Quanta AT8 DA0AT8MB8F0, Pavilion dv9700, AT8 DA0AT8MB8H6 Schematic
1
2
3
4
5
6
7
8
PCB STACK UP
LAYER 1 : TOP
LAYER 2 : SGND1
AA
LAYER 3 : IN1
RUN POWER
SW
PG 36,37
AC/BATT
CONNECTOR
BATT
CHARGER
PG 34
PG 34
Turion64
Sempron
LAYER 4 : IN2
LAYER 5 : VCC
DDRII-SODIMM1
PG 5
LAYER 6 : IN3
LAYER 7 : SGND2
DDRII-SODIMM2
PG 5
LAYER 8 : BOT
Cable
BB
Docking
VGA
RJ-45
CIR/Pwr btn
TV_OUT
Mini PCI-E Card
PCI Express Mini Card
(Wireless LAN/WAN)
PG 27
DDRII 667mhz
DDRII 667mhz
PCI-E
Express Card
(NEW CARD)
PG 28
25W/35W
AMD Socket S1 638P
PG 2,3,4
HT Link
nVIDIA
C51M/D
Integraded VGA Function
468PIN
PCI-Express 16X
TV_OUT
CRT_OUT
SPDIF Out
LVDS(2 Channel)
PG 31
Stereo MIC
Headphone Jack
USB Port
VOL Cntr
SIM CARD
Option for 17" only
SATA - HDD
PG 27
PG 28
CLOCK
INTERFACE
SATA2
PG 6,7,8
HT Link
nVIDIA
MCP51M
508PIN
PATA
SATA0
(66/100/133)
PG 15,16,17
SATA - HDD
CC
PATA-
PG 26
CD-ROM
PG 26
LPC
Keyboard
3
PG 29
PG 23
PG 29
ENE KBC
KB3920 Bx
FAN
PG 31
4
PG 30
X-Bus
Flash
AUDIO
Amplifier
PG 25
Jack to
Speaker
PG 25
PG 30
5
Touch Pad
VAULE DEFINE
A=0603,B=0805,C=1206,F=1%,
OTHER IS 0402
EXAMPLE
DD
10R=10ohm(0402)
10A=10ohm(0603)
CIR
Capacitive Sense
SW
10B=10ohm(0805)
10C=10ohm(1206)
10/F=10ohm(0402 and 1%)
1
2
CPU VR
PG 38
DC/DC
+3VSUS
+5VSUS
PG 33
USB2.0
Bluetooth
PG 28
USB2.0 I/O Ports
X3
PCI BUS / 33MHz
LAN
Azalia
Conexant
Venice AMOM
CX20549-12
PG 23
MDC DAA
PG 24
MODEM RJ 11
PG 20
Altlantis/Apollo
Block Diagram
NVDIA G3-64 for 15.4"
NVDIA G3-128 for 17"
Graphics
CRT/S-VIDEO
Panel Connector
15" / 17"
PCI ROUTING
TABLE
REQ0# / GNT0#
6
PG 9,10,11,12,13,14
PG 19
PG 18
PG 26
Two-element
microphone
PG 23
Audio Jacks
(Phone/SPDIF/
MIC)
PG 23
NB5/RD2/HW1
Camera
1.3MP
PG 23
Mini PCI-E Card x1
Express Card x1
Cable Docking x1
REALTEK
RTL8201CL
(10/100)/
REL8211B
(10/100 /Gigabit)
PG 20
RJ45
PG 20
IDSEL
INTERUPT
AD21
INTA#,INTB#
PROJECT : AT8
Quanta Computer Inc.
SizeDocument NumberRev
Custom
Block Diagram
Date:Sheet of
7
Option for 17" only
HDMI CON
PG 18
RICOH
RICOH 832
PG 21
IEEE1394
CONN
Memory
CardReader
PG 21
DEVICE
RICOH832
138Thursday, December 29, 2005
8
PG 22
1A
PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com
1
HT_RXD[15..0]6
C703.22U
C7064.7UA
C7024.7UA
C704.22U
AA
BB
HT_CPU_UPCLK06
HT_CPU_UPCLK16
HT_CPU_UPCLK#06
HT_CPU_UPCLK#16
HT_CPU_UPCTL06
1.2V_HT
HT_CPU_UPCTL#06
R43549.9F
R43449.9F
HT_RXD#[15..0]
HT_RXD[15..0]
1.2V_HT
1.2V_HT
1.2V_HT
HT_RXD0
HT_RXD1
HT_RXD2
HT_RXD3
HT_RXD4
HT_RXD5
HT_RXD6
HT_RXD7
HT_RXD8
HT_RXD9
HT_RXD10
HT_RXD11
HT_RXD12
HT_RXD13
HT_RXD14
HT_RXD15
HT_RXD#0
HT_RXD#1
HT_RXD#2
HT_RXD#3
HT_RXD#4
HT_RXD#5
HT_RXD#6
HT_RXD#7
HT_RXD#8
HT_RXD#9
HT_RXD#10
HT_RXD#11
HT_RXD#12
HT_RXD#13
HT_RXD#14
HT_RXD#15
HT_CPU_UPCLK0
HT_CPU_UPCLK1
HT_CPU_UPCLK#0
HT_CPU_UPCLK#1
HT_CPU_UPCTL0
HT_CPU_UPCTL1
HT_CPU_UPCTL#1
HT_RXCTL1/HT_RXCRL#1 MUST <1.5" FROM CPU PIN
THERM_ALERT#
1
2
3V
LM86_SMC
LM86_SMD
LM86_SMC
R642.7K
3V
MBCLK30,34
R632.7K
R72*10K
3V
R7310K
3V
RHU002N06
3
Q8
CC
THERM_OVER#17
MBCLK/MBDATA NEED PU TO 3VPCU
D1
D2
D3
D4
E3
E1
G3
G1
J1
L3
L1
N3
E5
F3
G5
H3
K3
L5
M3
N5
E2
F1
G2
H1
K1
L2
M1
N2
F5
F4
H5
H4
K4
M5
M4
P5
J3
J5
J2
K5
N1
P3
P1
P4
R62200R
3V
LM86_SMD5
2
U26A
V_HT0_A1
V_HT0_A2
V_HT0_A3
V_HT0_A4
HT_RXD0
HT_RXD1
HT_RXD2
HT_RXD3
HT_RXD4
HT_RXD5
HT_RXD6
HT_RXD7
HT_RXD8
HT_RXD9
HT_RXD10
HT_RXD11
HT_RXD12
HT_RXD13
HT_RXD14
HT_RXD15
HT_RXD#0
HT_RXD#1
HT_RXD#2
HT_RXD#3
HT_RXD#4
HT_RXD#5
HT_RXD#6
HT_RXD#7
HT_RXD#8
HT_RXD#9
HT_RXD#10
HT_RXD#11
HT_RXD#12
HT_RXD#13
HT_RXD#14
HT_RXD#15
HT_RXCLK0
HT_RXCLK1
HT_RXCLK#0
HT_RXCLK#1
HT_RXCTL0
HT_RXCTL1
HT_RXCTL#0
HT_RXCTL#1
AMD S1 SOCKET
U1
8
SCLK
7
SDA
6
ALERT#
4
OVERT#
MAX6657
G781P8
ADDRESS: 98H
LM86_SMC5
LM86_SMD
HT_TXD[15..0]6HT_RXD#[15..0]6
HT_TXD#[15..0]6
V_HT0_B1
V_HT0_B2
V_HT0_B3
V_HT0_B4
HT_TXD0
HT_TXD1
HT_TXD2
HT_TXD3
HT_TXD4
HT_TXD5
HT_TXD6
HT_TXD7
HT_TXD8
HT_TXD9
HT_TXD10
HT_TXD11
HT_TXD12
HT_TXD13
HT_TXD14
HT_TXD15
HT_TXD#0
HT_TXD#1
HT_TXD#2
HT_TXD#3
HT_TXD#4
HT_TXD#5
HT_TXD#6
HT_TXD#7
HT_TXD#8
HT_TXD#9
HT_TXD#10
HT_TXD#11
HT_TXD#12
HT_TXD#13
HT_TXD#14
HT_TXD#15
HT_TXCLK0
HT_TXCLK1
HT_TXCLK#0
HT_TXCLK#1
HT_TXCTL0
HT_TXCTL1
HT_TXCTL#0
HT_TXCTL#1
6648VCC
1
VCC
2
DXP
3
DXN
5
GND
1
AE2
AE3
AE4
AE5
AD1
AC2
AB1
AA2
W2
V1
U2
T1
AD4
AD5
AB4
AB5
Y5
V4
V5
T4
AC1
AC3
AA1
AA3
W3
U1
U3
R1
AD3
AC5
AB3
AA5
W5
V3
U5
T3
Y1
Y4
W1
Y3
R2
T5
R3
R5
C88.1U
Q9
RHU002N06
2
3V
3
HT_TXD[15..0]
HT_TXD#[15..0]
1.2V_HT
1.2V_HT1.2V_HT
1.2V_HT
1.2V_HT
1.2V_HT
HT_TXD0
HT_TXD1
HT_TXD2
HT_TXD3
HT_TXD4
HT_TXD5
HT_TXD6
HT_TXD7
HT_TXD8
HT_TXD9
HT_TXD10
HT_TXD11
HT_TXD12
HT_TXD13
HT_TXD14
HT_TXD15
HT_TXD#0
HT_TXD#1
HT_TXD#2
HT_TXD#3
HT_TXD#4
HT_TXD#5
HT_TXD#6
HT_TXD#7
HT_TXD#8
HT_TXD#9
HT_TXD#10
HT_TXD#11
HT_TXD#12
HT_TXD#13
HT_TXD#14
HT_TXD#15
HT_CPU_DWNCLK0
HT_CPU_DWNCLK1
HT_CPU_DWNCLK#0
HT_CPU_DWNCLK#1
HT_CPU_DWNCTL0
HT_CPU_DWNCTL1
HT_CPU_DWNCTL#1
10/20mils
CPU_THERMDA
C120
2200P/X7R
CPU_THERMDC
3
MBDATA30,34
C7074.7UA
C705180P/50V
C709180P/50V
HT_CPU_DWNCLK06
HT_CPU_DWNCLK16
HT_CPU_DWNCLK#06
HT_CPU_DWNCLK#16
HT_CPU_DWNCTL06
T157
HT_CPU_DWNCTL#06
T156
4
TEST PU/PL MUST
FOLLOW ERRATUM
133
REVISION GUIDE
FROM AMD NPT
0Fh CPU
MUST KEEP LOW DURING S3-S5 TO MEET HT IO LINK SPEC
HT LINK CONTROL LEVEL SHIFTERCPU THERMAL SENSOR & CONTROL
HTCPU_RST#6
HTCPU_PWRGD6
HTCPU_STOP#6
FOLLOW AMD AND NVIDIA RECOMMEND
1.8VSUS
1.8VSUS
CPU_SID
CPU_SIC
If AMD SI is not used
SID can be left, SIC
300ohm to VSS.
ECPWROK17,30
ECPWROK
ECPWROK
ROUTE TRACES 80OHM DIFF
IMPEDENCE 8/5/20 SPACING
R428*300R
R427*300R
R422300R
5
T14
T158
T2
T164
T1
T159
T12
T9
T5
T3
T7
R58300R
R53300R
T162
R48300R
T165
T160
T161
R55510F
R49510F
R429300R
T169
T4
T6
R5280.6F
1.8VSUS
1.8VSUS
U25
2
1
74LVC1G08GW
3 5
1.8VSUS
U28
2
1
74LVC1G08GW
3 5
1.8VSUS
U24
2
1
74LVC1G08GW
3 5
CPUTEST2
CPUTEST3
CPU_THERMDA
CPU_THERMDC
CPUTEST6
CPUTEST7
CPUTEST8
CPUTEST10
CPUTEST12
CPUTEST14
CPUTEST15
CPUTEST16
CPUTEST17
CPUTEST18
CPUTEST19
CPUTEST20
CPUTEST21
CPUTEST22
CPUTEST23
CPUTEST24
CPUTEST25
CPUTEST25#
CPUTEST26
CPUTEST27
CPUTEST28
CPUTEST28#
FBCLKOUT
FBCLKOUT#
HTCPU_RST1#
4
HTCPU_PWROK1
4
HTCPU_STOP1#
4
W18
AB6
AA6
AC8
AA7
H10
AF7
AB8
AE8
AD7
AE7
AE6
AF8
H19
H18
N20
P20
P19
N19
P22
R26
Y6
W8
W7
C3
C4
C2
K8
C7
F7
E7
D7
G9
E9
E8
J7
H8
C9
C8
B3
D5
U26E
TEST2
TEST3
THERMDA
THERMDC
TEST6
TEST7
TEST8
TEST9
TEST10
TEST12
TEST13
TEST14
TEST15
TEST16
TEST17
TEST18
TEST19
TEST20
TEST21
TEST22
TEST23
TEST24
TEST25
TEST25#
TEST26
TEST27
TEST28
TEST28#
TEST29
TEST29#
RSVD_1
RSVD_2
RSVD_3
RSVD_4
RSVD_5
RSVD_6
RSVD_7
RSVD_8
RSVD_9
RSVD_10
RSVD_11
AMD S1 SOCKET
6
VDDA_1
VDDA_2
RESET#
PWROK
LDTSTOP#
HTREF0
HTREF1
VDD_FB
VDD_FB#
VDDIO_FB
VDDIO_FB#
CLKIN
CLKIN#
DBRDY
DBREQ#
TMS
TCK
TRST#
TDO
CPU_PRESENT#
PSI#
VID0
VID1
VID2
VID3
VID4
VID5
PROCHOT#
THERMTRIP#
RSVD_12
RSVD_13
RSVD_14
RSVD_15
RSVD_16
RSVD_17
RSVD_18
RSVD_19
RSVD_20
RSVD_21
7
W/S= 15 mil/20mil
CPU2.5V
TDI
SID
SIC
C43.22U
CPU2.5VCPU2.5V
F9
CPU2.5VCPU2.5V
F8
HTCPU_RST1#
B7
HTCPU_PWROK1
A7
HTCPU_STOP1#
F10
CPUHTREF0
R6
CPUHTREF1
P6
CPU_CORE_FB
F6
CPU_CORE_FB#
E6
CPU_SUS_FB
W9
Y9
CPUCLKIN
A9
CPUCLKIN#
A8
CPU_DBRDY
G10
CPU_DBRDY#
E10
CPU_TMS
AA9
CPU_TCK
AC9
CPU_TRST#
AD9
CPU_TDI
AF9
CPU_TDO
AE9
CPU_PRES#
AC6
A3
CPU_VID0_L
B5
CPU_VID1_L
C5
CPU_VID2_L
A4
CPU_VID3_L
A6
CPU_VID4_L
C6
CPU_VID5_L
A5
CPU_SID
AF5
CPU_SIC
AF4
CPU_PROCHOT#
AC7
CPU_THERMIP#
AF6
R22
H16
R23
R25
B18
R24
C1
H6
KEEP TRACE RESISTOR <0.6" FROM CPU
G6
AA8
AND TRACE TO AC CAP <1.25"
CPUVID1 PU REQUIRED
FOR COMPATIBILITY WITH
FUTURE CPU
CPU_THERMIP#
PLACE CLOSE CPU
L80FBMJ3216HS800-T
C7124.7UA
C523300P/X7R
CPUCLKIN
CPUCLKIN#
R457*300R
R460*300R
R450*300R
R43744.2F
R43644.2F
T173
T170
T39
T31
T18
T167
T174
T176
T175
R4251K
R33*300R
R30300R
R21*300R
R37*300R
R31*300R
R23*300R
R426300R
R433300R
C7163900P
C7143900P
R446169F
OVER TEMP CONTROL
Q35
PDTC144EU
1 3
1.8VSUS
100U/6032
1.2V_HT
CPU_CORE_FB38
CPU_CORE_FB#38
CPU_SUS_FB37
1.8VSUS
CPU_PSI#38
CPUCLKINCPUCLKIN#
2
2.5V
C711
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
CPU_CLK6
CPU_CLK#6
MCP_THERMIP#17
THERM_ALERT#
D31CH500H
R4234.7K
CPU OT THERM IC THERMTRIP TO SHUTDOWN SYS FROM SB
1 3
EC_PROCHOT#30
DIMM_THEM#5
D29
CH500H
D30
*CH500H
CPU_PROCHOT#THERM_OVER#
Q36
PDTC144EU
2
3V
CPU PROCHOT INPUT FROM THERMAL IC OR SODIMM SENSOR
8
02
3V
NEED TO CONFIRM NVIDIA FOR THE USAGE CONNECTION TO SB
5
R400R
3
Q5
*RHU002N06
Q3
*RHU002N06
3
R390A
R442*8.2K
2.5V
1
2
2
1
R32*4.7K
R35*4.7K
CPU_VID517,38
6
CPU_VID417,38
3V
3V
NB5/RD2/HW1
R441*34.8KF
PROJECT : AT8
Quanta Computer Inc.
SizeDocument NumberRev
Custom
CPU(HT_LINK /CTL)
Date:Sheet of
7
CPU_FETGATE
238Thursday, December 29, 2005
8
1A
R190A R430A
CPU_VID1_L CPU_VID3_L CPU_VID4_L
DD
CPU_FETGATE CPU_FETGATE
CPU_VID0_L CPU_VID2_L CPU_VID5_L
3
Q4
*RHU002N06
Q6
*RHU002N06
3
R380R
1
1
2
2
1
R20*4.7K
R36*4.7K
CPU_VID017,38
CPU_VID117,38
3V
3V
2
Q7
*RHU002N06
Q2
*RHU002N06
3
3
2
2
3
R180A
1
R34*4.7K
R22*4.7K
1
CPU_VID317,38
3V
3V
CPU_VID217,38
4
CPU_FETGATE
PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com
1
M_A_DQ63
AA12
M_A_DQ62
AB12
M_A_DQ61
AA14
M_A_DQ60
AB14
M_A_DQ59
W11
M_A_DQ58
M_A_DQ57
AD13
M_A_DQ56
AB13
M_A_DQ55
AD15
M_A_DQ54
AB15
M_A_DQ53
AA
BB
CC
M_A_DQ52
M_A_DQ51
M_A_DQ50
M_A_DQ49
M_A_DQ48
M_A_DQ47
M_A_DQ46
M_A_DQ45
M_A_DQ44
M_A_DQ43
M_A_DQ42
M_A_DQ41
M_A_DQ40
M_A_DQ39
M_A_DQ38
M_A_DQ37
M_A_DQ36
M_A_DQ35
M_A_DQ34
M_A_DQ33
M_A_DQ32
M_A_DQ31
M_A_DQ30
M_A_DQ29
M_A_DQ28
M_A_DQ27
M_A_DQ26
M_A_DQ25
M_A_DQ24
M_A_DQ23
M_A_DQ22
M_A_DQ21
M_A_DQ20
M_A_DQ19
M_A_DQ18
M_A_DQ17
M_A_DQ16
M_A_DQ15
M_A_DQ14
M_A_DQ13
M_A_DQ12
M_A_DQ11
M_A_DQ10
M_A_DQ9
M_A_DQ8
M_A_DQ7
M_A_DQ6
M_A_DQ5
M_A_DQ4
M_A_DQ3
M_A_DQ2
M_A_DQ1
M_A_DQ0
M_A_A15
M_A_A14
M_A_A13
M_A_A12
M_A_A11
M_A_A10
M_A_A9
M_A_A8
M_A_A7
M_A_A6
M_A_A5
M_A_A4
M_A_A3
M_A_A2
M_A_A1
M_A_A0
AB17
W14
W16
AD17
AD19
AD21
AB21
AB18
AA18
AA20
AA22
W21
W22
AA21
AB22
AB24
U26B
MA_DATA[63]
MA_DATA[62]
MA_DATA[61]
MA_DATA[60]
MA_DATA[59]
Y12
MA_DATA[58]
MA_DATA[57]
MA_DATA[56]
MA_DATA[55]
MA_DATA[54]
MA_DATA[53]
Y17
MA_DATA[52]
Y14
MA_DATA[51]
MA_DATA[50]
MA_DATA[49]
MA_DATA[48]
Y18
MA_DATA[47]
MA_DATA[46]
MA_DATA[45]
MA_DATA[44]
MA_DATA[43]
MA_DATA[42]
MA_DATA[41]
Y20
MA_DATA[40]
MA_DATA[39]
Y22
MA_DATA[38]
MA_DATA[37]
MA_DATA[36]
MA_DATA[35]
MA_DATA[34]
MA_DATA[33]
Y24
MA_DATA[32]
H22
MA_DATA[31]
H20
MA_DATA[30]
E22
MA_DATA[29]
E21
MA_DATA[28]
J19
MA_DATA[27]
H24
MA_DATA[26]
F22
MA_DATA[25]
F20
MA_DATA[24]
C23
MA_DATA[23]
B22
MA_DATA[22]
F18
MA_DATA[21]
E18
MA_DATA[20]
E20
MA_DATA[19]
D22
MA_DATA[18]
C19
MA_DATA[17]
G18
MA_DATA[16]
G17
MA_DATA[15]
C17
MA_DATA[14]
F14
MA_DATA[13]
E14
MA_DATA[12]
H17
MA_DATA[11]
E17
MA_DATA[10]
E15
MA_DATA[9]
H15
MA_DATA[8]
E13
MA_DATA[7]
C13
MA_DATA[6]
H12
MA_DATA[5]
H11
MA_DATA[4]
G14
MA_DATA[3]
H14
MA_DATA[2]
F12
MA_DATA[1]
G12
MA_DATA[0]
K19
MA_ADD[15]
K20
MA_ADD[14]
V24
MA_ADD[13]
K24
MA_ADD[12]
L20
MA_ADD[11]
R19
MA_ADD[10]
L19
MA_ADD[9]
L22
MA_ADD[8]
L21
MA_ADD[7]
M19
MA_ADD[6]
M20
MA_ADD[5]
M24
MA_ADD[4]
M22
MA_ADD[3]
N22
MA_ADD[2]
N21
MA_ADD[1]
R21
MA_ADD[0]
AMD S1 SOCKET
2
Y13
MA_DM[7]
AB16
MA_DM[6]
Y19
MA_DM[5]
AC24
MA_DM[4]
F24
MA_DM[3]
E19
MA_DM[2]
C15
MA_DM[1]
E12
MA_DM[0]
W12
MA_DQS[7]
Y15
MA_DQS[6]
AB19
MA_DQS[5]
AD23
MA_DQS[4]
G22
MA_DQS[3]
C22
MA_DQS[2]
G16
MA_DQS[1]
G13
MA_DQS[0]
W13
MA_DQS#[7]
W15
MA_DQS#[6]
AB20
MA_DQS#[5]
AC23
MA_DQS#[4]
G21
MA_DQS#[3]
C21
MA_DQS#[2]
G15
MA_DQS#[1]
H13
MA_DQS#[0]
E16
MA0_CLK[1]
MA0_CLK[2]
MA_BANK[2]
MA_BANK[1]
MA_BANK[0]
MA_RAS#
MA_CAS#
MA_WE#
MA0_CS#[3]
MA0_CS#[2]
MA0_CS#[1]
MA0_CS#[0]
MA_CKE[1]
MA_CKE[0]
MA0_ODT[1]
MA0_ODT[0]
F16
Y16
AA16
K22
R20
T22
T20
U20
U21
V19
J22
V22
T19
J20
J21
V20
U19
MA0_CLK#[1]
MA0_CLK#[2]
3
M_A_DQM7
M_A_DQM6
M_A_DQM5
M_A_DQM4
M_A_DQM3
M_A_DQM2
M_A_DQM1
M_A_DQM0
M_A_DQS7
M_A_DQS6
M_A_DQS5
M_A_DQS4
M_A_DQS3
M_A_DQS2
M_A_DQS1
M_A_DQS0
M_A_DQS#7
M_A_DQS#6
M_A_DQS#5
M_A_DQS#4
M_A_DQS#3
M_A_DQS#2
M_A_DQS#1
M_A_DQS#0
M_A_CK1
M_A_CK1#
M_A_CK2
M_A_CK2#
M_A_BA2
M_A_BA1
M_A_BA0
M_A_RAS#
M_A_CAS#
M_A_WE#
M_A_CS#3
M_A_CS#2
M_A_CS#1
M_A_CS#0
M_A_CKE1
M_A_CKE0
M_A_ODT1
M_A_ODT0
Tolerance is
+-10%
C1251.5P
C1271.5P
TRACE FROM CAP TO CPU MUST BE LESS
THAN 1200MILS MAX NECKDOWN TO &
FROM CAPS IS 500MILS
4
M_A_CLK15
M_A_CLK1#5
M_A_CLK25
M_A_CLK2#5
M_B_DQ63
M_B_DQ62
M_B_DQ61
M_B_DQ60
M_B_DQ59
M_B_DQ58
M_B_DQ57
M_B_DQ56
M_B_DQ55
M_B_DQ54
M_B_DQ53
M_B_DQ52
M_B_DQ51
M_B_DQ50
M_B_DQ49
M_B_DQ48
M_B_DQ47
M_B_DQ46
M_B_DQ45
M_B_DQ44
M_B_DQ43
M_B_DQ42
M_B_DQ41
M_B_DQ40
M_B_DQ39
M_B_DQ38
M_B_DQ37
M_B_DQ36
M_B_DQ35
M_B_DQ34
M_B_DQ33
M_B_DQ32
M_B_DQ31
M_B_DQ30
M_B_DQ29
M_B_DQ28
M_B_DQ27
M_B_DQ26
M_B_DQ25
M_B_DQ24
M_B_DQ23
M_B_DQ22
M_B_DQ21
M_B_DQ20
M_B_DQ19
M_B_DQ18
M_B_DQ17
M_B_DQ16
M_B_DQ15
M_B_DQ14
M_B_DQ13
M_B_DQ12
M_B_DQ11
M_B_DQ10
M_B_DQ9
M_B_DQ8
M_B_DQ7
M_B_DQ6
M_B_DQ5
M_B_DQ4
M_B_DQ3
M_B_DQ2
M_B_DQ1
M_B_DQ0
M_B_A15
M_B_A14
M_B_A13
M_B_A12
M_B_A11
M_B_A10
M_B_A9
M_B_A8
M_B_A7
M_B_A6
M_B_A5
M_B_A4
M_B_A3
M_B_A2
M_B_A1
M_B_A0
5
AD11
AF11
AF14
AE14
AB11
AC12
AF13
AF15
AF16
AC18
AF19
AD14
AC14
AE18
AD18
AD20
AC20
AF23
AF24
AF20
AE20
AD22
AC22
AE25
AD26
AA25
AA26
AE24
AD24
AA23
AA24
W25
M26
N23
N24
N25
N26
Y11
G24
G23
D26
C26
G26
G25
E24
E23
C24
B24
C20
B20
C25
D24
A21
D20
D18
C18
D14
C14
A20
A19
A16
A15
A13
D12
E11
G11
B14
A14
A11
C11
J25
J26
L23
L25
U25
L24
L26
P24
P26
T24
U26C
MB_DATA[63]
MB_DATA[62]
MB_DATA[61]
MB_DATA[60]
MB_DATA[59]
MB_DATA[58]
MB_DATA[57]
MB_DATA[56]
MB_DATA[55]
MB_DATA[54]
MB_DATA[53]
MB_DATA[52]
MB_DATA[51]
MB_DATA[50]
MB_DATA[49]
MB_DATA[48]
MB_DATA[47]
MB_DATA[46]
MB_DATA[45]
MB_DATA[44]
MB_DATA[43]
MB_DATA[42]
MB_DATA[41]
MB_DATA[40]
MB_DATA[39]
MB_DATA[38]
MB_DATA[37]
MB_DATA[36]
MB_DATA[35]
MB_DATA[34]
MB_DATA[33]
MB_DATA[32]
MB_DATA[31]
MB_DATA[30]
MB_DATA[29]
MB_DATA[28]
MB_DATA[27]
MB_DATA[26]
MB_DATA[25]
MB_DATA[24]
MB_DATA[23]
MB_DATA[22]
MB_DATA[21]
MB_DATA[20]
MB_DATA[19]
MB_DATA[18]
MB_DATA[17]
MB_DATA[16]
MB_DATA[15]
MB_DATA[14]
MB_DATA[13]
MB_DATA[12]
MB_DATA[11]
MB_DATA[10]
MB_DATA[9]
MB_DATA[8]
MB_DATA[7]
MB_DATA[6]
MB_DATA[5]
MB_DATA[4]
MB_DATA[3]
MB_DATA[2]
MB_DATA[1]
MB_DATA[0]
MB_ADD[15]
MB_ADD[14]
MB_ADD[13]
MB_ADD[12]
MB_ADD[11]
MB_ADD[10]
MB_ADD[9]
MB_ADD[8]
MB_ADD[7]
MB_ADD[6]
MB_ADD[5]
MB_ADD[4]
MB_ADD[3]
MB_ADD[2]
MB_ADD[1]
MB_ADD[0]
AMD S1 SOCKET
MB_DM[7]
MB_DM[6]
MB_DM[5]
MB_DM[4]
MB_DM[3]
MB_DM[2]
MB_DM[1]
MB_DM[0]
MB_DQS[7]
MB_DQS[6]
MB_DQS[5]
MB_DQS[4]
MB_DQS[3]
MB_DQS[2]
MB_DQS[1]
MB_DQS[0]
MB_DQS#[7]
MB_DQS#[6]
MB_DQS#[5]
MB_DQS#[4]
MB_DQS#[3]
MB_DQS#[2]
MB_DQS#[1]
MB_DQS#[0]
MB0_CLK[1]
MB0_CLK#[1]
MB0_CLK[2]
MB0_CLK#[2]
MB_BANK[2]
MB_BANK[1]
MB_BANK[0]
MB_RAS#
MB_CAS#
MB_WE#
MB0_CS#[3]
MB0_CS#[2]
MB0_CS#[1]
MB0_CS#[0]
MB_CKE[1]
MB_CKE[0]
MB0_ODT[1]
MB0_ODT[0]
VTT_SENSE
M_VREF
M_ZN
M_ZP
6
AD12
AC16
AE22
AB26
E25
A22
B16
A12
AF12
AE16
AF21
AC25
F26
A24
D16
C12
AE12
AD16
AF22
AC26
E26
A23
C16
B12
A17
A18
AF18
AF17
K26
T26
U26
U24
V26
U22
Y26
J24
W24
U23
H26
J23
W23
W26
Y10
W17
AE10
AF10
M_B_DQM7
M_B_DQM6
M_B_DQM5
M_B_DQM4
M_B_DQM3
M_B_DQM2
M_B_DQM1
M_B_DQM0
M_B_DQS7
M_B_DQS6
M_B_DQS5
M_B_DQS4
M_B_DQS3
M_B_DQS2
M_B_DQS1
M_B_DQS0
M_B_DQS#7
M_B_DQS#6
M_B_DQS#5
M_B_DQS#4
M_B_DQS#3
M_B_DQS#2
M_B_DQS#1
M_B_DQS#0
TRACE FROM CAP TO CPU MUST BE LESS
THAN 1200MILS MAX NECKDOWN TO &
FROM CAPS IS 500MILS
M_B_CK1
M_B_CK1#
M_B_CK2
M_B_CK2#
M_B_BA2
M_B_BA1
M_B_BA0
M_B_RAS#
M_B_CAS#
M_B_WE#
M_B_CS#3
M_B_CS#2
M_B_CS#1
M_B_CS#0
M_B_CKE1
M_B_CKE0
M_B_ODT1
M_B_ODT0
VTERM_FB
C51M_VREF
MEMZN
MEMZP
?mil
C1401.5P
C7311.5P
Tolerance is
+-10%
R45839.2F
R46139.2F
VTERM_FB37
7
1.8VSUS
1000P/X7R
M_B_CLK15
M_B_CLK1#5
M_B_CLK25
M_B_CLK2#5
C151
1.8VSUS
C139
.1U
8
03
R79
2KF
R77
2KF
M_A_DQ[63..0]5 M_A_DQM[7..0]5
M_A_A[15..0]4,5
DD
M_A_DQ[63..0]
M_A_A[15..0]
M_A_DQM[7..0]
M_A_DQS[7..0]
M_A_DQS#[7..0]
M_A_BA[2..0]
M_A_CS#[3..0]
M_A_RAS#
M_A_CAS#
M_A_WE#
M_A_CKE1
M_A_CKE0
M_A_ODT1
M_A_ODT0
M_A_DQS[7..0]5
M_A_DQS#[7..0]5
M_A_BA[2..0]4,5
M_A_CS#[3..0]4,5
M_A_RAS#4,5
M_A_CAS#4,5
M_A_WE#4,5
M_A_CKE14,5
M_A_CKE04,5
M_A_ODT14,5
M_A_ODT04,5
M_B_DQ[63..0]5
M_B_A[15..0]4,5
M_B_DQ[63..0]
M_B_A[15..0]
M_B_DQM[7..0]
M_B_DQS[7..0]
M_B_DQS#[7..0]
M_B_BA[2..0]
M_B_CS#[3..0]
M_B_RAS#
M_B_CAS#
M_B_WE#
M_B_CKE1
M_B_CKE0
M_B_ODT1
M_B_ODT0
M_B_DQM[7..0]5
M_B_DQS[7..0]5
M_B_DQS#[7..0]5
M_B_BA[2..0]4,5
M_B_CS#[3..0]4,5
M_B_RAS#4,5
M_B_CAS#4,5
M_B_WE#4,5
M_B_CKE14,5
M_B_CKE04,5
M_B_ODT14,5
M_B_ODT04,5
C51MVREF : W =20MIL AND SPACE = 20MIL
PROJECT : AT8
Quanta Computer Inc.
SizeDocument NumberRev
Custom
1
2
3
4
5
6
NB5/RD2/HW1
CPU(MEM/IF)
Date:Sheet of
7
338Thursday, December 29, 2005
8
1A
PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com
1
VCC_CORE
VCC_CORE
C6922UB/X7R
C6822UB/X7R
C10522UB/X7R
C49.01U
C47.22U
C48.22U
C64180PA/50V
C7122UB/X7R
C10322UB/X7R
AA
BB
CC
C10222UB/X7R
C7022UB/X7R
C4422UB/X7R
C10422UB/X7R
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
VCC_CORE
AC4
AD2
M10
M16
N11
R11
U11
U13
U15
G4
H2
J9
J11
J13
J15
K6
K10
K12
K14
K16
L4
L7
L9
L11
L13
L15
M2
M6
M8
N7
N9
P8
P10
P16
R4
R7
R9
T2
T6
T8
T10
T12
T14
T16
U7
U9
V6
V8
V10
V12
V14
V16
W4
Y2
2
U26D
VDD1
VDD2
VDD3
VDD4
VDD5
VDD6
VDD7
VDD8
VDD9
VDD10
VDD11
VDD12
VDD13
VDD14
VDD15
VDD16
VDD17
VDD18
VDD19
VDD20
VDD21
VDD22
VDD23
VDD24
VDD25
VDD26
VDD27
VDD28
VDD29
VDD30
VDD31
VDD32
VDD33
VDD34
VDD35
VDD36
VDD37
VDD38
VDD39
VDD40
VDD41
VDD42
VDD43
VDD44
VDD45
VDD46
VDD47
VDD48
VDD49
VDD50
VDD51
VDD52
VDD53
VDD54
AMD S1 SOCKET
VDDIO1
VDDIO2
VDDIO3
VDDIO4
VDDIO5
VDDIO6
VDDIO7
VDDIO8
VDDIO9
VDDIO10
VDDIO11
VDDIO12
VDDIO13
VDDIO14
VDDIO15
VDDIO16
VDDIO17
VDDIO18
VDDIO19
VDDIO20
VDDIO21
VDDIO22
VDDIO23
VDDIO24
VDDIO25
VDDIO26
VDDIO27
VTT1
VTT2
VTT3
VTT4
VTT5
VTT6
VTT7
VTT8
VTT9
H25
J17
K18
K21
K23
K25
L17
M18
M21
M23
M25
N17
P18
P21
P23
P25
R17
T18
T21
T23
T25
U17
V18
V21
V23
V25
Y25
A10
AA10
AB10
AC10
AD10
B10
C10
D10
W10
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
(0.9VSUS)
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
3
1.8VSUS
C164.01U
C149.01U
C205180PA/50V
C198180PA/50V
C159.22U
C7964.7UA
C8094.7UA
C8074.7UA
C7954.7UA
C173.22U
C170.22U
C163.22U
C13022UB/X7R
C79422UB/X7R
C13822UB/X7R
C12622UB/X7R
C12922UB/X7R
C80022UB/X7R
C799.22U
SMDDR_VTERM
C392*4.7UB
C395*4.7UB
C393.1U
C802.1U
C412.1U
4
CPU POWER PLANE AND BY PASS CAP
C804.7UA
C725.22U
C614.7UA
C814.7UA
C654.7UA
C56.22U
C723.22U
C57.22U
C541000P/X7R
C551000P/X7R
C719180PA/50V
C75180PA/50V
C74180PA/50V
C718180PA/50V
C601000P/X7R
C591000P/X7R
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
AA11
AA13
AA15
AA17
AA19
AB23
AB25
AC11
AC13
AC15
AC17
AC19
AC21
AD25
AE11
AE13
AE15
AE17
AE19
AE21
AE23
AA4
AB2
AB7
AB9
AD6
AD8
B11
B13
B15
B17
B19
B21
B23
B25
D11
D13
D15
D17
D19
D21
D23
D25
H21
H23
B4
B6
B8
B9
D6
D8
D9
E4
F2
F11
F13
F15
F17
F19
F21
F23
F25
H7
H9
J4
U26F
VSS1
VSS2
VSS3
VSS4
VSS5
VSS6
VSS7
VSS8
VSS9
VSS10
VSS11
VSS12
VSS13
VSS14
VSS15
VSS16
VSS17
VSS18
VSS19
VSS20
VSS21
VSS22
VSS23
VSS24
VSS25
VSS26
VSS27
VSS28
VSS29
VSS30
VSS31
VSS32
VSS33
VSS34
VSS35
VSS36
VSS37
VSS38
VSS39
VSS40
VSS41
VSS42
VSS43
VSS44
VSS45
VSS46
VSS47
VSS48
VSS49
VSS50
VSS51
VSS52
VSS53
VSS54
VSS55
VSS56
VSS57
VSS58
VSS59
VSS60
VSS61
VSS62
VSS63
VSS64
VSS65
AMD S1 SOCKET
VSS66
VSS67
VSS68
VSS69
VSS70
VSS71
VSS72
VSS73
VSS74
VSS75
VSS76
VSS77
VSS78
VSS79
VSS80
VSS81
VSS82
VSS83
VSS84
VSS85
VSS86
VSS87
VSS88
VSS89
VSS90
VSS91
VSS92
VSS93
VSS94
VSS95
VSS96
VSS97
VSS98
VSS99
VSS100
VSS101
VSS102
VSS103
VSS104
VSS105
VSS106
VSS107
VSS108
VSS109
VSS110
VSS111
VSS112
VSS113
VSS114
VSS115
VSS116
VSS117
VSS118
VSS119
VSS120
VSS121
VSS122
VSS123
VSS124
VSS125
VSS126
VSS127
VSS128
VSS129
5
6
7
8
DDR2 TERMINATION BYPASS CAP
J6
J8
J10
J12
J14
J16
J18
K2
K7
K9
K11
K13
K15
K17
L6
L8
L10
L12
L14
L16
L18
M7
M9
M11
M17
N4
N6
N8
N10
N16
N18
P2
P7
P9
P11
P17
R8
R10
R16
R18
T7
T9
T11
T13
T15
T17
U4
U6
U8
U10
U12
U14
U16
U18
V2
V7
V9
V11
V13
V15
V17
W6
Y21
Y23
SMDDR_VTERM32,37
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
CHANNEL A
C299.1U
C381.1U
C358.1U
C359.1U
C362.1U
C379.1U
C356.1U
C302.1U
Layout note: Place one cap close to every 2
pullup resistors terminated to
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
C275.1U
C277.1U
C276.1U
CHANNEL B
SMDDR_VTERMSMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
1.8VSUS
1.8VSUS
1.8VSUS
C414.1U
C298.1U
C415.1U
C409.1U
C303.1U
C410.1U
C378.1UC797.22U
C372.1U
04
DDRII CHANNEL B TERMINATIONDDRII CHANNEL A TERMINATION
M_A_BA1
M_A_A0 M_A_A12
M_A_CS#0
M_A_BA0
M_A_WE#3,5
M_A_RAS#3,5
DD
M_A_A[15..0]
M_A_CKE[1..0]
M_A_ODT[1..0]
M_A_BA[2..0]
M_A_CS#[3..0]
M_A_WE#
M_A_ODT1
M_A_CS#3
M_A_ODT0 M_B_BA0
M_A_A5
M_A_A3
M_A_A13
M_A_RAS#
M_A_CS#2 M_A_CAS#
M_A_CKE0
M_A_CKE1
M_A_A15
1
RP2347X2
RP1647X2
RP1747X2
RP2547X2
RP1447X2
RP2447X2
RP1147X2
RP1947X2
M_A_A[15..0]3,5
M_A_CKE[1..0]3,5
M_A_ODT[1..0]3,5
M_A_BA[2..0]3,5
M_A_CS#[3..0]3,5
132
132
132
132
132
132
132
132
4
4
4
4
4
4
4
4
2
M_A_CAS#3,5
M_A_BA2
M_A_A10
M_A_A1
M_A_A9
M_A_A8
M_A_A11
M_A_A14
M_A_A7
M_A_A6
M_A_A4
M_A_A2
M_A_CS#1
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
3
RP1247X2
132
132
132
132
132
132
132
C360.1U
C361.1U
C394.1U
C413.1U
C411.1U
4
4
4
4
4
4
4
RP1547X2
RP1347X2
RP2047X2
RP2147X2
RP2247X2
RP1847X2
SMDDR_VTERM SMDDR_VTERMSMDDR_VTERM SMDDR_VTERM
M_B_WE#3,5
M_B_CAS#3,5
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
SMDDR_VTERM
4
5
M_B_BA1
M_B_A4
M_B_ODT0 M_B_A0
M_B_CS#1
M_B_A3
M_B_A1
M_B_WE#
M_B_A2
M_B_A6
M_B_CAS#
M_B_ODT1
M_B_CKE1
M_B_CKE0
M_B_A11
M_B_A15
M_B_A[15..0]
M_B_CKE[1..0]
M_B_ODT[1..0]
M_B_BA[2..0]
M_B_CS#[3..0]
RP3847X2
132
RP3247X2
RP2947X2
RP3147X2
RP3747X2
RP3347X2
RP3447X2
RP3547X2
4
132
4
132
4
132
4
132
4
132
4
132
4
132
4
M_B_A[15..0]3,5
M_B_CKE[1..0]3,5
M_B_ODT[1..0]3,5
M_B_BA[2..0]3,5
M_B_CS#[3..0]3,5
6
M_B_RAS#3,5
NB5/RD2/HW1
M_B_CS#0
M_B_RAS#
M_B_A10
M_B_A12
M_B_BA2
M_B_A7
M_B_A14
M_B_A8
M_B_A5
M_B_CS#2
M_B_A9
M_B_CS#3
M_B_A13
SizeDocument NumberRev
Custom
Date:Sheet of
7
RP3947X2
132
132
132
132
132
132
132
4
4
4
4
4
4
4
RP3047X2
RP2747X2
RP3647X2
RP2847X2
RP2647X2
RP4047X2
PROJECT : AT8
Quanta Computer Inc.
CPU(POWER/GND)
438Thursday, December 29, 2005
8
1A
PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com
1
2
3
4
5
6
7
8
M_A_CKE[0..1]
M_A_CS#[0..3]
M_A_RAS#
M_A_CAS#
M_A_WE#
AA
M_A_DQ5
M_A_DQ2
M_A_DQ3
M_A_DQ0
M_A_DQ4
M_A_DQ6
M_A_DQ7
M_A_DQ9
M_A_DQ8
M_A_DQ10
M_A_DQ14
M_A_DQ13
M_A_DQ12
M_A_DQ15
M_A_DQ11
M_A_DQ17
M_A_DQ21
M_A_DQ18
M_A_DQ16
M_A_DQ20
M_A_DQ19
M_A_DQ22
M_A_DQ23
M_A_DQ24
M_A_DQ25
M_A_DQ27
M_A_DQ30
BB
M_A_DQ28
M_A_DQ29
M_A_DQ26
M_A_DQ31
M_A_A0
M_A_A1
M_A_A2
M_A_A3
M_A_A4
M_A_A5
M_A_A7
M_A_A6
M_A_A8
M_A_A9
M_A_A10
M_A_A11
M_A_A12
M_A_BA0
M_A_BA1
M_A_BA2
M_A_CLK1
M_A_CLK1#
M_A_CLK2
M_A_CLK2#
CC
DDR_SMBCLK
DDR_SMBDTA
DIM1_SA0
DIM1_SA1
M_A_CKE[0..1]3,4 M_A_CLK13
M_A_CS#[0..3]3,4
M_A_RAS#3,4
M_A_CAS#3,4
M_A_WE#3,4
5
DQ0
7
DQ1
17
DQ2
19
DQ3
4
DQ4
6
DQ5
14
DQ6
16
DQ7
23
DQ8
25
DQ9
35
DQ10
37
DQ11
20
DQ12
22
DQ13
36
DQ14
38
DQ15
43
DQ16
45
DQ17
55
DQ18
57
DQ19
44
DQ20
46
DQ21
56
DQ22
58
DQ23
61
DQ24
63
DQ25
73
DQ26
75
DQ27
62
DQ28
64
DQ29
74
DQ30
76
DQ31
102
A0
101
A1
100
A2
99
A3
98
A4
97
A5
94
A6
92
A7
93
A8
91
A9
105
A10/AP
90
89
107
106
85
30
32
164
166
197
195
198
200
199
R13810K
R13910K
A11
A12
BA0
BA1
NC/BA2
CLK0
CLK0
CLK1
CKL1
SCL
SDA
SA0
SA1
VDDSPD
2-1734073-1
CN23A
PC210 0 D DR2 SDRAM SO-D IMM
(200P)
DIM1_SA0 DIM2_SA0
DIM1_SA1
DQ32
DQ33
DQ34
DQ35
DQ36
DQ37
DQ38
DQ39
DQ40
DQ41
DQ42
DQ43
DQ44
DQ45
DQ46
DQ47
DQ48
DQ49
DQ50
DQ51
DQ52
DQ53
DQ54
DQ55
DQ56
DQ57
DQ58
DQ59
DQ60
DQ61
DQ62
DQ63
DM0
DM1
DM2
DM3
DM4
DM5
DM6
DM7
DQS0
DQS0
DQS1
DQS1
DQS2
DQS2
DQS3
DQS3
DQS4
DQS4
DQS5
DQS5
DQS6
DQS6
DQS7
DQS7
CS0
CS1
RAS
CAS
CKE0
CKE1
WE
H 9.2
123
125
135
137
124
126
134
136
141
143
151
153
140
142
152
154
157
159
173
175
158
160
174
176
179
181
189
191
180
182
192
194
10
26
52
67
130
147
170
185
13
11
31
29
51
49
70
68
131
129
148
146
169
167
188
186
110
115
108
113
109
79
80
M_A_CLK1
M_A_CLK1#
M_A_CLK2
M_A_CLK2#
M_A_BA[0..2]
M_A_ODT[0..1]
M_A_DQ32
M_A_DQ36M_A_DQ1
M_A_DQ34
M_A_DQ37
M_A_DQ33
M_A_DQ38
M_A_DQ39
M_A_DQ35
M_A_DQ40
M_A_DQ41
M_A_DQ42
M_A_DQ46
M_A_DQ44
M_A_DQ45
M_A_DQ43
M_A_DQ47
M_A_DQ55
M_A_DQ54
M_A_DQ49
M_A_DQ52
M_A_DQ48
M_A_DQ53
M_A_DQ50
M_A_DQ51
M_A_DQ57
M_A_DQ61
M_A_DQ63
M_A_DQ62
M_A_DQ56
M_A_DQ60
M_A_DQ59
M_A_DQ58
M_A_DQM0
M_A_DQM1
M_A_DQM2
M_A_DQM3
M_A_DQM4
M_A_DQM5
M_A_DQM6
M_A_DQM7
M_A_DQS0
M_A_DQS#0
M_A_DQS1
M_A_DQS#1
M_A_DQS2
M_A_DQS#2
M_A_DQS3
M_A_DQS#3
M_A_DQS4
M_A_DQS#4
M_A_DQS5
M_A_DQS#5
M_A_DQS6
M_A_DQS#6
M_A_DQS7
M_A_DQS#7
M_A_CS#0
M_A_CS#1
M_A_RAS#
M_A_CAS#
M_A_WE#
M_A_CKE0
M_A_CKE1
CKE 0,1
M_A_CLK1#3
M_A_CLK23
M_A_CLK2#3
M_A_BA[0..2]3,4
M_A_ODT[0..1]3,4
M_B_DQ1
M_B_DQ4
M_B_DQ3
M_B_DQ2
M_B_DQ0
M_B_DQ5
M_B_DQ7
M_B_DQ6
M_B_DQ9
M_B_DQ8
M_B_DQ14
M_B_DQ15
M_B_DQ12
M_B_DQ13
M_B_DQ10
M_B_DQ11
M_B_DQ17
M_B_DQ20
M_B_DQ19
M_B_DQ18
M_B_DQ16
M_B_DQ21
M_B_DQ22
M_B_DQ23
M_B_DQ24
M_B_DQ25
M_B_DQ30
M_B_DQ31
M_B_DQ28
M_B_DQ29
M_B_DQ27
M_B_DQ26
M_B_A0
M_B_A1
M_B_A2
M_B_A3
M_B_A4
M_B_A5
M_B_A6
M_B_A7
M_B_A8
M_B_A9
M_B_A10
M_B_A11
M_B_A12
M_B_BA0
M_B_BA1
M_B_BA2
M_B_CLK1
M_B_CLK1#
M_B_CLK2
M_B_CLK2#
DDR_SMBCLK
DDR_SMBDTA
DIM2_SA0
DIM2_SA1
3V3V
M_A_DQM[0..7]
M_A_DQ[0..63]
M_A_DQS[0..7]
M_A_DQS#[0..7]
M_A_A[15..0]
5
DQ0
7
DQ1
17
DQ2
19
DQ3
4
DQ4
6
DQ5
14
DQ6
16
DQ7
23
DQ8
25
DQ9
35
DQ10
37
DQ11
20
DQ12
22
DQ13
36
DQ14
38
DQ15
43
DQ16
45
DQ17
55
DQ18
57
DQ19
44
DQ20
46
DQ21
56
DQ22
58
DQ23
61
DQ24
63
DQ25
73
DQ26
75
DQ27
62
DQ28
64
DQ29
74
DQ30
76
DQ31
102
A0
101
A1
100
A2
99
A3
98
A4
97
A5
94
A6
92
A7
93
A8
91
A9
105
A10/AP
90
A11
89
A12
107
BA0
106
BA1
85
NC/BA2
30
CLK0
32
CLK0
164
CLK1
166
CKL1
197
SCL
195
SDA
198
SA0
200
SA1
199
VDDSPD
1565917-4
CN24A
DIM2_SA1
M_A_DQM[0..7]3
M_A_DQ[0..63]3
M_A_DQS[0..7]3
M_A_DQS#[0..7]3
M_A_A[15..0]3,4
DQ32
DQ33
DQ34
DQ35
DQ36
DQ37
DQ38
DQ39
DQ40
DQ41
DQ42
DQ43
DQ44
DQ45
DQ46
DQ47
DQ48
DQ49
DQ50
DQ51
DQ52
DQ53
DQ54
DQ55
DQ56
DQ57
DQ58
DQ59
DQ60
DQ61
DQ62
DQ63
DM0
DM1
DM2
DM3
DM4
DM5
DM6
DM7
DQS0
DQS0
DQS1
PC2100 D DR 2 SD R AM SO-DIMM
(200P)
DQS1
DQS2
DQS2
DQS3
DQS3
DQS4
DQS4
DQS5
DQS5
DQS6
DQS6
DQS7
DQS7
CS0
CS1
RAS
CAS
WE
CKE0
CKE1
R15010K
R15110K
123
125
135
137
124
126
134
136
141
143
151
153
140
142
152
154
157
159
173
175
158
160
174
176
179
181
189
191
180
182
192
194
10
26
52
67
130
147
170
185
13
11
31
29
51
49
70
68
131
129
148
146
169
167
188
186
110
115
108
113
109
79
80
H 5.2
CKE 2,3
3V
M_B_DQ36
M_B_DQ37
M_B_DQ38
M_B_DQ34
M_B_DQ32
M_B_DQ33
M_B_DQ39
M_B_DQ35
M_B_DQ44
M_B_DQ41
M_B_DQ47
M_B_DQ46
M_B_DQ40
M_B_DQ45
M_B_DQ42
M_B_DQ43
M_B_DQ55
M_B_DQ54
M_B_DQ53
M_B_DQ48
M_B_DQ51
M_B_DQ50
M_B_DQ49
M_B_DQ52
M_B_DQ57
M_B_DQ60
M_B_DQ62
M_B_DQ59
M_B_DQ61
M_B_DQ56
M_B_DQ58
M_B_DQ63
M_B_DQM0
M_B_DQM1
M_B_DQM2
M_B_DQM3
M_B_DQM4
M_B_DQM5
M_B_DQM6
M_B_DQM7
M_B_DQS0
M_B_DQS#0
M_B_DQS1
M_B_DQS#1
M_B_DQS2
M_B_DQS#2
M_B_DQS3
M_B_DQS#3
M_B_DQS4
M_B_DQS#4
M_B_DQS5
M_B_DQS#5
M_B_DQS6
M_B_DQS#6
M_B_DQS7
M_B_DQS#7
M_B_CS#0
M_B_CS#1
M_B_RAS#
M_B_CAS#
M_B_WE#
M_B_CKE0
M_B_CKE1
M_B_CKE[0..1]
M_B_CS#[0..3]
M_B_RAS#
M_B_CAS#
M_B_WE#
SMDDR_VREF_DIMM SMDDR_VREF_DIMM
C8322.2UA
C8082.2UA
C8292.2UA
C803.1U
C804.1U
C375.1U C827.1U
C798.1U
C830.1U
C374.1U
C380.1U
C810.1U
M_A_ODT0
M_A_ODT1
M_A_CS#2 M_B_CS#2
M_A_A15
M_A_A14
M_A_A13
M_A_CS#3
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
M_B_CKE[0..1]3,4
M_B_CS#[0..3]3,4
M_B_RAS#3,4
M_B_CAS#3,4
M_B_WE#3,4
1
VREF
81
VDD_1
82
VDD_2
87
VDD_3
88
VDD_4
95
VDD_5
96
VDD_6
103
VDD_7
104
VDD_8
111
VDD_9
112
VDD_10
117
VDD_11
118
VDD_12
114
ODT0
119
ODT1
50
NC_1
69
NC_2
83
NC_3
84
NC_4/A15
86
NC_5/A14
116
NC_6/A13
120
NC_7
163
NC_8
162
VSS_45
165
VSS_46
168
VSS_47
171
VSS_48
172
VSS_49
177
VSS_50
178
VSS_51
183
VSS_52
184
VSS_53
187
VSS_54
190
VSS_55
193
VSS_56
196
VSS_57
201
VSS_58
2-1734073-1
CN23B
PC2100 DDR2 SDRAM
M_B_CLK1
M_B_CLK1#
M_B_CLK2
M_B_CLK2#
M_B_BA[0..2]
M_B_ODT[0..1]
VSS_1
VSS_2
VSS_3
VSS_4
VSS_5
VSS_6
VSS_7
VSS_8
VSS_9
VSS_10
VSS_11
VSS_12
VSS_13
VSS_14
VSS_15
VSS_16
VSS_17
VSS_18
VSS_19
VSS_20
VSS_21
VSS_22
VSS_23
VSS_24
VSS_25
VSS_26
VSS_27
VSS_28
VSS_29
VSS_30
VSS_31
VSS_32
SO-DIMM (200P)
VSS_33
VSS_34
VSS_35
VSS_36
VSS_37
VSS_38
VSS_39
VSS_40
VSS_41
VSS_42
VSS_43
VSS_44
VSS_59
2
3
8
9
12
15
18
21
24
27
28
33
34
39
40
41
42
47
48
53
54
59
60
65
66
71
72
77
78
121
122
127
128
132
133
138
139
144
145
149
150
155
156
161
202
M_B_CLK13
M_B_CLK1#3
M_B_CLK23
M_B_CLK2#3
M_B_BA[0..2]3,4
M_B_ODT[0..1]3,4
C8052.2UA
C8062.2UA
C8312.2UA
C825.1U
C826.1U
C824.1U
C376.1U
C377.1U
C373.1U
C828.1U
M_B_ODT0
M_B_ODT1
M_B_A15
M_B_A14
M_B_A13
M_B_CS#3
SO-DIMM BYPASS PLACEMENT :
Place these Caps near So-Dimm1.
No Vias Between the Trace of PIN to CAP.
R1282KF
C382.1U
C3082.2UA
C396.1U
C3112.2UA
SMDDR_VREF_DIMM
R127*0R
R1232KF
SMDDR_VREF_DIMM
SMDDR_VREF_DIMM
3V
3V
3V
1.8VSUS
SMDDR_VREF
1.8VSUS
C370.1U
C3882.2UA
C3842.2UA
C309.1U
M_B_DQM[0..7]
M_B_DQ[0..63]
M_B_DQS[0..7]
M_B_DQS#[0..7]
M_B_A[15..0]
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
1.8VSUS
3V2,7,8,9,10,11,15,16,17,18,19,23,26,27,28,29,30,32,33,35,36,38
1.8VSUS2,3,4,32,36,37
81
82
87
88
95
96
103
104
111
112
117
118
114
119
50
69
83
84
86
116
120
163
162
165
168
171
172
177
178
183
184
187
190
193
196
201
1
1565917-4
CN24B
M_B_DQM[0..7]3
M_B_DQ[0..63]3
M_B_DQS[0..7]3
M_B_DQS#[0..7]3
M_B_A[15..0]3,4
VREF
VDD_1
VDD_2
VDD_3
VDD_4
VDD_5
VDD_6
VDD_7
VDD_8
VDD_9
VDD_10
VDD_11
VDD_12
ODT0
ODT1
NC_1
NC_2
NC_3
NC_4/A15
NC_5/A14
NC_6/A13
NC_7
NC_8
VSS_45
PC2100 DDR2 SDRAM
VSS_46
VSS_47
VSS_48
VSS_49
VSS_50
VSS_51
VSS_52
VSS_53
VSS_54
VSS_55
VSS_56
VSS_57
VSS_58
VSS_1
VSS_2
VSS_3
VSS_4
VSS_5
VSS_6
VSS_7
VSS_8
VSS_9
VSS_10
VSS_11
VSS_12
VSS_13
VSS_14
VSS_15
VSS_16
VSS_17
VSS_18
VSS_19
VSS_20
VSS_21
VSS_22
VSS_23
VSS_24
VSS_25
VSS_26
VSS_27
VSS_28
VSS_29
VSS_30
VSS_31
VSS_32
SO-DIMM (200P)
VSS_33
VSS_34
VSS_35
VSS_36
VSS_37
VSS_38
VSS_39
VSS_40
VSS_41
VSS_42
VSS_43
VSS_44
VSS_59
2
3
8
9
12
15
18
21
24
27
28
33
34
39
40
41
42
47
48
53
54
59
60
65
66
71
72
77
78
121
122
127
128
132
133
138
139
144
145
149
150
155
156
161
202
05
SMDDR_VREF_DIMM :
TRACE WIDTH > 20 MIL
PUT BYPASS CAP ON EACH DIMM
SMbus address A0 SMbus address A4
Close DDR2 socket
O.S
GND
3V
C801*.1U
8
DIMM_THEM#
3
4
DIMM_THEM#
DIMM_THEM#2
Address:92h
6
NB5/RD2/HW1
PROJECT : AT8
Quanta Computer Inc.
SizeDocument NumberRev
Custom
CPU(MEM/IF)
Date:Sheet of
7
538Thursday, December 29, 2005
8
1A
DDR_SMBDTA
DD
CGCLK_SMB17
1
1
Q132N7002E
3
Q122N7002E
3
2
3V
1
2
3V
CGDAT_SMB17
DDR_SMBCLK
2
DDR_SMBDTA
DDR_SMBCLK
3
R1412.2K
R1352.2K
3V
LM86_SMD2
LM86_SMC2
4
3V
LM86_SMD
LM86_SMC
3V
U33
A07+VS
6
A1
5
A2
1
SDA
2
SCL
(LM75CIMM3)
*G751
R537*10K
5
PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com
1
2
3
4
5
6
7
8
HT_TXD[15..0]2
AA
HT_TXD#[15..0]2
HT_CPU_DWNCLK02
BB
HT_CPU_DWNCLK#12
HT_CPU_DWNCTL#02
HT_CPU_DWNCTL02
1.2V_HT
R50150R
R59150R
as close as ball
HT_TXD0
HT_TXD1
HT_TXD2
HT_TXD3
HT_TXD4
HT_TXD5
HT_TXD6
HT_TXD7
HT_TXD8
HT_TXD9
HT_TXD10
HT_TXD11
HT_TXD12
HT_TXD13
HT_TXD14
HT_TXD15
HT_TXD#0
HT_TXD#1
HT_TXD#2
HT_TXD#3
HT_TXD#4
HT_TXD#5
HT_TXD#6
HT_TXD#7
HT_TXD#8
HT_TXD#9
HT_TXD#10
HT_TXD#11
HT_TXD#12
HT_TXD#13
HT_TXD#14
HT_TXD#15
HT_CPU_DWNCLK0
HT_CPU_DWNCLK#0
HT_CPU_DWNCLK1
HT_CPU_DWNCLK#1
HT_CPU_DWNCTL0
HT_CPU_DWNCTL#0
5mil/10mil
CPU_CAL_1P2V
CPU_CAL_GND
5mil/10mil
+1.2V_HT_PLL
within 500mils
+2.5V_HT_PLL
L120B
L90B
HT_MCP_RXD7
HT_MCP_RXD#7
+1.2V_HT_PLL
+2.5V_HT_PLL
R68*49.9F
R70*49.9F
C841U
C111.1U
C911U
C37.1U
CC
C354.7UB
HT_MCP_RXD[0..7]15
1.2V
2.5V
HT_MCP_RXD#[0..7]15
1.2V
STUFF : 4X4 HT LINK/UNUSED PIN FLOATING
NON-STUFF : 8X8 HT LINK(DEFAULT)
HTMCP_UPCLK015
HTMCP_UPCLK#015
HTMCP_UPCTL15
HTMCP_UPCTL#15
DD
1
HTMCP_PWRGD15
MCPOUT_200M15
MCPOUT_200M#15
2
T46
T36
HTMCP_REQ#15
HTMCP_STOP#15
HTMCP_RST#15
MCPOUT_25M15
HT_MCP_RXD0
HT_MCP_RXD1
HT_MCP_RXD2
HT_MCP_RXD3
HT_MCP_RXD4
HT_MCP_RXD5
HT_MCP_RXD6
HT_MCP_RXD7
HT_MCP_RXD8
T63
HT_MCP_RXD9
T58 T17
HT_MCP_RXD10
T52
HT_MCP_RXD11
T53
HT_MCP_RXD12
T49
HT_MCP_RXD13
T40
HT_MCP_RXD14
T41
HT_MCP_RXD15
T38
HT_MCP_RXD#0
HT_MCP_RXD#1
HT_MCP_RXD#2
HT_MCP_RXD#3
HT_MCP_RXD#4
HT_MCP_RXD#5
HT_MCP_RXD#6
HT_MCP_RXD#7
HT_MCP_RXD#8
T59 T13
HT_MCP_RXD#9
T55
HT_MCP_RXD#10
T62
HT_MCP_RXD#11
T51
HT_MCP_RXD#12
T47
HT_MCP_RXD#13
T44
HT_MCP_RXD#14
T48
HT_MCP_RXD#15
T32
HTMCP_UPCLK0
HTMCP_UPCLK#0
C51_HT_MCP_RX_CLK1
C51_HT_MCP_RX_CLK1#
HTMCP_UPCTL
HTMCP_UPCTL#
HTMCP_REQ#
HTMCP_STOP#
HTMCP_RST#
HTMCP_PWRGD
MCPOUT_25M
MCPOUT_200M
MCPOUT_200M#
3
U27A
Y23
HT_CPU_RXD0_P
W24
HT_CPU_RXD1_P
V24
HT_CPU_RXD2_P
U22
HT_CPU_RXD3_P
R24
HT_CPU_RXD4_P
P24
HT_CPU_RXD5_P
P22
HT_CPU_RXD6_P
N22
HT_CPU_RXD7_P
Y21
HT_CPU_RXD8_P
V21
HT_CPU_RXD9_P
W21
HT_CPU_RXD10_P
T21
HT_CPU_RXD11_P
R18
HT_CPU_RXD12_P
P16
HT_CPU_RXD13_P
N20
HT_CPU_RXD14_P
M17
HT_CPU_RXD15_P
Y22
HT_CPU_RXD0_N
W23
HT_CPU_RXD1_N
V23
HT_CPU_RXD2_N
U21
HT_CPU_RXD3_N
R23
HT_CPU_RXD4_N
P23
HT_CPU_RXD5_N
P21
HT_CPU_RXD6_N
N21
HT_CPU_RXD7_N
Y20
HT_CPU_RXD8_N
W20
HT_CPU_RXD9_N
W22
HT_CPU_RXD10_N
U20
HT_CPU_RXD11_N
R19
HT_CPU_RXD12_N
P17
HT_CPU_RXD13_N
N19
HT_CPU_RXD14_N
N18
HT_CPU_RXD15_N
T23
HT_CPU_RX_CLK0_P
T22
HT_CPU_RX_CLK0_N
R21
HT_CPU_RX_CLK1_P
R20
HT_CPU_RX_CLK1_N
M23
HT_CPU_RXCTL_P
M22
HT_CPU_RXCTL_N
W19
HT_CPU_CAL_1P2V
Y19
HT_CPU_CAL_GND
N16
+1.2V_PLLHTCPU
T13
+1.2V_PLLHTMCP
L16
+2.5V_PLLHTCPU
AD6
HT_MCP_RXD0_P
AC7
HT_MCP_RXD1_P
AA8
HT_MCP_RXD2_P
AA9
HT_MCP_RXD3_P
AD10
HT_MCP_RXD4_P
AD11
HT_MCP_RXD5_P
AC12
HT_MCP_RXD6_P
AC13
HT_MCP_RXD7_P
AA6
HT_MCP_RXD8_P
W7
HT_MCP_RXD9_P
Y8
HT_MCP_RXD10_P
V9
HT_MCP_RXD11_P
Y10
HT_MCP_RXD12_P
AA11
HT_MCP_RXD13_P
V11
HT_MCP_RXD14_P
W12
HT_MCP_RXD15_P
AC6
HT_MCP_RXD0_N
AB7
HT_MCP_RXD1_N
AB8
HT_MCP_RXD2_N
AB9
HT_MCP_RXD3_N
AC10
HT_MCP_RXD4_N
AC11
HT_MCP_RXD5_N
AB12
HT_MCP_RXD6_N
AB13
HT_MCP_RXD7_N
Y6
HT_MCP_RXD8_N
Y7
HT_MCP_RXD9_N
AA7
HT_MCP_RXD10_N
W9
HT_MCP_RXD11_N
W10
HT_MCP_RXD12_N
Y12
HT_MCP_RXD13_N
W11
HT_MCP_RXD14_N
V13
HT_MCP_RXD15_N
AD9
HT_MCP_RX_CLK0_P
AC9
HT_MCP_RX_CLK0_N
U10
HT_MCP_RX_CLK1_P
T10
HT_MCP_RX_CLK1_N
AD14
HT_MCP_RXCTL_P
AC14
HT_MCP_RXCTL_N
AB5
HT_MCP_REQ#
AA5
HT_MCP_STOP#
AC5
HT_MCP_RESET#
AD5
HT_MCP_PWRGD
AC4
CLKIN_25MHZ
Y5
CLKIN_200MHZ_P
W5
CLKIN_200MHZ_N
C51M/C51D
CPU I/F
4
HT_CPU_TX_CLK0_P
HT_CPU_TX_CLK0_N
HT_CPU_TX_CLK1_P
HT_CPU_TX_CLK1_N
CLKOUT_PRI_200MHZ_P
CLKOUT_PRI_200MHZ_N
CLKOUT_SEC_200MHZ_P
CLKOUT_SEC_200MHZ_N
MCP I/F
HT_MCP_TX_CLK0_P
HT_MCP_TX_CLK0_N
HT_MCP_TX_CLK1_P
HT_MCP_TX_CLK1_N
CLKOUT_CTERM_GND
SCLKI_MCLKO_200MHZ_P
SCLKI_MCLKO_200MHZ_N
HT_CPU_TXD0_P
HT_CPU_TXD1_P
HT_CPU_TXD2_P
HT_CPU_TXD3_P
HT_CPU_TXD4_P
HT_CPU_TXD5_P
HT_CPU_TXD6_P
HT_CPU_TXD7_P
HT_CPU_TXD8_P
HT_CPU_TXD9_P
HT_CPU_TXD10_P
HT_CPU_TXD11_P
HT_CPU_TXD12_P
HT_CPU_TXD13_P
HT_CPU_TXD14_P
HT_CPU_TXD15_P
HT_CPU_TXD0_N
HT_CPU_TXD1_N
HT_CPU_TXD2_N
HT_CPU_TXD3_N
HT_CPU_TXD4_N
HT_CPU_TXD5_N
HT_CPU_TXD6_N
HT_CPU_TXD7_N
HT_CPU_TXD8_N
HT_CPU_TXD9_N
HT_CPU_TXD10_N
HT_CPU_TXD11_N
HT_CPU_TXD12_N
HT_CPU_TXD13_N
HT_CPU_TXD14_N
HT_CPU_TXD15_N
HT_CPU_TXCTL_P
HT_CPU_TXCTL_N
HT_CPU_REQ#
HT_CPU_STOP#
HT_CPU_RESET#
HT_CPU_PWRGD
HT_MCP_TXD0_P
HT_MCP_TXD1_P
HT_MCP_TXD2_P
HT_MCP_TXD3_P
HT_MCP_TXD4_P
HT_MCP_TXD5_P
HT_MCP_TXD6_P
HT_MCP_TXD7_P
HT_MCP_TXD8_P
HT_MCP_TXD9_P
HT_MCP_TXD10_P
HT_MCP_TXD11_P
HT_MCP_TXD12_P
HT_MCP_TXD13_P
HT_MCP_TXD14_P
HT_MCP_TXD15_P
HT_MCP_TXD0_N
HT_MCP_TXD1_N
HT_MCP_TXD2_N
HT_MCP_TXD3_N
HT_MCP_TXD4_N
HT_MCP_TXD5_N
HT_MCP_TXD6_N
HT_MCP_TXD7_N
HT_MCP_TXD8_N
HT_MCP_TXD9_N
HT_MCP_TXD10_N
HT_MCP_TXD11_N
HT_MCP_TXD12_N
HT_MCP_TXD13_N
HT_MCP_TXD14_N
HT_MCP_TXD15_N
HT_MCP_TXCTL_P
HT_MCP_TXCTL_N
HT_MCP_CAL_1P2V
HT_MCP_CAL_GND
HT_RXD0
C23
HT_RXD1
D23
HT_RXD2
E22
HT_RXD3
F23
HT_RXD4
H22
HT_RXD5
J21
HT_RXD6
K21
HT_RXD7
K23
HT_RXD8
D21
HT_RXD9
F19
HT_RXD10
F21
HT_RXD11
G20
HT_RXD12
J19
HT_RXD13
L17
HT_RXD14
L20
HT_RXD15
L18
HT_RXD#0
C24
HT_RXD#1
D24
HT_RXD#2
E23
HT_RXD#3
F24
HT_RXD#4
H23
HT_RXD#5
J22
HT_RXD#6
K22
HT_RXD#7
K24
HT_RXD#8
D22
HT_RXD#9
E20
HT_RXD#10
E21
HT_RXD#11
G19
HT_RXD#12
J18
HT_RXD#13
K17
HT_RXD#14
K19
HT_RXD#15
L19
HT_CPU_UPCLK0
G23
HT_CPU_UPCLK#0
G24
HT_CPU_UPCLK1
G22
HT_CPU_UPCLK#1
G21
HT_CPU_UPCTL0
L23
HT_CPU_UPCTL#0
L24
CPU_CLK
B24
CPU_CLK#
B23
C51_200MHZ
A22
C51_200MHZ#
B21
HT_CPU_REQ#
F18
HTCPU_STOP#
G18
HTCPU_RST#
D20
HTCPU_PWRGD
E19
HT_MCP_TXD0
AC24
HT_MCP_TXD1
AD23
HT_MCP_TXD2
AC22
HT_MCP_TXD3
AC20
HT_MCP_TXD4
AB18
HT_MCP_TXD5
AA17
HT_MCP_TXD6
AB16
HT_MCP_TXD7
AC16
HT_MCP_TXD8
AB21
HT_MCP_TXD9
AB20
HT_MCP_TXD10
AB19
HT_MCP_TXD11
W18
HT_MCP_TXD12
W15
HT_MCP_TXD13
AA15
HT_MCP_TXD14
Y14
HT_MCP_TXD15
W13
HT_MCP_TXD#0
AC23
HT_MCP_TXD#1
AD22
HT_MCP_TXD#2
AC21
HT_MCP_TXD#3
AD20
HT_MCP_TXD#4
AC18
HT_MCP_TXD#5
AB17
HT_MCP_TXD#6
AB15
HT_MCP_TXD#7
AD16
HT_MCP_TXD#8
AB22
HT_MCP_TXD#9
AA20
HT_MCP_TXD#10
AA19
HT_MCP_TXD#11
V17
HT_MCP_TXD#12
V15
HT_MCP_TXD#13
Y15
HT_MCP_TXD#14
W14
HT_MCP_TXD#15
Y13
HTMCP_DWNCLK0
AC19
HTMCP_DWNCLK#0
AD19
HT_MCP_TX_CK1
Y17
HT_MCP_TX_CK1#
W17
HTMCP_DWNCTL
AC15
HTMCP_DWNCTL#
AD15
C51_CTERM
B22
C51_MCKL_200MHZ
A20
C51_MCKL_200MHZ#
B20
MCP_CAL_1P2V
AB23
MCP_CAL_GND
AB24
5
HT_RXD[15..0]2
HT_RXD#[15..0]2
HT_CPU_UPCLK02
HT_CPU_UPCLK#02HT_CPU_DWNCLK#02
HT_CPU_UPCLK12HT_CPU_DWNCLK12
HT_CPU_UPCLK#12
HT_CPU_UPCTL02
HT_CPU_UPCTL#02
CPU_CLK2
CPU_CLK#2
T163
T166
HTCPU_STOP#2
HTCPU_RST#2
HTCPU_PWRGD2
HT_MCP_TXD[0..7]15
T8
T20
T19
T26
T33
T34
T43
HT_MCP_TXD#[0..7]15
T10
T22
T11
T25
T28
T27
T30
HTMCP_DWNCLK015
HTMCP_DWNCLK#015
T24
T16
HTMCP_DWNCTL15
R4402.37KF
5/510mil
5/510mil
HTMCP_DWNCTL#15
T171
T168
R438150R
R439150R
as close as ball
within 500mils
1.2V
6
HT_CPU_REQ#
HTCPU_STOP#
HTCPU_RST#
HTCPU_PWRGD
NB5/RD2/HW1
06
#note from nv design
guide
Pull-Hi for rise
R5722K
R4491K
R4561K
R4591K
SizeDocument NumberRev
Custom
Date:Sheet of
7
time
2.5V
PROJECT : AT8
Quanta Computer Inc.
C51MV ( HT LINK)
638Thursday, December 29, 2005
8
1A
PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com
1
2
3
4
5
6
7
8
PEG_RXP[15..0]9
AA
PE0_PRSNT#
BB
CRT_R_C5119
CRT_G_C5119
CRT_B_C5119
CC
MCP_TV_EN17,19
C51D SUPPORT PCI-E LANE REVERSE
C51D
1X16(PORT0)
2X1(PORT1,2)
CRT_R_C51
CRT_G_C51
CRT_B_C51
CRTTV_SET
R490
R489124F
Q42
*2N7002E
N/A
LOW
CLK_PCIE_VGA9
CLK_PCIE_VGA#9
CLK_PCIE_MINI#27
PCIE_RXP027
PCIE_RXN027
PCIE_TXP027
PCIE_TXN027
CLK_MINI_OE#27
CLK_PCIE_MINI27
HSYNC10,19
VSYNC10,19
*274F
C733*18P/50V
C730*18P/50V
GPU...
PCI-E
MINI CARD
1
2
3
PEG_RXN[15..0]9
C51M
YES
2X1(PORT1,2)
N/A
3V
15mil/8mil
3V
R509*150R
R494*150R
R493*150R
C738.01U
5mil/10mil
1 2
Y5
*27MHZ
1 2
R534*10K
R5270R
R51922R
R52022R
C188.1U
C189.1U
R52322R
R52422R
L82*BLM21PG220SN1D
C72710K
C728*4.7UB
R492*0R
R491*0R
only required for C51M TV-OUT
C136*1U
1.2V
1.2V
DD
1.2V
C114*.1U
L17*BLM21PG220SN1D
C1341U
C137.1U
L19BLM21PG220SN1D
C89*1U
C36*.1U
L8*BLM21PG220SN1D
+1.2V_PLLGPU
+1.2V_PLLGPU
+1.2V_PLLGPU
+1.2V_PLLCORE
+1.2V_PLLCORE
+1.2V_PLLCORE
+1.2V_PLLIFP
+1.2V_PLLIFP
+1.2V_PLLIFP
3V
T172
R44722K
R45122K
R44422K
R44322K
R4531K
PEG_RXP0
PEG_RXP1
PEG_RXP2
PEG_RXP3
PEG_RXP4
PEG_RXP5
PEG_RXP6
PEG_RXP7
PEG_RXP8
PEG_RXP9
PEG_RXP10
PEG_RXP11
PEG_RXP12
PEG_RXP13
PEG_RXP14
PEG_RXP15
PEG_RXN0
PEG_RXN1
PEG_RXN2
PEG_RXN3
PEG_RXN4
PEG_RXN5
PEG_RXN6
PEG_RXN7
PEG_RXN8
PEG_RXN9
PEG_RXN10
PEG_RXN11
PEG_RXN12
PEG_RXN13
PEG_RXN14
PEG_RXN15
PE0_PRSNT#
PE0_REFCLK_P
PE0_REFCLK_N
PCIE_RXP0
PCIE_RXN0
PCIE_TXP0_C
PCIE_TXN0_C
CLK_MINI_OE#
C51CLK_PCIE_MINI
C51CLK_PCIE_MINI#
T178
T179
C51_DAC_IDUMP
T37
T45
T23
T15
T21
C51JTAG_TDO
C51JTAG_TDI
C51JTAG_TMS
C51JTAG_TCK
C51JTAG_TRST#
C51_TESTMODE_EN
C51_REFCLKIN#
C51_REFCLKIN
+3VDAC
CRT_R_C51
CRT_G_C51
CRT_B_C51
HSYNC_R
VSYNC_R
DAC_RSET
C51_DAC_VREF
C51_NC1
C51_NC2
C51MV_XTALIN
C51MV_XTALOUT
C51_NC3
C51_NC4
C51_NC5
+1.2V_PLLGPU
+1.2V_PLLCORE
+1.2V_PLLIFP
U27B
J8
PE0_RX0_P
J6
PE0_RX1_P
K9
PE0_RX2_P
L6
PE0_RX3_P
L7
PE0_RX4_P
M9
PE0_RX5_P
N8
PE0_RX6_P
N6
PE0_RX7_P
R6
PE0_RX8_P
P3
PE0_RX9_P
R8
PE0_RX10_P
U6
PE0_RX11_P
T8
PE0_RX12_P
U7
PE0_RX13_P
V4
PE0_RX14_P
Y3
PE0_RX15_P
J7
PE0_RX0_N
J5
PE0_RX1_N
J9
PE0_RX2_N
L5
PE0_RX3_N
L8
PE0_RX4_N
M8
PE0_RX5_N
N7
PE0_RX6_N
N5
PE0_RX7_N
R5
PE0_RX8_N
P4
PE0_RX9_N
R7
PE0_RX10_N
U5
PE0_RX11_N
T9
PE0_RX12_N
U8
PE0_RX13_N
V3
PE0_RX14_N
AA3
PE0_RX15_N
D1
PE0_PRSNT#
K1
PE0_REFCLK_P
K2
PE0_REFCLK_N
G6
PE1_RX_P
H6
PE1_RX_N
G4
PE1_TX_P
G5
PE1_TX_N
D3
PE1_CLKREQ#/CLK
E2
PE1_PRSNT#
G2
PE1_REFCLK_P
G3
PE1_REFCLK_N
AB3
PE_REFCLKIN_N
AC3
PE_REFCLKIN_P
A9
+3.3V_DAC
A5
DAC_RED
B6
DAC_GREEN
A6
DAC_BLUE
B7
DAC_HSYNC
C7
DAC_VSYNC
D8
DAC_RSET
D9
DAC_VREF
C8
DAC_IDUMP
F12
NC1
E11
NC2
C9
XTAL_IN
B9
XTAL_OUT
E17
NC3
F17
NC4
G17
NC5
R9
+1.2V_PLLGPU
P9
+1.2V_PLLCORE
H16
+1.2V_PLLIFP
C19
JTAG_TDO
B19
JTAG_TDI
B18
JTAG_TMS
C18
JTAG_TCK
A19
JTAG_TRST#
D17
PKG_TEST
C17
TEST_MODE_EN
C51M/C51D
CRT/TV
PE0_TX0_P
PE0_TX1_P
PE0_TX2_P
PE0_TX3_P
PE0_TX4_P
PE0_TX5_P
PE0_TX6_P
PE0_TX7_P
PE0_TX8_P
PE0_TX9_P
PE0_TX10_P
PE0_TX11_P
PE0_TX12_P
PE0_TX13_P
PE0_TX14_P
PE0_TX15_P
PE0_TX0_N
PE0_TX1_N
PE0_TX2_N
PE0_TX3_N
PE0_TX4_N
PE0_TX5_N
PE0_TX6_N
PE0_TX7_N
PE0_TX8_N
PE0_TX9_N
PE0_TX10_N
PE0_TX11_N
PE0_TX12_N
PE0_TX13_N
PE0_TX14_N
PE0_TX15_N
PE2_RX_P
PE2_RX_N
PE2_TX_P
PE2_TX_N
PE2_CLKREQ#/DATA
PE2_PRSNT#
PE2_REFCLK_P
PE2_REFCLK_N
PE_TSTCLK_P
PE_TSTCLK_N
PE_RST#
PE_CTERM_GND
+1.2V_PLLPE
IFPA_TXC_P
IFPA_TXC_N
IFPA_TXD0_P
IFPA_TXD1_P
IFPA_TXD2_P
IFPA_TXD3_P
IFPA_TXD0_N
IFPA_TXD1_N
IFPA_TXD2_N
IFPA_TXD3_N
IFPB_TXC_P
IFPB_TXC_N
LVDS I/F
IFPB_TXD4_P
IFPB_TXD5_P
IFPB_TXD6_P
IFPB_TXD7_P
IFPB_TXD4_N
IFPB_TXD5_N
IFPB_TXD6_N
IFPB_TXD7_N
IFPAB_VPROBE
IFPAB_RSET
+2.5V_PLLIFP
+2.5V_PLLCORE
+2.5V_PLLGPU
C_PEG_TXP0
L1
C_PEG_TXP1
L3
C_PEG_TXP2
L4
C_PEG_TXP3
M4
C_PEG_TXP4
P1
C_PEG_TXP5
R1
C_PEG_TXP6
R3
C_PEG_TXP7
R4
C_PEG_TXP8
U4
C_PEG_TXP9
V1
C_PEG_TXP10
W1
C_PEG_TXP11
W3
C_PEG_TXP12
AA1
C_PEG_TXP13
AB1
C_PEG_TXP14
AC1
C_PEG_TXP15
AD2
C_PEG_TXN0
L2
C_PEG_TXN1
M2
C_PEG_TXN2
M3
C_PEG_TXN3
N3
C_PEG_TXN4
P2
C_PEG_TXN5
R2
C_PEG_TXN6
T2
C_PEG_TXN7
T3
C_PEG_TXN8
U3
C_PEG_TXN9
V2
C_PEG_TXN10
W2
C_PEG_TXN11
Y2
C_PEG_TXN12
AA2
C_PEG_TXN13
AB2
C_PEG_TXN14
AC2
C_PEG_TXN15
AD3
PCIE_RXP1
J4
PCIE_RXN1
K3
PCIE_TXP1_C
H4
PCIE_TXN1_C
J3
CLK_C51_NEW_OE#
E4
CPPE#
E3
C51CLK_PCIE_NEW_C
H2
C51CLK_PCIE_NEW_C#
H3
PEX_TSTCLK
F1
PEX_TSTCLK#
F2
PCIE_RST#
G1
C51_PE_CTERM_GND
D2
+1.2V_PLLPE
T11
LA_CLK
C14
LA_CLK#
B13
LA_DATAP0
A15
LA_DATAP1
D15
LA_DATAP2
A14
LA_DATAP3
F14
LA_DATAN0
B15
LA_DATAN1
C15
LA_DATAN2
B14
LA_DATAN3
E14
LB_CLK
A10
LB_CLK#
B10
LB_DATAP0
B11
LB_DATAP1
E13
LB_DATAP2
D13
LB_DATAP3
B12
LB_DATAN0
A11
LB_DATAN1
F13
LB_DATAN2
C13
LB_DATAN3
C12
C51IFPAB_VPROBE
A16
C51IFPAB_RST
F15
+2.5V_PLLIFP
E16
H12
+2.5V_PLLGPU
H13
C109*.1U
C100*4.7UB
R109*100F
C99.1U
C1221U
L11
C87*.1U
C79*1U
+2.5V_PLLCORE
C116.1U
C1134.7UB
C767.1U
C783.1U
C765.1U
C780.1U
C763.1U
C778.1U
C762.1U
C776.1U
C772.1U
C770.1U
C760.1U
C759.1U
C756.1U
C753.1U
C749.1U
C740.1U
C768.1U
C782.1U
C766.1U
C781.1U
C764.1U
C779.1U
C761.1U
C777.1U
C773.1U
C771.1U
C775.1U
C769.1U
C758.1U
C755.1U
C751.1U
C747.1U
C187.1U
C186.1U
R52122R
R52222R
R5332.37KF
L140B
LA_CLK10
T29
T35
LB_CLK10
T42
T50
C721*.1U
R67*1K
*BLM21PG220SN1D
L16
0B
L13*BLM21PG220SN1D
PEG_TXP_C0
PEG_TXP_C1
PEG_TXP_C2
PEG_TXP_C3
PEG_TXP_C4
PEG_TXP_C5
PEG_TXP_C6
PEG_TXP_C7
PEG_TXP_C8
PEG_TXP_C9
PEG_TXP_C10
PEG_TXP_C11
PEG_TXP_C12
PEG_TXP_C13
PEG_TXP_C14
PEG_TXP_C15
PEG_TXN_C0
PEG_TXN_C1
PEG_TXN_C2
PEG_TXN_C3
PEG_TXN_C4
PEG_TXN_C5
PEG_TXN_C6
PEG_TXN_C7
PEG_TXN_C8
PEG_TXN_C9
PEG_TXN_C10
PEG_TXN_C11
PEG_TXN_C12
PEG_TXN_C13
PEG_TXN_C14
PEG_TXN_C15
LA_CLK#10
LA_DATAP010
LA_DATAP110
LA_DATAP210
LA_DATAN010
LA_DATAN110
LA_DATAN210
LB_CLK#10
LB_DATAP010
LB_DATAP110
LB_DATAP210
LB_DATAN010
LB_DATAN110
LB_DATAN210
1.2V
PEG_TXP_C[15..0]9
PEG_TXN_C[15..0]9
PCIE_RXP128
PCIE_RXN128
PCIE_TXP128
PCIE_TXN128
CLK_C51_NEW_OE#28
CPPE#28
CLK_PCIE_NEW_C28
CLK_PCIE_NEW_C#28
PCIE_RST#9,27,28
20mil/8mil
LVDS
LVDS
20mil
2.5V
15mil/8mil
2.5V
15mil/8mil
2.5V
15mil/8mil
NEW CARD
07
CLK_MINI_OE#
CLK_C51_NEW_OE#
CPPE#
C786*10P/50V
C787*10P/50V
C784*10P/50V
C785*10P/50V
C788*10P/50V
C789*10P/50V
C51D Unused Power Ball Terinations
C51D Signal NameTermination
+1.2V_PLLGPU
+1.2V_PLLIFP
+2.5V_IFPA
+2.5V_IFPB
+2.5V_PLLIFP
+2.5V_PLLGPU
+3.3V_DACto GND directly
DAC_RSET
DAC_VREF
TRACE WIDTH :
C51_PE_CTERM_GND 5mil/5mil
C51IFPAB_VPROBE
C51IFPAB_RST
C51_DAC_VREF 5mil/10mil
+1.2V_PLLPE
+2.5V_PLLIFP
+2.5V_PLLCORE
+2.5V_PLLGPU
R53210K
R526*10K
R525*10K
CLK_PCIE_NEW_C
CLK_PCIE_NEW_C#
CLK_PCIE_VGA
CLK_PCIE_VGA#
CLK_PCIE_MINI
CLK_PCIE_MINI#
Leave NC
Leave NC
Leave NC
Leave NC
Leave NC
Leave NC
124Ohm to GND
0.01u to GND
+1.2V_PLLIFP
+1.2V_PLLCORE
+1.2V_PLLGPU
3V
1
2
3
4
PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com
PROJECT : AT8
Quanta Computer Inc.
SizeDocument NumberRev
Custom
5
6
NB5/RD2/HW1
C51MV ( PCIE/LCD/RGB )
Date:Sheet of
7
738Thursday, December 29, 2005
8
1A
1
2
3
4
5
6
7
8
08
C51M/C51D POWER PLANE/GND & BYPASS
U27C
AA
BB
CC
C14422UB/X5R
C16022UB/X5R
C1171U
C1101U
C1061U
C1151U
C1011U
C1081U
C961U
C1691U
C112.1U
C67.1U
C121.1U
C13122UB/X5R
C135
C1461U
C95.1U
C78.1U
C5822UB/X5R
C1191U
C341U
C1964.7UA
C1974.7UA
C133.1U
C158.1U
C195.1U
C531U
C511U
C6222UB/X5R
C72.1U
C45.1U
C77.1U
C85.1U
C92.1U
C90.1U
C661U
1.2V
B5
+1.2V_CORE1
1.2V
C6
+1.2V_CORE2
1.2V
D7
+1.2V_CORE3
1.2V
E8
+1.2V_CORE4
1.2V
E9
+1.2V_CORE5
1.2V
E10
+1.2V_CORE6
1.2V
F10
+1.2V_CORE7
1.2V
F11
+1.2V_CORE8
1.2V
G11
+1.2V_CORE9
1.2V
H11
+1.2V_CORE10
1.2V
J11
+1.2V_CORE11
1.2V
1U C174.1U
3V
1.2V_HT
1.2V_HT
1.2V_HT
1.2V_HT
1.2V_HT
1.2V_HT
1.2V_HT
1.2V_HT
1.2V_HT
1.2V
1.2V
1.2V
1.2V
1.2V
1.2V
1.2V
1.2V
1.2V
1.2V
1.2V
1.2V
1.2V
1.2V
1.2V
3V
3V
AB11
AA18
W16
M16
M21
AA21
AA13
AB10
M19
J12
J13
J14
T15
U13
U11
Y9
U16
U15
B4
C5
D6
E7
K16
R16
J20
T16
U17
C21
H17
D18
C10
C1
U14
H14
C11
AB4
AA4
J15
E12
Y18
E18
U18
E15
Y11
U19
N17
F16
J17
L13
B1
T17
D11
T12
J16
D19
H19
L21
P19
T19
F3
L9
P8
N9
K4
+1.2V_CORE12
+1.2V_CORE13
+1.2V_CORE14
+1.2V_HTMCP1
+1.2V_HTMCP2
+1.2V_HTMCP3
+1.2V_HTMCP4
+1.2V_HTMCP5
+1.2V_HTMCP6
+1.2V_HTMCP7
+1.2V_HTMCP8
+1.2V_HTMCP9
+1.2V_PED1
+1.2V_PED2
+1.2V_PED3
+1.2V_PED4
+1.2V_HT1
+1.2V_HT2
+1.2V_HT3
+1.2V_HT4
+1.2V_HT5
+1.2V_HT6
+1.2V_HT7
+1.2V_HT8
+1.2V_HT9
+3.3V_2
+3.3V_1
GND1
GND2
GND3
GND4
GND5
GND6
GND7
GND8
GND9
GND10
GND11
GND12
GND13
GND14
GND15
GND16
GND17
GND18
GND19
GND20
GND21
GND22
GND23
GND24
GND25
GND26
GND27
GND28
GND29
GND30
GND31
GND32
PE_GND1
PE_GND2
PE_GND3
PE_GND4
PE_GND5
C51M/C51D
POWER/GND
+1.2V_PLL10
+1.2V_PLL11
+1.2V_PLL12
+2.5V_CORE1
+2.5V_CORE2
+1.2V_PEA1
+1.2V_PEA2
+1.2V_PEA3
+1.2V_PEA4
+1.2V_PEA5
+1.2V_PEA6
+1.2V_PEA7
+1.2V_PEA8
+1.2V_PLL1
+1.2V_PLL2
+1.2V_PLL3
+1.2V_PLL4
+1.2V_PLL5
+1.2V_PLL6
+1.2V_PLL7
+1.2V_PLL8
+1.2V_PLL9
+2.5V_IFPA
+2.5V_IFPB
GND33
GND34
GND35
GND36
GND37
GND38
GND39
GND40
GND41
GND42
GND43
GND44
GND45
GND46
GND47
GND48
GND49
GND50
GND51
GND52
GND53
GND54
GND55
GND56
GND57
GND58
GND59
GND60
GND61
GND62
GND63
GND64
GND65
GND66
PE_GND6
PE_GND7
PE_GND8
PE_GND9
PE_GND10
PE_GND11
PE_GND12
PE_GND13
PE_GND14
PE_GND15
PE_GND16
PE_GND17
PE_GND18
PE_GND19
PE_GND20
PE_GND21
PE_GND22
A3
B3
C4
D5
E6
F7
F8
F9
A2
B2
C2
C3
D4
E5
F6
G7
G8
G9
H10
J10
C16
B16
G15
H15
V19
T14
C20
R17
AB14
U12
G13
Y16
H21
C22
AB6
F22
L22
R22
V22
AA22
A23
AA23
AA24
L11
M11
N11
P11
M12
N12
P12
M13
N13
P13
M14
N14
P14
L14
L12
N4
T4
W4
Y4
U9
V8
K6
M6
P6
T6
W6
W8
H8
K8
V6
F4
H9
L320B
1.2V_PEA
C178.1U
1.2V_PEA
C145.1U
1.2V_PEA
C150.1U
1.2V_PEA
C180.1U
1.2V_PEA
C161.1U
1.2V_PEA
C1751U
1.2V_PEA
C1541U
1.2V_PEA
C17922UB/X5R
1.2V_PLL
C1661U
1.2V_PLL
C1851U
1.2V_PLL
1.2V_PLL
C184.1U
1.2V_PLL
C142.1U
1.2V_PLL
C155.1U
1.2V_PLL
C177.1U
1.2V_PLL
C132.1U
1.2V_PLL
C19222UB/X5RC1231U
1.2V_PLL
C19122UB/X5R
1.2V_PLL
1.2V_PLL
2.5V
2.5V
1.8V_IFP
1.8V_IFP
L310B
C861U
C7622UB/X5R
C97*1U
C98*.1U
L10*BLM21PG220SN1D
1.2V
1.2V
1.8V
1.2V_HT 1.2V_PEA 1.8V
C157
*22UB/X5R
C94
*.1U
C176
*22UB/X5R
C118
*1U
C107
*.1U
C63
*22UB/X5R
1.2V
C168
*22UB/X5R
1.2V
C93
*.1U
C124
*1U
C141
*.1U
C167
*.1U
C128
*1U
C143
*.1U
C50
*22UB/X5R
C148
*1U
2.5V
C46
C83
*1U
*1U
C162
C73
*1U
*1U
C82
*.1U
C156
*1U
DD
PROJECT : AT8
Quanta Computer Inc.
SizeDocument NumberRev
Custom
1
2
3
4
5
6
NB5/RD2/HW1
C51MV (POWER/GND)
Date:Sheet of
7
838Wednesday, January 11, 2006
8
1A
PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com
U35F
AA12
GND_0
AA2
GND_1
AA21
GND_2
AA31
GND_3
AB27
GND_4
AB6
GND_5
AC10
GND_6
AC23
GND_7
AC29
GND_8
AC4
GND_9
AD16
GND_10
AD17
DD
CC
BB
AA
AD2
AD31
AE17
AE27
AE6
AF11
AF26
AF29
AF4
AF7
AG10
AG11
AG14
AG15
AG19
AG2
AG22
AG31
AG8
AH24
AJ10
AJ13
AJ16
AJ17
AJ20
AJ23
AJ26
AJ29
AJ4
AJ7
AK2
AK28
AK31
AL11
AL14
AL19
AL22
AL25
AL3
AL6
AL9
AM13
AM16
AM17
AM20
AM23
AM26
AM29
B12
B15
B18
B21
B24
B27
B30
C31
D10
D13
D16
D17
D20
D23
D26
D29
B3
B6
B9
C2
GND_11
GND_12
GND_13
GND_14
GND_15
GND_16
GND_17
GND_18
GND_19
GND_20
GND_21
GND_22
GND_23
GND_24
GND_25
GND_26
GND_27
GND_28
GND_29
GND_30
GND_31
GND_32
GND_33
GND_34
GND_35
GND_36
GND_37
GND_38
GND_39
GND_40
GND_41
GND_42
GND_43
GND_44
GND_45
GND_46
GND_47
GND_48
GND_49
GND_50
GND_51
GND_52
GND_53
GND_54
GND_55
GND_56
GND_57
GND_58
GND_59
GND_60
GND_61
GND_62
GND_63
GND_64
GND_65
GND_66
GND_67
GND_68
GND_69
GND_70
GND_71
GND_72
GND_73
GND_74
GND_75
GND_76
GND_77
GND_78
GND_79
U_GPU_G3
5
D4
GND_80
D7
GND_81
F11
GND_82
F14
GND_83
F19
GND_84
F2
GND_85
F22
GND_86
F25
GND_87
F31
GND_88
F8
GND_89
G26
GND_90
G29
GND_91
G4
GND_92
G7
GND_93
H27
GND_94
H6
GND_95
J16
GND_96
J17
GND_97
J2
GND_98
J31
GND_99
K10
GND_100
K23
GND_101
K29
GND_102
K4
GND_103
L27
GND_104
L6
GND_105
M12
GND_106
M2
GND_107
M31
GND_108
N15
GND_109
N18
GND_110
N29
GND_111
N4
GND_112
P15
GND_113
P18
GND_114
P27
GND_115
P6
GND_116
R13
GND_117
R14
GND_118
R15
GND_119
R18
GND_120
R19
GND_121
R2
GND_122
R20
GND_123
R31
GND_124
T16
GND_125
T17
GND_126
T24
GND_127
T29
GND_128
T4
GND_129
U16
GND_130
U17
GND_131
U24
GND_132
U29
GND_133
U8
GND_134
V13
GND_135
V14
GND_136
V15
GND_137
V18
GND_138
V19
GND_139
V2
GND_140
V20
GND_141
V31
GND_142
W15
GND_143
W18
GND_144
W27
GND_145
W6
GND_146
Y15
GND_147
Y18
GND_148
Y29
GND_149
Y4
GND_150
AL10
GND_151
AM10
GND_152
AG13
GND_153
3V
12
C793.1U
U32
PCIE_RST#7,27,28
5
2
1
*TC7SH08FU
3 5
D38CH500H
4
PEG_RXP157
PEG_RXN157
PEG_RXP147
PEG_RXN147
PEG_RXP137
PEG_RXN137
PEG_RXP127
PEG_RXN127
PEG_RXP117
PEG_RXN117
PEG_RXP107
PEG_RXN107
PEG_RXP97
PEG_RXN97
PEG_RXP87
PEG_RXN87
PEG_RXP77
PEG_RXN77
PEG_RXP67
PEG_RXN67
PEG_RXP57
PEG_RXN57
PEG_RXP47
PEG_RXN47
PEG_RXP37
PEG_RXN37
PEG_RXP27
PEG_RXN27
PEG_RXP17
PEG_RXN17
PEG_RXP07
PEG_RXN07
PEG_TXP_C157
PEG_TXN_C157
PEG_TXP_C147
PEG_TXN_C147
PEG_TXP_C137
PEG_TXN_C137
PEG_TXP_C127
PEG_TXN_C127
PEG_TXP_C117
PEG_TXN_C117
PEG_TXP_C107
PEG_TXN_C107
PEG_TXP_C97
PEG_TXN_C97
PEG_TXP_C87
PEG_TXN_C87
PEG_TXP_C77
PEG_TXN_C77
PEG_TXP_C67
PEG_TXN_C67
PEG_TXP_C57
PEG_TXN_C57
PEG_TXP_C47
PEG_TXN_C47
PEG_TXP_C37
PEG_TXN_C37
PEG_TXP_C27
PEG_TXN_C27
PEG_TXP_C17
PEG_TXN_C17
PEG_TXP_C07
PEG_TXN_C07
CLK_PCIE_VGA7
CLK_PCIE_VGA#7
4
4
PEG_RXP15
PEG_RXP14
PEG_RXP13
PEG_RXN13
PEG_RXP12
PEG_RXN12
PEG_RXP11
PEG_RXN11
PEG_RXP10
PEG_RXN10
PEG_RXP9
PEG_RXN9
PEG_RXN8
PEG_RXP7
PEG_RXN7
PEG_RXP6
PEG_RXN6
PEG_RXP5
PEG_RXN5
PEG_RXP4
PEG_RXN4
PEG_RXP2
PEG_RXN2
PEG_RXP1
PEG_RXN1
PEG_RXP0
PEG_RXN0
PEG_TXP_C15
PEG_TXN_C15
PEG_TXP_C14
PEG_TXN_C14
PEG_TXP_C13
PEG_TXN_C13
PEG_TXP_C12
PEG_TXN_C12
PEG_TXP_C11
PEG_TXN_C11
PEG_TXP_C10
PEG_TXN_C10
PEG_TXP_C9
PEG_TXN_C9
PEG_TXP_C8
PEG_TXN_C8
PEG_TXP_C7
PEG_TXN_C7
PEG_TXP_C6
PEG_TXN_C6
PEG_TXP_C5
PEG_TXN_C5
PEG_TXP_C4
PEG_TXN_C4
PEG_TXP_C3
PEG_TXN_C3
PEG_TXP_C2
PEG_TXN_C2
PEG_TXP_C1
PEG_TXN_C1
PEG_TXP_C0
PEG_TXN_C0
CLK_PCIE_VGA
CLK_PCIE_VGA#
VGA_RST#
R535
100K
C204.1U
C211.1U
C225.1U
C219.1U
C244.1U
C233.1U
C256.1U
C265.1U
C251.1U
C243.1U
C271.1U
C262.1U
C284.1U
C274.1U
C291.1U
C285.1U
C307.1U
C295.1U
C310.1U
C318.1U
C320.1U
C327.1U
C339.1U
C330.1U
C352.1U
C340.1U
C363.1U
C353.1U
C369.1U
C371.1U
C368.1U
C364.1U
T117
T119
T211
T209
C_PEG_RXP15
C_PEG_RXN15PEG_RXN15
C_PEG_RXP14
C_PEG_RXN14PEG_RXN14
C_PEG_RXP13
C_PEG_RXN13
C_PEG_RXP12
C_PEG_RXN12
C_PEG_RXP11
C_PEG_RXN11
C_PEG_RXP10
C_PEG_RXN10
C_PEG_RXP9
C_PEG_RXN9
C_PEG_RXP8PEG_RXP8
C_PEG_RXN8
C_PEG_RXP7
C_PEG_RXN7
C_PEG_RXP6
C_PEG_RXN6
C_PEG_RXP5
C_PEG_RXN5
C_PEG_RXP4
C_PEG_RXN4
C_PEG_RXP3PEG_RXP3
C_PEG_RXN3PEG_RXN3
C_PEG_RXP2
C_PEG_RXN2
C_PEG_RXP1
C_PEG_RXN1
C_PEG_RXP0
C_PEG_RXN0
VGA_RFU0
VGA_RFU1
PEX_TSTCK
PEX_TSTCK#
AJ15
PEX_TX0
AK15
PEX_TX0#
AH16
PEX_TX1
AG16
PEX_TX1#
AG17
PEX_TX2
AH17
PEX_TX2#
AG18
PEX_TX3
AH18
PEX_TX3#
AK18
PEX_TX4
AJ18
PEX_TX4#
AJ19
PEX_TX5
AH19
PEX_TX5#
AG20
PEX_TX6
AH20
PEX_TX6#
AG21
PEX_TX7
AH21
PEX_TX7#
AK21
PEX_TX8
AJ21
PEX_TX8#
AJ22
PEX_TX9
AH22
PEX_TX9#
AG23
PEX_TX10
AH23
PEX_TX10#
AK24
PEX_TX11
AJ24
PEX_TX11#
AJ25
PEX_TX12
AH25
PEX_TX12#
AH26
PEX_TX13
AG26
PEX_TX13#
AK27
PEX_TX14
AJ27
PEX_TX14#
AJ28
PEX_TX15
AH27
PEX_TX15#
AK13
PEX_RX0
AK14
PEX_RX0#
AM14
PEX_RX1
AM15
PEX_RX1#
AL15
PEX_RX2
AL16
PEX_RX2#
AK16
PEX_RX3
AK17
PEX_RX3#
AL17
PEX_RX4
AL18
PEX_RX4#
AM18
PEX_RX5
AM19
PEX_RX5#
AK19
PEX_RX6
AK20
PEX_RX6#
AL20
PEX_RX7
AL21
PEX_RX7#
AM21
PEX_RX8
AM22
PEX_RX8#
AK22
PEX_RX9
AK23
PEX_RX9#
AL23
PEX_RX10
AL24
PEX_RX10#
AM24
PEX_RX11
AM25
PEX_RX11#
AK25
PEX_RX12
AK26
PEX_RX12#
AL26
PEX_RX13
AL27
PEX_RX13#
AM27
PEX_RX14
AM28
PEX_RX14#
AL28
PEX_RX15
AL29
PEX_RX15#
AH14
PEX_REFCLK
AJ14
PEX_REFCLK#
AH15
PEX_RST#
AG12
RFU0
AH13
RFU1
AM12
PEX_TSTCLK_OUT
AM11
PEX_TSTCLK_OUT#
U_GPU_G3
U35A
3
VGA_VDD
VDD_0
VDD_1
VDD_2
VDD_3
VDD_4
VDD_5
VDD_6
VDD_7
VDD_8
VDD_9
VDD_10
VDD_11
VDD_12
VDD_13
VDD_15
VDD_16
VDD_17
VDD_18
VDD_19
VDD_20
VDD_21
VDD_22
VDD_23
VDD_24
VDD_25
VDD_26
VDD_27
VDD_28
VDD_29
VDD_30
VDD_31
VDD_32
VDD_33
VDD_34
VDD_35
VDD_36
VDD_LP_0
VDD_LP_1
VDD_LP_2
VDD_LP_3
VDD_LP_4
VDD_LP_5
VDD33_0
VDD33_1
VDD33_2
VDD33_3
VDD33_4
VDD33_5
VDD33_6
VDD33_7
VDD33_8
VDD33_9
VDD33_10
VDD33_11
VDD33_12
NC_0
NC_1
NC_2
AD23
AF23
AF24
AF25
AG24
AG25
AC16
AC17
AC21
AC22
AE18
AE21
AE22
AF12
AF18
AF21
AF22
K16
K17
N13
N14
N16
N17
N19
P13
P14
P16
P17
P19
R16
R17
T14
T15
T18
T19
U13
U14
U15
U18
U19
V16
V17
W13
W14
W16
W17
W19
Y13
Y14
Y16
Y17
Y19
Y20
P20
T20
T23
U20
U23
W20
N20
M21
AC11
AC12
AC24
AD24
AE11
AE12
H7
J7
K7
L10
L7
L8
M10
AF15
AE15
AE16
T13
AM8
AM9
B32
NV_PLLAVDD
C334.1U
C336.1U
C3541U
C3551U
C8164.7UB
VGA_VDDQ
C268.1U
C247.1U
C317.47UA
C301.47UA
C3331U
C2791U
C28910UA
C283.1U
C335.1U
C264.1U
C263.1U
C270.1U
C293.1U
C294.1U
C31610UA
C286.1U
C3151U
C305.1U
C306.1U
C314.1U
C287.1U
C29210UA
C266.47UA
C324.47UA
C253.47UA
C326.47UA
C2581U
C2691U
C278.47UA
C300.47UA
C288.47UA
C259.47UA
C322.47UA
C325.47UA
C27310UA
VDD_SENSE
GND_SENSE
VGA_VDD3
C208.1U
C209.1U
C206.1U
C351.47UA
C245.47UA
C228.47UA
C2071U
15mil
PEX_PLLAVDD
PEX_PLLDVDD
15mil
15mil
PCIE
PEX_IOVDD_0
PEX_IOVDD_1
PEX_IOVDD_2
PEX_IOVDD_3
PEX_IOVDD_4
PEX_IOVDD_5
PEX_IOVDDQ_0
PEX_IOVDDQ_1
PEX_IOVDDQ_2
PEX_IOVDDQ_3
PEX_IOVDDQ_4
PEX_IOVDDQ_5
PEX_IOVDDQ_6
PEX_IOVDDQ_7
PEX_IOVDDQ_8
PEX_IOVDDQ_9
PEX_IOVDDQ_10
VDD_SENSE
GND_SENSE
PEX_PLLAVDD
PEX_PLLDVDD
PEX_PLLGND
NV_PLLAVDD
R5410B
R5400B
VCORE
C313
*.01U
R1140B
L200A
C2551U
C153.01U
C152.1U
C14710UA
L250A
C1711U
C172.01U
C254.1U
C16510UA
L330A
C257.1U
C20010UA
2
1.2V
PLACE NEAR GPU
1.2V
PLACE NEAR GPU
PLACE NEAR GPU
T120
T121
3V
PLACE NEAR GPU
SPDIF_VGA
1.2V
1.2V
PLACE NEAR GPU
1.2V
1
For 3.3V swing, we can remove Ra, Rb
and Rc and replace C with 0ohm resistor.
RB500
RB500
3V
Ra
D1
D2
R107
*24.3KF
2 1
2 1
C
C1900R
Rb
R113
*3.4KA/F
SPDIF
Rc
R112
*76.8/F
09
SPDIF23,31
PROJECT : AT8
SPDIF_VGA
J6
SPDIF
3
2
NB5/RD2/HW1
Quanta Computer Inc.
SizeDocument NumberRev
Custom
GFX (PCIE INTERFACE)
Date:Sheet of
938Thursday, December 29, 2005
1
1A
PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com
5
4
3
2
1
L22
0A
2.5V
DD
1.8V
CC
2.5V
15mil
2.5V
BB
2.5V
3V
3V
IFPC_DVI_3V
T207
T208
IFPAB_PLLVDD
C223470P/X7R
C2154700P
C18310UA
C739*220U/7343 RP470X2
+
C217470P/X7R
C2244700P
C18210UA
L210A
IFPABVPROBE
IFPABRSET
L24
0A
C239470P/X7R
C2324700P
C18110UA
C240.01U
R119124F
L270A
C212470P/X7R
C2134700P
C23710UA
C214.01U
R117124F
15mil
C194*.01U
R111*1K
L290A
C222470P/X7R
C2314700P
C23810UA
L840A
C203470P/X7R
C1994700P
C74810UA
R11510K
R11810K
L300A
C216.1U
C2214700P
C21010UA
L280A
C241.1U
C2424700P
C23610UA
IFPA_IOVDD
15mil
DACA_VDD
15mil
DACA_VREF
DACA_RSET
DACB_VDD
DACB_VREF
DACB_RSET
IFPCDVPROBE
IFPCDRSET
IFPCD_PLLVDD
15mil
IFPC_IOVDD
IFPD_IOVDD
15mil
DACC_VD
DACC_IDUMP
NV_PLLVDD
DISP_PLLVDD
15mil
15mil
15mil
AC9
AD9
AF9
AF8
AM4
AD10
AH10
AH9
AG9
AK3
AH3
AA10
AB10
AD6
AE7
AD7
AH4
AF5
AG4
U10
AL5
V8
R5
R7
V7
T9
T10
U35D
IFPAB_PLLVDD
IFPAB_PLLGND
IFPA_IOVDD
IFPB_IOVDD
IFPAB_VPROBE
IFPAB_RSET
DACA_VDD
DACA_VREF
DACA_RSET
DACA_IDUMP
DACB_VDD
DACB_VREF
DACB_RSET
DACB_IDUMP
IFPCD_VPROBE
IFPCD_RSET
IFPCD_PLLVDD
IFPCD_PLLGND
IFPC_IOVDD
IFPD_IOVDD
DACC_VDD
DACC_VREF
DACC_RSET
DACC_IDUMP
PLLVDD
VID_PLLVDD
PLLGND
U_GPU_G3
LVDS
DACA_HSYNC
CRT
DACA_VSYNC
DACA_GREEN
DACB_GREEN
TV
TMDS
DACC_HSYNC
DAC
DACC_VSYNC
DACC_GREEN
XTALOUTBUFF
XTAL
IFPA_TXC#
IFPA_TXC
IFPA_TXD0#
IFPA_TXD0
IFPA_TXD1#
IFPA_TXD1
IFPA_TXD2#
IFPA_TXD2
IFPA_TXD3#
IFPA_TXD3
IFPB_TXC#
IFPB_TXC
IFPB_TXD4#
IFPB_TXD4
IFPB_TXD5#
IFPB_TXD5
IFPB_TXD6#
IFPB_TXD6
IFPB_TXD7#
IFPB_TXD7
I2CA_SCL
I2CA_SDA
DACA_RED
DACA_BLUE
DACB_RED
DACB_BLUE
IFPC_TXC#
IFPC_TXC
IFPC_TXD0#
IFPC_TXD0
IFPC_TXD1#
IFPC_TXD1
IFPC_TXD2#
IFPC_TXD2
IFPD_TXC#
IFPD_TXC
IFPD_TXD4#
IFPD_TXD4
IFPD_TXD5#
IFPD_TXD5
IFPD_TXD6#
IFPD_TXD6
I2CB_SCL
I2CB_SDA
DACC_RED
DACC_BLUE
XTALSSIN
XTALIN
XTALOUT
AJ9
AK9
AJ6
AH6
AH7
AH8
AK8
AJ8
AH5
AJ5
AL4
AK4
AM5
AM6
AL7
AM7
AK5
AK6
AL8
AK7
K2
J3
AF10
AK10
AH11
AJ12
AH12
R6
T5
T6
AM3
AM2
AE1
AE2
AF2
AF1
AH1
AG1
AH2
AG3
AJ1
AK1
AL1
AL2
AJ3
AJ2
H4
J4
AG7
AG5
AF6
AG6
AE5
T2
T1
U1
U2
C_TXLCLKOUT+
C_TXLCLKOUTÂC_TXLOUT0ÂC_TXLOUT0+
C_TXLOUT1ÂC_TXLOUT1+
C_TXLOUT2ÂC_TXLOUT2+
C_TXLOUT3ÂC_TXLOUT3+
C_TXUCLKOUTÂC_TXUCLKOUT+
C_TXUOUT0ÂC_TXUOUT0+
C_TXUOUT1ÂC_TXUOUT1+
C_TXUOUT2+
C_TXUOUT2ÂC_TXUOUT3ÂC_TXUOUT3+
L_DDCCLK
L_DDCDAT
CRT_HSYNC
CRT_VSYNC
L_CRT_R
L_CRT_G
L_CRT_B
L_S-CD1
L_S-YD1
L_S-CVBS1
TXC_HDMIÂTXC_HDMI+
TX0_HDMIÂTX0_HDMI+
TX1_HDMIÂTX1_HDMI+
TX2_HDMIÂTX2_HDMI+
IFPD_TCXÂIFPD_TCX+
IFPD_TC4ÂIFPD_TC4+
IFPD_TC5ÂIFPD_TC5+
IFPD_TC6ÂIFPD_TC6+
HDMI_SCL
HDMI_SDA
DAC_HSYNC
DAC_VSYNC
DAC_RED
DAC_GRN
DAC_BLU
27M_BUFO
GFX_27MSS
XTALI
C74418P/50V
Y6
27MHZ
XTALO
RP510X2
RP90X2
RP490X2
RP20X2
RP30X2
RP70X2
RP50X2
R1080R
R1100R
R920R
R910R
R270R
R250R
R290R
Close to NC7SB3157
R260R
R240R
R280R
2
1
4
3
2
1
4
3
2
1
4
3
4
3
2
1
T73
T97
4
3
2
1
4
3
2
1
2
1
4
3
2
1
4
3
T105
T107
Close to NC7SB3157
TXC_HDMI-18
TXC_HDMI+18
TX0_HDMI-18
TX0_HDMI+18
TX1_HDMI-18
TX1_HDMI+18
TX2_HDMI-18
TX2_HDMI+18
T197
T75
T182
T180
T198
T91
T79
T194
HDMI_SCL18
HDMI_SDA18
T108
T84
T85
T102
T71
R500*10K
21
C74518P/50V
TXLCLKOUT+
TXLCLKOUTÂTXLOUT0ÂTXLOUT0+
TXLOUT1ÂTXLOUT1+
TXLOUT2ÂTXLOUT2+
TXUCLKOUTÂTXUCLKOUT+
TXUOUT0ÂTXUOUT0+
TXUOUT1ÂTXUOUT1+
TXUOUT2+
TXUOUT2-
DDCCLK
DDCDAT
HSYNC
VSYNC
CRT_R
CRT_G
CRT_B
S-CD
S-YD
S-CVBS
27M_BUFO
TXLCLKOUT+18
TXLCLKOUT-18
TXLOUT0-18
TXLOUT0+18
TXLOUT1-18
TXLOUT1+18
TXLOUT2-18
TXLOUT2+18
TXUCLKOUT-18
TXUCLKOUT+18
TXUOUT0-18
TXUOUT0+18
TXUOUT1-18
TXUOUT1+18
TXUOUT2+18
TXUOUT2-18
DDCCLK17,19,31
DDCDAT17,19,31
HSYNC7,19
VSYNC7,19
CRT_R19,31
CRT_G19,31
CRT_B19,31
S-CD19,31
S-YD19,31
S-CVBS19,31
R510*22R
C746
*10P/50V
OPTION SIGNAL FROM NB FOR UMA VGA
TXLCLKOUTÂTXLCLKOUT+
TXLOUT0ÂTXLOUT0+
TXLOUT1ÂTXLOUT1+
TXLOUT2ÂTXLOUT2+
TXUCLKOUTÂTXUCLKOUT+
TXUOUT0ÂTXUOUT0+
TXUOUT1ÂTXUOUT1+
TXUOUT2ÂTXUOUT2+
L_CRT_R
L_CRT_G
L_CRT_B
L_S-CD1
L_S-YD1
L_S-CVBS1
RP50*0X2
3
1
RP10*0X2
1
3
RP46*0X2
1
3
RP48*0X2
3
1
RP1*0X2
3
1
RP4*0X2
3
1
RP8*0X2
1
3
RP6*0X2
3
1
R93150R
R90150R
R94150R
R100150R
R102150R
R101150R
Close to GPU
HDMI_SCL
HDMI_SDA
R4782.2K
R822.2K
10
LA_CLK#
4
LA_CLK
2
LA_DATAN0
2
LA_DATAP0
4
LA_DATAN1
2
LA_DATAP1
4
LA_DATAN2
4
LA_DATAP2
2
LB_CLK#
4
LB_CLK
2
LB_DATAN0
4
LB_DATAP0
2
LB_DATAN1
2
LB_DATAP1
4
LB_DATAN2
4
LB_DATAP2
2
3V
LA_CLK#7
LA_CLK7
LA_DATAN07
LA_DATAP07
LA_DATAN17
LA_DATAP17
LA_DATAN27
LA_DATAP27
LB_CLK#7
LB_CLK7
LB_DATAN07
LB_DATAP07
LB_DATAN17
LB_DATAP17
LB_DATAN27
LB_DATAP27
3V
Q40
3
AO3409
VGA_GD#
R46810K
3
Q39
2N7002E
1
2
5
3V
R464
10K
AA
IPFC_C
2
R473
*0A
15mil
1
IFPC_DVI_3V
C734
4.7UB
FOR IFPC VDD LEAKAGE CIRCIUT
EDIDCLK11,17,18
EDIDDATA11,17,18
4
3V
R501
10K
27M_BUFO
R51110K
ICSS_PD 3V_SSC
EDIDCLK
EDIDDATA
U29
8
PD#
1
CLKIN
7
SCL
6
SDA
ICS91730AM-T
VDD
CLKOUT
REFOUT
GND
I2C ADDRESS: 0xD4H
3
2
4
ICSS_RFO
5
3
R474
10K
3V
R483
R48422R
GFX27M_L
10K
12mils
C741
470P/X7R
C743
10P/50V
C742
.1U
GFX_27MSS
C737
4.7UB
R4774.7A
C736
4.7UB
2
SPREAD SPECTRUM
3V
PROJECT : AT8
Quanta Computer Inc.
SizeDocument NumberRev
Custom
NB5/RD2/HW1
GFX(LVDS, CRT, TV)
Date:Sheet of
1038Thursday, December 29, 2005
1
1A
PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com
5
15mil
C234*.1U
T189
T191
T200
MIOAVDD
MIOACAL_PU
MIOACAL_PD
MIOA_VREF
L260B
3V
DD
15milPCI_DEVICE2
C201*.1U
T181
T67
T206
MIOBVDD
MIOBCAL_PD
MIOBCAL_PU
MIOBVREF
GFX_THMDÂGFX_THMD+
JTAG_TCK
JTAG_TMS
JTAG_TDI
JTAG_TDO
JTAG_TRST#
STRAP
VGA_FU6
VGA_FU7
VGA_FU8
VGA_FU9
VGA_FU10
VGA_FU11
VGA_FU12
VGA_FU13
VGA_FU14
VGA_FU15
VGA_FU16
VGA_FU17
VGA_FU18
VGA_FU19
VGA_FU20
L230B
3V
CC
T115
T192
T116
T210
T212
T195
T68
T74
T106
T61
T76
T65
T83
T89
T185
BB
T98
T187
T77
T66
T101
T104
U35E
M7
MIOA_VDDQ_0
M8
MIOA_VDDQ_1
R8
MIOA_VDDQ_2
T8
MIOA_VDDQ_3
U9
MIOA_VDDQ_4
L3
MIOACAL_PU_GND
L1
MIOACAL_PD_VDDQ
L2
MIOA_VREF
AA8
MIOB_VDDQ_0
AB7
MIOB_VDDQ_1
AB8
MIOB_VDDQ_2
AC6
MIOB_VDDQ_3
AC7
MIOB_VDDQ_4
Y1
MIOBCAL_PD_VDDQ
Y3
MIOBCAL_PU_GND
Y2
MIOB_VREF
J1
THERMDN
K1
THERMDP
AJ11
JTAG_TCK
AK11
JTAG_TMS
AK12
JTAG_TDI
AL12
JTAG_TDO
AL13
JTAG_TRST#
F1
STRAP
U3
RFU6
V3
RFU7
U6
RFU8
U5
RFU9
U4
RFU10
V4
RFU11
V6
RFU12
W3
RFU13
V1
RFU14
Y5
RFU15
W1
RFU16
W4
RFU17
W5
RFU18
V5
RFU19
Y6
RFU20
U_GPU_G3
MIOAD
MIOBD
THERMAL
GPIO
MEMSTRAPSEL0
MEMSTRAPSEL1
MEMSTRAPSEL2
MEMSTRAPSEL3
ROM
MIOAD0
MIOAD1
MIOAD2
MIOAD3
MIOAD4
MIOAD5
MIOAD6
MIOAD7
MIOAD8
MIOAD9
MIOAD10
MIOAD11
MIOA_HSYNC
MIOA_VSYNC
MIOA_DE
MIOA_CTL3
MIOA_CLKOUT
MIOA_CLKOUT#
MIOA_CLKIN
MIOBD0
MIOBD1
MIOBD2
MIOBD3
MIOBD4
MIOBD5
MIOBD6
MIOBD7
MIOBD8
MIOBD9
MIOBD10
MIOBD11
MIOB_VSYNC
MIOB_HSYNC
MIOB_DE
MIOB_CTL3
MIOB_CLKOUT
MIOB_CLKOUT#
MIOB_CLKIN
CLAMP
I2CC_SCL
I2CC_SDA
GPIO0
GPIO1
GPIO2
GPIO3
GPIO4
GPIO5
GPIO6
GPIO7
GPIO8
GPIO9
GPIO10
GPIO11
GPIO12
ROMCS#
ROM_SI
ROM_SO
ROM_SCLK
I2CH_SCL
I2CH_SDA
BUFRST#
STEREO
SWAPRDY_A
TESTMEMCLK
TESTMODE
P2
N2
N1
N3
M1
M3
P5
N6
N5
M4
L4
L5
R3
R1
P1
P3
R4
P4
M5
AC3
AC1
AC2
AB2
AB1
AA1
AB3
AA3
AC5
AB5
AB4
AA5
AE3
AF3
AD1
AD3
AD4
AD5
AE4
F6
G2
G1
K3
H1
K5
G5
E2
J5
G6
K6
E1
D2
H5
F4
E3
AE26
AD26
AH31
AH32
AA4
W2
AA6
AA7
G3
H3
F3
T3
M6
A26
H2
4
MIOAD0
MIOAD1
MIOAD2
MIOAD3
MIOAD4
MIOAD5
MIOAD6
MIOAD7
MIOAD8
MIOAD9
MIOAD10
MIOAD11
MIOAHSYNC
MIOAVSYNC
MIOADE
MIOACTL3
MIOA_CKO
MIOA_CKO#
MIOA_CKI
MIOBD0
MIOBD1
MIOBD2
VIPD3
VIPD4
VIPD5
MIOBD6
MIOBD7
MIOBD8
MIOBD9
VIPD10
VIPD11
ROMTYPE1
G73_AF3
G73_AD1
G73_AD3
G73_AD4
G73_AD5
G73_AE4
G73_F6
EDIDCLK
EDIDDATA
HDMI_DET
GPIO1
DPST_PWM
DISP_ON
LVDS_BLON
GFX_VID0
GFX_VID1
GFX_VID2
VGA_OVT#
GPIO9
GPIO10
GPIO11
GFX_GPIO12
MSTRAPSEL0
MSTRAPSEL1
MSTRAPSEL2
MSTRAPSEL3
ROM_CS#
ROM_SI
ROM_SO
ROM_CK
HDCP_SCL
HDCP_SDA
RESET_BUF#
STEREO
SWAPRDY_A
VGA_TEST
VGA_TMODE
T188
T64
T204
T56
T60
T72
T87
T54
T184
T201
T86
T80
T57
T99
T196
T90
T81
T78
T70
T92
T190
T193
T93
T109
T69
T96
EDIDCLK10,17,18
EDIDDATA10,17,18
HDMI_DET18
T177
DPST_PWM17,18
DISP_ON17,18
LVDS_BLON17,18
T110
T82
T203
T100
T94
T123
T126
T220
T215
T95
T205
T103
T112
T88
T202
T113
R53810K
R49610K
3
FOR HDMI ONLY
3V
R528
10K
HDCP_SDA
HDCP_SCL
R512
10K
U31
5
SDA
3
SDA
6
SCL
2
NC2
AT88SC0808C
VCC
VCC
GND
GND
PCI DEVICE
PCI_DEVICE[3:0]
1000
0111
others
GFX_VID0
L : Low Voltage
H : Normal Voltage
GFX_VID0
JTAG_TMS
JTAG_TDI
JTAG_TCK
JTAG_TRST#
DISP_ON
HDMI_DET
GPIO1
DPST_PWM
LVDS_BLON
DESCRIPTION
G72M/G73M
G72M-V/G73M-V
Reserved
R81*10K
R51310K
R51810K
R12010K
R53610K
R9510K
R480*10K
R47910K
R9610K
R49510K
2
3V
8
7
C774
.1U
1
4
3V
R10610K
R505*10K
R10510K
R10410K
R5042K
R5022K
R5032K
R103*2K
R99*2K
R4972K
SHARE M/B SYSTEM BIOS, SUB VENDOR
ID NEED PULL DOWN .
G72M VRAM Configuration Table
RAM_CFG[3:0]
0000
0001
0010
0011
0100
0101
0110
0111
1000
1001
1010
1011Hynix
others
MIOBD0
MIOBD1
MIOBD8
MIOBD9
VIPD4
VIPD5
VIPD3
VIPD11
MIOAHSYNC
MIOAD1
DESCRIPTION
DDR2 16Mx16x4, 64bit, 128MB
DDR2 16Mx16x4, 64bit, 128MB
DDR2 16Mx16x4, 64bit, 128MB
DDR2 16Mx16x4, 64bit, 128MB
Reserved
DDR2 32Mx16x4, 64bit, 256MB
DDR2 32Mx16x4, 64bit, 256MB
DDR2 32Mx16x4, 64bit, 256MB
DDR2 16Mx16x2, 32bit, 64MB
DDR2 16Mx16x2, 32bit, 64MB
DDR2 16Mx16x2, 32bit, 64MB
DDR2 16Mx16x2, 32bit, 64MB
Reserved
R89*10K
R48810K
R88*10K
R87*10K
R487*2K
R485*2K
R486*2K
R862K
R852K
1
3V
11
RAM_CFG0
RAM_CFG1
RAM_CFG2
RAM_CFG3
PCI_DEVICE0
PCI_DEVICE1
PCI_DEVICE3
SLOT_CLOCK_CFG
SUB_VENDOR
Vendor
Elpida
Samsung
Infineon
Hynix
Samsung
Infineon
Hynix
Elpida
Samsung
Infineon
G73M VRAM Configuration Table
RAM_CFG[3:0]
0000
0001
0010
0011
0100
0101
0110
0111
1000
1001
1010
1011Hynix
1100
1101
1110
1111
DESCRIPTION
DDR2 16Mx16x8, 128bit, 256MB
DDR2 16Mx16x8, 128bit, 256MB
DDR2 16Mx16x8, 128bit, 256MB
DDR2 16Mx16x8, 128bit, 256MB
Reserved
DDR2 32Mx16x8, 128bit, 512MB
DDR2 32Mx16x8, 128bit, 512MB
DDR2 32Mx16x8, 128bit, 512MB
DDR2 16Mx16x4, 64bit, 128MB
DDR2 16Mx16x4, 64bit, 128MB
DDR2 16Mx16x4, 64bit, 128MB
DDR2 16Mx16x4, 64bit, 128MB
Reserved
DDR2 32Mx16x4, 64bit, 256MB
DDR2 32Mx16x4, 64bit, 256MB
DDR2 32Mx16x4, 64bit, 256MB
Vendor
Elpida
Samsung
Infineon
Hynix
Samsung
Infineon
Hynix
Elpida
Samsung
Infineon
Samsung
Infineon
Hynix
ALERT
GND
9
OVT
DXP
DXN
3
3V
R517
R514
*2.2K
2.2K
4
6
2
3
MAX6649_O#
MAX6649_A#
GFX_THMD+
C757
2200P/X7R
GFX_THMD-
R516
R515
Place close GPU
0R
*0R
VGA_OVT#
VGA_OVT#
2
R4992K
R498*2K
R982K
R972K R83*2K
MIOAD0
MIOAD6
MIOAD8
MIOAD9
NB5/RD2/HW1
SizeDocument NumberRev
Custom
Date:Sheet of
3V
R529
R530
*47K
*10K
C750
.1U
U30
7
SDAT
8
SCLK
1
VCC
5
GND
MAX6649
G799P8X
3
Q44
*2N7002E
2
1
EDIDDATA
EDIDCLK
3V
R5070R
R5060R
R508200A/F
GFX_SDA
GFX_SCL
MAX6649_V
VGA THERMAIL CIRCUIT
4
GFX_GPIO12 VGA_OVT#
AA
ACIN30,34
FOR BATTERY MODE FUNCTION
GFX_GPIO12=H ENABLE
GFX_GPIO12=L DISABLE
R531
*10K
G73_BATL
3
Q43
*2N7002E
2
1
5
C790
*.1U
MIOA_VDDQ
R482*2K
R4812K
R84*2K
PEX_PLL_EN
3GIO_PADCFG_LUT_ADR0
3GIO_PADCFG_LUT_ADR1
3GIO_PADCFG_LUT_ADR2
PROJECT : AT8
Quanta Computer Inc.
GFX(ROM, GPIO, STRAP)
1
1138Thursday, December 29, 2005
1A
PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com
5
4
3
2
1
Channel C is available on G73M only
VMC_DQ0
VMC_DQ1
VMC_DQ2
VMC_DQ3
VMC_DQ4
VMC_DQ5
VMC_DQ6
VMC_DQ7
VMC_DQ8
VMC_DQ9
VMC_DQ10
VMC_DQ11
VMC_DQ12
VMC_DQ13
VMC_DQ14
VMC_DQ15
VMC_DQ16
VMC_DQ17
VMC_DQ18
VMC_DQ19
VMC_DQ20
VMC_DQ21
VMC_DQ22
VMC_DQ23
VMC_DQ24
VMC_DQ25
VMC_DQ26
VMC_DQ27
VMC_DQ28
VMC_DQ29
VMC_DQ30
VMC_DQ31
VMC_DQ32
VMC_DQ33
VMC_DQ34
VMC_DQ35
VMC_DQ36
VMC_DQ37
VMC_DQ38
VMC_DQ39
VMC_DQ40
VMC_DQ41
VMC_DQ42
VMC_DQ43
VMC_DQ44
VMC_DQ45
VMC_DQ46
VMC_DQ47
VMC_DQ48
VMC_DQ49
VMC_DQ50
VMC_DQ51
VMC_DQ52
VMC_DQ53
VMC_DQ54
VMC_DQ55
VMC_DQ56
VMC_DQ57
VMC_DQ58
VMC_DQ59
VMC_DQ60
VMC_DQ61
VMC_DQ62
VMC_DQ63
VMC_DM0
VMC_DM1
VMC_DM2
VMC_DM3
VMC_DM4
VMC_DM5
VMC_DM6
VMC_DM7
VMC_WDQS0
VMC_WDQS1
VMC_WDQS2
VMC_WDQS3
VMC_WDQS4
VMC_WDQS5
VMC_WDQS6
VMC_WDQS7
VMC_RDQS0
VMC_RDQS1
VMC_RDQS2
VMC_RDQS3
VMC_RDQS4
VMC_RDQS5
VMC_RDQS6
VMC_RDQS7
B7
A7
C7
A2
B2
C4
A5
B5
F9
F10
D12
D9
E12
D11
E8
D8
E7
F7
D6
D5
D3
E4
C3
B4
C10
B10
C8
A10
C11
C12
A11
B11
B28
C27
C26
B26
C30
B31
C29
A31
D28
D27
F26
D24
E23
E26
E24
F23
B23
A23
C25
C23
A22
C22
C21
B22
E22
D22
D21
E21
E18
D19
D18
E19
A4
E11
F5
C9
C28
F24
C24
E20
C5
E10
E5
B8
A29
D25
B25
F20
C6
E9
E6
A8
B29
E25
A25
F21
U35C
FBCD0
FBCD1
FBCD2
FBCD3
FBCD4
FBCD5
FBCD6
FBCD7
FBCD8
FBCD9
FBCD10
FBCD11
FBCD12
FBCD13
FBCD14
FBCD15
FBCD16
FBCD17
FBCD18
FBCD19
FBCD20
FBCD21
FBCD22
FBCD23
FBCD24
FBCD25
FBCD26
FBCD27
FBCD28
FBCD29
FBCD30
FBCD31
FBCD32
FBCD33
FBCD34
FBCD35
FBCD36
FBCD37
FBCD38
FBCD39
FBCD40
FBCD41
FBCD42
FBCD43
FBCD44
FBCD45
FBCD46
FBCD47
FBCD48
FBCD49
FBCD50
FBCD51
FBCD52
FBCD53
FBCD54
FBCD55
FBCD56
FBCD57
FBCD58
FBCD59
FBCD60
FBCD61
FBCD62
FBCD63
FBCDQM0
FBCDQM1
FBCDQM2
FBCDQM3
FBCDQM4
FBCDQM5
FBCDQM6
FBCDQM7
FBCDQS_WP0
FBCDQS_WP1
FBCDQS_WP2
FBCDQS_WP3
FBCDQS_WP4
FBCDQS_WP5
FBCDQS_WP6
FBCDQS_WP7
FBCDQS_RN0
FBCDQS_RN1
FBCDQS_RN2
FBCDQS_RN3
FBCDQS_RN4
FBCDQS_RN5
FBCDQS_RN6
FBCDQS_RN7
U_GPU_G3
3
FBC
FBCAL_PD_VDDQ
FBCAL_TERM_GND
FBVTT_0
FBVTT_1
FBVTT_2
FBVTT_3
FBVTT_4
FBVTT_5
FBVTT_6
FBVTT_7
FBVTT_8
FBVTT_9
FBVTT_10
FBVTT_11
FBVTT_12
FBVTT_13
FBVTT_14
FBVTT_15
FBVTT_16
FBVTT_17
FBC_CMD0
FBC_CMD1
FBC_CMD2
FBC_CMD3
FBC_CMD4
FBC_CMD5
FBC_CMD6
FBC_CMD7
FBC_CMD8
FBC_CMD9
FBC_CMD10
FBC_CMD11
FBC_CMD12
FBC_CMD13
FBC_CMD14
FBC_CMD15
FBC_CMD16
FBC_CMD17
FBC_CMD18
FBC_CMD19
FBC_CMD20
FBC_CMD21
FBC_CMD22
FBC_CMD23
FBC_CMD24
FBC_CMD25
FBC_CMD26
FBC_CLK0
FBC_CLK0#
FBC_CLK1
FBC_CLK1#
RFU4
RFU5
FBC_DEBUG
FBC_REFCLK
FBC_REFCLK#
FBC_PLLVDD
FBC_PLLAVDD
FBC_PLLGND
FBCAL_PU_GND
FB_VREF2
AA23
C344.1U
AB23
C252.1U
H16
C321.1U
H17
C390.1U
J10
C282.47UA
J23
C297.47UA
J24
C24810UA
J9
C345.1U
K11
C328.1U
K12
C272.1U
K21
C246.1U
K22
C329.47UA
K24
C220.47UA
K9
C31210UA
L23
M23
T25
PLACE NEAR GPU
U25
VMC_MA3
C13
VMC_MA0
A16
VMC_MA2
A13
VMC_MA1
B17
VMC_MA3H
B20
VMC_MA4H
A19
VMC_MA5H
B19
VMC_BA2
B14
VMC_CS0#
E16
VMC_WE#
A14
VMC_BA0
C15
VMC_CKE
B16
VMC_RST#
F17
VMC_MA2H
C19
VMC_MA12
D15
VMC_RAS#
C17
VMC_MA11
A17
VMC_MA10
C16
VMC_BA1
D14
VMC_MA8
F16
VMC_MA9
C14
VMC_MA6
C18
VMC_MA5
E14
VMC_MA7
B13
VMC_MA4
E15
VMC_CAS#
F15
VMC_MA13
A20
VMC_CLK0
E13
VMC_CLK0#
F13
VMC_CLK1
F18
VMC_CLK1#
E17
G73_C20
C20
G73_D1
D1
VMC_DEBUG
F12
VMC_REFCK
B1
VMC_REFCK#
C1
G73_G8
G8
G10
G9
K26
H26
J26
A28
FBC_PLLAVDD
C227
470P/X7R
FBCAL_PD
R13640.2A/F
FBCAL_PU
R14030.1F
FBCAL_TERM
R137*40.2F
15mil
FB_VREF2
R5431K
R542
C817
1K
.1U
G73M : Stuff these parts
G72M : NC
T111
T118
T214
T213
T186
T114
T199
T183
C226
4700P
2
VMC_MA314
VMC_MA014
VMC_MA214
VMC_MA114
VMC_MA3H14
VMC_MA4H14
VMC_MA5H14
VMC_CS0#14
VMC_WE#14
VMC_BA014
VMC_CKE14
VMC_MA2H14
VMC_MA1214
VMC_RAS#14
VMC_MA1114
VMC_MA1014
VMC_BA114
VMC_MA814
VMC_MA914
VMC_MA614
VMC_MA514
VMC_MA714
VMC_MA414
VMC_CAS#14
VMC_CLK014
VMC_CLK0#14
VMC_CLK114
VMC_CLK1#14
L34
BLM18PG330SN1D
15mil
C218
4.7UA
1.8V
VMA_RST#
R5440R
VMC_RST# VMC_ODT
R1250R
1.2V
1.8V
SizeDocument NumberRev
NB5/RD2/HW1
Custom
Date:Sheet of
VMA_DQ[63..0]13
VMA_DM[7..0]13
VMA_WDQS[7..0]13
VMA_RDQS[7..0]13
VMC_DQ[63..0]14
VMC_DM[7..0]14
VMC_WDQS[7..0]14
VMC_RDQS[7..0]14
VMA_ODT
G72M/G73M: STUFF
R545
UMA:NC
10K
G72M/G73M: STUFF
R124
UMA:NC
10K
PROJECT : AT8
Quanta Computer Inc.
GFX (MEM INTERFACE)
1
12
VMA_ODT13
VMC_ODT14
1A
1238Thursday, December 29, 2005
C822
.1U
M27
AD29
AE29
AD28
AC28
AB29
AA30
AB30
AM30
AF30
AJ31
AJ30
AJ32
AK29
AM31
AL30
AE32
AE30
AE31
AD30
AC31
AC32
AB32
AB31
AG27
AF28
AH28
AG28
AG29
AD27
AF27
AE28
M29
M30
G30
AA29
AK30
AC30
AG30
G32
G28
AB28
AL32
AF32
AH30
M28
G31
G27
AA28
AL31
AF31
AH29
N27
N28
L29
K27
K28
J29
J28
P30
N31
N30
N32
L31
L30
J30
L32
H30
K30
H31
F30
H32
E31
D30
E30
H28
H29
E29
J27
F27
E27
E28
F28
Y28
F29
L28
K31
K32
E32
U35B
FBAD0
FBAD1
FBAD2
FBAD3
FBAD4
FBAD5
FBAD6
FBAD7
FBAD8
FBAD9
FBAD10
FBAD11
FBAD12
FBAD13
FBAD14
FBAD15
FBAD16
FBAD17
FBAD18
FBAD19
FBAD20
FBAD21
FBAD22
FBAD23
FBAD24
FBAD25
FBAD26
FBAD27
FBAD28
FBAD29
FBAD30
FBAD31
FBAD32
FBAD33
FBAD34
FBAD35
FBAD36
FBAD37
FBAD38
FBAD39
FBAD40
FBAD41
FBAD42
FBAD43
FBAD44
FBAD45
FBAD46
FBAD47
FBAD48
FBAD49
FBAD50
FBAD51
FBAD52
FBAD53
FBAD54
FBAD55
FBAD56
FBAD57
FBAD58
FBAD59
FBAD60
FBAD61
FBAD62
FBAD63
FBADQM0
FBADQM1
FBADQM2
FBADQM3
FBADQM4
FBADQM5
FBADQM6
FBADQM7
FBADQS_WP0
FBADQS_WP1
FBADQS_WP2
FBADQS_WP3
FBADQS_WP4
FBADQS_WP5
FBADQS_WP6
FBADQS_WP7
FBADQS_RN0
FBADQS_RN1
FBADQS_RN2
FBADQS_RN3
FBADQS_RN4
FBADQS_RN5
FBADQS_RN6
FBADQS_RN7
FB_VREF1
U_GPU_G3
FBA
FBVDD_0
FBVDD_1
FBVDD_2
FBVDD_3
FBVDD_4
FBVDD_5
FBVDD_6
FBVDD_7
FBVDD_8
FBVDD_9
FBVDD_10
FBVDD_11
FBVDD_12
FBVDD_13
FBVDD_14
FBVDD_15
FBVDD_16
FBVDD_17
FBVDD_18
FBVDD_19
FBVDDQ_0
FBVDDQ_1
FBVDDQ_2
FBVDDQ_3
FBVDDQ_4
FBVDDQ_5
FBVDDQ_6
FBVDDQ_7
FBVDDQ_8
FBVDDQ_9
FBVDDQ_10
FBVDDQ_11
FBVDDQ_12
FBVDDQ_13
FBVDDQ_14
FBVDDQ_15
FBVDDQ_16
FBVDDQ_17
FBVDDQ_18
FBVDDQ_19
FBVDDQ_20
FBVDDQ_21
FBVDDQ_22
FBVDDQ_23
FBA_CMD0
FBA_CMD1
FBA_CMD2
FBA_CMD3
FBA_CMD4
FBA_CMD5
FBA_CMD6
FBA_CMD7
FBA_CMD8
FBA_CMD9
FBA_CMD10
FBA_CMD11
FBA_CMD12
FBA_CMD13
FBA_CMD14
FBA_CMD15
FBA_CMD16
FBA_CMD17
FBA_CMD18
FBA_CMD19
FBA_CMD20
FBA_CMD21
FBA_CMD22
FBA_CMD23
FBA_CMD24
FBA_CMD25
FBA_CMD26
FBA_CLK0
FBA_CLK0#
FBA_CLK1
FBA_CLK1#
RFU2
RFU3
FBA_DEBUG
FBA_REFCLK
FBA_REFCLK#
FBA_PLLVDD
FBA_PLLAVDD
FBA_PLLGND
A12
A15
A18
A21
A24
A27
A3
A30
A6
A9
AA32
AD32
AG32
AK32
C32
F32
J32
M32
R32
V32
AA25
AA26
AB25
AB26
G11
G12
G15
G18
G21
G22
H11
H12
H15
H18
H21
H22
L25
L26
M25
M26
R25
R26
V25
V26
P32
U27
P31
U30
Y31
W32
W31
T32
V27
T28
T31
U32
W29
W30
T27
V28
V30
U31
R27
V29
T30
W28
R29
R30
P29
U28
Y32
P28
R28
Y27
AA27
Y30
AC26
AC27
D32
D31
G23
G25
G24
C402.1U
C401.1U
C193.1U
C202.1U
C342.47UA
C349.47UA
C23510UA
C385.1U
C383.1U
C366.1U
C261.1U
C267.47UA
C290.47UA
C34610UA
PLACE NEAR GPU
C387.1U
C386.1U
C332.1U
C397.1U
C343.47UA
C338.47UA
C34110UA
C357.1U
C365.1U
C389.1U
C391.1U
C260.47UA
C347.47UA
C36710UA
PLACE NEAR GPU
VMA_MA3
VMA_MA0
VMA_MA2
VMA_MA1
VMA_MA3H
VMA_MA4H
VMA_MA5H
VMA_BA2
VMA_CS0#
VMA_WE#
VMA_BA0
VMA_CKE
VMA_RST#
VMA_MA2H
VMA_MA12
VMA_RAS#
VMA_MA11
VMA_MA10
VMA_BA1
VMA_MA8
VMA_MA9
VMA_MA6
VMA_MA5
VMA_MA7
VMA_MA4
VMA_CAS#
VMA_MA13
VMA_CLK0
VMA_CLK0#
VMA_CLK1
VMA_CLK1#
G73_Y30
G73_AC26
VMA_DEBUG
VMA_REFCK
VMA_REFCK#
G73_G23
FBA_PLLAVDD
15mil
C418
4700P
C416
470P/X7R
VMA_MA313
VMA_MA013
VMA_MA213
VMA_MA113
VMA_MA3H13
VMA_MA4H13
VMA_MA5H13
T218
VMA_CS0#13
VMA_WE#13
VMA_BA013
VMA_CKE13
VMA_MA2H13
VMA_MA1213
VMA_RAS#13
VMA_MA1113
VMA_MA1013
VMA_BA113
VMA_MA813
VMA_MA913
VMA_MA613
VMA_MA513
VMA_MA713
VMA_MA413
VMA_CAS#13
T217
VMA_CLK013
VMA_CLK0#13
VMA_CLK113
VMA_CLK1#13
T219
T124
T125
T221
T216
T122
C420
4.7UA
For EMI
1.8V 1.8V
1.8V
L42
BLM18PG330SN1D
C348
.1U
1.2V
VMA_DQ0
VMA_DQ1
VMA_DQ2
VMA_DQ3
VMA_DQ4
VMA_DQ5
VMA_DQ6
VMA_DQ7
R5501K
R549
1K
VMA_DQ8
VMA_DQ9
VMA_DQ10
VMA_DQ11
VMA_DQ12
VMA_DQ13
VMA_DQ14
VMA_DQ15
VMA_DQ16
VMA_DQ17
VMA_DQ18
VMA_DQ19
VMA_DQ20
VMA_DQ21
VMA_DQ22
VMA_DQ23
VMA_DQ24
VMA_DQ25
VMA_DQ26
VMA_DQ27
VMA_DQ28
VMA_DQ29
VMA_DQ30
VMA_DQ31
VMA_DQ32
VMA_DQ33
VMA_DQ34
VMA_DQ35
VMA_DQ36
VMA_DQ37
VMA_DQ38
VMA_DQ39
VMA_DQ40
VMA_DQ41
VMA_DQ42
VMA_DQ43
VMA_DQ44
VMA_DQ45
VMA_DQ46
VMA_DQ47
VMA_DQ48
VMA_DQ49
VMA_DQ50
VMA_DQ51
VMA_DQ52
VMA_DQ53
VMA_DQ54
VMA_DQ55
VMA_DQ56
VMA_DQ57
VMA_DQ58
VMA_DQ59
VMA_DQ60
VMA_DQ61
VMA_DQ62
VMA_DQ63
VMA_DM0
VMA_DM1
VMA_DM2
VMA_DM3
VMA_DM4
VMA_DM5
VMA_DM6
VMA_DM7
VMA_WDQS0
VMA_WDQS1
VMA_WDQS2
VMA_WDQS3
VMA_WDQS4
VMA_WDQS5
VMA_WDQS6
VMA_WDQS7
VMA_RDQS0
VMA_RDQS1
VMA_RDQS2
VMA_RDQS3
VMA_RDQS4
VMA_RDQS5
VMA_RDQS6
VMA_RDQS7
15mil
FB_VREF1
DD
CC
BB
AA
1.8V
VREF = FBVDDQ * Rbot/(Rtop + Rbot)
5
4
PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com
Loading...
