QDSP-5001 Series
Fanless Box PC w/ Intel® Celeron Dual Core / Core i Processor
User’s Guide
QDSP-5001 Series User’s Manual
I
Contact Info: Quanmax Inc.
4F, No. 415, Ti-Ding Blvd. Sec. 2NeiHu District,
Taipei 114Taiwan
Tel: +886-2-2799-2789
Fax: +886-2-2799-7399
Visit our site at: www.quanmax.com
© 2013 Quanmax Inc. All rights reserved.
The information in this user’s guide is provided for reference only. Quanmax does not assume any
liability arising out of the application or use of the information or products described herein. This user’s
guide may contain or reference information and products protected by copyrights or patents and does
not convey any license under the patent rights of Quanmax, nor the rights of others.
Quanmax is a registered trademark of Quanmax. All trademarks, registered trademarks, and trade
names used in this user’s guide are the property of their respective owners. All rights reserved. This
user’s guide contains information proprietary to Quanmax. Customers may reprint and use this user’s
guide in other publications. Customers may alter this user’s guide and publish it only after they remove
the Quanmax name, cover, and logo.
Quanmax reserves the right to make changes without notice in product or component design as
warranted by evolution in user needs or progress in engineering or manufacturing technology.
Changes which affect the operation of the unit will be documented in the next revision of this user’s
guide.
QDSP-5001 Series User’s Manual
II
Content
Content
Content ....................................................................................................................... 3
Figures ....................................................................................................................... 4
Tables ......................................................................................................................... 5
Safety Instructions ...................................................................................................... 6
Before You Begin ......................................................................................... 6
When Working Inside a Computer ............................................................... 7
Preventing Electrostatic Discharge .............................................................. 7
Instructions for Lithium Battery .................................................................... 8
Preface ....................................................................................................................... 9
How to Use This Guide ................................................................................ 9
Unpacking .................................................................................................... 9
Regulatory Compliance Statements ............................................................ 9
Warranty Policy ......................................................................................... 10
Maintaining Your Computer ....................................................................... 12
Chapter 1 Introduction ........................................................................................... 14
Overview ................................................................................................... 14
Product Specifications ............................................................................... 15
System tour ............................................................................................... 16
Mechanical Dimensions ............................................................................. 19
Chapter 2 Getting Started ...................................................................................... 20
Setting up your PC .................................................................................... 20
Chapter 3 AMI BIOS Setup .................................................................................... 24
Overview ................................................................................................... 24
Main Menu ................................................................................................. 25
Advanced Menu ......................................................................................... 26
Boot Menu ................................................................................................. 38
Security Menu ............................................................................................ 39
Save & Exit Menu ...................................................................................... 40
Chapter 4 Driver Installation .................................................................................. 42
QDSP-5001 Series User’s Manual
3
Figures
Figures
Figure 1 Front Panel .................................................................................. 16
Figure 2 Rear Panel ................................................................................... 18
Figure 3 Mechanical Dimensions ............................................................... 19
Figure 4 Connect the DP /HDMI cable ....................................................... 20
Figure 5 Connecting USB mouse & keyboard ............................................ 21
Figure 6 Network cable with RJ45 connector ............................................. 21
Figure 7 COM Ports ................................................................................... 22
Figure 8 Turning on the system .................................................................. 23
QDSP-5001 Series User’s Manual
4
Tables
Tables
Table 1 QDSP-5001 Series Specification ................................................... 15
Table 2 BIOS Main Menu ........................................................................... 25
Table 3 Advanced Menu ............................................................................. 26
Table 4 Advanced Menu – Display Configuration ....................................... 27
Table 5 Advanced Menu –Power Management Configuration .................... 28
Table 6 Advanced Menu –CPU Advanced Configuration ........................... 29
Table 7 Advanced Menu –AMT Configuration ............................................ 30
Table 8 Advanced Menu –Trusted Computing ........................................... 31
Table 9 Advanced Menu –SATA Configuration ........................................... 32
Table 10 Advanced Menu – Intel Rapid Start Technology .......................... 33
Table 11 Advanced Menu –Intel TXT (LT) Configuration ............................ 33
Table 12 Advanced Menu –USB Configuration .......................................... 34
Table 13 Advanced Menu – Super IO Configuration .................................. 35
Table 14 Advanced Menu –Super IO Configuration – Serial Port 1
Configuration ............................................................................... 35
Table 15 Advanced Menu –Super IO Configuration – Serial Port 2
Configuration ............................................................................... 36
Table 16 Advanced Menu –H/W Monitor .................................................... 37
Table 17 Boot Menu ................................................................................... 38
Table 18 Security Menu ............................................................................. 39
Table 19 Save & Exit Menu ........................................................................ 40
QDSP-5001 Series User’s Manual
5
Safety Instructions
Safety Instructions
Before You Begin
Before handling the product, read the instructions and safety guidelines on the
following pages to prevent damage to the product and to ensure your own personal
safety. Refer to the “Advisories” section in the Preface for advisory conventions used
in this user’s guide, including the distinction between Warnings, Cautions, Important
Notes, and Notes.
Always use caution when handling/operating a computer. Only qualified,
experienced, authorized electronics service personnel should access the
interior of a computer. The power supplies produce high voltages and
energy hazards, which can cause bodily harm.
Use extreme caution when installing or removing components. Refer to the
installation instructions in this user’s guide for precautions and procedures.
If you have any questions, please contact Quanmax Post-Sales Technical
Support.
Access can only be gained by service persons or by users who have been
instructed about the reasons for the restrictions applied to the location and
about any precautions that shall be taken; and access is through the use of
a tool or lock and key, or other means of security, and is controlled by
authority responsible for the location.
WARNING
High voltages are present inside the chassis when the unit’s power cord is
plugged into an electrical outlet. Turn off system power, turn off the power
supply, and then disconnect the power cord from its source before
removing the chassis cover. Turning off the system power switch does not
remove power to components.
QDSP-5001 Series User’s Manual
6
Safety Instructions
When Working Inside a Computer
Before taking covers off a computer, perform the following steps:
1. Turn off the computer and any peripherals.
2. Disconnect the computer and peripherals from their power sources or
subsystems to prevent electric shock or system board damage. This does not
apply when hot swapping parts.
3. Follow the guidelines provided in “Preventing Electrostatic Discharge” on the
following page.
4. Disconnect any telephone or telecommunications lines from the computer.
In addition, take note of these safety guidelines when appropriate:
To help avoid possible damage to system boards, wait five seconds after
turning off the computer before removing a component, removing a system
board, or disconnecting a peripheral device from the computer.
When you disconnect a cable, pull on its connector or on its strain-relief loop,
not on the cable itself. Some cables have a connector with locking tabs. If you
are disconnecting this type of cable, press in on the locking tabs before
disconnecting the cable. As you pull connectors apart, keep them evenly
aligned to avoid bending any connector pins. Also, before connecting a cable,
make sure both connectors are correctly oriented and aligned.
CAUTION
Do not attempt to service the system yourself except as explained in this
user’s guide. Follow installation and troubleshooting instructions closely.
Preventing Electrostatic Disch ar ge
Static electricity can harm system boards. Perform service at an ESD workstation
and follow proper ESD procedure to reduce the risk of damage to components.
Quanmax strongly encourages you to follow proper ESD procedure, which can
include wrist straps and smocks, when servicing equipment.
You can also take the following steps to prevent damage from electrostatic
discharge (ESD):
QDSP-5001 Series User’s Manual
7
Safety Instructions
When unpacking a static-sensitive component from its shipping carton, do not
remove the component’s antistatic packing material until you are ready to install
the component in a computer. Just before unwrapping the antistatic packaging,
be sure you are at an ESD workstation or grounded. This will discharge any
static electricity that may have built up in your body.
When transporting a sensitive component, first place it in an antistatic container
or packaging.
Handle all sensitive components at an ESD workstation. If possible, use
antistatic floor pads and workbench pads.
Handle components and boards with care. Don’t touch the components or
contacts on a board. Hold a board by its edges or by its metal mounting bracket.
Do not handle or store system boards near strong electrostatic, electromagnetic,
magnetic, or radioactive fields.
Instructions for Lithium Battery
WARNING
Danger of explosion when battery is replaced with incorrect type. Only replace
with the same or equivalent type recommended by the manufacturer.
Do not dispose of lithium batteries in domestic waste. Dispose of the battery
according to the local regulations dealing with the disposal of these special
materials (e.g. to the collecting points for disposal of batteries)
QDSP-5001 Series User’s Manual
8
Preface
Preface
How to Use This Guide
This guide is designed to be used as step-by-step instructions for installation, and as
a reference for operation, troubleshooting, and upgrades.
NOTE
Driver downloads and additional information are available under
Downloads on our web site: www.quanmax.com.
Unpacking
When unpacking, follow these steps:
1. After opening the box, save it and the packing material for possible future
shipment.
2. Remove all items from the box. If any items listed on the purchase order
are missing, notify Quanmax customer service immediately.
3. Inspect the product for damage. If there is damage, notify Quanmax
customer service immediately. Refer to “Warranty Policy” for the return
procedure.
Regulatory Compliance Statements
This section provides the FCC compliance statement for Class A devices.
FCC Compliance Statement:
This equipment has been tested and found to comply with limits for a Class A digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reason able protection against harmful interference in residential installations. This
equipment generates, uses, and can radiate radiofrequency energy, and if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
QDSP-5001 Series User’s Manual
9
Preface
interference to radio or television equipment reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by your dealer could void the
user's authority to operate the equipment.
NOTE
The assembler of a personal computer system may be required to test
the system and/or make necessary modifications if a system is found to
cause harmful interference or to be noncompliant with the appropriate
standards for its intended use.
Warranty Policy
Limited Warranty
Please consult your distributor for warranty verification.
The limited warranty is void if the product has been subjected to alteration, neglect,
misuse, or abuse; if any repairs have been attempted by anyone other than your
manufacturer or its authorized agent; or if the failure is caused by accident, acts of
God, or other causes beyond the control of your dealer or the manufacturer. Neglect,
misuse, and abuse shall include any installation, operation, or maintenance of the
product other than in accordance with the user’s guide.
No agent, dealer, distributor, service company, or other party is authorized to change,
modify, or extend the terms of this Limited Warranty in any manner whatsoever. Your
manufacturer reserves the right to make changes or improvements in any product
without incurring any obligation to similarly alter products previously purchased.
QDSP-5001 Series User’s Manual
10
Preface
Return Procedure
For any Limited Warranty return, please contact with your dealer.
All product(s) returned to your dealer for service or credit must be accompanied by a
Return Material Authorization (RMA) Number. Freight on all returned items must be
prepaid by the customer who is responsible for any loss or damage caused by
common carrier in transit. Returns for Warranty must include a Failure Report for
each unit, by serial number(s), as well as a copy of the original invoice showing the
date of purchase.
To reduce risk of damage, returns of product must be in a shipping container. If the
original container has been lost or damaged, new shipping containers may be
obtained from your dealer’s Customer Service at a nominal cost.
We own all parts removed from repaired products. We use new and reconditioned
parts made by various manufacturers in performing warranty repairs and building
replacement products. If your dealer repairs or replaces a product, its warranty term
is not extended.
Shipments not in compliance with this Limited Warranty Return Policy will not be
accepted by us.
Limitation of Liability
In no event shall your dealer be liable for any defect in hardware, software, loss, or
inadequacy of data of any kind, or for any direct, indirect, incidental, or
consequential damages in connection with or arising out of the performance or use
of any product furnished hereunder. Our liability shall in no event exceed the
purchase price of the product purchased hereunder. The foregoing limitation of
liability shall be equally applicable to any service provided by us or its authorized
agent.
QDSP-5001 Series User’s Manual
11
Maintaining Your Computer
Environmental Factors
Temperature
The ambient temperature within an enclosure may be greater than room
ambient temperature. Installation in an enclosure should be such that the
amount of air flow required for safe operation is not compromised.
Consideration should be given to the maximum rated ambient temperature.
Overheating can cause a variety of problems, including premature aging and
failure of chips or mechanical failure of devices.
If the system has been exposed to abnormally cold temperatures, allow a
two-hour warm-up period to bring it up to normal operating temperature before
turning it on. Failure to do so may cause damage to internal components,
Preface
particularly the hard disk drive.
Humidity
High-humidity can cause moisture to enter and accumulate in the system. This
moisture can cause corrosion of internal components and degrade such
properties as electrical resistance and thermal conductivity. Extreme moisture
buildup inside the system can result in electrical shorts, which can cause
serious damage to the system.
Buildings in which climate is controlled usually maintain an acceptable level of
humidity for system equipment. However, if a system is located in an unusually
humid location, a dehumidifier can be used to maintain the humidity within an
acceptable range. Refer to the “Specifications” section of this user’s guide for
the operating and storage humidity specifications.
Altitude
Operating a system at a high altitude (low pressure) can cause electrical
problems related to arcing and corona effects. This condition can also cause
sealed components with internal pressure, such as electrolytic capacitors, to fail
or perform at reduced efficiency.
QDSP-5001 Series User’s Manual
12
Preface
Power Protection
The greatest threats to a system’s supply of power are power loss, power spikes,
and power surges caused by electrical storms, which interrupt system operation
and/or damage system components. To protect your system, always properly
ground power cables and one of the following devices.
Surge Protector
Surge protectors are available in a variety of types and usually provide a level
of protection proportional with the cost of the device. Surge protectors prevent
voltage spikes from entering a system through the AC power cord. Surge
protectors, however, do not offer protection against brownouts, which occur
when the voltage drops more than 20 percent below the normal AC line voltage
level.
Line Conditioner
Line conditioners go beyond the over voltage protection of surge protectors.
Line conditioners keep a system’s AC power source voltage at a fairly constant
level and, therefore, can handle brownouts. Because of this added protection,
line conditioners cost more than surge protectors. However, line conditioners
cannot protect against a complete loss of power.
Uninterruptible Power Supply
Uninterruptible power supply (UPS) systems offer the most complete protection
against variations on power because they use battery power to keep the server
running when AC power is lost. The battery is charged by the AC power while it
is available, so when AC power is lost, the battery can provide power to the
system for a limited amount of time, depending on the UPS system.
UPS systems range in price from a few hundred dollars to several thousand
dollars, with the more expensive unit s allowing you to run larger systems for a
longer period of time when AC power is lost. UPS systems that provide only 5
minutes of battery power let you conduct an orderly shutdown of the system,
but are not intended to provide continued operation. Surge protectors should be
used with all UPS systems, and the UPS system should be Underwriters
Laboratories (UL) safety approved.
QDSP-5001 Series User’s Manual
13
Chapter 1
Chapter 1
Introduction
Overview
The QDSP-5001 Series is a fanless Box PC ideal for space critical applications. This
embedded hardware platform features Intel® Celeron Dual Core / Core i Processor,
Intel® HM76 Express chipset, and DDR3 1333/1600 SO-DIMM. It comes with 2.5”
SSD, mSATA, 2x Mini-PCIe slots, HDMI, 2x DP, 2x USB2.0, 4x USB3.0, 2x COM,
and Audio. The QDSP-5001 provides triple-independent display and dual storage,
high reliability rugged case not only for great protection from EMI, cold and heat, but
also integrated with passive cooling design for quiet fanless operation such as Digital
Signage.
Checklist
QDSP-5001 series
Power Adapter
Power Cord
Driver CD
Quick installation Guide
Optional VESA-mount and Wall-Mount
Optional wireless LAN / 3G
Features
Intel
DDR3 1333/1600 MHz memory support up to 16 GB
®
Celeron Dual Core / Core i Processor / Intel
®
HM76 Express Chipset
1x HDMI, 2x DP, 1x S/PDIF Output and Clear CMOS
2x USB2.0, 4x USB3.0, 2x COM, 2x GbE LAN and Audio
1x mSATA, 2x Mini-PCIe slots
Triple-independent display /Dual storage
TPM, iAMT supported
Optional VESA-mount and Wall-Mount
QDSP-5001 Series User’s Manual
14
Product Specifications
Chapter 1
Dimensions
Chipset
CPU support
Memory
BIOS
Storage
Front IO
220 x 153.3 x 38 mm (W x D x H)
Intel® HM76 Express Chipset
QDSP-5001-Intel® 3rd generation Core i5 Processor 3337U
QDSP-5002-Intel® 3rd generation Core i3 Processor 3227U
QDSP-5004-Intel® Celeron® Processor 1037U
QDSP-5005- Intel® Celeron® Processor 1047UE
2x Single Channel DDR3 1333/1600MHz SODIMM support (16 GB max)
AMI Plug & Play SPI BIOS
1x 2.5” SSD
1x eSATA and USB 2.0 combo connector and 1x m SATA
■ Realtek ALC662 HD Codec w/ 2W Audio Amplifier, Mic-In, Line-In, Line-Out
■ 1x S/PDIF Output
■ 1x eSATA and USB 2.0 combo supported
■ 2x USB 2.0 2x USB 3.0
■ 1x Power Button with Power LED1x Storage HDD status LED ( RED )
■ 1x Wifi /3G status LED ( Green )
Rear IO
Expansion Slot
TPM / iAMT
OS Support
Hardw are Moni tor
Watchdog Timer
Power
Temperature /
Humidity
Mounting
■ 1x Clear CMOS
■ 1x DC JACK
■ 1x HDMI , 2x DP
■ 2x RJ-45 GbE ports (Realtek RTL8111E/ Intel 82579 )PXE / WOL supported
■ 2x USB 3.0, 2x COM Ports support RS-232/422/485
■ 2x WiFi External Antennas ( optional )
■ 1x 3G External Antenna ( optional )
2x Mini-PCIe slots (SIM Card socket supported)
TPM, iAMT supported
Windows 7/ Windows 8 / Linux
Operating voltage, CPU temperature
1-255 step, can be set with software on Super I/O
DC 19V Input
Operating: 0°C to 40°C, 0%-90%, non-condensing
Storage: -20°C to 80°C, 0%-90%, non-condensing
Optional VESA-mount and Wall-Mount
Certifications
CE, FCC Class A
Table 1 QDSP-5001 Series Specification
QDSP-5001 Series User’s Manual
15
System tour
Refer to the figures below to identify the components of the system.
Front Panel
Chapter 1
Figure 1 Front Panel
Power Switch
The power push button allows powering ON and OFF the system.
Clear CMOS Button
To clear the CMOS, use the tip of a pen to press the button briefly
Power LED (Blue)
The power LED will light when the PC is power-on.
HDD LED (Red)
The hard disk LED blinks when data is being written into or read from the HDD.
WiFi LED (Green)
When the data is Transferring, the WiFi LED will blink.
USB
The USB (Universal Serial Bus) port is compatible with USB devices such as
keyboards, mouse devices, cameras, and hard disk drives. USB allows many
devices to run simultaneously on a single computer, with some peripheral
acting as additional plug-in sites or hubs.
QDSP-5001 Series User’s Manual
16
eSATA/USB (combo)
This provides eSATA and USB connectivity as a combo con
S/PDIF
S/PDIF output for carrying digital audio signals out to the device.
Phone Jack
Audio Out
The stereo headphone jack is used to connect the system’s audio out signal to
amplified speakers or headphones.
MIC-IN
The microphone jack is designed to connect the microphone used for video
conferencing, voice narrations, or simple audio recordings.
Chapter 1
Line-IN
The Line-in jack is designed to take input from a higher-powered sound
source.
CAUTION
This connector do not support hot-swapping. Users should not connect or
disconnect their eSATA/USB devices from PC when the system is working.
QDSP-5001 Series User’s Manual
17
Rear Panel
Figure 2 Rear Panel
COM
COM 1/COM 2 - D-Sub 9 pin connector for RS-232/422/485 connection
Chapter 1
Ethernet
The eight-pin RJ-45 LAN port supports a standard Ethernet cable for
connection to a local network.
HDMI
HDMI connector for display output
DC Jack
The supplied power adapter converts AC power to DC for use with this jack.
Power supplied through this jack supplies power to the PC. To prevent damage
to the PC, always use the supplied power adapter.
DP
DP is a display interface used to connect a video source to a display device such
as a computer monitor or a television set.
WiFi / 3G External Antenna (optional)
Spared hole on the casing for connecting WiFi /3G external antenna
USB
The USB (Universal Serial Bus) port is compatible with USB devices such as
keyboards, mouse devices, cameras, and hard disk drives. USB allows many
devices to run simultaneously on a single computer, with some peripheral
acting as additional plug-in sites or hubs.
QDSP-5001 Series User’s Manual
18
Mech anical Dimension s
Chapter 1
Dimension: 220 x 38 x 153.3 mm (W x H x D)
Figure 3 Mechanical Dimensions
QDSP-5001 Series User’s Manual
19
Chapter 2
Getting Started
Setting up your PC
￭ Connect the monitor, mouse and keyboard
Connecting the monitor
Connect the DP/ HDMI cable from your display to the DP/ HDMI port.
Chapter 2
Figure 4 Connect the DP /HDMI cab le
HDMI
2xDP
QDSP-5001 Series User’s Manual
20
Chapter 2
Connecting USB mouse & keyboard
Your QDSP-5001 does not come with a keyboard and mouse, but you can use any
USB keyboard or mouse with your computer.
2xUSB 3.0
Using a third-party USB mouse or keyboard may require software drivers.
2x USB 2.0
2xUSB 3.0 eSATA/USB2.0
Figure 5 Connecting USB mouse & keyboard
NOTE
Check the manufacturer’s website for the latest software drivers.
Connecting to a network devic e
Connect one end of a network cable to the LAN port on the system rear panel
and the other end to a hub or switch.
2x LAN
Figure 6 Network cable with RJ45 connector
QDSP-5001 Series User’s Manual
21
Pin RS-232
RS-422
Half Duplex RS-485
Full Duplex RS-485
Pin RS-232
RS-422
Half Duplex RS-485
Full Duplex RS-485
*
COM ports
Chapter 2
COM ports with the pin definitions.
Figure 7 COM Ports
COM1 RS-232 / 422 / 485 Port DB-9
1 DCD TX DATA TX
2 RXD RX+ NA RX+
3 TXD TX+ DATA+ TX+
4 DTR RX NA RX
5 GND GND GND GND
6 DSR NA NA NA
COM 1
COM 2
7 RTS NA NA NA
8 CTS NA NA NA
9 RI / +5V* NA / +5V* NA / +5V* NA / +5V*
*:Pin-9 can be set for +5V output in BIOS setup.
COM2 RS-232 / 422 / 485 Port DB-9
1 DCD TX DATA TX
2 RXD RX+ NA RX+
3 TXD TX+ DATA+ TX+
4 DTR RX NA RX
5 GND GND GND GND
6 DSR NA NA NA
7 RTS NA NA NA
8 CTS NA NA NA
9 RI / +5V* NA / +5V* NA / +5V* NA / +5V*
QDSP-5001 Series User’s Manual
:Pin-9 can be set for +5V output in BIOS setup.
22
Chapter 2
DC Jack
Turning on the system
1. Connect the power adapter cable to the DC jack (DC IN) of the QDSP-5001
2. Connect the power cable to the power adapter
3. Connect the power cable to a power outlet
4. Press the power button on the front panel to turn on the system
Power button
Figure 8 Turning on the system
QDSP-5001 Series User’s Manual
23
Chapter 3
Chapter 3
AMI BIOS Setup
Overview
This chapter provides a description of the AMI BIOS. The BIOS setup menus
and available selections may vary from those of your product. For specific
information on the BIOS for your product, please contact with your dealer.
NOTE
The BIOS menus and selections for your product may vary from
those in this chapter. For the BIOS manual specific to your
product, please contact with us.
AMI's ROM BIOS provides a built-in Setup program, which allows the user to
modify the basic system configuration and hardware parameters. The
modified data will be stored in a battery-backed CMOS, so that data will be
retained even when the power is turned off. In general, the information
saved in the CMOS RAM will not need to be changed unless there is a
configuration change in the system, such as a hard drive replacement or
when a device is added.
It is possible for the CMOS battery to fail, which will cause data loss in the
CMOS only. If this happens you will need to reconfigure your BIOS settings.
QDSP-5001 Series User’s Manual
24
Chapter 3
Product Name
BIOS Build Date
11/06/2012
ME FW Version
8.0.20.1513
System date
[Mon 12/17/2012]
Main Menu
The BIOS Setup is accessed by pressing the DEL key after the Power-On
Self-Test (POST) memory test begins and before the operating system boot
begins. Once you enter the BIOS Setup Utility, the Main Menu will appear on
the screen. The Main Menu provides System Overview information and
allows you to set the System Time and Date. Use the “<” and “>” cursor keys
to navigate between menu screens.
Table 2 BIOS Main Menu
BIOS SETUP UTILITY
Main Advanced Boot Security Save & Exit
Product Information
BIOS Version 0.01 (x64 )
CPU Information
Intel® Core ™ i5-3337U CPU @ 2.70GHz
Microcode Revision 15
Processor Cores 2
Memory Information
Total Size 8192 MB (DDR3)
Frequency 1333 MHz
System time [13:22:19]
Version 2.15.1234. Copyright (C) 2012, American Megatrends, Inc.
QDSP-5001
Select Screen
↑↓ Select Item
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4 Save & Exit
ESC Exit
QDSP-5001 Series User’s Manual
25
Audio Controller
[Enabled]
> Display Configuration
> AMT Configuration
> Trusted Computing
> SATA Configuration
> Intel(R) Rapid Start Technology
>USB Configuration
Advanced Menu
Table 3 Advanced Menu
BIOS SETUP UTILITY
Main Advanced Boot Security Server M gmt Save & Exit
Onboard LAN1 Controller [Enabled]
Onboard LAN1 Boot [Disabled]
Onboard LAN2 Controller [Enabled]
Onboard LAN2 Boot [Disabled]
> Power Management Configuration
> CPU Advanced Configuration
Select Screen
↑↓ Select Item
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4 Save & Exit
ESC Exit
Chapter 3
> Intel TXT(LT) Configuration
>Super IO Configuration
>H/W Monitor
Version 2.15.1234. Copyright (C) 2012, American Megatrends, Inc.
Onboard LAN 1 Controller
Options: Disabled, Enabled
Onboard LAN 1 Boot
Options: Disabled, Enabled
Onboard LAN 2 Controller
Options: Disabled, Enabled
Onboard LAN 2 Boot
Options: Disabled, Enabled
Audio Controller
Options: Disabled, Enabled
QDSP-5001 Series User’s Manual
26
Aperture Size
Allocated
DVMT Total Gfx Mem
Table 4 Advanced Menu – Display Configuration
BIOS SETUP UTILITY
Main Advanced Boot Security Server M gmt Save & Exit
Display Configuration
DVMT Pre-
IGFX – Boot Type
Version 2.15.1234. Copyright (C) 2012, American Megatrends, Inc.
[256 MB]
[64M]
[256 M]
[VBIOS Default]
Select Screen
↑↓ Select Item
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4 Save & Exit
ESC Exit
Chapter 3
Aperture Size
Options: 128MB, 256MB, 512MB
DVMT Pre-Allocated
Options:32M, 64M, 96M, 128M, 160M, 192M, 224M, 256M, 288M, 320M,
352M, 384M, 416M, 448M, 480M, 512M, 1024M
DVMT Total Gfx Mem
Options: 128M, 256M, MAX
IGFX – Boot Type
Options: VBIOS Default, CRT, HDMI, DP1, DP2
QDSP-5001 Series User’s Manual
27
Chapter 3
ACPI Sleep State
[S3 (Suspend to RAM)]
Resume By PCIE Device
[Disabled]
Table 5 Advanced Menu –Power Management Configuration
BIOS SETUP UTILITY
Main Advanced Boot Security Server M gmt Save & Exit
Power Management Configuration
Restore AC Power Loss [Power Off]
Resume By RTC Alarm [Disabled]
EUP Power Saving Mode [Disabled]
>Watchdog Timer Configuration
Version 2.15.1234. Copyright (C) 2012, American Megatrends, Inc.
Select Screen
↑↓ Select Item
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4 Save & Exit
ESC Exit
ACPI Sleep State
Options: Suspend Disabled, S1 (CPU Stop Clock), S3 (Suspend to RAM)
Restore AC Power Loss
Options: Power Off, Power On, Last State
Resume By PCIE Device
Options: Disabled, Enabled
Resume By RTC Alarm
Options: Disabled, Enabled
EUP Power Saving Mode
Options: Disabled, Enabled
Watchdog Timer Configuration
■ WDT Function [Disabled]
Options: Disabled, Enabled
QDSP-5001 Series User’s Manual
28
Chapter 3
Hyper Treading
[Enabled]
Intel ® Virtualization Tech
[Disabled]
Table 6 Advanced Menu –CPU Advanced Configuration
BIOS SETUP UTILITY
Main Advanced Boot Security Save & Exit
CPU Advanced Configuration
EIST [Enabled]
Turbo Mode [Enabled]
VT-d [Enabled]
Active Processor Cores [All]
Limit CPUID Maximum [Disabled]
Select Screen
↑↓ Select Item
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4 Save & Exit
ESC Exit
Execute Disable Bit
Version 2.15.1234. Copyright (C) 2012, American Megatrends, Inc.
EIST
Options: Disabled, Enabled
Turbo Mode
Options: Disabled, Enabled
Hyper Threading
Options: Disabled, Enabled
VT-d
Options: Disabled, Enabled
Active Processor Cores
Options: All, 1
Limit CPUID Maximum
Options: Disabled, Enabled
Execute Disable Bit
[Enabled]
Options: Disabled, Enabled
Intel ® Virtualization Tech
Options: Disabled, Enabled
QDSP-5001 Series User’s Manual
29
Chapter 3
ESC Exit
Table 7 Advanced Menu –AMT Configuration
BIOS SETUP UTILITY
Main Advanced Boot Security Save & Exit
Intel AMT [Enabled] Select Screen
Un-Configure ME [Disabled]
Version 2.15.1234. Copyright (C) 2012, American Megatrends, Inc.
↑↓ Select Item
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4 Save & Exit
Intel AMT
Options: Disabled, Enabled
Un-Configure ME
Options: Disabled, Enabled
QDSP-5001 Series User’s Manual
30
Table 8 Advanced Menu –Trusted Computing
Security Device Support
[Disable]
BIOS SETUP UTILITY
Main Advanced Boot Security Save & Exit
Configuration Select Screen
Current Status Information
SUPPORT TURNED OFF
Version 2.15.1234. Copyright (C) 2012, American Megatrends, Inc.
↑↓ Select Item
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4 Save & Exit
ESC Exit
Security Device Support
Options: Disable, Enable
Chapter 3
QDSP-5001 Series User’s Manual
31
Table 9 Advanced Menu –SATA Configuration
SATA Controller(s)
SATA Device Type
[ Hard Disk Driver]
SATA Device Type
BIOS SETUP UTILITY
Main Advanced Boot Security Save & Exit
[Enabled]
SATA Mode Selection [ AHCI]
SATA Controller Speed [ Default ]
Serial ATA Port 0 Empty
Software Preserve
Port 0
Serial ATA Port 1
Software Preserve
Port 1
Serial ATA Port 4
Software Preserve
Port 4
INTEL SSDSA2M0 (400GB)
Version 2.15.1234. Copyright (C) 2012, American Megatrends, Inc.
Unknown
[ Enabled ]
Supported
[ Enabled ]
[ Hard Disk Driver]
Empty
Unknown
[ Enabled ]
Select Screen
↑↓ Select Item
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4 Save & Exit
ESC Exit
SATA Controller(s)
Chapter 3
Options: Disabled, Enabled
SATA Mode Selection
Options: IDE, AHCI
SATA Co ntroller Speed
Options: Default, Gen 1, Gen 2, Gen 3
Port 0, 1, 4
Options: Disabled, Enabled
SATA Device Type
Options: Hard Disk Driver, Solid State Driver
QDSP-5001 Series User’s Manual
32
Table 10 Advanced Menu – Intel Rapid Start Technology
ESC Exit
BIOS SETUP UTILITY
Main Advanced Boot Security Server M gmt Save & Exit
Intel® Rapid Start Technology
Version 2.15.1234. Copyright (C) 2012, American Megatrends, Inc.
[Disabled]
Select Screen
↑↓ Select Item
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4 Save & Exit
Intel® Rapid Start Technology
Options: Disabled, Enabled
Table 11 Advanced Menu –Intel TXT (LT) Configuration
BIOS SETUP UTILITY
Chapter 3
Main Advanced Boot Security Save & Exit
Intel Trusted Execution technology Configuration
Intel TXT support only can be enabled / disabled if SMX is enabled.
VT and VT-d support must also be enabled prior to TXT.
Secure Mode Extensions (SMX) Enabled
Intel TXT (LT) Support [Disabled]
Version 2.15.1234. Copyright (C) 2012, American Megatrends, Inc.
Select Screen
↑↓ Select Item
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4 Save & Exit
ESC Exit
QDSP-5001 Series User’s Manual
33
USB Mass Storage Driver Support [ Enabled]
Table 12 Advanced Menu –USB Configuration
BIOS SETUP UTILITY
Main Advanced Boot Security Save & Exit
USB Configuration
USB Devices:
1 Keyboard, I Mouse, 2 Hubs
Legacy USB Support [Enabled]
USB 3.0 Support [Enabled]
XHCI hand-off [Enabled]
EHCI Hand-off [Disabled]
XHCI Pre-Boot Driver [Enabled]
XHCI Mode [ Smart Auto]
Version 2.15.1234. Copyright (C) 2012, American Megatrends, Inc.
Select Screen
↑↓ Select Item
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4 Save & Exit
ESC Exit
Legacy USB Support
Chapter 3
Options: Disabled, Enabled, Auto
USB 3.0 Support
Options: Disabled, Enabled
XHCI hand-off
Options: Disabled, Enabled
EHCI hand-off
Options: Disabled, Enabled
USB Mass Storage Driver Support
Options: Disabled, Enabled
XHCI Pre-Boot Driver
Options: Disabled, Enabled
XHCI Mode
Options: Auto, Smart Auto, Disabled, Enabled
QDSP-5001 Series User’s Manual
34
Chapter 3
>Serial Port 1 Configuration
Change Settings
[Auto]
Table 13 Advanced Menu – Super IO Configuration
BIOS SETUP UTILITY
Main Advanced Boot Security Server M gmt Save & Exit
Super IO Configuration
>Serial Port 2 Configuration
Version 2.15.1234. Copyright (C) 2012, American Megatrends, Inc.
Table 14 Advanced Menu –Super IO Configuration – Serial Port 1 Configuration
BIOS SETUP UTILITY
Main Advanced Boot Security Server M gmt Save & Exit
Serial Port 1 Configuration Select Screen
Serial Port [Enabled]
Device Settings IO=3F8h; IRQ=4
Serial Port 1 Type [RS232]
COM1 Pin9 Definition [RI]
↑↓ Select Item
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.15.1234. Copyright (C) 2012, American Megatrends, Inc.
Serial Port
Options: Disabled, Enabled
Change Settings
Options: Auto,
IO=3F8h; IRQ=4;
IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
Serial Port Type
Options: RS232, RS422, RS485
COM1 Pin9 Definition
Options: RI, +5V
QDSP-5001 Series User’s Manual
35
Table 15 Advanced Menu –Super IO Configuration – Serial Port 2 Configuration
Serial Port
[Enabled]
Change Settings
[Auto]
BIOS SETUP UTILITY
Main Advanced Boot Security Server M gmt Save & Exit
Serial Port 2 Configuration Select Screen
Device Settings IO=2F8h; IRQ=3
Serial Port 1 Type [RS232]
COM2 Pin9 Definition [RI]
Version 2.15.1234. Copyright (C) 2012, American Megatrends, Inc.
↑↓ Select Item
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4 Save & Exit
ESC Exit
Serial Port
Options: Disabled, Enabled
Change Settings
Options: Auto,
Chapter 3
IO=2F8h; IRQ=3;
IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
Serial Port Type
Options: RS232, RS422, RS485
COM2 Pin9 Definition
Options: RI, +5V
QDSP-5001 Series User’s Manual
36
Chapter 3
Table 16 Advanced Menu –H/W Monitor
BIOS SETUP UTILITY
Main Advanced Boot Security Save & Exit
PC Health Status
CPU Warning Temperature [Disabled]
CPU Temperature : +50 C
Bottom Side System Temperature : +51 C
Top Side System Temperature : +49 C
+3.3V : +3.344 V
+VCORE : +0.864 V
+1.05V : +1.008 V
+1.5V : +1.517 V
+5VDUAL : +5.120 V
+VIN : +19.448 V
+3.3VSB : +3.360 V
Version 2.15.1234. Copyright (C) 2012, American Megatrends, Inc.
Select Screen
↑↓ Select Item
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4 Save & Exit
ESC Exit
CPU Warning Temperature
Options: Disabled, 80 C, 85 C, 90 C, 95 C
QDSP-5001 Series User’s Manual
37
Setup Prompt Timeout
1
Boot Option #1
[ P1: INTEL SSDSA2M04..]
Boot Menu
Table 17 Boot Menu
BIOS SETUP UTILITY
Main Advanced Boot Security Save & Exit
Boot Configuration
Full Screen LOGO Display [Disabled]
Bootup NumLock State [On]
UEFI Boot
Boot Option Priorities
Hard Drive BBS Priorities
[Disabled]
Select Screen
↑↓ Select Item
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4 Save & Exit
ESC Exit
Chapter 3
Version 2.15.1234. Copyright (C) 2012, American Megatrends, Inc.
Full Screen LOGO Display
Options: Disabled, Enabled
Bootup Numlock State
Options: On, Off
UEFI Boot
Options: Disabled, Enabled
Boot Option #1
Options: P1: INTEL SSDSA2M040G2GC, Disabled
Hard Drive BBS Priorities
■ Boot Option #1 [ INTEL SSDSA2M040G2GC ]
Options: INTEL SSDSA2M040G2GC, Disabled
QDSP-5001 Series User’s Manual
38
s password is set, then this only limits access to
s password is set, then this is a power on password and
t or enter Setup. In Setup the User will have
P1 : INTEL SSDSA2
Security Menu
Table 18 Security Menu
BIOS SETUP UTILITY
Main Advanced Boot Security Save & Exit
Password Description
If ONLY the Administrator’
Setup and is only asked for when entering Setup
If ONLY the User’
must be entered to boo
Administrator rights
The password length must be in the following range:
Minimum Length 3
Maximum length 20
Administrator Password
User Password
HDD Security Configuration
Select Screen
↑↓ Select Item
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4 Save & Exit
ESC Exit
Chapter 3
Version 2.15.1234. Copyright (C) 2012, American Megatrends, Inc.
QDSP-5001 Series User’s Manual
39
ESC Exit
Save & Exit M enu
Table 19 Save & Exit Menu
BIOS SETUP UTILITY
Main Advanced Boot Security Save & Exit
Discard Changes and Reset
Discard Changes and Reset
Save Options
Save Changes
Discard Changes
Restore Defaults
Version 2.15.1234. Copyright (C) 2012, American Megatrends, Inc.
Select Screen
↑↓ Select Item
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4 Save & Exit
Chapter 3
QDSP-5001 Series User’s Manual
40
Chapter 3
Save Changes and Exit
Exit system setup after saving the changes. Once you are finished making
your selections, choose this option from the Exit menu to ensure the values
you selected are saved to the CMOS RAM. The CMOS RAM is sustained by
an onboard backup battery and stays on even when the PC is turned off. When
you select this option, a confirmation window appears. Select [Yes] to save
changes and exit.
Discard Changes and Exit
Exit system setup without saving any changes. Select this option only if you do
not want to save the changes that you made to the Setup program. If you
made changes to fields other than system date, system time, and password,
the BIOS asks for a confirmation before exiting.
Discard Changes
Discards changes done so far to any of the setup values. This option allows
you to discard the selections you made and restore the previously saved
values. After selecting this option, a confirmation appears. Select [Yes] to
discard any changes and load the previously saved values.
Load Optimal Defaults
Load Optimal Default values for all the setup values. This option allows you to
load optimal default values for each of the parameters on the Setup menus,
which will provide the best performance settings for your system. The F9 key
can be used for this operation.
Load Failsafe Defaults
Load Optimal Default values for all the setup values. This option allows you to
load failsafe default values for each of the parameters on the Setup menus,
which will provide the most stable performance settings. The F8 key can be
used for this operation.
QDSP-5001 Series User’s Manual
41
Chapter 4
Chapter 4
Driver Installation
If your QDSP-5001 does not come with an operating system pre-installed,
you will need to install an operating system and the necessary drivers to
operate it. After you have finished assembling your system and connected
the appropriate power source, power it up using the power supply and install
the desired operating system.
For other operating systems, please contact with your nearest Quanmax
Sale.
QDSP-5001 Series User’s Manual
