Owner’s Manual

Installation and Operation

Model:

COLBAY-INS

COLUMBIA BAY INSERT

DIRECT VENT GAS APPLIANCE

Portland

Oregon USA

Tested and

Listed by

O-T L

OMNI-Test Laboratories, Inc.

CAUTION

DO NOT DISCARD THIS MANUAL

• Important operating and maintenance instructions included.

WARNING: If the information in these instructions is not followed exactly, a ﬁ re or explosion may result causing property damage, personal injury, or death.

• Do not store or use gasoline or other ﬂ am- mable vapors and liquids in the vicinity of this or any other appliance.

• What to do if you smell gas

- Do not try to light any appliance.

- Do not touch any electrical switch. Do not

use any phone in your building.

- Immediately call your gas supplier from a

neighbor’s phone. Follow the gas supplier’s instructions.

- If you cannot reach your gas supplier, call

the ﬁ re department.

• Installation and service must be performed by a qualiﬁ ed installer, service agency , or the gas supplier.

Installation and service of this appliance should be performed by qualiﬁ ed personnel. Hearth & Home Technologies suggests NFI certiﬁ ed or factory trained professionals, or technicians supervised by an NFI certiﬁ ed professional.

• Read, understand and follow these instructions for safe installation and operation.

DO NOT

DISCARD

• Leave this manual with party responsible for use and operation.

WARNING

HOT SURFACES!

Glass and other surfaces are hot during operation AND cool down.

Hot glass will cause burns.

• Do not touch glass until it is cooled

• NEVER allow children to touch glass

• Keep children away

• CAREFULLY SUPERVISE children in same room as ﬁ replace.

• Alert children and adults to hazards of high temperatures.

High temperatures may ignite clothing or other ﬂ ammable materials.

• Keep clothing, furniture, draperies and other ﬂ ammable materials away.

In the Commonwealth of Massachusetts:

• installation must be performed by a licensed plumber or gas ﬁ tter;

• a CO detector shall be installed in the room where the appliance is installed.

This appliance may be installed as an OEM installation in manufactured home (USA only) or mobile home and must be installed in accordance with the manufacturer's instructions and the manufactured home construction and safety standard, Title 24 CFR, Part 3280 or Standard for

Installation in Mobile Homes, CAN/CSA Z240MH.

This appliance is only for use with the type(s) of gas indicated on the rating plate.

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/08 1

and Welcome to the Quadra-Fire Family!

Hearth & Home Technologies welcomes you to our tradition of excellence! In choosing a Quadra-Fire appliance, you have our assurance of commitment to quality , durability, and performance.

This commitment begins with our research of the market, including ‘Voice of the Customer’ contacts, ensuring we make products that will satisfy your needs. Our Research and Development facility then employs the world’s most advanced technology to achieve the optimum operation of our stoves, inserts and ﬁ replaces. And yet we are old-fash- ioned when it comes to craftsmanship. Each appliance

SAMPLE OF SERIAL NUMBER / SAFETY LABEL

LOCATION: HANGING ON A CHAIN ON BACK OF APPLIANCE

SERIAL

Test Lab & Report No.

Tested and

Listed by

Report No. / Rapport Numero

FAN TYPE VENTED CIRCULATOR Blower Electrical Rating115 V., 1.5 Amps, 60 Hz, 150 Watts

APPROVED FOR CANADA AND USA TO: ANSI Z21.88b-2003 / CSA 2.33b -2003 Vented Gas Fireplace Heater, and applicable sections of UL307b Gas Burning Heating Appliances for Manufactured Homes and Recreational Vehicles, CAN/CG A 2.17-M91 “Gas Fired Appliances for use at High Altitudes.” This appliance is manufactured for operation with Natural Gas. For conversion to propane the Manufacturer’s kit provided with the stove must be used in conjuntion with the instructions in the owner's manual. This vented gas fireplace heater is not for use with air filters. This appliance may be installed in a bedroom or bedsitting room; in Canada remote thermostat installation is required.

Input Rate on “HI” (BTU/Hr) 30,000 28,000 Input Rate on “LO” (BTU/Hr) 22,500 22,650 Main Burner Orifice (DMS) 36 52 Minimum Inlet Pressure (Inches W.C.) 4.5” 11” Maximum Inlet Pressure (Inches W.C.) 7.0” 14” Manifold Pressure on “HI” (Inches W.C.) 3.5” 10” Efficiency up to 82.5% 81% AFUE 71% 72.5%

This appliance equipped for altitudes 0-2000’ (0-610m) in USA; and in Canada for altitudes of 0-4500’ (0-1370m). In USA for Altitudes above 2000’, the vent configuration, orifice, or combination of both may need to be changed. See Owner’s Manual for information on making these changes.

This appliance must be installed in accordance with local codes, if any (and Commonwealth of Massachusetts approved); if none, follow The National Fuel Gas Code,ANSI Z223.1 and NFPA54; or Canadian Installation Codes CAN/CGA-B149. NOTE: Have the gas supply line installed in accordance with local building codes by a qualified installer approved and/or licensed as required by the locality. (In the Commonwealth of Massachusetts, installation must be performed by a licensed plumber or gas fitter.)

OMNI-Test Laboratories, Inc.

061-S-63-5

Beaverton

Oregon USA

P.4.1-02 Canada Minimum Pipe 69% NG / 71% LP

MINIMUM CLEARANCES TO COMBUSTIBLES

XXX

NO.

MODEL: XXXXXXX

VENTED GAS

NOT FOR USE WITH SOLID FUE

For use with Natural Gas For use with Propane

"0-2000’ "0-2000’

is meticulously fabricated and gold and nickel surfaces are hand-ﬁ nished for lasting beauty and enjoyment. Our pledge to quality is completed as each model undergoes a quality control inspection. From design, to fabrication, to shipping: Our guarantee of quality is more than a word, it’s Quadra-Fire tradition, and we proudly back this tradition with a Limited Lifetime Warranty.

We wish you and your family many years of enjoyment in the warmth and comfort of your hearth appliance. Thank you for choosing Quadra-Fire.

Serial Number

Model Name

APPLIANCE

Manufactured by:

2005 2006 2007 Feb Mar Apr May Jun Jul Aug Sep Oct Nov DecJan

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/082

Date of Manufacture / Date du Manufacturier

DO NOT REMOVE THIS LABEL

MADE IN U.S.A.

7031-221

Manufactured Date

Table of Contents

1 Listing and Code Approvals

A. Appliance Certiﬁ cation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

B. Glass Speciﬁ cations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

C. BTU Speciﬁ cations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

D. High Altitude Installations . . . . . . . . . . . . . . . . . . . . . . . . . . 4

E. Non-Combustible Materials Speciﬁ cation. . . . . . . . . . . . . . 4

F. Combustible Materials Speciﬁ cation . . . . . . . . . . . . . . . . . 4

G. Electrical Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2 Getting Started

A. Design and Installation Considerations . . . . . . . . . . . . . . . 5

B. Tools and Supplies Needed . . . . . . . . . . . . . . . . . . . . . . . . 5

C. Inspect Appliance and Components . . . . . . . . . . . . . . . . . . 5

3 Framing and Clearances

A. Selecting Appliance Location . . . . . . . . . . . . . . . . . . . . . . . 6

B. Clearances to Combustibles . . . . . . . . . . . . . . . . . . . . . . . 6

4 Termination Locations

A. Vent Termination Minimum Clearances . . . . . . . . . . . . . . . 7

5 Vent Information

A. Venting and Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

6 Gas Information

A. Fuel Conversions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

B. Converting to LP Gas . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

C. Valve Regulator Replacement . . . . . . . . . . . . . . . . . . . . . .11

D. Gas Pressures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

E. Gas Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

7 Electrical Information

A. Recommendation for Wire . . . . . . . . . . . . . . . . . . . . . . . . 14

B. Connecting to the Appliance. . . . . . . . . . . . . . . . . . . . . . . 14

C. Standing Pilot Ignition System Wiring . . . . . . . . . . . . . . . 14

8 Appliance Setup

A. Remove Shipping Materials . . . . . . . . . . . . . . . . . . . . . . . 16

B. Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

C. Door Crown Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 16

D. Grille Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

E. Panel Set Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

F. Brick Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

G. Positioning the Logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

H. Mineral Wool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

I. Blower Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

J. Air Shutter Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

9 Operating Instructions

A. Before Lighting Appliance. . . . . . . . . . . . . . . . . . . . . . . . . 23

B. Lighting Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

C. After Appliance is Lit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

D. Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . 25

10 Troubleshooting

A. Standing Pilot Ignition System . . . . . . . . . . . . . . . . . . . . . 26

11 Maintaining and Servicing Appliance

A. Glass Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

B. Maintenance Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

12 Reference Materials

A. Appliance Dimension Diagram . . . . . . . . . . . . . . . . . . . . . 30

B. Vent Components List . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

C. Service Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

D. Limited Lifetime Warranty . . . . . . . . . . . . . . . . . . . . . . . . . 35

E. Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/08 3

 = Contains updated information.

Listing and Code Approvals

A. Appliance Certiﬁ cation

MODELS: Columbia Bay Insert LABORA T ORY: Omni Test Laboratories, Inc. 061-S-30-5

TYPE: Direct Vent Gas Fireplace Heater STANDARD: ANSI Z21.88-2002 • CSA 2.33-2002 • UL307B

CAN/CBA 2.17-M91

This product is listed to ANSI standards for “Vented Gas Appliance Heaters” and applicable sections of “Gas Burning Heating Appliances for Manufactured Homes and Recreational Vehicles”, and “Gas Fired Appliances for Use at High Altitudes”.

Manufactured Home or Mobile Home installation may occur only after the home is site located and must conform with the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, or, when such a standard is not applicable, the Standard for Manufactured Home Installations, ANSI/NCSBCS A225.1, or Standard for Gas Equipped Recreational Vehicles and Mobile Housing, CSA Z240.4.

When installed, the appliance must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.1.

B. Glass Speciﬁ cations

This appliance is equipped with 5 mm ceramic glass. Replace glass only with 5 mm ceramic glass. Please contact your dealer for replacement glass.

D. High Altitude Installations

Omni-Test Laboratories, Inc. listed gas appliances are tested and approved without requiring changes for elevations from 0 to 2000 feet in the U.S.A. and 0 to 4500 feet in Canada.

When installing this appliance at an elevation above 2000 feet, it may be necessary to decrease the input rating by changing the existing burner oriﬁ ce to a smaller size. Input rate should be reduced by 4% for each 1000 feet above a 2000 foot elevation in the U.S.A. If the heating value of the gas has been reduced, these rules do not apply. To identify the proper oriﬁ ce size, check with the local gas utility.

If installing this appliance at an elevation above 4500 feet (in Canada), check with local authorities.

WARNING

Do NOT use this appliance if any part has been under water. Immediately call a qualiﬁ ed service technician to inspect the appliance and to replace any part of the control system and any gas control which has been under water.

E. Non-Combustible Materials Speciﬁ cation

Material which will not ignite and burn. Such materials are those consisting entirely of steel, iron, brick, tile, concrete, slate, glass or plasters, or any combination thereof.

Materials that are reported as passing ASTM E 136,

Standard Test Method for Behavior of Materials in a Vertical Tube Furnace at 750ºC, shall be considered

non-combustible materials.

Note: This installation must conform with local codes. In the absence of local c odes you must comply w ith the National Fuel Gas Code, ANSI Z223. 1-latest edition in the U.S.A. and the CAN/CGA B149 Installation Codes in Canada.

C. BTU Speciﬁ cations

Model

(US or Canada)

Columbia Bay

Insert (NG)

Columbia Bay

Insert (LP)

*Maximum Vent Blower On **Canada Only

Maximum

Input

BTU/h

30,000 20,000 .106 83.07 67.15

30,000 23,000 .063 84.66 70.32

Minimum

Input

BTU/h

Oriﬁ ce

Size

(DMS)

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/084

*Steady

State

Efﬁ ciency %

**P.4

F. Combustible Materials Speciﬁ cation

Materials made of or surfaced with wood, compressed paper, plant ﬁ bers, plastics, or other material that can ig- nite and burn, whether ﬂ ame proofed or not, or whether plastered or unplastered shall be considered combustible materials.

G. Electrical Codes

NOTICE: This appliance must be electrically wired and grounded in accordance with local codes or, in the absence of local codes, with National Electric Code ANSI/NFPA

70-latest edition or the Canadian Electric Code CSA C22.1.

• A 110-120 VAC circuit for this product must be protected

with ground-fault circuit-interrupter protection, in compliance with the applicable electrical codes, when it is installed in locations such as in bathrooms or near sinks.



Getting Started

A. Design and Installation Considerations

Quadra-Fire direct vent gas appliances are designed to operate with all combustion air siphoned from outside of the building and all exhaust gases expelled to the outside. No additional outside air source is required.

C. Inspect Appliance and Components

CAUTION

Check building codes prior to installation.

• Installation MUST comply with local, regional, state and national codes and regulations.

• Consult local building, ﬁ re ofﬁ cials or authorities having jurisdic- tion about restrictions, installation inspection, and permits.

When planning an appliance installation, it’s necessary to determine the following information before installing:

• Where the appliance is to be installed.

• The vent system conﬁ guration to be used.

• Gas supply piping.

• Electrical wiring.

• Framing and ﬁ nishing details.

• Whether optional accessories—devices such as a fan, wall switch, or remote control—are desired.

• Carefully remove the appliance and components from the packaging.

• Remove cast door and glass, and set aside on protective surface.

• Remove log set and component pack from ﬁ rebox.

• Report to your dealer any parts damaged in shipment, particularly the condition of the glass.

• Read all of the instructions before starting the installation. Follow these instructions carefully during the installation to ensure maximum safety and beneﬁ t.

WARNING

Keep appliance dry.

• Mold or rust may cause odors.

• Water may damage controls.

B. Tools and Supplies Needed

Before beginning the installation be sure that the following tools and building supplies are available.

Reciprocating saw Framing material Pliers Hi temp caulking material Hammer Gloves Phillips screwdriver Framing square Flat blade screwdriver Electric drill and bits (1/4 in.) Plumb line Safety glasses Level Wrenches Ratchets/Sockets Allen Wrench Set Manometer Voltmeter Tape measure 1/2 - 3/4 inch length, #6 or #8 Self-drilling screws One 1/4 inch female connection (for optional fan) Noncorrosive leak check solution or combustible gas detector

• Installation and use of any damaged appliance or vent system component.

• Modiﬁ cation of the appliance or vent system.

• Installation other than as instructed by Hearth & Home Technologies.

• Improper positioning of the gas logs or the glass door.

• Installation and/or use of any component part not approved by Hearth & Home Technologies.

Any such action may cause a ﬁ re hazard.

WARNING

Inspect appliance and components for damage. Damaged parts may impair safe operation.

• Do NOT install damaged components.

• Do NOT install incomplete components.

• Do NOT install substitute components. Report damaged parts to dealer.

WARNING

Hearth & Home Technologies disclaims any responsibility for, and the warranty will be voided by, the following actions:

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/08 5

Framing and Clearances

Note:

• Illustrations reflect typical installations and are FOR

DESIGN PURPOSES ONLY.

• Illustrations/diagrams are not drawn to scale.

• Actual installation may vary due to individual design

preference.

A. Selecting Appliance Location

When selecting a location for your appliance it is important to consider the required clearances to walls (see ﬁ gure 3.1).

B. Clearances to Combustibles

WARNING

Fire Risk Provide adequate clearance:

• Around air openings

• To combustibles

• For service access Locate appliance away from trafﬁ c areas.

NOTE: For actual appliance dimensions refer to Section 12.

To 8 in. (203 mm ) Deep mantel: 14 in. (356 mm) From top of insert

SIDE WALL

Model A B C D

Columbia Bay Insert

Underneath bottom of appliance to combustibles: 3/8 in. (10 mm) 16 in. (406 mm) front floor protection required 0 in. to 1-1/2 in. (38 mm) below bottom of appliance. (1/2 in. of "k" = .84) No floor protection needed if 1-1/2 in. (38 mm) or greater from bottom of appliance.

Inches 13 10 10 7

Millimeters 330 254 254 178

16 in. (406 mm)

1-1/2 in. (38 mm)

HEARTH

Figure 3.1

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/086

Termination Locations

A. Vent Termination Minimum Clearances

Figure 4.1 speciﬁ es minimum vent heights for various pitched roofs.

HORIZONTAL

OVERHANG

2 FT. MIN.

GAS DIRECT VENT TERMINATION CAP

Roof Pitch H (Min.) Ft.

Flat to 6/12...........................................................1.0*

Over 6/12 to 7/12 .................................................1.25*

Over 7/12 to 8/12 .................................................1.5*

Over 8/12 to 9/12 .................................................2.0*

Over 9/12 to 10/12 ...............................................2.5*

Over 10/12 to 11/12 .............................................3.25

Over 11/12 to 12/12 .............................................4.0

Over 12/12 to 14/12 .............................................5.0

Over 14/12 to 16/12 .............................................6.0

Over 16/12 to 18/12 .............................................7.0

Over 18/12 to 20/12 .............................................7.5

Over 20/12 to 21/12 .............................................8.0

* 3 foot minimum in snow regions

Figure 4.1 Minimum height from roof to lowest discharge opening

20 INCHES MIN.

LOWEST

DISCHARGE

OPENING

H (MIN.) - MINIMUM HEIGHT FROM ROOF TO LOWEST DISCHARGE OPENING

ROOF PITCH

IS X/ 12

VERTICAL

WALL

GAS OR WOOD

TERMINATION

GAS

TERMINATION

18 IN.

Gas Termination Wood & Fuel Oil Termination

A 6 in. 20 in.

Figure 4.2 Multiple Vertical Termination

2 FEET

(MINIMUM) TO

PERPENDICULAR

WALL (GAS ONLY)

WARNING

Fire Risk. Asphyxiation Risk.

• Terminations MUST meet minimum clearances.

• Exhaust gases are hot.

• Nearby vents may draw fumes into house.

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/08 7

Vent Information

A. Venting and Installation

Tools and supplies needed: Pliers; Phillips screwdriver;

Tape measure; Level; Electrical drill and bits; Square; and High Temperature Sealant Material.

Note: Quadra-Fire gas inserts are designed for recessed installations into solid fuel Masonry or Factory Built Noncombustible ﬁ replaces that have been installed in accordance with the National, Provincial, State and Local building codes.

Note: Shipping brackets used to attach appliance to pallet can be used as leveling legs when attached to back of appliance.

The damper of the masonry or factory-built chimney must be removed or ﬁ xed open to install the appliance.

Note: In the Commonwealth of Massachusetts, the word damper shall be replaced with the words ﬂ ue restrictor.

Minimum ﬁ replace opening requirements are shown on section 12 of this manual. The ﬁ rebrick (refractory) can be removed from a factory built ﬁ replace in order to gain minimum gas insert opening requirements.

Before installing the 3 in. (76 mm) ﬂ ex vent pipe, mark or label the exhaust pipe at both ends.

Attach the pipe-to-cap adapter to the termination cap and to the top of the ﬂ exible vent pipe and set the cap in place at the top of the chimney. Attach the labeled vent pipe to the labeled collar on the termination.

Install the 3 in. (76 mm) ﬂ exible vent pipes down through the chimney. Attach and secure the bottom ends of the ﬂ ex pipes to the starting collar bracket with set screws on each collar. Attach the labeled pipe to the exhaust collar on the starter collar bracket.

Place the insert on the hearth and carefully slide it into the ﬁ replace. Be sure the gas line enters the heater through the gas access opening and that the electrical cord is extending out the right. (Cord may be re-routed to the left if necessary. A notch will be needed in the trim piece for the cord restraint.)

Position any excess ﬂ ex vent pipe back up into the chimney.

Install LP conversion, brick set and panel and trim at this point in accordance with your installation plans. See instructions in this manual to do so.

Slide the unit back into the ﬁ replace. Attach transition assembly to the appliance. Rotate transi-

tion assembly latches and lock with the 7/16 in. wrench.

AIR INTAKE

Figure 5.1

TERMINATION CAP

ADAPTER

FLEX PIPE

TRANSITION ASSEMBLY

SHIPPING BRACKETS ATTACHED TO REAR OF APPLIANCE FOR USE AS LEVELING LEGS

Figure 5.2

High Temperature Sealant Material. Sealants that will

withstand high temperatures (at least 350 degrees Fahrenheit); General Electric RTV103 (Black), or equivalent. Rutland, Inc. Fireplace Mortar #63, or equivalent; Dow Corning 732 or equivalent.

Note: To avoid down drafts and/or cold air problems, it is recommended to seal off the area between the termination cap and the top of the solid-fuel chimney opening into which the vent cap has been installed.

Note: the metal ﬂ oor of the solid fuel ﬁ rebox may be removed to facilitate the installation of the insert. Clearance to combustible material under the insert is 3/8 in. (1 mm). You must use the leveling legs to raise the insert a minimum of 3/8 in. (10 mm) if the insert is to sit on combustible material. The side walls and top structure of the ﬁ rebox may not be altered with the exception of removable bafﬂ es and dampers. The original ﬁ replace may never be returned to solid fuel in this condition.

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/088

EXHAUST AIR VENT PIPE

THIS OPTION SHOWS THE AIR INLET TERMINATING IN THE CHIMNEY.

TERMINATION CAP

ADAPTOR

V=10 FT. (3 M) MINIMUM

40 FT. (12 M) MAXIMUM

Figure 5.3

INLET AIR VENT PIPE

WARNING

Fire Hazard. Asphyxiation Risk.

• The exhaust pipe must only be connected to the exhaust starting collar of the unit and the center collar of the termination cap.

• The inlet air pipe must only be connected to the inlet air collar of the unit and either attached to the inlet air collar of the termination cap or terminated in the chimney.

INSULATION

Note: Insulation is not included with the venting kit.

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/08 9

Gas Information

A. Fuel Conversions

Before making gas connections ensure that appliance being installed is compatible with the available gas type.

Any natural or propane gas conversions necessary to meet the appliance and locality needs must be made by a qualiﬁ ed technician using Hearth & Home Technologies speciﬁ ed and approved parts.

B. Converting to LP Gas

Note: Gas conversions should only be performed by a

qualiﬁ ed service person, and/or where required by state and local codes, licensed installer/service technician. In the Commonwealth of Massachusetts, installation must be performed by a licensed plumber or gas ﬁ tter.

Kit contents: Replacement oriﬁ ce; replacement pilot injector; valve regulator; conversion label.

Tools required: Power drill (a 90° handle is helpful); #2 Phillips bit; 5/32 in. (4 mm) Allen wrench; 5/8 in. (16 mm) open end wrench.

Remove logs and refractory support covers from the burner pan. Remove the two screws that secure the burner pan to the burner support with the screwdriver. Lift burner up and out of the ﬁ rebox opening.

With a 5/8 in. wrench remove the oriﬁ ce retaining nut. Replace with the appropriate oriﬁ ce (.063 LP / .106 NG).

Figure 6.2

Remove the pilot hood and set aside.

Figure 6.1

Figure 6.3

Note: Do not remove retaining clip from the pilot hood.

Using a 5/32 in. (4 mm) Allen wrench, remove the pilot injector and replace with an appropriate injector (#35 LP / #62 NG).

Figure 6.4

Reinstall burner and secure with the two screws previously removed.

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/0810

C. Valve Regulator Replacement

Remove upper and lower back shield. Loosen the set collars on the extension rods with the 3/32 in. Allen wrench. Remove the rods and adapter cap.

Turn control knob to the OFF position, ensure that gas supply to the valve has been turned off. Using a Torx TH20, or slotted screwdriver, remove the three pressure regulator mounting screws (A), pressure regulator tower (B), and diaphragm (C).

Ensure that the rubber gasket (D) is properly positioned and install the new HI/LO pressure regulator assembly to the valve using the new screws (E) supplied with the kit. Tighten screws securely. (Reference torque = 25 in./lb.) Install the enclosed identiﬁ cation label (F) to the valve body where it can be seen.

Fill out the conversion label and attach it to the valve cover.

Figure 6.5

WARNING

Fire Risk. Explosion Risk.

• Disconnect any electrical cords and turn off gas supply to unit before proceeding if converting fuel on an appliance already fully installed.

Figure 6.6

WARNING

Fire Risk. Explosion Risk. Gas Leak Risk.

• Rubber gasket must be seated properly on valve face.

• Do no install a valve or regulator that has been dropped.

WARNING

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/08 11

Fire Risk. Explosion Risk.

• If the information in these instructions is

not followed exactly, a ﬁ re, explosion or production of carbon monoxide may result causing property damage, personal injury or loss of life.

• The qualiﬁ ed service agency is responsible for the proper installation of this conversion kit. The installation is not proper and complete until the operation of the converted appliance is checked as speciﬁ ed in the manufacturer’s instructions supplied with the kit.

D. Gas Pressures

Proper input pressures are required for optimum appliance performance. Gas line sizing requirements need to be made following NFPA54.



WARNING

Fire Risk. Explosion Hazard. High pressure will damage valve.

• Disconnect gas supply piping BEFORE pressure testing gas line at test pressures above 1/2 psig.

• Close the manual shutoff valve BEFORE pressure testing gas line at test pressures equal to or less than 1/2 psig.

E. Gas Connection

Note: Have the gas supply line installed in acc ordance

with local building codes, if any. If not, follow ANSI

223.1. Installation should be done by a qualiﬁ ed installer approved and/or licensed as required by the locality. (In the Commonwealth of Massachusetts installation must be performed by a licensed plumber or gas ﬁ tter).

Note: A listed (and Commonwealth of Massachusetts approved) 1/2 inch (13 mm) T-handle manual shut-of f valve and ﬂ exible gas connector are connected to the 1/2 inch (13 mm) control valve inlet.

• If substituting for these components, please consult local codes for compliance.

WARNING

Verify inlet pressures.

• High pressure may cause overﬁ re condition.

• Low pressure may cause explosion.

• Verify minimum pressures when other household gas appliances are operating.

Install regulator upstream of valve if line pressure is greater than 1/2 psig.

Pressure requirements for appliance are shown in the table below. Minimum pressures must be met when other household gas appliances are operating.

Pressure Natural Gas Propane

Minimum inlet pressure

Maximum inlet gas pressure

Manifold pressure

4.5 inches w.c.

7.0 inches w.c.

3.5 inches w.c.

If the pressure is not sufﬁ cient, ensure:

• The piping used is large enough.

• The supply regulator is adequately adjusted.

• That the total gas load for the residence does not exceed the amount supplied.

The supply regulator (the regulator that attaches directly to the residence inlet or to the propane tank) should supply gas at the suggested input pressure listed above. Contact the local gas supplier if the regulator is at an improper pressure.

11.0 inches w.c.

14.0 inches w.c.

10.0 inches w.c.

Gas Leak Risk

• Support control when attaching pipe to prevent bending gas line.

Note: The gap between supply piping and gas access hole may be caulked with high temperature c aulk o r stu ffed with non-combustible, unfaced insulation to prevent cold air inﬁ ltration.

Leak test all gas line joints and the gas control valve prior to and after starting the appliance.

Before making the gas connection, ensure that the appliance you are installing is designed for the type of gas being supplied. This information can be found on the ratings label under the appliance. If the appliance has been converted to propane (LP), the valve cover should have a label stating that the appliance has been converted to propane.

Connect the gas line at the 3/8 in. (10 mm) pipe connector on the valve at the back of appliance. We recommend connecting the appliance with an approved flex gas line. If flex gas lines are not approved in your area, you must connect a hard pipe to the gas hookup.

You must supply a manual shut-off valve in a visible location within 3 ft. (914 mm) of the appliance.

Ensure that gas line does not come in contact with outer wrap of appliance. Follow local codes.

Incoming gas line should be piped into the valve compartment and connected to the 1/2 inch connection on the manual shutoff valve.

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/0812

WARNING

Fire or Explosion Hazard

• Gas buildup during line purge may ignite.

• Purge should be performed by qualiﬁ ed technician.

• Ensure adequate ventilation.

• Ensure there are no ignition sources such as sparks or open ﬂ ames.

• A small amount of air will be in the gas supply lines. When ﬁ rst lighting appliance it will take a short time for air to purge from lines. When purging is complete the appliance will light and operate normally.

Air only needs to be purged again if gas valve has been

turned to the OFF position.

WARNING

CHECK FOR GAS LEAKS Explosion Risk Fire Risk Asphyxiation Risk

• Check all ﬁ ttings and connections.

• Do not use open ﬂ ame.

• After the gas line installation is complete, all connections must be tightened and checked for leaks with a commercially-available, non-corrosive leak check solution. Be sure to rinse off all leak check solution following testing.

Fittings and connections may have loosened during shipping and handling.

WARNING

Fire hazard. Do NOT change the valve settings.

• This valve has been preset at the factory.

• Changing valve settings may result in ﬁ re hazard or bodily injury.

HIGH AL TITUDE INST ALLATIONS

Omni-T est Laboratories, Inc. listed gas appliances are tested and approved without requiring changes for elevations from 0 to 2000 feet in the U.S.A. and 0 to 4500 feet in Canada.

If installing this appliance at an elevation above 4500 feet (in Canada), check with local authorities.

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/08 13

This appliance is equipped with a three pronged (grounding) plug for your protection against shock hazard and should be plugged directly into a prop

Electrical Information

A. Recommendation for Wire

See Figure 7.1 for recommended maximum lead length (two wire) when using wall thermostat/switch.

NOTE: This appliance must be electrically wired and grounded in accordance with local codes or, in the absence of local codes, with National Electric Code ANSI/NFPA 70-latest edition or the Canadian Electric Code, CSA C221.1.



• A 110-120 V AC circuit for this product must be protected with ground-fault circuit-interrupter protection, in compliance with the applicable electrical codes, when it is installed in locations such as in bathrooms or near sinks.

B. Connecting to the Appliance

1. This appliance may be used with a wall switch, wall

mounted thermostat and / or a remote control

2. If using thermostat, use one compatible with a millivolt

gas valve system.

3. Follow parameters for locating thermostat (see individ-

ual thermostat instructions) to ensure proper operation of appliance.

4. Use low resistance thermostat wire for wiring from

ignition system to the wall switch and thermostat.

5. Use the following chart for wire sizing.

Do not connect this appliance to a thermostat serving any other appliance.

Bedroom installation in Canada requires this appliance to be connected to a thermostat.

WARNING

Shock hazard.

•

This appliance is equipped with a three pronged (grounding) plug for your protection against shock hazard and should be plugged directly into a properly grounded three prong receptacle. Do not cut or remove the grounding prong from this plug.

C. Standing Pilot Ignition System Wiring

This appliance DOES NOT require 110 VAC supply for operation. A wiring diagram is shown in Figure 7.2 on the next page.

This appliance is equipped with a millivolt control valve.

Wire Size Max. Length

16 gauge 65 feet 18 gauge 40 feet 20 gauge 25 feet 22 gauge 18 feet

Figure 7.1

6. Keep wire lengths as short as possible by removing

any excess wire length.

7. Low voltage and 110 VAC voltage cannot be shared

within the same wall box.

8. Ensure the thermostat is mounted level for accurate

readings.

9. The thermostat should be mounted on an inside wall

and not in direct line with the appliance convection air.

10. If the thermostat is located too close to the appli-

ance, you may need to set the temperature setting slightly higher to maintain the desired temperature in your home.

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/0814

PILOT ADJUSTMENT CAP

VARIABLE REGULATOR

MANIFOLD PRESSURE

ROCKER SWITCH / WALL THERMOSTAT / REMOTE

PUSH BUTTON IGNITOR

THERMOPILE

PILOT

IGNITOR

THERMOCOUPLE

INLET PRESSURE

Figure 7.2

CAUTION

Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing.

WARNING

Shock hazard.

• Replace damaged wire with type 105º C rated wire.

• Wire must have high temperature insulation.

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/08 15

STATIONARY LATCHES

SPRING LOADED LATCHES

Appliance Setup

A. Remove Shipping Materials

Remove shipping materials from inside or underneath the ﬁ rebox.

B. Accessories

Install approved accessories per instructions included with accessories. See Service Parts List for appropriate accessories.

WARNING

Shock or ﬁ re risk. Use ONLY optional accessories approved for

this appliance.

• Using non-listed accessories voids warranty.

• Using non-listed accessories may result in a safety hazard.

• Only Hearth & Home Technologies approved accessories may be used safely.

C. Door Crown Installation

Open lower access panel. Pull out and unhook the two spring latches on the bottom of the appliance that secure the door.

Rotate the door forward approximately 1-1/2 in. (38 mm). Holding the ashlip, lift the door up off of the stationary latches and away from the appliance.

Uninstall the existing crown by removing the four screws on the back side of the door. Retain the screws.

Figure 8.2

Use a ﬂ at-head screwdriver to pry the black crown free on the right side. Remove the crown and discard.

Figure 8.1

STATIONARY LATCHES

SPRING LOADED LATCHES

Figure 8.3

Carefully align the left side of the crown into place, and wrap it across the face of door, ﬁ nally place on the right hand side. Reinsert and tighten the screws previously removed.

Figure 8.4

Note: Use a soft cloth and a window cleaning solution to clean

all ﬁ ngerprint oils from t he gold or nickel surfac e of crown PRIOR to lighting the appliance.

snapping it into

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/0816

D. Grille Installation

SCREWS

BACK OF TOP PANEL

BACK OF SIDE PANEL

SCREWS

Remove the door of appliance. Remove the four screws (two at each end) holding grille in place. Lift up to remove.

Figure 8.5

Install the new grille by reversing removal instructions.

Note: Clean glass and gold or nickel with glass cleaner and a soft cloth, wiping off all ﬁ ngerprints prior to ﬁ rst ﬁ re to prevent permanent staining.

Assemble the trim with the two corner brackets provided. Slide the assembled trim over the assembled panel set.

Figure 8.7

Slide the panel/trim down over the face of the unit, behind the top, aligning the holes in the upper and lower, right and left corners, and secure the panel and trim set to the appliance with the attachment screws using four screws, two per side.

E. Panel Set Installation

Included in kit: (2) Angle Brackets and set screws; (1)

3 piece Trim; (2) Side Panels; (1) Top Panel; (1) Switch plug; and (8) screws.

Tools required: Philips head screwdriver.

Note: Remove the door from the insert before beginning the

panel installation.

Assemble the panel top to the panel sides with the screws provided.

BACK OF TOP PANEL

SCREWS

BACK OF SIDE PANEL

Figure 8.6

SCREWS

Figure 8.8

Determine your desired placement of the rocker switch. 1 If you wish to place it on the control panel in the "Main

Burner" opening: Disconnect the "ON/OFF" switch from the low voltage wire leads. Pull the wires through the control panel, attach the wires to the "ON/OFF" rocker switch and push the rocker switch into the "Main Burner opening on control panel. Place the plug provided in empty opening on the panel and trim.

2. If you wish to place it on the side of appliance in the knock out provided on the panel and trim: Carefully reposition the wiring beneath the firebox to the RIGHT side of appliance. Disconnect the "ON/OFF" switch from the low voltage wire leads. Pull the wires through the knockout plate on the panel and trim, attach the wires to the "ON/OFF" rocker switch and push the rocker switch into the opening on the panel and trim. Place plug provided with panel set in empty switch location.

Install the power cord restraint found in the appliance component bag. (Cord is shipped exiting the right side of the appliance, but can be routed in either direction.) A notch will be needed in the trim piece for the cord restraint.

Slide the appliance back until the panel is tight to the ﬁ replace.

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/08 17

F. Brick Installation

BAFFLE

SUPPORTS

BAFFLE

REAR BRICK PANEL

BRICK CLIPS

BRICK CLIP

Install baffle: Bring the front edge of the baffle up and

forward until the baffle rests on the baffle supports, as shown.

BAFFLE

SUPPORTS

BAFFLE

Rest bottom of panel on

shelf and push top into position. Hold in place by bending brick clips over along front edge of brick.

Figure 8.12

Figure 8.9

Lift the baffle slightly and install the rear brick panel. Rest baffle on rear brick panel.

BAFFLE

REAR BRICK PANEL

Figure 8.10

Install right brick panel.

Install left brick panel in the same way by pushing in the top and securing by bending clips at top and bottom.

BRICK CLIP

Figure 8.13

Finished brick installment.

BRICK CLIPS

Figure 8.11

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/0818

Figure 8.14

G. Positioning the Logs

While still breakable, the logs do not become fragile until after the appliance is burned and they have cured. After curing, any handling must be done with care as breakage can easily occur.

Note: Logs have been designed to work speciﬁ cally with the burner of this appliance. Exact placement will ensure proper operation of your gas appliance and reduce sooting.

Complete log installation.

Install left log (#2) over locating pins on burner.

Figure 8.18

Install right log (#3) in empty space on burner.

Figure 8.15

After installing brick, install rear log (#1) over locating pins on log shelf, as shown.

Note: Locator pins are included in the log component package.

Figure 8.16

Install cover for refractory supports on left and right sides.

Figure 8.19

Install "S" shaped log (#4) on pins on right and rear logs.

Figure 8.20

Install left twig (#5) on pin in left log resting just under "S" shaped log.

Left side

Figure 8.17

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/08 19

Right side

Figure 8.21

H. Mineral Wool I. Blower Installation

Included in kit: Blower.

WARNING

Explosion Risk.

• Follow ember placement instructions in manual.

• Do NOT place embers directly over burner ports.

• Replace ember material annually.

Improperly placed embers interferes with proper burner operation.

Place individual pieces of embers in front of and around the gas log where they can be seen. Space them so that gas can contact them on all sides. Avoid stacking the embers on top of each other.

Tools required: Powered Phillips head screwdriver.

Turn off gas and disconnect appliance from electricity. Remove logs and burner from appliance. Remove blower access cover in bottom of firebox by removing the screws. Retain screws for reassembly.

Figure 8.23

Figure 8.22

Note: Do not block gas ports.

Disconnect wires from the snap disk on back of access cover.

Figure 8.24

Lift blower off of studs and pull through opening.

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/0820

Figure 8.25

Disconnect wires from the blower. Remove grommet retainer from old blower and install on

new blower.

Figure 8.26

F = 1/4 in. (6 mm) female spade M = 1/4 in. (6 mm) male spade

BLK

Figure 8.27

Installation is the reverse of removal.

RHEOSTAT

SNAP DISC

WHT

BLK

WHT

BLK

WHT

GRN

BLOWER

Figure 8.28 Blower Wiring Diagram

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/08 21

J. Air Shutter Adjustment

The air shutter is used to fine-tune the flame as necessary.

The air shutter is shipped in the fully open position.

Allow the unit to operate 15-20 minutes before making any adjustments to the air shutter. This will give the flame time to reach its height and color before making adjustments.

The air shutter control bolt adjusts the amount of air that mixes with the gas as it enters the burner pan.

To adjust the air shutter, remove the screw from the control panel.

Figure 8.29

The air shutter is located on the underside of the appliance, on the right side. The air shutter is secured with a wing nut. Loosen the wing nut but do not remove.

Figure 8.31

Moving the shutter bolt to the right closes the air shutter. Moving the shutter bolt to the left, will open the air shutter.

Opening the air shutter causes flames to become shorter and blue. Closing the air shutter creates taller orange/ yellow flames.

After adjustment, tighten wing nut to lock in place.

Rotate forward and lift off.

Figure 8.30

OPENS LEFT CLOSES RIGHT

Figure 8.32

Note: Do not close so muc h as to cause a sooty ﬂ ame.

Improper adjustment can cause sooting in the ﬁ rebox and/or on the outside of a house with a horizontal termination.

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/0822

Operating Instructions

A. Before Lighting Appliance

Read this entire manual prior to using the appliance. Failure to follow the instructions may result in property damage, bodily injury, or even death.

Before operating this appliance have a qualiﬁ ed tech- nician:

• Remove all shipping materials from inside and/or underneath the ﬁ rebox.

• Review proper placement of logs and mineral wool.

• Check the wiring.

• Check the air shutter adjustment.

• Ensure that there are no gas leaks.

• Ensure that the glass is sealed and in the proper position.

• Ensure that the ﬂ ow of combustion and ventilation air is not obstructed (front grilles and vent caps).

WARNING

Glass door must be in place when appliance is operating.

Risk of:

• Combustion Fumes

• Fire Do NOT operate appliance with glass

door removed.

• Open viewing glass for servicing only.

• Glass door MUST be in place and sealed before operating appliance.

• Only use glass door certiﬁ ed for use with appliance.

• Glass replacement should be done by qualiﬁ ed technician.

WARNING

HOT SURFACES!

Glass and other surfaces are hot during operation AND cool down.

Hot glass will cause burns.

• Do not touch glass until it is cooled

• NEVER allow children to touch glass

• Keep children away

• CAREFULLY SUPERVISE children in same room as ﬁ replace.

• Alert children and adults to hazards of high temperatures.

High temperatures may ignite clothing or other ﬂ ammable materials.

• Keep clothing, furniture, draperies and other ﬂ ammable materials away.

WARNING

Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to the owner’s information manual provided with this appliance. For assistance or additional information consult a qualiﬁ ed installer, service agency or the gas supplier.

WARNING

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/08 23

B. Lighting Appliance

FOR YOUR SAFETY READ BEFORE LIGHTING

LIGHTING INSTRUCTIONS

TO TURN OFF GAS TO APPLIANCE

FOR YOUR SAFETY READ BEFORE LIGHTING

WARNING: If you do not follow these instructions exactly, a fire or explosion may

result causing property damage, personal injury or loss of life

A. This appliance has a pilot that must be lit manually. When lighting the pilot, follow these instructions exactly. B. BEFORE LIGHTING, smell around the appliance area for gas. Be sure to smell next to the floor because some gas is heavier

WHAT TO DO IF YOU SMELL GAS:

* Do not try to light any appliance. * Do not touch any electric switch, do not use any phone in your building. * Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions. * If you cannot reach your gas supplier, call the fire department. C. Use only your hand to push in or turn the gas control knob. Never use tools. If the knob will not push in or turn by hand, don't

D. Do not use this appliance if any part has been under water. Immediately call a qualified service technician to

than air and will settle on the floor.

try to repair it, call a qualified service technician. Force or attempted repair may result in a fire or explosion.

inspect the appliance

and to replace any part of the control system and any gas control which has been under water.

LIGHTING INSTRUCTIONS

1. STOP! Read the safety information above on this label.

2. Set the thermostat to the lowest setting (if applicable) and turn off the switch at the control panel.

3. Disconnect the power from the appliance.

4. Open the door of the appliance. May need to remove face/front first.

5. Push in gas control knob slightly and turn clockwise to the "OFF" position. Do not force.

6. Wait five (5) minutes to clear out any gas. Smell for gas, including near the floor. If you smell gas, STOP! Follow "B" of the safety information above. If you don't smell gas go to the next step.

7. Push gas control knob in and turn counterclockwise to the pilot position. NOTE: Knob cannot be turned unless knob is pushed in slightly. Do not force.

8. PIEZO IGNITER: (This may take many repetitions for lighting.)

ELECTRONIC IGNITER: If the unit is equipped with an electronic igniter it should begin sparking right away.

9. The pilot should be visible through the door opening.

10. After the pilot is lit, continue holding control knob down for approximately 30 seconds. Release the knob and it will pop back up. Pilot should remain lit.

If it goes out, repeat steps 7 through 9.

* If the knob does not pop up when released, stop and immediately call your

service technician or gas supplier.

* If the pilot will not stay lit after several tries, turn the gas control knob

clockwise to "OFF" and call your service technician or gas supplier.

11. Reinstall door and face. Wait five minutes to allow pilot flame to stabilize and establish proper draft.

12. Push down and turn gas control knob counterclockwise to "ON".

13. Push burner rocker switch on the control panel to "ON". If thermostat is to be used, leave switch in "OFF" position and set the

thermostat to desired setting.

14. Reconnect electrical power to appliance.

Press down on the gas control knob in pilot position and simultaneously press the piezo igniter.

MILLIVOLT GENERATOR

PILOT HOOD

THERMOCOUPLE

TO TURN OFF GAS TO APPLIANCE

1. Set the thermostat to lowest setting.

2. Turn off all electric power to the appliance if service is to be performed.

3. Push in gas control knob slightly and turn clockwise to "OFF" position.

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/0824

C. After Appliance is Lit

Initial Break-in Procedure

When you light the appliance, you may notice that it produces heat which does have an associated odor or smell. If you feel this odor is excessive it may require the initial three to four hour continuous burn on high followed by a second burn up to 12 hours to fully drive off any odor from paint and lubricants used in the manufacturing process. Condensation of the glass is normal.

CAUTION

• Prevent accidental appliance operation when not attended.

• Unplug or remove batteries from remote control if absent or if appliance will not be used for an extended period of time.

• Property damage possible from elevated temperatures.

NOTE: The appliance should be run three to four hours on the initial start-up. Turn it off and let it cool completely. Remove and clean the glass. Replace the glass and run the appliance for an additional 12 hours. This will help to cure the products used in the paint and logs.

During this break-in period it is recommended that some windows in the house be opened for air circulation. This will help avoid setting off smoke detectors, and help eliminate any odors associated with the appliance’s initial burning.

WARNING

Fire Risk. High Temperatures. Keep combustible household items away from

appliance. Do NOT obstruct combustion and ventilation air.

• Do NOT place combustible items on top of or in front of appliance.

• Keep furniture, draperies away from appliance.

CAUTION

Smoke and odors released during initial operation.

• Open windows for air circulation.

• Leave room during initial operation.

• Smoke may set off smoke detectors.

Smoke and odors may be irritating to sensitive individuals.

WARNING

Fire Hazard. Keep combustible materials, gasoline and

other ﬂ ammable vapors and liquids clear of appliance.

• Do NOT store ﬂ ammable materials in the appliance’s vicinity.

• Do NOT use gasoline, lantern fuel, kerosene, charcoal lighter ﬂ uid or similar liquids in this appliance.

• Combustible materials may ignite.

D. Frequently Asked Questions

ISSUE SOLUTIONS

Condensation on the glass

Blue ﬂ ames

Odor from appliance

Film on the glass

Metallic noise

This is a result of gas combustion and temperature variations. As the appliance warms, this condensation will disappear.

This is a result of normal operation and the ﬂ ames will begin to yellow as the appliance is al- lowed to burn for 20 to 40 minutes.

When ﬁ rst operated, this appliance may release an odor for the ﬁ rst several hours. This is caused by the curing of the paint and the burning off of any oils remaining from manufacturing. If appliance has not been used for some time, dust can build up and cause an odor.

This is a normal result of the curing process of the paint and logs. Glass should be cleaned within 3 to 4 hours of initial burning to remove deposits left by oils from the manufacturing process. A non-abrasive cleaner such as gas ﬁ replace glass cleaner may be necessary. See your dealer.

Noise is caused by metal expanding and contracting as it heats up and cools down, similar to the sound produced by a furnace or heating duct. This noise does not affect the operation or longevity of the appliance.

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/08 25

Troubleshooting

With proper installation, operation, and maintenance your gas appliance will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist a qualiﬁ ed service person in the diagnosis of a problem and the corrective action to be taken. This troubleshooting guide can only be used by a qualiﬁ ed service technician.

A. Standing Pilot Ignition System

Symptom Possible Causes Corrective Action

1. After repeated triggering of the red or black piezo ignitor button, the spark ignitor will not light the pilot.

2. The pilot will not stay lit after carefully following the lighting instructions.

a. Defective ignitor. Check the spark at the electrode and pilot. If no spark and electrode

wire is properly connected, replace the ignitor.

b. Defective pilot or misaligned electrode (spark at electrode).

c. No gas or low gas pressure. Check the remote shut-off valves from the ﬁ replace. Usually, there

d. No LP in tank. Check the LP (propane) tank. You may be out of fuel. a. Defective thermocouple. Check that the pilot ﬂ ame impinges on the thermocouple. Clean

b. Defective valve. If the thermocouple is producing more than 15 millivolts, replace

Using match, light the pilot. If the pilot lights, turn off the pilot and trigger the red piezo ignitor button again. If the pilot lights, an improper gas/air mixture caused the bad lighting and a longer purge period is recommended. If the pilot will not light, ensure the gap at the electrode and pilot is one-eighth (1/8) inch to have a strong spark. If the gap is OK, replace the pilot.

is a valve near the gas main. There can be more than one (1) valve between the ﬁ replace and the main.

and/or adjust the pilot for maximum ﬂ ame impingement. Ensure that the thermocouple connection at the gas valve is fully

inserted and tight (hand tighten plus 1/4 turn). Disconnect the thermocouple from the valve, place one millivolt

meter lead wire on the tip of the thermcouple and the other meter lead wire on the thermocouple copper lead. Start the pilot and hold the valve knob in. If the millivolt reading is less than 15mV, replace the thermocouple.

faulty valve.

3. The pilot is burning, there is no burner ﬂ ame, the valve knob is in the ON position, and the ON/OFF switch is in the ON position.

a. ON/OFF switch or wires defective.

b. Thermopile may not be generating sufﬁ cient millivoltage.

Check the ON/OFF switch and wires for proper connections. Place the jumper wires across the terminals at the switch. If the burner comes on, replace the defective switch. If the switch is OK, place the jumper wires across the switch wires at the gas valve. If the burner comes on, the wires are faulty or connections are bad.

If the pilot ﬂ ame is not close enough physically to the thermopile, adjust the pilot ﬂ ame.

Be sure the wire connections from the thermopile at the gas valve terminals are tight and that the thermopile is fully inserted into the pilot bracket.

Check the thermopile with a millivolt meter. Take the reading at TH-TP&TP terminals of the gas valve. The meter should read 325 millivolts minimum, while holding the valve knob depressed in the pilot position, with the pilot lit, and the ON/OFF switch in the OFF position. Replace the faulty thermopile if the reading is below the speciﬁ ed minimum.

With the pilot in the ON position, disconnect the thermopile leads from the valve. Take a reading at the thermopile leads. The reading should be 325 millivolts minimum. Replace the thermopile if the reading is below the minimum.

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/0826

Troubleshooting (continued)

Symptom Possible Cause Corrective Action

3. Continued c. Defective valve. Turn the valve knob to the ON position. Place the ON/OFF switch in the ON position. Check the millivolt meter a the thermopile terminals. The millivolt meter should read greater than 125mV. If the reading is acceptable, and if the burner does not come on, replace the gas valve.

d. Plugged burner oriﬁ ce. Check the burner oriﬁ ce for stoppage. Remove stop-

page.

e. Wall switch or wires are defective. Follow the corrective action in Symptom and Pos-

sible Cause 1.a above. Check the switch and wiring. Replace where defective.

4. Frequent pilot outage

problem.

5. The pilot and main

burner extinguish while in operation.

6. Glass soots. a. Flame impingement. Adjust the log set so that the ﬂ ame does not exces-

7. Flame burns blue

and lifts off burner.

a. Pilot ﬂ ame may be too high or too low, or blow- ing out (high pressure), causing pilot safety to drop out.

a. No LP in tank. Check the LP (propane) tank. Reﬁ ll the fuel tank. b. Inner vent pipe leaking exhaust gases back into

the system. c. Glass too loose and air tight packet leaks in

corners after usage. d. Bad thermopile or thermocouple. Replace if necessary. e. Improper vent cap installation. Check for proper installation and freedom from debris

b. Improper air shutter setting. Adjust the air shutter located on the control panel. c. Debris around air shutter. Inspect the opening at the base of the burner. NO MA-

a. Insufﬁ cient oxygen being supplied. Ensure that the vent cap is installed properly and free

Clean thermocouple and adjust the pilot ﬂ ame for maximum ﬂ ame impingement. Follow lighting instruc- tions carefully.

Check venting system for damage. Replace/repair improperly assembled pipe sections.

Replace glass panel assembly.

or blockage.

sively impinge on it.

TERIAL SHOULD BE PLACED IN THIS OPENING.

of debris. Ensure that the vent system joints are tight and have no leaks.

Ensure that no debris has been placed at the base of, or in the area of the air holes in the center of the base pan beneath the burner.

Ensure that the glass is tightened properly on the unit, particularly on top corners.

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/08 27

Although the frequency of appliance servicing and maintenance will depend on use and the type of installation, a qualiﬁ ed service technician should perform an appliance checkup at the beginning of each heating season.

Maintaining and Servicing Appliance

WARNING

Risk of injury or property damage.

Before servicing:

• Turn off gas.

• Turn off electricity to appliance.

• Disable remote control, if one is present.

• Ensure appliance is completely cooled.

After servicing:

• Replace any screen or barrier that was removed.

• Reseal and reinstall any venting removed for servicing.

WARNING

Annual inspection by qualiﬁ ed technician recommended.

Check:

• Condition of glass, glass assembly and glass seal.

• Obstructions of combustion and ventilation air.

• Obstructions of termination cap.

• Burner ignition and operation.

• Burner air shutter adjustment

• Gas connections and ﬁ ttings.

Clean:

• Glass

• Air passageways, grilles, control compartment

• Burner, burner ports

Risk of:

• Fire

• Delayed ignition or explosion

• Exposure to combustion fumes

• Odors

WARNING

Inspect external vent cap regularly.

• Ensure no debris blocks cap.

• Combustible materials blocking cap may ignite.

• Restricted air ﬂ ow affects burner operation.

A. Glass Replacement

Glass can be replaced either as three separate pieces, or as an assembly with the door. See Service Parts List.

To Replace Separate Glass Pieces

• Turn off gas to the appliance.

• Remove the door and set on a protective surface.

• Remove the door crown.

• Remove the top and bottom retainer screws from the front of the door. Set the top and bottom glass retainers aside.

• Loosen the side glass retainer screws, but do not remove.

• Remove the glass pieces and discard. Keep the aluminum channels for reassembly.

• Slide replacement side glass into the side glass retainers.

• Place the aluminum channels over the side glass.

• Install the center glass into the aluminum channels.

• Reinstall the glass retainers and screws. Reinstall door crown.

CAUTION

Handle glass assembly with care.

NOTE: Clean glass after initial 3-4 hours operation. Longer operation without cleaning glass may cause a permanent white ﬁ lm on glass.

When cleaning glass door:

• Avoid striking, scratching or slamming glass.

• Do NOT use abrasive cleaners.

• Use a hard water deposit glass cleaner on white ﬁ lm.

• Do NOT clean glass when hot.

• Turn off appliance after 3-4 hours of operation and ALLOW TO COOL.

• Remove and clean glass assembly.

• Replace glass assembly and operate appliance for additional 12 hours.

Refer to maintenance instructions.

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/0828

Door Frame with Glass Assembly Replacement

Use only Door Assembly replacement as speciﬁ ed in Sec- tion 8 of this manual, available from your dealer, if any glass becomes broken in the Columbia Bay Insert.

Follow the previous instructions to install the door crown and grille to the new Door Assembly.

Note: The glass and gasketing must be replaced as a complete unit as supplied by the manuf ac tur er. Do not use substitute material.

B. Maintenance Tasks

Inspect Maintenance Tasks

Doors 1. Inspect for scratches, dents or other damage and repair as necessary.

2. Verify no obstructions to air ﬂ ow.

3. Verify maintenance of proper clearance to combustible household objects.

Gasket Seal, Glass Assembly and Glass

Valve Compartment and Firebox Top

Logs 1. Inspect for broken, damaged, or missing logs. Replace as necessary.

Firebox 1. Inspect for paint condition, warpage, corrosion or perforation. Sand and repaint as neces-

Burner Ignition and Operation

Venting 1. Inspect venting for blockage or obstruction such as bird nests, leaves, etc.

Remote Controls 1. Verify operation of remote.

1. Inspect gasket seal and its condition.

2. Inspect glass for scratches and nicks that can lead to breakage when exposed to heat.

3. Conﬁ rm there is no damage to glass or glass frame, Replace as necessary.

4. Verify that latches engage properly and glass attachment components are intact and operating properly. Replace as necessary.

5. Clean glass. Replace glass assembly if severely coated with silicate deposits that cannot be removed.

1. Vacuum and wipe out dust, cobwebs, debris or pet hair. Use caution when cleaning these areas. Screw tips that have penetrated the sheet metal are sharp and should be avoided.

2. Remove any foreign objects.

3. Verify unobstructed air circulation.

2. Verify correct log placement and no ﬂ ame impingement causing sooting. Correct as neces- sary.

sary.

2. Replace appliance if ﬁ rebox has been perforated.

1. Verify burner is properly secured and aligned with pilot or igniter.

2. Clean off burner top, inspect for plugged ports, corrosion or deterioration. Replace burner if necessary. USE CAUTION WHEN CLEANING/HANDLING CERAMIC BURNER.

3. Replace ember material with new dime-size and shape pieces. Do not block ports or obstruct lighting paths.

4. Check for smooth lighting and ignition carryover to all ports. Verify there is no ignition delay.

5. Inspect for lifting and other ﬂ ame problems.

6. Inspect oriﬁ ce for soot, dirt or corrosion.

7. Verify manifold and inlet pressures. Adjust regulator as required.

8. Inspect pilot ﬂ ame strength. Clean or replace oriﬁ ce as necessary.

9. Inspect thermocouple/thermopile sensor rod for soot, corrosion and deterioration. Clean with emery cloth or replace as required.

10. Verify millivolt output. Replace as necessary.

2. Conﬁ rm that termination cap remains clear and unobstructed by plants, etc.

3. Verify that termination cap clearance to subsequent construction (building additions, decks, fences or sheds) has been maintained.

4. Inspect for corrosion or separation.

5. Verify weather stripping, sealing and ﬂ ashing remains intact.

2. Replace batteries in remote transmitters and battery-powered receivers.

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/08 29

Reference Materials

A. Appliance Dimension Diagram

Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section 3.

RIGHT SIDE OF STOVE

B A

ROCKER SWITCH AND

WIRING IS ACCESSIBLE

HERE WHEN SHIPPED

ABCDEFG

inches 20 25-7/8 10-7/8 8-5/16 29 21-1/2 19

Millimeters 508 657 276 211 737 546 483

MINIMUM FIREBOX OPENING

Height: Width: Depth:

Front Rear Front Rear Top Bottom

Inches 19 13-1/2 26 20 13 13

Millimeters 483 343 660 508 330 330

ELECTRICAL

CONNECTION AND GAS

CONNECTION EXTEND

FROM HERE

Figure 12.1 Appliance Dimensions

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/0830

B. Vent Components List

HHT

Component # Dura-Vent GS

Catalog #

LINK-DV4-30B Includes one piece 3 in. x 30 ft. Flex; one piece 3 in. x 4 ft. Flex; Cap/Adapter Linear

923GK Colineal Flex Connector 991 High Wind Vertical Termination Cap 2280 3 in. x 35 ft. Flex Extension Length

Venting System Components Description

to Coaxial with Flashing.

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/08 31

Service Parts

COLBAY-INS

Service Parts Diagram Columbia Bay Insert

Beginning Manufacturing Date: April 2003

Ending Manufacturing Date: ______

Log Set Assembly

Part number list on following page.

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/0832



C. Service Parts List

IMPORT ANT: THIS IS DA TED INFORMA TION. When requesting service or replacement parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer.

ITEM DESCRIPTION SERIAL # PART NUMBER

Log Set Assembly 7002-009 Y 1 Blower, Convection 2 Blower Access Plate, Rear 7008-141

Transition Assembly 7008-01 1

3 4 T op Assembly 7008-027 5 Latch Assembly , Stationary 6

Brick Retainer 7 Refractory Support, Rear 8 Brick Set 7002-002 9 Refractory Support, Left

Black 7008-009

10 Grill Bar Assembly, Rod

11 Door Assembly with Glass 12 13 Door, Face Access 14 Burner with Neck Assembly 7002-005 Y 15 Refractory Support, Right

Door Crown

Anti -Bang Kit 842-5040

Bafﬂ e Seal 7002-131

Blower Access Plate 7008-135

Component Pack

Gold RDGRL-GD Nickel RDGRL-NL

812-4900 Y

7003-006 479-0190 7002-128

7002-130

DOOR-COLBAY-INS 462-0150 7008-117

7002-129

COLBAY-INS

Stocked at Depot

Contains LP Oriﬁ ce, Mineral Wool, LP Pilot Injector, Strain Relief Bushing, Hose Clamp, LP Conversion Regulator, conversion Labels, Touch-up Paint, Owner’s Manual, Warranty Card, and Consumer View Card

Gasket Tadpole (10 FT) 842-5130 Y

Mineral Wool 050-721

On/Off Valve

Snap disc, Ceramic 230-0960 Y

Switch, ON/Off Rocker 230-0730 Y

Thermostat, Progammmable 811-0520

Wire Harness (For Blower) 455-7240 Y

Wire Harness (For Main Burner) 462-0510 Y

Conversion Kit NG 844-8230 Y

Conversion Kit LP LPK-MB Y

Pilot Oriﬁ ce NG 29476 Y Pilot Oriﬁ ce LP 200-2630 Y Regulator NG 230-1570 Y Regulator LP 230-1520 Y

Additional service part numbers appear on following page.

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/08 33

7002-006

15697 Y

Service Parts

COLBAY-INS

Bottom Firebox Assembly

Valve Assembly Diagram Columbia Bay Insert

Beginning Manufacturing Date: April 2003

Ending Manufacturing Date: ______

IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer.

ITEM DESCRIPTION SERIAL # PART NUMBER

Pilot Assembly NG( for LP use LP Pilot Oriﬁ ce) 1

Pilot Assembly NG (with Injector) 2 Speed Control 3 Valve Bracket

Valve NG 4

Valve LP 5 Knob Extension, On/ Off 6 Knob, Extension, HI/LO 571-533 7 Piezo Ignitor 8 Bulkhead Stop 9 Bulkhead

10 Air shutter Assembly 1 1 Latch Assembly 12 Burner Support, Front 13 Burner support, Rear

Oriﬁ ce, NG .106 19837

Oriﬁ ce, LP .063 17236

Flex Assembly 24 in 2098-034

230-1781 842-4280 842-0370 7008-112 842-0230 842-0240 571-534

291-513 474-0090 26457 7002-016 7003-005 7002-132 7002-127

Stocked

at Depot

Y Y Y

Y Y Y Y Y

Y Y Y

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/0834



D. Limited Lifetime Warranty Hearth & Home Technologies LIMITED WARRANTY

Hearth & Home Technologies (“HHT”) and its respective brands extends the following warranty for HHT gas, wood, pellet and electric appliances purchased from an authorized HHT dealer and installed in the United States of America or Canada. Warranty starts with date of purchase by the original owner (End User) except as noted for replacement parts.

Warranty Period HHT Manufactured Appliances and Venting Parts Labor Gas Wood Pellet

1 Year XXXXXX

EPA

Wood

Electric Venting

Components Covered

All Parts and Material Except as

covered by Conditions, Exclusion,

and Limitations listed

2 years

3 years X Firepots

5 years 3 years X X Castings & Bafﬂ es

7 years 3 years X X X

10 years 1 year X Burners, Logs & Refractory

Limited

Lifetime

1 year X Firebox & Heat Exchanger

90 Days XXXXXX All Replacement Parts

XXXX Blowers

X Molded Refractory Panels

Igniters, Electronic Components,

and Glass

Firebox, HHT Chimney,

Termination & Heat

Exchanger

See Conditions, Exclusions, and limitations. 9-01-08

CONDITIONS, EXCLUSIONS & LIMITATION OF LIABILITY

• This warranty applies to the original owner and is transferable up to two years from date of purchase to the new homeowner, provided the purchase was made through an authorized dealer or distributor of HHT, and the appliance remains in its original place of installation.

• The maximum amount recoverable under this warranty is limited to the purchase price of the product.

• In no event shall HHT be liable for any incidental or consequential damages caused by defects in the product.

• Adjustments, regular maintenance, cleaning and temporary repairs, or the failure to duplicate the problem in the home is not covered under this warranty.

Page 1 of 2 4021-645A 09-01-08

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/08 35

D. Limited Lifetime Warranty (continued)

• This limited warranty does not extend to or include surface ﬁ nish on the appliance or terminations, door gasketing, glass gasketing, glass discoloration, ﬁ rebrick, pellet logs, kaowool or other ceramic insulating materials. Rust and/or corrosion on any of the metal surfaces, cast iron components, bafﬂ es, ﬁ repots, doors, or ﬁ rebox area are not covered by this warranty.

• Noise resulting from minor expansion, contraction, or movement of certain parts is normal and complaints related to this noise are not covered by this warranty.

• HHT’s obligation under this warranty does not extend to damages resulting from: (1) installation, operation or maintenance of the appliance not in accordance with the installation instructions; operating instructions and the listing agent identiﬁ cation label furnished with the appliance; (2) installation which does not comply with local building codes; (3) shipping, improper handling, improper operation, abuse, misuse, accident or unworkmanlike repairs; (4) environmental conditions, inadequate ventilation or drafting caused by tight sealing construction of the structure or handling devices such as exhaust fans or forced air furnaces or other such causes; (5) use of fuels other than those speciﬁ ed in the operating instructions; (6) installation or use of components not supplied with the appliance or any other components not expressly authorized and approved by HHT; and/or (7) modiﬁ cation of the appliance not expressly authorized and approved by HHT in writing.

• This warranty does not apply to non-HHT venting components, hearth components or other accessories used in conjunction with the installation of this product.

• This warranty is void if the appliance has been over-ﬁ red or operated in atmospheres contaminated by chlorine, ﬂ uorine, or other damaging chemicals the appliance is subject to prolonged periods of dampness or condensation, or there is any damage to the appliance or other components due to water or weather damage which is the result of, but not limited to, improper chimney or venting installation.

• HHT’s liability under this warranty is limited to the replacement and repair of defective components or workmanship during the applicable period. HHT may fully discharge all of its obligations under such warranties by repairing the defective component(s) at HHT’s discretion. Shipping costs are not covered under this warranty.

• Some states do not allow exclusions or limitation of incidental or consequential damages, so those limitations may not apply to you. This warranty gives you speciﬁ c rights; you may also have other rights, which vary from state to state.

• EXCEPT TO THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE WARRANTY SPECIFIED ABOVE.

This Limited Warranty is effective on all HHT appliances sold after September 01, 2008 and supersedes any and all warranties currently in existence.

If warranty service is needed, you should contact your installing dealer. If the installing dealer is unable to provide necessary parts or components, contact the nearest authorized HHT dealer or supplier.

Page 2 of 2 4021-645A 09-01-08

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/0836

E. Contact Information

Quadra-Fire, a brand of Hearth & Home Technologies Inc.

20802 Kensington Boulevard, Lakeville, MN 55044

www.quadraﬁ re.com

Please contact your Quadra-Fire dealer with any questions or concerns.

For the location of your nearest Quadra-Fire dealer,

please visit www.quadraﬁ re.com.

- NOTES -

________________________________________________________________________________

CAUTION

DO NOT DISCARD THIS MANUAL

• Important operating and maintenance instructions included.

• Read, understand and follow these instructions for safe installation and operation.

• Leave this manual with party responsible for use and operation.

This product may be covered by one or more of the following patents: (United States) 4593510, 4686807, 4766876, 4793322, 4811534, 5000162, 5016609, 5076254, 51 13843, 5191877, 5218953, 5263471, 5328356, 5341794, 5347983, 5429495, 5452708, 5542407, 5601073, 5613487, 5647340, 5688568, 5762062, 5775408, 5890485, 5931661, 5941237, 5947112, 5996575, 6006743, 6019099, 6048195, 6053165, 6145502, 6170481, 6237588, 6296474, 6374822, 6413079, 6439226, 6484712, 6543698, 6550687, 6601579, 6672860, 6688302B2, 6715724B2, 6729551, 6736133, 6748940, 6748942, 6769426, 6774802, 6796302, 6840261, 6848441, 6863064, 6866205, 6869278, 6875012, 6880275, 6908039, 6919884, D320652, D445174, D462436; (Canada) 1297749, 2195264, 2225408, 2313972; (Australia) 780250, 780403, 1418504 or other U.S. and foreign patents pending.

Quadra-Fire • Columbia Bay Insert • 7002-109 Rev. H • 10/08 37

Quadra-Fire Vented Gas Fireplace Heater COLBAY-INS, COLBAY-INS Owner's Manual & Installation

Specifications and Main Features

Frequently Asked Questions

User Manual
