

H_DBSY#

HPLL_CLK

HPLL_CLK#

H_DPWR#

H_DRDY#

H_HIT#

H_HITM#

H_LOCK#
H_TRDY#

H_DINV#_0
H_DINV#_1
H_DINV#_2
H_DINV#_3

H_REQ#_0
H_REQ#_1
H_REQ#_2
H_REQ#_3
H_REQ#_4

H_RS#_0
H_RS#_1
H_RS#_2

A14
C15
F16
H13
C18
M16
J13
P16
R16
N17
M13
E17
P17
F17
G20
B19
J16
E20
H16
J20
L17
A17
B17
L16
C21
J17
H20
B18
K17
B20
F21
K21
L20

H12
B16
G17
A9
F11
G12
E9
B10
AH7
AH6
J11
F9
H9
E12
H11
C9

J8
L3
Y13
Y1

L10
M7
AA5
AE6

L9
M8
AA6
AE5

B15
K13
F13
B13
B14

B6
F12
C8

H_A#3
H_A#4
H_A#5
H_A#6
H_A#7
H_A#8
H_A#9
H_A#10
H_A#11
H_A#12
H_A#13
H_A#14
H_A#15
H_A#16
H_A#17
H_A#18
H_A#19
H_A#20
H_A#21
H_A#22
H_A#23
H_A#24
H_A#25
H_A#26
H_A#27
H_A#28
H_A#29
H_A#30
H_A#31
H_A#32
H_A#33
H_A#34
H_A#35

6

H_A#[3..35] (3)

H_ADS# (3)
H_ADSTB#0 (3)
H_ADSTB#1 (3)
H_BNR# (3)
H_BPRI# (3)
H_BR0# (3)
H_DEFER# (3)
H_DBSY# (3)
CLK_MCH_BCLK (17)
CLK_MCH_BCLK# (17)
H_DPWR# (3)
H_DRDY# (3)
H_HIT# (3)
H_HITM# (3)
H_LOCK# (3)
H_TRDY# (3)

H_DINV#0 (3)
H_DINV#1 (3)
H_DINV#2 (3)
H_DINV#3 (3)

H_DSTBN#0 (3)
H_DSTBN#1 (3)
H_DSTBN#2 (3)
H_DSTBN#3 (3)

H_DSTBP#0 (3)
H_DSTBP#1 (3)
H_DSTBP#2 (3)
H_DSTBP#3 (3)

H_REQ#0 (3)
H_REQ#1 (3)
H_REQ#2 (3)
H_REQ#3 (3)
H_REQ#4 (3)

H_RS#0 (3)
H_RS#1 (3)
H_RS#2 (3)

7

8

Layout Note:
Place the 0.1 uF

D D

1

2

decoupling capacitor
within 100 mils from
GMCH pins.

3

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

4

5

6

Date: Sheet

COMPUTER

Cantiga_A (HOST)

Cantiga_A (HOST)

Cantiga_A (HOST)

RM2 3A

RM2 3A

RM2 3A

7

of

of

of

559Friday, August 08, 2008

559Friday, August 08, 2008

559Friday, August 08, 2008

8

1

http://hobi-elektronika.net

+1.5V_DDR

R120

R120
1K/F

SM_RCOMP_VOH

C139

C139

0.01U

0.01U

25

25

A A

SM_RCOMP_VOL

C146

C146

0.01U

0.01U

25

25

+3.3V_RUN

R122 10KR122 10K
R126 10KR126 10K

+1.05V_VCCP

R84 56R84 56

B B

+3.3V_RUN

C C

Gur_0808: 0 ohm removal, delete R125

D D

1K/F

C136

C136

2.2U

2.2U

R115

R115

10

10

3.01K

3.01K

C147

C147

2.2U

2.2U

R118

R118

10

10

1K/F

1K/F

PM_EXTTS#0
PM_EXTTS#1

THERMTRIP_MCH#

Layout Note:
Location of all MCH_CFG strap
resistors needs to be close to
minmize stub.

CPU_MCH_BSEL0(3,17)
CPU_MCH_BSEL1(3,17)
CPU_MCH_BSEL2(3,17)

1

T30

T30

PAD

PAD

T38

T38

PAD

PAD

R104 *2.21K/F_NCR104 *2.21K/F_NC

12

T36

T36

PAD

PAD

T39

T39

PAD

PAD

T33

T33

PAD

PAD

R95 *2.21K/F_NCR95 *2.21K/F_NC

12

T112

T112

PAD

PAD

T34

T34

PAD

PAD

T32

T32

PAD

PAD

T35

T35

PAD

PAD

T29

T29

PAD

PAD

T31

T31

PAD

PAD

R96 *2.21K/F_NCR96 *2.21K/F_NC

12

T37

T37

PAD

PAD

T40

T40

PAD

PAD

R116 *4.02K_NCR116 *4.02K_NC
R108 *4.02K_NCR108 *4.02K_NC

PM_BMBUSY#(13)

H_DPRSTP#(3,11,51)
PM_EXTTS#0(15)
PM_EXTTS#1(16)
ICH_PWRGD(13,45)

DPRSLPVR(13,51)

T128

T128

PAD

PAD

T131

T131

PAD

PAD

T129

T129

PAD

PAD

T127

T127

PAD

PAD

T126

T126

PAD

PAD

T125

T125

PAD

PAD

T132

T132

PAD

PAD

T124

T124

PAD

PAD

T48

T48

PAD

PAD

T122

T122

PAD

PAD

T121

T121

PAD

PAD

T123

T123

PAD

PAD

T111

T111

PAD

PAD

T110

T110

PAD

PAD

T108

T108

PAD

PAD

T109

T109

PAD

PAD

SB_NB_PCIE_RST#(12)

PLTRST#(12,30,31,33,34,43)

CFG3
CFG4
CFG5
CFG6
CFG7
CFG8
CFG9
CFG10
CFG11
CFG12
CFG13
CFG14
CFG15
CFG16
CFG17
CFG18
CFG19
CFG20

PM_EXTTS#0
PM_EXTTS#1

PLTRST#_R
THERMTRIP_MCH#

R75 *0_NCR75 *0_NC

R73 0R73 0

AH10
AH12
AH13

AL34
AK34
AN35
AM35

AY21

BG23
BF23
BH18
BF18

AT40
AT11

BG48
BF48
BD48
BC48
BH47
BG47
BE47
BH46
BF46
BG45
BH44
BH43

M36

N36
R33
T33

AH9

K12

T24

B31
AJ6

M1

A47

T25
R25
P25
P20
P24
C25
N24

M24

E21
C23
C24
N21
P21
T21
R20

M20

L21
H21
P29
R28
T28

R29

B7
N33
P32

T20
R32

BH6
BH5
BG4
BH3

BF3

BH2
BG2
BE2
BG1

BF1

BD1
BC1

F1

2

U30B

U30B

RSVD1
RSVD2
RSVD3
RSVD4
RSVD5
RSVD6
RSVD7
RSVD8
RSVD9
RSVD10
RSVD11
RSVD12
RSVD13
RSVD14

RSVD15
RSVD16
RSVD17

RSVD20

RSVD21
RSVD22
RSVD23
RSVD24
RSVD25

CFG_0
CFG_1
CFG_2
CFG_3
CFG_4
CFG_5
CFG_6
CFG_7
CFG_8
CFG_9
CFG_10
CFG_11
CFG_12
CFG_13
CFG_14
CFG_15
CFG_16
CFG_17
CFG_18
CFG_19
CFG_20

PM_SYNC #
PM_DPRS TP#
PM_EXT_TS#_0
PM_EXT_TS#_1
PWRO K
RSTIN#
THERMTRIP#
DPRSLPVR

NC_1
NC_2
NC_3
NC_4
NC_5
NC_6
NC_7
NC_8
NC_9
NC_10
NC_11
NC_12
NC_13
NC_14
NC_15
NC_16
NC_17
NC_18
NC_19
NC_20
NC_21
NC_22
NC_23
NC_24
NC_25

CANTIGA_verB3

CANTIGA_verB3

R80 100R80 100

2

NC

NC

PLTRST#_R

3

AP24

SA_CK_0

AT21

SA_CK_1

AV24

SB_CK_0

AU20

SB_CK_1

AR24

SA_CK#_0

AR21

SA_CK#_1

AU24

SB_CK#_0

AV20

SB_CK#_1

BC28

SA_CKE_0

AY28

SA_CKE_1

AY36

SB_CKE_0

RSVD

RSVD

SM_RCOMP_VOH
SM_RCOMP_VOL

DDR CONTROL/COMPENSATION

DDR CONTROL/COMPENSATION

DPLL_REF_CLK#

DPLL_REF_SSCLK

DPLL_REF_SSCLK#

CLK

CLK

CFG

CFG

DMI

DMI

PM

PM

GRAPHICS VID

GRAPHICS VID

MEHDA

MEHDA

DDPC_CTRLCLK

DDPC_CTRLDATA

SDVO_CTRLCLK

SDVO_CTRLDATA

MISC

MISC

SB_CKE_1

SA_CS#_0
SA_CS#_1
SB_CS#_0
SB_CS#_1

SA_ODT_0
SA_ODT_1
SB_ODT_0
SB_ODT_1

SM_RCOMP

SM_RCOMP#

SM_VREF

SM_PWROK

SM_REXT

SM_DRAMRST#

DPLL_REF_CLK

PEG_CLK

PEG_CLK #

DMI_RXN_0
DMI_RXN_1
DMI_RXN_2
DMI_RXN_3

DMI_RXP_0
DMI_RXP_1
DMI_RXP_2
DMI_RXP_3

DMI_TXN_0
DMI_TXN_1
DMI_TXN_2
DMI_TXN_3

DMI_T XP_0
DMI_T XP_1
DMI_T XP_2
DMI_T XP_3

GFX_VID _0
GFX_VID _1
GFX_VID _2
GFX_VID _3
GFX_VID _4

GFX_VR_ EN

CL_CLK

CL_DATA

CL_PWROK

CL_RST#
CL_VREF

CLKREQ#

ICH_SYNC#

TSATN

HDA_BCLK
HDA_RST#

HDA_SDI

HDA_SDO

HDA_SYNC

BB36

BA17
AY16
AV16
AR13

BD17
AY17
BF15
AY13

BG22
BH21

BF28
BH28

AV42
AR36
BF17
BC36

B38
A38
E41
F41

F43
E43

AE41
AE37
AE47
AH39

AE40
AE38
AE48
AH40

AE35
AE43
AE46
AH42

AD35
AE44
AF46
AH43

B33
B32
G33
F33
E33

C34

AH37
AH36
AN36
AJ35
AH34

N28
M28
G36
E36
K36
H36

B12

B28
B30
B29
C29
A28

SMRCOMPP
SMRCOMPN

SM_RCOMP_VOH
SM_RCOMP_VOL

SM_PWROK

12

R88 499/FR88 499/F

T115 PADT115 PAD
T113 PADT113 PAD
T41 PADT41 PAD
T117 PADT117 PAD
T114 PADT114 PAD

T118 PADT118 PAD

CL_CLK0 (13)
CL_DATA0 (13)
ICH_CL_PWROK (13,31)

ICH_CL_RST0# (13)

MCH_CLVREF

CLK_3GPLLREQ# (17)
MCH_ICH_SY NC# (13 )

R449 56R449 56

3

M_CLK_DDR0 (15)
M_CLK_DDR1 (15)
M_CLK_DDR3 (16)
M_CLK_DDR4 (16)

M_CLK_DDR#0 (15)
M_CLK_DDR#1 (15)
M_CLK_DDR#3 (16)
M_CLK_DDR#4 (16)

DDR_CKE0_DIMMA (15)
DDR_CKE1_DIMMA (15)
DDR_CKE3_DIMMB (16)
DDR_CKE4_DIMMB (16)

DDR_CS0_DIMMA# (15)
DDR_CS1_DIMMA# (15)
DDR_CS2_DIMMB# (16)
DDR_CS3_DIMMB# (16)

M_ODT0 (15)
M_ODT1 (15)
M_ODT2 (16)
M_ODT3 (16)

CLK_MCH_3GPLL (17)
CLK_MCH_3GPLL# (17)

DMI_MRX_ITX_N0 (12)
DMI_MRX_ITX_N1 (12)
DMI_MRX_ITX_N2 (12)
DMI_MRX_ITX_N3 (12)

DMI_M RX_ITX_ P0 (12)
DMI_M RX_ITX_ P1 (12)
DMI_M RX_ITX_ P2 (12)
DMI_M RX_ITX_ P3 (12)

DMI_MTX_IRX_N0 (12)
DMI_MTX_IRX_N1 (12)
DMI_MTX_IRX_N2 (12)
DMI_MTX_IRX_N3 (12)

DMI_M TX_IRX_ P0 (12)
DMI_M TX_IRX_ P1 (12)
DMI_M TX_IRX_ P2 (12)
DMI_M TX_IRX_ P3 (12)

+V_DDR_MCH_REF

DDR3_DRAMRST# (15,16)

+1.05V_VCCP

4

SMRCOMPP
SMRCOMPN

R311

R311

12.1K/F

12.1K/F

SM_PWROK

R131

R131
10K/F

10K/F

+1.05V_VCCP

Non-iAMT

MCH_CLVREF

12

C158

C158

0.1U

0.1U

CL_VREF~=0.35V

4

R124

R124
1K/F

1K/F

R128

R128
499/F

499/F

+1.5V_DDR

12

R93

R93

80.6/F

80.6/F

12

R94

R94

80.6/F

80.6/F

SM_PWROK_R

1.5V

4

U12

U12
74AHC1G08GW

74AHC1G08GW

+3.3V_ALW

3 5

2

1

5

1.5V_DDR_PWRGD (45,49)

5

CFG5

CFG9

CFG16

CFG19

CFG20

SDVO_CRTL_DATA

U30C

U30C

L32

L_BKLT_CTRL

G32

L_BKLT_EN

M32

L_CTRL_CLK

M33

L_CTRL_DATA

K33

L_DDC_CLK

J33

L_DDC_DATA

M29

L_VDD_EN

C44

LVDS_IBG

B43

LVDS_VBG

E37

LVDS_VREFH

E38

LVDS_VREFL

C41

LVDSA_CLK#

C40

LVDSA_CLK

B37

LVDSB_CLK#

A37

LVDSB_CLK

H47

LVDSA_DATA#_0

E46

LVDSA_DATA#_1

G40

LVDSA_DATA#_2

A40

LVDSA_DATA#_3

H48

LVDSA_DATA_0

D45

LVDSA_DATA_1

F40

LVDSA_DATA_2

B40

LVDSA_DATA_3

A41

LVDSB_DATA#_0

H38

LVDSB_DATA#_1

G37

LVDSB_DATA#_2

J37

LVDSB_DATA#_3

B42

LVDSB_DATA_0

G38

LVDSB_DATA_1

F37

LVDSB_DATA_2

K37

LVDSB_DATA_3

F25

TVA_DAC

H25

TVB_DAC

K25

TVC_DAC

H24

TV_RTN

C31

TV_DCONSEL_0

E32

TV_DCONSEL_1

E28

CRT_BLUE

G28

CRT_GREEN

J28

CRT_RED

G29

CRT_IRTN

H32

CRT_DDC_CLK

J32

CRT_DDC_DATA

J29

CRT_HSYNC

E29

CRT_TVO_IREF

L29

CRT_VSYNC

CANTIGA_verB3

CANTIGA_verB3

DMI X2 Select

PCI Express
Graphic Lane

FSB Dynamic
ODT

DMI Lane
Reversal

SDVO/PCIE
Concurrent
Operation

SDVO Present.

6

PEG_COM PI

PEG_COM PO

PEG_RX#_0
PEG_RX#_1
PEG_RX#_2
PEG_RX#_3
PEG_RX#_4
PEG_RX#_5
PEG_RX#_6

LVDS

LVDS

TV

TV

Low=DMIx2
High=DMIx4(Default)

Low= Reveise Lane
High=Normal operation

Low=Dynamic ODT Disable
High=Dynamic ODT Enable(default).

Low=Normal(default).
High=Lane Reversed

Low=Only SDVO or PCIEx1 is
operational (defaults)
High=SDVO and PCIEx1 are operating
simultaneously via PEG port

Low=No SDVO Device Present
(default)
High=SDVO Device Present

6

PEG_RX#_7
PEG_RX#_8

PEG_RX#_9
PEG_RX#_10
PEG_RX#_11
PEG_RX#_12
PEG_RX#_13
PEG_RX#_14
PEG_RX#_15

PEG_RX_0
PEG_RX_1
PEG_RX_2
PEG_RX_3
PEG_RX_4
PEG_RX_5
PEG_RX_6
PEG_RX_7
PEG_RX_8

PEG_RX_9
PEG_RX_10
PEG_RX_11
PEG_RX_12
PEG_RX_13
PEG_RX_14
PEG_RX_15

PEG_TX#_0
PEG_TX#_1
PEG_TX#_2
PEG_TX#_3
PEG_TX#_4
PEG_TX#_5
PEG_TX#_6
PEG_TX#_7
PEG_TX#_8
PEG_TX#_9

PEG_TX#_10
PEG_TX#_11

PCI-EXPRESS GRAPHICS

PCI-EXPRESS GRAPHICS

PEG_TX#_12
PEG_TX#_13
PEG_TX#_14
PEG_TX#_15

PEG_TX_0

PEG_TX_1

PEG_TX_2

PEG_TX_3

VGA

VGA

PEG_TX_4

PEG_TX_5

PEG_TX_6

PEG_TX_7

PEG_TX_8

PEG_TX_9
PEG_TX_10
PEG_TX_11
PEG_TX_12
PEG_TX_13
PEG_TX_14
PEG_TX_15

+VCC3G_PCIE_R

T37
T36

PCIE_MRX_GTX_N0PCIE_MRX_GTX_N0

H44

PCIE_MRX_GTX_N1

J46

PCIE_MRX_GTX_N2PCIE_MRX_GTX_N2

L44

PCIE_MRX_GTX_N3PCIE_MRX_GTX_N3

L40

PCIE_MRX_GTX_N4PCIE_MRX_GTX_N4

N41

PCIE_MRX_GTX_N5PCIE_MRX_GTX_N5

P48

PCIE_MRX_GTX_N6PCIE_MRX_GTX_N6

N44

PCIE_MRX_GTX_N7PCIE_MRX_GTX_N7

T43

PCIE_MRX_GTX_N8PCIE_MRX_GTX_N8

U43

PCIE_MRX_GTX_N9PCIE_MRX_GTX_N9

Y43

PCIE_MRX_GTX_N10PCIE_MRX_GTX_N10

Y48

PCIE_MRX_GTX_N11PCIE_MRX_GTX_N11

Y36

PCIE_MRX_GTX_N12PCIE_MRX_GTX_N12

AA43

PCIE_MRX_GTX_N13PCIE_MRX_GTX_N13

AD37

PCIE_MRX_GTX_N14PCIE_MRX_GTX_N14

AC47

PCIE_MRX_GTX_N15PCIE_MRX_GTX_N15

AD39

PCIE_MRX_GTX_P0PCIE_MRX_GTX_P0

H43

PCIE_MRX_GTX_P1

J44

PCIE_MRX_GTX_P2PCIE_MRX_GTX_P2

L43

PCIE_MRX_GTX_P3PCIE_MRX_GTX_P3

L41

PCIE_MRX_GTX_P4PCIE_MRX_GTX_P4

N40

PCIE_MRX_GTX_P5PCIE_MRX_GTX_P5

P47

PCIE_MRX_GTX_P6PCIE_MRX_GTX_P6

N43

PCIE_MRX_GTX_P7PCIE_MRX_GTX_P7

T42

PCIE_MRX_GTX_P8PCIE_MRX_GTX_P8

U42

PCIE_MRX_GTX_P9PCIE_MRX_GTX_P9

Y42

PCIE_MRX_GTX_P10PCIE_MRX_GTX_P10

W47

PCIE_MRX_GTX_P11PCIE_MRX_GTX_P11

Y37

PCIE_MRX_GTX_P12PCIE_MRX_GTX_P12

AA42

PCIE_MRX_GTX_P13PCIE_MRX_GTX_P13

AD36

PCIE_MRX_GTX_P14PCIE_MRX_GTX_P14

AC48

PCIE_MRX_GTX_P15PCIE_MRX_GTX_P15

AD40

PCIE_MTX_GRX_C_N0PCIE_MTX_GRX_C_N0

J41

PCIE_MTX_GRX_C_N1PCIE_MTX_GRX_C_N1

M46

PCIE_MTX_GRX_C_N2PCIE_MTX_GRX_C_N2

M47

PCIE_MTX_GRX_C_N3PCIE_MTX_GRX_C_N3

M40

PCIE_MTX_GRX_C_N4PCIE_MTX_GRX_C_N4

M42

PCIE_MTX_GRX_C_N5PCIE_MTX_GRX_C_N5

R48

PCIE_MTX_GRX_C_N6PCIE_MTX_GRX_C_N6

N38

PCIE_MTX_GRX_C_N7PCIE_MTX_GRX_C_N7

T40

PCIE_MTX_GRX_C_N8PCIE_MTX_GRX_C_N8

U37

PCIE_MTX_GRX_C_N9PCIE_MTX_GRX_C_N9

U40

PCIE_MTX_GRX_C_N10PCIE_MTX_GRX_C_N10

Y40

PCIE_MTX_GRX_C_N11PCIE_MTX_GRX_C_N11

AA46

PCIE_MTX_GRX_C_N12PCIE_MTX_GRX_C_N12

AA37

PCIE_MTX_GRX_C_N13PCIE_MTX_GRX_C_N13

AA40

PCIE_MTX_GRX_C_N14PCIE_MTX_GRX_C_N14

AD43

PCIE_MTX_GRX_C_N15PCIE_MTX_GRX_C_N15

AC46

PCIE_MTX_GRX_C_P0PCIE_MTX_GRX_C_P0

J42

PCIE_MTX_GRX_C_P1PCIE_MTX_GRX_C_P1

L46

PCIE_MTX_GRX_C_P2PCIE_MTX_GRX_C_P2

M48

PCIE_MTX_GRX_C_P3PCIE_MTX_GRX_C_P3

M39

PCIE_MTX_GRX_C_P4PCIE_MTX_GRX_C_P4

M43

PCIE_MTX_GRX_C_P5PCIE_MTX_GRX_C_P5

R47

PCIE_MTX_GRX_C_P6PCIE_MTX_GRX_C_P6

N37

PCIE_MTX_GRX_C_P7PCIE_MTX_GRX_C_P7

T39

PCIE_MTX_GRX_C_P8PCIE_MTX_GRX_C_P8

U36

PCIE_MTX_GRX_C_P9PCIE_MTX_GRX_C_P9

U39

PCIE_MTX_GRX_C_P10PCIE_MTX_GRX_C_P10

Y39

PCIE_MTX_GRX_C_P11PCIE_MTX_GRX_C_P11

Y46

PCIE_MTX_GRX_C_P12PCIE_MTX_GRX_C_P12

AA36

PCIE_MTX_GRX_C_P13PCIE_MTX_GRX_C_P13

AA39

PCIE_MTX_GRX_C_P14PCIE_MTX_GRX_C_P14

AD42

PCIE_MTX_GRX_C_P15PCIE_MTX_GRX_C_P15

AD46

7

+VCC_PEG

R130 49.9/FR130 49.9/F

1 2

PCIE_MRX_GTX_N[0..15] (18)

PCIE_MRX_GTX_P[0..15] (18)

C213 0.1UC213 0.1U
C631 0.1UC631 0.1U
C627 0.1UC627 0.1U
C190 0.1UC190 0.1U
C630 0.1UC630 0.1U
C626 0.1UC626 0.1U
C208 0.1UC208 0.1U
C211 0.1UC211 0.1U
C181 0.1UC181 0.1U
C206 0.1UC206 0.1U
C204 0.1UC204 0.1U
C216 0.1UC216 0.1U
C202 0.1UC202 0.1U
C201 0.1UC201 0.1U
C247 0.1UC247 0.1U
C215 0.1UC215 0.1U

C212 0.1UC212 0.1U
C632 0.1UC632 0.1U
C628 0.1UC628 0.1U
C182 0.1UC182 0.1U
C629 0.1UC629 0.1U
C625 0.1UC625 0.1U
C209 0.1UC209 0.1U
C210 0.1UC210 0.1U
C174 0.1UC174 0.1U
C207 0.1UC207 0.1U
C205 0.1UC205 0.1U
C217 0.1UC217 0.1U
C203 0.1UC203 0.1U
C200 0.1UC200 0.1U
C246 0.1UC246 0.1U
C214 0.1UC214 0.1U

Title

Title

Title

Cantiga_B (VGA,DMI)

Cantiga_B (VGA,DMI)

Cantiga_B (VGA,DMI)

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

RM2 3A

RM2 3A

RM2 3A

Date: Sheet

Date: Sheet

Date: Sheet

7

PCIE_MTX_GRX_N0
PCIE_MTX_GRX_N1
PCIE_MTX_GRX_N2
PCIE_MTX_GRX_N3
PCIE_MTX_GRX_N4
PCIE_MTX_GRX_N5
PCIE_MTX_GRX_N6
PCIE_MTX_GRX_N7
PCIE_MTX_GRX_N8
PCIE_MTX_GRX_N9
PCIE_MTX_GRX_N10
PCIE_MTX_GRX_N11
PCIE_MTX_GRX_N12
PCIE_MTX_GRX_N13
PCIE_MTX_GRX_N14
PCIE_MTX_GRX_N15

PCIE_MTX_GRX_P0
PCIE_MTX_GRX_P1
PCIE_MTX_GRX_P2
PCIE_MTX_GRX_P3
PCIE_MTX_GRX_P4
PCIE_MTX_GRX_P5
PCIE_MTX_GRX_P6
PCIE_MTX_GRX_P7
PCIE_MTX_GRX_P8
PCIE_MTX_GRX_P9
PCIE_MTX_GRX_P10
PCIE_MTX_GRX_P11
PCIE_MTX_GRX_P12
PCIE_MTX_GRX_P13
PCIE_MTX_GRX_P14
PCIE_MTX_GRX_P15

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

8

PCIE_MTX_GRX_N[0..15] (18)
PCIE_MTX_GRX_P[0..15] (18)

of

of

of

659Friday, August 08, 2008

659Friday, August 08, 2008

659Friday, August 08, 2008

8

1

http://hobi-elektronika.net

2

3

4

5

6

7

8

DDR_A_D[0..63](15)

A A

B B

C C

DDR_A_D0
DDR_A_D1
DDR_A_D2
DDR_A_D3
DDR_A_D4
DDR_A_D5
DDR_A_D6
DDR_A_D7
DDR_A_D8
DDR_A_D9
DDR_A_D10
DDR_A_D11
DDR_A_D12
DDR_A_D13
DDR_A_D14
DDR_A_D15
DDR_A_D16
DDR_A_D17
DDR_A_D18
DDR_A_D19
DDR_A_D20
DDR_A_D21
DDR_A_D22
DDR_A_D23
DDR_A_D24
DDR_A_D25
DDR_A_D26
DDR_A_D27
DDR_A_D28
DDR_A_D29
DDR_A_D30
DDR_A_D31
DDR_A_D32
DDR_A_D33
DDR_A_D34
DDR_A_D35
DDR_A_D36
DDR_A_D37
DDR_A_D38
DDR_A_D39
DDR_A_D40
DDR_A_D41
DDR_A_D42
DDR_A_D43
DDR_A_D44
DDR_A_D45
DDR_A_D46
DDR_A_D47
DDR_A_D48
DDR_A_D49
DDR_A_D50
DDR_A_D51
DDR_A_D52
DDR_A_D53
DDR_A_D54
DDR_A_D55
DDR_A_D56
DDR_A_D57
DDR_A_D58
DDR_A_D59
DDR_A_D60
DDR_A_D61
DDR_A_D62
DDR_A_D63

AJ38

AJ41
AN38
AM38

AJ36

AJ40
AM44
AM42
AN43
AN44
AU40
AT38
AN41
AN39
AU44
AU42
AV39
AY44
BA40
BD43
AV41
AY43
BB41
BC40
AY37
BD38
AV37
AT36
AY38
BB38
AV36

AW36

BD13
AU11
BC11
BA12
AU13
AV13
BD12
BC12

BB9
BA9

AU10

AV9

BA11

BD9
AY8
BA6
AV5
AV7
AT9
AN8
AU5
AU6

AT5
AN10
AM11

AM5

AJ9

AJ8
AN12
AM13

AJ11
AJ12

U30D

U30D

SA_DQ_0
SA_DQ_1
SA_DQ_2
SA_DQ_3
SA_DQ_4
SA_DQ_5
SA_DQ_6
SA_DQ_7
SA_DQ_8
SA_DQ_9
SA_DQ_10
SA_DQ_11
SA_DQ_12
SA_DQ_13
SA_DQ_14
SA_DQ_15
SA_DQ_16
SA_DQ_17
SA_DQ_18
SA_DQ_19
SA_DQ_20
SA_DQ_21
SA_DQ_22
SA_DQ_23
SA_DQ_24
SA_DQ_25
SA_DQ_26
SA_DQ_27
SA_DQ_28
SA_DQ_29
SA_DQ_30
SA_DQ_31
SA_DQ_32
SA_DQ_33
SA_DQ_34
SA_DQ_35
SA_DQ_36
SA_DQ_37
SA_DQ_38
SA_DQ_39
SA_DQ_40
SA_DQ_41
SA_DQ_42
SA_DQ_43
SA_DQ_44
SA_DQ_45
SA_DQ_46
SA_DQ_47
SA_DQ_48
SA_DQ_49
SA_DQ_50
SA_DQ_51
SA_DQ_52
SA_DQ_53
SA_DQ_54
SA_DQ_55
SA_DQ_56
SA_DQ_57
SA_DQ_58
SA_DQ_59
SA_DQ_60
SA_DQ_61
SA_DQ_62
SA_DQ_63

CANTIGA_verB3

CANTIGA_verB3

DDR_A_BS0

BD21

SA_BS_0
SA_BS_1
SA_BS_2

SA_RAS#
SA_CAS#

SA_WE#

SA_DM_0
SA_DM_1
SA_DM_2
SA_DM_3
SA_DM_4
SA_DM_5
SA_DM_6
SA_DM_7

SA_DQS_0
SA_DQS_1
SA_DQS_2
SA_DQS_3
SA_DQS_4
SA_DQS_5
SA_DQS_6

SA_DQS_7
SA_DQS#_0
SA_DQS#_1
SA_DQS#_2
SA_DQS#_3
SA_DQS#_4
SA_DQS#_5
SA_DQS#_6
SA_DQS#_7

SA_MA_0
SA_MA_1
SA_MA_2
SA_MA_3
SA_MA_4
SA_MA_5
SA_MA_6
SA_MA_7
SA_MA_8

SA_MA_9
SA_MA_10
SA_MA_11
SA_MA_12
SA_MA_13

DDR SYSTEM MEMORY A

DDR SYSTEM MEMORY A

SA_MA_14

BG18
AT25

BB20
BD20
AY20

AM37
AT41
AY41
AU39
BB12
AY6
AT7
AJ5

AJ44
AT44
BA43
BC37
AW12
BC8
AU8
AM7
AJ43
AT43
BA44
BD37
AY12
BD8
AU9
AM8

BA21
BC24
BG24
BH24
BG25
BA24
BD24
BG27
BF25
AW24
BC21
BG26
BH26
BH17
AY25

DDR_A_BS1
DDR_A_BS2

DDR_A_RAS#
DDR_A_CAS#
DDR_A_WE#

DDR_A_DM0
DDR_A_DM1
DDR_A_DM2
DDR_A_DM3
DDR_A_DM4
DDR_A_DM5
DDR_A_DM6
DDR_A_DM7

DDR_A_DQS0
DDR_A_DQS1
DDR_A_DQS2
DDR_A_DQS3
DDR_A_DQS4
DDR_A_DQS5
DDR_A_DQS6
DDR_A_DQS7
DDR_A_DQS#0
DDR_A_DQS#1
DDR_A_DQS#2
DDR_A_DQS#3
DDR_A_DQS#4
DDR_A_DQS#5
DDR_A_DQS#6
DDR_A_DQS#7

DDR_A_MA0
DDR_A_MA1
DDR_A_MA2
DDR_A_MA3
DDR_A_MA4
DDR_A_MA5
DDR_A_MA6
DDR_A_MA7
DDR_A_MA8
DDR_A_MA9
DDR_A_MA10
DDR_A_MA11
DDR_A_MA12
DDR_A_MA13
DDR_A_MA14

DDR_A_BS0 (15)
DDR_A_BS1 (15)
DDR_A_BS2 (15)

DDR_A_RAS# (15)
DDR_A_CAS# (15)
DDR_A_WE# (15)

DDR_A_DM[0..7] ( 15)

DDR_A_DQS[0..7] (15)

DDR_A_DQS#[0..7] (15)

DDR_A_MA[0..14] (15)

DDR_B_D[0..63](16)

DDR_B_D0
DDR_B_D1
DDR_B_D2
DDR_B_D3
DDR_B_D4
DDR_B_D5
DDR_B_D6
DDR_B_D7
DDR_B_D8
DDR_B_D9
DDR_B_D10
DDR_B_D11
DDR_B_D12
DDR_B_D13
DDR_B_D14
DDR_B_D15
DDR_B_D16
DDR_B_D17
DDR_B_D18
DDR_B_D19
DDR_B_D20
DDR_B_D21
DDR_B_D22
DDR_B_D23
DDR_B_D24
DDR_B_D25
DDR_B_D26
DDR_B_D27
DDR_B_D28
DDR_B_D29
DDR_B_D30
DDR_B_D31
DDR_B_D32
DDR_B_D33
DDR_B_D34
DDR_B_D35
DDR_B_D36
DDR_B_D37
DDR_B_D38
DDR_B_D39
DDR_B_D40
DDR_B_D41
DDR_B_D42
DDR_B_D43
DDR_B_D44
DDR_B_D45
DDR_B_D46
DDR_B_D47
DDR_B_D48
DDR_B_D49
DDR_B_D50
DDR_B_D51
DDR_B_D52
DDR_B_D53
DDR_B_D54
DDR_B_D55
DDR_B_D56
DDR_B_D57
DDR_B_D58
DDR_B_D59
DDR_B_D60
DDR_B_D61
DDR_B_D62
DDR_B_D63

AK47
AH46
AP47
AP46

AJ46

AJ48
AM48
AP48
AU47
AU46
BA48
AY48
AT47
AR47
BA47
BC47
BC46
BC44
BG43
BF43
BE45
BC41
BF40
BF41
BG38
BF38
BH35
BG35
BH40
BG39
BG34
BH34
BH14
BG12
BH11

BG8
BH12
BF11

BF8
BG7
BC5
BC6

AY3

AY1

BF6

BF5
BA1
BD3
AV2
AU3
AR3
AN2

AY2
AV1
AP3
AR1

AL1

AL2

AJ1
AH1
AM2
AM3
AH3

AJ3

U30E

U30E

SB_DQ_0
SB_DQ_1
SB_DQ_2
SB_DQ_3
SB_DQ_4
SB_DQ_5
SB_DQ_6
SB_DQ_7
SB_DQ_8
SB_DQ_9
SB_DQ_10
SB_DQ_11
SB_DQ_12
SB_DQ_13
SB_DQ_14
SB_DQ_15
SB_DQ_16
SB_DQ_17
SB_DQ_18
SB_DQ_19
SB_DQ_20
SB_DQ_21
SB_DQ_22
SB_DQ_23
SB_DQ_24
SB_DQ_25
SB_DQ_26
SB_DQ_27
SB_DQ_28
SB_DQ_29
SB_DQ_30
SB_DQ_31
SB_DQ_32
SB_DQ_33
SB_DQ_34
SB_DQ_35
SB_DQ_36
SB_DQ_37
SB_DQ_38
SB_DQ_39
SB_DQ_40
SB_DQ_41
SB_DQ_42
SB_DQ_43
SB_DQ_44
SB_DQ_45
SB_DQ_46
SB_DQ_47
SB_DQ_48
SB_DQ_49
SB_DQ_50
SB_DQ_51
SB_DQ_52
SB_DQ_53
SB_DQ_54
SB_DQ_55
SB_DQ_56
SB_DQ_57
SB_DQ_58
SB_DQ_59
SB_DQ_60
SB_DQ_61
SB_DQ_62
SB_DQ_63

CANTIGA_verB3

CANTIGA_verB3

DDR_B_BS0

BC16

SB_BS_0
SB_BS_1
SB_BS_2

SB_RAS#
SB_CAS#

SB_WE#

SB_DM_0
SB_DM_1
SB_DM_2
SB_DM_3
SB_DM_4
SB_DM_5
SB_DM_6
SB_DM_7

SB_DQS_0
SB_DQS_1
SB_DQS_2
SB_DQS_3
SB_DQS_4
SB_DQS_5
SB_DQS_6

SB_DQS_7
SB_DQS#_0
SB_DQS#_1
SB_DQS#_2
SB_DQS#_3
SB_DQS#_4
SB_DQS#_5
SB_DQS#_6
SB_DQS#_7

SB_MA_0
SB_MA_1
SB_MA_2
SB_MA_3
SB_MA_4
SB_MA_5
SB_MA_6
SB_MA_7
SB_MA_8

SB_MA_9
SB_MA_10
SB_MA_11
SB_MA_12
SB_MA_13

DDR SYSTEM MEMORY B

DDR SYSTEM MEMORY B

SB_MA_14

BB17
BB33

AU17
BG16
BF14

AM47
AY47
BD40
BF35
BG11
BA3
AP1
AK2

AL47
AV48
BG41
BG37
BH9
BB2
AU1
AN6
AL46
AV47
BH41
BH37
BG9
BC2
AT2
AN5

AV17
BA25
BC25
AU25
AW25
BB28
AU28
AW28
AT33
BD33
BB16
AW33
AY33
BH15
AU33

DDR_B_BS1
DDR_B_BS2

DDR_B_RAS#
DDR_B_CAS#
DDR_B_WE#

DDR_B_DM0
DDR_B_DM1
DDR_B_DM2
DDR_B_DM3
DDR_B_DM4
DDR_B_DM5
DDR_B_DM6
DDR_B_DM7

DDR_B_DQS0
DDR_B_DQS1
DDR_B_DQS2
DDR_B_DQS3
DDR_B_DQS4
DDR_B_DQS5
DDR_B_DQS6
DDR_B_DQS7
DDR_B_DQS#0
DDR_B_DQS#1
DDR_B_DQS#2
DDR_B_DQS#3
DDR_B_DQS#4
DDR_B_DQS#5
DDR_B_DQS#6
DDR_B_DQS#7

DDR_B_MA0
DDR_B_MA1
DDR_B_MA2
DDR_B_MA3
DDR_B_MA4
DDR_B_MA5
DDR_B_MA6
DDR_B_MA7
DDR_B_MA8
DDR_B_MA9
DDR_B_MA10
DDR_B_MA11
DDR_B_MA12
DDR_B_MA13
DDR_B_MA14

DDR_B_BS0 (16)
DDR_B_BS1 (16)
DDR_B_BS2 (16)

DDR_B_RAS# (16)
DDR_B_CAS# (16)
DDR_B_WE# (16)

DDR_B_DM[0..7] (16)

DDR_B_DQS[0..7] (16)

DDR_B_DQS#[0..7] (16)

DDR_B_MA[0..14] (16)

D D

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

Cantiga_C (DDR3)

Cantiga_C (DDR3)

Cantiga_C (DDR3)

RM2 2D

RM2 2D

RM2 2D

7

of

of

of

759Wednesday, August 06, 2008

759Wednesday, August 06, 2008

759Wednesday, August 06, 2008

8

1

2

3

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

4

5

6

Date: Sheet

5

http://hobi-elektronika.net

U30G

AP33
AN33
BH32

BG32

BF32
BD32
BC32
BB32
BA32

AY32

AW32

AV32
AU32
AT32
AR32
AP32
AN32
BH31

BG31

BF31

BG30

BH29

BG29

BF29
BD29
BC29
BB29
BA29
AY29

AW29

AV29
AU29
AT29
AR29
AP29

BA36
BB24
BD16

BB21
AW16
AW13

AT13

AE25

AB25

AA25

AE24

AC24

AA24

AE23

AC23

AB23

AA23

AJ21

AG21

AE21

AC21

AA21

AH20

AF20

AE20

AC20

AB20

AA20

AM15

AL15

AE15

AJ15

AH15

AG15

AF15

AB15

AA15

AN14

AM14

AJ14

AH14

Y26

Y24

Y21

T17
T16

Y15
V15
U15

U14
T14

U30G

VCC_SM_1
VCC_SM_2
VCC_SM_3
VCC_SM_4
VCC_SM_5
VCC_SM_6
VCC_SM_7
VCC_SM_8
VCC_SM_9
VCC_SM_10
VCC_SM_11
VCC_SM_12
VCC_SM_13
VCC_SM_14
VCC_SM_15
VCC_SM_16
VCC_SM_17
VCC_SM_18
VCC_SM_19
VCC_SM_20
VCC_SM_21
VCC_SM_22
VCC_SM_23
VCC_SM_24
VCC_SM_25
VCC_SM_26
VCC_SM_27
VCC_SM_28
VCC_SM_29
VCC_SM_30
VCC_SM_31
VCC_SM_32
VCC_SM_33
VCC_SM_34
VCC_SM_35

VCC_SM_36/NC
VCC_SM_37/NC
VCC_SM_38/NC
VCC_SM_39/NC
VCC_SM_40/NC
VCC_SM_41/NC
VCC_SM_42/NC

VCC_AXG_1
VCC_AXG_2
VCC_AXG_3
VCC_AXG_4
VCC_AXG_5
VCC_AXG_6
VCC_AXG_7
VCC_AXG_8
VCC_AXG_9
VCC_AXG_10
VCC_AXG_11
VCC_AXG_12
VCC_AXG_13
VCC_AXG_14
VCC_AXG_15
VCC_AXG_16
VCC_AXG_17
VCC_AXG_18
VCC_AXG_19
VCC_AXG_20
VCC_AXG_21
VCC_AXG_22
VCC_AXG_23
VCC_AXG_24
VCC_AXG_25
VCC_AXG_26
VCC_AXG_27
VCC_AXG_28
VCC_AXG_29
VCC_AXG_30
VCC_AXG_31
VCC_AXG_32
VCC_AXG_33
VCC_AXG_34
VCC_AXG_35
VCC_AXG_36
VCC_AXG_37
VCC_AXG_38
VCC_AXG_39
VCC_AXG_40
VCC_AXG_41
VCC_AXG_42

VCC_AXG_SENSE
VSS_AXG_SENSE

CANTIGA_verB3

CANTIGA_verB3

VCC_AXG_NCTF_1
VCC_AXG_NCTF_2
VCC_AXG_NCTF_3
VCC_AXG_NCTF_4
VCC_AXG_NCTF_5
VCC_AXG_NCTF_6
VCC_AXG_NCTF_7
VCC_AXG_NCTF_8

VCC_AXG_NCTF_9
VCC_AXG_NCTF_10
VCC_AXG_NCTF_11
VCC_AXG_NCTF_12
VCC_AXG_NCTF_13
VCC_AXG_NCTF_14
VCC_AXG_NCTF_15
VCC_AXG_NCTF_16
VCC_AXG_NCTF_17
VCC_AXG_NCTF_18
VCC_AXG_NCTF_19
VCC_AXG_NCTF_20
VCC_AXG_NCTF_21

POWER

POWER

VCC_AXG_NCTF_22
VCC_AXG_NCTF_23
VCC_AXG_NCTF_24
VCC_AXG_NCTF_25
VCC_AXG_NCTF_26
VCC_AXG_NCTF_27
VCC_AXG_NCTF_28
VCC_AXG_NCTF_29
VCC_AXG_NCTF_30

VCC SMVCC GFX

VCC SMVCC GFX

VCC_AXG_NCTF_31
VCC_AXG_NCTF_32
VCC_AXG_NCTF_33
VCC_AXG_NCTF_34
VCC_AXG_NCTF_35
VCC_AXG_NCTF_36
VCC_AXG_NCTF_37
VCC_AXG_NCTF_38
VCC_AXG_NCTF_39
VCC_AXG_NCTF_40
VCC_AXG_NCTF_41
VCC_AXG_NCTF_42
VCC_AXG_NCTF_43
VCC_AXG_NCTF_44
VCC_AXG_NCTF_45
VCC_AXG_NCTF_46
VCC_AXG_NCTF_47
VCC_AXG_NCTF_48
VCC_AXG_NCTF_49
VCC_AXG_NCTF_50
VCC_AXG_NCTF_51
VCC_AXG_NCTF_52
VCC_AXG_NCTF_53
VCC_AXG_NCTF_54
VCC_AXG_NCTF_55

VCC GFX NCTF

VCC GFX NCTF

VCC_AXG_NCTF_56
VCC_AXG_NCTF_57
VCC_AXG_NCTF_58
VCC_AXG_NCTF_59
VCC_AXG_NCTF_60

Added for SI
recommend.

D D

+1.5V_DDR

1 2

C151 0.1U/10VC151 0.1U/10V

1 2

C152 0.1U/10VC152 0.1U/10V

1 2

C150 0.1U/10VC150 0.1U/10V

1 2

C154 0.1U/10VC154 0.1U/10V

2600mA

C C

B B

A A

5

4

VCC_SM_LF1
VCC_SM_LF2
VCC_SM_LF3
VCC_SM_LF4
VCC_SM_LF5
VCC_SM_LF6
VCC_SM_LF7

VCC SM LF

VCC SM LF

4

W28
V28
W26
V26
W25
V25
W24
V24
W23
V23
AM21
AL21
AK21
W21
V21
U21
AM20
AK20
W20
U20
AM19
AL19
AK19
AJ19
AH19
AG19
AF19
AE19
AB19
AA19
Y19
W19
V19
U19
AM17
AK17
AH17
AG17
AF17
AE17
AC17
AB17
Y17
W17
V17
AM16
AL16
AK16
AJ16
AH16
AG16
AF16
AE16
AC16
AB16
AA16
Y16
W16
V16
U16

AV44
BA37
AM40
AV21
AY5
AM10
BB13

VCCSM_LF1
VCCSM_LF2
VCCSM_LF3
VCCSM_LF4
VCCSM_LF5
VCCSM_LF6
VCCSM_LF7

Layout Note:
370 mils from edge.

+1.5V_DDR

12

C142

C142

0.1U/10V

0.1U/10V

Layout Note:
Place C233 where LVDS
and DDR2 taps.

C111

C111

0.1U/10V

0.1U/10V

12

C110

C110

0.1U/10V

0.1U/10V

12

+1.05V_VCCP

+

+

C587

C587
330U

330U

12

C98

C98

0.22U/10V

0.22U/10V

3

+3.3V_RUN

R440 10R440 10

1 2

Layout Note:
Inside GMCH cavity.

+VCC_GMCH_L

Ivcc=1930.4+508.12=2438.52mA

12

C99

C99

0.22U/10V

0.22U/10V

12

C140

C140
22U/4V

22U/4V

Layout Note:
Place on the edge.

12

C161

C161
1U/10V

1U/10V

3

12

C129

C129

0.22U/10V

0.22U/10V

12

C109

C109
22U/4V

22U/4V

+

+

12

C245

C245
330U/2.5V

330U/2.5V

12

C169

C169

0.47U/10V

0.47U/10V

12

C156

C156

0.22U/10V

0.22U/10V

VCC_SM

12

12

C175

C175
1U/10V

1U/10V

SDMK0340L-7-F

SDMK0340L-7-F

12

C153

C153
22U/4V

22U/4V

D25

D25

C94

C94

0.1U/10V

0.1U/10V

2

U30F

U30F

21

2

AG34

VCC_1

AC34

VCC_2

AB34

VCC_3

AA34

VCC_4

Y34

VCC_5

V34

VCC_6

U34

VCC_7

AM33

VCC_8

AK33

VCC_9

AJ33

VCC_10

AG33

VCC_11

AF33

VCC_12

AE33

VCC_13

AC33

VCC_14

AA33

VCC_15

Y33

VCC_16

W33

VCC_17

V33

VCC_18

U33

VCC_19

AH28

VCC_20

AF28

VCC_21

AC28

VCC_22

AA28

VCC_23

AJ26

VCC_24

AG26

VCC_25

AE26

VCC_26

AC26

VCC_27

AH25

VCC_28

AG25

VCC_29

AF25

VCC_30

AG24

VCC_31

AJ23

VCC_32

AH23

VCC_33

AF23

VCC_34

T32

VCC_35

CANTIGA_verB3

CANTIGA_verB3

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

VCC CORE

VCC CORE

POWER

POWER

VCC NCTF

VCC NCTF

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

Cantiga_D (VCC,NCTF)

Cantiga_D (VCC,NCTF)

Cantiga_D (VCC,NCTF)

RM2 2D

RM2 2D

RM2 2D

VCC_NCTF_1
VCC_NCTF_2
VCC_NCTF_3
VCC_NCTF_4
VCC_NCTF_5
VCC_NCTF_6
VCC_NCTF_7
VCC_NCTF_8

VCC_NCTF_9
VCC_NCTF_10
VCC_NCTF_11
VCC_NCTF_12
VCC_NCTF_13
VCC_NCTF_14
VCC_NCTF_15
VCC_NCTF_16
VCC_NCTF_17
VCC_NCTF_18
VCC_NCTF_19
VCC_NCTF_20
VCC_NCTF_21
VCC_NCTF_22
VCC_NCTF_23
VCC_NCTF_24
VCC_NCTF_25
VCC_NCTF_26
VCC_NCTF_27
VCC_NCTF_28
VCC_NCTF_29
VCC_NCTF_30
VCC_NCTF_31
VCC_NCTF_32
VCC_NCTF_33
VCC_NCTF_34
VCC_NCTF_35
VCC_NCTF_36
VCC_NCTF_37
VCC_NCTF_38
VCC_NCTF_39
VCC_NCTF_40
VCC_NCTF_41
VCC_NCTF_42
VCC_NCTF_43
VCC_NCTF_44

1

+1.05V_VCCP

AM32
AL32
AK32
AJ32
AH32
AG32
AE32
AC32
AA32
Y32
W32
U32
AM30
AL30
AK30
AH30
AG30
AF30
AE30
AC30
AB30
AA30
Y30
W30
V30
U30
AL29
AK29
AJ29
AH29
AG29
AE29
AC29
AA29
Y29
W29
V29
AL28
AK28
AL26
AK26
AK25
AK24
AK23

of

of

of

859Wednesday, August 06, 2008

859Wednesday, August 06, 2008

859Wednesday, August 06, 2008

1

5

http://hobi-elektronika.net

+1.05V_VCCP

D D

C C

B B

45mA MAx.

R660R66

FB_120ohm+-25%_100mHz

0

_200mA_0.2ohm DC

L10

L10

12

BLM18AG121SN1D

BLM18AG121SN1D

603

603

+VCCA_MPLL_L

L9

L9
BLM18AG121SN1D

BLM18AG121SN1D

603

603

R70

R70

1 2

0.5/F 603

0.5/F 603

12

C90

C90
22U

22U

1206 10V

1206 10V

+1.05V_VCCP

FB_220ohm+-25%
_100MHz_2A_0.1ohm DC

+1.05V_VCCP

+1.5V_RUN

12

L25

L25

1 2

BLM21PG221SN1D

BLM21PG221SN1D

805

805

L22

L22

BLM18PG181SN1D

BLM18PG181SN1D

603

603

BLM18PG181SN1D

BLM18PG181SN1D

1 2

+VCCA_MPLL

L14

L14

603

603

+VCCA_HPLL

C91

C91

4.7U

4.7U

805

805

6.3

6.3

+VCCA_PEG_PLL

12

R174

R174
1/F

1/F

603

603

+VCCA_PEG_PLL_R

12

C254

C254
10U

10U

603

603

6.3

6.3

+VCCD_PEG_PLL

12

R1631R163
1

+VCCD_PEG_PLL_RC

C232

C232
10U

10U

603

603

6.3

6.3

12

C589

C589

0.1U/10V

0.1U/10V

10V

10V

12

C588

C588

0.1U

0.1U

10V

10V

50mA

C143

C143

0.01U

0.01U

25

25

Gur_0808: 0 ohm
removal, delete R99

+1.05V_VCCP

H=1.9

+VCCD_QDAC

12

C144

C144

0.1U

0.1U

10V

10V

+1.05V_VCCP

12

C586

C586

+

+

100U/6.3V_3528

100U/6.3V_3528

3528

3528

6.3

6.3

1uH+-20%_300mA

120uA

L13

L13

1uH/300mA

1uH/300mA

4

U30H

U30H

B27

VCCA_CRT_DAC_1

A26

VCCA_CRT_DAC_2

A25

VCCA_DAC _BG

B25

VSSA_DAC_BG

F47

VCCA_DPLLA

L48

24mA

139.2mA

+1.5V_RUN

+VCCA_HPLL

+VCCA_MPLL

414uA

12

C624

C624

0.1U

0.1U

10V

10V

+VCCA_PEG_PLL

12

C248

C248

0.1U

0.1U

10V

10V

50mA

480mA

12

12

C117

C117

C127

C127

4.7U

4.7U

*22U_NC

*22U_NC

805

805

805

6.3

6.3

12

+VCCA_SM_CK

12

C141

C141
*22U/10V_NC

*22U/10V_NC

157.2mA

805
10

10

C585 0.1U/10VC585 0.1U/10V

12

C244

C244

0.1U/10V

0.1U/10V

1 2

C112

C112
22U

22U

805

805
10

10

C137

C137
22U/10V

22U/10V

12

12

24mA

35mA

12

C115

C115
1U

1U

603

603
10

10

12

C138

C138

0.1U/10V

0.1U/10V

+VCCD_TVDAC

+VCCD_QDAC

+VCCA_MPLL_L

+VCCD_PEG_PLL

VCCA_DPLLB

AD1

VCCA_HP LL

AE1

VCCA_MP LL

J48

VCCA_LVDS

J47

VSSA_LVDS

AD48

VCCA_PEG_BG

AA48

VCCA_PEG_PLL

AR20

VCCA_SM _1

AP20

VCCA_SM _2

AN20

VCCA_SM _3

AR17

VCCA_SM _4

AP17

VCCA_SM _5

AN17

VCCA_SM _6

AT16

VCCA_SM _7

AR16

VCCA_SM _8

AP16

VCCA_SM _9

AP28

VCCA_SM_CK_1

AN28

VCCA_SM_CK_2

AP25

VCCA_SM_CK_3

AN25

VCCA_SM_CK_4

AN24

VCCA_SM_CK_5

AM28

VCCA_SM_CK_NCTF_1

AM26

VCCA_SM_CK_NCTF_2

AM25

VCCA_SM_CK_NCTF_3

AL25

VCCA_SM_CK_NCTF_4

AM24

VCCA_SM_CK_NCTF_5

AL24

VCCA_SM_CK_NCTF_6

AM23

VCCA_SM_CK_NCTF_7

AL23

VCCA_SM_CK_NCTF_8

B24

VCCA_T V_DAC_1

A24

VCCA_T V_DAC_2

A32

VCC_HD A

M25

VCCD_T VDAC

L28

VCCD_Q DAC

AF1

VCCD_H PLL

AA47

VCCD_PEG_PLL

M38

VCCD_LVDS_1

L37

VCCD_LVDS_2

CANTIGA_verB3

CANTIGA_verB3

3

CRTPLLA PEGA SM

CRTPLLA PEGA SM

A LVDS

A LVDS

POWER

POWER

A CK

A CK

TV

TV

HDA

HDA

D TV/CRT

D TV/CRT

LVDS

LVDS

AXF

AXF

VCC_SM_CK_1
VCC_SM_CK_2
VCC_SM_CK_3
VCC_SM_CK_4

SM CK

SM CK

VCC_TX_LVDS

HV

HV

PEG

PEG

DMI

DMI

VTT_1
VTT_2
VTT_3
VTT_4
VTT_5
VTT_6
VTT_7
VTT_8

VTT_9
VTT_10
VTT_11
VTT_12
VTT_13
VTT_14

VTT

VTT

VTT_15
VTT_16
VTT_17
VTT_18
VTT_19
VTT_20
VTT_21
VTT_22
VTT_23
VTT_24
VTT_25

VCC_AXF_ 1
VCC_AXF_ 2
VCC_AXF_ 3

VCC_HV_1
VCC_HV_2
VCC_HV_3

VCC_PE G_1
VCC_PE G_2
VCC_PE G_3
VCC_PE G_4
VCC_PE G_5

VCC_DMI_1
VCC_DMI_2
VCC_DMI_3
VCC_DMI_4

VTTLF1
VTTLF2
VTTLF3

VTTLF

VTTLF

U13
T13
U12
T12
U11
T11
U10
T10
U9
T9
U8
T8
U7
T7
U6
T6
U5
T5
V3
U3
V2
U2
T2
V1
U1

B22
B21
A21

BF21
BH20
BG20
BF20

K47

C35
B35
A35

V48
U48
V47
U47
U46

AH48
AF48
AH47
AG47

A8
L1
AB2

12

C149

C149

2.2U/6.3V

2.2U/6.3V

+VCC_SM_CK

+VCC_TX_LVDS_L

+3.3V_VCC_HV

1782mA

456mA

+VTTLF1
+VTTLF2
+VTTLF3

119.85mA

+VCC_PEG

12

852mA

12

C145

C145

4.7U/6.3V

4.7U/6.3V

Close to VTT

105.3mA

12

+

+

C636

C636
220U/4V

220U/4V

2V

2V

C221

C221

0.1U/10V

0.1U/10V

+VTTLF1
+VTTLF2
+VTTLF3

12

2

12

+VCC_PEG

C100

C100

0.47U/10V

0.47U/10V

C130

C130

0.47U/6.3V

0.47U/6.3V

12

C634

C634
22U/10V

22U/10V

12

C148

C148

4.7U

4.7U

603

603

6.3

6.3

12

C128

C128
1U/10V

1U/10V

12

C118

C118

0.1U/10V

0.1U/10V

Actual measurement
(VCC_PEG+VCC_DMI) :

1386.7 mA (under
3DMark06)

120 ohm, 3A

L70 BLM31PG121SN1LL70 BLM31PG121SN1L

1 2

C240

C240

4.7U

4.7U

805

805

1 2

6.3

6.3

12

C96

C96

0.47U/10V

0.47U/10V

+1.05V_VCCP

12

+

+

C582

C582
220U/4V

220U/4V

7343

7343
2

2

Place on chip edge.

Gur_0808: 0 ohm removal, delete L12

C131

C131
*10U_NC

*10U_NC

603

603

6.3

6.3

L11

805L11

805

1uH/300MA

12

C594

C594

0.47U/10V

0.47U/10V

1uH/300MA

12

R871R87
1

+VCC_SM_CK_L

C116

C116
10U

10U

603

603

6.3

6.3

+1.05V_VCCP

+3.3V_VCC_HV

+1.5V_DDR

R132 0R132 0

12

C167

C167

0.1U/10V

0.1U/10V

1 2

1

VCC_HV

D9

D9
*SDMK0340L-7-F_NC

*SDMK0340L-7-F_NC

+1.05V_VCCP

+1.05V_VCCP

21

D10

D10
SDM10K45-7-F

SDM10K45-7-F

R12910R129
10

1 2

+1.05V_VCCP

+3.3V_RUN

+3.3V_RUN

21

+VCC_HV_L

12

R69

R69
*10_NC

*10_NC

A A

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

Cantiga_E (POWER)

Cantiga_E (POWER)

Cantiga_E (POWER)

RM2 3A

RM2 3A

RM2 3A

1

of

of

of

959Thursday, August 14, 2008

959Thursday, August 14, 2008

959Thursday, August 14, 2008

5

4

Title

Title

Title

Size Docum ent Number Rev

Size Docum ent Number Rev

Size Docum ent Number Rev

Date: Sheet

Date: Sheet

3

2

Date: Sheet

5

http://hobi-elektronika.net

U30I

U30I

AU48

VSS_1

AR48

VSS_2

AL48

VSS_3

BB47

VSS_4

AW47

VSS_5

AN47

VSS_6

AJ47

VSS_7

D D

C C

B B

A A

5

AF47

AD47

AB47

N47

G47

BD46

BA46
AY46

AV46
AR46
AM46

V46
R46
P46
H46

BF44
AH44
AD44

AA44

U44

M44

BC43

AV43
AU43
AM43

C43

BG42

AY42

AT42
AN42

AJ42

AE42

N42

BD41
AU41
AM41
AH41
AD41

AA41

U41

M41
G41
B41

BG40

BB40

AV40
AN40

H40
E40

AT39
AM39

AJ39

AE39

N39

B39
BH38
BC38

BA38
AU38
AH38
AD38

AA38

U38

C38
BF37
BB37

AW37

AT37

AN37

AJ37

H37

C37

BG36
BD36

AK15

AU36

Y47
T47

L47

F46

Y44

T44

F44

J43

L42

Y41

T41

L39

Y38

T38
J38
F38

VSS_8
VSS_9
VSS_10
VSS_11
VSS_12
VSS_13
VSS_14
VSS_15
VSS_16
VSS_17
VSS_18
VSS_19
VSS_20
VSS_21
VSS_22
VSS_23
VSS_24
VSS_25
VSS_26
VSS_27
VSS_28
VSS_29
VSS_30
VSS_31
VSS_32
VSS_33
VSS_34
VSS_35
VSS_36
VSS_37
VSS_38
VSS_39
VSS_40
VSS_41
VSS_42
VSS_43
VSS_44
VSS_45
VSS_46
VSS_47
VSS_48
VSS_49
VSS_50
VSS_51
VSS_52
VSS_53
VSS_54
VSS_55
VSS_56
VSS_57
VSS_58
VSS_59
VSS_60
VSS_61
VSS_62
VSS_63
VSS_64
VSS_65
VSS_66
VSS_67
VSS_68
VSS_69
VSS_70
VSS_71
VSS_72
VSS_73
VSS_74
VSS_75
VSS_76
VSS_77
VSS_78
VSS_79
VSS_80
VSS_81
VSS_82
VSS_83
VSS_84
VSS_85
VSS_86
VSS_87
VSS_88
VSS_89
VSS_90
VSS_91
VSS_92
VSS_93
VSS_94
VSS_95
VSS_96
VSS_97
VSS_98
VSS_99

CANTIGA_verB3

CANTIGA_verB3

VSS

VSS

4

4

VSS_100
VSS_101
VSS_102
VSS_103
VSS_104
VSS_105
VSS_106
VSS_107
VSS_108
VSS_109
VSS_110
VSS_111
VSS_112
VSS_113
VSS_114
VSS_115
VSS_116
VSS_117
VSS_118
VSS_119
VSS_120
VSS_121
VSS_122
VSS_123
VSS_124
VSS_125
VSS_126
VSS_127
VSS_128
VSS_129
VSS_130
VSS_131
VSS_132
VSS_133
VSS_134
VSS_135
VSS_136
VSS_137
VSS_138
VSS_139
VSS_140
VSS_141
VSS_142
VSS_143
VSS_144
VSS_145
VSS_146
VSS_147
VSS_148
VSS_149
VSS_150
VSS_151
VSS_152
VSS_153
VSS_154
VSS_155
VSS_156
VSS_157
VSS_158
VSS_159
VSS_160
VSS_161
VSS_162
VSS_163
VSS_164
VSS_165
VSS_166
VSS_167
VSS_168
VSS_169
VSS_170
VSS_171
VSS_172
VSS_173
VSS_174
VSS_175
VSS_176
VSS_177
VSS_178
VSS_179
VSS_180
VSS_181
VSS_182
VSS_183
VSS_184
VSS_185
VSS_186
VSS_187
VSS_188
VSS_189
VSS_190
VSS_191
VSS_192
VSS_193
VSS_194
VSS_195
VSS_196
VSS_197
VSS_198

AM36
AE36
P36
L36
J36
F36
B36
AH35
AA35
Y35
U35
T35
BF34
AM34
AJ34
AF34
AE34
W34
B34
A34
BG33
BC33
BA33
AV33
AR33
AL33
AH33
AB33
P33
L33
H33
N32
K32
F32
C32
A31
AN29
T29
N29
K29
H29
F29
A29
BG28
BD28
BA28
AV28
AT28
AR28
AJ28
AG28
AE28
AB28
Y28
P28
K28
H28
F28
C28
BF26
AH26
AF26
AB26
AA26
C26
B26
BH25
BD25
BB25
AV25
AR25
AJ25
AC25
Y25
N25
L25
J25
G25
E25
BF24
AD12
AY24
AT24
AJ24
AH24
AF24
AB24
R24
L24
K24
J24
G24
F24
E24
BH23
AG23
Y23
B23
A23

3

U30J

U30J

BG21

VSS_199

L12

VSS_200

AW21

VSS_201

AU21

VSS_202

AP21

VSS_203

AN21

VSS_204

AH21

VSS_205

AF21

VSS_206

AB21

VSS_207

R21

VSS_208

M21

VSS_209

J21

VSS_210

G21

VSS_211

BC20

VSS_212

BA20

VSS_213

AW20

VSS_214

AT20

VSS_215

AJ20

VSS_216

AG20

VSS_217

Y20

VSS_218

N20

VSS_219

K20

VSS_220

F20

VSS_221

C20

VSS_222

A20

VSS_223

BG19

VSS_224

A18

VSS_225

BG17

VSS_226

BC17

VSS_227

AW17

VSS_228

AT17

VSS_229

R17
M17
H17
C17

BA16

AU16
AN16

N16
K16
G16
E16

BG15

AC15

W15

A15

BG14

AA14

C14

BG13

BC13
BA13

AN13
AJ13
AE13

N13

L13
G13
E13

BF12
AV12
AT12

AM12

AA12

J12
A12

BD11
BB11
AY11
AN11
AH11

Y11
N11
G11
C11

BG10

AV10
AT10
AJ10
AE10
AA10

M10
BF9
BC9
AN9

AM9

AD9

G9

B9
BH8
BB8
AV8
AT8

3

VSS_230
VSS_231
VSS_232
VSS_233

VSS_235

VSS_237
VSS_238
VSS_239
VSS_240
VSS_241
VSS_242
VSS_243
VSS_244
VSS_245
VSS_246
VSS_247
VSS_248
VSS_249
VSS_250
VSS_251
VSS_252

VSS_255
VSS_256
VSS_257
VSS_258
VSS_259
VSS_260
VSS_261
VSS_262
VSS_263
VSS_264
VSS_265
VSS_266
VSS_267
VSS_268
VSS_269
VSS_270
VSS_271
VSS_272
VSS_273

VSS_275
VSS_276
VSS_277
VSS_278
VSS_279
VSS_280
VSS_281
VSS_282
VSS_283
VSS_284
VSS_285
VSS_286
VSS_287
VSS_288
VSS_289
VSS_290
VSS_291
VSS_292
VSS_293
VSS_294
VSS_295
VSS_296

CANTIGA_verB3

CANTIGA_verB3

VSS

VSS

VSS_NCTF_10
VSS_NCTF_11
VSS_NCTF_12
VSS_NCTF_13

VSS NCTF

VSS NCTF

VSS_NCTF_14
VSS_NCTF_15
VSS_NCTF_16

VSS SCB

VSS SCB

NC

NC

VSS_297
VSS_298
VSS_299
VSS_300
VSS_301
VSS_302
VSS_303
VSS_304
VSS_305
VSS_306
VSS_307
VSS_308
VSS_309
VSS_310
VSS_311
VSS_312
VSS_313
VSS_314
VSS_315
VSS_316
VSS_317
VSS_318
VSS_319
VSS_320
VSS_321
VSS_322
VSS_323
VSS_324
VSS_325

VSS_327
VSS_328
VSS_329
VSS_330
VSS_331
VSS_332
VSS_333
VSS_334
VSS_335
VSS_336
VSS_337
VSS_338
VSS_339
VSS_340
VSS_341
VSS_342
VSS_343
VSS_344
VSS_345
VSS_346
VSS_347
VSS_348
VSS_349
VSS_350

VSS_351
VSS_352
VSS_353
VSS_354

VSS_NCTF_1
VSS_NCTF_2
VSS_NCTF_3
VSS_NCTF_4
VSS_NCTF_5
VSS_NCTF_6
VSS_NCTF_7
VSS_NCTF_8
VSS_NCTF_9

VSS_SCB_1
VSS_SCB_2
VSS_SCB_3
VSS_SCB_4
VSS_SCB_5
VSS_SCB_6

NC_26
NC_27
NC_28
NC_29
NC_30
NC_31
NC_32
NC_33
NC_34
NC_35
NC_36
NC_37
NC_38
NC_39
NC_40
NC_41
NC_42

2

AH8
Y8
L8
E8
B8
AY7
AU7
AN7
AJ7
AE7
AA7
N7
J7
BG6
BD6
AV6
AT6
AM6
M6
C6
BA5
AH5
AD5
Y5
L5
J5
H5
F5
BE4

BC3
AV3
AL3
R3
P3
F3
BA2
AW2
AU2
AR2
AP2
AJ2
AH2
AF2
AE2
AD2
AC2
Y2
M2
K2
AM1
AA1
P1
H1

U24
U28
U25
U29

AF32
AB32
V32
AJ30
AM29
AF29
AB29
U26
U23
AL20
V20
AC19
AL17
AJ17
AA17
U17

BH48
BH1
A48
C1
B2
A3

E1
D2
C3
B4
A5
A6
A43
A44
B45
C46
D47
B47
A46
F48
E48
C48
B48

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

2

Date: Sheet

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

Cantiga_F (VSS)

Cantiga_F (VSS)

Cantiga_F (VSS)

RM2 2D

RM2 2D

RM2 2D

1

of

of

of

10 59Wednesday, August 06, 2008

10 59Wednesday, August 06, 2008

10 59Wednesday, August 06, 2008

1

1

http://hobi-elektronika.net

2

3

4

5

6

7

8

32.768KHZ

12

C623

C623
15P/50V

15P/50V

A A

B B

C C

ICH_AZ_CODEC_BITCLK(40)

ICH_AZ_CODEC_SYNC(40)

ICH_AZ_CODEC_RST#(31,40)

ICH_AZ_CODEC_SDOUT(40)

Place all series terms close to ICH9 except for SDIN input
lines,which should be close to source.Placement of R603, R600,
R607 & R612 should equal distance to the T split trace point as
R604, R599, R606 & R608 respective. Basically,keep the same
distance from T for all series termination resistors.

R467 10MR467 10M

Gur_0808: 0 ohm
removal, delete R470

+RTC_CELL

12

R1511MR151
1M

1 2

12

W1

W1

32.768KHZ

32.768KHZ

R135

R135
20K

20K

C195

C195
1U/10V

1U/10V

12

12

R466

R466
20K

20K

1 2

ICH_RTCRST#
ICH_SRTCRST#
ICH_INTRUDER#

12

C621

C621
1U/10V

1U/10V

ICH_RTCX2ICH_RTCX1

12

C622

C622
15P/50V

15P/50V

R225 33R225 33

1 2

C338

C338
*27P/50V_NC

*27P/50V_NC

1 2

R228 33R228 33

1 2

R236 33R236 33

1 2

R229 33R229 33

1 2

ICH9M Internal VR Enable Strap
(Internal VR for VccSus1.05, VccSus1.5, VccCL1.5)

ICH_INTVRMEN

ICH_RTCX1
ICH_RTCX2

ICH_RTCRST#
ICH_SRTCRST#
ICH_INTRUDER#

ICH_INTVRMEN
ICH_LAN100_SLP

T50 PADT50 PAD

+3.3V_SUS

+3.3V_SUS

SATA_ACT#(38)

SATA_RX0-(36)

SATA_RX0+(36)
SATA_TX0-_C(36)
SATA_TX0+_C(36)

SATA_RX1-(36)

SATA_RX1+(36)
SATA_TX1-_C(36)
SATA_TX1+_C(36)

T144

T144
T145

T145
T77

T77

T140 PADT140 PAD

T61 PADT61 PAD
T66 PADT66 PAD
T64 PADT64 PAD
T67 PADT67 PAD
T68 PADT68 PAD
T69 PADT69 PAD

R496 *10K_NCR496 *10K_NC

R462 24.9/FR462 24.9/F

1 2

ACZ_BIT_C LK

ACZ_SYNC

ACZ_RST#

ACZ_SDO UT ACZ_ SYNC

Reserved for
Intel Nineveh
design.

+1.5V_PCIE_ICH

ICH_AZ_CODEC_SDIN0(40)

HDD

ODD

GLAN_CLK

LAN_RSTSYNC

LAN_RXD0
LAN_RXD1
LAN_RXD2
LAN_TXD0
LAN_TXD1
LAN_TXD2

12

GLAN_COMP

ACZ_BIT_C LK

ACZ_RST#

PAD

PAD
PAD

PAD
PAD

PAD

ACZ_SDO UT

R196 *10K_NCR196 *10K_NC
R247 *10K_NCR247 *10K_NC

12
12

+RTC_CELL +RTC_CELL

12

R477

R477
332K/F

332K/F

ICH_INTVRMEN ICH_LAN100_SLP

12

R476

R476
*0_NC

*0_NC

ICH9M LAN100 SLP Strap

Low = Internal VR Di sabled
High = Internal VR Enabled(Default)

U34A

U34A

C23

RTCX1

C24

RTCX2

A25

RTCRST#

F20

SRTCRST#

C22

INTRUDER#

B22

INTV RMEN

A22

LAN100_SLP

E25

GLAN_CLK

C13

LAN_RSTSYNC

F14

LAN_RXD0

G13

LAN_RXD1

D14

LAN_RXD2

D13

LAN_TXD0

D12

LAN_TXD1

E13

LAN_TXD2

B10

GLAN_DOCK#/GPIO56

B28

GLAN_COMPI

B27

GLAN_COMPO

AF6

HDA_BIT_CLK

AH4

HDA_SYNC

AE7

HDA_RST#

AF4

HDA_SDIN0

AG4

HDA_SDIN1

AH3

HDA_SDIN2

AE5

HDA_SDIN3

AG5

HDA_SDOUT

AG7

HDA_DOCK_EN#/GPIO33

AE8

HDA_DOCK_RST#/GPIO34

AG8

SATALED#

AJ16

SATA0RXN

AH16

SATA0RXP

AF17

SATA0TXN

AG17

SATA0TXP

AH13

SATA1RXN

AJ13

SATA1RXP

AG14

SATA1TXN

AF14

SATA1TXP

ICH9M_verA3

ICH9M_verA3

RTCLAN / GLAN

RTCLAN / GLAN

IHDA

IHDA

SATA

SATA

(Internal VR for VccLAN1.05 and VccCL1.05)

ICH_LAN100_SLP

LDRQ0#

A20GATE

A20M#

DPRSTP#

DPSLP#

FERR#

IGNNE#

INIT#
INTR

RCIN#

NMI

SMI#

STPCLK#

TP9

SATA4RXN
SATA4RXP
SATA4TXN
SATA4TXP

SATA5RXN
SATA5RXP
SATA5TXN
SATA5TXP

K5
K4
L6
K2

K3

J3
J1

N7
AJ27

AJ25
AE23

AJ26

AD22

AF25

AE22
AG25
L3

AF23
AF24

AH27

AG26

AG27

AH11
AJ11
AG12
AF12

AH9
AJ9
AE10
AF10

AH18
AJ18

AJ7
AH7

SIO_A20GATE

H_DPRSTP#
H_DPSLP#

H_FERR#_L

SIO_RCIN#

THERMTRIP#_ICH

SATABIAS

FWH0/LAD0
FWH1/LAD1
FWH2/LAD2
FWH3/LAD3

FWH4/LFRAME#

LDRQ1#/GPIO23

LPCCPU

LPCCPU

CPUPWRGD

THRMTRIP#

SATA_CLKN
SATA_CLKP

SATARBIAS#

SATARBIAS

Low = Internal VR Di sabled
High = Internal VR Enabled(Default)

12

R473

R473
332K/F

332K/F

12

R472

R472
*0_NC

*0_NC

R139 56R139 56

R210 24.9/FR210 24.9/F

1 2

LPC_LAD0 (31,34)
LPC_LAD1 (31,34)
LPC_LAD2 (31,34)
LPC_LAD3 (31,34)

LPC_LFRAME# (31,34)

T81PAD T81PAD
T147PAD T147PAD

SIO_A20GATE (31)
H_A20M# (3)

H_DPRSTP# (3,6,51)
H_DPSLP# (3)

H_FERR#

12

H_PWRGOOD (3)

H_IGNNE# (3)

H_INIT# (3)
H_INTR (3)

SIO_RCIN# (31)

H_NMI (3)
H_SMI# (3)

H_STPCLK# (3)

T119PAD T119PAD

SATA_RX5- (35)
SATA_RX5+ (35)
SATA_TX5-_C (35)

SATA_TX5+_C (35)

CLK_PCIE_SATA# (17)
CLK_PCIE_SATA (17)

Place within 500mils
of ICH9 ball

H_FERR# (3)

E-SATA

1 2

H_DPRSTP#
H_DPSLP#
H_FERR#

SIO_A20GATE
SIO_RCIN#

THERMTRIP#_ICH

R147

R147
*56_NC

*56_NC

+1.05V_VCCP

R156

R156
*56_NC

*56_NC

1 2

R197

R197

8.2K

8.2K

1 2

+1.05V_VCCP

1 2

+3.3V_RUN

1 2

1 2

R14056R140
56

R525

R525
10K

10K

R46356R463
56

+3.3V_RUN

R223

5

1 2

1 2

R223
*1K_NC

*1K_NC

R475

R475
*1K_NC

*1K_NC

ACZ_SDO UT

ICH_RSVD (13)

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

6

Date: Sheet

COMPUTER

ICH9-M(CPU,SATA,IDE)

ICH9-M(CPU,SATA,IDE)

ICH9-M(CPU,SATA,IDE)

RM2 3A

RM2 3A

RM2 3A

7

of

of

of

11 59Friday, August 08, 2008

11 59Friday, August 08, 2008

11 59Friday, August 08, 2008

8

D D

1

2

3

XOR Chain Entrance Strap

ICH RSVD

HDA SDOUT

0

0

1

1

Description

0

RSVD

Enter XOR Chain

1

Normal Oper ation (Default)

0

Set PCIE port config b it 1

1

4

1

http://hobi-elektronika.net

Place TX DC blocking caps close ICH8.

C617 0.1U 10C617 0.1U 10

PCIE_TX1-(34)
PCIE_TX1+(34)

PCIE_TX2-(33)
PCIE_TX2+(33)

PCIE_TX3-(34)

A A

B B

PCIE_TX3+(34)

PCIE_TX4-(30)
PCIE_TX4+(30)

PCIE_TX6- /GLAN_TX-(43)
PCIE_TX6+ /GLAN_TX+(43)

ICH_SPI_CS1#_R
PCI_GNT0#

1 2

R227

R227
*1K_NC

*1K_NC

12

1 2

C616 0.1U 10C616 0.1U 10

1 2

C615 0.1U 10C615 0.1U 10

1 2

C614 0.1U 10C614 0.1U 10

1 2

C613 0.1U 10C613 0.1U 10

1 2

C612 0.1U 10C612 0.1U 10

1 2

C611 0.1U 10C611 0.1U 10

1 2

C610 0.1U 10C610 0.1U 10

1 2

C609 0.1U 10C609 0.1U 10

1 2

C608 0.1U 10C608 0.1U 10

1 2

R150

R150
*1K_NC

*1K_NC

SPI1001

WWAN Noise - ICH improvements

OC6#
OC4#
OC5#
OC7#
USB_OC8#
OC2_3#
USB_OC0_1#
OC9#

C C

D D

C339 *0.1U_NC 10C339 *0.1U_NC 10
C690 *0.1U_NC 10C690 *0.1U_NC 10
C692 *0.1U_NC 10C692 *0.1U_NC 10
C325 *0.1U_NC 10C325 *0.1U_NC 10
C342 *0.1U_NC 10C342 *0.1U_NC 10
C336 *0.1U_NC 10C336 *0.1U_NC 10
C310 *0.1U_NC 10C310 *0.1U_NC 10
C691 *0.1U_NC 10C691 *0.1U_NC 10

PCI_AD[0..31](28,56)

PCI_PIRQA & D :
Mini PCI debug
PCI_PIRQB & C :
Card Reader

PCI_PIRQA#(56)
PCI_PIRQB#(28)

PCI_PIRQD#(56)

1

1 2
1 2
1 2
1 2
1 2
1 2
1 2
1 2

PCI_AD0
PCI_AD1
PCI_AD2
PCI_AD3
PCI_AD4
PCI_AD5
PCI_AD6
PCI_AD7
PCI_AD8
PCI_AD9
PCI_AD10
PCI_AD11
PCI_AD12
PCI_AD13
PCI_AD14
PCI_AD15
PCI_AD16
PCI_AD17
PCI_AD18
PCI_AD19
PCI_AD20
PCI_AD21
PCI_AD22
PCI_AD23
PCI_AD24
PCI_AD25
PCI_AD26
PCI_AD27
PCI_AD28
PCI_AD29
PCI_AD30
PCI_AD31

PCI_PIRQA#
PCI_PIRQB#
PCI_PIRQC#
PCI_PIRQD#

2

PCIE_TXN1_C
PCIE_TXP1_C

PCIE_TXN2_C
PCIE_TXP2_C

PCIE_TXN3_C
PCIE_TXP3_C

PCIE_TXN4_C
PCIE_TXP4_C

GLAN_TXN_ C
GLAN_TXP_ C

PCIE_RX6 -/GLAN_RX-(43)
PCIE_RX6 +/GLAN_RX+(43)

Boot BIOS Strap

GNT0# SPI_CS1#

11LPC

No stuff

No stuff

No stuff

StuffPCI

Stuff

No stuff

Places within 500 mils
of the ICH9

+3.3V_SUS

U34B

U34B

D11

AD0

G11

D10

E12

E10

F11

F10

C8
D9

E9

C9

B7
C7
C5

F8

E7

A3
D2

D5

B3

F7
C3

F3

F4
C1
G7
H7
D1
G5
H6
G1
H3

J5

E1

J6

PCI

PCI

AD1
AD2
AD3
AD4
AD5
AD6
AD7
AD8
AD9
AD10
AD11
AD12
AD13
AD14
AD15
AD16
AD17
AD18
AD19
AD20
AD21
AD22
AD23
AD24
AD25
AD26
AD27
AD28
AD29
AD30
AD31

Interrupt I/F

Interrupt I/F

PIRQA#
PIRQB#
PIRQC#
PIRQD#C4PIRQH#/GPIO5

ICH9M_verA3

ICH9M_verA3

2

OC9#
OC4#
USB_OC8#
OC5#

OC10#
OC11#

REQ0#

GNT0#
REQ1#/GPIO50
GNT1#/GPIO51
REQ2#/GPIO52
GNT2#/GPIO53
REQ3#/GPIO54
GNT3#/GPIO55

C/BE0#
C/BE1#
C/BE2#
C/BE3#

IRDY#

PAR

PCIRST#

DEVSEL#

PERR#

PLOCK#

SERR#
STOP#
TRDY#

FRAME#

PLTRST#

PCICLK

PME#

PIRQE#/GPIO2
PIRQF#/GPIO3

PIRQG#/GPIO4

3

PCIE_RX1-(34)
PCIE_RX1+(34)

MiniWWAN

PCIE_RX2-(33)
PCIE_RX2+(33)

MiniWLAN

PCIE_RX3-(34)
PCIE_RX3+(34)

MiniWPAN

PCIE_RX4-(30)
PCIE_RX4+(30)

Express Card

Giga Bit LOM

T51 PADT51 PAD
T45 PADT45 PAD

T49 PADT49 PAD
T52 PADT52 PAD

USB_OC0_1#(35)

USB_OC8#(35)

R527 22.6/FR527 22.6/F

1 2

RP6

RP6

6
7
8
9

10

10KX8

10KX8
R219 10KR219 10K
R224 10KR224 10K

PCI_REQ0#

F1

PCI_GNT0#

G4

PCI_REQ1#

B6

PCI_GNT1#

A7

SB_WWAN_PCIE_RST#

F13

PCI_GNT2#

F12

SB_LOM_PCIE_RST#

E6

PCI_GNT3#

F6

D8
B4
D6
A5

PCI_IRDY#

D3
E3

PCI_RST#_G

R1

PCI_DEVSEL#

C6

PCI_PERR#

E4

PCI_PLOCK#

C2

PCI_SERR#

J4

PCI_STOP#

A4

PCI_TRDY#

F5

PCI_FRAME#

D7

PCI_PLTRST#

C14

CLK_PCI_ICH

D4
R2

SB_WPAN_PCIE_RST#

H4

SB_WLAN_PCIE_RST#

K6

SB_NB_PCIE_RST#

F2

ICH_IRQH_GPIO5

G2

3

ICH_SPI_CS1#_R

USB_OC0_1#

OC2_3#

OC4#
OC5#
OC6#
OC7#
USB_OC8#
OC9#
OC10#
OC11#

USBRBIAS

+3.3V_SUS

5
4
3
2
1

12
12

PCIE_TXN1_C
PCIE_TXP1_C

PCIE_TXN2_C
PCIE_TXP2_C

PCIE_TXN3_C
PCIE_TXP3_C

PCIE_TXN4_C
PCIE_TXP4_C

T44 PADT44 PAD
T116 PADT116 PAD
T47 PADT47 PAD
T46 PADT46 PAD

GLAN_TXN_ C
GLAN_TXP_ C

OC7#
OC6#
USB_OC0_1#
OC2_3#

+3.3V_SUS

PCI_REQ0# (28)
PCI_GNT0# (28)
PCI_REQ1# (56)
PCI_GNT1# (56)
SB_WWAN_PCIE_RST# (34)

T71PAD T71PAD

SB_LOM_PCIE_RST# (43)

T75PAD T75PAD

PCI_C_BE0# (28,56)
PCI_C_BE1# (28,56)
PCI_C_BE2# (28,56)
PCI_C_BE3# (28,56)

PCI_IRDY# (28,56)
PCI_PAR (28,56)

PCI_DEVSEL# (28,56)
PCI_PERR# (28,56)

PCI_SERR# (28,56)
PCI_STOP# (28,56)
PCI_TRDY# (28,56)
PCI_FRAME# (28,56)

CLK_PCI_ ICH (1 7)
ICH_PME# (28,56)

SB_WPAN_PCIE_RST# (34)
SB_WLAN_PCIE_RST# (33)
SB_NB_PCIE_RST# (6)PCI_PIRQC#(28)

T83PAD T83PAD

4

U34D

U34D

N29

PERN1

N28

PERP1

P27

PETN1

P26

PETP1

L29

PERN2

L28

PERP2

M27

PETN2

M26

PETP2

J29

PERN3

J28

PERP3

K27

PETN3

K26

PETP3

G29

PERN4

G28

PERP4

H27

PETN4

H26

PETP4

E29

PERN5

E28

PERP5

F27

PETN5

F26

PETP5

C29

PERN6/GLAN_RXN

C28

PERP6/GLAN_RXP

D27

PETN6/GLAN_TXN

D26

PETP6/GLAN_TXP

D23

SPI_CLK

D24

SPI_CS0#

F23

SPI_CS1#/GPIO58/CLGPIO6

D25

SPI_MOSI

E23

SPI_MISO

N4

OC0#/GPIO59

N5

OC1#/GPIO40

N6

OC2#/GPIO41

P6

OC3#/GPIO42

M1

OC4#/GPIO43

N2

OC5#/GPIO29

M4

OC6#/GPIO30

M3

OC7#/GPIO31

N3

OC8#/GPIO44

N1

OC9#/GPIIO45

P5

OC10#/GPIO46

P3

OC11#/GPIO47

AG2

USBRBIAS

AG1

USBRBIAS#

ICH9M_verA3

ICH9M_verA3

Card Reader

Mini PCI debug

4

5

V27

DMI0RXN

V26

DMI0RXP

U29

DMI0TXN

U28

DMI0TXP

Y27

DMI1RXN

Y26

DMI1RXP

W29

DMI1TXN

W28

DMI1TXP

AB27

DMI2RXN

AB26

DMI2RXP

AA29

DMI2TXN

AA28

DMI2TXP

AD27

DMI3RXN

AD26

DMI3RXP

AC29

DMI3TXN

AC28

DMI3TXP

T26

DMI_CLKN
DMI_CLKP

USBP0N
USBP0P
USBP1N
USBP1P
USBP2N
USBP2P
USBP3N
USBP3P
USBP4N
USBP4P
USBP5N
USBP5P
USBP6N
USBP6P
USBP7N
USBP7P
USBP8N
USBP8P
USBP9N

USBP9P
USBP10N
USBP10P
USBP11N
USBP11P

T25

AF29
AF28

AC5
AC4
AD3
AD2
AC1
AC2
AA5
AA4
AB2
AB3
AA1
AA2
W5
W4
Y3
Y2
W1
W2
V2
V3
U5
U4
U1
U2

DMI_COMP

PCI-Express

PCI-Express

DMI_ZCOMP

Direct Media Interface

Direct Media Interface

DMI_IRCOMP

SPI

SPI

USB

USB

A16 away override strap .

SB_NB_PCIE_RST#

5

DMI_MTX_IRX_N 0 (6)
DMI_MTX_IRX_P 0 (6 )

DMI_MRX_ITX_N 0 ( 6)
DMI_MRX_ITX_P 0 (6)

DMI_MTX_IRX_N 1 (6)
DMI_MTX_IRX_P 1 (6 )

DMI_MRX_ITX_N 1 ( 6)
DMI_MRX_ITX_P 1 (6)

DMI_MTX_IRX_N 2 (6)
DMI_MTX_IRX_P 2 (6 )

DMI_MRX_ITX_N 2 ( 6)
DMI_MRX_ITX_P 2 (6)

DMI_MTX_IRX_N 3 (6)
DMI_MTX_IRX_P 3 (6 )

DMI_MRX_ITX_N 3 ( 6)
DMI_MRX_ITX_P 3 (6)

CLK_PCIE_ICH# (17)
CLK_PCIE_ICH (17)

1 2

R464 24.9/FR464 24.9/F

ICH_USBP0- (42)
ICH_USBP0+ (42)
ICH_USBP1- (42)
ICH_USBP1+ (42)

T151PAD T151PAD
T152PAD T152PAD
T78PAD T78PAD

T80PAD T80PAD

ICH_USBP4- (33)
ICH_USBP4+ (33)
ICH_USBP5- (34)
ICH_USBP5+ (34)
ICH_USBP6- (34)
ICH_USBP6+ (34)
ICH_USBP7- (30)
ICH_USBP7+ (30)
ICH_USBP8- (35)
ICH_USBP8+ (35)
ICH_USBP9- (35)
ICH_USBP9+ (35)

T76PAD T76PAD

T79PAD T79PAD

ICH_USBP11- (37)
ICH_USBP11+ (37)

PCI_GNT3#

12

R209

R209

*1K_NC

*1K_NC

Low = A16 swap ov erride enabled.
High = Default.

CLK_PCI_ICH

Reserved for
EMI.Place
resister and cap
close to ICH.

6

+1.5V_PCIE_ICH

Place within 500mils of ICH8

Side pair (Top / left, IB)

Side pair (Bottom / left, IB)

Mini Card (WLAN)

Mini Card (WWAN)

Mini Card (WPAN)

Express Card

USB W/ E-SATA port

TV

Camera

Non-iAMT

R232

R232
*10_NC

*10_NC

1 2

C340

C340
*8.2P_NC

*8.2P_NC

1 2

16

16

6

7

8

PCI Pullups

RP5

PCI_FRAME#
PCI_DEVSEL#
PCI_TRDY#
PCI_STOP#

+3.3V_RUN

PCI_PIRQB#
PCI_PIRQC#
PCI_PIRQA#
PCI_REQ0#

+3.3V_RUN

SB_WPAN_PCIE_RST#
SB_WWAN_PCIE_RST#
SB_WLAN_PCIE_RST#
SB_LOM_PCIE_RST#
SB_NB_PCIE_RST#

BIOS should not enable the
internal GPIO pull up resistor.

+3.3V_SUS

C349

C349

1 2

0.047U

0.047U

2

10

10

PCI_RST#_G

PCI_PLTRST#

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

1

+3.3V_SUS

C647

C647

1 2

0.047U

0.047U

2

10

10

1

ICH9-M(USB,PCIE,DMI)

ICH9-M(USB,PCIE,DMI)

ICH9-M(USB,PCIE,DMI)

RM2 2D

RM2 2D

RM2 2D

7

RP5

6
7
8
9

10

8.2K_10P8R

8.2K_10P8R

RP7

RP7

6
7
8
9

10

8.2K_10P8R

8.2K_10P8R

Add Buffers as needed for
Loading and fanout concerns.

5

U5

U5

4

TC7SZ32FU(T5L,F,T)

TC7SZ32FU(T5L,F,T)

5

U35

U35

4

TC7SZ32FU(T5L,F,T)

TC7SZ32FU(T5L,F,T)

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

+3.3V_RUN

5

PCI_REQ1#

4

PCI_IRDY#

3

PCI_PIRQD#

2

PCI_PERR#

1

+3.3V_RUN

5

PCI_PLOCK#

4
3

ICH_IRQH_GPIO5

2

PCI_SERR#

1

R203 20KR203 20K
R182 20KR182 20K
R205 20KR205 20K
R220 20KR220 20K
R522 20KR522 20K

PLTRST# (6,30,31,33,34,43)

12
12
12
12
12

PCI_RST# (28,56)

12 59Wednesday, August 06, 2008

12 59Wednesday, August 06, 2008

12 59Wednesday, August 06, 2008

8

of

of

of

PCI_IRDY#

1

http://hobi-elektronika.net

2

3

4

5

6

7

8

+3.3V_SUS

RP2

RP2

1
3

2.2KX2

2.2KX2

A A

+3.3V_RUN

R242

R242

8.2K

8.2K

1 2

R233

B B

C C

+3.3V_RUN

+3.3V_RUN

D D

+3.3V_SUS

R233
*10_NC

*10_NC

1 2

Option to " Disable "
clkrun. Pulling it down
will keep the clks
running.

PCIE_MCARD1_DET#(33)

R177 10KR177 10K

R159 2.2KR159 2.2K

R171 100KR171 100K

1 2

R154 100KR154 100K

1 2

R243 100KR243 100K

1 2

R215 100KR215 100K

1 2

R158 100KR158 100K

1 2

R148 *10K_NCR148 *10K_NC
R193 10KR193 10K
R149 10KR149 10K

R164 10KR164 10K
R478 10KR478 10K
R480 100KR480 100K

1 2

Non-iAMT

ICH_SMBDATA

2

ICH_SMBCLK

4

Gur_0808: 0 ohm remo val,
delete R178, R186, RP14

CLKRUN#

PCIE_MCARD1_DET#

PLTRST_DELAY#

12

IMVP_PWRGD

12

USB_MCARD2_DET#

USB_MCARD3_DET#

PCIE_MCARD1_DET#

PCIE_MCARD2_DET#
PCIE_MCARD3_DET#

MCH_ICH_SYNC#

12

IRQ_SERIR Q

12

THERM_ALERT#

12

RSV_WOL_EN

12

SIO_EXT_SMI#

12

USB_MCARD1_DET#

1

R244

R244

4.7K

4.7K

Gur_0808: 0 ohm
removal, delete R146

2

12

WPAN_ RADIO_DIS_MINI#(34)

+3.3V_SUS

R180 *10K_NCR180 *10K_NC
R176 10KR176 10K
R489 10KR489 10K
R173 1KR173 1K

ITP_DBRESET#(3)

PM_BMBUSY#(6)

USB_MCARD1_DET#(33)

H_STP_PCI#(17)
H_STP_CPU#(17)

CLKRUN#(28,31,56)

PCIE_WAKE#(30,33,34,43)
IRQ_SERIRQ(28,31,56)

THERM_ALE RT#(39)

IMVP_PW RGD(31,45,51)

USB_MCARD2_DET#(34)
USB_MCARD3_DET#(34)

SIO_EXT_WAKE#(31)
SIO_EXT_SMI#(31)
SIO_EXT_SCI#(31)

KB_LED_DET(37)

PCIE_MCARD2_DET#(34)
PCIE_MCARD3_DET#(34)

WLAN_ RADIO_DIS#(33)

CAMERA_CBL_DET#(37)

SATA_CLKREQ#(17)

PLTRST_DELAY#(18)

WWAN_RADIO_DIS#(34)

MCH_ICH_SYNC#(6)

ICH_RSVD(11)

SPKR

T63 PADT63 P AD
T60 PADT60 P AD
T65 PADT65 P AD

T72 PADT72 P AD

T134 PADT134 PAD

T133 PADT133 PAD

T120 PADT120 PAD
T143 PADT143 PAD

SPKR(40)

T138 PADT138 PAD
T135 PADT135 PAD
T130 PADT130 PAD

+3.3V_RUN

No Reboot strap.

12
12
12
12

12

R200

R200

*1K_NC

*1K_NC

Low = Default.
High = No Reboot.

Non-iAMT

RSV_ICH_CL_RST1#
ICH_RI#
SIO_EXT_SCI#
PCIE_WAKE#

ICH_SMBCLK
ICH_SMBDATA
RSV_ICH_CL_RST1#
ICH_SMBCLK
ICH_SMBDATA

ICH_RI#

RSV_LPCPD#

USB_MCARD1_DET#

CLKRUN#

PCIE_WAKE#
IRQ_SERIR Q
THERM_ALERT#

IMVP_PWRGD

USB_MCARD2_DET#
USB_MCARD3_DET#

SIO_EXT_SMI#
SIO_EXT_SCI#

PCIE_MCARD2_DET#
PCIE_MCARD3_DET#

PLTRST_DELAY#

SPKR
MCH_ICH_SYNC#

TP9
TP10
TP11

SPKR

3

U34C

U34C

G16

SMBCLK

A13

SMBDATA

E17

LINKALERT#/GPIO60/CLGPIO4

C17

SMLINK0

B18

SMLINK1

F19

RI#

R4

SUS_STAT#/LPCPD#

G19

SYS_RESET#

M6

PMSYNC#/GPIO0

A17

SMBALERT#/GPIO11

A14

STP_PCI#/GPIO15

E19

STP_CPU#/GPIO25

L4

CLKRUN#/GPIO32

E20

WAKE#

M5

SERIRQ

AJ23

THRM#

D21

VRMPWRGD

A20

TP8

AG19

TACH1/GPIO1

AH21

TACH2/GPIO6

AG21

TACH3/GPIO7

A21

GPIO8

C12

LANPHYPC/GPIO12

C21

ENGDET/GPIO13

AE18

TACH0/GPIO17

K1

GPIO18

AF8

GPIO20

AJ22

SCLOCK/GPIO22

A9

QRT_STATE0/GPIO27

D19

QRT_STATE1/GPIO28

L1

SATACLKREQ#/GPIO35

AE19

SLOAD/GPIO38

AG22

SDATAOUT0/GPIO39

AF21

SDATAOUT1/GPIO48

AH24

GPIO49

A8

GPIO57/CLGPIO5

M7

SPKR

AJ24

MCH_SYNC#

B21

TP3

AH20

TP9

AJ20

TP10

AJ21

TP11

ICH9M_verA3

ICH9M_verA3

+3.3V_RUN

R155

R155

8.2K

8.2K

1 2

CLK_ICH_14M
CLK_ICH_48M

ICH_SUSCLK

ICH_PWRGD
DPRSLPVR

ICH_BATLOW#

RSV_ICH_LAN_RST#

ICH_RSMRST#

ICH_CL_PWROK

RSV_ICH_CL_CLK1

RSV_ICH_CL_DATA1

CL_VREF0
CL_VREF1

CL_RST1#

RSV_GPIO24
RSV_GPIO10
RSV_GPIO14
RSV_WOL_EN

2

4

RP3

RP3

2.2KX2

2.2KX2

1

3

CLK_ICH_14M (17)
CLK_ICH_48M (17)

SIO_SLP_S3# (31)

SIO_SLP_S5# (31)

ICH_PWRGD (6,45)
DPRSLPVR (6,51)

R488 8.2KR488 8.2K

SIO_PWRBTN# (31)

ICH_RSMRST# (31)

CLK_PWRGD (17)

ICH_CL_PWROK (6,31)

CL_CLK0 (6)

CL_DATA0 (6)

ICH_CL_RST0# (6)

R188 8.2KR188 8.2K

Non-iAMT

MEM_SCLK (15,16)ICH_SMBCLK(30,33,34)

12

12

T148PAD T148PAD

T58PAD T58PAD

+3.3V_SUS

T53PAD T53PAD

T55PAD T55PAD

T136PAD T136PAD

T137PAD T137PAD

T139PAD T139PAD

T62PAD T62PAD
T56PAD T56PAD
T70PAD T70PAD
T54PAD T54PAD

+3.3V_SUS

6

CLK14
CLK48

SUSCLK

SLP_S3#
SLP_S4#
SLP_S5#

PWROK

BATLOW#

PWRBTN#

LAN_RST#

RSMRST#

CLPWROK

SLP_M#

CL_CLK0
CL_CLK1

CL_DATA0
CL_DATA1

CL_VREF0
CL_VREF1

CL_RST0#
CL_RST1#

+3.3V_RUN

AH23
AF19
AE21
AD20

H1
AF3

P1

C16
E16
G17

C10

G20

M2

B13

R3

D20

D22

R5

R6

B16

F24
B19

F22
C19

C25
A19

F21
D18

A16
C18
C11
C20

SATA0GP/GPIO21
SATA1GP/GPIO19
SATA4GP/GPIO36
SATA5GP/GPIO37

SATA

GPIO

SATA

GPIO

SMB

SMB

Clocks

Clocks

S4_STATE#/GPIO26

DPRSLPVR/GPIO16

SYS GPIO

SYS GPIO

Power MGTController Link

Power MGTController Link

CK_PWRGD

GPIO

GPIO

MEM_LED/GPIO24

ALERT#/GPIO10

NETDETECT/GPIO14

WOL_EN/GPIO9

MISC

MISC

SMbus address D2

These are for
backdrive issue.

2

Q26

ICH_SMBDATA(30,33,34) MEM_SDATA (15,16)

4

ICH_SMBDATA

ICH_SMBCLK

3 1

2N7002W-7-F

2N7002W-7-F

+3.3V_RUN

2

3 1

2N7002W-7-F

2N7002W-7-F

5

Q26

Q25

Q25

Place these close to ICH8.

CLK_ICH_48M

R235

R235
*10_NC

*10_NC

1 2
12

50

50

R524

R524
*10_NC

*10_NC

1 2
12

50

50

R162 10KR162 10K

R526 100KR526 100K

1 2

R152 10KR152 10K

R167 10KR167 10K

R198 1MR198 1M

R170 10KR170 10K

Non-iAMT

CLK_ICH_14M

ICH_PWRGD

DPRSLPVR

ICH_RSMRST#

RSV_ICH_LAN_RST#

ICH_CL_PWROK

RSV_GPIO10

DIS:ALW
UMA:SUS

Non-iAMT

CL_VREF0/1 ~=0.405V

Title

Title

Title

ICH9-M(PM,GPIO,SMB)

ICH9-M(PM,GPIO,SMB)

ICH9-M(PM,GPIO,SMB)

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

RM2 3A

RM2 3A

RM2 3A

Date: Sheet

Date: Sheet

Date: Sheet

+3.3V_RUN

R136

R136

3.24K/F

3.24K/F

CL_VREF0

12

C179

C179

0.1U

0.1U

10

10

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

7

R469

R469
*3.24K/F_NC

*3.24K/F_NC

1 2

1 2

CL_VREF1

12

12

C249

C249

R137

R137

*0.1U_NC

*0.1U_NC

453/F

453/F

10

10

C348

C348
*4.7P_NC

*4.7P_NC

C689

C689
*4.7P_NC

*4.7P_NC

12

12

12

12

12

+3.3V_SUS+3.3V_ALW

1 2

12

13 59Wednesday, August 13, 2008

13 59Wednesday, August 13, 2008

13 59Wednesday, August 13, 2008

8

+3.3V_SUS

R471

R471
*3.24K/F_NC

*3.24K/F_NC

R169

R169
*453/F_NC

*453/F_NC

of

of

of

1

http://hobi-elektronika.net

U34E

U34E

AA26

VSS[001]

AA27

VSS[002]

AA3

VSS[003]

AA6

VSS[004]

AB1

VSS[005]

AA23

VSS[006]

AB28

VSS[007]

AB29

VSS[008]

AB4

VSS[009]

AB5

VSS[010]

AC17

VSS[011]

AC26

VSS[012]

A A

B B

C C

D D

AC27

AC3

AD1
AD10
AD12
AD13
AD14
AD17
AD18
AD21
AD28
AD29

AD4

AD5

AD6

AD7

AD9
AE12
AE13
AE14
AE16
AE17

AE2
AE20
AE24

AE3

AE4

AE6

AE9
AF13
AF16
AF18
AF22
AH26
AF26
AF27

AF5

AF7

AF9

AG13
AG16
AG18
AG20
AG23

AG3

AG6

AG9

AH12
AH14
AH17
AH19

AH2

AH22
AH25
AH28

AH5

AH8
AJ12
AJ14
AJ17

B11

B14

B17

B20

B23

C26

C27

E11

E14

E18

E21

E24

G12

G14

G18

G21

G24

G26

G27

H23

H28

H29

AJ8

B2

B5
B8

E2

E5

E8
F16
F28
F29

G8
H2

VSS[013]
VSS[014]
VSS[015]
VSS[016]
VSS[017]
VSS[018]
VSS[019]
VSS[020]
VSS[021]
VSS[022]
VSS[023]
VSS[024]
VSS[025]
VSS[026]
VSS[027]
VSS[028]
VSS[029]
VSS[030]
VSS[031]
VSS[032]
VSS[033]
VSS[034]
VSS[035]
VSS[036]
VSS[037]
VSS[038]
VSS[039]
VSS[040]
VSS[041]
VSS[042]
VSS[043]
VSS[044]
VSS[045]
VSS[046]
VSS[047]
VSS[048]
VSS[049]
VSS[050]
VSS[051]
VSS[052]
VSS[053]
VSS[054]
VSS[055]
VSS[056]
VSS[057]
VSS[058]
VSS[059]
VSS[060]
VSS[061]
VSS[062]
VSS[063]
VSS[064]
VSS[065]
VSS[066]
VSS[067]
VSS[068]
VSS[069]
VSS[070]
VSS[071]
VSS[072]
VSS[073]
VSS[074]
VSS[075]
VSS[076]
VSS[077]
VSS[078]
VSS[079]
VSS[080]
VSS[081]
VSS[082]
VSS[083]
VSS[084]
VSS[085]
VSS[086]
VSS[087]
VSS[088]
VSS[089]
VSS[090]
VSS[091]
VSS[092]
VSS[093]
VSS[094]
VSS[095]
VSS[096]
VSS[097]
VSS[098]
VSS[099]
VSS[100]
VSS[101]
VSS[102]
VSS[103]
VSS[104]
VSS[105]
VSS[106]

ICH9M_verA3

ICH9M_verA3

1

VSS_NCTF[01]
VSS_NCTF[02]
VSS_NCTF[03]
VSS_NCTF[04]
VSS_NCTF[05]
VSS_NCTF[06]
VSS_NCTF[07]
VSS_NCTF[08]
VSS_NCTF[09]
VSS_NCTF[10]
VSS_NCTF[11]
VSS_NCTF[12]

VSS[107]
VSS[108]
VSS[109]
VSS[110]
VSS[111]
VSS[112]
VSS[113]
VSS[114]
VSS[115]
VSS[116]
VSS[117]
VSS[118]
VSS[119]
VSS[120]
VSS[121]
VSS[122]
VSS[123]
VSS[124]
VSS[125]
VSS[126]
VSS[127]
VSS[128]
VSS[129]
VSS[130]
VSS[131]
VSS[132]
VSS[133]
VSS[134]
VSS[135]
VSS[136]
VSS[137]
VSS[138]
VSS[139]
VSS[140]
VSS[141]
VSS[142]
VSS[143]
VSS[144]
VSS[145]
VSS[146]
VSS[147]
VSS[148]
VSS[149]
VSS[150]
VSS[151]
VSS[152]
VSS[153]
VSS[154]
VSS[155]
VSS[156]
VSS[157]
VSS[158]
VSS[159]
VSS[160]
VSS[161]
VSS[162]
VSS[163]
VSS[164]
VSS[165]
VSS[166]
VSS[167]
VSS[168]
VSS[169]
VSS[170]
VSS[171]
VSS[172]
VSS[173]
VSS[174]
VSS[175]
VSS[176]
VSS[177]
VSS[178]
VSS[179]
VSS[180]
VSS[181]
VSS[182]
VSS[183]
VSS[184]
VSS[185]
VSS[186]
VSS[187]
VSS[188]
VSS[189]
VSS[190]
VSS[191]
VSS[192]
VSS[193]
VSS[194]
VSS[195]
VSS[196]
VSS[197]
VSS[198]

H5
J23
J26
J27
AC22
K28
K29
L13
L15
L2
L26
L27
L5
L7
M12
M13
M14
M15
M16
M17
M23
M28
M29
N11
N12
N13
N14
N15
N16
N17
N18
N26
N27
P12
P13
P14
P15
P16
P17
P2
P23
P28
P29
P4
P7
R11
R12
R13
R14
R15
R16
R17
R18
R28
T12
T13
T14
T15
T16
T17
T23
B26
U12
U13
U14
U15
U16
U17
AD23
U26
U27
U3
V1
V13
V15
V23
V28
V29
V4
V5
W26
W27
W3
Y1
Y28
Y29
Y4
Y5
AG28
AH6
AF2
B25

A1
A2
A28
A29
AH1
AH29
AJ1
AJ2
AJ28
AJ29
B1
B29

2

2

+5V_RUN

+3.3V_RUN

Non-iAMT

+5V_SUS

+3.3V_SUS

+1.5V_RUN

L69

L69
BLM21PG331SN1D

BLM21PG331SN1D

805

805

12

+

+

C606

C606
220U

220U

4

4
7343

7343

+1.5V_RUN

Gur_0808: 0 ohm
removal, delete R172

10uH+-20%_100mA

+VCCSATPLL

12

C239

C239
1U

1U

10

10
603

603

Non-iAMT

Place C625
close to A27.

+1.5V_RUN

C196

C196

0.1U

0.1U

1 2

10

10

+RTC_CELL

R501 100R501 100

1 2

D28

D28

2 1

SDMK0340L-7-F

SDMK0340L-7-F

R535 10R535 10

1 2

D29

D29

2 1

SDMK0340L-7-F

SDMK0340L-7-F

646mA

L24

L24
10uH

10uH

805

805

3

12

C199

C199
1U

1U

1 2

603

603
10

10

+ICH_V5REF_RUN

12

C672

C672

2mA

1U

1U

603

603
10

10

+ICH_V5REF_SUS

2mA

C694

C694

0.1U

0.1U

1 2

10

10

FB_330ohm+-25%_100mHz_

1.5A_0.09 ohm DC

+1.5V_PCIE_ICH

12

12

12

C605

C605
22U

22U

10

10
1206

1206

C604

C604
22U

22U

10

10
1206

1206

47mA

C251

C251

VCC1_5_A TOTAL 1.342A

10U

10U

6.3

6.3
603

603

+1.5V_RUN

C278

C278

0.1U

0.1U

1 2

10

10

Non-iAMT

+3.3V_RUN

+1.5V_PCIE_ICH

3

C228

C228

0.1U

0.1U

10

10

C607

C607

2.2U

2.2U

1 2

10

10
805

805

+1.5V_RUN

+1.5V_RUN

+1.5V_RUN

T142PADT142PAD
T141PADT141PAD

1 2

12

C620

C620

0.1U

0.1U

1 2

10

10

11mA

1 2

C299

C299

0.1U

0.1U

10

10

C191

C191

4.7U

4.7U

6.3

6.3
603

603

C311

C311

0.1U

0.1U

10

10

+VCCSATPLL

12

C263

C263
1U

1U

10

10
603

603

12

C283

C283
1U

1U

10

10
603

603

TP_VCCSUSLAN1
TP_VCCSUSLAN2

19mA

+1.5V_RUN

23mA

80mA

+3.3V_RUN

1mA

4

4

A23

AE1

AA24
AA25
AB24
AB25
AC24
AC25
AD24
AD25
AE25
AE26
AE27
AE28
AE29

F25
G25
H24
H25

J24

J25

K24

K25

L23

L24

L25
M24
M25
N23
N24
N25

P24

P25
R24
R25
R26
R27

T24

T27

T28

T29
U24
U25

V24

V25
U23

W24
W25

K23

Y24

Y25

AJ19

AC16
AD15
AD16
AE15
AF15
AG15
AH15

AJ15

AC11
AD11
AE11
AF11
AG10
AG11
AH10

AJ10

AC9

AC18
AC19

AC21

G10

AC12
AC13
AC14

AJ5

AA7
AB6
AB7
AC6
AC7

A10

A11

A12

B12

A27

D28
D29

E26

E27

A26

U34F

U34F

VCCRTC

A6

V5REF

V5REF_SUS

VCC1_5_B[01]
VCC1_5_B[02]
VCC1_5_B[03]
VCC1_5_B[04]
VCC1_5_B[05]
VCC1_5_B[06]
VCC1_5_B[07]
VCC1_5_B[08]
VCC1_5_B[09]
VCC1_5_B[10]
VCC1_5_B[11]
VCC1_5_B[12]
VCC1_5_B[13]
VCC1_5_B[14]
VCC1_5_B[15]
VCC1_5_B[16]
VCC1_5_B[17]
VCC1_5_B[18]
VCC1_5_B[19]
VCC1_5_B[20]
VCC1_5_B[21]
VCC1_5_B[22]
VCC1_5_B[23]
VCC1_5_B[24]
VCC1_5_B[25]
VCC1_5_B[26]
VCC1_5_B[27]
VCC1_5_B[28]
VCC1_5_B[29]
VCC1_5_B[30]
VCC1_5_B[31]
VCC1_5_B[32]
VCC1_5_B[33]
VCC1_5_B[34]
VCC1_5_B[35]
VCC1_5_B[36]
VCC1_5_B[37]
VCC1_5_B[38]
VCC1_5_B[39]
VCC1_5_B[40]
VCC1_5_B[41]
VCC1_5_B[42]
VCC1_5_B[43]
VCC1_5_B[44]
VCC1_5_B[45]
VCC1_5_B[46]
VCC1_5_B[47]
VCC1_5_B[48]
VCC1_5_B[49]

VCCSATAPLL

VCC1_5_A[01]
VCC1_5_A[02]
VCC1_5_A[03]
VCC1_5_A[04]
VCC1_5_A[05]
VCC1_5_A[06]
VCC1_5_A[07]
VCC1_5_A[08]

VCC1_5_A[09]
VCC1_5_A[10]
VCC1_5_A[11]
VCC1_5_A[12]
VCC1_5_A[13]
VCC1_5_A[14]
VCC1_5_A[15]
VCC1_5_A[16]

VCC1_5_A[17]

VCC1_5_A[18]
VCC1_5_A[19]

VCC1_5_A[20]

VCC1_5_A[21]

G9

VCC1_5_A[22]

VCC1_5_A[23]
VCC1_5_A[24]
VCC1_5_A[25]

VCCUSBPLL

VCC1_5_A[26]
VCC1_5_A[27]
VCC1_5_A[28]
VCC1_5_A[29]
VCC1_5_A[30]

VCCLAN1_05[1]
VCCLAN1_05[2]

VCCLAN3_3[1]
VCCLAN3_3[2]

VCCGLANPLL

VCCGLAN1_5[1]
VCCGLAN1_5[2]
VCCGLAN1_5[3]
VCCGLAN1_5[4]

VCCGLAN3_3

ICH9M_verA3

ICH9M_verA3

VCC1_05[01]
VCC1_05[02]
VCC1_05[03]
VCC1_05[04]
VCC1_05[05]
VCC1_05[06]
VCC1_05[07]
VCC1_05[08]
VCC1_05[09]
VCC1_05[10]
VCC1_05[11]
VCC1_05[12]
VCC1_05[13]
VCC1_05[14]
VCC1_05[15]
VCC1_05[16]

CORE

CORE

VCC1_05[17]
VCC1_05[18]
VCC1_05[19]
VCC1_05[20]
VCC1_05[21]
VCC1_05[22]
VCC1_05[23]
VCC1_05[24]
VCC1_05[25]
VCC1_05[26]

VCCA3GP ATXARX USB CORE

VCCA3GP ATXARX USB CORE

V_CPU_IO[1]
V_CPU_IO[2]

VCCP_COREVCCPSUSVCCPUSB

VCCP_COREVCCPSUSVCCPUSB

PCI

PCI

VCCSUSHDA

VCCSUS1_05[1]
VCCSUS1_05[2]

VCCSUS1_5[1]

VCCSUS1_5[2]

VCCSUS3_3[01]
VCCSUS3_3[02]
VCCSUS3_3[03]
VCCSUS3_3[04]

VCCSUS3_3[05]

VCCSUS3_3[06]
VCCSUS3_3[07]
VCCSUS3_3[08]
VCCSUS3_3[09]
VCCSUS3_3[10]
VCCSUS3_3[11]
VCCSUS3_3[12]
VCCSUS3_3[13]
VCCSUS3_3[14]
VCCSUS3_3[15]
VCCSUS3_3[16]
VCCSUS3_3[17]
VCCSUS3_3[18]
VCCSUS3_3[19]
VCCSUS3_3[20]

VCCCL3_3[1]
VCCCL3_3[2]

GLAN POWER

GLAN POWER

VCCDMIPLL

VCC_DMI[1]
VCC_DMI[2]

VCC3_3[01]

VCC3_3[02]

VCC3_3[07]

VCC3_3[03]
VCC3_3[04]
VCC3_3[05]
VCC3_3[06]

VCC3_3[08]
VCC3_3[09]
VCC3_3[10]
VCC3_3[11]
VCC3_3[12]
VCC3_3[13]
VCC3_3[14]

VCCHDA

VCCCL1_05

VCCCL1_5

5

A15
B15
C15
D15
E15
F15
L11
L12
L14
L16
L17
L18
M11
M18
P11
P18
T11
T18
U11
U18
V11
V12
V14
V16
V17
V18

23mA

R29

48mA

W23
Y23

2mA

AB23
AC23

VCC3_3 308mA

AG29

AJ6

AC10

AD19
AF20
AG24
AC20

B9
F9
G3
G6
J2
J7
K7

AJ4

AJ3

TP_VCCSUS1.05_1

AC8

TP_VCCSUS1.05_2TP_VCCSUS1.05_2

F17

TP_VCCSUS1.5_1

AD8

TP_VCCSUS1.5_2

F18

A18
D16
D17
E22

AF1

VCCSUS 3_3 212mA

T1
T2
T3
T4
T5
T6
U6
U7
V6
V7
W6
W7
Y6
Y7
T7

+VCCCL1_05

G22

+VCCCL1_5

G23

A24
B24

19mA

5

6

+1.05V_VCCP

C293

C273

C273

0.1U

0.1U

1 2

10

10

C293

0.1U

0.1U

1 2

10

10

1uH+-30%_60mA

+1.5V_DMIPLL

C173

C173

0.01U

0.01U

1 2

25

25

+VCC_DMI_ICH

C302

C238

C238

0.1U

0.1U

1 2

10

10

C334

C334

0.1U

0.1U

1 2

10

10

C302

0.1U

0.1U

1 2

10

10

C319

C319

0.1U

0.1U

1 2

10

10

C304

C304

0.1U

0.1U

1 2

10

10

C326

C326

0.1U

0.1U

1 2

10

10

12

+3.3V_RUN

11mA

11mA

T73PAD T73PAD
T57PAD T57PAD

T74PAD T74PAD

1 2

C256 0.1U

C256 0.1U

10

10

12

C344

C344

0.022U/16V

0.022U/16V

WWAN Noise - ICH improvements

12

12

C318

C318
*0.1U_NC

*0.1U_NC

10

10

+3.3V_RUN

Non-iAMT

C323

C323
*0.1U_NC

*0.1U_NC

10

10

12

C321

C321
*0.1U_NC

*0.1U_NC

10

10

C220

C220

0.1U

0.1U

10

10

1 2

6

7

+1.05V_VCCP +1.5V_RUN

C168

C168
10U

10U

1 2

6.3

6.3
603

603

C233

C233
22U/4V/0805

22U/4V/0805

+3.3V_SUS

12

L15

L15
1uH

1uH

12

L21

L21

BLM21PG331SN1D

BLM21PG331SN1D

805

805

1 2

+3.3V_RUN

12

C693

C693

0.1U

0.1U

10

10

C330

C330

0.022U/16V

0.022U/16V

D27

D27

1

2

BAT54C T/R

BAT54C T/R

+1.5V_DMIPLL_R

C257

C257

0.1U

0.1U

10

10

12

C324

C324

0.1U

0.1U

10

10

12

C316

C316

0.1U

0.1U

10

10

R459

R459

3

1 2

10

10

805

805

R133 1R133 1

+1.05V_VCCP

C276

C276

0.1U

0.1U

1 2

10

10

Gur_0808: 0 ohm remo val,
delete R226, R231, R234, C345

+3.3V_SUS

+1.5V_RUN

12

12

C237

C237

4.7U

4.7U

603

603

6.3

6.3

RESERVE 1.5V_SUS FOR VCCSUSHDA

12

C313

C313
*0.1U_NC

*0.1U_NC

10

10

C219

C219
*1U_NC

*1U_NC

10

10
603

603

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

+3.3V_SUS

12

C320

C320

0.1U

0.1U

10

10

C347

C347
*1U/6.3V_NC

*1U/6.3V_NC

12

C231

C231

0.1U

0.1U

10

10

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

ICH9-M(POWER,GND)

ICH9-M(POWER,GND)

ICH9-M(POWER,GND)

RM2 3A

RM2 3A

RM2 3A

7

8

+1.05V_VCCP

WWAN Noise - ICH improvements

C258

C258
*0.1U_NC

*0.1U_NC

U4

U4

VIN3VOUT

1

SHDN

2

GND

*G913C_NC

*G913C_NC

10

10

12

C180

C180
*0.1U_NC

*0.1U_NC

SET

12

10

10

4

R1

5

R2

10

10

12

C337

C337
*0.1U_NC

*0.1U_NC

14 59Friday, August 08, 2008

14 59Friday, August 08, 2008

14 59Friday, August 08, 2008

+3.3V_RUN

R240

R240

*22.1K/F_NC

*22.1K/F_NC

R245

R245
*100K/F_NC

*100K/F_NC

8

12

C194

C194
*0.1U_NC

*0.1U_NC

10

10

+1.5V_SUS

C350

C350
*4.7U/6.3V_NC

*4.7U/6.3V_NC

of

of

of

1

http://hobi-elektronika.net

2

3

4

5

6

7

8

+3.3V_RUN

+1.5V_DDR

CN23A

CN23A

DDR-AS0A62X-U4RN-7F-204P

A A

DDR_A_MA[0..14](7)

Gur_0808: 0 ohm
removal, delete R161

DDR_A_BS0(7)
DDR_A_BS1(7)
DDR_A_BS2(7)

DDR_A_RAS#(7)
DDR_A_CAS#(7)
DDR_A_WE#(7)

B B

DDR_CS0_DIMMA#(6)
DDR_CS1_DIMMA#(6)

M_ODT0(6)
M_ODT1(6)

M_CLK_DDR1(6)
M_CLK_DDR#1(6)
M_CLK_DDR0(6)
M_CLK_DDR#0(6)

DDR_CKE0_DIMMA(6)
DDR_CKE1_DIMMA(6)

DDR_A_DM[0..7](7)

C C

DDR_A_DQS[0..7](7)
DDR_A_DQS#[0..7](7)

MEM_SDATA(13,16)

MEM_SCLK(13,16)

DDR_A_MA0
DDR_A_MA1
DDR_A_MA2
DDR_A_MA3
DDR_A_MA4
DDR_A_MA5
DDR_A_MA6
DDR_A_MA7
DDR_A_MA8
DDR_A_MA9
DDR_A_MA10
DDR_A_MA11
DDR_A_MA12
DDR_A_MA13
DDR_A_MA14

M_CLK_DDR1
M_CLK_DDR#1
M_CLK_DDR0
M_CLK_DDR#0

DDR_A_DM0
DDR_A_DM1
DDR_A_DM2
DDR_A_DM3
DDR_A_DM4
DDR_A_DM5
DDR_A_DM6
DDR_A_DM7

DDR_A_DQS0
DDR_A_DQS#0
DDR_A_DQS1
DDR_A_DQS#1
DDR_A_DQS2
DDR_A_DQS#2
DDR_A_DQS3
DDR_A_DQS#3
DDR_A_DQS4
DDR_A_DQS#4
DDR_A_DQS5
DDR_A_DQS#5
DDR_A_DQS6
DDR_A_DQS#6
DDR_A_DQS7
DDR_A_DQS#7

MEM_SDATA
MEM_SCLK

SM_MEM BUS ADDRESS

SO-DIMM0 1010 000

SO-DIMM1 1010 010

DDR-AS0A62X-U4RN-7F-204P

SO_DIMM204_DDR3

SO_DIMM204_DDR3

98

A0

A0

97

A1

A1

96

A2

A2

95

A3

A3

92

A4

A4

91

A5

A5

90

A6

A6

86

A7

A7

89

A8

A8

85

A9

A9

107

A10/AP

A10/AP

84

A11

A11

83

A12/BC*

A12/BC*

119

A13

A13

80

A14

A14

78

A15

A15

109

BA0

BA0

108

BA1

BA1

79

BA2

BA2

110

RAS*

RAS*

115

CAS*

CAS*

113

WE*

WE*

114

S0*

S0*

121

S1*

S1*

116

ODT0

ODT0

120

ODT1

ODT1

101

CK0

CK0

103

CK0*

CK0*

102

CK1

CK1

104

CK1*

CK1*

73

CKE0 DQ41

CKE0 DQ41

74

CKE1

CKE1

11

DM0

DM0

28

DM1

DM1

46

DM2

DM2

63

DM3

DM3

136

DM4

DM4

153

DM5

DM5

170

DM6

DM6

187

DM7

DM7

12

DQS0

DQS0

10

DQS0*

DQS0*

29

DQS1

DQS1

27

DQS1*

DQS1*

47

DQS2

DQS2

45

DQS2*

DQS2*

64

DQS3

DQS3

62

DQS3*

DQS3*

137

DQS4

DQS4

135

DQS4*

DQS4*

154

DQS5

DQS5

152

DQS5*

DQS5*

171

DQS6

DQS6

169

DQS6*

DQS6*

188

DQS7

DQS7

186

DQS7*

DQS7*

200

SDA

SDA

202

SCL

SCL

197

SA0

SA0

201

SA1

SA1

SO_DIMM204_DDR3

SO_DIMM204_DDR3

EVENT*

EVENT*

RESET*

RESET*

DQ10

DQ10
DQ11

DQ11
DQ12

DQ12
DQ13

DQ13
DQ14

DQ14
DQ15

DQ15
DQ16

DQ16
DQ17

DQ17
DQ18

DQ18
DQ19

DQ19
DQ20

DQ20
DQ21

DQ21
DQ22

DQ22
DQ23

DQ23
DQ24

DQ24
DQ25

DQ25
DQ26

DQ26
DQ27

DQ27
DQ28

DQ28
DQ29

DQ29
DQ30

DQ30
DQ31

DQ31
DQ32

DQ32
DQ33

DQ33
DQ34

DQ34
DQ35

DQ35
DQ36

DQ36
DQ

DQ
DQ38

DQ38
DQ39

DQ39
DQ40

DQ40

DQ42

DQ42
DQ43

DQ43
DQ44

DQ44
DQ45

DQ45
DQ46

DQ46
DQ47

DQ47
DQ48

DQ48
DQ49

DQ49
DQ50

DQ50
DQ51

DQ51
DQ52

DQ52
DQ53

DQ53
DQ54

DQ54
DQ55

DQ55
DQ56

DQ56
DQ57

DQ57
DQ58

DQ58
DQ59

DQ59
DQ60

DQ60
DQ61

DQ61
DQ62

DQ62
DQ63

DQ63

TEST

TEST

DQ0
DQ1

DQ1
DQ2

DQ2
DQ3

DQ3
DQ4

DQ4
DQ5

DQ5
DQ6

DQ6
DQ7

DQ7
DQ8

DQ8
DQ9

DQ9

37

37

DDR_A_D0

7

DDR_A_D3

15

DDR_A_D2

17

DDR_A_D5

4

DDR_A_D1

6

DDR_A_D6

16

DDR_A_D7

18

DDR_A_D8

21

DDR_A_D9

23

DDR_A_D10

33

DDR_A_D11

35

DDR_A_D12

22

DDR_A_D13

24

DDR_A_D15

34

DDR_A_D14

36

DDR_A_D21

39

DDR_A_D16

41

DDR_A_D23

51

DDR_A_D18

53

DDR_A_D17

40

DDR_A_D20

42

DDR_A_D22

50

DDR_A_D19

52

DDR_A_D24

57

DDR_A_D25

59

DDR_A_D30

67

DDR_A_D31

69

DDR_A_D28

56

DDR_A_D29

58

DDR_A_D26

68

DDR_A_D27

70

DDR_A_D32

129

DDR_A_D33

131

DDR_A_D34

141

DDR_A_D35

143

DDR_A_D36

130

DDR_A_D37

132

DDR_A_D38

140

DDR_A_D39

142

DDR_A_D40

147

DDR_A_D41

149

DDR_A_D47

157

DDR_A_D43

159

DDR_A_D44

146

DDR_A_D45

148

DDR_A_D46

158

DDR_A_D42

160

DDR_A_D49

163

DDR_A_D48

165

DDR_A_D50

175

DDR_A_D55

177

DDR_A_D52

164

DDR_A_D53

166

DDR_A_D54

174

DDR_A_D51

176

DDR_A_D60

181

DDR_A_D61

183

DDR_A_D62

191

DDR_A_D63

193

DDR_A_D57

180

DDR_A_D56

182

DDR_A_D58

192

DDR_A_D59

194

DDR_A_D4

5

DQ0

198

30

125

T43 PADT43 P AD

DDR_A_D[0..63] (7)

Gur_0808: 0 ohm remo val,
delete R78, R222

PM_EXTTS#0 (6)

DDR3_DRAMRST# (6,16)

+V_DDR_MCH_REF

+0.75V_DDR_VTT

12

C101

C101
10U/10V

10U/10V

CC0805

CC0805

12

C106

C106

0.1U/10V

0.1U/10V

12

C157

C157

0.1U/10V

0.1U/10V

12

C102

C102

0.1U/10V

0.1U/10V

+1.5V_DDR

+1.5V_DDR

12

C162

C162

4.7U/6.3V

4.7U/6.3V

CC0603

CC0603

12

C170

C170
10U/10V

10U/10V

CC0805

CC0805

CN23B

CN23B

DDR-AS0A62X-U4RN-7F-204P

DDR-AS0A62X-U4RN-7F-204P

SO_DIMM204_DDR3

SO_DIMM204_DDR3

199

VDDSPD

VDDSPD

1

VREFDQ

VREFDQ

126

VREFCA

VREFCA

77

NC

NC

122

NC

NC

203

VTT

VTT

204

VTT

VTT

2

VSS

VSS

3

VSS

VSS

8

VSS

VSS

9

VSS

VSS

13

VSS

VSS

14

VSS

VSS

19

VSS

VSS

20

VSS

VSS

25

VSS

VSS

26

VSS

VSS

31

VSS

VSS

32

VSS

VSS

37

VSS

VSS

38

VSS

VSS

43

VSS

VSS

44

VSS

VSS

48

VSS

VSS

49

VSS

VSS

54

VSS

VSS

55

VSS

VSS

60

VSS

VSS

61

VSS

VSS

65

VSS

VSS

66

VSS

VSS

71

VSS

VSS

72

VSS

VSS

127

VSS

VSS

128

VSS

VSS

133

VSS

VSS

134

VSS

VSS

SO_DIMM204_DDR3

SO_DIMM204_DDR3

12

C255

C255

4.7U/6.3V

4.7U/6.3V

CC0603

CC0603

12

C184

C184

0.1U/10V

0.1U/10V

12

C197

C197
1U/10V

1U/10V

CC0603

CC0603

12

C226

C226

0.1U/10V

0.1U/10V

12

12

VDD

VDD
VDD

VDD
VDD

VDD
VDD

VDD
VDD

VDD
VDD

VDD
VDD

VDD
VDD

VDD
VDD

VDD
VDD

VDD
VDD

VDD
VDD

VDD
VDD

VDD
VDD

VDD
VDD

VDD
VDD

VDD
VDD

VDD
VDD

VDD

VSS

VSS
VSS

VSS
VSS

VSS
VSS

VSS
VSS

VSS
VSS

VSS
VSS

VSS
VSS

VSS
VSS

VSS
VSS

VSS
VSS

VSS
VSS

VSS
VSS

VSS
VSS

VSS
VSS

VSS
VSS

VSS
VSS

VSS
VSS

VSS
VSS

VSS
VSS

VSS
VSS

VSS
VSS

VSS

C183

C183
1U/10V

1U/10V

CC0603

CC0603

C229

C229

0.1U/10V

0.1U/10V

75
76
81
82
87
88
93
94
99
100
105
106
111
112
117
118
123
124

138
139
144
145
150
151
155
156
161
162
167
168
172
173
178
179
184
185
189
190
195
196

12

12

C252

C252
1U/10V

1U/10V

CC0603

CC0603

C166

C166

0.1U/10V

0.1U/10V

12

+

+

C640

C640
*330U/6.3V_NC

*330U/6.3V_NC

CC7343

CC7343

D D

For EMI Reserved

M_CLK_DDR1
M_CLK_DDR0

1

R144 *200/F_NCR144 *200/F_NC

1 2

R143 *200/F_NCR143 *200/F_NC

1 2

2

M_CLK_DDR#1
M_CLK_DDR#0

Place ESD Protection diodes.

ESD1

MEM_SDATA

MEM_SCLK

3

ESD1

1

1

2

2
334

*RCLAMP0504S.TCT_NC

*RCLAMP0504S.TCT_NC

6

6

5

5

4

+3.3V_RUN

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

4

5

6

Date: Sheet

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

DDR3 SO-DIMM1 (204P)

DDR3 SO-DIMM1 (204P)

DDR3 SO-DIMM1 (204P)

RM2 3A

RM2 3A

RM2 3A

7

of

of

of

15 59Thursday, August 14, 2008

15 59Thursday, August 14, 2008

15 59Thursday, August 14, 2008

8

1

http://hobi-elektronika.net

2

3

4

5

6

7

8

+3.3V_RUN

+1.5V_DDR

CN22A

CN22A

DDR-AS0A62X-U8RN-7F-204P

A A

DDR_B_MA[0..14](7)

Gur_0808: 0 ohm
removal, delete R166

DDR_B_BS0(7)
DDR_B_BS1(7)
DDR_B_BS2(7)

DDR_B_RAS#(7)
DDR_B_CAS#(7)
DDR_B_WE#(7)

B B

DDR_CS2_DIMMB#(6)
DDR_CS3_DIMMB#(6)

M_ODT2(6)
M_ODT3(6)

M_CLK_DDR4(6)
M_CLK_DDR#4(6)
M_CLK_DDR3(6)
M_CLK_DDR#3(6)

DDR_CKE3_DIMMB(6)
DDR_CKE4_DIMMB(6)

DDR_B_DM[0..7](7)

C C

DDR_B_DQS[0..7](7)
DDR_B_DQS#[0..7](7)

MEM_SDATA(13,15)

MEM_SCLK(13,15)

DDR_B_MA0
DDR_B_MA1
DDR_B_MA2
DDR_B_MA3
DDR_B_MA4
DDR_B_MA5
DDR_B_MA6
DDR_B_MA7
DDR_B_MA8
DDR_B_MA9
DDR_B_MA10
DDR_B_MA11
DDR_B_MA12
DDR_B_MA13
DDR_B_MA14

M_CLK_DDR4
M_CLK_DDR#4
M_CLK_DDR3
M_CLK_DDR#3

DDR_B_DM0
DDR_B_DM1
DDR_B_DM2
DDR_B_DM3
DDR_B_DM4
DDR_B_DM5
DDR_B_DM6
DDR_B_DM7

DDR_B_DQS0
DDR_B_DQS#0
DDR_B_DQS1
DDR_B_DQS#1
DDR_B_DQS2
DDR_B_DQS#2
DDR_B_DQS3
DDR_B_DQS#3
DDR_B_DQS4
DDR_B_DQS#4
DDR_B_DQS5
DDR_B_DQS#5
DDR_B_DQS6
DDR_B_DQS#6
DDR_B_DQS7
DDR_B_DQS#7

+3.3V_RUN

D D

1

2

DDR-AS0A62X-U8RN-7F-204P

SO_DIMM204_DDR3

SO_DIMM204_DDR3

98

A0

A0

97

A1

A1

96

A2

A2

95

A3

A3

92

A4

A4

91

A5

A5

90

A6

A6

86

A7

A7

89

A8

A8

85

A9

A9

107

A10/AP

A10/AP

84

A11

A11

83

A12/BC*

A12/BC*

119

A13

A13

80

A14

A14

78

A15

A15

109

BA0

BA0

108

BA1

BA1

79

BA2

BA2

110

RAS*

RAS*

115

CAS*

CAS*

113

WE*

WE*

114

S0*

S0*

121

S1*

S1*

116

ODT0

ODT0

120

ODT1

ODT1

101

CK0

CK0

103

CK0*

CK0*

102

CK1

CK1

104

CK1*

CK1*

73

CKE0 DQ41

CKE0 DQ41

74

CKE1

CKE1

11

DM0

DM0

28

DM1

DM1

46

DM2

DM2

63

DM3

DM3

136

DM4

DM4

153

DM5

DM5

170

DM6

DM6

187

DM7

DM7

12

DQS0

DQS0

10

DQS0*

DQS0*

29

DQS1

DQS1

27

DQS1*

DQS1*

47

DQS2

DQS2

45

DQS2*

DQS2*

64

DQS3

DQS3

62

DQS3*

DQS3*

137

DQS4

DQS4

135

DQS4*

DQS4*

154

DQS5

DQS5

152

DQS5*

DQS5*

171

DQS6

DQS6

169

DQS6*

DQS6*

188

DQS7

DQS7

186

DQS7*

DQS7*

200

SDA

SDA

202

SCL

SCL

197

SA0

SA0

201

SA1

SA1

SO_DIMM204_DDR3

SO_DIMM204_DDR3

For EMI Reserved

M_CLK_DDR4
M_CLK_DDR3

R138 *200/F_NCR138 *200/F_NC
R142 *200/F_NCR142 *200/F_NC

1 2
1 2

3

EVENT*

EVENT*

RESET*

RESET*

DQ10

DQ10
DQ11

DQ11
DQ12

DQ12
DQ13

DQ13
DQ14

DQ14
DQ15

DQ15
DQ16

DQ16
DQ17

DQ17
DQ18

DQ18
DQ19

DQ19
DQ20

DQ20
DQ21

DQ21
DQ22

DQ22
DQ23

DQ23
DQ24

DQ24
DQ25

DQ25
DQ26

DQ26
DQ27

DQ27
DQ28

DQ28
DQ29

DQ29
DQ30

DQ30
DQ31

DQ31
DQ32

DQ32
DQ33

DQ33
DQ34

DQ34
DQ35

DQ35
DQ36

DQ36
DQ

DQ
DQ38

DQ38
DQ39

DQ39
DQ40

DQ40

DQ42

DQ42
DQ43

DQ43
DQ44

DQ44
DQ45

DQ45
DQ46

DQ46
DQ47

DQ47
DQ48

DQ48
DQ49

DQ49
DQ50

DQ50
DQ51

DQ51
DQ52

DQ52
DQ53

DQ53
DQ54

DQ54
DQ55

DQ55
DQ56

DQ56
DQ57

DQ57
DQ58

DQ58
DQ59

DQ59
DQ60

DQ60
DQ61

DQ61
DQ62

DQ62
DQ63

DQ63

TEST

TEST

DQ0

DQ0
DQ1

DQ1
DQ2

DQ2
DQ3

DQ3
DQ4

DQ4
DQ5

DQ5
DQ6

DQ6
DQ7

DQ7
DQ8

DQ8
DQ9

DQ9

37

37

M_CLK_DDR#4
M_CLK_DDR#3

DDR_B_D4

5

DDR_B_D5

7

DDR_B_D2

15

DDR_B_D7

17

DDR_B_D1

4

DDR_B_D0

6

DDR_B_D6

16

DDR_B_D3

18

DDR_B_D13

21

DDR_B_D12

23

DDR_B_D15

33

DDR_B_D14

35

DDR_B_D9

22

DDR_B_D8

24

DDR_B_D11

34

DDR_B_D10

36

DDR_B_D19

39

DDR_B_D16

41

DDR_B_D22

51

DDR_B_D23

53

DDR_B_D17

40

DDR_B_D20

42

DDR_B_D21

50

DDR_B_D18

52

DDR_B_D24

57

DDR_B_D25

59

DDR_B_D30

67

DDR_B_D27

69

DDR_B_D28

56

DDR_B_D29

58

DDR_B_D31

68

DDR_B_D26

70

DDR_B_D32

129

DDR_B_D37

131

DDR_B_D39

141

DDR_B_D35

143

DDR_B_D33

130

DDR_B_D36

132

DDR_B_D38

140

DDR_B_D34

142

DDR_B_D40

147

DDR_B_D45

149

DDR_B_D47

157

DDR_B_D46

159

DDR_B_D44

146

DDR_B_D41

148

DDR_B_D42

158

DDR_B_D43

160

DDR_B_D52

163

DDR_B_D48

165

DDR_B_D50

175

DDR_B_D55

177

DDR_B_D49

164

DDR_B_D53

166

DDR_B_D54

174

DDR_B_D51

176

DDR_B_D61

181

DDR_B_D60

183

DDR_B_D58

191

DDR_B_D62

193

DDR_B_D57

180

DDR_B_D56

182

DDR_B_D59

192

DDR_B_D63

194

198

30

125

T42 PADT42 P AD

DDR_B_D[0..63] (7)

Gur_0808: 0 ohm remo val,
delete R77, R221

PM_EXTTS#1 (6)

DDR3_DRAMRST# (6,15)

+1.5V_DDR

12

C186

C186

0.1U/10V

0.1U/10V

12

AC Stitch Cap

C185

C185

0.1U/10V

0.1U/10V

+V_DDR_MCH_REF

+0.75V_DDR_VTT

12

C193

C193

0.1U/10V

0.1U/10V

12

C95

C95
10U/10V

10U/10V

CC0805

CC0805

+1.5V_DDR

C159

C159

0.1U/10V

0.1U/10V

12

12

4

C198

C198

0.1U/10V

0.1U/10V

12

C225

C225

0.1U/10V

0.1U/10V

5

+1.5V_DDR

12

+1.5V_DDR

12

12

C104

C104

0.1U/10V

0.1U/10V

12

C160

C160

0.1U/10V

0.1U/10V

12

C103

C103

0.1U/10V

0.1U/10V

C164

C164

4.7U/6.3V

4.7U/6.3V

CC0603

CC0603

C171

C171
10U/10V

10U/10V

CC0805

CC0805

12

C250

C250

4.7U/6.3V

4.7U/6.3V

CC0603

CC0603

12

C230

C230

0.1U/10V

0.1U/10V

6

CN22B

CN22B

DDR-AS0A62X-U8RN-7F-204P

DDR-AS0A62X-U8RN-7F-204P

SO_DIMM204_DDR3

SO_DIMM204_DDR3

199

VDDSPD

VDDSPD

1

VREFDQ

VREFDQ

126

VREFCA

VREFCA

77

NC

NC

122

NC

NC

203

VTT

VTT

204

VTT

VTT

2

VSS

VSS

3

VSS

VSS

8

VSS

VSS

9

VSS

VSS

13

VSS

VSS

14

VSS

VSS

19

VSS

VSS

20

VSS

VSS

25

VSS

VSS

26

VSS

VSS

31

VSS

VSS

32

VSS

VSS

37

VSS

VSS

38

VSS

VSS

43

VSS

VSS

44

VSS

VSS

48

VSS

VSS

49

VSS

VSS

54

VSS

VSS

55

VSS

VSS

60

VSS

VSS

61

VSS

VSS

65

VSS

VSS

66

VSS

VSS

71

VSS

VSS

72

VSS

VSS

127

VSS

VSS

128

VSS

VSS

133

VSS

VSS

134

VSS

VSS

SO_DIMM204_DDR3

SO_DIMM204_DDR3

12

12

C218

C218
1U/10V

1U/10V

CC0603

CC0603

C172

C172

0.1U/10V

0.1U/10V

12

C163

C163
1U/10V

1U/10V

CC0603

CC0603

12

C227

C227

0.1U/10V

0.1U/10V

Title

Title

Title

DDR3 SO-DIMM2 (204P)

DDR3 SO-DIMM2 (204P)

DDR3 SO-DIMM2 (204P)

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

RM2 3A

RM2 3A

RM2 3A

Date: Sheet

Date: Sheet

Date: Sheet

7

75

VDD

VDD

76

VDD

VDD

81

VDD

VDD

82

VDD

VDD

87

VDD

VDD

88

VDD

VDD

93

VDD

VDD

94

VDD

VDD

99

VDD

VDD

100

VDD

VDD

105

VDD

VDD

106

VDD

VDD

111

VDD

VDD

112

VDD

VDD

117

VDD

VDD

118

VDD

VDD

123

VDD

VDD

124

VDD

VDD

138

VSS

VSS

139

VSS

VSS

144

VSS

VSS

145

VSS

VSS

150

VSS

VSS

151

VSS

VSS

155

VSS

VSS

156

VSS

VSS

161

VSS

VSS

162

VSS

VSS

167

VSS

VSS

168

VSS

VSS

172

VSS

VSS

173

VSS

VSS

178

VSS

VSS

179

VSS

VSS

184

VSS

VSS

185

VSS

VSS

189

VSS

VSS

190

VSS

VSS

195

VSS

VSS

196

VSS

VSS

12

C253

C253
1U/10V

1U/10V

CC0603

CC0603

12

C192

C192

0.1U/10V

0.1U/10V

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

12

+

+

C619

C619
*330U/6.3V_NC

*330U/6.3V_NC

CC7343

CC7343

of

of

of

16 59Thursday, August 14, 2008

16 59Thursday, August 14, 2008

16 59Thursday, August 14, 2008

8

1

http://hobi-elektronika.net

2

3

4

5

6

7

8

Add capacitor pads for improving WWAN.

Y3

Y3

21

14.318MHZ

14.318MHZ

CLK_XTAL_OUTCLK_XTAL_ IN

12

C267

C267

0.1U

0.1U

10

10

FSA
FSC
PCI_SIO
PCI_PCCARD
PCI_ICH
27M_SEL

SATA_CLKREQ#
CLK_3GPLLREQ#

12

C280

C280

0.1U

0.1U

10

10

R230 2.2R230 2.2

1 2

R185 2.2R185 2.2

1 2

R192 2.2R192 2.2

1 2

R191 2.2R191 2.2

1 2

C661

C661
33P

33P

50

50

1 2

R490 475/FR490 475/F
R491 475/FR491 475/F

1 2

R492 22R492 22

1 2

R493 22R493 22

1 2

R494 33R494 33
R195 33R195 33
R495 33R495 33

R486 33R486 33

R487 2.2KR487 2.2K

R497 10KR497 10K

R498 33R498 33

Gur_0808: 0 ohm remo val,
delete R485

+CK_VDD_MAIN

12

C242

C242

0.1U

0.1U

10

10

+CK_VDD_PCI

+CK_VDD_PLL3

+CK_VDD_48

+CK_VDD_SRC

2

1 2

1 2

12

C243

C243

0.1U

0.1U

10

10

12

12

12

12

12
12
12

12

12

C308

C308

0.1U

0.1U

10

10

C281

C281

0.1U

0.1U

10

10

C301

C301

0.1U

0.1U

10

10

C241

C241

0.1U

0.1U

10

10

+CK_VDD_PCI

+CK_VDD_PLL3
+CK_VDD_48
+CK_VDD_SRC

+CK_VDD_MAIN

SATA_CLKREQ#_C
CLK_3GPLLREQ#_C
PCI_PCCARD
PCI_SIO
27M_SEL
PCI_ICH

FSA

FSC

CLK_XTAL_OUT
CLK_XTAL_ IN

CLK_SDATA
CLK_SCLK

UMA without iAMT

12

12

C274

C274

C294

C294

0.1U

0.1U

0.1U

0.1U

10

10

10

10

12

C309

C309

0.1U

0.1U

10

10

12

C296

C296

4.7U

4.7U

6.3

6.3
603

603

C295

C295

0.1U

0.1U

10

10

1 2

3

C657 27P 50C657 27P 50

1 2

C662 *27P_NC 50C662 *27P_NC 50

1 2

C332 *27P_NC 50C332 *27P_NC 50

1 2

C331 *27P_NC 50C331 *27P_NC 50

1 2

C666 *27P_NC 50C666 *27P_NC 50

1 2

C322 *27P_NC 50C322 *27P_NC 50

1 2

A A

C673

C673
33P

33P

50

50

1 2

CLK_LPC_DEBUG FOR DEBUG NEED POP RESISTOR

B B

+3.3V_RUN

14.318MHz

SATA_CLKREQ#(13)

CLK_3GPLLREQ#(6)

CLK_LPC_DEBUG(34)
CLK_PCI_PCCARD(28)

CLK_PCI_8512(31)

CLK_PCI_DEBUG(56)

CLK_PCI_ICH(12)

CLK_ICH_48M(13)

CPU_MCH_BSEL0(3,6)
CPU_MCH_BSEL1(3,6)
CPU_MCH_BSEL2(3,6)

CLK_ICH_14M(13)

CLK_PWRGD(13)

L36 BLM21PG600SN1D

L36 BLM21PG600SN1D

805

805

120 ohms@100Mhz

C C

L35 BLM21PG600SN1D

L35 BLM21PG600SN1D

805

805

120 ohms@100Mhz

D D

1

C259

C259

*10U_NC

*10U_NC

1 2

6.3

6.3

U36

U36

9

VDD_PCI

4

VDD_REF

23

VDD_PLL3

16

VDD_48

46

VDD_SRC

62

VDD_CPU

19

VDD_IO

27

VDD_IO

33

VDD_IO

43

VDD_IO

52

VDD_IO

56

VDD_IO

15

GND

18

GND

22

GND

26

GND

30

GND

36

GND

49

GND

59

GND

1

GND

8

CR#_A/PCI-0

10

CR_B/PCI-1

11

TME/PCI-2

12

SRC5_EN/PCI-3

13

27M_SEL/PCI-4

14

ITP_EN/PCIF-5#

17

FSA/USB48

64

FSB/TEST_MODE

5

FSC/TEST_SEL/REF

55

RESET#

63

CK_PWRGD/PD#

2

XOUT

3

XIN

6

SDATA

7

SCLK

SLG8SP513V

SLG8SP513V

SMbus address D2

These are for
backdrive issue.

CK505

CK505

QFN64

QFN64

SMBDAT1(26,31,39)

SMBCLK1(26,31,39)

4

CPU-0

CPU-0#

CPU-1

CPU-1#

SRC-8/CPU_ITP

SRC-8#/CPU_ITP#

SRC-0/DOT96

SRC-0#/DOT96#

SRC-1/SE1

SRC-1#/SE2

SRC-2/SATA

SRC-2#/SATA#

CR#_C/SRC-3

CR#_D/SRC-3#

SRC-4

SRC-4#

PCI_STOP#/SRC-5

CPU_STOP#/SRC5-5#

SRC-6

SRC-6#

CR#_F/SRC-7

CR#_E/SRC-7#

SRC-9

SRC-9#

SRC-10

SRC-10#

CR#_H/SRC-11

CR#_G/SRC-11#

GND

3 1

3 1

CPU_BCLK

61

CPU_BCLK#

60

MCH_BCLK

58

MCH_BCLK#

57

CPU_ITP

54

CPU_ITP#

53

DOT96_SSC

20

DOT96_SSC#

21

27M_NSS

24

27M_SS

25

PCIE_SATA

28

PCIE_SATA#

29

PCIE_MINI3

31

PCIE_MINI3#

32

MCH_3GPLL

34

MCH_3GPLL#

35

45
44

PCIE_EXPCARD

48

PCIE_EXPCARD#

47

MINI1CLK_REQ#_C MINI1CLK_REQ#

51
50

PCIE_MINI2

37

PCIE_MINI2#

38

PCIE_ICH

41

PCIE_ICH#

42

PCIE_LOM

40

PCIE_LOM#

39

65

+3.3V_RUN

RP4

RP4

2.2KX2

2.2KX2

2

2N7002W-7-F

2N7002W-7-F

+3.3V_RUN

2

2N7002W-7-F

2N7002W-7-F

Non-iAMT 27M_SEL

2

4

1

3

Q28

Q28

CLK_SDATA

Q27

Q27

CLK_SCLK

5

4
2

4
2

4
2

2
4

2
4

2
4

2
4

2
4

4
2

R484 475/FR484 475/F

1 2

R482 475/FR482 475/F

1 2

2
4

2
4

4
2

Gur_0808: delete reserved
ITP clock & ITP_EN circuit

RP19 0RP19 0

3
1

RP18 0RP18 0

3
1

RP16 0RP16 0

3
1

RP20 0RP20 0

1
3

RP17 33RP17 33

1
3

RP15 0RP15 0

1
3

RP13 0RP13 0

1
3

RP12 0RP12 0

1
3

RP8 0RP8 0

3
1

RP11 0RP11 0

1
3

RP9 0RP9 0

1
3

RP10 0RP10 0

3
1

27M_SEL

+3.3V_RUN

6

H_STP_PCI#
H_STP_CPU#

CARD_CLK_REQ#CARD_CLK_REQ#_C

R202

R202
10K

10K

1 2

R213

R213
*10K_NC

*10K_NC

1 2

CLK_CPU_BCLK (3)
CLK_CPU_BCLK# (3)

CLK_MCH_BCLK (5)
CLK_MCH_BCLK# (5)

CLK_PCIE _MINI1 ( 33)
CLK_PCIE _MINI1# (33)

CLK_PCIE_VGA (18)
CLK_PCIE_VGA# (18)

CLK_VGA_27M_NSS (19)

CLK_VGA_27M_SS (19)

CLK_PCIE_SATA (11)
CLK_PCIE_SATA# (11)

CLK_PCIE _MINI3 ( 34)
CLK_PCIE _MINI3# (34)

CLK_MCH_3GPLL (6)
CLK_MCH_3GPLL# (6)

H_STP_PCI# (13)
H_STP_CPU# (13)

CLK_PCIE_EXPCARD (30)
CLK_PCIE_EXPCARD# (30)

MINI1CLK_REQ# (33)
CARD_CLK_REQ# (30)

CLK_PCIE _MINI2 ( 34)
CLK_PCIE _MINI2# (34)

CLK_PCIE_ICH (12)
CLK_PCIE_ICH# (12)

CLK_PCIE_LOM (43)
CLK_PCIE_LOM# (43)

CLK_3GPLLREQ#
SATA_CLKREQ#
CARD_CLK_REQ#
MINI1CLK_REQ#
PCI_PCCARD

PCI_SIO

Mini Card (WLAN)

to ATI VGA

Mini Card (WPAN)

H_STP_PCI#
H_STP_CPU#

R474 10KR474 10K
R165 10KR165 10K

Mini Card (WWAN)

R500 10KR500 10K
R499 10KR499 10K
R481 10KR481 10K
R483 10KR483 10K
R212 *10K_NCR212 *10K_NC

1 2

R214 *10K_NCR214 *10K_NC

1 2

12
12

12
12
12
12

FSC FSB FSA CPU SRC PCI

100

1

0

0

1

0

1

00

1

0

1

1

1

1

27M_SEL
(PIN13)

0=UMA

1 = Disc.
GRFX down

PIN20 PIN21 PIN24 PIN25

DOT96T

DOT96C

SRCT0 SRCC0

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet of

Date: Sheet

Date: Sheet

COMPUTER

CLOCK GENERATOR

CLOCK GENERATOR

CLOCK GENERATOR

RM2 3A

RM2 3A

RM2 3A

7

1

10

1

0

0

0

0

1

96/
100M_T

27Mout

100

133

166

200

266

333

400

RSVD

100

100

100

100

100

100

100

27MSSout

17 59Friday, August 08, 2008

17 59Friday, August 08, 2008

17 59Friday, August 08, 2008

8

96/
100M_C

of

of

+3.3V_RUN

+3.3V_RUN

330

33

33

33

33

33

33

33

5

http://hobi-elektronika.net

4

3

2

1

PCIE_MTX_GRX_P[0..15](6)
PCIE_MTX_GRX_N[0..15](6)

D D

C C

CLK_PCIE_VGA(17)
CLK_PCIE_VGA#(17)

PLTRST_DELAY#(13)

PCIE_MTX_GRX_P0
PCIE_MTX_GRX_N0

PCIE_MTX_GRX_P1
PCIE_MTX_GRX_N1

PCIE_MTX_GRX_P2
PCIE_MTX_GRX_N2

PCIE_MTX_GRX_P3
PCIE_MTX_GRX_N3

PCIE_MTX_GRX_P4
PCIE_MTX_GRX_N4

PCIE_MTX_GRX_P5
PCIE_MTX_GRX_N5

PCIE_MTX_GRX_P6
PCIE_MTX_GRX_N6

PCIE_MTX_GRX_P7
PCIE_MTX_GRX_N7

PCIE_MTX_GRX_P8
PCIE_MTX_GRX_N8

PCIE_MTX_GRX_P9
PCIE_MTX_GRX_N9

PCIE_MTX_GRX_P10
PCIE_MTX_GRX_N10

PCIE_MTX_GRX_P11
PCIE_MTX_GRX_N11

PCIE_MTX_GRX_P12
PCIE_MTX_GRX_N12

PCIE_MTX_GRX_P13
PCIE_MTX_GRX_N13

PCIE_MTX_GRX_P14
PCIE_MTX_GRX_N14

PCIE_MTX_GRX_P15
PCIE_MTX_GRX_N15

Gur_0808: 0 ohm
remova l, delete R19 9

AK33

AJ33

AJ35
AJ34

AH35
AH34

AG35
AG34

AF33
AE33

AE35
AE34

AD35
AD34

AC35
AC34

AB33
AA33

AA35
AA34

AJ31
AJ30

AK35
AK34

AM32

Y35
Y34

W35
W34

V33
U33

U35
U34

T35
T34

R35
R34

U38A

U38A

PCIE_RX0P
PCIE_RX0N

PCIE_RX1P
PCIE_RX1N

PCIE_RX2P
PCIE_RX2N

PCIE_RX3P
PCIE_RX3N

PCIE_RX4P
PCIE_RX4N

PCIE_RX5P
PCIE_RX5N

PCIE_RX6P
PCIE_RX6N

PCIE_RX7P
PCIE_RX7N

PCIE_RX8P
PCIE_RX8N

PCIE_RX9P
PCIE_RX9N

PCIE_RX10P
PCIE_RX10N

PCIE_RX11P
PCIE_RX11N

PCIE_RX12P
PCIE_RX12N

PCIE_RX13P
PCIE_RX13N

PCIE_RX14P
PCIE_RX14N

PCIE_RX15P
PCIE_RX15N

Clock

Clock

PCIE_REFCLKP
PCIE_REFCLKN

SM Bus

SM Bus

NC_SMB_DATA
NC_SMBCLK

PERSTB

M86-ME XT A11

M86-ME XT A11

PART 1 OF 7

PART 1 OF 7

P

P
C

C
I

I

-

­E

E
X

X
P

P
R

R
E

E
S

S
S

S

I

I
N

N
T

T
E

E
R

R
F

F
A

A
C

C
E

E

PCIE_TX0P
PCIE_TX0N

PCIE_TX1P
PCIE_TX1N

PCIE_TX2P
PCIE_TX2N

PCIE_TX3P
PCIE_TX3N

PCIE_TX4P
PCIE_TX4N

PCIE_TX5P
PCIE_TX5N

PCIE_TX6P
PCIE_TX6N

PCIE_TX7P
PCIE_TX7N

PCIE_TX8P
PCIE_TX8N

PCIE_TX9P
PCIE_TX9N

PCIE_TX10P

PCIE_TX10N

PCIE_TX11P

PCIE_TX11N

PCIE_TX12P

PCIE_TX12N

PCIE_TX13P

PCIE_TX13N

PCIE_TX14P

PCIE_TX14N

PCIE_TX15P

PCIE_TX15N

Calibration

Calibration

PCIE_CALRN

PCIE_CALRP

NC_DRAM_0
NC_DRAM_1

NC_AC_ BATT

NC_FAN_TACH

AG31
AG30

AF31
AF30

AF28
AF27

AD31
AD30

AD28
AD27

AB31
AB30

AB28
AB27

AA31
AA30

AA28
AA27

W31
W30

W28
W27

V31
V30

V28
V27

U31
U30

U28
U27

R31
R30

AG26

AJ27

AF3
AG9
AK29
AK14

PCIE_MRX_GTX_C_P0
PCIE_MRX_GTX_C_N0

PCIE_MRX_GTX_C_P1
PCIE_MRX_GTX_C_N1

PCIE_MRX_GTX_C_P2
PCIE_MRX_GTX_C_N2

PCIE_MRX_GTX_C_P3
PCIE_MRX_GTX_C_N3

PCIE_MRX_GTX_C_P4
PCIE_MRX_GTX_C_N4

PCIE_MRX_GTX_C_P5
PCIE_MRX_GTX_C_N5

PCIE_MRX_GTX_C_P6
PCIE_MRX_GTX_C_N6

PCIE_MRX_GTX_C_P7
PCIE_MRX_GTX_C_N7

PCIE_MRX_GTX_C_P8
PCIE_MRX_GTX_C_N8

PCIE_MRX_GTX_C_P9
PCIE_MRX_GTX_C_N9

PCIE_MRX_GTX_C_P10
PCIE_MRX_GTX_C_N10

PCIE_MRX_GTX_C_P11
PCIE_MRX_GTX_C_N11

PCIE_MRX_GTX_C_P12
PCIE_MRX_GTX_C_N12

PCIE_MRX_GTX_C_P13
PCIE_MRX_GTX_C_N13

PCIE_MRX_GTX_C_P14
PCIE_MRX_GTX_C_N14

PCIE_MRX_GTX_C_P15
PCIE_MRX_GTX_C_N15

R238 2K/FR238 2K/F

R168

R168

1.27K

1.27K

+PCIE_VDDC

PCIE_MRX_GTX_C_P0

PCIE_MRX_GTX_C_P1

PCIE_MRX_GTX_C_P2

PCIE_MRX_GTX_C_P3

PCIE_MRX_GTX_C_P4

PCIE_MRX_GTX_C_P5

PCIE_MRX_GTX_C_P6

PCIE_MRX_GTX_C_P7

PCIE_MRX_GTX_C_P8

PCIE_MRX_GTX_C_P9

PCIE_MRX_GTX_C_P10

PCIE_MRX_GTX_C_P11

PCIE_MRX_GTX_C_P12

PCIE_MRX_GTX_C_P13

PCIE_MRX_GTX_C_P14

PCIE_MRX_GTX_C_P15

PCIE_MRX_GTX_C_N0

PCIE_MRX_GTX_C_N1

PCIE_MRX_GTX_C_N2

PCIE_MRX_GTX_C_N3

PCIE_MRX_GTX_C_N4

PCIE_MRX_GTX_C_N5

PCIE_MRX_GTX_C_N6

PCIE_MRX_GTX_C_N7

PCIE_MRX_GTX_C_N8

PCIE_MRX_GTX_C_N9

PCIE_MRX_GTX_C_N10

PCIE_MRX_GTX_C_N11

PCIE_MRX_GTX_C_N12

PCIE_MRX_GTX_C_N13

PCIE_MRX_GTX_C_N14

PCIE_MRX_GTX_C_N15

C638 0.1UC638 0.1U

C650 0.1UC650 0.1U

C644 0.1UC644 0.1U

C653 0.1UC653 0.1U

C643 0.1UC643 0.1U

C649 0.1UC649 0.1U

C665 0.1UC665 0.1U

C668 0.1UC668 0.1U

C654 0.1UC654 0.1U

C679 0.1UC679 0.1U

C639 0.1UC639 0.1U

C674 0.1UC674 0.1U

C669 0.1UC669 0.1U

C683 0.1UC683 0.1U

C671 0.1UC671 0.1U

C677 0.1UC677 0.1U

C641 0.1UC641 0.1U

C648 0.1UC648 0.1U

C645 0.1UC645 0.1U

C656 0.1UC656 0.1U

C642 0.1UC642 0.1U

C646 0.1UC646 0.1U

C660 0.1UC660 0.1U

C663 0.1UC663 0.1U

C652 0.1UC652 0.1U

C675 0.1UC675 0.1U

C637 0.1UC637 0.1U

C678 0.1UC678 0.1U

C664 0.1UC664 0.1U

C682 0.1UC682 0.1U

C667 0.1UC667 0.1U

C680 0.1UC680 0.1U

PCIE_MRX_GTX_P0

PCIE_MRX_GTX_P1

PCIE_MRX_GTX_P2

PCIE_MRX_GTX_P3

PCIE_MRX_GTX_P4

PCIE_MRX_GTX_P5

PCIE_MRX_GTX_P6

PCIE_MRX_GTX_P7

PCIE_MRX_GTX_P8

PCIE_MRX_GTX_P9

PCIE_MRX_GTX_P10

PCIE_MRX_GTX_P11

PCIE_MRX_GTX_P12

PCIE_MRX_GTX_P13

PCIE_MRX_GTX_P14

PCIE_MRX_GTX_P15

PCIE_MRX_GTX_N0

PCIE_MRX_GTX_N1

PCIE_MRX_GTX_N2

PCIE_MRX_GTX_N3

PCIE_MRX_GTX_N4

PCIE_MRX_GTX_N5

PCIE_MRX_GTX_N6

PCIE_MRX_GTX_N7

PCIE_MRX_GTX_N8

PCIE_MRX_GTX_N9

PCIE_MRX_GTX_N10

PCIE_MRX_GTX_N11

PCIE_MRX_GTX_N12

PCIE_MRX_GTX_N13

PCIE_MRX_GTX_N14

PCIE_MRX_GTX_N15

PCIE_MRX_GTX_P[0..15] ( 6)

PCIE_MRX_GTX_N[0..15] (6)

B B

A A

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

M86XT_PCIE

M86XT_PCIE

M86XT_PCIE

RM2 3A

RM2 3A

RM2 3A

1

of

of

of

18 59Friday, August 08, 2008

18 59Friday, August 08, 2008

18 59Friday, August 08, 2008

5

4

Title

Title

Title

Size Docum ent Number Rev

Size Docum ent Number Rev

Size Docum ent Number Rev

Date: Sheet

Date: Sheet

3

2

Date: Sheet

5

http://hobi-elektronika.net

MEMORY APERTURE SIZE SELECT

MEMORY

CFG3

CFG2

CFG1

SIZE

GPIO9

128MB

256MB

64MB

512MB

+3.3V_DELAY

D D

R298 *10K_NCR298 *10K_NC
R560 *10K_NCR560 *10K_NC
R564 10KR564 10K
R296 *10K_NCR296 *10K_NC

+1.8V_RUN

R515 10KR515 10K
R512 *10K_NCR512 *10K_NC
R528 *10K_NCR528 *10K_NC
R521 10KR521 10K

+3.3V_DELAY

R540 10KR540 10K
R549 10KR549 10K
R563 *10K_NCR563 *10K_NC
R294 *10K_NCR294 *10K_NC
R556 *10K_NCR556 *10K_NC
R557 *10K_NCR557 *10K_NC
R293 *10K_NCR293 *10K_NC
R567 *10K_NCR567 *10K_NC
R295 *10K_NCR295 *10K_NC
R218 10KR218 10K
R288 10KR288 10K
R275 *10K_NCR275 *10K_NC

R276 10KR276 10K

C C

ATI_DP_HPD(25)

B B

CLK_VGA_27M_SS( 17)

CLK_VGA_27M_NSS(17)

A A

GPIO13

X

0

X

00

X

X0

1

RAM_CFG0
RAM_CFG1
RAM_CFG2
RAM_CFG3

RAM_TYPE_CFG0
RAM_TYPE_CFG1
RAM_TYPE_CFG2
RAM_TYPE_CFG3

1 2

R507

R507

10K

10K

Q66

Q66

MMST3904-7-F

MMST3904-7-F

R513

R513

10K

10K

OSC_SPREAD(22)

OSC_OUT(22)

GPIO12

00

GPIO0
GPIO1
GPIO2
GPIO3
GPIO4
GPIO5
GPIO6
HDMI_HD_EN
GPIO10
VGAHSYNC
GFX_CLKREQ#
TEMP_FAIL#

TEMP_FAIL#

+3.3V_DELAY

MMST3904-7-F

MMST3904-7-F

2

1 3

R190 100/FR190 100/F

R189 120/FR189 120/F

CLK_VGA_27M_NSS_R

R183 *1M_NCR183 *1M_NC

12

C290

C290

*18P_NC

*18P_NC

50

50

5

CFG0
GPIO11

1

0001

VRAM SIZE

VRAM TYPE

GPIO_23_CLKREQB
DRIVES LOW
DURING RESET

R523

R523

10K

10K

Q67

Q67

2

12

Y2

21

*27MHZ_NCY2*27MHZ_NC

GPIO14_HPD2

1 3

GFX_CORE_CNTRL0(52)

GFX_CORE_CNTRL1(52)

Gur_0808: 0 ohm removal,
delete R287, R574

R299 *0_NCR299 *0_NC

1 2

R300 *0_NCR300 *0_NC

1 2

R187 0R187 0

1 2

R184 *0_NCR184 *0_NC

1 2

R181 *0_NCR181 *0_NC

1 2

12

C275

C275

*18P_NC

*18P_NC

50

50

THERMAL_INT#(22)

+1.8V_RUN

R267

R267

499/F

499/F

R270

R270

249/F

249/F

CLK_VGA_27M_SS_R

12

R303

R303
*10K_NC

*10K_NC

ATI_PANEL_BKEN(31)

Gur_0808: 0 ohm
remova l, delete R27 3

TEMP_FAIL#(20)

BB_ENA(20)

PLACE VREF
DIVIDER
AND CAP CLOSE
TO ASIC

4

+3.3V_DELAY

8/15: The strap on VIP[3] is
for enabling HD Audio on M86.

R255

R255
R249

R249
R258

R258
R246

R246
R253

R253
R237

R237
R250

R250
R263

R263

R241

R241

R510

R510

R534

R534

TEMP_FAIL#

GFX_CLKREQ#

C398

C398

100nF

100nF

VGA_THERMDN(22)
VGA_THERMDP(22)

+DPLL_PVDD

+PCIE_PVDD

+DPLL_VDDC

4

*10K_NC

*10K_NC

VIP_0

*10K_NC

*10K_NC

VIP_1

*10K_NC

*10K_NC

VIP_2

10K

10K

VIP_3

*10K_NC

*10K_NC

VIP_4

*10K_NC

*10K_NC

VIP_5

*10K_NC

*10K_NC

VIP_6

*10K_NC

*10K_NC

VIP_7

*10K_NC

*10K_NC

VHAD0

*10K_NC

*10K_NC

*10K_NC

*10K_NC

RAM_TYPE_CFG0
RAM_TYPE_CFG1
RAM_TYPE_CFG2
RAM_TYPE_CFG3

GPIO0
GPIO1
GPIO2
GPIO3
GPIO4
GPIO5
GPIO6

HDMI_HD_EN
RAM_CFG3
GPIO10
RAM_CFG0
RAM_CFG1
RAM_CFG2
GPIO14_HPD2

CLK_VGA_27M_SS_R

T93 PADT93 PAD

T87 PADT87 PAD

T95 PADT95 PAD
T89 PADT89 PAD
T92 PADT92 PAD
T90 PADT90 PAD
T85 PADT85 PAD
T86 PADT86 PAD
T84 PADT84 PAD
T146 PADT 146 PAD
T150 PADT 150 PAD
T82 PADT82 PAD
T149 PADT 149 PAD

+MPVDD

XTAIN
XTAOUT

PSYNC

DVALID

1KR305 1KR305

U38B

U38B

AM12

VIP_0

AL12

VIP_1

AJ12

VIP_2

AH12

VIP_3

AM10

VIP_4

AL10

VIP_5

AJ10

VIP_6

AH10

VIP_7

AM9

VHAD_0

AL9

VHAD_1

AJ9

VPHCTL

AL7

VPCLK0

AK7

VIPCLK

AM7

PSYNC

AJ7

DVALID

AK6

SDA

AM6

SCL

AN8

DVPCNTL__MVP_0

AP8

DVPCNTL__MVP_1

AG1

DVPCNTL_0

AH3

DVPCNTL_1

AH2

DVPCNTL_2

AH1

DVPCLK

AJ3

DVPDATA_ 0

AJ2

DVPDATA_ 1

AJ1

DVPDATA_ 2

AK2

DVPDATA_ 3

AK1

DVPDATA_ 4

AL3

DVPDATA_ 5

AL2

DVPDATA_ 6

AL1

DVPDATA_ 7

AM3

DVPDATA_ 8

AM2

DVPDATA_ 9

AN2

DVPDATA_ 10

AP3

DVPDATA_ 11

AR3

DVPDATA_ 12

AN4

DVPDATA_ 13

AR4

DVPDATA_ 14

AP4

DVPDATA_ 15

AN5

DVPDATA_ 16

AR5

DVPDATA_ 17

AP5

DVPDATA_ 18

AP6

DVPDATA_ 19

AR6

DVPDATA_ 20

AN7

DVPDATA_ 21

AP7

DVPDATA_ 22

AR7

DVPDATA_ 23

AG2

GPIO_0

AF2

GPIO_1

AF1

GPIO_2

AE3

GPIO_3

AE2

GPIO_4

AE1

GPIO_5

AD3

GPIO_6

AD2

GPIO_7_BLON

AD1

GPIO_8_ROMSO

AD5

GPIO_9_ROMSI

AD4

GPIO_10_ROMSCK

AC3

GPIO_11

AC2

GPIO_12

AC1

GPIO_13

AB3

GPIO_14_HPD2

AB2

GPIO_15_PWRCNTL_0

AB1

GPIO_16_SSIN

AF5

GPIO_17_THERMAL_INT

AF4

GPIO_18_HPD3

AG4

GPIO_19_CTF

AG3

GPIO_20_PWRCNTL_1

AD9

GPIO_21_BBEN

AD8

GPIO_22_ROMCSB

AD7

GPIO_23_CLKREQB

AB4

GPIO_24_JMODE

AB6

GPIO_25_TDI

AB7

GPIO_26_TCK

AB9

GPIO_27_TMS

AA9

GPIO_28_TDO

AF8

GEN_A

AF7

GEN_B

AG5

GEN_C

AP9

GEN_D_HPD4

AR9

GEN_E

AP13

GEN_F

AR13

GEN_G

AD12

VREFG

AR20

DPLL_PVDD

AP20

DPLL_PVSS

AM35

PCIE_PVDD

A14

MPVDD

B15

MPVSS

AR33

XTALIN

AP33

XTALOUT

AG19

DPLL_VDDC

AG21

TS_FDO

AK4

DMINUS

AM4

DPLUS

M86-ME XT A11

M86-ME XT A11

VIP / I2C

VIP / I2C

MULTI_GFX

MULTI_GFX
EXTERNAL

EXTERNAL
TMDS

TMDS

GENERAL

GENERAL
PURPOSE

PURPOSE
I/O

I/O

PLL

PLL
CLOCKS

CLOCKS

THERMAL

THERMAL

PART 2 OF 7

PART 2 OF 7

TXCAM_DPA0P

TXCBM_DPB0P
TXCBP_DPB0N

INTEGRATED

INTEGRATED
TMDS/DP

TMDS/DP

DAC1

DAC1

DAC2

DAC2

DDC

DDC
DP AUX

DP AUX

DDC3DATA_DP3_AUXN

DDC3CLK_DP3_AUXP

DDC4DATA_DP4_AUXN

DDC4CLK_DP4_AUXP

TXCAP_DPA0N

TX0M_DPA1P

TX0P_DPA1N

TX1M_DPA2P

TX1P_DPA2N

TX2M_DPA3P

TX2P_DPA3N

TX3M_DPB1P
TX3P_DPB1N

TX4M_DPB2P
TX4P_DPB2N

TX5M_DPB3P
TX5P_DPB3N

DPA_PVDD

DPA_PVSS

DPB_PVDD

DPB_PVSS

DPB_VDDR_1
DPB_VDDR_2
DPA_VDDR_3
DPA_VDDR_4

DPB_VSSR_1
DPB_VSSR_2
DPB_VSSR_3
DPB_VSSR_4
DPB_VSSR_6
DPA_VSS R_5
DPA_VSS R_7
DPA_VSS R_8
DPA_VSS R_9

DPA_VSS R_10

DP_CALR

NC_TPVDDC

NC_TPVSSC

HPD1

HSYNC

VSYNC

RSET

AVDD

AVSSQ

VDD1DI
VSS1DI

COMP

V2SYNC
H2SYNC

A2VDD

A2VDDQ

A2VSSQ

VDD2DI
VSS2DI

R2SET

DDC1DATA

DDC1CLK

DDC2DATA

DDC2CLK

R

RB

G

GB

B

BB

R2

R2B

G2

G2B

B2

B2B

C

Y

3

AN9
AN10

AR10
AP10

AR11
AP11

AR12
AP12

AR14
AP14

AR15
AP15

AR16
AP16

AR17
AP17

AM14
AL14

AH17
AG17

AN19
AN20
AP19
AR19

AN18
AP18
AR18
AN16
AN17
AN15
AN11
AN12
AN13
AN14

R259 150/FR259 150/F

AG15
AH18
AG18
AG6

AR31
AP31

AR30
AP30

AR29
AP29

AN29
AN30

R201 499/FR201 499/F

AN31

AR32

AP32

AR28
AP28

AM19
AL19

AM18
AL18

AM17
AL17

AK19
AK18
AK17

AL15
AM15

AM21

AL21

AK21

AH22
AG22

R175 715/FR175 715/F

AJ21

ATI_LCD_DDCDAT

AM29

ATI_LCD_DDCCLK

AL29

AJ15
AH15

AJ5
AJ4

AH14
AG14

3

ATI_HD MI_CLK- (2 5)
ATI_HD MI_CLK+ (2 5)

ATI_HDMI_TX0- (25)
ATI_HDMI_TX0+ (25)

ATI_HDMI_TX1- (25)
ATI_HDMI_TX1+ (25)

ATI_HDMI_TX2- (25)
ATI_HDMI_TX2+ (25)

DP_LANE0_P (25)
DP_LANE0_N (25)

DP_LANE1_P (25)
DP_LANE1_N (25)

DP_LANE2_P (25)
DP_LANE2_N (25)

DP_LANE3_P (25)
DP_LANE3_N (25)

+TPVDD

+DPB_VDDR

+DPA_VDDR

Gur_0808: 0 ohm removal,
delete R194, R208, R216

12

+AVDD

+VDD1DI

+A2VDD

+A2VDDQ

+VDD2DI

12

ATI_LCD_DDCDAT (26)
ATI_LCD_DDCCLK (26)

G_DAT_DDC (27)
G_CLK_DDC (27)

ATI_HDMI_SDA (25)
ATI_HDMI_SCL (25)

AUX_SINK_N ( 25)
AUX_SINK_P (25)

Memory Straps

900 MHz 256MB(16M*32) Hynix_Tiva die

800 MHz 256MB(16M*32) Qimonda_B2 die

reserve for Samsung

reserve for Hynix

900 MHz 512MB(32M*32) Qimonda_A die

800 MHz 512MB(32M*32) Samsung_D die

Note : Required Frequency = 800 MHz

VGA_RED

VGA_GRN

VGA_BLU

VGAHSYNC

VGA_RED (27)

VGA_GRN (27)

VGA_BLU (27)

VGAHSYNC (27)
VGAVSYNC (27)

LVDS

CRT

HDMI

DP

2

RAM_

R279

R279
10K

10K

Layout Note:
Place 150 ohm
termina tion resistors
close to ATI CHIP.

12
12

TYPE_CFG3

+3.3V_DELAY

Title

Title

Title

Size D ocument Number Rev

Size D ocument Number Rev

Size D ocument Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

H5RS5223CFR-11C

HYB18H512321B2F-12

HYB18H1G321AF-11

K4J10324QD-HC12

+3.3V_DELAY

R297

R297
10K

10K

Q38

Q38

2

MMST3904-7-F

MMST3904-7-F

1 3

ATI_LCD_DDCDAT
ATI_LCD_DDCCLK

3.3V to 5V level shift Logic required
If DDC1,DDC2 used on M8x or DDC1,DDC2,DDC3 used on M7x
DDC3,DDC4 are 5V tolerant on M8x

2

R290

R290
10K

10K

MMST3904-7-F

MMST3904-7-F

1 3

R206

R206

R211

R211

150/F

150/F

150/F

150/F

R157 2.2KR157 2.2K
R160 2.2KR160 2.2K

Q37

Q37

2

R204

R204
150/F

150/F

VGA_BLU
VGA_GRN
VGA_RED

1

RAM_

RAM_
TYPE_CFG1

1

0

110

0

1

RAM_
TYPE_CFG0

0

1

01

1

19 59Friday, August 08, 2008

19 59Friday, August 08, 2008

19 59Friday, August 08, 2008

TYPE_CFG2

1111

11

1

1

1

1

0

01

ATI_HDMI_DET (25)

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

M86XT_IO

M86XT_IO

M86XT_IO

RM2 3A

RM2 3A

RM2 3A

of

of

of

5

http://hobi-elektronika.net

U38E

U38E

P33

PCIE_VSS_1

P34

PCIE_VSS_2

P35

PCIE_VSS_3

R27

PCIE_VSS_4

R28

PCIE_VSS_5

R29

PCIE_VSS_6

R32

PCIE_VSS_7

R33

PCIE_VSS_8

U29

PCIE_VSS_9

U32

PCIE_VSS_10

V29

PCIE_VSS_11

V32

PCIE_VSS_12

T33

PCIE_VSS_13

AA29
AA32
AB29
AB32

AB34
AB35
AC33
AD29
AD32
AF29
AF32
AD33
AF34

AF35
AG27
AG29
AG32
AG33

AJ29

AJ32

AH33

AL34

AL35

AK32

V34

V35
W29
W32
W33

Y33

A2

A34

C3
C5
A4

C18

A21
C23
C11
C13
C14

A18

A11
C26
C33

F35

R7

G10

F15
H17
G21
D29

A29

G1
F14
J15
E19
E22
E24

D7

G9
F26

G29
D33

M5

G4
E10
E12
F17

G18
G22

F30
J35
J18

H19

J21

F7
J12
J24
J26
K30
J32
F33

K6

K9
K14
K15
K17
K18
K19
K21
K22

M28

K3
L33

PCIE_VSS_14
PCIE_VSS_15
PCIE_VSS_16
PCIE_VSS_17
PCIE_VSS_18
PCIE_VSS_19
PCIE_VSS_20
PCIE_VSS_21
PCIE_VSS_22
PCIE_VSS_23
PCIE_VSS_24
PCIE_VSS_25
PCIE_VSS_26
PCIE_VSS_27
PCIE_VSS_28
PCIE_VSS_29
PCIE_VSS_30
PCIE_VSS_31
PCIE_VSS_32
PCIE_VSS_33
PCIE_VSS_34
PCIE_VSS_35
PCIE_VSS_36
PCIE_VSS_37
PCIE_VSS_38
PCIE_VSS_39
PCIE_VSS_40
PCIE_VSS_41
PCIE_VSS_42
PCIE_VSS_43

VSS_1
VSS_2
VSS_3
VSS_4
VSS_5
VSS_6
VSS_7
VSS_8
VSS_9
VSS_10
VSS_11
VSS_12
VSS_13
VSS_14
VSS_15
VSS_16
VSS_17
VSS_18
VSS_19
VSS_20
VSS_21
VSS_22
VSS_23
VSS_24
VSS_25
VSS_26
VSS_27
VSS_28
VSS_29
VSS_30
VSS_31
VSS_32
VSS_33
VSS_34
VSS_35
VSS_36
VSS_37
VSS_38
VSS_39
VSS_40
VSS_41
VSS_42
VSS_43
VSS_44
VSS_45
VSS_46
VSS_47
VSS_48
VSS_49
VSS_50
VSS_51
VSS_52
VSS_53
VSS_54
VSS_55
VSS_56
VSS_57
VSS_58
VSS_59
VSS_60
VSS_61
VSS_62
VSS_63
VSS_64
VSS_65

TEMP_FAIL#(19)

D D

C C

B B

A A

RUN_ON(26,45,48,49,55)

5

Part 6 of 7

Part 6 of 7

CORE GND

CORE GND

VSS_66
VSS_67
VSS_68
VSS_69
VSS_70
VSS_71
VSS_72
VSS_73
VSS_74
VSS_75
VSS_76

PCI-Express GND

PCI-Express GND

VSS_77
VSS_78
VSS_79
VSS_80
VSS_81
VSS_82
VSS_83
VSS_84
VSS_85
VSS_86
VSS_87
VSS_88
VSS_89
VSS_90
VSS_91
VSS_92
VSS_93
VSS_94
VSS_95
VSS_96
VSS_97
VSS_98

VSS_99
VSS_100
VSS_101
VSS_102
VSS_103
VSS_104
VSS_105
VSS_106
VSS_107
VSS_108
VSS_109
VSS_110
VSS_111
VSS_112
VSS_113
VSS_114
VSS_115
VSS_116
VSS_117
VSS_118
VSS_119
VSS_120
VSS_121
VSS_122
VSS_123
VSS_124
VSS_125
VSS_126
VSS_127
VSS_128
VSS_129
VSS_130
VSS_131
VSS_132
VSS_133
VSS_134
VSS_135
VSS_136
VSS_137
VSS_138
VSS_139
VSS_140
VSS_141
VSS_142
VSS_143
VSS_144
VSS_145
VSS_146
VSS_147
VSS_148
VSS_149
VSS_150
VSS_151
VSS_152
VSS_153
VSS_154
VSS_155
VSS_156
VSS_157
VSS_158
VSS_159
VSS_160
VSS_161
VSS_162
VSS_163
VSS_164
VSS_165
VSS_166

MECH_1
MECH_2
MECH_3

M86-ME XT A11

M86-ME XT A11

31

2

Gur_0808: 0 ohm
removal, delete R278

P6
M9
M26
K28
M32
N14
N17
N19
N22
N33
N3
R5
U8
P13
P15
P18
P21
P23
P26
P29
P30
R1
U5
P9
R10
R14
R17
R19
R22
V3
AK9
U10
U15
U18
U21
U23
V7
W8
V10
V14
V17
V19
V22
V1
AK12
V9
W10
W15
W18
W21
W23
AA6
AA10
AA14
AA17
AA19
AA22
AB8
AB10
AB13
AB15
AB18
AB21
AB23
AC14
AC17
AC19
AC22
AF9
AD6
AB5
AD24
W5
AF6
AF14
AF21
AF22
AK10
AF17
AF18
AF19
AA3
AG12
AJ14
AH21
D4
AF15
AG10
AN6
AK15
AJ17
AJ18
AJ19
AF24
AN32
AK3
AN3
AR8
AM1
AK30
V11

A35
AR1
AR35

+3.3V_SUS +3.3V_SU S

12

R271

R271
*100K_NC

*100K_NC

Q33

Q33

*2N7002W-7-F_NC

*2N7002W-7-F_NC

C419

C419

0.1U

0.1U

25

25
603

603

+1.8V_RUN

+3.3V_DELAY

+1.8V_RUN

53

1

2

4

U10

U10
*74AHC1G08GW_NC

*74AHC1G08GW_NC

R292 0R292 0

C447

C447
10uF

10uF

C741

C741
1uF

1uF

C439

C439
10uF

10uF

C4001UC400
1U

C397

C397
1uF

1uF

C735

C735
1uF

1uF

C367

C367
10uF

10uF

+BBP

C747

C747
100nF

100nF

C480

C480
1uF

1uF

C425

C425
1uF

1uF

C389

C389
10uF

10uF

C423

C423
1uF

1uF

C442

C442
1uF

1uF

4

U38D

U38D

D1

VDDR1_1

A8

C417

C417

C483

C483

10uF

10uF

10uF

10uF

C728

C728

C404

C404

1uF

1uF

1uF

1uF

C687

C687

C726

C726

1uF

1uF

1uF

1uF

C368

C368

C703

C703

1uF

1uF

1uF

1uF

+VDD_CT

( 3.3V @ 50MA VDDR3)

C386

C386

C372

C372

C370

1uF

1uF

+VDD_MEM_CLK0
+VDD_MEM_CLK1

C415

C415
1uF

1uF

OPTIONAL RC NETWORK
TO FINE TUNE
POWER SEQUENCING

GFX_RUN_ON ( 52)

C370
1uF

1uF

R283 75K/FR283 75K/F

1uF

1uF

C444

C444
1uF

1uF

+VDD_MEM_CLK2
+VDD_MEM_CLK3

C412

C412
1uF

1uF

4

VDDR1_2

A12

VDDR1_3

A16

VDDR1_4

A20

VDDR1_5

A24

VDDR1_6

A28

VDDR1_7

B1

VDDR1_8

H1

VDDR1_9

H35

VDDR1_10

L18

VDDR1_11

L19

VDDR1_12

L21

VDDR1_13

L22

VDDR1_14

M10

VDDR1_15

M35

VDDR1_16

P10

VDDR1_17

T1

VDDR1_18

Y1

VDDR1_19

B35

VDDR1_20

M1

VDDR1_21

D35

VDDR1_22

K10

VDDR1_23

K12

VDDR1_24

K24

VDDR1_25

K26

VDDR1_26

L14

VDDR1_27

L15

VDDR1_28

L17

VDDR1_29

AA11

VDD_CT_1

AB11

VDD_CT_2

AD10

VDD_CT_3

AF10

VDD_CT_4

R11

VDD_CT_5

R25

VDD_CT_6

U11

VDD_CT_7

U25

VDD_CT_8

AE14

VDDR3_1

AE15

VDDR3_2

AF12

VDDR3_3

AE17

VDDR3_4

AP2

VDDR4_1

AR2

VDDR4_2

AN1

VDDR5_1

AP1

VDDR5_2

A25

VDDRHA_1

A32

VDDRHA_2

B25

VSSRHA_1

B32

VSSRHA_2

B2

VDDRHB_1

L1

VDDRHB_2

C2

VSSRHB_1

L2

VSSRHB_2

W13

BBN_1

AA13

BBN_2

U13

BBP_1

V13

BBP_2

Q32

Q32
SI2303BDS-T1-E3

SI2303BDS-T1-E3

C410

C410

0.1U

0.1U

3

2

+3.3V_DELAY +3.3V_RUN

10

10

PART 5 OF 7

PART 5 OF 7

Memory I/O

Memory I/O

P

P
O

O

I/O Internal

I/O Internal

W

W
E

E
R

R

Memory I/O

Clock

Memory I/O

Clock

Back

Bias

Back

Bias

1

12

2

R274

R274
100K

100K

31

Q36

Q36
2N7002W-7-F

2N7002W-7-F

3

PCI-Express

PCI-Express

BB_ENA(19)

3

PCIE_VDDR_1
PCIE_VDDR_2
PCIE_VDDR_3
PCIE_VDDR_4
PCIE_VDDR_5
PCIE_VDDR_6
PCIE_VDDR_7
PCIE_VDDR_8

PCIE_VDDC_1
PCIE_VDDC_2
PCIE_VDDC_3
PCIE_VDDC_4
PCIE_VDDC_5
PCIE_VDDC_6
PCIE_VDDC_7
PCIE_VDDC_8

PCIE_VDDC_9
PCIE_VDDC_10
PCIE_VDDC_11
PCIE_VDDC_12

VDDC_1
VDDC_2
VDDC_3
VDDC_4
VDDC_5
VDDC_6
VDDC_7
VDDC_8

VDDC_9
VDDC_10
VDDC_11
VDDC_12
VDDC_13
VDDC_14
VDDC_15
VDDC_16

Core

Core

VDDC_17
VDDC_18
VDDC_19
VDDC_20
VDDC_21
VDDC_22
VDDC_23
VDDC_24
VDDC_25
VDDC_26
VDDC_27
VDDC_28
VDDC_29
VDDC_30
VDDC_31
VDDC_32
VDDC_33
VDDC_34
VDDC_35
VDDC_36
VDDC_37
VDDC_38
VDDC_39
VDDC_40
VDDC_41
VDDC_42
VDDC_43
VDDC_44

VDDCI_1
VDDCI_2
VDDCI_3
VDDCI_4

M86-ME XT A11

M86-ME XT A11

+BBP

10

10

2

AR34
AL33
AM33
AN33
AN34
AN35
AP34
AP35

R26
U26
V25
V26
W25
W26
AA25
AD26
AF26
AA26
AB25
AB26

N13
N15
N18
N21
N23
P14
P17
P19
P22
V18
V21
V23
W14
W17
W19
W22
AA15
AA18
AA21
AA23
AB14
AB17
AB19
AB22
AC13
AC15
AC18
AC21
AC23
AE18
AE22
AE19
AE21
R13
R15
R18
R21
R23
U14
U17
U19
U22
V15
W11

M12
M24
P11
P25

3

12

C371

C371
1U

1U

603

603

2

R239

R239
10K

10K

+VDDCI

1

Q29

Q29

2

SI2303BDS-T1-E3

SI2303BDS-T1-E3

31

Q30

Q30
2N7002W-7-F

2N7002W-7-F

+PCIE_VDDR

+PCIE_VDDC

C379

C379
10uF

10uF

C395

C395
10uF

10uF

C405

C405
10uF

10uF

C356

C356
10uF

10uF

C401

C401
10uF

10uF

C867

C867
10uF

10uF

C427

C427
10uF

10uF

+1.8V_RUN

C403

C403
1uF

1uF

C381

C381
1uF

1uF

C357

C357
1uF

1uF

C380

C380
1uF

1uF

C414

C414
1uF

1uF

C868

C868
10uF

10uF

C375

C375
1uF

1uF

C374

C374
1uF

1uF

C387

C387
1uF

1uF

C393

C393
1uF

1uF

C420

C420
1uF

1uF

C421

C421
1uF

1uF

3 1

Q31

Q31
2N7002W-7-F

2N7002W-7-F

2

R251 100KR251 100K

C361

C361
1uF

1uF

C402

C402
1uF

1uF

C355

C355
1uF

1uF

C390

C390
1uF

1uF

C396

C396
1uF

1uF

C385

C385
1uF

1uF

+VCC_GFX_CORE

2

C392

C392
1uF

1uF

12

+VCC_GFX_CORE

C391

C391
1uF

1uF

C383

C383
1uF

1uF

C360

C360
1uF

1uF

C406

C406
1uF

1uF

C366

C366
1uF

1uF

L39

L39

BLM15AG121SN1D

BLM15AG121SN1D

+5V_RUN

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

Title

Title

Title

Size D ocument Number Rev

Size D ocument Number Rev

Size D ocument Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

COMPUTER

M86XT_POWER

M86XT_POWER

M86XT_POWER

RM2 3A

RM2 3A

RM2 3A

1

of

of

of

20 59Friday, August 08, 2008

20 59Friday, August 08, 2008

1

20 59Friday, August 08, 2008

5

http://hobi-elektronika.net

4

3

2

1

+LVDDR

R179

R179

R179

R179

0

0

C235

C235

C260

C260

100nF

100nF

100nF

100nF

100nF

100nF

100nF

100nF

100nF

100nF

1uFC222 1uFC222

1 2

+LVDDC

+LPVDD

+DPLL_PVDD

+PCIE_PVDD

+1.8V_RUN

BLM18PG471SN1D

BLM18PG471SN1D

D D

+1.8V_RUN

BLM15BD121SN1D

BLM15BD121SN1D

+1.8V_RUN

BLM15BD121SN1D

BLM15BD121SN1D

L33

L33

+1.8V_RUN

BLM15BD121SN1D

BLM15BD121SN1D

C C

+1.8V_RUN

BLM15BD121SN1D

BLM15BD121SN1D

+1.8V_RUN

BLM15BD121SN1D

BLM15BD121SN1D

C266

C266

L26

L26

L20

L20

L17

L17

L23

L23

L19

L19

10uF

10uF

L20

L20

C236

C236

C317

C317

C315

C315

10uF

10uF

C178

C178

10uF

10uF

C262

C262

C224

C224

10uF

10uF

10uF

10uF

C176

C176

10uF

10uF

C264

C264

C234

C234

C261

C261

C223

C223

C265

C265

100nF

100nF

1uF

1uF

C314

C314

1uF

1uF

C177

C177

1uF

1uF

1uF

1uF

100nF

100nF

LVDS

(1.8V @ 400MA LVDDC,LVDDR)

(1.8V @ 30MA LPVDD)

PLL_CLK

(1.8V @ 40MA DPLL_PVDD)

(1.8V @ 40MA PCIE_PVDD)

(1.8V @ 2MA A2V DDQ)

+A2VDDQ

DAC(CRT)

+VDD1DI

( 1.8V @ 100MA VDD1DI)

+VDD2DI

+1.1V_GFX_PCIE

+1.1V_GFX_PCIE

+1.1V_GFX_PCIE

+VCC_GFX_CORE

BLM15BD121SN1D

BLM15BD121SN1D

BLM15BD121SN1D

BLM15BD121SN1D

+3.3V_DELAY

L34

L34

L31

L31

BLM18PG121SN1D

BLM18PG121SN1D

L38

L38

BLM15BD121SN1D

BLM15BD121SN1D

L30

L30

BLM18PG471SN1D

BLM18PG471SN1D

L46

L46

BLM15BD121SN1D

BLM15BD121SN1D

( 1.1V @ 200MA EACH SINGLE LINK)

C328

C328

C329

C329

10uF

10uF

C307

C307

10uF

10uF

C358

C358

C352

C352

10uF

10uF

1uF

1uF

C363

C363

C369

C369

1uF

1uF

1uF

1uF

C286

C286

C291

C291

1uF

1uF

10uF

10uF

C466

C466

10uF

10uF

L28

L28

10uF

10uF

C271

C271

100nF

100nF

C469

C469

1uF

1uF

C305

C305

100nF

100nF

C351

C351

100nF

100nF

C362

C362

1uF

1uF

C285

C285

100nF

100nF

1uF

1uF

C327

C327

+DPLL_VDDC

C460

C460

100nF

100nF

C270

C270

100nF

100nF

+DPA_VDDR

+DPB_VDDR

C306

C306

1uF

1uF

+PCIE_VDDC

(PCIE_VDDC 1.1V @ 1A )

(DPLL_VDDC 1.1V @ 100 MA)

+MPVDD

( .95V-1.1V @ 345MA MPVDD)

+A2VDD

C269

C269

1uF

1uF

( 1.1V @ 200MA EACH SINGLE LINK)

(3.3V @ 135MA A2VDD)

TMDS

+1.8V_RUN

BLM15BD121SN1D

BLM15BD121SN1D

L18

L18

+1.8V_RUN

BLM15BD121SN1D

BLM15BD121SN1D

L29

L29

B B

+1.8V_RUN

BLM15BD121SN1D

BLM15BD121SN1D

L32

L32

+1.8V_RUN

BLM18PG471SN1D

BLM18PG471SN1D

L27

L27

C289

C289

C277

C277

C189

C189

C187

C187

1uF

100nF

100nF

C288

C288

100nF

100nF

C292

C292

C298

C298

100nF

100nF

1uF

1uF

C188

C188

1uF

C287

C287

1uF

1uF

1uF

1uF

C297

C297

C282

C282

100nF

100nF

10uF

10uF

10uF

10uF

C300

C300

10uF

10uF

10uF

10uF

+VDD_CT

+PCIE_VDDR

+AVDD

(1.8V @ 65MA AV DD)

+TPVDD

(1.8V @ 20 MA SINGLE LINK 1X4DP and 40mA for Dual-Link 2X4DP)

(VDD_CT 1.8V
@ 110MA (VDD_CT)

(1.8V @ 400MA PCIE_VDDR)

PLACE ALL DECOUPLING AS CLOSE TO ASIC AS POSSIBLE

MEM IO CLK

+1.8V_RUN

BLM15BD121SN1D

BLM15BD121SN1D

L74

L74

+1.8V_RUN

BLM15BD121SN1D

BLM15BD121SN1D

L44

A A

+1.8V_RUN

+1.8V_RUN

L44

BLM15BD121SN1D

BLM15BD121SN1D

L45

L45

BLM15BD121SN1D

BLM15BD121SN1D

L76

L76

5

C737

C737

10uF_6.3V

10uF_6.3V

C452

C452

10uF

10uF

C467

C467

10uF

10uF

C449

C449

10uF

10uF

C453

C453

C462

C462

C461

C461

C733

C733

1uF

1uF

1uF

1uF

1uF

1uF

1uF

1uF

C454

C454

C458

C458

C742

C742

100nF

100nF

100nF

100nF

100nF

100nF

C464

C464

100nF

100nF

+VDD_MEM_CLK0

+VDD_MEM_CLK1

+VDD_MEM_CLK2

+VDD_MEM_CLK3

(1.8V @ MA VDDRHA_1
INCLUDED IN VDDR1)

(1.8V @ MA VDDRHA_2
INCLUDED IN VDDR1)

(1.8V @ MA VDDRHB_1
INCLUDED IN VDDR1)

(1.8V @ MA VDDRHB_2
INCLUDED IN VDDR1)

4

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

Title

Title

Title

Size D ocument Number Rev

Size D ocument Number Rev

Size D ocument Number Rev

Date: Sheet

Date: Sheet

3

2

Date: Sheet

COMPUTER

M86XT_POWER RAIL

M86XT_POWER RAIL

M86XT_POWER RAIL

RM2 2E

RM2 2E

RM2 2E

1

of

of

of

21 59Tuesday, July 15, 2008

21 59Tuesday, July 15, 2008

21 59Tuesday, July 15, 2008

5

http://hobi-elektronika.net

MDA0
MDA1
MDA2
MDA3
MDA4
MDA5
MDA6
MDA7
MDA8
MDA9
MDA10
MDA11
MDA12
MDA13
MDA14
MDA15
MDA16
MDA17
MDA18
MDA19
MDA20
MDA21
MDA22
MDA23
MDA24
MDA25
MDA26
MDA27
MDA28
MDA29
MDA30
MDA31
MDA32
MDA33
MDA34
MDA35
MDA36
MDA37
MDA38
MDA39
MDA40
MDA41 QSA#6
MDA42
MDA43
MDA44
MDA45
MDA46
MDA47
MDA48
MDA49
MDA50
MDA51
MDA52
MDA53
MDA54
MDA55
MDA56
MDA57
MDA58
MDA59
MDA60
MDA61
MDA62
MDA63

+1.8V_RUN

R506

R506

100/F

100/F

QSA#[7..0]

QSA[7..0]

DQMA#[7..0]

MDA[63..0]

MAA[11..0]

R516

R516

40.2/F

40.2/F

R517

R517

100/F

100/F

C681

C681

100nF

100nF

RASA0#
RASA1#

CASA0#
CASA1#

WEA0#
WEA1#

CKEA0
CKEA1

CSA0_0#
CSA1_0#

CSA0_1#
CSA1_1#

CLKA0
CLKA0#

CLKA1
CLKA1#

A_BA0
A_BA1
A_BA2

C686

C686

100nF

100nF

RASA0#(23)
RASA1#(23)

CASA0#(23)
CASA1#(23)

WEA0#(23)
WEA1#(23)

CKEA0(23)
CKEA1(23)

D D

C C

PLACE MVREF DIVIDERS
AND CAPS CLOSE TO ASIC

CSA0_0#(23)
CSA1_0#(23)

CSA0_1#(23)
CSA1_1#(23)

CLKA0(23)
CLKA0#(23)

CLKA1(23)
CLKA1#(23)

QSA#[7..0](23)

QSA[7..0](23)

DQMA#[7..0](23)

MDA[63..0]( 23)

MAA[11..0](23)

A_BA0(23)
A_BA1(23)
A_BA2(23)

+1.8V_RUN +1.8V_RUN

R509

R509

40.2/F

40.2/F

AM34

P27
P28
P31
P32

M27

K29
K31

K32
M33
M34

L34

L35

J33

J34

H33

H34

K27

J29

J30

J31

F29

F32

D30

D32

G33

G34

G35

F34

D34

C34

C35

B34

C24

B24

B23

A23

C21

B21

C20

B20

J22

H22

F22

D21

J19

G19

F19

D19

C19

B19

A19

B18

C16

B16

C15

A15

H18

F18

E18

D18

J17

G15

E15

D15

N35

N34

4

U38C

U38C

DQA_0
DQA_1
DQA_2
DQA_3
DQA_4
DQA_5
DQA_6
DQA_7
DQA_8
DQA_9
DQA_10
DQA_11
DQA_12
DQA_13
DQA_14
DQA_15
DQA_16
DQA_17
DQA_18
DQA_19
DQA_20
DQA_21
DQA_22
DQA_23
DQA_24
DQA_25
DQA_26
DQA_27
DQA_28
DQA_29
DQA_30
DQA_31
DQA_32
DQA_33
DQA_34
DQA_35
DQA_36
DQA_37
DQA_38
DQA_39
DQA_40
DQA_41
DQA_42
DQA_43
DQA_44
DQA_45
DQA_46
DQA_47
DQA_48
DQA_49
DQA_50
DQA_51
DQA_52
DQA_53
DQA_54
DQA_55
DQA_56
DQA_57
DQA_58
DQA_59
DQA_60
DQA_61
DQA_62
DQA_63

MVREFDA
MVREFSA

NC_1

M86-ME XT A11

M86-ME XT A11

Part 3 of 7

Part 3 of 7

MEMORY INTERFACE A

MEMORY INTERFACE A

MAA_0
MAA_1
MAA_2
MAA_3
MAA_4
MAA_5
MAA_6
MAA_7
MAA_8

MAA_9
MAA_10
MAA_11

MAA_A12
MAA_BA2
MAA_BA0
MAA_BA1

DQMAb_0
DQMAb_1
DQMAb_2
DQMAb_3
DQMAb_4
DQMAb_5
DQMAb_6
DQMAb_7

QSA_0
QSA_1
QSA_2
QSA_3
QSA_4
QSA_5
QSA_6
QSA_7

QSA_0B
QSA_1B
QSA_2B
QSA_3B
QSA_4B
QSA_5B
QSA_6B
QSA_7B

write strobe read strobe

write strobe read strobe

ODTA0
ODTA1

CLKA0
CLKA1

CLKA0b
CLKA1b

RASA0b
RASA1b

CASA0b
CASA1b

CSA0b_0

CSA0b_1

CSA1b_0

CSA1b_1

CKEA0
CKEA1

WEA0b
WEA1b

C27
B28
B27
G26
F27
E27
D27
J27
E29
C30
E26
A27
G27
D26
C28
B29

M29
K33
G30
E33
C22
H21
C17
G17

M30
K34
G31
E34
B22
F21
B17
D17

M31
K35
G32
E35
A22
E21
A17
E17

C31
C25

A33
A26

B33
B26

A31
D24

C32
H26

A30
B30

G24
H24

B31
F24

C29
D22

MAA0
MAA1
MAA2
MAA3
MAA4
MAA5
MAA6
MAA7
MAA8
MAA9
MAA10
MAA11

A_BA2
A_BA0
A_BA1

DQMA#0
DQMA#1
DQMA#2
DQMA#3
DQMA#4
DQMA#5
DQMA#6
DQMA#7

QSA0
QSA1
QSA2
QSA3
QSA4
QSA5
QSA6
QSA7

QSA#0
QSA#1
QSA#2
QSA#3
QSA#4
QSA#5

QSA#7

CLKA0
CLKA1

CLKA0#
CLKA1#

RASA0#
RASA1#

CASA0#
CASA1#

CSA0_0#
CSA0_1#

CSA1_0#
CSA1_1#

CKEA0
CKEA1

WEA0#
WEA1#

3

R542

R542

4.7K

4.7K

1KR153 1KR153

MDB0
MDB1
MDB2
MDB3
MDB4
MDB5
MDB6
MDB7
MDB8

MDB9
MDB10
MDB11
MDB12
MDB13
MDB14
MDB15
MDB16
MDB17
MDB18
MDB19
MDB20
MDB21
MDB22
MDB23
MDB24
MDB25
MDB26
MDB27
MDB28
MDB29
MDB30
MDB31
MDB32
MDB33
MDB34
MDB35
MDB36
MDB37
MDB38
MDB39
MDB40
MDB41
MDB42
MDB43
MDB44
MDB45
MDB46
MDB47
MDB48
MDB49
MDB50
MDB51
MDB52
MDB53
MDB54
MDB55
MDB56
MDB57
MDB58
MDB59
MDB60
MDB61
MDB62
MDB63

R594

R594

40.2/F

40.2/F

R595

R595

100/F

100/F

RASB0#
RASB1#

CASB0#
CASB1#

WEB0#
WEB1#

CKEB0
CKEB1

CSB0_0#
CSB1_0#

CSB0_1#
CSB1_1#

CLKB0
CLKB0#

CLKB1
CLKB1#

QSB#[7..0]

QSB[7..0]

DQMB#[7..0]

MDB[63..0]

MAB[11..0]

B_BA0
B_BA1
B_BA2

C759

C759

100nF

100nF

R538

R538

4.7K

4.7K

RASB0#(24)
RASB1#(24)

CASB0#(24)
CASB1#(24)

WEB0#(24)
WEB1#(24)

CKEB0(24)

R591

R591

100/F

100/F

CKEB1(24)

CSB0_0#(24)
CSB1_0#(24)

CSB0_1#(24)
CSB1_1#(24)

CLKB0(24)
CLKB0#(24)

CLKB1(24)
CLKB1#(24)

QSB#[7..0](24)

QSB[7..0](24)

DQMB#[7..0](24)

MDB[63..0]( 24)

MAB[11..0](24)

B_BA0(24)
B_BA1(24)
B_BA2(24)

PLACE MVREF DIVIDERS

R590

R590

AND CAPS CLOSE TO ASIC

40.2/F

40.2/F

C756

C756

+1.8V_RUN

100nF

100nF

T88PAD T88PAD

R554

R554

240/F

240/F

AM30

AH19

H15
G14
E14
D14
H12
G12
F12
D10
B13
C12
B12
B11

C9

J10
H10
F10

D9
G7
G6

D6
C8
C7

C4

M3
M2
N2
N1
R3
R2

M8
M7

R9
R8
R6
U4
U3
U2
U1

AA2
AA1

U9
U7
U6

W9

W7

W6

W4

B14
A13

AA8
AA7
AA5

2

U38G

U38G

DQB_0
DQB_1
DQB_2
DQB_3
DQB_4
DQB_5
DQB_6
DQB_7
DQB_8
DQB_9
DQB_10
DQB_11
DQB_12

B9

DQB_13

A9

DQB_14

B8

DQB_15
DQB_16
DQB_17
DQB_18
DQB_19
DQB_20
DQB_21

F6

DQB_22
DQB_23
DQB_24
DQB_25

B7

DQB_26

A7

DQB_27

B5

DQB_28

A5

DQB_29
DQB_30

B4

DQB_31
DQB_32
DQB_33
DQB_34
DQB_35
DQB_36
DQB_37

T3

DQB_38

T2

DQB_39
DQB_40
DQB_41

P5

DQB_42

P4

DQB_43
DQB_44
DQB_45
DQB_46
DQB_47
DQB_48
DQB_49
DQB_50

V2

DQB_51

Y3

DQB_52

Y2

DQB_53
DQB_54
DQB_55
DQB_56
DQB_57
DQB_58

V4

DQB_59
DQB_60
DQB_61
DQB_62
DQB_63

MVREFDB
MVREFSB

TESTEN
TEST_MCLK
TEST_YCLK
MEMTEST
PLLTEST

M86-ME XT A11

M86-ME XT A11

Part 4 of 7

Part 4 of 7

MEMORY INTERFACE B

MEMORY INTERFACE B

MAB_0
MAB_1
MAB_2
MAB_3
MAB_4
MAB_5
MAB_6
MAB_7
MAB_8

MAB_9
MAB_10
MAB_11

MAB_A12
MAB_BA2
MAB_BA0
MAB_BA1

DQMBb_0
DQMBb_1
DQMBb_2
DQMBb_3
DQMBb_4
DQMBb_5
DQMBb_6
DQMBb_7

QSB_0

QSB_1

QSB_2

QSB_3

QSB_4

QSB_5

QSB_6

QSB_7

QSB_0B
QSB_1B
QSB_2B
QSB_3B
QSB_4B
QSB_5B
QSB_6B
QSB_7B

write strobe read strobe

write strobe read strobe

ODTB0

ODTB1

CLKB0

CLKB1

CLKB0b
CLKB1b

RASB0b
RASB1b

CASB0b
CASB1b

CSB0b_0
CSB0b_1

CSB1b_0
CSB1b_1

CKEB0

CKEB1

WEB0b
WEB1b

DRAM_RST

H2
H3
J3
J5
J4
J6
G5
J9
F3
F4
J1
J2
J7
F1
G2
G3

D12
C10
E7
C6
P3
R4
W3
V8

J14
B10
F9
B6
P2
P8
W2
V6

H14
A10
E9
A6
P1
P7
W1
V5

D2
K5

A3
K1

B3
K2

D3
K7

C1
K4

E1
E2

L3
M4

E3
K8

F2
M6

AA4

MAB0
MAB1
MAB2
MAB3
MAB4
MAB5
MAB6
MAB7
MAB8
MAB9
MAB10
MAB11

B_BA2
B_BA0
B_BA1

DQMB#0
DQMB#1
DQMB#2
DQMB#3
DQMB#4
DQMB#5
DQMB#6
DQMB#7

QSB0
QSB1
QSB2
QSB3
QSB4
QSB5
QSB6
QSB7

QSB#0
QSB#1
QSB#2
QSB#3
QSB#4
QSB#5
QSB#6
QSB#7

CLKB0
CLKB1

CLKB0#
CLKB1#

RASB0#
RASB1#

CASB0#
CASB1#

CSB0_0#
CSB0_1#

CSB1_0#
CSB1_1#

CKEB0
CKEB1

WEB0#
WEB1#

4.7KR 577 4.7KR577

1

T94PAD T94PAD

GDDR3_RST (23,24)

+1.8V_RUN

+3.3V_DELAY

12

R145

R145

4.7K

4.7K

THERMAL_INT#

Gur_0814: change U33 from
ADM1032AR MZ to ADM1032ARMZ -1RL

12

12

THERMAL MONITOR

12

R141

R141

4.7K

4.7K

U33

U33

8

SCLK

7

SDATA

6

ALERT#

5

GND

ADM1032ARMZ-1RL

ADM1032ARMZ-1RL

+3.3V_DELAY

THERM#

+3.3V_DELAY

1

VDD

2

D+

3

D-

MB_THERM#

4

12

C633

C633

0.1U

0.1U

10

10

12

C635

C635
2200P

2200P

50

50

MB_THERM# (50)

VGA_THERMDP (19 )

VGA_THERMDN (19)

Spread Spectrum

If U7070, the discrete spread spectrum chip
is not used, then pop R8328 in order to
pull-down BXTALOUT for EMI reasons.

OSC_OUT(19)

OSC_SPREAD(19)

R134 *10K_NCR134 *10K_NC

R465 *0_NCR465 *0_NC

1 2

U32

U32

1

XIN/CLKIN

2

VSS

3

SO

4

SSCLK

*P1819GF-08SR_NC

*P1819GF-08SR_NC

XOUT

REFCLK

+3.3V_RUN

R460

R460

R461

R461

*10K_NC

*10K_NC

*10K_NC

*10K_NC

8

7

VDD

6

PD#

12

5

+3VL

C165

C165
*10U_NC

*10U_NC

805

805
10

10

L16 *BLM18AG121SN1D_NCL16 *BLM18AG121SN1D_NC

C155

C155

12

*0.1U_NC

*0.1U_NC

10

10

+3.3V_RUN

3 1

2N7002W-7-F

2N7002W-7-F

2N7002W-7-F

2N7002W-7-F

2

Q23

Q23

+3.3V_DELAY

2

3 1

Q24

Q24

THERMAL_INT#(19)

MB_THERM#

THERMAL_INT#

R479 10KR479 10K

R468 10KR468 10K

B B

SMBCLK0(31,47,54)

SMBDAT0(31,47,54)

S0

-1.75% (DOWN)10

0.85% (CENTER)

A A

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

M86XT_MEMORY/LVDS/THER

M86XT_MEMORY/LVDS/THER

M86XT_MEMORY/LVDS/THER

RM2 3A

RM2 3A

RM2 3A

1

of

of

of

22 59Thursday, August 14, 2008

22 59Thursday, August 14, 2008

22 59Thursday, August 14, 2008

5

4

Title

Title

Title

Size D ocument Number Rev

Size D ocument Number Rev

Size D ocument Number Rev

Date: Sheet

Date: Sheet

3

2

Date: Sheet

1

http://hobi-elektronika.net

VREF_A0

H1

VREF_A1

H12

CLKA0

CLKA0(22)
CLKA0#(22)

CKEA0(22)

RASA0#(22)
CASA0#(22)
WEA0#(22)
CSA0_0#(22)

A A

B B

J11

CLKA0#

J10

CKEA0

H4

RASA0#

H3

CASA0#

F4

WEA0#

H9

CSA0_0#

F9

DQMA#2

E3

DQMA#3

E10

DQMA#0

N10

DQMA#1 DQMA#4

N3

QSA#2

D2

QSA#3

D11

QSA#0

P11

QSA#1

P2
D3

QSA3

D10

QSA0

P10

QSA1

P3

MAA0

K4

MAA1

H2

MAA2

K3

MAA3

M4

MAA4

K9

MAA5

H11

MAA6

K10

MAA7

L9

MAA8

K11

MAA9

M9

MAA10

K2

MAA11

L4

A_BA0

G4

A_BA1

G9

A_BA2

H10

R257

R257

2.37K/F

2.37K/F

R252

R252

C365

C365

5.49K/F

5.49K/F

0.1U

0.1U

1 2

10

10

1 2

2

U3A

U3A

VREF1
VREF2

CK
CK
CKE

RAS
CAS
WE
CS

DM0
DM1
DM2
DM3
WDQS0
WDQS1
WDQS2
WDQS3
RDQS0
RDQS1
RDQS2
RDQS3

A0
A1
A2
A3
A4
A5
A6
A7
A8/AP
A9
A10
A11

BA0
BA1
BA2

GDDR3_SDRAM

GDDR3_SDRAM

VREF_A1 VREF_A3VREF_A0 VREF_A2

MDA16

B2

DQ0

MDA20

B3

DQ1

MDA17

C2

DQ2

MDA22

C3

DQ3

MDA19

E2

DQ4

MDA23

F3

DQ5

MDA18

F2

DQ6

MDA21

G3

DQ7

MDA29

B11

DQ8

MDA31

B10

DQ9

MDA30

C11

DQ10

MDA24

C10

DQ11

MDA28

E11

DQ12

MDA27

F10

DQ13

MDA25

F11

DQ14

MDA26

G10

DQ15

MDA7

M11

DQ16

MDA5

L10

DQ17

MDA0

N11

DQ18

MDA6

M10

DQ19

MDA4

R11

DQ20

MDA1

R10

DQ21

MDA3

T11

DQ22

MDA2

T10

DQ23

MDA12

M2

DQ24

MDA15

L3

DQ25

MDA14

N2

DQ26

MDA13

M3

DQ27

MDA10

R2

DQ28

MDA8

R3

DQ29

MDA9

T2

DQ30

MDA11

T3

DQ31

R268 240/FR268 240/F

A4
A9

GDDR3_RST

V9
V4

CSA0_1#

J3

J2

R520

R520

2.37K/F

2.37K/F

1 2

C684

C684

0.1U

0.1U

1 2

10

10

1 2

Gur_0808: 0 ohm
removal, delete R503

ZQ

MF
RES
SEN
RFU

NC0

+1.8V_RUN +1.8V_RUN+1.8V_RUN +1.8V_RUN

1 2

R514

R514

5.49K/F

5.49K/F

3

MDA[63..0](22)

MAA[11..0](22)

QSA#[7..0](22)

QSA[7..0](22)

DQMA#[7..0](22)

A_BA[2..0](22)

GDDR3_RST (22,24)

CSA0_1# (22)

1 2

1 2

R284

R284

2.37K/F

2.37K/F

C426

C426

0.1U

0.1U

10

10

MDA[63..0]

MAA[11..0]

QSA#[7..0]

QSA[7..0]

DQMA#[7..0]

A_BA[2..0]

R291

R291

5.49K/F

5.49K/F

1 2

4

GDDR3 32MX32

+1.8V_RUN

R505 121/FR505 121/F
R571 121/FR571 121/F

R248 121/FR248 121/F
R566 121/FR566 121/F

R533 121/FR533 121/F
R578 121/FR578 121/F

R511 121/FR511 121/F
R572 121/FR572 121/F

R518 121/FR518 121/F
R579 121/FR579 121/F

R508 60.4/FR508 60.4/F
R504 60.4/FR504 60.4/F

R573 60.4/FR573 60.4/F
R568 60.4/FR568 60.4/F

R502 121/FR502 121/F
R569 121/FR569 121/F

R582

R582

2.37K/F

2.37K/F

1 2

C739

C739

0.1U

0.1U

1 2

10

10

1 2
1 2

1 2
1 2

1 2
1 2

1 2
1 2

1 2
1 2

1 2
1 2

1 2
1 2

1 2
1 2

1 2

R576

R576

5.49K/F

5.49K/F

5

CLKA1(22)
CLKA1#(22)

CKEA1(22)

RASA1#(22)
CASA1#(22)
WEA1#(22)
CSA1_0#(22)

CKEA0
CKEA1

RASA0#
RASA1#

CASA0#
CASA1#

WEA0#
WEA1#

CSA0_0#
CSA1_0#

CLKA0
CLKA0#

CLKA1
CLKA1#

CSA0_1#
CSA1_1#

GDDR3 32Mx32 configuration

Non
Merged

Merged

VREF_A2
VREF_A3

CLKA1
CLKA1#
CKEA1

RASA1#
CASA1#
WEA1#
CSA1_0#

DQMA#6
DQMA#7
DQMA#5

QSA#6
QSA#7
QSA#5
QSA#4
QSA6QSA2
QSA7
QSA5
QSA4

MAA0
MAA1
MAA2
MAA3
MAA4
MAA5
MAA6
MAA7
MAA8
MAA9
MAA10
MAA11

A_BA0
A_BA1
A_BA2

1CS

2CS

1CS

2CS

6

U11A

U11A

H1

VREF1

H12

VREF2

J11

CK

J10

CK

H4

CKE

H3

RAS

F4

CAS

H9

WE

F9

CS

E3

DM0

E10

DM1

N10

DM2

N3

DM3

D2

WDQS0

D11

WDQS1

P11

WDQS2

P2

WDQS3

D3

RDQS0

D10

RDQS1

P10

RDQS2

P3

RDQS3

K4

A0

H2

A1

K3

A2

M4

A3

K9

A4

H11

A5

K10

A6

L9

A7

K11

A8/AP

M9

A9

K2

A10

L4

A11

G4

BA0

G9

BA1

H10

BA2

GDDR3_SDRAM

GDDR3_SDRAM

Pin J2 Pi n J3

MAA12

NC

NC CSAx_1#

NC

MAA12

NC

CSAx_1#

DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23
DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31

DQ0
DQ1
DQ2
DQ3
DQ4
DQ5
DQ6
DQ7
DQ8
DQ9

ZQ

MF
RES
SEN
RFU

NC0

MDA53

B2

MDA54

B3

MDA55

C2

MDA52

C3

MDA50

E2

MDA48

F3

MDA49

F2

MDA51

G3

MDA60

B11

MDA61

B10

MDA62

C11

MDA63

C10

MDA56

E11

MDA58

F10

MDA59

F11

MDA57

G10

MDA43

M11

MDA45

L10

MDA41

N11

MDA47

M10

MDA44

R11

MDA46

R10

MDA40

T11

MDA42

T10

MDA39

M2

MDA37

L3

MDA36

N2

MDA38

M3

MDA35

R2

MDA33

R3

MDA32

T2

MDA34

T3

R589 240/FR589 240/F

1 2

A4
A9

GDDR3_RST

V9
V4

CSA1_1#

J3

J2

Gur_0808: 0 ohm
removal, delete R570

7

CSA1_1# (22)

8

+1.8V_RUN

C C

12

C655

C655

10uF_6.3V

10uF_6.3V

CC0603

CC0603

12

C341

C341

0.1U/10V

0.1U/10V

D D

1

12

C333

C333

10uF_6.3V

10uF_6.3V

CC0603

CC0603

12

C343

C343

0.1U/10V

0.1U/10V

12

12

C651

C651

1U/6.3V

1U/6.3V

C335

C335

0.1U/10V

0.1U/10V

12

12

C670

C670

1U/6.3V

1U/6.3V

C658

C658

0.1U/10V

0.1U/10V

BLM15BD121SN1DL37 BLM15BD121SN1DL37
BLM15BD121SN1DL71 BLM15BD121SN1DL71 BLM15BD121SN1DL73 BLM15BD121SN1DL73

12

12

C382

C382

C373

C373

0.01U/16V

0.01U/16V

0.01U/16V

0.01U/16V

12

12

C659

C659

C704

C704

0.1U/10V

0.1U/10V

0.1U/10V

0.1U/10V

2

C346 0.1U/10VC346 0.1U/10V

1 2

C676 0.1U/10VC676 0.1U/10V

1 2

U3B

U3B

K12

VDD10

K1

VDD9

V11

VDD8

V2

VDD7

M12

VDD6

M1

VDD5

F12

VDD4

F1

VDD3

A11

VDD2

A2

VDD1

A1

VDDQ1

A12

VDDQ2

C1

VDDQ3

C4

VDDQ4

C9

VDDQ5

C12

VDDQ6

J4

VDDQ7

J9

VDDQ8

N1

VDDQ9

N4

VDDQ10

N9

VDDQ11

N12

VDDQ12

R1

VDDQ13

R4

VDDQ14

R9

VDDQ15

R12

VDDQ16

V1

VDDQ17

V12

VDDQ18

E1

VDDQ19

E4

VDDQ20

E9

VDDQ21

E12

VDDQ22

GDDR3_SDRAM

GDDR3_SDRAM

3

VSS10

VSS9
VSS8
VSS7
VSS6
VSS5
VSS4
VSS3
VSS2
VSS1

VSSQ20
VSSQ19
VSSQ18
VSSQ17
VSSQ16
VSSQ15
VSSQ14
VSSQ13
VSSQ12
VSSQ11
VSSQ10

VSSQ9
VSSQ8
VSSQ7
VSSQ6
VSSQ5
VSSQ4
VSSQ3
VSSQ2
VSSQ1

12

C718

C718

0.01U/16V

0.01U/16V

12

C748

C748

0.1U/10V

0.1U/10V

BLM15BD121SN1DL40 BLM15BD121SN1DL40

12

C722

C722

0.01U/16V

0.01U/16V

12

C750

C750

0.1U/10V

0.1U/10V

6

+1.8V_RUN

J12
J1
V10
V3
L12
L1
G12
G1
A10
A3

T12
T9
T4
T1
P12
P9
P4
P1
L11
L2
G11
G2
D12
D9
D4
D1
B12
B9
B4
B1

4

12

C761

C761

10uF_6.3V

10uF_6.3V

CC0603

CC0603

12

C713

C713

0.1U/10V

0.1U/10V

12

C760

C760

10uF_6.3V

10uF_6.3V

CC0603

CC0603

12

C711

C711

0.1U/10V

0.1U/10V

C752

C752

1U/6.3V

1U/6.3V

C712

C712

0.1U/10V

0.1U/10V

12

12

C740

C740

1U/6.3V

1U/6.3V

C719

C719

0.1U/10V

0.1U/10V

12

12

5

C411 0.1U/10VC411 0.1U/10V

1 2

C723 0.1U/10VC723 0.1U/10V

1 2

U11B

U11B

K12

VDD10

K1

VDD9

V11

VDD8

V2

VDD7

M12

VDD6

M1

VDD5

F12

VDD4

F1

VDD3

A11

VDD2

A2

VDD1

A1

VDDQ1

A12

VDDQ2

C1

VDDQ3

C4

VDDQ4

C9

VDDQ5

C12

VDDQ6

J4

VDDQ7

J9

VDDQ8

N1

VDDQ9

N4

VDDQ10

N9

VDDQ11

N12

VDDQ12

R1

VDDQ13

R4

VDDQ14

R9

VDDQ15

R12

VDDQ16

V1

VDDQ17

V12

VDDQ18

E1

VDDQ19

E4

VDDQ20

E9

VDDQ21

E12

VDDQ22

GDDR3_SDRAM

GDDR3_SDRAM

Title

Title

Title

M86XT_DDR3_A_512M

M86XT_DDR3_A_512M

M86XT_DDR3_A_512M

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

RM2 3A

RM2 3A

RM2 3A

Date: Sheet

Date: Sheet

Date: Sheet

J12

VSS10

J1

VSS9

V10

VSS8

V3

VSS7

L12

VSS6

L1

VSS5

G12

VSS4

G1

VSS3

A10

VSS2

A3

VSS1

T12

VSSQ20

T9

VSSQ19

T4

VSSQ18

T1

VSSQ17

P12

VSSQ16

P9

VSSQ15

P4

VSSQ14

P1

VSSQ13

L11

VSSQ12

L2

VSSQ11

G11

VSSQ10

G2

VSSQ9

D12

VSSQ8

D9

VSSQ7

D4

VSSQ6

D1

VSSQ5

B12

VSSQ4

B9

VSSQ3

B4

VSSQ2

B1

VSSQ1

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

7

of

of

of

23 59Friday, August 08, 2008

23 59Friday, August 08, 2008

23 59Friday, August 08, 2008

8

1

http://hobi-elektronika.net

VREF_B0

H1

VREF_B1

H12

CLKB0

CLKB0(22)
CLKB0#(22)

RASB0#(22)
CASB0#(22)
WEB0#(22)
CSB0_0#(22)

A A

B B

J11

CLKB0# MDB3

J10

CKEB0

H4

RASB0#

H3

CASB0#

F4

WEB0#

H9

CSB0_0#

F9

DQMB#0

E3

DQMB#1

E10

DQMB#2

N10

DQMB#3

N3

QSB#0

D2

QSB#1

D11

QSB#2

P11

P2

QSB0

D3

QSB1

D10

QSB2

P10

QSB3

P3

MAB0

K4

MAB1

H2

MAB2

K3

MAB3

M4

MAB4

K9

MAB5

H11

MAB6

K10

MAB7

L9

MAB8

K11

MAB9

M9

MAB10

K2

MAB11

L4

B_BA0

G4

B_BA1

G9

B_BA2

H10

R370

R370

2.37K/F

2.37K/F

C486

C486

0.1U

0.1U

1 2

10

10

1 2

U43A

U43A

VREF1
VREF2

CK
CK
CKE

RAS
CAS
WE
CS

DM0
DM1
DM2
DM3
WDQS0
WDQS1
WDQS2
WDQS3
RDQS0
RDQS1
RDQS2
RDQS3

A0
A1
A2
A3
A4
A5
A6
A7
A8/AP
A9
A10
A11

BA0
BA1
BA2

GDDR3_SDRAM

GDDR3_SDRAM

R365

R365

5.49K/F

5.49K/F

2

MDB0

B2

DQ0

MDB1

B3

DQ1

MDB2

C2

DQ2

C3

DQ3

MDB4

E2

DQ4

MDB5

F3

DQ5

MDB6

F2

DQ6

MDB7

G3

DQ7

MDB8

B11

DQ8

MDB9

B10

DQ9

MDB10

C11

DQ10

MDB11

C10

DQ11

MDB12

E11

DQ12

MDB13

F10

DQ13

MDB14

F11

DQ14

MDB15

G10

DQ15

MDB16

M11

DQ16

MDB17

L10

DQ17

MDB18QSB#3

N11

DQ18

MDB19

M10

DQ19

MDB21

R11

DQ20

MDB20

R10

DQ21

MDB22

T11

DQ22

MDB23

T10

DQ23

MDB24

M2

DQ24

MDB25

L3

DQ25

MDB26

N2

DQ26

MDB27

M3

DQ27

MDB31

R2

DQ28

MDB28

R3

DQ29

MDB30

T2

DQ30

MDB29

T3

DQ31

R342 240/FR342 240/F

A4

ZQ

MF
RES
SEN
RFU

NC0

VREF_B1 VREF_B3VREF_B0 VREF_B2

1 2

A9

GDDR3_RST

V9
V4

CSB0_1#

J3

J2

Gur_0808: 0 ohm
removal, delete R338

+1.8V_RUN +1.8V_RUN+1.8V_RUN +1.8V_RUN

R593

R593

2.37K/F

2.37K/F

C757

C757

0.1U

0.1U

1 2

10

10

1 2

3

MDB[63..0](22)

MAB[11..0](22)

QSB#[7..0](22)CKEB0(22) CKEB1(22)

QSB[7..0](22)

DQMB#[7..0](22)

B_BA[2..0](22)

GDDR3_RST (22,23)

CSB0_1# (22)

R592

R592

5.49K/F

5.49K/F

MDB[63..0]

MAB[11..0]

QSB#[7..0]

QSB[7..0]

DQMB#[7..0]

B_BA[2..0]

R371

R371

2.37K/F

2.37K/F

C494

C494

0.1U

0.1U

1 2

10

10

4

GDDR3 32MX32

+1.8V_RUN

R366

R366

5.49K/F

5.49K/F

1 2

R337 121/FR337 121/F

1 2

R351 121/FR351 121/F

1 2

R354 121/FR354 121/F

1 2

R363 121/FR363 121/F

1 2

R359 121/FR359 121/F

1 2

R350 121/FR350 121/F

1 2

R341 121/FR341 121/F

1 2

R334 121/FR334 121/F

1 2

R343 121/FR343 121/F

1 2

R332 121/FR332 121/F

1 2

R335 60.4/FR335 60.4/F

1 2

R333 60.4/FR333 60.4/F

1 2

R331 60.4/FR331 60.4/F

1 2

R336 60.4/FR336 60.4/F

1 2

R349 121/FR349 121/F

1 2

R339 121/FR339 121/F

1 2

R326

R326

2.37K/F

2.37K/F

C445

C445

0.1U

0.1U

1 2

10

10

1 2

R325

R325

5.49K/F

5.49K/F

5

RASB1#(22)
CASB1#(22)
WEB1#(22)
CSB1_0#(22)

CKEB0
CKEB1

RASB0#
RASB1#

CASB0#
CASB1#

WEB0#
WEB1#

CSB0_0#
CSB1_0#

CLKB0
CLKB0#

CLKB1
CLKB1#

CSB0_1#
CSB1_1#

CLKB1(22)
CLKB1#(22)

GDDR3 32Mx32 configuration

Non
Merged

Merged

VREF_B2
VREF_B3

CLKB1
CLKB1#
CKEB1

RASB1#
CASB1#
WEB1#
CSB1_0#

DQMB#4
DQMB#5
DQMB#6
DQMB#7
QSB#4
QSB#5
QSB#6
QSB#7
QSB4
QSB5
QSB6
QSB7

MAB0
MAB1
MAB2
MAB3
MAB4
MAB5
MAB6
MAB7
MAB8
MAB9
MAB10
MAB11

B_BA0
B_BA1
B_BA2

1CS

2CS

1CS

2CS

H12

J11
J10

E10
N10

D11
P11

D10
P10

H11
K10

K11

H10

6

U44A

U44A

H1

VREF1
VREF2

CK
CK

H4

CKE

H3

RAS

F4

CAS

H9

WE

F9

CS

E3

DM0
DM1
DM2

N3

DM3

D2

WDQS0
WDQS1
WDQS2

P2

WDQS3

D3

RDQS0
RDQS1
RDQS2

P3

RDQS3

K4

A0

H2

A1

K3

A2

M4

A3

K9

A4
A5
A6

L9

A7
A8/AP

M9

A9

K2

A10

L4

A11

G4

BA0

G9

BA1
BA2

GDDR3_SDRAM

GDDR3_SDRAM

Pin J2 Pi n J3

MAB12

NC CSBx_1#

NC

NC

NC

MAB12

CSBx_1#

DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23
DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31

DQ0
DQ1
DQ2
DQ3
DQ4
DQ5
DQ6
DQ7
DQ8
DQ9

ZQ

MF
RES
SEN
RFU

NC0

MDB32

B2

MDB33

B3

MDB34

C2

MDB35

C3

MDB36

E2

MDB38

F3

MDB37

F2

MDB39

G3

MDB40

B11

MDB41

B10

MDB42

C11

MDB43

C10

MDB44

E11

MDB46

F10

MDB45

F11

MDB47

G10

MDB48

M11

MDB49

L10

MDB50

N11

MDB51

M10

MDB52

R11

MDB53

R10

MDB54

T11

MDB55

T10

MDB56

M2

MDB57

L3

MDB58

N2

MDB59

M3

MDB62

R2

MDB60

R3

MDB63

T2

MDB61

T3

R348 240/FR348 240/F

1 2

A4
A9

GDDR3_RST

V9
V4

CSB1_1#

J3

J2

Gur_0808: 0 ohm
removal, delete R344

7

CSB1_1# (22)

8

+1.8V_RUN +1.8V_RUN

12

C478

C C

D D

C478

10uF_6.3V

10uF_6.3V

CC0603

CC0603

12

C488

C488

0.1U/10V

0.1U/10V

1

12

C470

C470

10uF_6.3V

10uF_6.3V

CC0603

CC0603

12

C493

C493

0.1U/10V

0.1U/10V

12

12

C474

C474

1U/6.3V

1U/6.3V

C485

C485

0.1U/10V

0.1U/10V

12

12

C487

C487

1U/6.3V

1U/6.3V

C491

C491

0.1U/10V

0.1U/10V

2

BLM15BD121SN1DL47 BLM15BD121SN1DL47 C492 0.1U/10VC492 0.1U/10V
BLM15BD121SN1DL75 BLM15BD121SN1DL75

12

12

C468

C468

0.01U/16V

0.01U/16V

12

C490

C490

0.1U/10V

0.1U/10V

12

C471

C471

0.01U/16V

0.01U/16V

C489

C489

0.1U/10V

0.1U/10V

3

1 2

C758 0.1U/10VC758 0.1U/10V

1 2

U43B

U43B

K12

VDD10

K1

VDD9

V11

VDD8

V2

VDD7

M12

VDD6

M1

VDD5

F12

VDD4

F1

VDD3

A11

VDD2

A2

VDD1

A1

VDDQ1

A12

VDDQ2

C1

VDDQ3

C4

VDDQ4

C9

VDDQ5

C12

VDDQ6

J4

VDDQ7

J9

VDDQ8

N1

VDDQ9

N4

VDDQ10

N9

VDDQ11

N12

VDDQ12

R1

VDDQ13

R4

VDDQ14

R9

VDDQ15

R12

VDDQ16

V1

VDDQ17

V12

VDDQ18

E1

VDDQ19

E4

VDDQ20

E9

VDDQ21

E12

VDDQ22

GDDR3_SDRAM

GDDR3_SDRAM

VSS10

VSS9
VSS8
VSS7
VSS6
VSS5
VSS4
VSS3
VSS2
VSS1

VSSQ20
VSSQ19
VSSQ18
VSSQ17
VSSQ16
VSSQ15
VSSQ14
VSSQ13
VSSQ12
VSSQ11
VSSQ10

VSSQ9
VSSQ8
VSSQ7
VSSQ6
VSSQ5
VSSQ4
VSSQ3
VSSQ2
VSSQ1

J12
J1
V10
V3
L12
L1
G12
G1
A10
A3

T12
T9
T4
T1
P12
P9
P4
P1
L11
L2
G11
G2
D12
D9
D4
D1
B12
B9
B4
B1

4

12

C482

C482

10uF_6.3V

10uF_6.3V

CC0603

CC0603

12

C451

C451

0.1U/10V

0.1U/10V

12

C463

C463

10uF_6.3V

10uF_6.3V

CC0603

CC0603

12

C779

C779

0.1U/10V

0.1U/10V

12

12

C500

C500

1U/6.3V

1U/6.3V

12

C778

C778

0.1U/10V

0.1U/10V

5

12

C501

C501

1U/6.3V

1U/6.3V

C455

C455

0.1U/10V

0.1U/10V

12

12

BLM15BD121SN1DL48 BLM15BD121SN1DL48
BLM15BD121SN1DL42 BLM15BD121SN1DL42

C503

C503

0.01U/16V

0.01U/16V

C446

C446

0.1U/10V

0.1U/10V

12

C495

C495

0.01U/16V

0.01U/16V

12

C472

C472

0.1U/10V

0.1U/10V

6

C496 0.1U/10VC496 0.1U/10V

1 2

C459 0.1U/10VC459 0.1U/10V

1 2

U44B

U44B

K12

VDD10

K1

VDD9

V11

VDD8

V2

VDD7

M12

VDD6

M1

VDD5

F12

VDD4

F1

VDD3

A11

VDD2

A2

VDD1

A1

VDDQ1

A12

VDDQ2

C1

VDDQ3

C4

VDDQ4

C9

VDDQ5

C12

VDDQ6

J4

VDDQ7

J9

VDDQ8

N1

VDDQ9

N4

VDDQ10

N9

VDDQ11

N12

VDDQ12

R1

VDDQ13

R4

VDDQ14

R9

VDDQ15

R12

VDDQ16

V1

VDDQ17

V12

VDDQ18

E1

VDDQ19

E4

VDDQ20

E9

VDDQ21

E12

VDDQ22

GDDR3_SDRAM

GDDR3_SDRAM

Title

Title

Title

M86XT_DDR3_B_512M

M86XT_DDR3_B_512M

M86XT_DDR3_B_512M

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

RM2 3A

RM2 3A

RM2 3A

Date: Sheet

Date: Sheet

Date: Sheet

J12

VSS10

J1

VSS9

V10

VSS8

V3

VSS7

L12

VSS6

L1

VSS5

G12

VSS4

G1

VSS3

A10

VSS2

A3

VSS1

T12

VSSQ20

T9

VSSQ19

T4

VSSQ18

T1

VSSQ17

P12

VSSQ16

P9

VSSQ15

P4

VSSQ14

P1

VSSQ13

L11

VSSQ12

L2

VSSQ11

G11

VSSQ10

G2

VSSQ9

D12

VSSQ8

D9

VSSQ7

D4

VSSQ6

D1

VSSQ5

B12

VSSQ4

B9

VSSQ3

B4

VSSQ2

B1

VSSQ1

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

7

of

of

of

24 59Friday, August 08, 2008

24 59Friday, August 08, 2008

24 59Friday, August 08, 2008

8

5

http://hobi-elektronika.net

R18 499/FR18 499/F
R17 499/FR17 499/F

R21 499/FR21 499/F
R22 499/FR22 499/F

R20 499/FR20 499/F

DP_LANE3_N(19)
DP_LANE3_P(19)

DP_LANE2_N(19)
DP_LANE2_P(19)

DP_LANE1_N(19)
DP_LANE1_P(19)

DP_LANE0_N(19)
DP_LANE0_P(19)

R19 499/FR19 499/F

R15 499/FR15 499/F
R16 499/FR16 499/F

31

2

Q3

Q3
2N7002W-7-F

2N7002W-7-F

AUX_SINK_N
AUX_SINK_P

C531 0.1U/10VC531 0. 1U/10V

1 2
1 2

C532 0.1U/10VC532 0. 1U/10V

C533 0.1U/10VC533 0. 1U/10V

1 2
1 2

C534 0.1U/10VC534 0. 1U/10V

C535 0.1U/10VC535 0. 1U/10V

1 2
1 2

C536 0.1U/10VC536 0. 1U/10V

C537 0.1U/10VC537 0. 1U/10V

1 2
1 2

C538 0.1U/10VC538 0. 1U/10V

C5 0.1U/10VC5 0.1U/10V

1 2
1 2

C6 0.1U/10VC6 0.1U/10V

D D

+5V_RUN

C C

Reserve For EMI

B B

A A

M86 DDC4, 5V
tolerance, no level
shift needed

HDMI_CLK+_L
HDMI_CLK-_L

HDMI_TX2+_L
HDMI_TX2-_L

HDMI_TX1+_L
HDMI_TX1-_L

HDMI_TX0+_L
HDMI_TX0-_L

C542 0.1UC542 0.1U
C541 0.1UC541 0.1U

C545 0.1UC545 0.1U
C546 0.1UC546 0.1U

C544 0.1UC544 0.1U
C543 0.1UC543 0.1U

C539 0.1UC539 0.1U
C540 0.1UC540 0.1U

ATI_HDMI_CLK+ (19)

ATI_HDMI_CLK- (19)

ATI_HDMI_TX2+ (19)

ATI_HDMI_TX2- (19)

ATI_HDMI_TX1+ (19)

ATI_HDMI_TX1- (19)

ATI_HDMI_TX0+ (19)

ATI_HDMI_TX0- (19)

12
12

12
12

12
12

12
12

Pop for ATI Graphic

L61

DP_LANE3_N_C

DP_LANE2_N_C DP_LANE2_N_R
DP_LANE2_P_C

DP_LANE1_N_C
DP_LANE1_P_C

DP_LANE0_N_C
DP_LANE0_P_C

+3.3V_DELAY

+3.3V_DELAY

12

12

R11

R11

R2

100K

100K

*100K_NCR2*100K_NC

AUX_SINK_N_C
AUX_SINK_P_C DP_LANE0_P_R

12

12

R8

R12

R12

100KR8100K

*100K_NC

*100K_NC

5

L61

1 2

*PLW3216S900SQ2T1_NC

*PLW3216S900SQ2T1_NC

R403 0R403 0

1 2

R404 0R404 0

1 2

L62

L62

1 2

*PLW3216S900SQ2T1_NC

*PLW3216S900SQ2T1_NC

R405 0R405 0

1 2

R406 0R406 0

1 2

L63

L63

3 4

*PLW3216S900SQ2T1_NC

*PLW3216S900SQ2T1_NC

R407 0R407 0

1 2

R408 0R408 0

1 2

L64

L64

3 4

*PLW3216S900SQ2T1_NC

*PLW3216S900SQ2T1_NC

R409 0R409 0

1 2

R410 0R410 0

1 2

L60

L60

1 2

*PLW3216S900SQ2T1_NC

*PLW3216S900SQ2T1_NC

R401 0R401 0

1 2

R402 0R402 0

1 2

DP_LANE3_N_R
DP_LANE3_P_RDP_LANE3_P_C

34

DP_LANE2_P_R

34

DP_LANE1_N_R
DP_LANE1_P_R

12

DP_LANE0_N_R
DP_LANE0_P_R

12

AUX_SINK_N_R
AUX_SINK_P_R

34

4

L59

HDMI_TX2-_L
HDMI_TX2+_L

HDMI_TX1-_L
HDMI_TX1+_L

HDMI_TX0-_L
HDMI_TX0+_L

HDMI_CLK-_L HDMI_CLK­HDMI_CLK+_L

Delete EMI ESD IC for EMI asked HDMI signals link to
CONN directly.

Reserve For ESD

AUX_SINK_P_R

DP_HPD_SINK DP_HPD_SINK

DP_LANE3_N_R
DP_LANE3_P_R

DP_LANE2_N_R
DP_LANE2_P_R

DP_LANE1_N_R
DP_LANE1_P_R

DP_LANE0_N_R
DP_LANE0_P_R

4

L59

1 2

EXC24CG900U

EXC24CG900U

R400 *0_NCR400 *0_NC

1 2

R399 *0_NCR399 *0_NC

1 2

L58

L58

1 2

EXC24CG900U

EXC24CG900U

R397 *0_NCR397 *0_NC

1 2

R398 *0_NCR398 *0_NC

1 2

L56

L56

1 2

EXC24CG900U

EXC24CG900U

R394 *0_NCR394 *0_NC

1 2

R393 *0_NCR393 *0_NC

1 2

L57

L57

1 2

EXC24CG900U

EXC24CG900U

R395 *0_NCR395 *0_NC

1 2

R396 *0_NCR396 *0_NC

1 2

U23

U23

1

1

2

2

3

GND

4

4

5

5

*RClamp0524P_NC

*RClamp0524P_NC

U24

U24

1

1

2

2

3

GND

4

4

5

5

*RClamp0524P_NC

*RClamp0524P_NC

U25

U25

1

1

2

2

3

GND

4

4

5

5

*RClamp0524P_NC

*RClamp0524P_NC

HDMI_TX2-

34

HDMI_TX2+

HDMI_TX1­HDMI_TX1+

34

Gur_0808: EMI solution, depop R393~R400,
pop L56~L59 with "CXCG900U000"

HDMI_TX0-

34

HDMI_TX0+

HDMI_CLK+

34

AUX_SINK_N_RAUX_SINK_N_R

10

10

AUX_SINK_P_R

9

9

7

7

CAD_SINKCAD_SINK

6

6

DP_LANE3_N_R

10

10

DP_LANE3_P_R

9

9

DP_LANE2_N_R

7

7

DP_LANE2_P_R

6

6

DP_LANE1_N_R

10

10

DP_LANE1_P_R

9

9

DP_LANE0_N_R

7

7

DP_LANE0_P_R

6

6

3

Gur_0808: 0 ohm removal, delete R9

+5V_RUN

R10

ATI_HDMI_DET(19)

R411 10KR 411 10K

+5V_RUN

12

R30

R30

4.7K

4.7K

R10

2.2K

2.2K

+3.3V_DELAY

12

DP_HPD_SINK

AUX_SINK_N_R
AUX_SINK_P_R

DP_LANE3_N_R
DP_LANE3_P_R

DP_LANE2_N_R
DP_LANE2_P_R

DP_LANE1_N_R
DP_LANE1_P_R

DP_LANE0_N_R

M86 DDC3, 5V
tolerance, no level
shift needed

ATI_HDMI_SCL(19)

ATI_HDMI_SDA(19)

DISPLAY PORT CONNECTOR

DP only, no dongle
support DVI or HDM I

ATI_DP_HPD(19)

3

12

12

R3

2.2KR32.2K

T2T2
T3T3

R1 10KR 1 10K

R414 0R414 0

F1

F1

1 2

*POLY SWITCH 1.1A_NC

*POLY SWITCH 1.1A_NC

R28

R28

4.7K

4.7K

Q5 FD V301NQ5 F DV301N

1

2

+3.3V_DELAY

2

1

Q4 FD V301NQ4 F DV301N

18

17
15

12
10

9
7

6
4

3
1

HDMI_TX2+

HDMI_TX2­HDMI_TX1+

HDMI_TX1­HDMI_TX0+

HDMI_TX0­HDMI_CLK+

HDMI_CLK­HDMI_CEC

HDMI_SCL_L
HDMI_SDA_L

HDMI_DET

+VCC_HDMI_+5V

12

HDMI_SCL_L

3

HDMI_SDA_L

3

CN17

CN17

dp-rsd-47644-001-20p-l-h

dp-rsd-47644-001-20p-l-h

HPD

AUXN
AUXP

LANE_3N
LANE_3P

LANE_2N
LANE_2P

LANE_1N
LANE_1P

LANE_0N
LANE_0P

20

20

18

18

16

16

14

14

12

12

10

10

8

8

6

6

4

4

2

2

19

19

17

17

15

15

13

13

11

11

9

9

7

7

5

5

3

3

1

1

C1
*0.1U_NCC1*0.1U_NC

*RB500V-40_NC

*RB500V-40_NC

SHIELD6
SHIELD5

PWR
PWR_RET

GND

GND
MODE

GND

GND

GND

GND

SHIELD3
SHIELD2

2

CN14

CN14

20

SHELL1

1

22

D2+

GND

2

D2 Shield

3

D2-

4

D1+

5

D1 Shield

6

D1-

7

D0+

8

D0 Shield

9

D0-

10

CK+

11

CK Shield

12

CK-

13

CE Remote

14

NC

15

DDC CLK

16

DDC DATA

17

GND

18

+5V

19

HDMI-2041602-3-19P-LDV-H

HDMI-2041602-3-19P-LDV-H

23

HP DET

GND

21

SHELL2

TYC_2041602-3

TYC_2041602-3

AUX_SINK_N(19)

AUX_SINK_P(19)

Temporary DP dongle
support circuit for DP
function test

Remember to keep 1M &
499/F connection when
remove dongle circuit.

+3.3V_RUN

21

D22

D22

21

C529

C529

23

220P

220P

20
19

16

CONFIG2

14

CAD_SINK

13

11

8

5

2

22
24

2

FS2

FS2
1206L150-C

1206L150-C

12

C530

C530

10U/6.3V/0603

10U/6.3V/0603

12

R723

R723
*499/F_NC

*499/F_NC

1

3

3

1

Q52

Q52

2

BSS138_NL

BSS138_NL

3

3

1

Q49

Q49

2

BSS138_NL

BSS138_NL

12

R421

R421
499/F

499/F

31

2

Q46

Q46
2N7002W-7-F

2N7002W-7-F

T1T1
T4T4

AUX_SINK_N_CAUX_SINK_N

1

Q53

Q53

2

BSS138_NL

BSS138_NL

AUX_SINK_P_CAUX_SINK_P

1

Q50

Q50

2

BSS138_NL

BSS138_NL

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

12

C551

C551

0.1U/10V

0.1U/10V

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

HDMI & DP

HDMI & DP

HDMI & DP

RM2 3A

RM2 3A

RM2 3A

12

R424

R424
100K

100K

31

Q48

Q48
2N7002W-7-F

2N7002W-7-F

1

+3.3V_RUN+5V_RUN

12

31

2

R419

R419
100K

100K

Q47

Q47
2N7002W-7-F

2N7002W-7-F

2

12

25 59Friday, August 08, 2008

25 59Friday, August 08, 2008

25 59Friday, August 08, 2008

CAD_SINK

R4201MR420
1M

of

of

of

5

http://hobi-elektronika.net

CN4

CN4

50
49
48
47
46
45
44
43
42
41
40
39
38

51

51

52

52

53

53

54

54

55

55

56

56

IPX_20323-050ED41

IPX_20323-050ED41

37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10

9
8
7
6
5
4
3
2
1

D D

C C

LCD_BCLK-

50

LCD_BCLK+

49
48

LCD_B3-

47

LCD_B3+

46
45

LCD_B2-

44

LCD_B2+

43
42

LCD_B1-

41

LCD_B1+

40
39

LCD_B0-

38

LCD_B0+

37
36

LCD_ACLK-

35

LCD_ACLK+

34
33

LCD_A3-

32

LCD_A3+

31
30

LCD_A2-

29

LCD_A2+

28
27

LCD_A1-

26

LCD_A1+

25
24

LCD_A0-

23

LCD_A0+

22
21
20
19
18
17
16
15
14
13
12
11
10

BACKLITE_DPST

9
8
7

SMBCLK1

6

SMBDAT1

5
4
3
2
1

+LCDVCC

12

C593

C593

0.1U/10V

0.1U/10V

ATI_LCD_DDCCLK (19)
ATI_LCD_DDCDAT (19)

Gur_0808: 0 ohm

+3.3V_RUN

removal, delete R72, R74

+LCDVCC

LCD_TST (31)

+GFX_PWR_SRC

Gur_0808: 0 ohm

+5V_ALW

remova l, delete R82

SMBCLK1 (17,31,39)

SMBDAT1 (17,31,39)

INVERTER_CBL_DET# (31)
LCD_BAK# (31)
PWM_VADJ (31)
LCD_CBL_DET# ( 31)

12

C595

C595

0.047U/10V

0.047U/10V

+3.3V_RUN

12

R444

R444
*10K_NC

*10K_NC

R446 0R446 0

+3.3V_RUN

12

C591

C591

0.1U/10V

0.1U/10V

DPST support : Pop 0 ohm,
Depop 10K

1 2

Adress : A9H --Contrast
AAH --Backlight

SMBCLK1
SMBDAT1

M86-LP

U38F

U38F

PART 7 OF 7

PART 7 OF 7

+LVDDR

+LVDDC

B B

+LPVDD

AJ26
AH26

AK27
AL27

AM24

AN28
AN21
AN24
AN25

AM22

AP21
AP26

AM27

AR21
AR26

AM26

AJ22
AJ24

AL22
AK22

LVDDR_1
LVDDR_2

LVDDC_1
LVDDC_2

LVSSR_1
LVSSR_2
LVSSR_3
LVSSR_4
LVSSR_5
LVSSR_6
LVSSR_7
LVSSR_8
LVSSR_9
LVSSR_10
LVSSR_11
LVSSR_12
LVSSR_13
LVSSR_14

LPVDD
LPVSS

M86-ME XT A11

M86-ME XT A11

Control

Control

TXCLK_UP

TXCLK_UN
TXOUT_U0P
TXOUT_U0N
TXOUT_U1P
TXOUT_U1N
TXOUT_U2P
TXOUT_U2N
TXOUT_U3P
TXOUT_U3N

TXCLK_LN

LVDS channel

LVDS channel

TXOUT_L0P
TXOUT_L0N
TXOUT_L1P
TXOUT_L1N
TXOUT_L2P
TXOUT_L2N
TXOUT_L3P
TXOUT_L3N

VARY_BL

DIGON

TXCLK_LP

AG7

AJ6

AK24
AL24
AN27
AN26
AP27
AR27
AG24
AH24
AK26
AL26

AR22
AP22
AN23
AN22
AP23
AR23
AP24
AR24
AP25
AR25

R265

R265
10K

10K

ATI_BIA_PWM

ENVDD

LCD_BCLK+
LCD_BCLK­LCD_B0+
LCD_B0­LCD_B1+
LCD_B1­LCD_B2+
LCD_B2­LCD_B3+
LCD_B3-

LCD_ACLK+
LCD_ACLK­LCD_A0+
LCD_A0­LCD_A1+
LCD_A1­LCD_A2+
LCD_A2­LCD_A3+
LCD_A3-

Gur_0808: 0 ohm
removal, delete R519

ATI_BIA_PWMBACKLITE_DPST

12

C114

C114
*47P/50V_NC

*47P/50V_NC

4

12

C113

C113
*47P/50V_NC

*47P/50V_NC

3

Shunt capacitors on LVDS for improving WWAN.

LCD_B0-

C87 *3.3P/50V_NCC87 *3.3P/50V_NC

LCD_B1- LCD_B1+
LCD_B2­LCD_B3- LCD_B3+

LCD_A0­LCD_A1­LCD_A2-

Support the new imbeded
diagnostics.

LCDVCC_TST_EN(31)

1 2

C86 *3.3P/50V_NCC86 *3.3P/50V_NC

1 2

C85 *3.3P/50V_NCC85 *3.3P/50V_NC

1 2

C84 *3.3P/50V_NCC84 *3.3P/50V_NC

1 2

C97 *3.3P/50V_NCC97 *3.3P/50V_NC

1 2

C93 *3.3P/50V_NCC93 *3.3P/50V_NC

1 2

C92 *3.3P/50V_NCC92 *3.3P/50V_NC

1 2

C89 *3.3P/50V_NCC89 *3.3P/50V_NC

1 2

Gur_0808: 0 ohm removal,
delete R61, R63, R65, R68

12

12

R67

R67

C88

C88

*0_NC

*0_NC

*3.3P/50V_NC

*3.3P/50V_NC

12

12

R62

R62

C82

C82

*0_NC

*0_NC

*3.3P/50V_NC

*3.3P/50V_NC

R458 *0_NCR458 *0_NC

1 2

D26

D26

ENVDD

1

2

BAT54C T/R

BAT54C T/R

3

EN_LCDVCC

LCD_B0+

LCD_B2+

LCD_A0+
LCD_A1+
LCD_A2+
LCD_A3+LCD_A3-

LCD_ACLK-

LCD_ACLK+

LCD_BCLK-

LCD_BCLK+

+3.3V_RUN +3.3V_SUS

12

R451

R451
*47K_NC

*47K_NC

2

+15V_ALW +LCDVCC+3.3V_RUN

12

31

12

R448

R448
47K

47K

Q62

Q62
DDTC124EUA-7-F

DDTC124EUA-7-F

1 3

2

+PWR_SRC +GFX_PWR_SRC

R457

R457
330K

330K

LCDVCC_ON

12

2

Q64

Q64
2N7002W-7-F

2N7002W-7-F

RUN_ON(20,45,48,49,55)

R455

R455
*100K_NC

*100K_NC

6
5
2
1

12

R76

R76
100K

100K

Q63

Q63
FDC655BN

FDC655BN

3

12

C599

C599

0.01U/25V

0.01U/25V

65 mils

2

4

2

12

31

12

12

31

R447

R447
47

47

RC0805

RC0805

C105

C105

0.1U/50V

0.1U/50V

0603

0603
50

50

R79

R79
100K

100K

Q10

Q10
2N7002W-7-F

2N7002W-7-F

Q60

Q60
2N7002W-7-F

2N7002W-7-F

4

12

C596

C596
22U/10V

22U/10V

CC1206

CC1206

3

6
5
2
1

Q9
FDC658APQ9FDC658AP

12

65 mils

12

C108

C108

0.1U/50V

0.1U/50V

CC0603

CC0603

GFX_PWR_SRC layout note:
40 mil trace for tube type
45 mil for white LED type
65 mil for RGB LED type

C592

C592

0.01U/25V

0.01U/25V

12

C107

C107

0.1U/50V

0.1U/50V

CC0603

CC0603

1

A A

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

M86XT_LVDS & LCD CONN

M86XT_LVDS & LCD CONN

M86XT_LVDS & LCD CONN

RM2 3A

RM2 3A

RM2 3A

1

of

of

of

26 59Friday, August 08, 2008

26 59Friday, August 08, 2008

26 59Friday, August 08, 2008

5

4

Title

Title

Title

Size D ocument Number Rev

Size D ocument Number Rev

Size D ocument Number Rev

Date: Sheet

Date: Sheet

3

2

Date: Sheet

A

http://hobi-elektronika.net

B

C

D

E

4 4

2

1

Layout Note:
Setting R,G,B treac

R23

R23
150/F

150/F

impedance to 50 ohm.

R24

R24
150/F

150/F

12

R26

R26
150/F

150/F

12

12

C7
22P/50VC722P/50V

12

C8
22P/50VC822P/50V

VGA_RED(19)

VGA_GRN(19)

VGA_BLU(19)

3 3

12

12

C9
22P/50VC922P/50V

L3

L3
BLM18BB750SN1D

BLM18BB750SN1D

RC0603

RC0603

1 2

L2

L2
BLM18BB750SN1D

BLM18BB750SN1D

RC0603

RC0603

1 2

L1

L1
BLM18BB750SN1D

BLM18BB750SN1D

RC0603

RC0603

1 2

D1

D1

3

*DA204U_NC

*DA204U_NC

12

C2
10P/50VC210P/50V

1

2

D2

D2

3

*DA204U_NC

*DA204U_NC

12

C3
10P/50VC310P/50V

Gur_0808: EMI solution , change C2~C4 fro m 5.6p to 10p ; C7~ C9 from 5.6p t o 22p

+3.3V_DELAY

12

12

G_DAT_DDC(19)

+5V_RUN

2 2

VGAHSYNC(19)

VGAVSYNC(19)

D23

D23
SDM10K45-7-F

SDM10K45-7-F

2 1

VGAHSYNC

C524

C524

0.1U/10V

0.1U/10V

CRT_VCC

12

1

5

2 4

74AHCT1G125GW

74AHCT1G125GW

1

5

2 4

74AHCT1G125GW

74AHCT1G125GW

U22

U22

U21

U21

R392 1KR392 1K

VGAHSYNC_R

VGAVSYNC_RVGAVSYNC

12

G_CLK_DDC(19)

R391 33R391 33

1 2

Place near
U24,U25 <
200 mil

R388 33R388 33

1 2

G_DAT_DDC

G_CLK_DDC

HSYNC

VSYNC

+3.3V_DELAY+5V_RUN

R412

R412

2.7K/F

2.7K/F

+3.3V_DELAY

R413

R413

2.7K/F

2.7K/F

1

1

Q45

Q45
BSS138_NL

BSS138_NL

2

2

Q44

Q44
BSS138_NL

BSS138_NL

3

3

12

C521

C521

0.01U/25V

0.01U/25V

G_DAT_DDC_C

G_CLK_DDC_C

12

C527

C527
*22P/50V_NC

*22P/50V_NC

12

R390

R390

2.7K/F

2.7K/F

12

C522

C522
*22P/50V_NC

*22P/50V_NC

12

C528

C528
*10P/50V_NC

*10P/50V_NC

12

C525

C525
*10P/50V_NC

*10P/50V_NC

+3.3V_DELAY

1

CRT_VCC

12

R389

R389

2.7K/F

2.7K/F

2

D3

D3

3

*DA204U_NC

*DA204U_NC

T100PAD T100PAD

12

C4
10P/50VC410P/50V

T99PAD T99PAD

R387 33R387 33

1 2

R386 33R386 33

1 2

L55 BLM11A05S

L55 BLM11A05S

1 2

RC0603

RC0603

L54 BLM11A05S

L54 BLM11A05S

1 2

RC0603

RC0603

RED

M_SEN#_R

GREEN

BLUE

M_ID2#

G_DAT_DDC_R

G_CLK_DDC_R

JVGA_HS

12

C526

C526
47P/50V

47P/50V

JVGA_VS

12

C523

C523
47P/50V

47P/50V

+5V_RUN

21

D17

D17
SDM10K45-7-F

SDM10K45-7-F

+5V_CRT_REF

CN18

CN18

6

11

1
7

12

2
8

13

3
9

14

4
10
15

5

FOX_DZ11A91-SB283-9F

FOX_DZ11A91-SB283-9F

DSUB-DZ11A91-SB283-9F-15P-H

DSUB-DZ11A91-SB283-9F-15P-H

Place near JVGA1 connector <

D

200 mil

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

COMPUTER

CRT CONN

CRT CONN

CRT CONN

RM2 3A

RM2 3A

RM2 3A

E

of

of

of

27 59Friday, August 08, 2008

27 59Friday, August 08, 2008

27 59Friday, August 08, 2008

2

1 1

A

1

D18

D18

3

*DA204U_NC

*DA204U_NC

1

2

D19

D19

3

*DA204U_NC

*DA204U_NC

VGAHSYNC
VGAVSYNC

B

1

2

D20

D20

3

*DA204U_NC

*DA204U_NC

1

2

D21

D21

3

*DA204U_NC

*DA204U_NC

G_DAT_DDC
G_CLK_DDC

C

A

http://hobi-elektronika.net

B

C

D

E

Place the power caps close
to the relation pins.

12

1 1

Please place
capacitors for
VCC_ROUTx as
close to R5C833 as
possible.

2 2

+3.3V_R5C833

12

R655

R655
100K

100K

GBRST#

12

C807

C807
1U/10V

1U/10V

GBRST# should be

CC0603

CC0603

asserted only when
system power supply
is on.

3 3

CLK_PCI_PCCARD

12

R660

R660
*22_NC

*22_NC

12

C823

C823
*1P/50V_NC

*1P/50V_NC

4 4

A

C804

C804
10U/6.3V

10U/6.3V

CC0603

CC0603

12

C805

C805

0.01U/25V

0.01U/25V

+3.3V_R5C833

PCI_PAR(12,56)
PCI_C_BE3#(12,56)
PCI_C_BE2#(12,56)
PCI_C_BE1#(12,56)
PCI_C_BE0#(12,56)

PCI_REQ0#(12)

PCI_GNT0#(12)
PCI_FRAME#(12,56)
PCI_IRDY#(12,56)
PCI_TRDY#(12,56)
PCI_DEVSEL#(12,56)
PCI_STOP#(12,56)
PCI_PERR#(12,56)

PCI_SERR#(12,56)

PCI_RST#(12,56)

CLK_PCI_PCCARD(17)

ICH_PME#(12,56)

CLKRUN#(13,31,56)

12

C802

C802
10U/6.3V

10U/6.3V

CC0603

CC0603

12

C822

C822

0.01U/25V

0.01U/25V

PCI_AD[31..0](12,56)

12

C806

C806

0.01U/25V

0.01U/25V

12

12

C811

C811

0.1U/10V

0.1U/10V

12

C809

C809

0.01U/25V

0.01U/25V

C808

C808

0.01U/25V

0.01U/25V

B

12

C812

C812

0.01U/25V

0.01U/25V

12

C800

C800

0.01U/25V

0.01U/25V

12

C796

C796

0.47U/10V

0.47U/10V

CC0603

CC0603

PCI_AD17

GBRST#

CLK_PCI_PCCARD

+3.3V_R5C833

12

C824

C824

0.01U/25V

0.01U/25V

12

C798

C798

0.01U/25V

0.01U/25V

12

C801

C801

0.47U/10V

0.47U/10V

CC0603

CC0603

PCI_AD31
PCI_AD30
PCI_AD29
PCI_AD28
PCI_AD27
PCI_AD26
PCI_AD25
PCI_AD24
PCI_AD23
PCI_AD22
PCI_AD21
PCI_AD20
PCI_AD19
PCI_AD18
PCI_AD17
PCI_AD16
PCI_AD15
PCI_AD14
PCI_AD13
PCI_AD12
PCI_AD11
PCI_AD10
PCI_AD9
PCI_AD8
PCI_AD7
PCI_AD6
PCI_AD5
PCI_AD4
PCI_AD3
PCI_AD2
PCI_AD1
PCI_AD0

R658 100R658 100

1 2

R654 *0_NCR654 *0_NC

1 2

10
20
27
32
41

128

61

16
34

64
114
120

125
126
127

1
2
3
5
6

9
11
12
14
15
17
18
19
36
37
38
39
40
42
43
44
46
47
48
49
50
51
52
53
33

7
21
35
45

8

124
123

23
24
25
26
29
30
31

71

119

121

70

117

U46B

U46B

VCC_PCI1
VCC_PCI2
VCC_PCI3
VCC_PCI4
VCC_PCI5
VCC_PCI6

VCC_RIN

VCC_ROUT1
VCC_ROUT2
VCC_ROUT3
VCC_ROUT4
VCC_ROUT5

AD31
AD30
AD29
AD28
AD27
AD26
AD25
AD24
AD23
AD22
AD21
AD20
AD19
AD18
AD17
AD16
AD15
AD14
AD13
AD12
AD11
AD10
AD9
AD8
AD7
AD6
AD5
AD4
AD3
AD2
AD1
AD0
PAR
C/BE3#
C/BE2#
C/BE1#
C/BE0#
IDSEL

REQ#
GNT#
FRAME#
IRDY#
TRDY#
DEVSEL#
STOP#
PERR#
SERR#

GBRST#
PCIRST#

PCICLK

PME#

CLKRUN#

R5C833T_V00

R5C833T_V00

PCI / OTHER

PCI / OTHER

C

VCC_3V

VCC_MD

GND1
GND2
GND3
GND4
GND5
GND6
GND7
GND8
GND9

GND10

AGND1
AGND2
AGND3
AGND4
AGND5

HWSPND#

MSEN

XDEN

UDIO5

UDIO3
UDIO4

UDIO2

UDIO1

UDIO0/SRIRQ#

INTA #

INTB #

TEST

+3.3V_RUN

+3.3V_R5C833

67

86

4
13
22
28
54
62
63
68
118
122

99
102
103
107
111

69

Memory Stick Enable

58

XD Card Enable

55

Serial ROM disable

57

SD Card Enable

65
59

MMC Card Enable

56

60

72

1394 Interrupt

115

Media card Interrupt

116

66

12

R651

R651
100K

100K

+3.3V_R5C833

R664

R664
0/0805

0/0805

RC0805

RC0805

1 2

12

Place the power caps
close to the relation
pins.

R653 10KR653 10K

1 2

C815

C815

0.1U/10V

0.1U/10V

T162PAD T162PAD

12

+3.3V_R5C833

D

C814

C814
10U/6.3V

10U/6.3V

CC0603

CC0603

IRQ_SERIRQ (13,31,56)

PCI_PIRQB# (12)

PCI_PIRQC# (12)

+3.3V_R5C833

+3.3V_R5C833

12

R648

R648
10K

10K

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

12

R645

R645
100K

100K

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

CardReader (5C833)

CardReader (5C833)

CardReader (5C833)

RM2 2D

RM2 2D

RM2 2D

E

of

of

of

28 59Wednesday, August 06, 2008

28 59Wednesday, August 06, 2008

28 59Wednesday, August 06, 2008

A

http://hobi-elektronika.net

1394_XI

1394_XO

Y4

Y4

24.576MHZ

24.576MHZ

12

C813

C813

1 1

22P/50V

22P/50V

XTAL for XO/XI, 50ppm or better
Required

2 2

3 3

SD_XD_MS_CLK

12

4 4

R656

R656
*22_NC

*22_NC

12

C810

C810
*1P/50V_NC

*1P/50V_NC

Gur_0808: 0 ohm
removal, delete R659

21

12

C816

C816
22P/50V

22P/50V

1394_XI

1394_XO

RICOH_FILO

T164PAD T16 4PAD

RICOH_REXT

R662

R662
10K/F

10K/F

A

RICOH_VREF

12

C820

C820

0.01U/25V

0.01U/25V

12

Place these
components as close
to the CardReader as
possible.

U46A

U46A

94

XI

95

XO

96

FIL0

101

REXT

100

VREF

97

RSV

R5C833T_V00

R5C833T_V00

The trace width for
+3.3V_RUN_CARD
should be 40MIL at
least.

IEEE1394/SD

IEEE1394/SD

+3.3V_RUN_CARD

12

C851

C851

0.01U/25V

0.01U/25V

AVCC_PHY1
AVCC_PHY2
AVCC_PHY3
AVCC_PHY4

TPBIAS0

TPBN0

TPBP0

TPAN0

TPAP0

MDIO17

MDIO16

MDIO15

MDIO14

MDIO13

MDIO12

MDIO11

MDIO10

MDIO05

MDIO08

MDIO19

MDIO18

MDIO02

MDIO03

MDIO00

MDIO01

MDIO09

MDIO04

MDIO06

MDIO07

12

C858

C858

0.01U/25V

0.01U/25V

B

B

98
106
110
112

113

104

105

108

109

87

92

89

91

90

93

81

82

75

88

83

85

78

77

80

79

84

76

74

73

XD_MMS_DATA7

XD_MMS_DATA6

XD_MMS_DATA5

XD_MMS_DATA4

SD_XD_MS_DATA3

SD_XD_MS_DATA2

SD_XD_MS_DATA1

SD_XD_MS_DATA0

XD_WP #

SD_XD_MS_CMD

XD_ALE

XD_CLE

XD_CE#

SD_WP#_XDR_B#

SD_CD#

MS_INS#

SD_XD_MS_CLK

MC_PWR_CTRL_0

80 mils

3.3V_RUN_PHY

12

C826

C826
10U/6.3V

10U/6.3V

CC0603

CC0603

12

12

R677

R677

R676

R676

56.2/F

56.2/F

56.2/F

56.2/F

R661

R661

56.2/F

56.2/F

T163PADT163PAD

Close Pin4 of
CardReader Conn

C857

C857

0.01U/25V

0.01U/25V

12

R693

R693
150K

150K

12

12

12

12

C821

C817

C817

0.1U/10V

0.1U/10V

C821

0.01U/25V

0.01U/25V

As possible as close
to CardReader

TPBIAS0

C825 0.33U/16V

C825 0.33U/16V

C818 0.01U/25VC818 0.01U/25V

Reserved EMI Solution

TPB0N

TPB0P

TPA0N

TPA0P

12

R663

R663

56.2/F

56.2/F

2.2uF cap is no more than
250mils away from the power
pin and a have a min trace
width of 40mils.

SD_CD#
SD_WP#

XD_MMS_DATA7
XD_MMS_DATA6
XD_MMS_DATA5
XD_MMS_DATA4
SD_XD_MS_DATA1
SD_XD_MS_DATA3
SD_XD_MS_DATA0
SD_XD_MS_DATA2
XD_MMS_DATA7
SD_XD_MS_DATA1

XD_MMS_DATA6
SD_XD_MS_CMD
SD_XD_MS_CLK
SD_XD_MS_DATA1
SD_XD_MS_DATA0
SD_XD_MS_DATA0

1 2

*DLW21SN900SQ2B_NC

*DLW21SN900SQ2B_NC

1 2

*DLW21SN900SQ2B_NC

*DLW21SN900SQ2B_NC

C832 270P/50VC832 270P/50V

R672 5.11K/FR672 5.11K/F

C852

C852

*270P/25V_NC

*270P/25V_NC

Close to the Chip

SD_CD#

MS_INS#

C

1 2

L80

L80
BLM18PG181SN1D

BLM18PG181SN1D

12

C819

C819

RC0603

RC0603

1000P/50V

1000P/50V

Place these caps as close to
the CardReader as possible.

1. TPA0P/TPA0N,TPB0P/TPB0N pair trace :
Same length electrically.

1 2

CC0603

CC0603

1 2

L53

L53

L52

L52

1 2

OLTPB-

34

OLTPB+

OLTPA-

34

OLTPA+

1 2

Gur_0808: 0 ohm
removal, delete R694

12

+3.3V_R5C833

D33

D33

2 1

1SS355

1SS355
D32

D32

2 1

1SS355

1SS355

C

2. TPA0P/TPA0N,TPB0P/TPB0N pair trace : As
close as possible.

3. Termination resistor for TPA+/- TPB+/- : As
close as possible to its cable driver (device pin
out).

12

C855

C855

2.2U/6.3V

2.2U/6.3V

CC0603

CC0603

C859

C859

*27P/50V_NC

*27P/50V_NC

12

R647

R647
*10K_NC

*10K_NC

D

+3.3V_R5C833

Layout Note:

1). The distance between Media Card Power
Switch and Media Socket should be less than
2-inches.

2). The trace width for +3.3V_RUN_CARD
should be 40MIL at least.

CN13

CN13

1
2
3
4
567

8

TYC_2041054-6

TYC_2041054-6

06FFS-SP-TF-6P-L

06FFS-SP-TF-6P-L

TPB0N

R385 0R385 0

TPB0P
TPA0N
TPA0P

+3.3V_RUN_CARD +3.3V_RUN_CARD

12

12

C853

C853
*270P/25V_NC

*270P/25V_NC

1 2

R384 0R384 0

1 2

R383 0R383 0

1 2

R382 0R382 0

1 2

CON1

CON1

1

SD(CD2/WP2/GND)

2

SD(CD1)

3

SD(WP1)

4

XD-18(VCC)

5

XD-17(D7)

6

XD-16(D6)

7

XD-15(D5)

8

XD-14(D4)

9

SD-8(DAT1 )

10

XD-13(D3)

11

SD-7(DAT0 )

12

XD-12(D2)

13

MMC-(D7)

14

XD-11(D1)

15

SD-6(GND/VSS2)

16

MS-1(VSS)

17

MMC-(D6)

18

MS-2(BS)

19

SD-5(CLK)

20

MS-3(VCC/DATA1)

21

XD-10(D0)

22

MS-4(SDIO/DA TA0)

23

SD-4(VCC/VDD)

TAI-SOL_144-2400002900

TAI-SOL_144-2400002900

8IN1-144-2400002900-45P-R-H

8IN1-144-2400002900-45P-R-H

SD Protect

XD_CDSW#

R642 0R642 0

1 2

3 1

Q77

Q77
*2N7002W-7-F_NC

*2N7002W-7-F_NC

2

OLTPB­OLTPB+
OLTPA­OLTPA+

D

MS-5(DATA 2)

XD-9(GND)

MS-6(INS)

SD-3(VSS1)

MS-7(DATA 3)

MMC-(D5)

MS-8(SCLK )

SD-2(CMD)
MS-9(VCC)

MMC-(D4)
MS-10(VSS)
SD-1(DAT3 )

XD-8(-W P)

SD-9(DAT2 )

XD-7(W E)

XD-6(ALE)
XD-5(CLE)

XD-4(CE)
XD-3(RE)

XD-2(R/-B)

XD-1(CD)

XD-0(GND)

SD_WP#SD_WP#_XDR_B#

3). The GND trace for Media Card Socket
should be 40MIL at least.

+3.3V_R5C833 +3.3V_RUN_CARD

MC_PWR_CTRL_0

12

24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45

12

C856

C856

270P/25V

270P/25V

Title

Title

Title

8 IN 1 & 1394 CONN

8 IN 1 & 1394 CONN

8 IN 1 & 1394 CONN

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

RM2 3A

RM2 3A

RM2 3A

Date: Sheet

Date: Sheet

Date: Sheet

U50

U50

IN5OUT

3

OC#

EN4GND

TPS2051BDBV

C849

C849

0.1U/10V

0.1U/10V

Gur_0808: 0 ohm
removal, delete R692

TPS2051BDBV

12

C850

C850
*27P/50V_NC

*27P/50V_NC

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

E

1

2

SD_XD_MS_DATA2

MS_INS#

SD_XD_MS_DATA3
XD_MMS_DATA5
SD_XD_MS_CLK
SD_XD_MS_CMD

XD_MMS_DATA4

SD_XD_MS_DATA3
XD_WP#
SD_XD_MS_DATA2
SD_XD_MS_CMD
XD_ALE
XD_CLE
XD_CE#
SD_XD_MS_CLK
SD_WP#_XDR_B#
XD_CDSW#

12

C860

C860
*27P/50V_NC

*27P/50V_NC

E

12

C854

C854
1U/10V

1U/10V

CC0603

CC0603

29 59Monday, Aug ust 11, 2008

29 59Monday, Aug ust 11, 2008

29 59Monday, Aug ust 11, 2008

of

of

of

1

http://hobi-elektronika.net

2

3

4

5

6

7

8

Express Card

A A

USB7_D­USB7_D+
CPUSB#

ICH_SMBCLK(13,33,34)
ICH_SMBDATA(13,33,34)

+1.5V_CARD

PCIE_WAKE#(13,33,34,43)

+3.3V_CARDAUX

+3.3V_CARD

EXPRCRD_PWREN#(31)
CLK_PCIE_EXPCARD#(17)
CLK_PCIE_EXPCARD(17)

PCIE_RX4-(12)
PCIE_RX4+(12)

PCIE_TX4-(12)
PCIE_TX4+(12)

B B

CARD_RESET#

CARD_CLK_REQ#_R
EXPRCRD_PWREN#

FOX_1CH4110C-PL

FOX_1CH4110C-PL

expcard-1cx41101-pl-26p-l-rm2

expcard-1cx41101-pl-26p-l-rm2

PCI-Express TX and RX direct to connector.

L82

L82

ICH_USBP7+(12)

ICH_USBP7-(12)

C C

1 2

R679 0R679 0

1 2

R680 0R680 0

1 2

34

*DLW21SN900SQ2B_NC

*DLW21SN900SQ2B_NC

CN12

CN12

1

GND_1

2

USB-

3

USB+

4

CPUSB#

5

RSV_0

6

RSV_1

7

SMBCLK

8

SMBDATA

9

+1.5V_0

10

+1.5V_1

11

WAKE#

12

+3.3VAUX

13

PERST#

14

+3.3V_1

15

+3.3V_2

16

CLKREQ#

17

CPPE#

18

REFCLK-

19

REFCLK+

20

GND_2

21

PERn0

22

PERp0

23

GND_3

24

PETn0

25

PETp0

26

GND_4

USB7_D+
USB7_D-

+1.5V_RUN +3.3V_RUN +3.3V_SUS

+3.3V_SUS

T166

PLTRST#(6,12,31,33,34,43)

NC430NC329NC228NC1

27

T166

+1.5V_CARD Max. 650mA, Average 500mA.
+3V_CARD Max. 1300mA, Average 1000mA.

U49

U49

17

R690 100KR690 100K

PAD

PAD

12

Please the cap
near pin 12 &
14(1.5VIN).

2

12
14

20

1
6

16

7

AUXIN

3.3VIN_0

3.3VIN_143.3VOUT_1

1.5VIN_0

1.5VIN_1

ExpressSwitch

ExpressSwitch

SHDN#
STBY#
SYSRST#

NC
GND0

12

C841

C841

0.1U/10V

0.1U/10V

AUXOUT

3.3VOUT_0

1.5VOUT_0

1.5VOUT_1

PERST#

CPPE#

CPUSB#

OC#

RCLKEN

R5538D001-TR-F

R5538D001-TR-F

+3.3V_RUN+1.5V_RUN

Please the cap
near pin 2 & 4
(3.3VIN).

+3.3V_CARDAUX +3.3V_CARD +1.5V_CARD

15
3
5
11
13

CARD_RESET#

8

EXPRCRD_PWREN#

10

CPUSB#

9
19

RCLKEN CARD_CLK_REQ#_R

18

12

C847

C847

0.1U/10V

0.1U/10V

R683 100KR683 100K
R685 100KR685 100K

31

2N7002W-7-F

2N7002W-7-F

2

+3.3V_SUS

12

C842

C842

0.1U/10V

0.1U/10V

Please the cap
near pin 17
(AUXIN).

Q78

Q78

+3.3V_SUS

12
12

R688 100KR688 100K

12

CARD_CLK_REQ# (17)

+3.3V_CARD

+3.3V_CARDAUX

12

C840

12

C837

C837
10U/6.3V

10U/6.3V

CC0603

CC0603

12

C839

C839

0.1U/10V

0.1U/10V

12

C838

C838

0.1U/10V

0.1U/10V

12

C834

C834

0.1U/10V

0.1U/10V

12

C835

C835

0.1U/10V

0.1U/10V

Please the cap near connector.Please the cap near connector.

D D

1

2

3

4

5

C840

0.1U/10V

0.1U/10V

Please the cap
near pin 15
(AUXOUT).

+3.3V_CARD +1.5V_CARD+1.5V_CARD+3.3V_CARD

12

C848

C848

0.1U/10V

0.1U/10V

Please the cap
near pin 3 & 5
(3.3VOUT).

6

12

C833

C833

0.1U/10V

0.1U/10V

Please the cap
near pin 11 &
13(1.5VOUT).

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

COMPUTER

EXPRESS CARD

EXPRESS CARD

EXPRESS CARD

RM2 2D

RM2 2D

RM2 2D

7

of

of

of

30 59Wednesday, August 06, 2008

30 59Wednesday, August 06, 2008

30 59Wednesday, August 06, 2008

8

5

http://hobi-elektronika.net

+3.3V_ALW

C794

1 2

10

10

6.3

6.3

D D

C C

Place these caps close to ITE8512.

603

603

THERM_STP#(39,50)

1 2

10

10

D34

D34

SDMK0340L-7-F

SDMK0340L-7-F

ICH_AZ_CODEC_RST#(11,40)

Gur_0808: 0 ohm
removal, delete R652

C794

C792

C792

0.1U

0.1U

10U

10U

1 2

CHARGE & BAT

CLK & LCD & thermal

G_thermal & LAN &media button

RESET_OUT#

12

R3461KR346
1K

B B

CLK_PCI_8512

R62510R625
10

12

C790

C790

2.2P

2.2P

50

50

C799

C799

0.1U

0.1U

C797

C797

C793

C793

0.1U

0.1U

0.1U

+3.3V_ALW

1 2

12

IMVP_PWRGD(13,45,51)

RESET_OUT#(45)

CLK_TP_SIO(37)
DAT_TP_SIO(37)

10

10

R678

R678
100K

100K

C8361UC836
1U

LED_MASK#(38)

0.1U

1 2

WRST#

Gur_0808: 0 ohm
removal, delete R628

SMBCLK0(22,47,54)
SMBDAT0(22,47,54)

SMBCLK1(17,26,39)
SMBDAT1(17,26,39)

SMBCLK2(37)
SMBDAT2(37)

+3.3V_ALW

1 2

10

10

21

CLK_PCI_8512(17)
LPC_LFRAME#(11,34)

LPC_LAD0(11,34)
LPC_LAD1(11,34)
LPC_LAD2(11,34)
LPC_LAD3(11,34)

CLKRUN#(13,28,56)

IRQ_SERIRQ(13,28,56)
SIO_EXT_SMI#(13)
SIO_EXT_SCI#(13)

SIO_A20GATE(11)

LCD_TST(26)

SIO_RCIN#(11)

LCD_BAK#(26)

NB_MUTE#(41)

PLTRST#(6,12,30,33,34,43)

32KHz Clock.

ITE8512_XTAL2

Gur_0808: 0 ohm

A A

removal, delete R622

W2

W2

1 4

2 3

32.768KHZ

32.768KHZ

C788

C788
18P

18P

50

50

ITE8512_XTAL1

5

C789

C789
18P

18P

50

50

1 2

ITE8512IX Populate R735 0 ohms.
ITE8512JX Populate R735 to 0.1uF, & De-pop Cap 1uF.

KSO[0..16](37)

KSI[0..7](37)

T98 P ADT98 P AD

CLK_PCI_8512

D14 SDMK0340L-7-FD14 SDMK0340L-7-F

2 1

D13 SDMK0340L-7-FD13 SDMK0340L-7-F

2 1

D16 SDMK0340L-7-FD16 SDMK0340L-7-F

2 1

D15 SDMK0340L-7-FD15 SDMK0340L-7-F

2 1

WRST#
LCD_BAK#

SMBCLK0
SMBDAT0

SMBCLK1
SMBDAT1

SMBCLK2
SMBDAT2

RESET_OUT#

T161 PADT161 PAD

ITE8512_XTAL1

ITE8512_XTAL2

ITE8512IX_JX

L78 BLM18AG121SN1D

L78 BLM18AG121SN1D

603

603

C795

L79

L79

BLM18AG121SN1D

BLM18AG121SN1D

ITE8512IX_JX

C791

C791

0.1U

0.1U

10

10

C795

0.1U

0.1U

1 2

10

10

603

603

KSO16
KSO15
KSO14
KSO13
KSO12
KSO11
KSO10
KSO9
KSO8
KSO7
KSO6
KSO5
KSO4
KSO3
KSO2
KSO1
KSO0

KSI7
KSI6
KSI5
KSI4
KSI3
KSI2
KSI1
KSI0

4

U45

U45

57

KSO17/GPC5

56

KSO16/GPC3

55

KSO15

54

KSO14

53

KSO13

52

KSO12/SLCT

51

KSO11/ERR

46

KSO10/PE

45

KSO9/BUSY

44

KSO8/ACK

43

KSO7/PD7

42

KSO6/PD6

41

KSO5/PD5

40

KSO4/PD4

39

KSO3/PD3

38

KSO2/PD2

37

KSO1/PD1

36

KSO0/PD0

65

KSI7

64

KSI6

63

KSI5

62

KSI4

61

KSI3/SLIN

60

KSI2/INT

59

KSI1/AFD

58

KSI0/STB

22

LPCRST/WUI4/GPD2

13

LPCCLK

6

LFRAME

10

LAD0

9

LAD1

8

LAD2

7

LAD3

93

CLKRUN/GPH0/ID0

5

SERIRQ

15

ECSMI/GPD4

23

ECSCI/GPD3

126

GA20/GPB5

17

LPCPD/WUI6/GPE6

4

KBRST/GPB6

14

WRST

16

PWUREQ/GPC7

19

L80HLAT/GPE0

20

L80LLAT/WUI7/GPE7

110

SMCLK0/GPB3

111

SMDAT0/GPB4

115

SMCLK1/GPC1

116

SMDAT1/GPC2

117

SMCLK2/GPF6

118

SMDAT2/GPF7

85

PS2CLK0/GPF0

86

PS2DAT0/GPF1

87

PS2CLK1/GPF2

88

PS2DAT1/GPF3

89

PS2CLK2/GPF4

90

PS2DAT2/GPF5

128

CK32K

2

CK32KE

1

VSS1

12

VSS2

27

VSS3

49

VSS4

91

VSS5

113

VSS6

122

VSS7

74

AVCC

75

AVSS

4

ITE8512E

ITE8512E
LQFP-128L

LQFP-128L

KEYBOARD

KEYBOARD

LPC

LPC

SMBUS

SMBUS

PS/2

PS/2

3

ADC0/GPI0
ADC1/GPI1
ADC2/GPI2
ADC3/GPI3
ADC4/GPI4
ADC5/GPI5

ADC/DAC

ADC/DAC

PWM

PWM

IR/UART

IR/UART

LPC/FWH

LPC/FWH
FLASH

FLASH

EGPC

EGPC

GPIO

GPIO

RING/PWRFAIL/LPCRST/GPB7

ADC6/GPI6
ADC7/GPI7

DAC0/GPJ0
DAC1/GPJ1
DAC2/GPJ2
DAC3/GPJ3
DAC4/GPJ4
DAC5/GPJ5

PWM0/GPA0
PWM1/GPA1
PWM2/GPA2
PWM3/GPA3
PWM4/GPA4
PWM5/GPA5
PWM6/GPA6
PWM7/GPA7

TACH0/GPD6
TACH1/GPD7

TMRI0/WUI2/GPC4
TMRI1/WUI3/GPC6

RXD/GPB0

TXD/GPB1
CRX0/GPC0
CTX0/GPB2

CRX1/GPH1/ID1

CTX1/GPH2/ID2

FLFRAME/GPG2/LF

FLRST/GPG0/TM

FLAD3/GPG6

FLAD2/SO

FLAD0/SCE

EGAD/GPE1
EGCS/GPE2

EGCLK/GPE3

GPH3/ID3
GPH4/ID4
GPH5/ID5
GPH6/ID6
GPG1/ID7

RI1/WUI0/GPD0
RI2/WUI1/GPD1

WUI5/GPE5

PWRSW /GPE4

GINT/GPD5

IT8512E/JX-L

IT8512E/JX-L

LQFP128-16X16-4-FX2

LQFP128-16X16-4-FX2

3

VBAT1

VCC

VSTBY1
VSTBY2
VSTBY3
VSTBY4
VSTBY5
VSTBY6

FLAD1/SI

FLCLK

3
11

26
50
92
114
121
127

66
67
68
69
70
71
72
73

76
77
78
79
80
81

24
25
28
29
30
31
32
34

47
48

120
124

108
109
119
123
94
95

100
106
104

103
102
101
105

82
83
84

96
97
98
99
107

18
21
35

112

125

33

+3.3V_RUN

12

+3.3V_ALW

HWPG

LCD_CBL_DET#

INVERTER_CBL_DET#

SIO_SLP_S5#

USB_CHG_DET#

21

D31 SDMK0340L-7-FD31 SDMK0340L-7-F

BREATH_LED#

T158PAD T158PAD

BAT_LED#

Gur_0808: 0 ohm remo val, delete R629

R630 *0_NCR630 *0_NC

1 2

IMVP_VR_ON

SUS_ON

T159PAD T159PAD

T160PAD T160PAD

USB_L_SIDE_EN#
BID0
BID1
BID2

C803

C803

R649

R649

0.1U

0.1U

1 2

*0_NC

*0_NC

10

10

HWPG (45)

IMVP6_PROCHOT# (51)

KB_DET# (37)
LCD_CBL_DET# (26)
INVERTER_CBL_DET# (26)
PBAT_PRES# (54)

IINP (47)

SIO_SLP_S5# (13)

USB_CHG_DET# (35)

SIO_EXT_WAKE# (13)
LAN_DISABLE (43)

EXPRCRD_PWREN# (30)

ICH_RSMRST# (13)
SIO_PWRBTN# (13)

BREATH_LED# (38)

FAN1_PWM (39)
PWM_VADJ (26)
BAT_LED# (38)
KB_BACKLITE_EN (37)
CAP_LED# (37)

BEEP (40)

FAN1_TACH (39)

ATI_PANEL_BKEN (19)

LID_SW# (37,38)
MEDIA_INT# (37)

AUDIO_AVDD_ON (41)

AUX_EN_WOWL (33)

CIRRX (32)

RUN_ON_1 (45)
HDDC_EN (36)
IMVP_VR_ON (51)

SUS_ON (49,53,55)

ICH_CL_PWROK (6,13)

EC_FLASH_SPI_DO (32)
EC_FLASH_SPI_DIN (32)
EC_FLASH_SPI_CS# (32)
EC_FLASH_SPI_CLK (32)

PS_ID (54)

5V_ALW_ON (50)

USB_L_SIDE_EN# (35)

MODC_EN (36)

SIO_SLP_S3# (13)
ACAV_IN (47)
MMB_ISSP# (37)

USB_SIN_SIDE_EN# (35)

MAIN_PWR_SW# (37)

LCDVCC_TST_EN (26)

2

Gur_0808: 0 ohm
removal, delete R650

2

1

SMBDAT0
SMBCLK0

SMBDAT1
SMBCLK1

SMBDAT2
SMBCLK2

SIO_SLP_S5#

LCD_CBL_DET#
INVERTER_CBL_DET#
USB_CHG_DET#

BREATH_LED#

BAT_LED#

IMVP_VR_ON

SUS_ON

HWPG

LCD_BAK#

R624 *10K_NCR624 *10K_NC

Gur_0808: depop R636 & R637 and pop R634
& R640 for BID update from 1001 to 1010

Board ID Straps

Discrete

12

12

R644

R644

R631

R631

10K

10K

*10K_NC

*10K_NC

R646

R646

R633

R633

*10K_NC

*10K_NC

10K

10K

1 2

1 2

2

1

4

3

2

1

4

3

2

1

4

3

R635 *100K_NCR635 *100K_NC

R641 100KR641 100K
R638 100KR638 100K
R643 100KR643 100K

R627 100KR627 100K

1 2

R626 100KR626 100K

1 2

R639 *100K_NCR639 *100K_NC

R632 100KR632 100K

R702 100KR702 100K

+3.3V_ALW

12

R637

R637

R634

R634

*10K_NC

*10K_NC

10K

10K

1 2

R636

R636

R640

R640

*10K_NC

*10K_NC

10K

10K

1 2

1 2

BID0
BID1
BID2
USB_L_SIDE_EN#

RP24

RP24

2.2KX2

2.2KX2

RP23

RP23
10KX2

10KX2

RP22

RP22
10KX2

10KX2

12

12

12
12
12

12

12

12

+3.3V_ALW+RTC_CELL

+3.3V_ALW

+3.3V_ALW

+3.3V_RUN

UMA

VGA_IDENTIFY (USB_L_SIDE_EN#)
1 = Discrete Gfx. ; 0 = U MA.

BID2 BID1

0

0

0

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

COMPUTER

SIO (ITE8512)

SIO (ITE8512)

SIO (ITE8512)

RM2 3A

RM2 3A

RM2 3A

010

0

1

BID0 RM2

PT (X00/X01) & PT2 (X02)0

ST (X03) & ST2(X04)

0

QT (A00)1

1

(A01)

1

of

of

of

31 59Friday, August 08, 2008

31 59Friday, August 08, 2008

31 59Friday, August 08, 2008

5

http://hobi-elektronika.net

4

3

16Mbit (2M Byte), SPI RTC BATTERY

+RTC_CELL

2

+PWR_SRC+3.3V_ALW

1

+3.3V_ALW+3.3V_ALW

12

C515

C515
22P/50V

22P/50V

12

R380

R380
10K

10K

1
6
5
2

3

SST25VF016B-50-4C-S2AF

SST25VF016B-50-4C-S2AF

U19

U19

CE#
SCK
SI
SO

WP#

VDD

HOLD#

VSS

12

R378

R378
10K

12

C514

C514

0.1U/10V

0.1U/10V

10K

C473

C473
1U/10V

1U/10V

CC0603

CC0603

1 2

8

7

4

D D

EC_FLASH_SPI_CS#(31)
EC_FLASH_SPI_CLK(31)
EC_FLASH_SPI_DIN(31)
EC_FLASH_SPI_DO(31)

R379 15R379 15

1 2

R381 15R381 15

1 2

R377 15R377 15

1 2

Consumer IR

C C

CIRRX(31)

21

D12

D12
SDMK0340L-7-F

SDMK0340L-7-F

21

D11

D11
SDMK0340L-7-F

SDMK0340L-7-F

12

R696

R696
100

100

12

C861

C861

4.7U/10V

4.7U/10V

CC0805

CC0805

12

C477

C477

2.2U/6.3V

2.2U/6.3V

CC0603

CC0603

+RTC_1 +RTC

1 2

R340 1KR340 1K

+3.3V_ALW+3.3V_ALW

R697

R697
10K

10K

1 2

12

C862

C862

0.1U/10V

0.1U/10V

CC0402

CC0402

U18

U18

3

OUT

4

5/3#

GND2SHDN

*MAX1615EUK-T+_NC

*MAX1615EUK-T+_NC

U20

U20

4

IRTX

3

VCC

2

GND1

1

GND2

IR-TSOP36136TR-4P

IR-TSOP36136TR-4P

IN

1

5

BT1

BT1

1
2

MLX_53398-0271

MLX_53398-0271

53261-0210-2P-L

53261-0210-2P-L

12

C481

C481
*1U/25V_NC

*1U/25V_NC

CC0805

CC0805

B B

A A

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

FLASH/ RTC/ CIR

FLASH/ RTC/ CIR

FLASH/ RTC/ CIR

RM2 2A

RM2 2A

RM2 2A

1

of

of

of

32 59Tuesday, July 15, 2008

32 59Tuesday, July 15, 2008

32 59Tuesday, July 15, 2008

5

4

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

3

2

Date: Sheet

1

http://hobi-elektronika.net

2

3

4

5

6

7

8

A A

Mini Card Nut

H16

H16
Mini Card Align ( h3.2)

Mini Card Align ( h3.2)

H17

H17
Mini Card Nut (h3.2)

Mini Card Nut (h3.2)

MiniCard WLAN Connector

1

COEX2_WLAN_ACTIVE(34)
COEX1_BT_ACTIVE_MINI(34)

12

C785

C785
220P/50V

220P/50V

B B

PCIE_MCARD1_DET#(13)

C C

PCIE_WAKE#(13,30,34,43)

MINI1CLK_REQ#(17)

CLK_PCIE_MINI1#(17)
CLK_PCIE_MINI1(17)

+PWR_SRC

1

PCI-Express TX and RX
direct to connector

PCIE_RX2-(12)
PCIE_RX2+(12)

PCIE_TX2-(12)
PCIE_TX2+(12)

12

12

R587

R587
*100K_NC

*100K_NC

Gur_0808: 0 ohm remo val,
delete R618, R621

MINI1CLK_REQ#MINI1CLK_REQ#

R596

R596
*100K_NC

*100K_NC

+3.3V_ALW

Q74

Q74
*FDC655BN_NC

*FDC655BN_NC

6
5
2
1

3

+3.3V_WLAN

4

CN28

CN28

1

WAKE#

3

RESERVED_1

5

RESERVED_2

7

CLKREQ#

9

GND1

11

REFCLK-

13

REFCLK+

15

GND2

17

UIM_C8

19

UIM_C4

21

GND4

23

PERn0

25

PERp0

27

GND6

29

GND7

31

PETn0

33

PETp0

35

GND9

37

RESERVED_3

39

RESERVED_4

41

RESERVED_5

43

RESERVED_6

45

RESERVED_7

47

RESERVED_8

49

RESERVED_9

51

RESERVED_10

TYC_1775838-1

TYC_1775838-1

MIPCIEXP-1775838-1-52P

MIPCIEXP-1775838-1-52P

+3.3V_RUN

R607

R607
0/0805

0/0805

RC0805

RC0805

1 2

3.3V_1
GND0

1.5V_1

UIM_PWR

UIM_DATA

UIM_CLK

UIM_RESET

UIM_VPP

GND3

W_DISABLE#

PERST#

3.3VAUX1
GND5

1.5V_2

SMB_CLK

SMB_DATA

GND8

USB_D-

USB_D+

GND10

LED_WW AN#

LED_WLAN#
LED_WPAN#

1.5V_3

GND11

3.3V_2

+1.5V_RUN

12

2
4
6
8
10
12
14
16

18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52

C777

C777

0.047U/10V

0.047U/10V

+3.3V_WLAN+3.3V_WLAN

+1.5V_RUN

R610 0R610 0

1 2

WLAN_ RADIO_OFF#

R609 *0_NCR609 *0_NC

1 2

WLAN_SMBCLK
WLAN_SMBDATA

USB4_D­USB4_D+

PLTRST# (6,12,30,31,34,43)

SB_WLAN_PCIE_RST# (12)

+3.3V_WLAN

USB_MCARD1_DET# (13)

T156PAD T156PAD

LED_WLAN_OUT# (38)

T157PAD T157PAD

Place caps close to connector.

12

C773

C773

0.047U/10V

0.047U/10V

Reserved PAD for EMI

USB4_D­USB4_D+

RP21

RP21

2.2KX2

2.2KX2

WLAN_SMBCLK

WLAN_SMBDATA

*DLW21SN900SQ2B_NC

*DLW21SN900SQ2B_NC

R611 0R611 0

R612 0R612 0

+3.3V_WLAN

2

4

1

3

R608 *0_NCR608 *0_NC

+3.3V_WLAN

R606 *0_NCR606 *0_NC

Suport for WoW

WLAN_ RADIO_OFF#

L77

L77

1 2

1 2

1 2

Q75

Q75

2

*2N7002W-7-F_NC

*2N7002W-7-F_NC

31

1 2

Q73

Q73

2

*2N7002W-7-F_NC

*2N7002W-7-F_NC

31

1 2

D30

D30
SDMK0340L-7-F

SDMK0340L-7-F

2 1

R614

R614
*0_NC

*0_NC

1 2

34

Prevent backdrive when
WoW is enabled.

ICH_USBP4- (12)
ICH_USBP4+ (12)

ICH_SMBCLK (13,30,34)

ICH_SMBDATA (13,30,34)

WLAN_RADIO_DIS# (13)

Q71B

Q71B

*2N7002DW-7-F_NC

*2N7002DW-7-F_NC

AUX_EN_W OWL(31)

D D

1

12

R598

R598
*100K_NC

*100K_NC

61

2

12

R588

R588

*200K_NC

*200K_NC

2

5

34

Q71A

Q71A
*2N7002DW-7-F_NC

*2N7002DW-7-F_NC

12

R600

R600
*470K_NC

*470K_NC

3

12

C770

C770
*4700P/50V_NC

*4700P/50V_NC

+3.3V_WLAN

4

12

C507

C507

0.1U/10V

0.1U/10V

12

C508

C508

0.047U/10V

0.047U/10V

12

5

C775

C775

0.1U/10V

0.1U/10V

12

C776

C776

0.047U/10V

0.047U/10V

1 2

C774

C774

4.7U/10V

4.7U/10V

CC0805

CC0805

6

12

+

+

C763

C763
*330U/6.3V_NC

*330U/6.3V_NC

CC7343

CC7343

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

COMPUTER

MINI-CARD (WLAN)

MINI-CARD (WLAN)

MINI-CARD (WLAN)

RM2 3A

RM2 3A

RM2 3A

7

of

of

of

33 59Friday, August 08, 2008

33 59Friday, August 08, 2008

33 59Friday, August 08, 2008

8

1

http://hobi-elektronika.net

2

3

4

5

6

7

8

Mini Card Nut

H24

H24
Mini Card Align ( h3.2)

Mini Card Align ( h3.2)

A A

B B

1

H25

H25
Mini Card Nut (h3.2)

Mini Card Nut (h3.2)

1

PCIE_WAKE#(13,30,33,43)
COEX2_WLAN_ACTIVE(33)
COEX1_BT_ACTIVE_MINI(33)

PCIE_MCARD3_DET#(13)

PCI-Express TX and RX
direct to connector

12

C846

C846
*33P/50V_NC

*33P/50V_NC

T165 PADT165 PAD

CLK_PCIE_MINI3#(17)
CLK_PCIE_MINI3(17)

PLTRST#(6,12,30,31,33,43)
CLK_LPC_DEBUG(17)

PCIE_RX3-(12)
PCIE_RX3+(12)

PCIE_TX3-(12) ICH_SMBDATA (13,30,33)
PCIE_TX3+(12)

COEX2_WLAN_ACTIVE

R689

R689
*100K_NC

*100K_NC

1 2

Gur_0808: 0 ohm remo val,

PCIE_WAKE#
COEX2_WLAN_ACTIVE

PLTRST#

delete R686, R687

Gur_0808: 0 ohm
removal, delete R691

MiniCard Robson, BT. UWB Connector

+1.5V_RUN

3.3V_1
GND0

1.5V_1

GND3

GND5

1.5V_2

GND8

GND10

1.5V_3

GND11

3.3V_2

2
4
6
8
10
12
14
16

18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52

+3.3V_RUN

+3.3V_RUN

CN31

CN31

1

WAKE#

3

RESERVED_1

5

RESERVED_2

7

CLKREQ#

9

GND1

11

REFCLK-

13

REFCLK+

15

GND2

17

UIM_C8

19

UIM_C4

21

GND4

23

PERn0

25

PERp0

27

GND6

29

GND7

31

PETn0

33

PETp0

35

GND9

37

RESERVED_3

39

RESERVED_4

41

RESERVED_5

43

RESERVED_6

45

RESERVED_7

47

RESERVED_8

49

RESERVED_9

51

RESERVED_10

TYC_1775838-1

TYC_1775838-1

MIPCIEXP-1775838-1-52P

MIPCIEXP-1775838-1-52P

UIM_PWR

UIM_DATA

UIM_CLK

UIM_RESET

UIM_VPP

W_DISABLE#

PERST#

3.3VAUX1

SMB_CLK

SMB_DATA

USB_D-

USB_D+

LED_WW AN#

LED_WLAN#

LED_WPAN#

Gur_0808: 0 ohm remo val, delete
R665, R666, R667, R668, R669

R670 0R670 0

1 2

R671 *0_NCR671 *0_NC

1 2

ICH_SMBCLK
ICH_SMBDATA

USB6_D­USB6_D+

Gur_0808: 0 ohm
removal, delete R675

PLTRST#

LPC_LFRAME# (11,31)
LPC_LAD3 (11,31)
LPC_LAD2 (11,31)
LPC_LAD1 (11,31)
LPC_LAD0 (11,31)

WPAN_RADIO_DIS_MINI# (13)

SB_WPAN_PCIE_RST# (12)

+3.3V_RUN

ICH_SMBCLK (13,30,33)

USB_MCARD3_DET# (13)

LED_WPAN_OUT# (38)

Mini Card Nut

H13

H12

H12
Mini Card Align ( h3.2)

1 2

1 2

12

Mini Card Align ( h3.2)

1

C697

C697
33P/50V

33P/50V

MiniCard WWAN Connector

+1.5V_RUN

3.3V_1
GND0

1.5V_1

GND3

GND5

1.5V_2

GND8

GND10

1.5V_3

GND11

3.3V_2

+3.3V_RUN

2
4
6
8
10
12
14
16

18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52

ESD3

ESD3

1

1

2

2
334

RCLAMP0504S.TCT

RCLAMP0504S.TCT

6

6

5

5

4

UIM_PWR
UIM_DATA
UIM_CLK
UIM_RESET
UIM_VPP

R529 0R529 0

R530 *0_NCR530 *0_NC

ICH_SMBCLK
ICH_SMBDATA

USB5_D­USB5_D+

UIM_VPP
UIM_PWR
UIM_DATA

+3.3V_RUN

CN25

11
13
15

17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
51

UIM_CLK

UIM_RESET

1
3
5
7
9

CN25

WAKE#
RESERVED_1
RESERVED_2
CLKREQ#
GND1
REFCLK­REFCLK+
GND2

UIM_C8
UIM_C4
GND4
PERn0
PERp0
GND6
GND7
PETn0
PETp0
GND9
RESERVED_3
RESERVED_4
RESERVED_5
RESERVED_6
RESERVED_7
RESERVED_8
RESERVED_9
RESERVED_10

TYC_1775838-1

TYC_1775838-1

MIPCIEXP-1775838-1-52P

MIPCIEXP-1775838-1-52P

UIM_PWR

UIM_DATA

UIM_CLK

UIM_RESET

UIM_VPP

W_DISABLE#

PERST#

3.3VAUX1

SMB_CLK

SMB_DATA

USB_D-

USB_D+

LED_WW AN#

LED_WLAN#

LED_WPAN#

layout note:10 mi l trace and 20 mil space fo r SIM card and UIM_PW R use 20mil

12

12

C701

C701
33P/50V

33P/50V

C700

C700
33P/50V

33P/50V

GND

VPP

DATA

PCIE_WAKE#

5

6

UIM_DATA

7

8

T155 PADT155 PAD
T153 PADT153 PAD
T154 PADT154 PAD

C C

D D

CLK_PCIE_MINI2#(17)
CLK_PCIE_MINI2(17)

PCIE_RX1-(12)
PCIE_RX1+(12)

PCIE_TX1-(12)

PCIE_MCARD2_DET#(13)

UIM_PWR

UIM_RESET UIM_VPP

UIM_CLK

PCIE_TX1+(12)

CN26

CN26

1

VCC

2

RST

3

CLK

Case_GND4Case_GND

YMI_10124-00001

YMI_10124-00001

H13
Mini Card Nut (h3.2)

Mini Card Nut (h3.2)

PLTRST#

WWAN_RADIO_DIS# (13)
SB_WWAN_PCIE_RST# (12)

+3.3V_RUN

USB_MCARD2_DET# (13)
LED_WWAN_OUT# (38)

UIM_PWR

12

C685

C685
33P/50V

33P/50V

1

12

C432

C432
1U/10V

1U/10V

CC0603

CC0603

Place as close as possible to JMINI connector

1

2

3

4

5

6

USB6_D­USB6_D+

Layout Note:
R240 and R244 close to choke as possible to minimize stubs.

+1.5V_RUN

12

C830

C830

0.047U/10V

0.047U/10V

+3.3V_RUN

12

C831

C831

0.1U/10V

0.1U/10V

12

C829

C829

0.1U/10V

0.1U/10V

Reserve For EMI

USB5_D­USB5_D+

Layout Note:
R240 and R244 close to choke as possible to minimize stubs.

+1.5V_RUN

12

C696

C696

0.047U/10V

0.047U/10V

+3.3V_RUN

12

C698

C698
33P/50V

33P/50V

12

12

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

Reserve For EMI

L81

L81

1 2

1 2
1 2

34

*DLW21SN900SQ2B_NC

*DLW21SN900SQ2B_NC

R673 0R673 0
R674 0R674 0

ICH_USBP6- (12)
ICH_USBP6+ (12)

Place caps close to connector.

12

C828

C828

0.047U/10V

0.047U/10V

12

C845

C845

0.047U/10V

0.047U/10V

12

C843

C843

0.047U/10V

0.047U/10V

L72

L72

1 2

1 2
1 2

34

*DLW21SN900SQ2B_NC

*DLW21SN900SQ2B_NC

R531 0R531 0
R532 0R532 0

12

C827

C827

4.7U/6.3V

4.7U/6.3V

CC0603

CC0603

12

+

+

C844

C844
*330U/6.3V_NC

*330U/6.3V_NC

CC7343

CC7343

ICH_USBP5- (12)
ICH_USBP5+ (12)

Place caps close to connector.

C699

C699
33P/50V

33P/50V

12

C729

C695

C695

0.047U/10V

0.047U/10V

MINI-CARD (WPAN,WWAN)

MINI-CARD (WPAN,WWAN)

MINI-CARD (WPAN,WWAN)

RM2 3A

RM2 3A

RM2 3A

C729
33P/50V

33P/50V

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

7

12

C730

C730

0.047U/10V

0.047U/10V

+

+

34 59Friday, August 08, 2008

34 59Friday, August 08, 2008

34 59Friday, August 08, 2008

12

C388

C388
330U/6.3V

330U/6.3V

CC7343

CC7343

8

of

of

of

1

http://hobi-elektronika.net

2

3

4

5

6

7

8

eSATA Re-driver IC

+1.8V_RUN

C720

C720

C479

0.1U/ 10V

0.1U/ 10V

SATA_TX5+_C
SATA_TX5-_C

SATA_RX5+

C479

0.1U/ 10V

0.1U/ 10V

C303 0.01U/16VC303 0.01U/16V

1 2
1 2

C312 0.01U/16VC312 0.01U/16V
C475 0.01U/16VC475 0.01U/16V

1 2
1 2

C476 0.01U/16VC476 0.01U/16V

C504

C504

0.1U/ 10V

0.1U/ 10V

+1.8V_RUN +1.8V_RUN

U42

12

12

U42

1

EQA

2

VDD

3

AI+

4

AI-

5

GND

6

VDD

7

BO+

8

BO-

9

GND

10

EQB

PI2EQX3211BHE

PI2EQX3211BHE

VDD

GND
VDD

GND
VDD

20

EN

19
18

AO+

17

AO-

16
15
14

BI+

13

BI-

12
11

R601 0R601 0

SATA_TX5+
SATA_TX5-

SATA_RX5+_C
SATA_RX5-_CSATA_RX5-

R613 0R613 0

Close IC, no stub at

12

high-speed trace on
PCB layout.

R360

R360
499/F

499/F

eSATA_TX5+_R
eSATA_TX5-_R

eSATA_RX5+
eSATA_RX5-

C498 0.01U/16VC498 0.01U/16V

eSATA_TX5+

1 2

eSATA_TX5-

1 2

C497 0.01U/16VC497 0.01U/16V

USB POWER SW

Place one 150uF cap by
each USB connector.

USB_SIN_SIDE_EN#(31)

C734

C734

0.1U/ 10V

0.1U/ 10V

A A

SATA_TX5+_C(11)

SATA_TX5-_C(11)

SATA_RX5+(11)

SATA_RX5-(11)

B B

USB BUS SW

C520

C520

0.1U/10V

0.1U/10V

ICH_USBP8+(12)

ICH_USBP8-(12)

+5V_ALW

U15

U15

2

IN

3

EN1#

4

EN2#

12

TPS2062DR

TPS2062DR

C441

C441

0.1U/50V

0.1U/50V

CC0603

CC0603

+3.3V_SUS

12

OUT1
OC1#

OUT2
OC2#

GND

U17

U17

7

COM1

V+

COM2

6

NO1

5

NO2

SHND

8

GND

IN

MAX4907ELA+

MAX4907ELA+

+USB_RIGHT_PWR

1

7
8

6
5

USB8_D+

3

USB8_D-

4

1

2

Each channel is 1A

USB_OC8# (12)

eSATA CONN

+USB_RIGHT_PWR

12

C505

C505

0.1U/10V

0.1U/10V

USB_CHG_DET#(31)

USB8_D­USB8_D+

eSATA_RX5+
eSATA_RX5-

eSATA_TX5­eSATA_TX5+

CN27

CN27

1
2
3
4
5
6
7
8

9
10
11
12
13
14
15
16
17
18
19
20

TYC_2006114-1

TYC_2006114-1

2006114-1-20P-L

2006114-1-20P-L

USB POWER SW

GND

OUT1
OC1#

OUT2
OC2#

+USB_LEFT_PWR

1

7
8

6
5

+5V_ALW

U29

U29

2

IN

USB_L_SIDE_EN#(31)

C C

C603

C603

0.1U/50V

0.1U/50V

CC0603

CC0603

3

EN1#

4

EN2#

12

TPS2062DR

TPS2062DR

Each channel is 1A

USB_OC0_1# (12)

TV module

ICH_USBP9-(12)
ICH_USBP9+(12)

L68

L68

34

1 2

*PLW3216S900SQ2T1_NC

*PLW3216S900SQ2T1_NC

R439 0R439 0

1 2

R438 0R438 0

1 2

ESD2

ESD2

1
2

6

1

6

5

2

5

4

334

*RCLAMP0504S.TCT_NC

*RCLAMP0504S.TCT_NC

USB9_D­USB9_D+

12

C581

C581
10U/10V

10U/10V

CC0805

CC0805

USB9_D-USB9_D+

+5V_RUN

Gur_0808: no inside
TV antenna, delete
signal TV_GPIO1 & 2

0.1U/10V

0.1U/10V

C583

C583

USB9_D+
USB9_D-

+5V_RUN

12

CN20

CN20

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

9

9

11

10

10

12

IPX_20374-010E-31

IPX_20374-010E-31

20374-010E-10P-L

20374-010E-10P-L

11
12

TV RF Jack & Microwave connector

CN16

CN16
MLX_733660490

MLX_733660490

mcx-73366-049-5p

mcx-73366-049-5p

Gur_0814: change P/N & footprint
& library for non-switch RF Jack

D D

1

2

3

4

1

1

2233445

5

RF_GND

CN1

CN1

3

2

RF_GND

TYC_1909763-1

TYC_1909763-1

1

MINIRF-1909763-1-3P

MINIRF-1909763-1-3P

5

R715 0R715 0

1 2

R716 0R716 0

1 2

R717 0R717 0

1 2

R718 0R718 0

1 2

6

RF_GND

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

COMPUTER

USB & eSATA & TV

USB & eSATA & TV

USB & eSATA & TV

RM2 3A

RM2 3A

RM2 3A

7

of

of

of

35 59Thursday, August 14, 2008

35 59Thursday, August 14, 2008

35 59Thursday, August 14, 2008

8

1

http://hobi-elektronika.net

SATA Connector

A A

+3.3V_RUN +5V_MOD

B B

+5V_HDD

C C

HDDC_EN(31)

D D

21
22
23
24

12

C133

C133
*10U/10V_NC

*10U/10V_NC

CC0805

CC0805

12

C134

C134
10U/10V

10U/10V

CC0805

CC0805

Place caps close to
connector.

12

R454

R454
100K

100K

1

CN21

CN21

GND1

RXP
RXN

GND2

TXN
TXP

GND3

3.3V_0

3.3V_1

3.3V_2
GND4
GND5
GND6

5V_0
5V_1
5V_2

GND9

GND7

GND10

GND8
12V_0

GND11

12V_1

GND12

FOX_GS12201-1011-9F

FOX_GS12201-1011-9F

2006114-1-20P-L

2006114-1-20P-L

12

C132

C132
*1U/10V_NC

*1U/10V_NC

CC0603

CC0603

12

C135

C135
1U/10V

1U/10V

CC0603

CC0603

+3.3V_ALW

12

R453

R453
100K

100K

34

5

Q61A

Q61A
2N7002DW-7-F

2N7002DW-7-F

12

C119

C119
*0.1U/16V_NC

*0.1U/16V_NC

CC0402

CC0402

12

C122

C122

0.1U/16V

0.1U/16V

CC0402

CC0402

+15V_ALW

1
2
3
4
5
6
7

8
9
10
11
12
13
14
15
16
17
18
19
20

+5V_ALW

1 2

R452

R452
100K

100K

SATA_TX0+
SATA_TX0-

SATA_RXN0_C
SATA_RXP0_C

12

C123

C123
*0.1U/16V_NC

*0.1U/16V_NC

CC0402

CC0402

12

C121

C121

0.1U/16V

0.1U/16V

CC0402

CC0402

Q65

Q65
FDC655BN

FDC655BN

6
524

1

3

61

2

2

+3.3V_RUN

+5V_HDD

HDD_EN_5V

Q61B

Q61B
2N7002DW-7-F

2N7002DW-7-F

2

C268 0.01U/16VC268 0.01U/16V

12

C272 0.01U/16VC272 0.01U/16V

12

C600 0.01U/25VC600 0.01U/25V

1 2

C601 0.01U/25VC601 0.01U/25V

1 2

12

C120

C120
*0.1U/16V_NC

*0.1U/16V_NC

CC0402

CC0402

12

C125

C125

0.1U/16V

0.1U/16V

CC0402

CC0402

+5V_HDD

12

C602

C602

4.7U/6.3V

4.7U/6.3V

CC0603

CC0603

12

C598

C598

0.1U/25V

0.1U/25V

CC0603

CC0603

12

C124

C124
*1000P/50V_NC

*1000P/50V_NC

CC0402

CC0402

12

C126

C126
1000P/50V

1000P/50V

CC0402

CC0402

12

R456

R456
100K

100K

SATA_TX0+_C (11)
SATA_TX0-_C (11)

SATA_RX0- (11)
SATA_RX0+ (11)

3

ODD Connector

MODC_EN(31)

3

12

C511

C511
*10U/10V_NC

*10U/10V_NC

CC0805

CC0805

Place caps close to
connector.

12

R367

R367
100K

100K

4

CN30

CN30

1

GND1

2

RXP

3

RXN

4

GND2

5

TXN

6

TXP

7

GND3

8

DP

9

5V_0

10

5V_1

MD

14

GND

15

GND

16

YMI_10120-00001

YMI_10120-00001

SATA-47645-2000-13P-L-H

SATA-47645-2000-13P-L-H

12

C510

C510
1U/10V

1U/10V

CC0603

CC0603

12

R364

R364
100K

100K

34

Q40A

Q40A
2N7002DW-7-F

2N7002DW-7-F

11
12
13

C783

C783

0.1U/16V

0.1U/16V

CC0402

CC0402

+15V_ALW

4

+5V_ALW

14
15
16

Gur_0808: change CN29 from
DFHD05MS095 to DFHD05MS017

12

+3.3V_ALW

5

SATA_TX1+
SATA_TX1-

SATA_RXN1_C
SATA_RXP1_C

12

C509

C509

0.1U/16V

0.1U/16V

CC0402

CC0402

R372

R372
100K

100K

1 2

+5V_MOD

Q76

Q76
SI4800BDY-T1-E3

SI4800BDY-T1-E3

8
762

5

4

61

2

C279 0.01U/16VC279 0.01U/16V

12

C284 0.01U/16VC284 0.01U/16V

12

C513 0.01U/25VC513 0.01U/25V

1 2

C512 0.01U/25VC512 0.01U/25V

1 2

12

C781

C781
1000P/50V

1000P/50V

CC0402

CC0402

+5V_MOD

3

1

MOD_EN_5V

Q40B

Q40B
2N7002DW-7-F

2N7002DW-7-F

12

12

C784

C784
10U/10V

10U/10V

CC0805

CC0805

C506

C506

0.1U/25V

0.1U/25V

CC0603

CC0603

5

SATA_TX1+_C (11)
SATA_TX1-_C (11)

SATA_RX1- (11)
SATA_RX1+ (11)

12

R375

R375
100K

100K

5

6

6

7

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

Title

Title

Title

HDD & ODD (SATA)

HDD & ODD (SATA)

HDD & ODD (SATA)

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

RM2 3A

RM2 3A

RM2 3A

Date: Sheet of

Date: Sheet of

7

Date: Sheet of

8

36 59Friday, August 08, 2008

36 59Friday, August 08, 2008

36 59Friday, August 08, 2008

8

1

http://hobi-elektronika.net

2

3

4

5

6

7

8

To Daughter Boar d connector

Solid White = System On, Normal Activity
Off= System off (system off or hibernate);
"Breathing White " = System in Standby (S3);

Power Button

A A

Speaker

Gur_0814: change
R722 to connect to
R721 from pin1 to pin2

KB LED

Touch Pad

Media Button

B B

MMB_ISSP#(31)

BREATH_PWRLED_INT(38)

LID_SW#(31,38)

R602 *0/ 0603_NCR602 *0/0603_NC

1 2

Q70 SI2303BDS-T1-E3Q70 SI2303BDS-T1-E3

1

12

R603

R603
100K

100K

AUD_SPK_L1(41)
AUD_SPK_L2(41)

KB_BACKLITE_EN(31)

LID_SW#

2

AUD_SPK_R1(41)
AUD_SPK_R2(41)

KB_LED_DET(13)

DAT_TP_SIO(31)

CLK_TP_SIO(31)

MEDIA_INT#(31)

+3.3V_ALW

SMBDAT2(31)

+5V_ALW

+MMB_PWR

SMBCLK2(31)

3

2

+5V_RUN

31

Q86

Q86
2N7002W-7-F

2N7002W-7-F

R722 200K/FR 722 200K/F

R721 100KR721 100K

R725 *0_NCR725 *0_NC

+MMB_PWR+5V_ALW2

POWER _ SW_I N0#

12
12

1 2

MEDIA_INT#

"MEDIA_INT#"
PU at MB side

FOX_GB5RF321-1203-7F

FOX_GB5RF321-1203-7F

gb5rf341-1203-7f-32p-l

gb5rf341-1203-7f-32p-l

+3.3V_ALW

MEDIA_INT#

CN8

CN8

1
2
3
4
5
6
7
8

9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32

12

Array Microphone & C amera

12

R615

R615
100K

RC0603

RC0603

RC0603

RC0603

12

C484

C484
*27P/50V_NC

*27P/50V_NC

100K

+3.6V_RUN+5V_RUN

R368 0R368 0

1 2

R369 0R369 0

1 2

L50

L50

*DLW21SN900SQ2B_NC

*DLW21SN900SQ2B_NC

ICH_USBP11+(12)
ICH_USBP11-(12)

DMIC_DATA(40)

DMIC_CLK(40)

CAMERA_CBL_DET#(13)

C C

12

C465

C465
*1U/10V_NC

*1U/10V_NC

CC0603

CC0603

DMIC_DATA

DMIC_CLK DMIC_CLK_R

12

C780

C780
*33P/50V_NC

*33P/50V_NC

U16

U16

5

IN1OUT

3

EN

2

GND

NC/FB

*TPS76301DBVR_NC

*TPS76301DBVR_NC

4

34

1 2

R617 0/0603

R617 0/0603

1 2

R616 22/0603

R616 22/0603

1 2

DMIC_DATA_RDMIC_CLK_R

12

C782

C782
*33P/50V_NC

*33P/50V_NC

12

R357

R357
*100K/F_NC

*100K/F_NC

12

R358

R358
*49.9K/F_NC

*49.9K/F_NC

R724

R724
100K

100K

12

12

12

C499

C499
*4.7U/6.3V_NC

*4.7U/6.3V_NC

CC0603

CC0603

L51

L51
BLM11A05S

BLM11A05S

RC0603

RC0603

C502

C502
10U/10V

10U/10V

CC0805

CC0805

Power Button

D35

D35
*DA204U_NC

*DA204U_NC

POWER _ SW_I N0#

+3.6V_RUN+3.3V_RUN+3.3V_RUN

12

L49

L49
*BLM11A05S_NC

*BLM11A05S_NC

RC0603

RC0603

USB11_D+
USB11_D­CAM_VCC

DMIC_DATA_R

+3.3V_ALW+3.3V_ALW

2

1

3

Hall Switch

12

R707

R707
100K

R709 10KR709 10K

1 2

C869 0.1U/10VC869 0.1U/10V

1 2

3

The GND (pin 8) for DMIC is defined as AGND.
Connect with GND at MB, but separate AGND
& GND at coaxial cable & CCD module.

100K

MAIN_PWR_SW# (31)

12

C863

C863
1U/10V

1U/10V

CC0603

CC0603

+3.3V_ALW

U54

U54

1

VDD

GND

R726 0R726 0

2

1 2

OUT

PT3661-BB

PT3661-BB

CN9

CN9

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

9

11

9

11

10

12

10

12

IPX_20374-010E-31

IPX_20374-010E-31

20374-010E-10P-L

20374-010E-10P-L

Gur_0808: no inside TV antenna,
change CN9 from 14 to 10 pins,
delete signal TV_GPIO1 & 2

LID_SW#

KEYBOARD CONNECTOR

KSI[0..7](31)

KSO[0..16](31)

R711 100KR711 100K

+3.3V_ALW

KB_DET#(31)

CAP_LED#(31)

KSI7
KSI6
KSI4
KSI2
KSI5
KSI1
KSI3
KSI0
KSO5
KSO4
KSO7
KSO6
KSO8
KSO3
KSO1
KSO2
KSO0
KSO12
KSO16
KSO15
KSO13
KSO14
KSO9
KSO11
KSO10
CAP_LED_L

+3.3V_ALW +5V_RUN+3.3V_ALW

12

R712

R712
100K

100K

CP2

CP2
*100PX4_NC

*100PX4_NC

KSI1

78

KSI3

5

6

KSI0

3

4

KSO5

1

2

50

50
NPO

NPO
1206

1206

CP4

CP4
*100PX4_NC

*100PX4_NC

KSO3

78

KSO1

5

6

KSO2

3

4

KSO0

1

2

50

50
NPO

NPO
1206

1206

CP6

CP6
*100PX4_NC

*100PX4_NC

KSO14 KSO12

78

KSO9 KSO16

5

6

KSO11

3

4

KSO10

1

2

50

50
NPO

NPO
1206

1206

C618

C618
*100P/50V_NC

*100P/50V_NC

KSI7

1 2

12

2

31

Q84

Q84
2N7002W-7-F

2N7002W-7-F

CN6

CN6

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30

13

47K

47K

2

10K

10K

CP1

CP1
*100PX4_NC

*100PX4_NC

6
4
2

50

50
NPO

NPO
1206

1206

CP3

CP3
*100PX4_NC

*100PX4_NC

6
4
2

50

50
NPO

NPO
1206

1206

CP5

CP5
*100PX4_NC

*100PX4_NC

6
4
2

50

50
NPO

NPO
1206

1206

100P CAPS close to KB connector

GND2 GND1

HRS_FH28-60(30)SB-1SH(86)

HRS_FH28-60(30)SB-1SH(86)

FH28-30SB-1SH-30P-R

FH28-30SB-1SH-30P-R

Q82

Q82
DDTA114YUA-7-F

DDTA114YUA-7-F

R708

R708

2.49K/F

2.49K/F

CAP_LED_L

1 2

KSI6

78

KSI4

5

KSI2

3

KSI5

1

KSO4

78

KSO7

5

KSO6

3

KSO8

1

78
5

KSO15

3

KSO13

1

D D

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

Title

Title

Title

KB/ CCD/ UI

KB/ CCD/ UI

KB/ CCD/ UI

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

RM2 3A

RM2 3A

RM2 3A

Date: Sheet

Date: Sheet

1

2

3

4

5

6

Date: Sheet

7

of

of

of

37 59Thursday, August 14, 2008

37 59Thursday, August 14, 2008

37 59Thursday, August 14, 2008

8

A

http://hobi-elektronika.net

Hinge & Power Button board LED (PWR/Battery indictor)

+5V_ALW2 +5V_ALW2+3.3V_ALW

12

4 4

BREATH_LED#(31)

LID_SW#(31,37)

3 3

BAT_LED#(31)

2 2

Q22

Q22

2N7002W-7-F

2N7002W-7-F

LID_SW#

2

+3.3V_ALW

12

2

+3.3V_ALW

5

2

3

31

R114

R114
100K

100K

31

Q19

Q19
2N7002W-7-F

2N7002W-7-F

4

U53

U53
TC7SZ04FU(T5L,F,T)

TC7SZ04FU(T5L,F,T)

R714

R714

5

100K

100K

2

+5V_SUS+5V_SUS

12

R113

R113
100K

100K

2

BAT_LED_EXT BAT_LED_EXT_R

4

U52

U52
TC7SZ04FU(T5L,F,T)

TC7SZ04FU(T5L,F,T)

3

5

4

U31

U31
TC7SZ04FU(T5L,F,T)

TC7SZ04FU(T5L,F,T)

3

R91 100R91 100

1 2

B

Hinge LED
Solid White= System On, Nor mal Activity
Solid White= Charging (system on);
Solid White= Charging (system off or hibernate and battery charge <90%);
Off= Charging (system off or hibernate and battery charge > 90%) ;
"Breathing White " = System in Standby (S3 );
Off = System Off (or in Hibernate);

BREATH_PWRLED_EXT BREATH_PWRLED_EXT_R

BREATH_PWRLED_INT_R

Hinge LED:
Flashing Amber = Low Battery (S0 and S3 and no AC) when battery c harge <10%
Flash rate = on 1/4 sec., off 3/4 sec.

R112 220R112 220

1 2

Power button board LE D:
Solid White = System On, Normal Activity
Off= System off (system off or hibernate);
"Breathing White " = System in Standby (S3 )

R127 1KR127 1K

1 2

BREATH_PWRLED_INT (37)

C

HDD Activity LED

LED_MASK#(31)

SATA_ACT#(11)

WLAN

LED_WLAN_OUT#(33)

BT / UWB LED

LED_WPAN_OUT#(34)

LED_MASK#

R85

R85
*0_NC

*0_NC

1 2

LED_MASK#

R105

R105
*0_NC

*0_NC

1 2

LED_MASK#

R92

R92
*0_NC

*0_NC

1 2

D

12

R89

R89
10K

10K

1 2

12

R111

R111

4.7K

4.7K

+3.3V_RUN +3.3V_RUN

12

R102

R102
100K

100K

R860R86
0

2

Q13

Q13
2N7002W-7-F

2N7002W-7-F

12

R1060R106
0

2

Q18

Q18
2N7002W-7-F

2N7002W-7-F

12

R970R97
0

2

Q15

Q15
2N7002W-7-F

2N7002W-7-F

E

+5V_RUN+3.3V_RUN +3.3V_RUN

47K

47K

2

31

10K

10K

+5V_RUN+3.3V_WLAN +3.3V_WLAN

47K

47K

2

31

10K

10K

+5V_RUN

47K

47K

2

31

10K

10K

Flicker with HDD activity.

13

Q12

Q12
DDTA114YU A-7-F

DDTA114YU A-7-F

HDD_LED_R

R90 2.49K/FR90 2.49K/F

1 2

Turns On when WiFi
radio is on.

13

Q17

Q17
DDTA114YU A-7-F

DDTA114YU A-7-F

WLAN_LED_R

R107 2.49K/FR107 2.49K/F

1 2

Turns On when
Bluetooth radio is on.

13

Q14

Q14
DDTA114YU A-7-F

DDTA114YU A-7-F

BT_LED_R

R101 2.49K/FR101 2.49K/F

1 2

HDD_LED (42)

WLAN_LED (42)

BT_LED (42)

+5V_RUN

R1210R121
0

13

47K

47K

31

2

10K

10K

WWAN_LED_R

Title

Title

Title

LED

LED

LED

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

RM2 3A

RM2 3A

RM2 3A

Date: Sheet

Date: Sheet

Date: Sheet

Turns On when
WWAN radio is on.

Q20

Q20
DDTA114YU A-7-F

DDTA114YU A-7-F

R119 2.49K/FR119 2.49K/F

1 2

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

WWAN_LED (42)

E

of

of

of

38 59Friday, August 08, 2008

38 59Friday, August 08, 2008

38 59Friday, August 08, 2008

R117

R117
*0_NC

*0_NC

1 2

+3.3V_RUN +3.3V_RUN

R123

R123
100K

100K

12

2

Q21

Q21
2N7002W-7-F

2N7002W-7-F

12

D

Hinge LED (PWR/Battery indictor)

WWAN

L-C filter (reser ve R-C) for EM I

Gur_0808: 0 ohm

1
2
3

1
2
3

12

removal, delete
R415, R417

12

C547

C547
2200P/50V

2200P/50V

A

Gur_0808: EMI solution , pop C547, C548, C786,
C787 with 2200p

Left side Right side

CN3

CN3

4

4

5

5

FOX_HS8803F

FOX_HS8803F

C548

C548

2200P/50V

2200P/50V

1 1

Solid White= System On, No rmal Activity
Solid White= Charging (system on);
Solid White= Charging (system off or hibernate and battery charg e <90%);
Off= Charging (system off o r hibernate and bat tery charge > 90%);
"Breathing White " = System in Standby (S3);
Off = System Of f (or in Hiber nate);

Flashing Amber = Low Battery (S0 and S3 and no AC) when battery charge <10%
Flash rate = on 1/4 sec., o ff 3/4 sec.

BREATH_PWRLED_EXT_R

BAT_LED_EXT_R

Gur_0808: 0 ohm
removal, delete
R619, R620

C786

C786

2200P/50V

2200P/50V

B

12

CN10

CN10

1
2
3

12

FOX_HS8803F

FOX_HS8803F

C787

C787
2200P/50V

2200P/50V

LED_MASK#

4

1

4

2

5

3

5

C

LED_WWAN_OUT#(34)

1

http://hobi-elektronika.net

Gur_0808: 0 ohm
removal, delete R50

2

+5V_RUN

12

C52

C52

2.2U/10V

2.2U/10V

CC0805

CC0805

3

4

5

6

7

8

A A

1

D8

D8

*DA204U_NC

*DA204U_NC

FAN1_PWM(31)

FAN1_TACH(31)

B B

C C

3

+5V_RUN+5V_RUN

2

12

R49

R49

4.7K

4.7K

Place these under CPU

Q54

Q54
MMST3904-7-F

MMST3904-7-F

H_THERMDA(3)

H_THERMDC(3)

2

1 3

D24

D24
*SSM34PT_NC

*SSM34PT_NC

2 1

FAN1_PWM

10/20mils

REM_DIODE1_P

12

C569

C569
*2200P/50V_NC

*2200P/50V_NC

REM_DIODE1_N

H_THERMDA

H_THERMDC

12

C51

C51

0.1U/10V

0.1U/10V

CN19

CN19

4

4

3

3

2

2

1

1

MLX_53398-0471

MLX_53398-0471

53398-0410-4P-R

53398-0410-4P-R

12

C579

C579
2200P/50V

2200P/50V

12

C580

C580
2200P/50V

2200P/50V

OTP 85 degree C

+3.3V_RUN

+3.3V_RUN

R98 10K/FR98 10K/F

1 2

R103 6.8K/FR103 6.8K/F

1 2

12

C578

C578

0.1U/10V

0.1U/10V

U28

U28

1

VDD

2

DP1

3

DN1

4

DP2

5

DN2

EMC1423-1-AIZL-TR

EMC1423-1-AIZL-TR

THERM_ALERT#_C

SYS_SHDN#

SCL

SDA

ALERT#

SYS_SHDN#

GND

+3.3V_RUN

12

R435

R435
10K

10K

THERM_SCL

THERM_SDA

+3.3V_RUN

10

9

8

7

6

Q58

Q58
2N7002W-7-F

2N7002W-7-F

THERM_ALERT#_C

SYS_SHDN#

+3.3V_RUN

12

R4371MR437
1M

31

2

12

C584

C584

0.1U/10V

0.1U/10V

+3.3V_RUN

12

R436

R436
10K

10K

+3.3V_RUN

Place close to IC

2

THERM_ALERT#

31

Q57

Q57
2N7002W-7-F

2N7002W-7-F

31

Q59

Q59
2N7002W-7-F

2N7002W-7-F

2

Q56

Q56
2N7002W-7-F

2N7002W-7-F

2

31

Q55

Q55

2

2N7002W-7-F

2N7002W-7-F

31

SMBCLK1 (17,26,31)

SMBDAT1 (17,26,31)

THERM_ALERT# (13)

THERM_STP# (31,50)

D D

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

FAN /THERMAL

FAN /THERMAL

FAN /THERMAL

RM2 3A

RM2 3A

RM2 3A

7

of

of

of

39 59Friday, August 08, 2008

39 59Friday, August 08, 2008

39 59Friday, August 08, 2008

8

1

2

3

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

4

5

6

Date: Sheet

1

http://hobi-elektronika.net

2

3

4

5

6

7

8

Layout Note:
Close to the Pin 34
of Codec

A A

2N7002W-7-F

2N7002W-7-F

SENSEB SENSEA

12

Q69

Q69

12

R597

R597
20K/F

20K/F

31

2

31

R585

R585

39.2K/F

39.2K/F

2

Q68

Q68
2N7002W-7-F

2N7002W-7-F

12

+VDDA +VDDA

R581

R581

5.1K/F

5.1K/F

1 2

C755

C755
1000P/50V

1000P/50V

MIC1_JD (42)HP2_JD(41,42) HP1_JD(41,42)

Layout Note:
Close to the Pin 13
of Codec

2

2N7002W-7-F

2N7002W-7-F

Q39

Q39

12

31

R289

R289

39.2K/F

39.2K/F

1 2

12

C413

C413
1000P/50V

1000P/50V

R285

R285

5.1K/F

5.1K/F

12

C768

C768
1U/10V

1U/10V

CC0603

CC0603

L41

L41

1 2

BLM21PG600SN1D

BLM21PG600SN1D

12

C431

C431
10U/10V

10U/10V

CC0805

CC0805

+5V_RUN+5V_SPK_AMP

FB_60ohm+-25%_100MHz
_3A_0.05ohm DC

Layout Note:
Place close to pin 8

AZALIA (HD) CODEC

+3.3V_RUN

B B

Gur_0808: 0 ohm
removal, delete R269

+3.3V_RUN

12

R536

R536
*10K_NC

*10K_NC

EAPD#

C C

D D

ICH_AZ_CODEC_BITCLK

12

R281

R281
*22_NC

*22_NC

12

C422

C422
*1P/50V_NC

*1P/50V_NC

DMIC_CLK

12

R552

R552
*22_NC

*22_NC

12

C707

C707
*1P/50V_NC

*1P/50V_NC

1

12

C409

C409
1U/10V

1U/10V

CC0603

CC0603

12

C408

C408
1U/10V

1U/10V

CC0603

CC0603

12

Depop these for 92HD73C

ICH_AZ_CODEC_BITCLK(11)

ICH_AZ_CODEC_SDIN0(11)

ICH_AZ_CODEC_SDOUT(11)

ICH_AZ_CODEC_SYNC(11)

ICH_AZ_CODEC_RST#(11,31)

Gur_0808: 0 ohm remo val, delete R539,
R541, R547, R548, R550, R551, R558, R559

2

C407

C407

0.1U/10V

0.1U/10V

R546 22R546 22

DMIC_CLK(37)

EAPD#(41)

DMIC_DATA(37)

R565 *100K_NCR565 *100K_NC

1 2

1 2

C725 *1000P/50V_NCC725 *1000P/50V_NC

ICH_AZ_CODEC_BITCLK

1 2

+3.3V_RUN

HDA_SDI

DMIC_CLK

EAPD#

DMIC_DATA

3

12

C709

C709
*10P/50V_NC

*10P/50V_NC

U40

U40

1

DVDD_CORE

9

DVDD_CORE

40

DVDD

6

HDA_BITCLK

8

HDA_SDI

5

HDA_SDO

10

HDA_SYNC

11

HDA_RST#

18

NC/CD_L

19

NC/CD_GND

20

NC/CD_R

2

DMIC0/VOL_UP/GPIO1

3

DMIC1/VOL_DN/GPIO2

47

DMIC_CLK/GPIO0/SPDIF_IN

48

SPDIF_OUT_0

4

DVSS1

7

DVSS2

92HD73C-C1

92HD73C-C1

4

AVDD
AVDD

SENSE_A
SENSE_B

PORT_A_L

PORT_A_R

NC/VREFOUT_A

PORT_B_L

PORT_B_R

VREFOUT_B

PORT_C_L
PORT_C_R

VREFOUT_C

PORT_D_L
PORT_D_R

VREFOUT_D

PORT_E_L

PORT_E_R

GPIO4/VREFOUT_E

PORT_F_L

PORT_F_R

GPIO3/VREFOUT_F

PORT_G_L

PORT_G_R

PORT_H_L
PORT_H_R

PC_BEEP

CAP2

VREFFILT

AVSS1
AVSS2

12

25
38

SENSEA

13

SENSEB

34

39
41
37

21
22
28

23
24
29

35
36
32

14
15
31

16
17
30

43
44

45
46

12
33
27

26
42

12

C749

C749
10U/10V

10U/10V

CC0805

CC0805

5

+VDDA

C731

C731
1U/10V

1U/10V

CC0603

CC0603

AUD_HP1_L0 (41)
AUD_HP1_R0 (41)

AUD_FRONT_L (41,42)
AUD_FRONT_R (41,42)

AUD_MIC_L0 (42)
AUD_MIC_R0 (42)

AUD_MIC1_VREFO (42)

AUD_HP2_L0 (41)
AUD_HP2_R0 (41)

12

C751

C751
1U/10V

1U/10V

CC0603

CC0603

12

C430

C430

0.1U/10V

0.1U/10V

Close to CODEC

AUD_PC_BEEPAUD_PC_BEEP

6

1 2

+VDDA

C710

C710

0.1U/16V

0.1U/16V

CC0603

CC0603

C708

C708
1U/10V

1U/10V

CC0603

CC0603

R545 10KR545 10K

BEEP2 BEEP1

1 2

12

R537

R537

2.2K

2.2K

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

COMPUTER

AZELIA CODEC (92HD73C)

AZELIA CODEC (92HD73C)

AZELIA CODEC (92HD73C)

RM2 3A

RM2 3A

RM2 3A

7

1 2

53

4

1

2

U39

U39
74LVC1G86GW

74LVC1G86GW

40 59Friday, August 08, 2008

40 59Friday, August 08, 2008

40 59Friday, August 08, 2008

8

BEEP (31)

SPKR (13)

of

of

of

5

http://hobi-elektronika.net

4

3

2

1

+5V_SPK_AMP

12

R277

R277

12

100K

AUD_SPK_ENABLE#(42)

D D

C C

B B

EAPD#(40)

NB_MUTE#(31)

HP1_JD(40,42) HP2_JD(40,42)

AUD_FRONT_L(40,42)

BUFFER_VIAS(42)

AUD_FRONT_R(40,42)

AUD_HP2_L0(40)
AUD_HP2_R0(40)

AUD_SPK_ENABLE#

EAPD#

Q35

Q35
2N7002W-7-F

2N7002W-7-F

NB_MUTE#

Q34

Q34
2N7002W-7-F

2N7002W-7-F

C354

C354

0.1U/10V

0.1U/10V

NB_MUTE#

BUFFER_VIAS

BUFFER_VIAS

C762 10U/25V/1206C762 10U/25V/1206

1 2

C766 10U/25V/1206C766 10U/25V/1206

1 2

C437

C437

0.047U/25V

0.047U/25V

C434

C434

0.047U/25V

0.047U/25V

LINE_OUT_R

1

2

WLP4.0 support

+3.3V_RUN

12

C717

C717
10U/10V

10U/10V

CC0805

A A

EMI Reserved

CC0805

C724 *47P/50V_NCC724 *47P/50V_NC

1 2

C732 *47P/50V_NCC732 *47P/50V_NC

1 2

C440 270P/50VC440 270P/50V
C443 270P/50VC443 270P/50V

12

C716

C716
1U/10V

1U/10V

CC0603

CC0603

LIN­RIN-

12
12

AUD_HP2_L1
AUD_HP2_R1

100K

R280

R280
100K

100K

31

2

31

2

+3.3V_RUN

U7

U7

12

TC7SZ08FU(T5L,F,T)

TC7SZ08FU(T5L,F,T)

5

AMP_HP1_SHUD_L#

4

3

R316 3.48K/FR316 3.48K/F

1 2

C438

C438

1 2

0.01U/50V

0.01U/50V
R308

R308

1 2

14.7K/F

14.7K/F

R324 3.48K/FR324 3.48K/F

1 2

C448

C448

1 2

0.01U/50V

0.01U/50V
R320

R320

1 2

14.7K/F

14.7K/F

C754 0.033U/50V CC1206C754 0.033U/50V CC1206
C753 0.033U/50V CC1206C753 0.033U/50V CC1206

C736 1U/10V CC0603C736 1U/10V CC0603

C715 1U/16V CC0805C715 1U/16V CC0805

1 2
1 2

AUD_HP2_L1_L
AUD_HP2_R1_L

1 2

1 2

+5V_SPK_AMP

C765 0.1U/10VC765 0.1U/10V

1 2

411

U13A

U13A
MAX4492AUD+

MAX4492AUD+

3

VDD

VDD

2

VSS

VSS

+5V_SPK_AMP

411

U13B

U13B
MAX4492AUD+

MAX4492AUD+

5

VDD

VDD

6

VSS

VSS

R584 2.2KR584 2.2K

1 2

R583 2.2KR583 2.2K

1 2

WLP4.0 support

5

INTERNAL SPEAKER AMP

C378 10U/25V/1206C378 10U/25V/1206

1 2

C359 10U/25V/1206C359 10U/25V/1206

1 2

WLP4.0 support

+3.3V_RUN

12

5

4

U6

U6
TC7SZ08 FU(T5L,F,T)

TC7SZ08 FU(T5L,F,T)

3

+5V_SPK_AMP

12

12

U41

U41

3

SPKR_INL

2

SPKR_INR

27

HP_INL

26

HP_INR

24

BIAS

23

SPKR_EN#

22

HP_EN

25

MUTE#

31

GAIN1

32

GAIN2

17

HPVDD

9

CPVDD

10

C1P

12

C1N

11

CPGND

14

PVSS

13

CPVSS

TPA6040A4

TPA6040A4

1

7

AUD_HP1_L0(40)
AUD_HP1_R0(40)

C353

C353

0.1U/10V

0.1U/10V

EAPD#

LINE_OUT_L

LINE_OUT_R

LIN-LINE_OUT_L
RIN-

AUD_HP2_L1
AUD_HP2_R1

AUD_SPK_ENABLE#
AMP_HP2_EN
AUD_AMP_MUTE#
AUD_AMP_GAIN1
AUD_AMP_GAIN2

12

C714

C714
1U/16V

1U/16V

CC0805

CC0805

R254 *0_NCR254 *0_NC

1 2

1

2

4

AMP_HP1_SHUD#HP1_JD

12

R318

R318

R317

R317

*100K_NC

*100K_NC

100K

100K

AUD_AMP_GAIN1
AUD_AMP_GAIN2

12

R313

R313

R312

R312

100K

100K

*100K_NC

*100K_NC

TPA6040A4

TPA6040A4
QFN 32PIN

QFN 32PIN

C706 270P/50V

AUD_HP1_L1_L
AUD_HP1_R1_L

C706 270P/50V

R261 2.2KR261 2.2K

1 2

R256 2.2KR256 2.2K

1 2

C702 270P/50V

C702 270P/50V

C705 2.2U/25V CC1206C705 2.2U/25V CC1206

GAIN1 GAIN2 GAIN

006dB

0 1 10dB

1 0 15.6dB

11

OUTL+

OUTL-

OUTR+

OUTR-

HPL
HPR

REGEN

SET

VOUT

VDD

PVDD_8

PVDD_18

GND_28
PGND_5

PGND_21

AGND

6
7

20
19

16
15

4
1

29

30
8
18

28
5
21

33

REGEN
SET

3

AUD_SPK_L1 (37)
AUD_SPK_L2 (37)

AUD_SPK_R1 (37)
AUD_SPK_R2 (37)

+5V_SPK_AMP

50

50

12

AUD_HP1_L1
AUD_HP1_R1

12

AMP_HP1_SHUD#

50

50

1 2

NB_MUTE#

21.6dB

AUD_HP2_L2 (42)
AUD_HP2_R2 (42)

12

C424

C424

0.1U/10V

0.1U/10V

Layout Note:
Place close to pin 18.

12

C377

C377

0.1U/10V

0.1U/10V

1

2

12

C721

C721
1U/10V

1U/10V

CC0603

CC0603

13
15

14
18

1
3

5
7

C416

C416

2.2U/25V

2.2U/25V

CC1206

CC1206

+3.3V_RUN

12

5

3

R302 *0_NCR302 *0_NC

12

C429

C429

0.033U/16V

0.033U/16V

12

C738

C738

0.033U/16V

0.033U/16V

+5V_SPK_AMP

U37

U37

INL
INR

SHDNR
SHDNL

C1P
C1N

PVSS
SVSS

U8

U8
TC7SZ08FU(T5L,F,T)

TC7SZ08FU(T5L,F,T)

1 2

GND21GND22GND23GND24GND

AMP_HP2_EN_L

4

+5V_SPK_AMP

OUTL

OUTR

NC1
NC2
NC3
NC4
NC5

NC6
SVDD
PVDD

PGND
SGND

MAX4411ETP+

MAX4411ETP+

25

12

R327

R327
100K

100K

R322 *0_NCR322 *0_NC

1 2

AUDIO_AVDD_ON

For MAX9789A, depop Cap., pop Res.

R580 *2.2K_NCR580 *2.2K_NC

1 2

12

R575

R575
*0_NC

*0_NC

For MAX9789A, depop
Cap., pop 0 ohm.

12

C746

C746
1U/10V

1U/10V

CC0603

12

C727

C727
10U/10V

10U/10V

CC0805

CC0805

CC0603

Layout Note:
Place close TPA6040.

2

9
11
4
6
8
12
16
20
10
19
2
17

+VDDA

EAPD#

12

C745

C745
1U/10V

1U/10V

CC0603

CC0603

0.1U/10V

0.1U/10V

AUDIO_AVDD_ONAUD_AMP_MUTE#

+VDDA

+3.3V_RUN

R262 *0_NCR262 *0_NC

1 2

+3.3V_RUN

C364

C364

1

2

AUD_HP1_L2 (42)
AUD_HP1_R2 (42)

Layout Note:
TPA 4411 : cannot connect EP to GND.
The reason that we can't solder the pad
to vdd or ground is because it is

12

internally connected to VSS.

C688

C688
1U/16V

1U/16V

CC0805

CC0805

12

5

AMP_HP2_ENHP2_JD

4

U9

U9
TC7SZ08FU(T5L,F,T)

TC7SZ08FU(T5L,F,T)

3

Layout Note:
MAX9789A/TPA6040A : need to connect
EP (exposed paddle) to GND.
TPA 4411 : cannot connect EP to GND.
MAX 4411: can connect EP to GND.

AUDIO_AVDD_ON (31)

12

C744

C744
1U/10V

1U/10V

CC0603

CC0603

Layout Note:
Place close pin 30.

Title

Title

Title

AUDIO AMP

AUDIO AMP

AUDIO AMP

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

RM2 2E

RM2 2E

RM2 2E

Date: Sheet

Date: Sheet

Date: Sheet

EMI Reserved

R83 *0/0603_NCR83 *0/0603_NC
R301 *0/0603_NCR301 *0/0603_NC
R110 *0/0603_NCR110 *0/0603_NC
R286 0_0805R286 0_0805
R543 *0/0603_NCR543 *0/0603_NC
R450 *0/0603_NCR450 *0/0603_NC
R544 *0/0603_NCR544 *0/0603_NC

+5V_SPK_AMP

C428

C428
1U/10V

1U/10V

CC0603

CC0603

12

12

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

1 2
1 2
1 2
1 2
1 2
1 2
1 2

C743

C743

0.1U/10V

0.1U/10V

of

of

of

41 59Wednesday, August 06, 2008

41 59Wednesday, August 06, 2008

41 59Wednesday, August 06, 2008

1

1

http://hobi-elektronika.net

INTERNAL SUBWOOFER AMP

+5V_SPK_AMP

A A

1 2

1 2

+5V_SPK_AMP

SYNC Condition

VDD

R321

R321

GND

100K

100K

FLOAT

SYNC

Clocked

R323

R323
*100K_NC

*100K_NC

Spread-spectrum mode with fS = 1200kHz ±70kHz.

Fixed-frequency mode with fS = 1100kHz.

Fixed-frequency mode with fS = 1500kHz.

Fixed-frequency mode with fS = external clock frequency.

2

3

4

AUD_SPK_ENABLE#(41)

C456

C456

100P

100P

50

50

NPO

NPO

+5V_SPK_AMP

L43 BLM18PG121SN1DL43 BLM18PG121SN1D

120ohm, 2A

AUD_SUB_IN+AUD_MONO_OUT

1 2

R314 100KR314 100K

Q72

Q72
2N7002W-7-F

2N7002W-7-F

+5V_SPK_AMP

2

5

31

1U/10V

1U/10V

C450

CC0603C450

CC0603

1 2
1 2

C457 1U/10V

C457 1U/10V

CC0603

CC0603

R329 100KR329 100K

1 2

SUB_MUTE#

SYNC

AUD_SUB_GAIN1

AUD_SUB_GAIN2

SUB_IN+
SUB_IN-

U14

U14

2

IN+

3

IN-

5

SHDN#

8

MUTE#

7

SYNC

13

SYNC_OUT

16

G1

15

G2

17

Exposed Paddle

MAX9759ETE+

MAX9759ETE+

6

MAX9759

MAX9759
TQFN 16PIN

TQFN 16PIN

OUT+

OUT-

VDD

GND

PVDD

PGND

PVDD

PGND

7

Gur_0808: 0 ohm remo val,
delete R304, R309

SUB_OUT+

11

SUB_OUT-

10

1

12

C767

C767

0.1U/10V

0.1U/10V

4

9

12

C764

C764

0.1U/10V

0.1U/10V

6

12

12

C769

C769

0.1U/10V

0.1U/10V

14

+5V_SPK_AMP

12

C772

C772
10U/10V

10U/10V

CC0805

CC0805

C376

C376
*100P_NC

*100P_NC

50

50
NPO

NPO

8

CN7

CN7

1

1

2

2

TYC_1775765-2

TYC_1775765-2

C394

C394
*100P_NC

*100P_NC

50

50
NPO

NPO

R604

R604
100K

100K

1 2

1 2

B B

R599

R599
100K

100K

BUFFER_VIAS

C771

C771

2.2U/10V

2.2U/10V

1 2

CC0805

CC0805

BUFFER_VIAS (41)

AUD_FRONT_L(40,41)

AUD_FRONT_R(40,41)

C435 0.47U/6.3VC435 0.47U/6.3V

1 2

1 2

C433 0.47U/6.3VC433 0.47U/6.3V

R310 10K/FR310 10K/F

1 2

1 2

R307 10K/FR307 10K/F

C865

C865

0.068U/16V

0.068U/16V

BUFFER_VIAS

1 2

12

R713

R713

11.8K/F

11.8K/F

+5V_SPK_AMP

U13C

U13C

411

MAX4492AUD +

MAX4492AUD +

10

VDD

VDD

9

VSS

VSS

C864 0.01U/50VC864 0.01U/50V

1 2

R623 4.99K/FR623 4.99K/F

12

BUFFER_VIAS

R605

R605

8

1 2

10K/F

10K/F

C866

C866

0.033U/16V

0.033U/16V

12

C436

C436

0.068U/16V

0.068U/16V

R720

R720
20K/F

20K/F

+5V_SPK_AMP

411

U13D

U13D
MAX4492AUD+

MAX4492AUD+

12

VDD

VDD

13

VSS

VSS

R306 100K/FR306 100K/F

1 2

R719 11.2K/FR719 11.2K/F

1 2

14

AUD_MONO_OUT

+5V_SPK_AMP

R319

R319
*100K_NC

*100K_NC

1 2

R315

R315
100K

100K

1 2

R330

R330
100K

100K

1 2

AUD_SUB_GAIN1
AUD_SUB_GAIN2

R328

R328
*100K_NC

*100K_NC

1 2

GAIN1 GAIN2 GAIN

0 0 24dB

0 1 18dB

1 0 12dB

1 1 6dB

Ambient Parts of Headphone & MIC Jack To IB(IO Board) connector

CN5

AUD_HP1_L2(41)

AUD_HP1_R2(41)

C C

D D

AUD_HP2_L2(41)

AUD_HP2_R2(41)

AUD_MIC1_VREFO(40)

AUD_MIC_L0(40)

AUD_MIC_R0(40)

+3.3V_RUN

12

R586

R586
100K

100K

R272

R272

C399

C399

4.7K

4.7K

2.2U/10V

2.2U/10V

CC0805

CC0805

1 2

1 2

C384

C384

2.2U/10V

2.2U/10V

CC0805

CC0805

12

12

R260

R260

R266

R266

100K

100K

100K

100K

HP1_JD
HP2_JD
MIC1_JD

1

AUD_HP1_L2

AUD_HP1_R2

Gur_0808: 0 ohm remo val, delete
R282, R553, R555, R561, R562

AUD_HP2_L2

AUD_HP2_R2

C418

C418
1U/10V

1U/10V

CC0603

CC0603

1 2

12

12

R264

R264

4.7K

4.7K

AUD_MIC_L1

AUD_MIC_R1

HP1_JD (40,41)
HP2_JD (40,41)
MIC1_JD (40)

2

3

CN5

32

34

31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1

33

FOX_GB5RF321-1203-7F

FOX_GB5RF321-1203-7F

gb5rf341-1203-7f-32p-l

gb5rf341-1203-7f-32p-l

ICH_USBP0- (12)

ICH_USBP0+ (12)

ICH_USBP1- (12)

ICH_USBP1+ (12)

WWAN_LED (38)

+USB_LEFT_PWR

WLAN_LED (38)
BT_LED (38)
HDD_LED (38)

AUD_HP1_L2
AUD_HP1_R2
HP1_JD

AUD_HP2_L2
AUD_HP2_R2
HP2_JD

AUD_MIC_L1
AUD_MIC_R1
MIC1_JD

Adding additional AGND

CN32

CN32

1

1

2

2

TYC_1775765-2

TYC_1775765-2

4

Two USB ports
& WWAN LED

Front Side LED

Audio Jack

5

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

6

Date: Sheet

COMPUTER

IB CONN & SUBWOOFER

IB CONN & SUBWOOFER

IB CONN & SUBWOOFER

RM2 3A

RM2 3A

RM2 3A

7

of

of

of

42 59Friday, August 08, 2008

42 59Friday, August 08, 2008

42 59Friday, August 08, 2008

8

5

http://hobi-elektronika.net

C44

C26

C26

C41

C41

C40

0.1U

0.1U

10

10
X7R

X7R

C40

0.1U

0.1U

0.1U

0.1U

10

10

10

10

X7R

X7R

X7R

X7R

C44

C35

C47

C47

0.1U

0.1U

10

10
X7R

X7R

C35

C38

0.1U

0.1U

10

10
X7R

X7R

C38

0.1U

0.1U

0.1U

0.1U

10

10

10

10

X7R

X7R

X7R

X7R

+1.2V_LOM

C36

C36

4.7U

4.7U

10

10
X5R

X5R
805

805

Core Power Decoupling

C27

C27

0.1U

0.1U

10

10
X7R

X7R

VDDP Power Decoupling

+1.2V_VDDC_IO

D D

C560

C560

C561

C561

0.1U

0.1U

0.1U

0.1U

10

10

10

10

X7R

X7R

X7R

X7R

VDDIO Power Decoupling

+3.3V_LAN

C45

Y1

25MHzY125MHz

C45

C33

C33

0.1U

0.1U

0.1U

0.1U

10

10

10

10

X7R

X7R

X7R

X7R

LAN_XTALO

12

LAN_XTALI

C559
27P

27P

50

50
NPO

NPO

C46

C46

4.7U

4.7U

10

10
X5R

X5R
805

805

R430 200/FR430 200/F

1 2

C556

C556
27P

27P

50

50
NPO

NPO

C C

B B

+1.2V_LOM

L6

L6
BLM18AG601SN1D

+3.3V_LAN

12

BLM18AG601SN1D

1 2

L66

L66
BLM18AG601SN1D

BLM18AG601SN1D

1 2

L67

L67
BLM18AG601SN1D

BLM18AG601SN1D

1 2

L7

L7
BLM18AG601SN1D

BLM18AG601SN1D

1 2

R427

R427

4.7K

4.7K

C48

C48

0.1U

0.1U

10

10
X7R

X7R

12

R426

R426

4.7K

4.7K

PCIE_TX6+/GLAN_T X+(12)
PCIE_TX6-/GLAN_T X-(12)

PCIE_RX6+/GLAN_RX+(12)
PCIE_RX6-/GLAN_RX-(12)

SB_LOM_PCIE_RST#(12)

LAN_DISABLE
is hign active

+LAN_AVDDL

C30 4.7U/10V/0805C30 4.7U/10V/0805

+LAN_GPHYPLLVDDL

C552 4.7U/10V/0805C552 4.7U/10V/0805

+LAN_PCIEPLLVDDL

C554 4.7U/10V/0805C554 4.7U/10V/0805

+LAN_PCIESDSVDDL

C31 4.7U/10V/0805C31 4.7U/10V/0805

PCIE_WAKE#(13,30,33,34)

PLTRST#(6,12,30,31,33,34)

CLK_PCIE_LOM(17)
CLK_PCIE_LOM#( 17)

LAN_DISABLE(31)

C29 0.1U/10VC29 0.1U/10V

C550 0.1U/10VC550 0.1U/10V

C555 0.1U/10VC555 0.1U/10VC559

C32 0.1U/10VC32 0.1U/10V

C37 0.1U 10C37 0.1U 10
C39 0.1U 10C39 0.1U 10

R45 0R45 0
R46 *0_NCR46 *0_NC

+3.3V_RUN

Make sure it
stays high w hen
not driven by
BCM5784M.

+3.3V_LAN

1 2
1 2

R425 1KR425 1K
R423 1KR423 1K

4

+1.2V_LOM +1.2V_VDDC_IO

LAN_PCIETXDP
LAN_PCIETXDN

R422

R422

1.24K/F

1.24K/F

+3.3V_LAN

R47

R47

*4.7K_NC

*4.7K_NC

1 2

LAN_DISABLE

LAN_XTALO
LAN_XTALI

LAN_RDAC

LOMCLK_REQ#

U26

U26

5

VDDC_IO/VDDC

55

VDDC_IO/VDDC

13

VDDC

20

VDDC

34

VDDC

60

VDDC

39

AVDDL

51

AVDDL

35

GPHY_PLLVDDL

30

PCIE_PLLVDDL

27

PCIE_PLLVDDL

33

PCIE_VDDL

24

PCIE_VDDL/GND

26

PCIE_TXD_P

25

PCIE_TXD_N

31

PCIE_RXD_P

32

PCIE_RXD_N

12

WAKE#

10

PERST#

29

PCIE_REFCLK_P

28

PCIE_REFCLK_N

54

VAUX_PRS NT

53

VMAIN_PR SNT

3

LOW_PWR

58

TEST1/SMB_CLK

57

TEST2/SMB_DATA

22

XTALO

21

XTALI

37

RDAC

11

CLK_REQ#

+3.3V_LAN

61

15

19

VDDIO6VDDIO56VDDIO

VDDIO

VDDIO

BCM5784M

BCM5784M

10mm x 10mm

10mm x 10mm

68-Pin QFN

68-Pin QFN

Package Body

Package Body

GND

69

3

T103

T103
PAD

PAD

68

BIASVDDH

DC/VDDP

XTALVDD H

AVDDL/AVD DH

DC/AVDDH

DC/AVDDH

TRD3_N
TRD3_P

AVDDH/TRD2_N

TRD2_N/TRD2_P

TRD2_P/AVDDL

AVDDH/TRD1_N

TRD1_N/TRD1_P

TRD1_P/AVDDL

TRD0_N
TRD0_P

LINKLED#

SPD100LED#

SPD1000LED#

TRAFFICLED#

GPIO2

UART_MODE

GPIO1 _SER IALDI

GPIO0_SERIALDO

SCLK_EECLK

SO_EEDATA

ENERGY_DET

VDDC_IO/VDDP

REGOUT12_IO/REGCTL25

REGCTL12

SUPER_IDDQ/GND

BCM5784MA0KMLG

BCM5784MA0KMLG

36

23

45

38

52

49
50

48
47
46

42
43
44

41
40

2
1
67
66

8

9
7
4

65
63

SI

64
62

CS#

59

17

18

14

16

LAN_BIASVDDH

LAN_XTALVDDH

+LAN_AVDDL

TRD3- (44)
TRD3+ (44)

+LAN_AVDDH

TRD2- (44)
TRD2+ (44)

+LAN_AVDDH

TRD1- (44)
TRD1+ (44)

TRD0- (44)
TRD0+ (44)

LINKLED# (44)
SPD100LED# (44)
SPD1000LED# (44)
IO_LOM_ACTLED_YEL# (44)

LAN_GPIO

BCM_WP

BCM_SCL
SI
BCM_SDA
CS#

LAN_ENERGY_DET

+1.2V_VDDC_IO

Gur_0808: 0 ohm
remova l, delete R41

LAN_REGCTL12

SUPER_IDDQ don't
work, to GND directly.

+LAN_AVDDH

C24 0.1U/10VC24 0.1U/10V

C553 0.1U/10VC553 0.1U/10V

T7 PADT7 PAD

+3.3V_LAN

12

R44

R44

4.7K

4.7K

T102 PADT102 PAD

R29

R29

Q51

Q51
MMJT9435T1G

MMJT9435T1G

1

2 3

4

L5 BLM18AG601SN1DL5 BLM18AG601SN1D

1 2

C25 0.1U/10VC25 0.1U/10V

L8 BLM18AG601SN1DL8 BLM18AG601SN1D

1 2

C42 0.1U/10VC42 0.1U/10V

L4

L4
BLM18AG601SN1D

BLM18AG601SN1D

1 2

Place one cap close
42, 48 respectively.

R1208 & R1210: Stuff
only if U8 6 is installed

12

12

R36

R36

R34

R34

*4.7K_NC

*4.7K_NC

4.7K

4.7K

T6

T5

PADT6PAD

PADT5PAD

+3.3V_LAN

12

C10

C10

0.1U

0.1U

1/F

1/F

10

10
X7R

X7R

+1.2V_LOM

C34

C34

0.1U

0.1U

10

10
X7R

X7R

T8
PADT8PAD

C11

C11

4.7U

4.7U

10

10
X5R

X5R
805

805

C28

C28
10U

10U

10

10
X7R

X7R
805

805

2

+3.3V_LAN

U1

U1

8

VCC

7

NC

6

SCL

5

SDA

24LC02BT-I/STG

24LC02BT-I/STG

1

+3.3V_LAN

C43

C43

0.1U

0.1U

10

10

BCM_SCL

SI

CS#

R37 4.7KR37 4.7K

R429 4.7KR429 4.7K

R428 4.7KR428 4.7K

X7R

X7R

1

A0

2

A1

3

A2

4

VSS

Note:thermal pad

A A

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

LAN (BCM5784M)

LAN (BCM5784M)

LAN (BCM5784M)

RM2 3A

RM2 3A

RM2 3A

1

of

of

of

43 59Friday, August 08, 2008

43 59Friday, August 08, 2008

43 59Friday, August 08, 2008

5

4

Title

Title

Title

Size D ocument Number Rev

Size D ocument Number Rev

Size D ocument Number Rev

Date: Sheet

Date: Sheet

3

2

Date: Sheet

A

http://hobi-elektronika.net

B

C

D

E

TRANSFORMER

Layout Note:
Route TRD+/- pairs with 100 ohm
differential trace immpedance.

4 4

12

TRD3+

TRD3-

TDCT

TDCT

TRD2+

TRD2-

TRD1+

TRD1-

TDCT

TDCT

TRD0+

TRD0-

C21

C21

0.1U/10V

0.1U/10V

TRD3+(43)

TRD3-(43)

TRD2+(43)

TRD2-(43)

TRD1+(43)

TRD1-(43)

TRD0+(43)

TRD0-(43)

Pace 0.1u physically

3 3

close to transformer

12

C15

C15

0.1U/10V

0.1U/10V

12

C14

C14

0.1U/10V

0.1U/10V

12

C20

C20

0.1U/10V

0.1U/10V

RJ-45 Connector

IO_LOM_ACTLED_YEL#(43)

+3.3V_LAN

13

Q1

Q1
DDTA114YU A-7-F

DDTA114YU A-7-F

47K

D4

D4

SPD100LED#(43)

2 2

+3.3V_LAN

R31 4.7KR31 4.7K

SPD1000LED#(43)

D6 SDMK0340L-7-FD6 SDMK0340L-7-F

LINKLED#(43)

21

SDMK0340L-7-F

SDMK0340L-7-F

21

D5 SDMK0340L-7-FD5 SDMK0340L-7-F

21

D7

D7

21

SDMK0340L-7-F

SDMK0340L-7-F

47K

2

10K

10K

R13 330R13 330

+3.3V_LAN

13

Q2

Q2
DDTA114YU A-7-F

DDTA114YU A-7-F

47K

47K

2

10K

10K

R14 330R14 330

L65

L65

CHIP SIDE MEDIA SIDE

1

2

3

4

5

6

7

8

9

10

11

12

R25 330R25 330

1 2

+3.3V_LAN

RJ45-TX3­RJ45-TX3+
RJ45-TX1­RJ45-TX2­RJ45-TX2+
RJ45-TX1+
RJ45-TX0­RJ45-TX0+

CHIP SIDE MEDIA SIDE

TD0+

TD0-

TDCT0

1:1

1:1

TDCT1

TD1+

TD1-

1:1

1:1

TD2+

TD2-

TDCT2

1:1

1:1

TDCT3

TD3+

TD3-

1:1

Pulse H5120BNL

Pulse H5120BNL

Gur_0808: change transfo rmer from
"H5120NL(for In tel LAN chip)" t o
"H5120BNL(for Broadcom LAN ch ip)".

1:1

CN15

CN15

10

LED_YN

9

LED_YP

8

8

7

7

6

6

5

5

4

4

3

3

2

2

1

1

12

LED_GND

11

LED_GP/AN

13

LED_GN/AP

TYC_2006250-1

TYC_2006250-1

rj45-2006250-13p-v-rm2

rj45-2006250-13p-v-rm2

Y

Y

OG

OG

CHSGND114CHSGND2

CHSGND316CHSGND4

15

17

TX0+

TX0-

TXCT0

TXCT1

TX1+

TX1-

TX2+

TX2-

TXCT2

TXCT3

TX3+

TX3-

24

23

22

21

20

19

18

17

16

15

14

13

+3.3V_SUS

1 2

RJ45-TX3+

RJ45-TX3-

TXCT3

TXCT2

RJ45-TX2+

RJ45-TX2-

RJ45-TX1+

RJ45-TX1-

TXCT1

TXCT0

RJ45-TX0+

RJ45-TX0-

R27

R27
0_0805

0_0805

R4 75/FR4 75/F

1 2

R5 75/FR5 75/F

1 2

R6 75/FR6 75/F

1 2

R7 75/FR7 75/F

1 2

+3.3V_LAN

GND_LAN

12

C549

C549
1000P/3K

1000P/3K

CC1808

CC1808

TRD0+
TRD0­TRD1+
TRD1-

TRD2+
TRD2­TRD3+
TRD3-

12

C19

C19
*1P/50V_NC

*1P/50V_NC

12

C13

C13
*1P/50V_NC

*1P/50V_NC

12

C18

C18
*1P/50V_NC

*1P/50V_NC

12

C12

C12
*1P/50V_NC

*1P/50V_NC

12

C23

C23
*1P/50V_NC

*1P/50V_NC

12

C17

C17
*1P/50V_NC

*1P/50V_NC

Reserved EMI

12

C22

C22
*1P/50V_NC

*1P/50V_NC

12

C16

C16
*1P/50V_NC

*1P/50V_NC

1 1

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

LAN SWITCH

LAN SWITCH

LAN SWITCH

RM2 3A

RM2 3A

RM2 3A

E

of

of

of

44 59Friday, August 08, 2008

44 59Friday, August 08, 2008

44 59Friday, August 08, 2008

A

B

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

C

D

Date: Sheet

1

http://hobi-elektronika.net

A A

2

3

Gur_0808: reserve optio n for
U47 power to +3. 3V_ALW

4

12

R728

R728

*0_NC

*0_NC

IMVP_PWRGD(13,31,51)

RESET_OUT#(31)

+3.3V_SUS+3.3V_ALW

12

R7270R727

0

U47

U47
74AHC1G08GW

74AHC1G08GW

2

1

3 5

5

4

ICH_PWRGD (6,13)

6

7

8

Keep Away from h igh speed buses

B B

1.8V_SUS_PWRGD(53)

1.5V_RUN_PWRGD(48)

GFX_PCIE_PWRGD(52)

GFX_CORE_PWRGD(52)

1.05V_RUN_PWRGD(48)

Gur_0808: 0 ohm remo val, delete

C C

1.5V_DDR_PWRGD(6,49)

RUN_ON_1(31)

D D

1

2

3

4

R698, R699, R700, R701, R703

R682 *0_NCR682 *0_NC

R684 *10K_NCR684 *10K_NC

1 2

R681 *10K_NCR681 *10K_NC

1 2

+3.3V_ALW

2

1

3 5

1 2

+3.3V_ALW

1

2

4

5

U48

U48
74AHC1G08GW

74AHC1G08GW

5

14

U51A

U51A

SN74AHC08PW

SN74AHC08PW

U51B

U51B

SN74AHC08PW

SN74AHC08PW

4

RUN_ON

RUN_ON_1

3

U51C

U51C

9

10

SN74AHC08PW

SN74AHC08PW

6

RUN_ON (20,26,48,49,55)

8

U51D

U51D

12

13

SN74AHC08PW

SN74AHC08PW

6

11

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

HWPG (31)

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

System Reset Circuit

System Reset Circuit

System Reset Circuit

RM2 3A

RM2 3A

RM2 3A

7

of

of

of

45 59Friday, August 08, 2008

45 59Friday, August 08, 2008

45 59Friday, August 08, 2008

8

1

http://hobi-elektronika.net

H-C276D118P2-8 * 9

H33

8
9

8
9

H33

H-C276D118P2-8

H-C276D118P2-8

6 7
5
4

H11

H11

H-C236D118P2-8

H-C236D118P2-8

6 7
5
4

H26

H26

H-C276D118P2-8

H-C276D118P2-8

6 7
5
4

123

A A

H-C236D118P2-8 * 3

H9

H9

H-C236D118P2-8

H-C236D118P2-8

6 7
5
4

123

123

8
9

123

6 7
5
4

8
9

H23

H23

H-C276D118P2-8

H-C276D118P2-8

8
9

123

H22

H22

H-C236D118P2-8

H-C236D118P2-8

6 7
5
4

123

2

H32

H32

H-C276D118P2-8

H-C276D118P2-8

6 7
5
4

8
9

123

8
9

H21

H21

H-C276D118P2-8

H-C276D118P2-8

6 7
5
4

123

8
9

3

H10

H10

H-C276D118P2-8

H-C276D118P2-8

6 7
5
4

123

8
9

H7

H7

H-C276D118P2-8

H-C276D118P2-8

6 7
5
4

123

8
9

4

H2

H2

H-C276D118P2-8

H-C276D118P2-8

6 7
5
4

123

8
9

H1

H1

H-C276D118P2-8

H-C276D118P2-8

6 7
5
4

123

5

PV5

PV5

*FDRM200201_NC

8
9

*FDRM200201_NC

GND

1

PV7

PV7

PAD181X67

PAD181X67

*FDRM200201_NC

*FDRM200201_NC

PV8

PV8

PAD181X67

PAD181X67

PV6

PV6

GND

1

PV9

PV9

PAD118X67

PAD118X67

6

PV4

PV4

*FDRM200201_NC

*FDRM200201_NC

GND

1

7

Gur_0808: change PV1 from
FDZD3002010 to FDEF3001015

PV3

PV3

*HYH_RHC-CP-27G03_NC

*HYH_RHC-CP-27G03_NC

GND

1

PV1

PV1

HYH_RHC-CP-27G03

HYH_RHC-CP-27G03

GND

1

8

PV2

PV2

*HYH_RHC-CP-27G03_NC

*HYH_RHC-CP-27G03_NC

GND

1

h-c236d197p2 * 1 H-C236D158P2 * 4

H14

H4

H4

h-c236d197p2

h-c236d197p2

1

H15

H15

H-C236D158P2

H-C236D158P2

1

H19

H19

H-C236D158P2

H-C236D158P2

1

H20

H20

H-C236D158P2

H-C236D158P2

H14

H-C236D158P2

H-C236D158P2

1

1

H-T295X280B236D118P2 * 1

H28

H28

H-T295X280B236D118P2

H-T295X280B236D118P2

B B

1

GND

1

RF_GND RF_GND RF_GND

H34

H34

o-rm2-1

o-rm2-1

1

GND

1

GND

1

h-c236d157p2 * 2

H3

H5

H5

H-C394D260P2-8

H-C394D260P2-8

8
9

123

H3

h-c236d157p2

h-c236d157p2

1

H-C394D260P2-8 * 1

H18

H18

H-C394D260P2-8

H-C394D260P2-8

6 7
5

8

4

9

123

H6

H6

h-c236d157p2

h-c236d157p2

1

h-c394d260p2 * 1

6 7
5
4

C C

h-c236d236n * 2

H31

H31

h-c236d236n

h-c236d236n

Gur_0814: delete H27

1

H-C197D118P2-8 * 1

H30

H30

H-C197D118P2-8

H-C197D118P2-8

6 7
5

8

4

9

123

H-C197D91P2-8 * 1

D D

H8

H8

H-C197D91P2-8

H-C197D91P2-8

6 7
5

8

4

9

123

1

h-o205x157d138x91p2 * 1

H29

H29

h-o205x157d138x91p2

h-o205x157d138x91p2

1

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

2

3

4

5

6

Date: Sheet

COMPUTER

PAD & SCREW & SPRING

PAD & SCREW & SPRING

PAD & SCREW & SPRING

RM2 3A

RM2 3A

RM2 3A

7

of

of

of

46 59Thursday, August 14, 2008

46 59Thursday, August 14, 2008

46 59Thursday, August 14, 2008

8

A

http://hobi-elektronika.net

1 1

PQ25

PQ25
SI4835DDY-T1-E3

SI4835DDY-T1-E3

8

+DC_IN_SS

2

2 2

8731LDO

PR59

PR59
10K/F

10K/F

ACAV_IN(31)

3 3

IINP(31)

Andy_0806: Del 0R PR60

PR63

PR63

15.8K/F

15.8K/F

PR57

PR57

8.45K/F

8.45K/F

SMBCLK0(22,31,54)

SMBDAT0(22,31,54)

PC64

PC64

0.1U/10V

0.1U/10V

PR46 49.9K/FPR46 49.9K/F

+3.3V_ALW

PR54

PR54
10K/F

10K/F

PC62

PC62

0.01U/25V

0.01U/25V

7
6
5

PR135

PR135

10K

10K

31

PQ6

PQ6
2N7002W-7-F

2N7002W-7-F

PR44

PR44
365K/F

365K/F

PC53 0.01U/25VPC53 0.01U/25V

PC60

PC60

0.01U/25V

0.01U/25V

4

+DC_IN_SS

PC65 0.1U/50V/0603PC65 0.1U/50V/0603

1
2
3

PR136

PR136
100K

100K

PC51

PC51
1U/25V/0805

1U/25V/0805

8731_ACIN

8731_IINP

PC58

PC58

0.01U/25V

0.01U/25V

B

22

13

11

10

14

8731REF

2

9

8

6

5

4

3

PC55

PC55
1U/10V

1U/10V

DCIN

ACIN

ACOK

VDD

SCL
SDA
BATSEL

IINP

CCV

CCI

CCS

REF

PR130

PR130

0.01/3720

0.01/3720

1

1

3

8731CSSP

28

1

GND

DAC

7

PC63

PC63

0.1U/10V

0.1U/10V

GND_CHG

2

2
443

8731CSSN

27

CSSP

CSSN

BST

LDO

VCC

DHI

LX

DLO

PGND

CSIP

CSIN

FBSA

FBSB

GND

MAX8731AETI+

MAX8731AETI+

12

PU2

PU2

25

21

26

24

23

20

19

18

17

15

16

PR47

PR47

2

Jump20X10

Jump20X10

8731BST

8731LDO

8731DHI

8731LX

8731DLO

PR51

PR51
100

100

PC52 1U/10V/0603PC52 1U/10V/0603

PR41

PR41
33/F/0603

33/F/0603

PC50 1U/10V/0603PC50 1U/10V/0603

+VCHGR

112

C

+PWR_SRC

FL4

FL4
HI1206T161R-10

HI1206T161R-10

8731LDO

21

PD1

PD1

SDM10K45-7-F

SDM10K45-7-F

PR43

PR43
0/0603

0/0603

PC45

PC45

0.1U/50V/0603

0.1U/50V/0603

PC34

PC34
3300P/50V

3300P/50V

PR42 1/0603PR42 1/0603 PC117

PC49

PC49
220P/50V

220P/50V

PQ4

PQ4
SI4812BDY-T1-E3

SI4812BDY-T1-E3

8731CSIP

8731CSIN

CHG_PWR_SRC

PC123

PC123
2200P/50V

2200P/50V

876

PQ3

PQ3
SI4800BDY-T1-E3

SI4800BDY-T1-E3

4

MPLC0730L4R7 5.6A/41mOhm)

MPLC0730L4R7 5.6A/41mOhm)

2

351

876

PR38

4

SI4812BDY-T1-E3
Rdson (MAX) =21mOhm

PR38

2.2/0805

2.2/0805

2

351

PC35

PC35
1000P/50V

1000P/50V

PL4

PL4

PC126

PC126

0.1U/50V/0603

0.1U/50V/0603

12

PC124

PC124
2200P/50V

2200P/50V

PR103

PR103

0.01/3720

0.01/3720

1

1

3

D

PQ18

PQ18
SI4835DDY-T1-E3

SI4835DDY-T1-E3

1
2
3

4

PC114

PC114

0.1U/50V/0603

0.1U/50V/0603

PC36

PC120

PC120

1000P/50V

1000P/50V

PC36
10U/25V/1206

10U/25V/1206

PC119

PC119

2200P/50V

2200P/50V

PC115

PC115

0.1U/50V/0603

0.1U/50V/0603

PC125

PC125

0.1U/50V/0603

0.1U/50V/0603

2

2
443

PC121

PC121

3300P/50V

3300P/50V

Frequency(Vadapter-Vbattery>5V) 400K

+DC_IN_SS

PR34

PR34
470K

470K

PC37

PC37
10U/25V/1206

10U/25V/1206

PC117

10U/25V/1206

10U/25V/1206

E

FL8

FL8

HI1206T161R-10

PC116

PC116

10U/25V/1206

10U/25V/1206

HI1206T161R-10

HI1206T161R-10

HI1206T161R-10

PC118

PC118

10U/25V/1206

10U/25V/1206

FL3

FL3

+VCHGR

+VCHGR (54)

8
7
6
5

4 4

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

CHARGER (MAX8731A)

CHARGER (MAX8731A)

CHARGER (MAX8731A)

RM2 3A

RM2 3A

RM2 3A

E

2005/4/21

of

of

of

47 59

47 59

47 59

A

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

B

C

D

Date: Sheet

5

http://hobi-elektronika.net

D D

PC111

PC111
*0.1U/16V_NC

*0.1U/16V_NC

Andy_0806: Del 0R PR99

PU4 TPS51117RGYRPU4 TPS51117RGYR

RUN_ON(20,26,45,49,55)

PR102

PR102
300/0603

PR101

PR101
100K

100K

300/0603

PC113

PC113

1U/10V/0603

1U/10V/0603

+5V_ALW

1.05V_RUN_PWRGD(45)

C C

+3.3V_SUS

+1.05V_VCCP

+1.05V_FB

PC112

PC112
*0.1U/10V_NC

*0.1U/10V_NC

1

2

3

4

5

6

7

EN_PSV

TON

VOUT

V5FILT

VFB

PGOOD

GND

THERM

15

PR100

PR100
237K/F

237K/F

4

VBST

DRVH

TRIP

V5DRV

DRVL

PGND

3

PC30

PC30
2200P/50V

2200P/50V

876

+1.05V_DH

4

PR98

PR98
0/0603

14

13

12

LL

11

10

9

8

0/0603

PC109

PC109
1U/10V/0603

1U/10V/0603

2

+5V_ALW

PR31

PR31

112

Jump20X10

Jump20X10

PC110

PC110

0.1U/50V/0603

0.1U/50V/0603

PR97

PR97

13.3K/F

13.3K/F

+1.05V_LX

+1.05V_DL

4

FDS6680AS
Rdson (MAX) =12.5mOhm

PQ17

PQ17

FDS8878

FDS8878

2

351

SIL104-1R0-R (11A/6.0mohm)

SIL104-1R0-R (11A/6.0mohm)

876

9

PR29

PR29
*2.2/F/0603_NC

*2.2/F/0603_NC

PC27

PC27
*2200P/50V_NC

*2200P/50V_NC

2

351

PQ16

PQ16
FDS6680AS

FDS6680AS

PC29

PC29

0.1U/50V/0603

0.1U/50V/0603

PL3

PL3

2

Andy_0806: Del PJP4

PC102

PC102
10U/25V/1206

10U/25V/1206

PR33

PR33
20K/F

20K/F

+1.05V_FB

0.75V

PR32

PR32

49.9K/F

49.9K/F

+PWR_SRC

PC103

PC103
10U/25V/1206

10U/25V/1206

Andy_0806: Del PJP5, PJP6

PC107

PC107

0.1U/50V/0603

PC31

PC31
*0.015U/16V_NC

*0.015U/16V_NC

0.1U/50V/0603

+1.05V_VCCP

+

+

PC101

PC101
330U/2.5V/ESR12

330U/2.5V/ESR12

1

+1.05V_VCCP
TDC : 9.70A
OCP : 13.86A

TON

Frequency

B B

Andy_0806: Del PJP3

+1.8V_SUS

PC104

PC104

10U/4V/0805

10U/4V/0805

0.1U/25V/0603

0.1U/25V/0603

PC105

PC105

PR3=237K

300K

PQ46

PQ46
SI4800BDY-T1-E3

SI4800BDY-T1-E3

8
7
6
5

4

3
2
1

+1.5V_RUN

PR94

PR94
100K

+3.3V_SUS

1.5V_RUN_PWRGD(45)

RUN_ON

+5V_SUS

A A

Andy_0806: Del 0R PR30, PR198

5

100K

PC28

PC28

0.1U/10V

0.1U/10V

PC100

PC100

1U/10V/0603

1U/10V/0603

PU3 RT9024PEPU3 RT9024PE

4

PGD

1

EN

6

VCC

2

4

DRV

GND

5

PC132

3

FB

PC132

100P/50V

100P/50V

PR96

PR96
14K/F/0603

14K/F/0603

0.8V

PR95

PR95
16K/F/0603

16K/F/0603

Andy_0806: Del PJP7

PC108

PC108
22U/10V/1206

22U/10V/1206

3

TDC : 2.69A

+1.5V_RUN

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

2

Date: Sheet

COMPUTER

1.05VCCP & 1.5VRUN

1.05VCCP & 1.5VRUN

1.05VCCP & 1.5VRUN

RM2 3A

RM2 3A

RM2 3A

1

of

of

of

48 59Thursday, August 07, 2008

48 59Thursday, August 07, 2008

48 59Thursday, August 07, 2008

5

http://hobi-elektronika.net

D D

4

PR50

PR50
*0_NC

*0_NC

3

2

1

S3_1.5V S5_1.5V

+PWR_SRC

Andy_0806: Del PJP10

PC57

PC57
*0.1U/10V_NC

*0.1U/10V_NC

+0.75V_DDR_VTT
TDC : 0.7A

Andy_0806: Del PJP1

+0.75V_DDR_VTT

PC151

PC151
10U/4V/0805

10U/4V/0805

C C

+V_DDR_MCH_REF

B B

Andy_0806: Del 0R PR134

PC152

PC152
10U/4V/0805

10U/4V/0805

PC150

PC150

0.033U/25V/0603

0.033U/25V/0603

PC149

PC149
1U/10V/0603

1U/10V/0603

DIS_MODE

TPS51116_V5IN

+1.5V_DDR

PU7

PU7
TPS51116PWPRG4

TPS51116PWPRG4

1

VLDOIN

2

VTT

4

VTTSNS

5

GND

3

VTTGND

6

MODE

7

VTTREF

8

COMP

9

VDDSNS

10

VDDQSET

PC148

PC148
*0.1U/10V_NC

*0.1U/10V_NC

PR131

PR131

49.9K/F

49.9K/F

0.75V

PR129

PR129

49.9K/F

49.9K/F

DRVH

VBST

DRVL

PGND

V5IN

PGOOD

GND21GND22GND23GND24GND25GND26GND

27

*1000P/50V_NC

*1000P/50V_NC

TPS51116_V5IN

PC68

PC68
*18P/50V_NC

*18P/50V_NC

19

PR120 0/0603PR120 0/0603

20

18

LL

17

16

S3_1.5V

11

S3

12

S5

14

13

15

CS

PC59

PC59

PR123 0PR123 0

S5_1.5V

PR122 0PR122 0

TPS51116_V5IN

PR48

PR48

11.3K/F

11.3K/F

PR56

PR56

2

Jump20X10

Jump20X10

PC56

PC56
*0.1U/10V_NC

*0.1U/10V_NC

PC139 0.1U/50V/0603PC139 0.1U/50V/0603

RUN_ON (20,26,45,48,55)

SUS_ON (31,53,55)

PR49 0/0603PR49 0/0603

PC138

PC138

4.7U/10V/0805

4.7U/10V/0805

+3.3V_SUS

112

GND_DDR

+5V_ALW

1.5V_DDR_PWRGD (6,45)

PR121

PR121
100K

100K

4

+1.5V_DH

+1.5V_LX

+1.5V_DL

4

FDS6680AS
Rdson (MAX) =12.5mOhm

2

2

876

PQ19

PQ19

FDS8878

FDS8878

351

876

PQ22

PQ22

FDS6680AS

FDS6680AS

351

PC47

PC47
2200P/50V

2200P/50V

PL5

SIL104R-1R5B (1.5UH/10A/8.1mOhm)

SIL104R-1R5B (1.5UH/10A/8.1mOhm)

PL5

PR119

PR119
*2.2/F/0603_NC

*2.2/F/0603_NC

PC140

PC140
*2200P/50V_NC

*2200P/50V_NC

12

Frequency(Fixed) 400K

PC48

PC48

0.1U/50V/0603

0.1U/50V/0603

PC135

PC135
10U/25V/1206

10U/25V/1206

PC129

PC129

0.1U/50V/0603

0.1U/50V/0603

PC134

PC134
10U/25V/1206

10U/25V/1206

+

+

PC127

PC127
330U/2.5V/ESR15

330U/2.5V/ESR15

+1.5V_DDR
TDC : 7.90A
OCP : 9.88A

+1.5V_DDR

Andy_0806: Del PJP9

A A

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

5

4

3

2

Date: Sheet

COMPUTER

1.5_DDR/0.75(TPS51116)

1.5_DDR/0.75(TPS51116)

1.5_DDR/0.75(TPS51116)

RM2 3A

RM2 3A

RM2 3A

1

of

of

of

49 59Thursday, August 07, 2008

49 59Thursday, August 07, 2008

49 59Thursday, August 07, 2008

5

http://hobi-elektronika.net

4

3

2

1

Andy_0806: Del PJP15

D D

+PWR_SRC

PC162

PC162

+5V_ALW
TDC : 4.90A
OCP : 7.0A

+5V_ALW

Andy_0806: Del PJP14

SIL1045R-3R3A (8A/21mOhm)

C C

+

+

PC160

PC160

220U/6.3V/ESR25

220U/6.3V/ESR25

B B

PC159

PC159

0.1U/50V/0603

0.1U/50V/0603

SIL1045R-3R3A (8A/21mOhm)

10U/25V/1206

10U/25V/1206

Andy_0808: Add Zener Diode and change
PR155=82.5K, PR156=200K to fix +3.3V_ALW
glitch issue when adapter unplug

PC163

PC163

PC161

PC161

PC164

10U/25V/1206

10U/25V/1206

PL9

PL9

*2.2/F/0603_NC

*2.2/F/0603_NC

*2200P/50V_NC

*2200P/50V_NC

+15V_ALW

PC164

0.1U/50V/0603

0.1U/50V/0603
2200P/50V

2200P/50V

PR142

PR142

PC167

PC167

SI4812BDY-T1-E3
Rdson (MAX) =21mOhm

PQ38

PQ38

DDTA114YUA-7-F

DDTA114YUA-7-F

Gur_0814: change
PR155 from 82.5K
to 68K as Andy's
information

PQ30

PQ30

876

SI4800BDY-T1-E3

SI4800BDY-T1-E3

4

2

351

+5V_LX

876

4

PQ33

PQ33

2

351

SI4812BDY-T1-E3

SI4812BDY-T1-E3

47K

47K

10K

10K

2

31

PQ37

PQ37

2

2N7002W-7-F

2N7002W-7-F

+5V_DH

+5V_DL

13

PR173

PR173
*0_NC

*0_NC

Andy_0806: Del 0R PR154

PD12

PD12
UDZSTE-175.6B

UDZSTE-175.6B

2 1

PR155

PR155
68K/F

68K/F

ISL6237_ONLOD

PR156

PR156
200K/F

200K/F

PC174

PC174

0.1U/50V/0603

0.1U/50V/0603

PR149 237K/FPR149 237K/F

+5V_EN1

PC168

PC168

0.1U/50V/0603

0.1U/50V/0603

Andy_0806: Del PR150,PR151

PC185

PC185

0.1U/50V/0603

0.1U/50V/0603

+15V_ALWP

PC186

PC186

0.1U/50V/0603

0.1U/50V/0603

POK1

PR153

PR153
1/0603

1/0603

+5V_ALW2

PC171

PC171

4.7U/25V/0805

4.7U/25V/0805

PC176

PC176
1U/6.3V

1U/6.3V

6

5

42

7

9

PD10

PD10

1

2

PD11

PD11

1

2

PAD
PAD
PAD
PAD
BYP
OUT1
FB1
ILIM1
PGOOD1
ON1
DH1
LX1
PAD
PAD

PAD33PAD34PAD

35

+5V_ALW2

PC173

PC173

1U/10V/0603

1U/10V/0603

8

VIN

LDO

RTC

PAD

LDOREFIN

PU8

PU8

MAX17020ETJ+

MAX17020ETJ+

BST117DL118VDD19SECFB20AGND21PGND22DL223BST2

SECFB

PC183

PC183

0.1U/50V/0603

0.1U/50V/0603

3

PC184

PC184

0.1U/50V/0603

0.1U/50V/0603

3

41
40
39
38

10
11
12
13
14
15
16
37
36

BAT54S-7-F

BAT54S-7-F

BAT54S-7-F

BAT54S-7-F

TON Frequency

ISL6237_ONLOD

4

ONLDO

2

10/0603

10/0603

PR170

PR170
*0_NC

*0_NC

3

1

2

TON

VCC

24

PR157

PR157

Jump20X10

Jump20X10

PR161

PR161

PR169

PR169

*0_NC

*0_NC

REF

REFIN2

OUT2

SKIP#

PGOOD2

112

ILIM2

ON2

DH2
LX2

PR160

PR160
1/0603

1/0603

SECFB

+5V_VCC1

PC177

PC177

1U/10V/0603

1U/10V/0603

32
31
30
29
28
27
26
25

PC181

PC181

0.1U/10V

0.1U/10V

PR167

PR167
348K/F

348K/F

POK2
+3.3V_EN2
+3.3V_DH

PC179

PC179

0.1U/50V/0603

0.1U/50V/0603

+3.3V_DL

PR1590PR159
0

PR168

PR168
*0_NC

*0_NC

PR172

PR172
*0_NC

*0_NC

SI4812BDY-T1-E3

SI4812BDY-T1-E3

+5V_ALW2

876

PQ34

4

+3.3V_LX

4

PQ31

PQ31

PQ34
SI4800BDY-T1-E3

SI4800BDY-T1-E3

2

351

876

2

351

SI4812BDY-T1-E3
Rdson (MAX) =21mOhm

PR148

PR148

*100K_NC

*100K_NC

POK2

POK1

PC175

PC175

0.1U/50V/0603

0.1U/50V/0603

SIL1045R-3R3A (8A/21mOhm)

SIL1045R-3R3A (8A/21mOhm)

PR158

PR158
*2.2/F/0603_NC

*2.2/F/0603_NC

PC178

PC178
*2200P/50V_NC

*2200P/50V_NC

PC172

PC172

2200P/50V

2200P/50V

PL10

PL10

PC170

PC170

10U/25V/1206

10U/25V/1206

+3.3V_ALW+3.3V_ALW

PR163

PR163
*100K_NC

*100K_NC

PC169

PC169

10U/25V/1206

10U/25V/1206

+3.3V_ALW
TDC : 6.76A
OCP : 9.66A

+3.3V_ALW

Andy_0806: Del PJP16

PC166

PC166

0.1U/50V/0603

0.1U/50V/0603

Andy_0806: NC PR163,PR148

+

+

PC165

PC165

220U/6.3V/ESR25

220U/6.3V/ESR25

OUT1@400K , OUT2@500KGND

VCC

+3.3V_DELAY

2

PQ32

PQ32
2N7002W-7-F

PR152 39K/FPR152 39K/F

Andy_0806: Del 0R PR145

+3.3V_EN2

PD9 1SS355PD9 1SS355

+5V_EN1

2 1

PR144

PR144
*0_NC

*0_NC

PR143

PR143
200K/F

200K/F

+5V_ALW2

A A

5V_ALW_ON(31)

5

3 1

PR146 0PR146 0

PR147 0PR147 0

4

2N7002W-7-F

PU 10K at Page 22 (GPU
Thermal Monitor side)

MB_THERM# (22)

THERM_STP# (31,39)

H_THERMTRIP# (3)

OPEN

3

OUT1@200K , OUT2@300K

OUT1@400K , OUT2@300K

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

2

Date: Sheet

COMPUTER

3.3V/5V/15V (MAX17020)

3.3V/5V/15V (MAX17020)

3.3V/5V/15V (MAX17020)

RM2 3A

RM2 3A

RM2 3A

50 59Thursday, August 14, 2008

50 59Thursday, August 14, 2008

50 59Thursday, August 14, 2008

of

of

1

of

5

http://hobi-elektronika.net

+3.3V_SUS

PR8

PR8
10/0603

PR770PR77
0

PC5

PC5

0.1U/10V

0.1U/10V

1

2

3

4

5

6

7

8

9

10

11

12

0.01U/16V

0.01U/16V

10/0603

PGOOD

PSI#

PMON

RBIAS

VR_TT#

NTC

SOFT

OCSET

VW

COMP

FB

FB2

PC81

PC81

49

GND

48

13

PC6

PC6

0.01U/50V

0.01U/50V

3V3

VDIFF

D D

+3.3V_SUS

PR1

PR1
*1.91K/F_NC

IMVP_PWRGD(13,31,45)

H_PSI#(3)

PR4 499/ FPR4 499/F

+3.3V_SUS

IMVP6_PROCHOT#(31)

C C

PR73 *NTC_470K_NCPR 73 *NTC_470K_N C

PC4 0.1U/10VPC4 0.1U/10V

PR74 *4.02K/F_NCPR74 *4.02K/ F_NC

PC78 *0.01U/16V_NCPC78 *0.01U/16V_NC

Close to Phase 1 Inductor

PC2 1000P/ 50VPC2 1000P/50V

PR75 6.81K/FPR75 6.81K/ F

PC3 220P/50VPC3 220P/50V

PR6 97.6K/FPR6 97.6K/F

PR76 255/FPR76 255/F

B B

PC1 470P/50VPC 1 470P/50V

PC80 1000P/ 50VPC80 1000P/50V

PR80 1KPR 80 1K

+VCCSENSE(4)

+VSSSENSE(4)

*1.91K/F_NC

Andy_0806: Del 0R PR2

PR7 4.99K/FPR7 4.99K/F

PWR_MON

PC79 0.015U/16VPC79 0.015U/16V

ISL6266_VO

PR5 12.7K/FPR5 12.7K/F

Parallel

PR3 147K/ FPR3 147K/F

PR91KPR9
1K

Andy_0806: Del 0R PR10,PR12

T101

T101

PAD

PAD

CLK_EN#

47

46

CLK_EN#

DPRSTP#

VSEN

RTN

14

15

PC11

PC11

0.22U/10V/0603

0.22U/10V/0603

ISL6266_VO

VSUM

4

45

DPRSLPVR

DROOP

16

PR84

PR84

4.02K/F

4.02K/F

PC7

PC7

180P/50V

180P/50V

PC82

PC82

0.01U/16V

0.01U/16V

44

17

PR141KPR14

43

VR_ON

ISL6262A

ISL6262A

DFB

VO

VSUM19VIN20GND

18

1K

VSUM

ISL6266_VO

PC83

PC83

0.33U/16V/0603

0.33U/16V/0603

PC8

PC8

0.022U/16V

0.022U/16V

PR82 499/FPR82 499/F

40

39

VID3

VID441VID542VID6

21

+CPU_PWR_SRC

PR88

PR88

10/0603

10/0603

PC9

PC9

0.1U/50V/0603

0.1U/50V/0603

PR17

PR17
11K/F

11K/F

VID138VID0

VID2

VDD22ISEN223ISEN1

ISEN2

PC84 0.22U/25V/0603PC84 0.22U/25V/0603

PR20

PR20
10/0603

10/0603

PC10

PC10
1U/10V/0603

1U/10V/0603

37

PU1

PU1

36

BOOT1

35

UGATE1

34

PHASE1

33

PGND1

32

LGATE1

31

PVCC

30

LGATE2

29

PGND2

28

PHASE2

27

UGATE2

26

BOOT2

25

NC

24

PC85 0.22U/25V/0603PC 85 0.22U/25V/ 0603

ISEN1

+5V_SUS

PR21

PR21

2.61K/F

2.61K/F

PR27

PR27
10K/0603_NTC

10K/0603_NTC

H_DPRSTP# (3,6,11)

DPRSLPVR (6,13)

IMVP_VR_ON (31)

VID6 (4)

VID5 (4)

VID4 (4)

VID3 (4)

VID2 (4)

VID1 (4)

VID0 (4)

PR23

PR23
1/0603

1/0603

UG1

PH1

LG1

LG2

PH2

UG2

PR24 1/0603PR24 1/0603

ISL6266_VO

PR91

PR91

2

112

Jump20X10

Jump20X10

3

PC14

PC14

2.2U/10V/0805

2.2U/10V/0805

PC12

PC12

0.22U/50V/0603

0.22U/50V/0603

+5V_SUS

PC13

PC13

0.22U/50V/0603

0.22U/50V/0603

VSUM

ISEN2

ISL6266_VO

ISEN1

VSUM

ISEN1

ISL6266_VO

ISEN2

PR85 3.65K/F/0603PR85 3.65K/ F/0603

PR87 10K/0603PR87 10K/0603

PR92 1/0603PR92 1/0603

PR89 10K/0603PR89 10K/0603

UG1

*NTMFS4707NT1G_NC

*NTMFS4707NT1G_NC

PH1

NTMFS4119NT1G

NTMFS4119NT1G

LG1

PR78 3.65K/F/0603PR78 3.65K/F/0603

PR79 10K/0603PR79 10K/0603

PR83 1/0603PR83 1/0603

PR81 10K/0603PR81 10K/0603

UG2

PH2

NTMFS4119NT1G

NTMFS4119NT1G

LG2

4

PQ2

PQ2

PQ13

PQ13

4

4

PQ1

PQ1

*NTMFS4707NT1G_NC

*NTMFS4707NT1G_NC

PQ14

PQ14

4

2

876

9

2

351

NTMFS4707NT1G

NTMFS4707NT1G

876

9

2

351

876

9

2

351

NTMFS4707NT1G

NTMFS4707NT1G

876

9

2

351

4

PQ11

PQ11

2

4

2

PQ15

PQ15
NTMFS4119NT1G

NTMFS4119NT1G

4

PQ10

PQ10

2

4

2

PQ12

PQ12

NTMFS4119NT1G

NTMFS4119NT1G

1

+PWR_SRC

FL1

FL1

HI1206T161R-10

0.1U/50V/0603

0.1U/50V/0603

PC89

PC89

HI1206T161R-10

HI1206T161R-10

HI1206T161R-10

PC91

PC91

2200P/50V

2200P/50V

+VCC_CORE

+CPU_PWR_SRC

PC92

PC92

0.1U/50V/0603

0.1U/50V/0603

FL2

FL2

2200P/50V

2200P/50V

+VCC_CORE

+CPU_PWR_SRC

PR25

PR25

PC87

PC87

876

9

*2.2/0805_NC

*2.2/0805_NC

351

PC20

PC20
*1500P/50V_NC

*1500P/50V_NC

PR93

PR93

876

9

2.2/0805

2.2/0805

PC97

PC97
1500P/50V

1500P/50V

351

PR26

PR26

*2.2/0805_NC

*2.2/0805_NC

876

9

351

PC21

PC21
*1500P/50V_NC

*1500P/50V_NC

PR28

PR28

2.2/0805

2.2/0805

876

9

PC24

PC24

351

1500P/50V

1500P/50V

PC15

PC15

PC90

PC90

*10U/25V/1206_NC

0.1U/50V/0603

0.1U/50V/0603

PC88

PC88

2 1

*10U/25V/1206_NC

2200P/50V

2200P/50V

PL1 0.36uH_30A_ETQP4LR36WFCPL1 0.36uH_30A_ETQP4LR36WFC

2 1

3

4

PC23

PC23

0.1U/50V/0603

0.1U/50V/0603

PC93

PC93

PC94

PC94

0.1U/50V/0603

0.1U/50V/0603

PL2 0.36uH_30A_ETQP4LR36WFCPL2 0.36uH_30A_ETQP4LR36WFC

10U/25V/1206

10U/25V/1206

2200P/50V

2200P/50V

3

4

PC22

PC22

PC18

PC18

PC17

PC95

PC95

10U/25V/1206

10U/25V/1206

PC96

PC96

0.1U/50V/0603

0.1U/50V/0603

PC17

PC86

PC86

10U/25V/1206

10U/25V/1206

10U/25V/1206

10U/25V/1206

PC25

PC25

PC26

PC26

+

+

+

+

330U/2V/ESR6

330U/2V/ESR6

330U/2V/ESR6

330U/2V/ESR6

PC16

PC16

PC19

PC19

*10U/25V/1206_NC

*10U/25V/1206_NC

10U/25V/1206

10U/25V/1206

PC98

PC98

+

+

330U/2V/ESR6

330U/2V/ESR6

10U/25V/1206

10U/25V/1206

PC99

PC99

+

+

330U/2V/ESR6

330U/2V/ESR6

A A

Close to Phase 1 Inductor

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

CPU_POWER (ISL6262A)

CPU_POWER (ISL6262A)

CPU_POWER (ISL6262A)

RM2 3A

RM2 3A

RM2 3A

1

51 59Thursday, August 07, 2008

51 59Thursday, August 07, 2008

51 59Thursday, August 07, 2008

of

of

of

5

4

Title

Title

Title

Size Docum ent Number Rev

Size Docum ent Number Rev

Size Docum ent Number Rev

Date: Sheet

Date: Sheet

3

2

Date: Sheet

1

http://hobi-elektronika.net

2

3

4

5

+5V_SUS

PR124

PR124
10/0603

GFX_+5V_RUN

A A

GFX_RUN_ON(20)

10/0603

PC142

PC142
1U/10V/0603

1U/10V/0603

PC141

PC141

2.2U/10V/0805

2.2U/10V/0805

PC122

PC122
10U/25V/1206

10U/25V/1206

PC128

PC128
10U/25V/1206

10U/25V/1206

PC44

PC44
*10U/25V/1206_NC

*10U/25V/1206_NC

Andy_0806: Del PJP8

PC38

PC38
2200P/50V

2200P/50V

+PWR_SRC

PC41

PC41

0.1U/50V/0603

0.1U/50V/0603

+VCC_GFX_CORE

21

PD6

PD6

SDM10K45-7-F

OUT

EPAD
EPAD

VIN

FB

SDM10K45-7-F

21

20

19

18

17

16

15

32
33

PC42

PC42
22U/4V/0805

22U/4V/0805

PC136

PC136

PR116

PR116

0.22U/50V/0603

0.22U/50V/0603

1/0603

1/0603

+GFX_LX

+GFX_DH

+GFX_DL

+1.8V_SUS

+1.1V_GFX_PCIE

+1.1V_GFX_PCIE
TDC : 1.23A

GFX_CORE_CNTRL0(19)

28

26

27

PU5

PR118

PR118
*61.9K/F_NC

*61.9K/F_NC

+VCC_GFX_CORE

GFX_REF

PC137

PC137

0.22U/6.3V

0.22U/6.3V

B B

TON

Frequency

C C

+3.3V_SUS

GFX_PCIE_PWRGD(45)

GFX_CORE_PWRGD(45)

OPEN REF

300K 450K

PR112

PR112
100K

100K

PR110

PR110
100K

100K

PR115

PR115
*0_NC

*0_NC

PR113

PR113
82K/F

82K/F

PR114

PR114

30.1K/F

30.1K/F

PR107

PR107
100K

100K

PC131

PC131

0.01U/16V

0.01U/16V

PR117

PR117
*0_NC

*0_NC

PU5

TPO

1

TON

2

OVP/UVP

3

REF

4

ILIM

5

POK1

6

POK2

7

STBY#

29

EPAD

30

EPAD

31

EPAD

SS8VTTS9VTTR10PGND211VTT12VTTI13REFIN

PC130

PC130

0.047U/10V

0.047U/10V

PR108

PR108

4.99K/F

4.99K/F

PR104

PR104

49.9K/F

49.9K/F

AVDD

SHDNA#

MAX8632ETI+

MAX8632ETI+

PC43

PC43
1U/10V/0603

1U/10V/0603

25

SKIP#

23

24

GND

PGND1

PC39

PC39
22U/4V/0805

22U/4V/0805

22

VDD

LGATE

BOOT

PHASE

UGATE

14

GFX_REF

PC46

PC46
10U/4V/0805

10U/4V/0805

PQ20

PQ20

NTMFS4707NT1G

NTMFS4707NT1G

4

4

PQ23

PQ23

NTMFS4119NT1G

NTMFS4119NT1G

NTMFS4119NT1G
Rdson ( MAX) =3.1m Ohm

+3.3V_SUS

PR37

PR37

*10K_NC

*10K_NC

PQ21

PQ21
NTMFS4707NT1G

876

9

4

2

351

876

9

4

2

351

PR39

PR39
10K

10K

NTMFS4707NT1G

876

9

PL6

PL6

2

351

MPC1040LR45C (0.45UH/25A/1.1mOhm)

MPC1040LR45C (0.45UH/25A/1.1mOhm)

876

2

351

PC40

PC40

0.01U/16V

0.01U/16V

9

PQ24

PQ24
NTMFS4119NT1G

NTMFS4119NT1G

PC133

PC133
1000P/50V

1000P/50V

PR109

PR109

93.1K/F

93.1K/F

34

5

PR45

PR45
*2.2/0805_NC

*2.2/0805_NC

PC54

PC54
*1500P/50V_NC

*1500P/50V_NC

PQ47A

PQ47A
2N7002DW-7-F

2N7002DW-7-F

PR111

PR111
20K/F

20K/F

0.7V

PR105

PR105

61.9K/F

61.9K/F

PQ47B

PQ47B

2N7002DW-7-F

2N7002DW-7-F

PC145

PC145

0.1U/50V/0603

0.1U/50V/0603

PR106

PR106
140K/F

140K/F

61

2

PC106

PC106

0.01U/16V

0.01U/16V

Andy_0806: Del PJP11,PJP12

+

+

PC67

PC67
220U/2.5V/ESR15

220U/2.5V/ESR15

PR40

PR40

10K

10K

+

+

PC69

PC69
220U/2.5V/ESR15

220U/2.5V/ESR15

PR126

PR126

2

Jump20X10

Jump20X10

+3.3V_SUS

TDC : 19.74A
OCP : 28.20A

+VCC_GFX_CORE

112

PR184

PR184
*10K_NC

*10K_NC

GFX_CORE_CNTRL1 (19)

GFX_CORE_CNTRL1GFX_CORE_CNTRL0

LOWLOW

D D

ILIM

SKIP#

OVP/UVP The overvoltage limit is 116% of Vout.

Iovp=(2*(Rb/(Ra+Rb))*0.1*(1/RDSON)+(I_DELTA/2)

AVDD = Low-noise, forced-PWM mode.
GND = Pulse-skipping operation.

The undervoltage limit is 70% of Vout.

1

2

HIGH HIGH 1.2V

3

HIGH

LOW

+VCC_GFX_CORE

0.95

1.1V

4

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

COMPUTER

VGA_M86 (MAX8632)

VGA_M86 (MAX8632)

VGA_M86 (MAX8632)

RM2 3A

RM2 3A

RM2 3A

5

of

of

of

52 59Thursday, August 07, 2008

52 59Thursday, August 07, 2008

52 59Thursday, August 07, 2008

5

http://hobi-elektronika.net

4

3

2

1

Andy_0806: Del PJP2

PC74

PC74
10U/25V/1206

10U/25V/1206

PC157

PC157

0.1U/50V/0603

0.1U/50V/0603

+PWR_SRC

+1.8V_SUS
TDC : 9.90A
OCP : 14.15A

+

+

PC153

PC153
330U/2.5V/ESR15

330U/2.5V/ESR15

+1.8V_SUS

D D

PC66

PC66
*0.1U/10V_NC

*0.1U/10V_NC

PR133

Andy_0806: Del 0R PR52

SUS_ON(31,49,55)

PR127

PR127
300/0603

+3.3V_SUS

300/0603

PC144

PC144

1U/10V/0603

1U/10V/0603

+5V_ALW

C C

1.8V_SUS_PWRGD(45)

PR128

PR128

100K

100K

+1.8V_SUS

PC143

PC143
*0.1U/10V_NC

*0.1U/10V_NC

+1.8V_FB

PU6 TPS51117RGYRPU6 TPS51117RGYR

1

EN_PSV

2

TON

3

VOUT

4

V5FILT

5

VFB

6

PGOOD

7

GND

14

VBST

13

DRVH

12

LL

11

TRIP

10

V5DRV

9

DRVL

8

PGND

THERM

15

PC146

PC146

1U/10V/0603

1U/10V/0603

PR133
0/0603

0/0603

+5V_ALW

PR132

PR132

13.7K/F

13.7K/F

+1.8V_DH

PC147

PC147

0.1U/50V/0603

0.1U/50V/0603

+1.8V_LX

+1.8V_DL

876

4

4

PQ26

PQ26

FDS8878

FDS8878

2

351

SIL104R-1R5B (1.5UH/10A/8.1mOhm)

SIL104R-1R5B (1.5UH/10A/8.1mOhm)

876

PQ28

PQ28
FDS6670AS

FDS6670AS

2

351

PC72

PC72
2200P/50V

2200P/50V

PL7

PL7

PR70

PR70
*1/0805_NC

*1/0805_NC

PC76

PC76
*2200P/50V_NC

*2200P/50V_NC

12

+1.8V_FB

PC71

PC71

0.1U/50V/0603

0.1U/50V/0603

PR55

PR55
14K/F

14K/F

0.75V

PR53

PR53
10K/F

10K/F

PC154

PC154
10U/25V/1206

10U/25V/1206

PC61

PC61
*1000P/50V_NC

*1000P/50V_NC

Andy_0806: Del PJP13

FDS6680AS
Rdson (MAX) =12.5mOhm

237K/F

PR61

PR61

2

B B

112

Jump20X10

Jump20X10

237K/F
PR62

PR62

GND_1P8V

TON

Frequency

PR185=237K

300K

A A

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

5

4

3

2

Date: Sheet

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

1.8V_SUS (TPS51117)

1.8V_SUS (TPS51117)

1.8V_SUS (TPS51117)

RM2 3A

RM2 3A

RM2 3A

53 59Thursday, August 07, 2008

53 59Thursday, August 07, 2008

53 59Thursday, August 07, 2008

of

of

1

of

A

http://hobi-elektronika.net

+3.3V_ALW

PC33

PC33
2200P/50V

2200P/50V

PC32

1 1

FOX_BP02096-B51F5-7F

FOX_BP02096-B51F5-7F

BAT-200045MR009H588ZR-9P-R-V

BAT-200045MR009H588ZR-9P-R-V

2 2

Gur_0808: change CN29 from
DFHD05MS095 to DFHD05MS017

3 3

PC32

0.1U/50V/0603

0.1U/50V/0603

CN24

CN24

BATT1+
BATT2+

SMB_CLK

SMB_DAT

BATT_PRES#

SYSPRES#

BATT_VOLT

BATT1­BATT2-

CN29

CN29

Adapter1+

Adapter2+

Adapter1-

Adapter2-

ACS_88314-057N

ACS_88314-057N

87437-0543-5p-r

87437-0543-5p-r

PSID

1
2
3
4
5
6
7
8
9

1

2

3

4

5

PRP1

PRP1

1
3

4P2R-100

4P2R-100

2
4

PR35

PR35
100

100

PC196 *0.1U_NCPC196 *0.1U_NC

PC195 *1000P/50V_NCPC195 *1000P/50V_NC

PC194 *2200P/50V_NCPC194 *2200P/50V_NC

Adapter_DCIN+

Adapter_DCIN-

12

PRV2

PRV2

*VZ0603M260AGT_NC

*VZ0603M260AGT_NC

B

PD3

PD3

2

1

DA204U

DA204U

3

FL6

FL6
BLM41PG600SN1L

BLM41PG600SN1L

1 2

FL5

FL5
BLM41PG600SN1L

BLM41PG600SN1L

1 2

12

PRV1

PRV1

*VZ0603M260AGT_NC

*VZ0603M260AGT_NC

C

PD4

PD4

2

1

DA204U

DA204U

3

PC77

PC77

0.1U/50V/0603

0.1U/50V/0603

1

2

3

0.47U/25V/0805

0.47U/25V/0805

PD5

PD5
DA204U

DA204U

+VCHGR

SMBCLK0 (22,31,47)
SMBDAT0 (22,31,47)

PC75

PC75

+DC_IN

PR71

PR71
240K

240K

+3.3V_ALW

1
2
3

PR72

PR72
100K

100K

+5V_ALW2

1

PR36

PR36

100K

100K

PBAT_PRES# (31)

PQ27

PQ27
SI4835DDY-T1-E3

SI4835DDY-T1-E3

4

2

8
7
6
5

+3.3V_ALW

PC158

PC158

0.01U/25V

0.01U/25V

D

PR137

PR137
10K/F/0603

10K/F/0603

PC156

PC156

0.1U/50V/0603

0.1U/50V/0603

+DC_IN_SS

PC155

PC155

4.7U/25V/0805

4.7U/25V/0805

E

PR139

2

*DA204U_NC

*DA204U_NC
PD2

PD2

PR139

2.2K

2.2K

PS_ID (31)

PS_ID_DISABLE#

D

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

COMPUTER

DCIN & Batt

DCIN & Batt

DCIN & Batt

RM2 3A

RM2 3A

RM2 3A

54 59Friday, August 08, 2008

54 59Friday, August 08, 2008

54 59Friday, August 08, 2008

of

of

E

of

PD8

PD8

3

DA204U

*100_NC

*100_NC
PR67

PR67

DA204U

+5V_ALW2

1

3

PQ29

PQ29
2N7002W-7-F

PR138

PR138
100K/F

100K/F

PR141

PR141
15K/F

15K/F

2N7002W-7-F

3 1

2

2

PQ8

PQ8

MMST3904-7-F

MMST3904-7-F

1 3

C

PR140

PR140
100

100

+5V_ALW2

PR66

PR66
10K

10K

PL8

PL8
BLM11B102S

BLM11B102S

1 2

4 4

A

B

DOCK_PSID

PD7

PD7
*SSM24PT_NC

*SSM24PT_NC

1

http://hobi-elektronika.net

2

3

4

5

SUS_ON(31,49,53)

+5V_ALW2

PR174

PR174

100K

100K

5

SUS_ON#

SUS_ON#

34

PQ39A

PQ39A
2N7002DW-7-F

2N7002DW-7-F

PQ43

PQ43

2N7002W-7-F

2N7002W-7-F

+5V_ALW+5V_ALW2

8
7

PR177

PQ9

PQ9

2

+15V_ALW

2

PR177

100K

100K

RUN_5V_ENABLE

61

PQ41B

PQ41B
2N7002DW-7-F

2N7002DW-7-F

PR69

PR69

100K

100K

RUN_1.8V_ENABLE

31

PC189

PC189
4700P/25V

4700P/25V

PC73

PC73

0.047U/25V

0.047U/25V

+1.8V_SUS +1.8V_RUN

PR178

PR178

100K

100K

A A

RUN_ON#

34

RUN_ON(20,26,45,48,49)

B B

5

PQ41A

PQ41A
2N7002DW-7-F

2N7002DW-7-F

RUN_ON#

2N7002W-7-F

2N7002W-7-F

6
5

Andy_0807: Change to SI4430BD Y-T1-E3
due to SI4336DY-T1-E3 EOL

8
7
6
5

PQ42

PQ42
SI4800BDY-T1-E3

SI4800BDY-T1-E3

3
2
1

4

PQ7

PQ7
SI4430BDY-T1-E3

SI4430BDY-T1-E3

3
2
1

4

+5V_RUN+15V_ALW

+5V_RUN

0.79A

PC190

PC190

0.1U/50V/0603

0.1U/50V/0603

+1.8V_RUN

6.03A

PC70

PC70

0.1U/50V/0603

0.1U/50V/0603

PR179

PR179
20K

20K

PR68

PR68
20K

20K

+15V_ALW +3.3V_ALW +3.3V_SUS

PR175

PR175
100K

100K

SUS_3.3V_ENABLE

61

2

PQ39B

PQ39B
2N7002DW-7-F

2

PR180

PR180

100K

100K

SUS_5V_ENABLE

31

2N7002DW-7-F

PC187

PC187
4700P/25V

4700P/25V

6
5
2
1

8
7
6
5

PQ44

PQ44
FDC655BN

FDC655BN

3

PC191

PC191
4700P/25V

4700P/25V

PQ40

PQ40
SI4800BDY-T1-E3

SI4800BDY-T1-E3

4

4

+5V_SUS+15V_ALW +5V_ALW

3
2
1

PC192

PC192

0.1U/50V/0603

0.1U/50V/0603

+3.3V_SUS

0.92A

PC188

PC188

0.1U/50V/0603

0.1U/50V/0603

+5V_SUS
TDC : 42mA

PR181

PR181
20K

20K

PR176

PR176
20K

20K

Andy_0807: Change to SI4430BD Y-T1-E3
due to SI4336DY-T1-E3 EOL

+3.3V_ALW

PR171

PQ36

PQ36

2

PR171

100K

100K

RUN_3.3V_ENABLE

31

C C

RUN_ON#

2N7002W-7-F

2N7002W-7-F

PQ35

PQ35
SI4430BDY-T1-E3

SI4430BDY-T1-E3

8
7
6
5

4

3
2
1

Reserve discharge path

+1.8V_RUN

R695

Q79

Q79

R695
*1K_NC

*1K_NC

31

2

*2N7002W-7-F_NC

*2N7002W-7-F_NC

Q41

Q41

R373

R373
*1K_NC

*1K_NC

31

2

R71047R710
47

Q85

Q85

31

2

*2N7002W-7-F_NC

*2N7002W-7-F_NC

1

D D

RUN_ON#

2N7002W-7-F

2N7002W-7-F

+1.5V_RUN+3.3V_RUN+5V_RUN +0.75V_DDR_VTT

R376

R376
*1K_NC

*1K_NC

31

2

Q43

Q43

*2N7002W-7-F_NC

*2N7002W-7-F_NC

2

2

Q42

Q42

*2N7002W-7-F_NC

*2N7002W-7-F_NC

31

R374

R374
*1K_NC

*1K_NC

+3.3V_RUN+15V_ALW

PC182

PC182
4700P/25V

4700P/25V

+3.3V_RUN

5.81A

PC180

PC180

0.1U/50V/0603

0.1U/50V/0603

3

PR162

PR162
20K

20K

Reserve discharge path

SUS_ON#

*2N7002W-7-F_NC

*2N7002W-7-F_NC

4

+1.8V_SUS +5V_SUS +3.3V_SUS

R704

Q80

Q80

R704
*1K_NC

*1K_NC

31

2

2

Q81

Q81

*2N7002W-7-F_NC

*2N7002W-7-F_NC

55 59Thursday, August 07, 2008

55 59Thursday, August 07, 2008

55 59Thursday, August 07, 2008

5

R706

R706
*30/F_NC

*30/F_NC

31

2

Q83

Q83

*2N7002W-7-F_NC

*2N7002W-7-F_NC

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

COMPUTER

Load Switch

Load Switch

Load Switch

RM2 3A

RM2 3A

RM2 3A

31

R705

R705
*1K_NC

*1K_NC

of

of

of

5

http://hobi-elektronika.net

D D

4

3

2

1

+3.3V_RUN +3.3V_RUN

CN11

CN11

1

TIP

3

8PMJ-3

5

8PMJ-6

7

8PMJ-7

9

8PMJ-8

11

LED1_GRNP

PCI_AD[31..0](12,28)

C C

B B

PCI_PIRQD#(12)

CLK_PCI_DEBUG(17)

PCI_REQ1#(12) PCI_GNT1# (12)

PCI_C_BE3#(12,28)

PCI_C_BE2#(12,28)
PCI_IRDY#(12,28)

CLKRUN#(13,28, 31)
PCI_SERR#(12,28)

PCI_PERR#(12,28)
PCI_C_BE1#(12,28)

T97T97

+5V_RUN

+5V_RUN

PCI_AD31
PCI_AD29

PCI_AD27
PCI_AD25

PCI_AD23

PCI_AD21
PCI_AD19

PCI_AD17

PCI_AD14

PCI_AD12
PCI_AD10

PCI_AD8
PCI_AD7

PCI_AD5

PCI_AD3

PCI_AD1

DEBUG_ENABLE

13

LED1_GRNN

15

CHSGND

17

INTB#

19

3.3V_1

21

USBD+

23

GND0

25

CLK

27

GND1

29

REQ#

31

3.3V_2

33

AD31

35

AD29

37

GND2

39

AD27

41

AD25

43

WLAN_ACTIVE

45

C/BE3#

47

AD23

49

GND3

51

AD21

53

AD19

55

GND4

57

AD17

59

C/BE2#

61

IRDY#

63

3.3V_3

65

CLKRUN#

67

SERR#

69

GND5

71

PERR#

73

C/BE1#

75

AD14

77

GND6

79

AD12

81

AD10

83

GND7

85

AD8

87

AD7

89

3.3V_4

91

AD5

93

RESERVED1

95

AD3

97

5V_1

99

AD1

101

GND8

103

AC_SYNC

105

AC_SDATA_IN

107

AC_BIT_CLK

109

AC_CODEC_ID1#

111

MOD_AUDIO_MON

113

AUDIO_GND1

115

SYS_AUDIO_OUT

117

SYS_AUDIO_OUT GND

119

AUDIO_GND2

121

RESERVED2

123

VCC5A

*MINI-PCI_AMP_NC

*MINI-PCI_AMP_NC

AC_SDATA_OUT
AC_CODEC_ID0#

SYS_AUDIO_IN GND

RING

8PMJ-1
8PMJ-2
8PMJ-4

8PMJ-5
LED2_YELP
LED2_YELN

RESERVED3

5V_2

INTA#

USBD-

3.3VAUX1
RST#

3.3V_5
GNT#
GND9

PME#

BT_ACTIVE

AD30

3.3V_6

AD28
AD26
AD24

IDSEL

GND10

AD22
AD20

AD18
AD16

GND11

FRAME#

TRDY#
STOP#

3.3V_7

DEVSEL#

GND12

AD15
AD13
AD11

GND13

C/BE0#

3.3V_8

RESERVED5
RESERVED6

GND14
M66EN

AC_RESET#
RESERVED7

GND15

SYS_AUDIO_IN

AUDIO_GND3

MCPIACT#

3.3VAUX2

2

4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52
54
56

PAR

58
60
62
64
66
68
70
72
74
76
78
80
82
84

AD9

86
88
90

AD6

92

AD4

94

AD2

96

AD0

98
100
102
104
106
108
110
112
114
116
118
120
122
124

+3.3V_RUN

12

C518

C518
*0.1U/10V_NC

*0.1U/10V_NC

+5V_RUN

+3.3V_SUS

PCI_AD30

PCI_AD28
PCI_AD26
PCI_AD24

R657 *100_NCR657 *100_NC

1 2

PCI_AD22
PCI_AD20

PCI_AD18
PCI_AD16

PCI_AD15
PCI_AD13
PCI_AD11

PCI_AD9

PCI_AD6
PCI_AD4
PCI_AD2
PCI_AD0

12

C519

C519
*0.1U/10V_NC

*0.1U/10V_NC

PCI_PIRQA# (12)

PCI_RST# (12,28)

ICH_PME# (12,28)

PCI_AD20

PCI_PAR (12,28)

PCI_FRAME# (12,28)
PCI_TRDY# (12,28)
PCI_STOP# (12,28)

PCI_DEVSEL# (12,28)

PCI_C_BE0# (12,28)

IRQ_SERIRQ (13, 28,31)

+3.3V_SUS

12

C517

C517
*0.1U/10V_NC

*0.1U/10V_NC

12

C516

C516
*0.1U/10V_NC

*0.1U/10V_NC

A A

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

Debug Port (Mini PCI)

Debug Port (Mini PCI)

Debug Port (Mini PCI)

RM2 2A

RM2 2A

RM2 2A

1

56 59Tuesday, July 15, 2008

56 59Tuesday, July 15, 2008

56 59Tuesday, July 15, 2008

of

of

of

5

4

Title

Title

Title

Size Docum ent Number Rev

Size Docum ent Number Rev

Size Docum ent Number Rev

Date: Sheet

Date: Sheet

3

2

Date: Sheet

1

http://hobi-elektronika.net

2

3

4

5

6

7

8

30

+3.3V_SUS

WWAN, WPAN

32

7

A A

ICH9-M

G16

A13

ICH_SMBCLK

ICH_SMBDATA

2.2K2.2K

+3.3V_WLAN

7002

WLAN_SMBCLK

WLAN_SMBDAT

8

EXPRESS CARD

30

MINICARD-WLAN

32

7002

+3.3V_ALW

2.2K2.2K

110

SMBCLK0

111

SMBDAT0

B B

+3.3V_WLAN

+3.3V_DELAY

7002

100

100

10

3

4

9

8

7

BATTERY

CHARGER

GPU
THERMAL

7002

+3.3V_ALW

+3.3V_DELAY

10K 10K

SIO
ITE8512

115

SMBCLK1

116

C C

SMBDAT1

+3.3V_RUN

7002

7002

+3.3V_RUN

6
5

7

6

10
9

LCD

CLOCK

THERMAL

+3.3V_ALW

2.2K 2.2K

117

SMBCLK2

118

SMBDAT2

D D

1

2

3

31

28

DB

4

2

5

5

5

MEDIA BUTTON

4

6

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

COMPUTER

SMBUS BLOCK

SMBUS BLOCK

SMBUS BLOCK

RM2 2A

RM2 2A

RM2 2A

7

of

of

of

57 59Tuesday, July 15, 2008

57 59Tuesday, July 15, 2008

57 59Tuesday, July 15, 2008

8

5

http://hobi-elektronika.net

POWER STATES

Signal

State

SLP
S3#

SLP
S4#

SLP
S5#

S4
STATE#

4

ALWAYS
PLANE

SUS
PLANE

RUN
PLANE

CLOCKS

3

2

USB PORT#

1

DESTINATION

S0 (Full ON) / M0

D D

S3 (Suspend to RAM) / M1 LOW HIGH HIGH

S4 (Suspend to DISK) / M1

S5 (SOFT OFF) / M1 LOW HIGH LOW

HIGH

HIGH HIGH

LOW HIGH HIGH

ICH9-M

S3 (Suspend to RAM) / M-OFF

S4 (Suspend to DISK) / M-OFF HIGH

S5 (SOFT OFF) / M-OFF

LOW HIGH HIGH

LOW LOW

LOW LOW LOW

0

1

2

3

4

5

6

7

Side pair Top / left

Side pair bottom / left

Reserved

Reserved

WLAN

Mini Card (WWAN)

Mini Card (WPAN)

Express Card

PM TABLE

C C

State

S0

S3

+3.3V_ALW +1.8V_SUS

+3.3V_RTC_LDO

+3.3V_WLAN

power
plane

+5V_ALW

+15V_ALW

ON

+0.9V_DDR_VTT

+1.8V_LOM

+3.3V_LAN

+3.3V_SUS

+5V_SUS

ON ON

ON

+1.05V_VCCP

+1.25V_RUN

+1.5V_CARD

+1.5V_RUN

+3.3V_CARD

+3.3V_CARDAUX

+3.3V_R5C832

+3.3V_RUN

+3.3V_RUN_CARD

+2.5V_RUN

+5V_MOD

+5V_RUN

+5V_SPK_AMP

+CPU_PWR_SRC

+VCC_CORE

+VDDA

OFFON

+DC_IN

+DC_IN_SS

+PWR_SRC

+RTC_CELL

ON

ON

ECE 5011

8

9

10

11

1

2

3

USB W/ E-SATA port

TV

Reserved

Camera

None

None

None

S5 S4/AC

B B

S5 S4/AC don't exist

ON

OFF

OFF

OFF

OFF

OFF

ON

ON

PCI EXPRESS

Lane 1

PCI TABLE

PCI DEVICE IDSEL

R5C833

A A

5

REQ#/GNT#

REQ#0 / GNT#0AD23

PIRQ

PIRQB: 1394
PIEQC: Card reader

4

3

Lane 2

Lane 3

Lane 4

Lane 5

Lane 6

4

DESTINATION

MINI CARD-1 WWAN

MINI CARD-2 WLAN

MINI CARD-3 WPAN

Express Card

None

LOM

2

None

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

COMPUTER

Power statu

Power statu

Power statu

RM2 2A

RM2 2A

RM2 2A

1

of

of

of

58 59Tuesday, July 15, 2008

58 59Tuesday, July 15, 2008

58 59Tuesday, July 15, 2008

5

http://hobi-elektronika.net

4

RM1 Power Design Block Diagram

3

2

1

2008/03/014

SI4835

D D

Power Jack

+DC_IN

+DC_IN_SS

Adapter input

Charger

MAX8731A

Pag 47

V_CHG

SI4835

Primary Battery

C C

+1.8V_SUS

RUN_ON

+5V_ALW

+3.3V_ALW +3.3V_RUN

B B

+3.3V_ALW +3.3V_SUS

SUS_ON

+5V_ALW +5V_SUS

RUN_ON

RUN_ON

SUS_ON

FDS6298

Pag 55

SI4800BDY

Pag 55

FDS8880_NL

Pag 55

FDC655BN

Pag 55

SI4800BDY

Pag 55

+1.8V_RUN

+5V_RUN

SUS POWER

RUN POWER
PLANE
SWITCH

SI4835

+PWR_SRC

+5V_ALW2(for +3.3V_ALW)

SUS_ON

DDR POWER

TPS51116

RUN_ON

TPS51116/LDO

RUN_ON

GFX_RUN_ON

+1.5V_DDR

IMVP_VR_ON

5V_ALW_ON

Pag 49

RUN_ON

+5V_ALW

+5V_ALW

N&S BRIDGE
POWER

TPS51117

Pag 48

+5V_SUS

N&S BRIDGE
POWER

MAX8632ETI+

Pag 52

MAX8632/LDO

+5V_ALW

+5V_SUS +3.3V_SUS

CPU POWER

ISL6262

TWO PHASE
SOLUTION

Pag 51

+5V_VCC1

SYSTEM POWER

ISL6237

Pag 50

+1.5V_DDR

1.5VDDR_PWRGD

+0.75V_DDR_VTT

1.05V_RUN_PWRGD

+1.05V_VCCP

+1.8V_SUS

GFX_CORE_PWRGD

+VCC_GFX_CORE

GFX_PCIE_PWRGD

+1.1V_GFX_PCIE

IMVP_PWRGD

+VCC_CORE

+5V_ALW

+3.3V_ALW

+5V_ALW2

+15V_ALW

3V_ALW_PWRGD

5V_ALW_PWRGD

L6935TR

RUN_ON

+1.5V_RUN

SUS_ON

A A

N&S BRIDGE
POWER

TPS51117

1.8V_SUS_PWRGD

+1.8V_SUS

Pag 53

QUANTA

QUANTA

QUANTA
COMPUTER

COMPUTER

COMPUTER

Title

Title

Title

Power Block Diagram

Power Block Diagram

Power Block Diagram

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

RM2 2A

RM2 2A

5

4

RM2 2A

Date: Sheet

Date: Sheet

3

2

Date: Sheet

59 59Tuesday, July 15, 2008

59 59Tuesday, July 15, 2008

59 59Tuesday, July 15, 2008

of

of

1

of

A

http://hobi-elektronika.net

MODEL

RM2 MB
with MV

4 4

3 3

2 2

1 1

REV CHANGE LIST

Pre

DATE

2008/03/05

2008/03/06

2008/03/10

2008/03/11

2008/03/12

2008/03/14

2008/03/17

2008/03/18

2008/03/20

2008/03/21

2008/03/24

Base on the schematic of "GM5- 0226-3.DSN"

CPU socket

P3,P4 use RM1(NV) CPU socket

DIMM fr om DDR2 to DDR3

P6,P15,P16 DIMM from DDR2 to DDR3 as RM1(NV)

VRAM from DDR2 t o DDR3

P23,P24 VRAM from DDR2 to DDR3 as RM1(NV)

HDMI function

P6,P25 delete parts of HDMI for UMA option, use RM1(NV) connector

DP function

P25 adding DP related part from RM1(NV), need to connect all signals

LCD panel

P6,P26 delete UMA option, use RM1(NV) connector & related parts

CRT

P6,P27 delete UMA option, use RM1(NV) connector and adding sync & SMBus ESD parts

1394

P29 use RM1(NV) connector

Card Reader

P30 use RM1(NV) connector, need re-connect signals

Express Card

P30 use RM1(NV) connector

FLASH/ RTC/ CIR

P32 use RM1(NV) parts, CIR need On/Off control (CIR-ON/OFF#) ?

WPAN, WWAN, WL AN

P33, P34 use RM1(NV) connector & nut, add WWAN LED as RM1(NV)

USB & eSATA & TV

P35 all the same with RM1(NV), need to re-connect all signals

HDD & ODD (SATA)

P11, P36 all the same with RM1(NV), delete SATA 4 for original 2nd HDD

KB/ CCD/ UI

P31, 37 use the same KB/CCD/Daughter Board with RM1, delete KSO17 & KSO18 &NUM_LED#, remember to re-connect all signals

LED

P31,P37,P38 delete original BATLED2; need to add BAT LED on Power Button board through DB; base on RM1's LED circuit & change Barrel LED from active low to active high

FAN /THERMAL

P39 use the same parts with RM1

Audio & Subwoofer & IB connector

P40~42 follow original RM1's; remember to add LED functi on on IB connector & board and re-connect USB signals

LAN

P43, P44 use RM1's transformer & RJ45 & related parts

Card Reader

P28~30 use RM1(NV) schematic, need re-connect signals

Express Card

P28~30 use RM1(NV) schematic, need re-connect signals

WPAN, WWAN, WL AN

P33~34 use RM1(NV) schematic, need re-connect signals

CRT

P27 use RM1(NV) schematic, need re-connect signals

remove reserved UMA circuit

P05~P10 remove reserved UMA circuit with "FM7MB_A1A_0227_DIS.DSN" reference

P31 depop Cap 1uF of "ITE8512IX_JX" for IT8512E/JX as ITE's review
P26 pop 0 ohm for DPST support from GPU

remove reserved UMA circuit

P31 remove reserved UMA circuit with "FM7MB_A1A_0227_DIS.DSN" reference

Codec update & WLP4.0 support from IDT suggestion

P40,41, update Codec to "AL73C1X5B01(rev B1)"; add 2.2K & 220p for HP as WLP4.0 from IDT suggestion

traces re-connect

P19, P28, P30, P33, P34, P35, P37, P42

P45, change power of ICH_PWRGD AND Gate from +3.3V_ALW to +3.3V_SUS for i ts glitch issue
P9, add 0 ohm, move "+VCCA_MPLL_L" as Intel CRB(373319, Rev 1.0)
P35, change eSATA traces name from SATA 2 to SATA 5 as GM5
P31, delete unused "USB_R_SIDE_EN#"

Power circuit update

P55, P56, rename Page 56 to Page 59; rename Page 55 to Page 56
P47~P55, update power circuit as "RM1 WITH MV_0312.DSN"

DIMM fr om DDR2 to DDR3

P6,P8,P9 change +1.8V_SUS to +1.5V_DDR of NB for DDR3 from DDR2

GM5-0311 schematic update f or issue fix

P25, change HDMI_DET serial Res. from 0 ohm to 10K
P31, delete 1U for the backdrive issue of IT8512E/JX when initial

P47~P55, update power circuit as "RM1MB_M86_A1A_0312 FOR 256MB(MV)_A.DSN"
P45, change Res of PWRGD logic power from 10K to 0 ohm

VRAM from DDR2 t o DDR3

P22~P24, update circuit as AMD M86 CRB "ref133-8.pdf"

P9, change C1020 from 7343(ESR=18m) to 3528(ESR=45m)
P47~P55, update power circuit as "RM1MB_M86_A1A_0314 FOR 256MB(MV)_2.DSN"
P44, reserve EMI Cap for LAN signals

HDMI & DP

P19, P25, update circuit by referring AMD M86 CRB "ref133-8.pdf"

P6, no UMA, delete HDA for UMA HDMI
P6, P15 PM_EXTTS#0 for DIMM1 event, PM_EXTTS#1 for DIMM2 event

Intel review

P3, P6, P8, P9, P14, P15, P17, P38, P51, update as Intel review list "Customer_schematics_review_DELL_0318.XLS"

P34, add trace name of debug Mini card
P47~P55, update power circuit as "RM2MB_M86_A1A_0318 FOR 256MB_1.DSN"
P19,P25, DP update & refer XM1(Nike) schematic for DP power issue
P11, delete IHDA for UMA HDMI
P12,P17,P57~P60, add Mini PCI debug at P57, original P57~P59 renamed with plus one page
P11, P35, P36, move SATA TX Cap from ICH to device side as Intel ICH Spec
P45, replace 1.25V_RUN_PWRGD by 1.8V_SUS_PWRGD; 1.5V_SUS_PWRGD by 1.5V_RUN_PWRGD
P31, delete GPIO ADAPT_TRIP_SEL & CIR_ON/OFF# & ADAPT_OC
P48, P50~P53 update power circuit as "RM2MB_M86_A1A_0320 FOR 256MB_1.DSN"

P31, BID update, change CHIPSET_ID1 to BID2; del DIS & UMA select ID
update connector P/N & footprint as "Paltrow_GGCL_EE_032108_Gur.xls"
P35, change eSATA re-driver IC from 3201 to 3211 as FM7
P37, change pin definition of to DB connector as IM3
P31, replace WIRELESS_ON/OFF# by AUDIO_AVDD_ON at EC pin 108
P42, add Front Side LED at IB connector (MB side) pin 15~18

TV tuner

P35, change CN19 from 4 to 10 pins for adding TV GPIO
P37, change CN7 from 20 to 14 pins for deleting LED & adding TV GPIO

USB charge

P35, add "USB_CHG_DET#" at CN29 pin 8 for USB charge detect
P31, add "USB_CHG_DET#" at EC pin 76

AMD review (update as"Dell Paltrow RM 2 M86XT Review Mar20_2008_Gur.doc")

P25, change CN14 to pin14 from GND to test PAD; add 499 ohm to GND for AUX_SINK_P
P27, +3.3V_RUN to +3.3V_DELAY for CRT RGB & DDC

P31, add DIS & UMA select ID back ; add test PAD for NC pins
P22~24, add MAA12 & MAB12 to reserve 32Mx32 GDDR usage
P48~P50, P53, P55, update power circuit as "RM2MB_M86_A1A_0321 FOR 256MB_1.DSN"
P29, change 1394 CONN for 1394 board, remember to update footprint

Intel review

P14, update as Intel review list "Customer_schematics_review_DELL_rev2.2_Gur.xls"

B

C

D

E

Model

RM2 MB with MV

Page FROM TO

1

2A

2

2A

3

2A

4

2A

5

2A

6

2A

7

2A

8

2A

9

2A

10

2A

11

2A

12

2A

13

2A

14

2A

15

2A

16

2A

17

2A

18

2A

19

2A

20

2A

21

2A

22

2A

23

2A

24

2A

25

2A

26

2A

27

2A

28

2A

29

2A

30

2A

31

2A

32

2A

33

2A

34

2A

35

2A

36

2A

37

2A

38

2A

39

2A

40

2A

41

2A

42

2A

43

2A

44

2A

45

2A

46

2A

47

2A

48

2A

49

2A

50

2A

51

2A

52

2A

53

2A

54

2A

55

2A

56

2A

57

2A

58

2A

59

2A

QUANTA

COMPUTER

A

PROJECT : RM2 DOC. NO. 204

APPROVED BY : Roger Chen

B

CHECKED BY : Roger Chen

REV:

2A

REV:

2A

REV:

2A

C

D

ASSY: 31RM2MB0000

DATE : SHEET OFDRAWN BY :

Mar., 24, 2008 1 4Guresu Lo

DATE : SHEET OFDRAWN BY :

Mar., 24, 2008 1 4Guresu Lo

DATE : SHEET OFDRAWN BY :

Mar., 24, 2008 1 4Guresu Lo

E

A

http://hobi-elektronika.net

MODEL

RM2 MB
with MV

4 4

3 3

2 2

1 1

REV CHANGE LIST

Pre

QUANTA

COMPUTER

A

DATE

2008/03/25

2008/03/26

2008/03/27

2008/03/28

2008/03/31

2008/04/01

2008/04/02

2008/04/03

2008/04/07

2008/04/08

2008/04/09

2008/04/10

2008/04/11

2008/04/14

2008/04/15

P56, remove original GM5 stitching Cap*5 & Spring*3
P46, update screw hole as mail "rm2 hole footprint ( 0325, 6:15PM)"
P11, change as RM1's for layout space limitation
update connector P/N & footprint as "Paltrow_GGCL_EE_032508_Gur.xls"

TV tuner module

P35, change bluk Cap of TV power from 1U to 10U
P35, as TV tuner vendor suggestion, exchange GPIO1 & 2 ; exchange USB signals ; connect pin 9 & 10 to GND

P18~P22, change AMD GPU from M86 LP to M86-ME XT A11
P15, P16, delete stitch Cap used for RM1 layout
P47~P55, update power circuit as "RM2MB_M86_A1A_0325 FOR 256MB_1.DSN"
P09, add trace name "+VCCA_SM" for layout

LAN from 5787 to 5784

P43, P44, update from 5787 to 5784, check support items

All page, change CC0402-FM6 to CC0402, RC0402-FM6 to RC0402; change R738, R741, R748 from CC0402-C to RC0402-C
P34, change SIM card back as RM1's
P20, add trace name +VDDCI
P19, update VRAM table & set configuration to 1111
P31, delete R1134 & "ADP_OC" for "IINP" for double reserved 0 ohm

Biometric de-feature

P12, P37, del USB 10, check re-arrange pin of DB connector

P47~P55, update power circuit as "RM2MB_M86_A1A_0327A FOR 256MB_1.DSN"
P22~P24, reserve MAA12, MAB12, CSAx_1# & CSBx_1# for 32Mx32 GDDR3, default set Non Merged & 1CS mode

Biometric de-feature

P28, del USB 10 & power of Biometric for de-feature, and re-arrange pin

H/P HDMI failure, foll ow "FM6-HDMI DDC test issue 0326.ppt"

P25, change D47 to 0_0805, change PU Res to 2.2K from 6.8K
P55, H/P HDMI failure, change R1261 from 1K to 47 ohm, and pop R1261 & Q121 for back drive solution

P31, P43, change "LAN_DISABLE#" to "LAN_DISABLE" for high active
P46, delete H23, H24, H27, H28, H29, H30
P52, update power circuit as "RM2MB_M86_A1A_0328 FOR 256MB_1.DSN"
P22, change GPU thermal SMBus from 2 to 0 for MMB FW ISSP Flash support
P19, R23, R24 update VRAM table & P/N to set Hynix(16Mx32) as default

Change by layout requirement

P15, P16, swap as "a788.1257a_ddr_swap_0331.xls"
P23, swap as "a788.1257a_vrma_swap_0329.xls"

Silego review

P17, update as "RM2_Silego Suggestion.pdf"
P17, delete R927, double reserved PD of PCI_ICH

P33, P34, change footprint of Mini Card nut from "MININUT-5028HB25" to "h-tc138bc236d55p2"
P38, change BAT LED Power from +5V_ALW2 to +3.3V_ALW ; add L-C f ilter (R-C) as EMI request
P25, reserve level shift for HDMI as HDMI issue on H/P

Intel review

P14, update as Intel review list "Customer_schematics_review_DELL_rev2.3_Gur.xls"

IDT review

P41, change C1456, C1457, C1458 and C1459 to 270Pfrom 220P; change C675, C676, C718, C719 from 2.2U to 10U

AMD review

P23, P24, update to 2CS, non-Merged mode for 32Mx32 GDDR3

change LAN to 5784 only

P43, P44, delete option for 5787, use 5784 only

P12, P13, swap as "a788.1257a_swap_0402_Gur.xls"
P35, change pin definition of CN19 for cable making process concern
P19, update VRAM table & config default GDDR3 is Samsung 32Mx32 ; VRAM size from 256M to 512M as default

RICOH review

P29, delete reserved C839 (0.01u), not necessary

P1, update Block Diagram
update connector P/N & footprint as "Paltrow_GGCL_EE_040308_Gur.xls"
P35, update library of RF Jack

P22~24, delete reserved MAA12/B12 for 2CS mode only.
P43, connect SUPER_IDDQ to GND directly
P26, delete Pin 59~62 of CN2 for footprint change
P31, change PU of "BREATH_LED#" & "BAT_LED#" from +5V_ALW2 to +3.3V_ALW

Intel review

P09, delete reserved +1.5V circut, connect +VCCD_TVDAC directly to GND ; delete reserved R798 PD Res of +VCCD_QDAC

Broadcom review

P43, update as "RM2_schematic_review_0407_Gur.doc"

P13, 25, 29, 35, swap as "a788.1257a_swap_0407.xls"
P34, update library as SIM card pin definition
P48, 49, 50, 52 ,53 ,55, update power circuit as "RM2MB_M86_A1A_0407 FOR 512MB_1.DSN"
P22, P50, add MOS to shutdown system 3/5V by GPU thermal trip
P46, P56, P57, P60, delete P56 "EMI CAP (blank page)", move P57 (Mini PCI) to P56 and P60 (SMBus) to P57; add 6 spring at P46
P29, P33, P34, P46, update connector P/N & footprint as "Paltrow_GGCL_EE_040808_Gur.xls"

P29, change CN35 library (to 1394 board) from 4 to 8 pins

MMB ISSP support

P31, P37 reserve circuit for MMB ISSP support

P23, P24 swap as "a788.1257a-vrma-swap-0410_Gur.xls"
P35, add hi-pot Cap for RF signal
P46, change from h-236d118p2 to h-tc197bc236d118p2

Internal review

P45, P50, P52, change 3V/5V_ALW_PWRGD to GFX PWRGD for PWRGD monitor change
P14, del reserve +1.5V_RUN and 0 ohm*1 & 0.1u*1
P23, P24, pop R1299, R1302, R1307, R1310 for 32Mx32
P28, del R605, connect CLK_PCI_PCCARD directly
P35, del R583, R474 for double PU to +3.3V_SUS with ICH
P01, P57, update Block Diagram & SMBus Block

P37, IDT check, change series Res of DMIC_CLK from 0 to 22 ohm
P17, add bead on BSEL0 & BSEL2 for EMI noise of 48M & 14M
P47, 48, 49, 50, 52 ,54, update power circuit as "RM2MB_M86_A1A_0410A FOR 512MB_1.DSN"
P37, update library of CN7 to add shield GND
P45, delete R1230 0 ohm to connect directly; change U87 & U92 from 74AHCT1G08GW to 74AHC1G08GW for working power issue, AHCT is 4.5~5.5V, AHC is 2~5.5V
P36, delete reserved 0_0805 to +5V_RUN of HDD & ODD power for layout concern

Intel review

P14, change back to 1U_0603_X5R from 0.1u_0402_X7R for V5REF decouping Cap; change series Res from 100 to 10 ohm for V5REF_SUS

Add temporary DP dongle support circuit f or DP function test

P25, add temporary DP dongle support circuit for DP function test at PT stage

P47, 49, 52, 53 ,55, update power circuit as "RM2MB_M86_A1A_0411 FOR 512MB_1.DSN"
P29, update connector P/N & footprint as "Paltrow_GGCL_EE_041108_Gur.xls"
Delete all test PAD which footprint is "PAD-VIA20D10A25TMP", T65,T70,T71,T72,T73,T74,T75,T76,T83,T84,T85,T86,T87,T88,T89,T90,T127,T128,T129,T130,T131,T132,T133,T134,T135,T136,T149,T150,T151,T152,T153,
T154,T155,T156,T160,T161,T163,T164,T175,T176,T177,T178,T179,T180,T181,T182,T183,T184,T185,T186,T187,T188,T189,T190,T191,T192,T193,T194,T196,T197,T198,T199,T200,T201,T204,T205,T266,T285,T286,T287,
T288,T289

P19, P38 delete repeat Res, R977 (series 0 ohm) with Page 31; R1181 (PU, 100K) with Page 38

GM5 update (0411 schematic)

P3, update BSEL table
P6, del R751 to prevent back driver(from +5V_ALW2 to +1.05_VCCP) when stuffed

P28, change IDSEL from PCI_AD23 to AD17 as FM7 & GM5
P41, pop 100K, depop 0 ohm for "AUD_AMP_MUTE#" as FM7 & GM5

Intel review

P03, Intel review, change R660 from 68 to 56 ohm as check list 2.0
P06, add circuit for SM_PWROK of DDR3

Brodacom review

P43, BCM review, delete R1185 & R1187 by power directly connecting to save cost

PROJECT : RM2 DOC. NO. 204

APPROVED BY : Roger Chen

B

CHECKED BY : Roger Chen

B

C

REV:

2A

REV:

2A

REV:

2A

C

D

ASSY: 31RM2MB0000

DATE : SHEET OFDRAWN BY :

Apr., 15, 2008 2 4Guresu Lo

DATE : SHEET OFDRAWN BY :

Apr., 15, 2008 2 4Guresu Lo

DATE : SHEET OFDRAWN BY :

D

Apr., 15, 2008 2 4Guresu Lo

E

Model

RM2 MB with MV

Page FROM TO

1

2A

2

2A

3

2A

4

2A

5

2A

6

2A

7

2A

8

2A

9

2A

10

2A

11

2A

12

2A

13

2A

14

2A

15

2A

16

2A

17

2A

18

2A

19

2A

20

2A

21

2A

22

2A

23

2A

24

2A

25

2A

26

2A

27

2A

28

2A

29

2A

30

2A

31

2A

32

2A

33

2A

34

2A

35

2A

36

2A

37

2A

38

2A

39

2A

40

2A

41

2A

42

2A

43

2A

44

2A

45

2A

46

2A

47

2A

48

2A

49

2A

50

2A

51

2A

52

2A

53

2A

54

2A

55

2A

56

2A

57

2A

58

2A

59

2A

E

A

http://hobi-elektronika.net

MODEL

RM2 MB
with MV

4 4

3 3

2 2

1 1

REV CHANGE LIST

Pre

2A(PT)

2B(PT)

2C(PT)

2D(ST)

2E(ST)

QUANTA

COMPUTER

A

DATE

2008/04/16

2008/04/17

2008/04/18

2008/04/18

2008/04/23

2008/04/24

2008/04/28
2008/05/02

2008/05/14

2008/05/29

2008/06/16

2008/06/19

2008/06/20

2008/06/24

2008/07/10

2008/07/14

P17, remove bead of BSEL0 & 2 for layout space concern

P1, update Block Diagram
P29, update library of CON1 to delete pin 48 & 49 (to GND)
P51 (after rename), pop PQ10 & PQ11, depop PQ1 & PQ2

Rename

P48, update power circuit as "RM2MB_M86_A1A_0417 FOR 512MB_1.DSN"
P31, BOM change for RP23 from "CJ310042N02" to "CJ310042N11"
P32, delete RTC battery "UBM2" for assembly process change

First Release

All pages, change revision form 1A to 2A for RM2 start from PT stage
P44, change footprint of RJ45 from "rj 45-2006250-13p-v-rm2" to "rj45-2006250-13p-h-rm2.

P01, change Ver. from 2A to 2B; adding Dell PWA, PWB, SCH P/N
P26, delete Pin 57, 58 of CN4 for new footprint

Update for AMD Po werPlay

P52, update power circuit as "RM2MB_M86_A1A_0418A FOR 512MB_1.DSN"
P19, pop R287 and separate "GFX_CORE_CNTRL" to ""GFX_CORE_CNTRL0" & "GFX_CORE_CNTRL1"

P48, update power circuit as "RM2MB_M86_B2B_0423 FOR 512MB_1.DSN"
P20, change reserved U10 from "74AHCT1G08GW" to "74AHC1G08GW" for logic power level issue

P4, pop C558 & depop C562 for mechanical interference concern

Badge LED don't light enough issue

P38, change R112 from 100K (CS41002JB20) to 220 (CS12202JB24) ; change R91 from 100K (CS41002JB20) to 150 (CS11502JB22) ; change R416 & R418 from 220 (CS12202JB24) to 0 ohm (CS00002JB38)

P1, change ver. from 2B to 2C
P14, change L15 from "CV-1008MZ14" to "CV-1001TN09"
P35, delete bypass Res. of eSATA

MMB ISSP backdrive issue

P37, reserve a MOS for +MMB_PWR backdrive when ISSP

LAN 10M & 100M LED reversed and LAN footprint update

P44, exchange CN15 pin 11 & 13 for LAN 10M & 100M LED reversed; change RJ45 footprint from "rj45- 2006250-13p-h-rm2" to "rj45-2006250-13p-v-rm2.

P46, change H14, H15, H19, H20 from "h-c236d197p2" to "H-C236D158P2"; change from "h-tc197bc236d118p2" to "H-T295X280B236D118P2"; change H30 from "h-c157d157n" to "H-C197D118P2"

for IB cable cost down from coxial to FFC type

P42, change CN5 from 30 to 32 pin for cable cost down from coxial to FFC type

P1, change ver. from 2C to 2D
P31, pop R637 & depop R640 for BID update from 1000 to 1001
P11, change C622 & C623 from 10pF to 15pF as TXC's validation.
P40, change U40 from AL73C1X5B02 to AL73C1X5B03 for Rev. from B2 to C1.
P43, change +2.5V_LOM to +1.2V_VDDC_IO & LAN_REGCTL25 to LAN_REGOUT12_IO to avoid confusion.
P46, change PV4~PV6 from FDZD3002010 to FDRM2002010 as ME's request

S3/S5 leakage

P28, R31, depop R654 for S3 leakage issue, and supplier indicate it's no need for R5C833; pop R652 as GM5, no leakage concern as test
P49, change PR121 PU from +3.3V_ALW to +3.3V_SUS for S5 leakage issue
P38, change design, add U52, R714 & U53, delete Q11, R416 & R418

Derating issue

P9, change L70(91nH, 1.5A) to 0_0805

P42, change CN5 from 32 FFC to 32 coxial connector for IB cable change
P35, del JP1, FS1, JP2, FS3 for direct USB SW power
P35, del C520 & add R715~R718 & change GND to RF_GND for TV layout ; del CN2 to disable internal antenna support
P46, depop PV2 & PV4 as ME request

XPS_Premium_LED_colors_behavior v3 3.xl s

P38, depop Q16, R100, U2, R109 of Power button board Amber LED as "XPS_Premium_LED_colors_behavior v3 3.xls"

MMB ISSP fail

P31, change RP22 from 2.2K to 10K for ISSP fail

Power issue (update as "RM2MB_M86_D2D_0616 FOR 512M B_1.DSN")

P47, Change PQ18,PQ25 to SI4835DDY-T1-E3 due to SI4835BDY-T1-E3 EOL; Change PL4 to SIL104R-5R8B due to SIL104R-5R8PF EOL; Change PR47 to short jumper; Remove 0R PR58
P48, Change PR97 from 15.8K to 13.3K for WCEPTA; Remove PR65 and PR64, directly connect pin6 to GND; Change PR31 to short jumper
P49, Remove PR65 and PR64, directly connect pin6 to GND; Depop PC56,PC57; Change PR48 from 15.4K to 11.32K for WCEPTA; Change PR56 to short jumper; Change PL5 to SIL104R-1R5B due to SIL104R-1R5PF EOL
P50, Remove 0R PR173; Change PR157 to short jumper; Remove 0R PR164; Remove 0R PR165 and PR166;
P51, Remove 0R PR11,PR13,PR15,PR86,PR16,PR18,PR19,PR22,PR90; Change PR84 to 4.02K; Change PR91 to short jumper; Andy_0617: Depop PC15,PC16
P52, Remove 0R PR125; Change PR113 to 82K; Change PR105 to 61.9K; Change PR126 to short jumper
P53, Change PR61 to short jumper; Change PL7 to SIL104R-1R5B due to SIL104R-1R5PF EOL
P54, Change to SI4835DDY-T1-E3 due to SI4835BDY-T1-E3 EOL

EMI Solution for Power as "RM2M B_M86_D2D_0619 FOR 512MB_1.DSN"

P47, Add FL8 for EMI solution
P50, Change PC176 from 0.1u to 1u by FEA suggestion
P54, Add PC194,PC195,PC196 for EMI solution

Derating issue

P9, as EMI request, change from R713 0_0805 to L70 "CX31P121001(120 ohm, 3A)"

P31, del R623 & "ICH_PME#" to connect "PLTRST#" to R652; add PD 1K for RESET_OUT#
P46, depop PV3, PV5 & PV6 as ME request; add PAD PV7, PV8 & PV9 & hole H34; change screw hole from " * " to " *-8 " for H26, H33, G23, H32, H21, H10, H7, H2, H1, H9, H22, H11, H18, H30 & H8
P41, change R286 from 0_0603 to 0_0805, depop R83, R301, R110, R543, R450 &R544
P38, add pin 4 & 5 for CN3 & CN10 to connect to GND
P42, change CN5 from 32 to 30 pin & change pin assignment for cable manuf acture
P30, change CN12 from "EXPCARD-1CX41101-PL-26P-L" to "expcard-1cx41101-pl-26p-l-rm2"
P54, change CN24 from "DFHD09MR017(SUYIN)" to "DFHD09MR024(FOXCONN)" as ME's information
P9,P11,P13,P20, change footprint from RC0402-C to RC0402 or CC0402-C to CC0402 for R247, R496, R489, R524, R525, C726, C728, C741, C624, C689
P3, depop R56 for abnormal H_RESET#

Combo USB EA fail - change USB Bus SW

P35, change U17 from "AL0USB31003" to "AL004907000"; del R345 & add C520 for support item

NB(Cantiga) & SB(ICH9M) P/N change

P5~P14, change NB from "AJ0QT780T08" to "AJSLB970T13(ver B3)"; change SB from "AJ0QT090T06" to "AJSLB8Q0T16(ver A3)"

For 2nd source BOM creation problem

P9, P26, P27,P38, P44, change Q63 from "BAM34560102" to "BAM06550025"; change D17 from "BCRB500VZ02" to "BC010K45004"; change D10 from "BC000501Z09" to "BC010K45004"; change D4 & D7 from
"BC000751Z05" to "BC000340033"; change Q20 from "BA001140Z08" to "BA001140001"

P1, change ver. from 2D to 2E
P47, update power circuit as "RM2MB_M86_D2D_0624 FOR 512MB_1.DSN"
P13,P51 depop PR1 & pop R159 for change IMVP_PWRGD PU from +3.3V_SUS & +3.3V_RUN
P42, change back CN5 from 30 pin coaxial to 32 pin FFC & change pin assignment for FFC implement; add CN32 for additional AGND
P20, add two more 10uF for +VCC_GFX_CORE ripple
P15,P34,P35, change ESD1~3 from ALSRV054011 to AL000504000 for EOL concern
P34, change SIM card connector to push-push type, CN26 from DG006001404 to DG006000020
P25, reserve R723 for option when remove DP dongle support

ST Internal Doc. 0703-1 update

P48, change PU3 from AL009194000 to AL009024000.
P38, change R127 from 220 to 1K; R90,R107,R101,R119 from 220 to 3.3K as IM3

XPS_Premium_LED_colors_behavior v3 7.xl s (no Amber LED & charge indicator on power button LED)

P37, del "BAT_LED_INT" as "XPS_Premium_LED_colors_behavior v3 7.xls"
P38, change power of R113 & U31 from +5V_ALW2 to +5V_SUS, no charge indicator ; del Q16, R100, U2, R109 of Power button board Amber LED

Subwoofer overload & band filter and mai n SPK EQ issue fix as "PALTROW EQ CIRCUIT rev 3.pptx"

P41, circuit change for main SPK EQ as "PALTROW EQ CIRCUIT rev 3.pptx"
P42, circuit change for subwoofer overload & band filter issue as "PALTROW EQ CIRCUIT rev 3.pptx"

add KB LED detect pin

P13, del T59 & add "KB_LED_DET"
P37, del +15V_ALW, add KB_LED_DET & R721, R722

P25, change DP connector footprint from "DP-47644-0001-20P-L-H" to "dp-r sd-47644-001-20p-l-h"
P20,P21, add "-C" on footprint for C867,C868,C427,C417,C405,C395,C401,C379,C367,L38,C356,C358,L39,C389
P46, update library for " *-8 " for H26, H33, G23, H32, H21, H10, H7, H2, H1, H9, H22, H11, H18, H30 & H8

debug port code "52" issue when "MEDIA_INT#" isn't high at system boot

P37, add R724, move PU of "MEDIA_INT#" to MB side

reserve Hall IC on MB side for opti on & study

P37, add U54, C869, R726 & reserve R725 for study of Hall IC on MB

PROJECT : RM2 DOC. NO. 204

APPROVED BY : Roger Chen

B

CHECKED BY : Roger Chen

B

C

REV:

2E

REV:

2E

REV:

2E

C

D

ASSY: 31RM2MB0000

DATE : SHEET OFDRAWN BY :

Jul., 14, 2008 3 4Guresu Lo

DATE : SHEET OFDRAWN BY :

Jul., 14, 2008 3 4Guresu Lo

DATE : SHEET OFDRAWN BY :

D

Jul., 14, 2008 3 4Guresu Lo

E

Model

RM2 MB with MV

Page FROM TO

1

2E

2

2A

3

2D

4

2B

5

2D

6

2D

7

2D

8

2D

9

2D

10

2D

11

2D

12

2D

13

2E

14

2D

15

2E

16

2A

17

2A

18

2A

19

2B

20

2E

21

2E

22

2A

23

2A

24

2A

25

2E

26

2D

27

2D

28

2D

29

2A

30

2D

31

2D

32

2A

33

2A

34

2E

35

2E

36

2A

37

2E

38

2E

39

2A

40

2D

41

2E

42

2E

43

2D

44

2D

45

2A

46

2E

47

2E

48

2E

49

2D

50

2D

51

2E

52

2D

53

2D

54

2D

55

2A

56

2A

57

2A

58

2A

59

2A

E

A

http://hobi-elektronika.net

MODEL

RM2 MB
with MV

4 4

3 3

2 2

1 1

REV CHANGE LIST

2E(ST)

3A(QT)

DATE

2008/07/15

2008/07/21

2008/08/08

2008/08/14

Subwoofer overload & band filter and mai n SPK EQ issue fix as "PALTROW EQ CIRCUIT rev 5.pptx"

P41, circuit change for main SPK EQ as "PALTROW EQ CIRCUIT rev 5.pptx"

P37, depop R602 & pop Q70, Q86, R603 to temporarily enable ISSP circuit for need.
P55, change PC73 from 4700p to 0.047U for GFX power sequence

LED fine tune

P37, P38 change R708,R90,R107,R101,R119 from 220/3.3K to 2.49K; change R91 from 150 to 100 as IM3

P1, change ver. from 2E to 3A and PCB from E to F.
P31, depop R636 & R637 and pop R634 & R640 for BID update from 1001 to 1010
P44, change transformer from "H5120NL(for I ntel LAN chip)" to "H5120BNL(for Broadcom LAN chip)".
P45, reserve option for U47 power to +3.3V_ALW
P47~P55, update power circuit as "RM2MB_M86_E2E_0721 FOR 512MB_1.DSN"
P3, P4, P36, P37, P46, P54, update connector P/N & footprint as "Paltrow_GGCL_EE_080808_Gur.xls"

Remove ITP reserve

P3, depop R38 to let ITP_TDO "No connect" as check list 2.0 ; delete reserved ITP by deleting JITP1, C49, C50, R39, R42, R43 ; delete trace of ITP_BPM#[0:5]
P17, delete reserved ITP clock & ITP_EN circuit

EMI solution implement

P25, depop R393~R400, pop L56~L59 with "CXCG900U000"
P27, change C2~C4 from 5.6p to 10p ; C7~C9 from 5.6p to 22p
P38, pop C547, C548, C786, C787 with 2200p

0 ohm removal for QT entr ance (orange circle)

P3, 5, 6, 9, 11, 13~20, 23~26, 29, 31, 33, 34, 38~40, 42, 43, 45 remove 0 ohm as "0 ohm removal(RM2)-0807.xls"

+3.3V_ALW have a glitch issue when unplug AC outlet or DC cable

P50, update power circuit as "RM2MB_M86_E2E_0721 FOR 512MB_2.DSN" for adding Zener Diode and change PR155=82.5K, PR156=200K

no inside TV antenna

P35, P37, delete signal TV_GPIO1 & 2; change CN9 from 14 to 10 pins

P35, change P/N & footprint & library for non-swit ch RF Jack
P50, change PR155 from 82.5K to 68K as Andy's informati on
P37 change R722 to connect to R721 from pin1 to pin2
P22, change U33 from ADM1032ARMZ to ADM1032ARMZ-1RL
P46, delete H27

B

C

D

E

Model

RM2 MB with MV

Page FROM TO

1

3A

2

2A

3

3A

4

3A

5

3A

6

3A

7

2D

8

2D

9

3A

10

2D

11

3A

12

2D

13

3A

14

3A

15

3A

16

3A

17

3A

18

3A

19

3A

20

3A

21

2E

22

3A

23

3A

24

3A

25

3A

26

3A

27

3A

28

2D

29

3A

30

2D

31

3A

32

2A

33

3A

34

3A

35

3A

36

3A

37

3A

38

3A

39

3A

40

3A

41

2E

42

3A

43

3A

44

3A

45

3A

46

3A

47

3A

48

3A

49

3A

50

3A

51

3A

52

3A

53

3A

54

3A

55

3A

56

2A

57

2A

58

2A

59

2A

QUANTA

COMPUTER

A

PROJECT : RM2 DOC. NO. 204

APPROVED BY : Roger Chen

B

CHECKED BY : Roger Chen

REV:

3A

REV:

3A

REV:

3A

C

D

ASSY: 31RM2MB0000

DATE : SHEET OFDRAWN BY :

Aug., 14, 2008 4 4Guresu Lo

DATE : SHEET OFDRAWN BY :

Aug., 14, 2008 4 4Guresu Lo

DATE : SHEET OFDRAWN BY :

Aug., 14, 2008 4 4Guresu Lo

E
