Qualcast CDB30 Assembly Manual
Assembly Manual
Qualcast
30cc Petrol Grass Trimmer
Complete Product
Support & Aftersales Service
Important - Please read these instructions fully before starting assembly
These instructions contain important information that will help you get the best from your grass
trimmer, ensuring it is assembled correctly and safely.
If you need help or have damaged or missing parts, call the Customer Helpline on 0845 034 2279
prior to returning product to store.
CDB30
Sep 2012 Rev A
Scan to watch
our new quick
start videos!
Complete Product Support &
Aftersales Service 7 days a week.
Do you need help with this product?
Instead of returning your product please
call 0845 034 2279 7 days a week.
Email: support@gardenservicecentre.co.uk
Or visit www.gardenservicecentre.co.uk
This does not affect your statutory rights.
Important - Please read these instructions fully before starting assembly
3
Customer Helpline 0845 034 2279
www.gardenservicecentre.co.uk
Contents
2
Customer Helpline 0845 034 2279
www.gardenservicecentre.co.uk
Safety Information .............................................................................................................................................3
Warning Symbols ..........................................................................................................................................3
General Safety ..............................................................................................................................................3
Personal Safety ............................................................................................................................................3
In the Box ..........................................................................................................................................................4
Parts ..............................................................................................................................................................4
Tools ..............................................................................................................................................................4
Assembly ...........................................................................................................................................................5
Preparing to assemble the grass trimmer ....................................................................................................5
Step 1 ............................................................................................................................................................5
Step 2 ............................................................................................................................................................6
Step 3 ............................................................................................................................................................6
Step 4 ............................................................................................................................................................7
The following warning symbols appear throughout this assembly manual and indicate the appropriate
safety measures you should take when assembling and operating the grass trimmer.
This symbol indicates there is a danger of serious personal injury or death if you do not observe the
warning.
This symbol indicates that there is a danger of damaging your hands if you do not wear thick,
protective gloves.
Warning Symbols
General Safety
Personal Safety
WARNING! Keeps this assembly manual in a safe place following assembly for reference at a later
date.
WARNING! Always ensure anyone intending to operate this grass trimmer is fully conversant
with the contents of this assembly manual prior to assembling, maintaining or operating the grass
trimmer.
WARNING! Perform assembly operations described in this manual. Failure to observe this warning
may lead to serious injury, death, or damage to the grass trimmer.
WARNING! Always take care when removing the packaging to prevent damage to you or to the
grass trimmer.
IMPORTANT! Before assembling the grass trimmer, check all the parts indicated in the manual
are in the box. Inspect all the parts for signs of damage. Do not assemble the grass trimmer if you
observe any damaged components.
WARNING! Only operate the grass trimmer if you are wearing the correct Personal Protective
Equipment (PPE) as described in the following warnings.
WARNING! Always wear suitable gloves when operating grass trimmer to protect your hands
from ying debris and/or sharp objects.
Safety Information
54
Customer Helpline 0845 034 2279
www.gardenservicecentre.co.uk
Customer Helpline 0845 034 2279
www.gardenservicecentre.co.uk
In the Box
Parts
Tools
A
WARNING! Always take care when removing the packaging to prevent damage to you or to the
grass trimmer.
IMPORTANT! Before assembling the grass trimmer, check all the parts indicated in the manual
are in the box. Inspect all the parts for signs of damage. Do not assemble the grass trimmer if
you observe any damaged components.
1. Remove all parts of the grass trimmer from the box and carefully remove all packaging. Take
care not to lose any instructions which may be afxed to the parts. These provide important
information which will be required while assembling the grass trimmer.
2. Keep all packaging until the grass trimmer is fully assembled and has been operated
successfully.
NOTE! Always recycle the packaging in accordance with local recycling schemes.
1a Take off the protection cap from the drive shaft. Push in the button located on the drive shaft.
1b Align the button with the guide recess on the upper shaft and slide the two shafts together.
Rotate the drive shaft until the button locks into the positioning hole. Tighten the knob on the
coupler, securing the two shafts together.
Preparing to assemble the grass trimmer
Assembly
Step 1
B
C D
1a 1b
1
40:1
5
10
5
10
2
3
4
A
Engine body with
upper shaft
B
Trimmer head with
lower shaft
C
Front handle+bolts
D
Safety guard+bolt
1
Plug wrench &
philips screwdriver
1pc
2
Allen wrench 1pc
3
Hex wrench 1pc
4
Mixing bottle
6
Customer Helpline 0845 034 2279
www.gardenservicecentre.co.uk
Step 2
Assembly
2a. Hold the top and bottom clamp snugly in position on the shaft housing so that handle will be
located to the operator’s left .
2b. Insert the end of the handle between the clamps.
2c. Align the bolt holes and push the long bolt through the handle side.
2d. Place short bolt through opposite side of clamp. Install at washer, lock washers and hex nuts
to hold the assembly in place.
2f. After assembly is complete, adjust the position of the handle for best balance and comfort.
2e. Tighten the long bolt rst and then the short bolt.
Step 3
Attach the curved shaft grass guard by snapping the guard around the shaft so it locates with the
