Product Name: Skyhook Anchor
Part #: 00300; 00310; 00320; 00330; 00340; 00342
Instruction Manual
Do not throw away these instructions!
Read and understand these instructions before using equipment!
Table of Contents
Introduction
Applicable Safety Standards
Worker Classifications
Safety Information
Maintenance, Cleaning, and Storage
Inspection
Product Specific Applications
Limitations
Components and Specifications
Installation and Use
Labels
Inspection Log
Notes
1-2
2
2
3-4
5
5
6
7-9
10
11-12
13
14
14
Introduction
Thank you for purchasing a Guardian Fall Protection Skyhook Anchor. This manual must be read
and understood in its entirety, and used as part of an employee training program as required by
OSHA or any applicable state agency.
This and any other included instructions must be made available to the user of the equipment.
The user must understand how to safely and effectively use the Skyhook Anchor, and all fall
safety equipment used in combination with the Skyhook Anchor.
Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: (800) 466-6385 fax: (800) 670-7892 www.guardianfall.com
1
User Information
Date of First Use:
Serial #:
Trainer:
User:
Applicable Safety Standards
When used according to instruction specifications, this product meets or exceeds all applicable
OSHA 1926 Subpart M, OSHA 1910, ANSI Z359.1-2007, and ANSI A10.32-2012 standards for fall
protection. Applicable standards and regulations depend on the type of work being done, and
also might include state-specific regulations. Consult regulatory agencies for more information
on personal fall arrest systems and associated components.
Worker Classifications
CAUTION
!
Qualified Person: A person with an accredited degree or certification, and with extensive
experience or sufficient professional standing, who is considered proficient in planning and
reviewing the conformity of fall protection and rescue systems.
Competent Person: A highly trained and experienced person who is ASSIGNED BY THE EMPLOYER
to be responsible for all elements of a fall safety program, including, but not limited to, its
regulation, management, and application. A person who is proficient in identifying existing and
predictable fall hazards, and who has the authority to stop work in order to eliminate hazards.
Authorized Person: A person who is assigned by their employer to work around or be subject to
potential or existing fall hazards.
It is the responsibility of a Qualified or Competent person to supervise the job site and
ensure all applicable safety regulations are complied with.
Understand the following definitions of those who
work near or who may be exposed to fall hazards.
2
Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: (800) 466-6385 fax: (800) 670-7892 www.guardianfall.com
Safety Information
Failure to understand and comply with safety regulations may result in
WARNING
!
Do not alter equipment.
Do not misuse equipment.
Workplace conditions, including, but not limited to, flame, corrosive chemicals, electrical shock,
sharp objects, machinery, abrasive substances, weather conditions, and uneven surfaces, must
be assessed by a Competent Person before fall protection equipment is selected.
The analysis of the workplace must anticipate where workers will be performing their duties,
the routes they will take to reach their work, and the potential and existing fall hazards they
may be exposed to.
Fall protection equipment must be chosen by a Competent Person. Selections must account for
all potential hazardous workplace conditions.
All fall protection equipment should be purchased new and in an unused condition.
Fall protection systems must be selected and installed under the supervision of a Competent
Person, and used in a compliant manner.
Fall protection systems must be designed in a manner compliant with all federal, state, and
safety regulations.
serious injury or death. Regulations included herein are not all-inclusive,
are for reference only, and are not intended to replace a Competent
Person’s judgment or knowledge of federal or state standards.
Unless explicitly stated otherwise, the maximum allowable free fall distance for lanyards must
not exceed 6’. No free fall allowed for non-LE SRLs. SRLs must arrest falls within 54”.
Forces applied to anchors must be calculated by a Competent Person.
Harnesses and connectors selected must be compliant with manufacturer’s instructions, and
must be of compatible size and configuration.
A pre-planned rescue procedure in the case of a fall is required. The rescue plan must be projectspecific. The rescue plan must allow for employees to rescue themselves, or provide an
alternative means for their prompt rescue.
Store rescue equipment in an easily accessible and clearly marked area.
Training of Authorized Persons to correctly erect, disassemble, inspect, maintain, store, and use
equipment must be provided by a Competent Person.
Training must include the ability to recognize fall hazards, minimize the likelihood of fall hazards,
and the correct use of personal fall arrest systems.
Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: (800) 466-6385 fax: (800) 670-7892 www.guardianfall.com
3
NEVER use fall protection equipment of any kind to hang, lift, support, or hoist tools or
equipment, unless explicitly certified for such use.
Maintenance of equipment must be done according to manufacturer’s instructions. Equipment
instructions must be retained for reference.
Prior to EACH use, all equipment in a fall protection system must be inspected for any potential
or existing deficiencies that may result in its failure or reduced functionality. IMMEDIATELY
remove equipment from service if any deficiencies are found.
Equipment must be inspected by a Competent Person at least every six months. These
inspections must be documented in equipment instruction manual and on equipment inspection
grid label.
Equipment must be inspected for defects, including, but not limited to, the absence of required
labels or markings, improper form/fit/function, evidence of cracks, sharp edges, deformation,
corrosion, excessive heating, alteration, excessive wear, fraying, knotting, abrasion, and absence
of parts.
Equipment that fails inspection in any way must immediately be removed from use, or repaired
by an entity approved by the manufacturer.
No on-site repair of equipment unless explicitly permitted by Guardian Fall Protection.
Equipment subjected to forces of fall arrest must immediately be removed from use.
Snap hooks, carabiners, and other connectors must be selected and applied in a compatible
fashion. All risk of disengagement must be eliminated. All snap hooks and carabiners must be
self-locking and self-closing, and must never be connected to each other.
Age, fitness, and health conditions can seriously affect the worker should a fall occur. Consult a
doctor if there is any reason to doubt a user’s ability to withstand and safely absorb fall arrest
forces or perform set-up of equipment.
Pregnant women and minors must not use this equipment.
Physical harm may still occur even if fall safety equipment functions correctly. Sustained post-fall
suspension may result in serious injury or death. Use trauma relief straps to reduce the effects of
suspension trauma.
Allowable individual worker weight limit (including all equipment), unless explicitly stated
otherwise, is 130-310 lbs.
4
Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: (800) 466-6385 fax: (800) 670-7892 www.guardianfall.com
Maintenance, Cleaning, and Storage
Repairs to Skyhook Anchors can only be made by a Guardian Fall Protection representative or an
entity authorized by Guardian. Contact Guardian for all maintenance and repair needs at:
1-800-466-6385. If a Skyhook Anchor fails inspection in any way, immediately remove it from
service, and contact Guardian to inquire about its return or repair.
Cleaning after use is important for maintaining the safety and longevity of Skyhook Anchors.
Remove all dirt, corrosives, and contaminants from Skyhook Anchors before and after each use.
If Skyhook Anchor cannot be cleaned with plain water, use mild soap and water, then rinse and
wipe dry. NEVER clean Skyhook Anchors with corrosive substances.
When not in use, store equipment where it will not be affected by heat, light, excessive
moisture, chemicals, or other degrading elements.
Inspection
KEEP INSTRUCTIONS AVAILABLE FOR REFERENCE. Record Date of First Use.
Prior to EACH use, inspect Skyhook Anchor for deficiencies, including, but not limited to,
corrosion, deformation, pits, burrs, rough surfaces, sharp edges, cracking, rust, paint buildup,
excessive heating, alteration, and missing or illegible labels. IMMEDIATELY remove Skyhook
Anchor from service if defects or damage are found, or if exposed to forces of fall arrest.
Ensure that applicable work area is free of all damage, including, but not limited to, debris, rot,
rust, decay, cracking, and hazardous materials. Ensure that selected work area will support the
application-specific minimum loads set forth in this instruction manual. Work area MUST be
stable.
At least every 6 months, a Competent Person other than the user must inspect Skyhook Anchors.
Competent Person inspections MUST be recorded in inspection log in instruction manual
and on equipment inspection grid label. The Competent Person must sign their initials in
the box corresponding to the month and year the inspection took place.
During inspection, consider all applications and hazards Skyhook Anchors have been subjected to.
Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: (800) 466-6385 fax: (800) 670-7892 www.guardianfall.com
5
Product Specific Applications
WARNING
!
Personal Fall Arrest: Skyhook Anchors may be used to support a MAXIMUM 1
Personal Fall Arrest System (PFAS) for use in Fall Arrest applications. Structure must
withstand loads applied in the directions permitted by the system of at least
5,000 lbs. Maximum free fall is 6‘, or up to 12’ if used in combination with
equipment explicitly certified for such use. Applicable D-ring: Dorsal.
Restraint: Skyhook Anchors may be used in Restraint applications. Restraint
systems prevent workers from reaching the leading edge of a fall hazard. Always
account for fully deployed length of lanyard/SRL. Structure must withstand loads
applied in the directions permitted by the system of at least 1,000 lbs. No free fall
is permitted. Restraint systems may only be used on surfaces with slopes up to
4/12 (vertical/horizontal). Applicable D-rings: Dorsal, Chest, Side, Shoulder.
Work Positioning: Skyhook Anchors may be used in Work Positioning applications.
Work Positioning systems allow a worker to be supported while in suspension and
work freely with both hands. Structure must withstand loads applied in the
directions permitted by the system of at least 3,000 lbs. Maximum allowable free
fall is 2’. Applicable D-rings: Side, Shoulder.
Use of equipment in unintended applications may result in serious
injury or death. Maximum 1 attachment per connection point.
For all applications: worker weight capacity range
(including all clothing, tools, and equipment) is 130-310 lbs.,
or up to 420 lbs. if used in combination with
equipment explicitly certified for such use.
6
Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: (800) 466-6385 fax: (800) 670-7892 www.guardianfall.com
Limitations
Fall Clearance: There must be sufficient clearance below the anchorage connector to arrest a fall
before the user strikes the ground or an obstruction. When calculating fall clearance, account for
a MINIMUM 3’ safety factor, deceleration distance, user height, length of lanyard/SRL, and all
other applicable factors. Diagram shown is an example fall clearance calculation ONLY.
FALL CLEARANCE CALCULATION
Lanyard length
(6’ total)
Required
distance
from
anchorage
(19’ total)
Deceleration
distance (4’ total)
Height of harness
dorsal D-ring from
worker’s feet
(6’ total)
Safety factor
(3’ total)
Swing Falls: Prior to installation or use, make considerations for eliminating or minimizing all
swing fall hazards. Swing falls occur when the anchor is not directly above the location where a
fall occurs. Always work as close to in line with the anchor point as possible. Swing falls
significantly increase the likelihood of serious injury or death in the event of a fall.
Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: (800) 466-6385 fax: (800) 670-7892 www.guardianfall.com
7
Compatibility: When making connections with Skyhook Anchors, eliminate all possibility of
roll-out. Roll-out occurs when interference between a hook and the attachment point causes the
hook gate to unintentionally open and release. All connections must be selected and deemed
compatible with Skyhook Anchors by a Competent Person. All connector gates must be
self-closing and self-locking, and withstand minimum loads of 3,600 lbs. See the following for
examples of compatible/incompatible connections:
Connector
closed and
locked to
D-ring. OK.
Two or more
snap hooks or
carabiners
connected to
each other. NO.
Two connectors
to same
D-ring. NO.
Incompatible
or irregular
application,
which may
increase risk
of roll-out. NO.
Connector
to integral
lanyard.
NO.
Connector
directly to
webbing.
NO.
Application
that places
load on gate.
NO.
Connector
directly to
horizontal
lifeline. NO.
8
Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: (800) 466-6385 fax: (800) 670-7892 www.guardianfall.com
Correct Anchorage Positioning:
This chart details allowable working zones required
to reduce risk of swing falls and improper side loading.
ALWAYS adhere to information specified by chart.
Anchor Distance
From
Leading Edge (Y)
6’
10’
15’
20’
25’
30’
35’
40’
45’
50’
55’
60’
Working Distance
Along Roof Edge
(Either Direction) (X)
8’
9’ - 9”
11’ - 7”
13’ - 3”
14’ - 6”
16’
17’ - 2”
18’ - 3”
19’ - 4”
19’ - 10”
21’ - 4”
22’ - 3”
Working Angle
From
Perpendicular (Ø)
53°
45°
38°
33°
30°
28°
26°
24°
23°
21°
21°
21°
For example, if the anchorage connector is 6’ from the leading
edge (Y), the working distance (X) is 8’ in each direction from
the perpendicular, which translates to a 53° working angle.
Ø: Total Working Angle
X: Working Distance
Along Leading Edge
Y: Distance From
Leading Edge
Y
ø
X
Leading Edge
Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: (800) 466-6385 fax: (800) 670-7892 www.guardianfall.com
X
9
Components and Specifications
Materials:
#00300, 00310, 00320, 00330, 00340:
Powder-coated steel
#00342: Powder-coated steel and
Zinc-plated steel
Connection Point
Fastener
Installation
Holes
(30 total,
15 per side)
See the following for applicable roof pitches for Skyhook Anchors:
#00310
28.00°
#00300
28.00°
Pitch: Flat.
Pitch: 1/12 - 3/12.
10
54.00°
Pitch 4/12 - 6/12.
Pitch: 9/12 - 12/12.
90.00°
#00320
#00330
106.00°
Pitch: 7/12 - 9/12.
#00340
#00342
Pitch: flat - 12/12.
Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: (800) 466-6385 fax: (800) 670-7892 www.guardianfall.com
Installation and Use
MINIMUM substrate requirements:
Wood: 3/4” CDX. Metal: 20g. Concrete: 6” (2,000 p.s.i. or greater).
Skyhook Anchor MUST install flush against substrate.
1. Determine desired location for anchor; ensure location is free of debris, rot, decay, cracking,
and hazardous materials. NEVER install on gable ends, fascias, rake ends, overhangs, bottom
cords, collar boards, spliced sections, or substrate incapable of withstanding application
minimum loads.
2. Make considerations for eliminating or minimizing swing fall hazards.
3. ALWAYS measure roof pitch prior to installation. NEVER use Skyhook Anchor incompatible with
roof pitch.
Guardian recommends Skyhook Anchors be placed no more than 20’ apart.
Skyhook Anchors MUST be placed a MINIMUM 10’ from all leading edges of fall hazards.
4. Ensure all fasteners are those supplied by Guardian Fall Protection, or are deemed compatible
by a Competent Person.
5. For installations on wood and metal, use (30) #14x10 2” screws or better. All Fastener
Installation Holes MUST be filled.
6. For installations on concrete, use (30) 3½” concrete fasteners that have been selected and
deemed compatible with Skyhook Anchor by a Competent Person. Concrete installations must
be done directly on substrate, and never through any intermediary substrates. All Fastener
Installation Holes MUST be filled.
Installation MUST be supervised by a Competent Person.
7. Connect to Skyhook Anchor with complete and compatible PFAS. All connector gates must be
self-closing and self-locking, and must withstand MINIMUM loads of 3,600 lbs.
Example installations:
#00300
Pitch: Flat
Substrate: 6”
(2,000 p.s.i. concrete)
#00320
Pitch: 4/12
Substrate: 20g metal
#00342
Pitch: 10/12
Substrate: 3/4” CDX
Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: (800) 466-6385 fax: (800) 670-7892 www.guardianfall.com
11
Skyhook Anchors must be properly flashed to be used in permanent applications.
It is the responsibility of the installer/roofer to properly flash this anchor.
Use Guardian Fall Protection flashing kit (#00352) with Skyhook Anchor:
1) Place large neoprene gasket at installation location.
2) Place Skyhook over large gasket.
3) Place small gasket over skyhook.
4) Install aluminum flashing over small gasket.
If removing and reinstalling a Skyhook Anchor, fully inspect the anchor according to
instruction inspection specifications.
DO NOT reuse if any signs of damage or defects are found.
ALWAYS use new fasteners for each new installation application.
Skyhook Anchor Horizontal Lifeline Systems:
1. Skyhook Anchors may be used to facilitate a cable Horizontal Lifeline, for use by up to 4
workers in fall restraint, OR 1 worker in fall arrest. Restraint applications allowed only on pitches
up to 4/12.
2. Horizontal Lifeline cable MUST be 3/8” galvanized aircraft cable (14,400 lb. minimum tensile
strength). Ensure that cable length will allow for a minimum 18“ of cumulative slack throughout
entire Horizontal Lifeline System.
3. To attach 3/8” cable, run cable through Connection Point of
Skyhook Anchor, then run through gusset hole on back of the
anchor, and bring back through the Connection Point. Secure
cable to itself using a MINIMUM 3 compatible cable clamps
(sold separately), as determined by a Qualified Person. Contact
Guardian Fall Protection with any questions.
4. Run cable through a series of Skyhook Anchor Connection Points, and terminate at Skyhook
Anchor at end of desired run length. Secure cable by running cable through Connection Point,
through gusset hole, back through Connection Point, and secure with 3 compatible cable clamps.
ALL Connection Points of Skyhook Anchors in horizontal lifeline system MUST be directly in
line.
5. NEVER stretch the cable tight! Allow 18” of cumulative slack throughout entire system.
Measure cable slack at midpoint between two consecutive Skyhook Anchors, and repeat for
entire system. NEVER use system in any application if less than 18” of cable slack exists. ALWAYS
ensure adequate fall clearance exists. All horizontal lifeline installation MUST be supervised by a
Qualified Person.
12
Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: (800) 466-6385 fax: (800) 670-7892 www.guardianfall.com
Labels
#00300: #00310:
Prior to use, read and understand all instructions provided
with equipment at time of shipment from manufacturer.
Compliant with all OSHA 1910, OSHA 1926 Subpart M,
Skyhook Anchor
Part #: 00300
Date of manufacture:
Capacity range: 130-310 lbs.
(including all equipment)
Materials: Powder-coated steel.
90045 (Rev. A)
www.guardianfall.com 1-800-466-63856305 S. 231st St., Kent, WA 98032
ANSI Z359.1-2007, and ANSI A10.32-2004 regulations.
All fasteners, equipment, and connections must be selected and deemed compatible
with the Skyhook Anchor by a Competent Person. All fastener holes MUST be filled.
Structure must withstand MINIMUM load of 5,000 lbs.
Substrate strength requirements: Wood: 3/4” CDX plywood or better.
Metal: 20ga. or thicker. Concrete: 2000 p.s.i. minimum.
Avoid contact with sharp and abrasive edges and surfaces.
WARNING
Avoid contact with all hazards, including, but not limited to,
!
electrical shock, corrosive substances, and excessive heat.
#00320: #00330:
Prior to use, read and understand all instructions provided
with equipment at time of shipment from manufacturer.
Compliant with all OSHA 1910, OSHA 1926 Subpart M,
Skyhook Anchor
Part #: 00320
Date of manufacture:
Capacity range: 130-310 lbs.
(including all equipment)
Materials: Powder-coated steel.
90047 (Rev. A)
www.guardianfall.com 1-800-466-63856305 S. 231st St., Kent, WA 98032
ANSI Z359.1-2007, and ANSI A10.32-2004 regulations.
All fasteners, equipment, and connections must be selected and deemed compatible
with the Skyhook Anchor by a Competent Person. All fastener holes MUST be filled.
Structure must withstand MINIMUM load of 5,000 lbs.
Substrate strength requirements: Wood: 3/4” CDX plywood or better.
Metal: 20ga. or thicker. Concrete: 2000 p.s.i. minimum.
Avoid contact with sharp and abrasive edges and surfaces.
WARNING
Avoid contact with all hazards, including, but not limited to,
!
electrical shock, corrosive substances, and excessive heat.
#00340: #00342:
Prior to use, read and understand all instructions provided
with equipment at time of shipment from manufacturer.
Compliant with all OSHA 1910, OSHA 1926 Subpart M,
Skyhook Anchor
Part #: 00340
Date of manufacture:
Capacity range: 130-310 lbs.
(including all equipment)
Materials: Powder-coated steel.
90049 (Rev. A)
www.guardianfall.com 1-800-466-63856305 S 231st St., Kent, WA 98032
ANSI Z359.1-2007, and ANSI A10.32-2004 regulations.
All fasteners, equipment, and connections must be selected and deemed compatible
with the Skyhook Anchor by a Competent Person. All fastener holes MUST be filled.
Structure must withstand MINIMUM load of 5,000 lbs.
Substrate strength requirements: Wood: 3/4” CDX plywood or better.
Metal: 20ga. or thicker. Concrete: 2000 p.s.i. minimum.
Avoid contact with sharp and abrasive edges and surfaces.
WARNING
Avoid contact with all hazards, including, but not limited to,
!
electrical shock, corrosive substances, and excessive heat.
Compatible roof pitch:
flat.
Compatible roof pitch:
4/12 - 6/12.
Compatible roof pitch:
10/12 - 12/12.
Skyhook Anchor
Part #: 00310
Date of manufacture:
Capacity range: 130-310 lbs.
(including all equipment)
Materials: Powder-coated steel.
90046 (Rev. A)
www.guardianfall.com 1-800-466-63856305 St. 231st St., Kent, WA 98032
Skyhook Anchor
Part #: 00330
Date of manufacture:
Capacity range: 130-310 lbs.
(including all equipment)
Materials: Powder-coated steel.
90048 (Rev. A)
www.guardianfall.com 1-800-466-63856305 S. 231st St., Kent, WA 98032
Adjustable
Skyhook Anchor
Part #: 00342
Date of manufacture:
Capacity range: 130-310 lbs.
(including all equipment)
Materials: Powder-coated steel
and Zinc-plated steel.
www.guardianfall.com 1-800-466-63856305 S 231st St., Kent, WA 98032
Prior to use, read and understand all instructions provided
with equipment at time of shipment from manufacturer.
Compliant with all OSHA 1910, OSHA 1926 Subpart M,
ANSI Z359.1-2007, and ANSI A10.32-2004 regulations.
All fasteners, equipment, and connections must be selected and deemed compatible
with the Skyhook Anchor by a Competent Person. All fastener holes MUST be filled.
Structure must withstand MINIMUM load of 5,000 lbs.
Substrate strength requirements: Wood: 3/4” CDX plywood or better.
Metal: 20ga. or thicker. Concrete: 2000 p.s.i. minimum.
Avoid contact with sharp and abrasive edges and surfaces.
WARNING
Avoid contact with all hazards, including, but not limited to,
!
electrical shock, corrosive substances, and excessive heat.
Prior to use, read and understand all instructions provided
with equipment at time of shipment from manufacturer.
Compliant with all OSHA 1910, OSHA 1926 Subpart M,
ANSI Z359.1-2007, and ANSI A10.32-2004 regulations.
All fasteners, equipment, and connections must be selected and deemed compatible
with the Skyhook Anchor by a Competent Person. All fastener holes MUST be filled.
Structure must withstand MINIMUM load of 5,000 lbs.
Substrate strength requirements: Wood: 3/4” CDX plywood or better.
Metal: 20ga. or thicker. Concrete: 2000 p.s.i. minimum.
Avoid contact with sharp and abrasive edges and surfaces.
WARNING
Avoid contact with all hazards, including, but not limited to,
!
electrical shock, corrosive substances, and excessive heat.
Prior to use, read and understand all instructions provided
with equipment at time of shipment from manufacturer.
Compliant with all OSHA 1910, OSHA 1926 Subpart M,
ANSI Z359.1-2007, and ANSI A10.32-2004 regulations.
All fasteners, equipment, and connections must be selected and deemed compatible
with the Skyhook Anchor by a Competent Person. All fastener holes MUST be filled.
Structure must withstand MINIMUM load of 5,000 lbs.
Substrate strength requirements: Wood: 3/4” CDX plywood or better.
Metal: 20ga. or thicker. Concrete: 2000 p.s.i. minimum.
Avoid contact with sharp and abrasive edges and surfaces.
WARNING
Avoid contact with all hazards, including, but not limited to,
!
electrical shock, corrosive substances, and excessive heat.
Compatible roof pitch:
1/12 - 3/12.
Compatible roof pitch:
7/12 - 9/12.
Compatible roof pitch:
flat - 12/12.
(Rev. A)
90050
For reference only. Background to be white.
Date of manufacture to be: month/year.
User must inspect prior to EACH use. Competent Person must complete
formal inspection every 6 months. Competent Person to inspect and initial.
Inspection Grid for all
Skyhook Anchors:
Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: (800) 466-6385 fax: (800) 670-7892 www.guardianfall.com
Date of First Use: __________________. Product lifetime is indefinite as
long as equipment passes pre-use and Competent Person inspections.
YR J F M A M J J A S O N D
20____
20____
20____
INSPECTION GRID
20____
20____
If equipment fails inspection
IMMEDIATELY REMOVE FROM SERVICE
DO NOT REMOVE LABELS
13
Inspection Log
User must inspect prior to EACH use. Competent Person other than user must complete
formal inspection at least every 6 months. Competent Person to inspect and initial.
Date of First Use: __________________. Product lifetime is indefinite as long as it passes
pre-use and Competent Person inspections.
This inspection log must be specific to one Skyhook Anchor. Separate inspection logs must
be used for each Skyhook Anchor. All inspection records must be made visible and
available to all users at all times.
If equipment fails inspection IMMEDIATELY REMOVE FROM SERVICE.
Notes
14 85046 (Rev. E)
Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: (800) 466-6385 fax: (800) 670-7892 www.guardianfall.com
Loading...
