Quad Pa-one+ User Manual
PA-ONE
+
PA-ONE+ Manual-181031.indd 1 2018/10/31 14:15:35
CAUTION!
IMPORTANT SAFETY INFORMATION
RISK OF ELECTRIC SHOCK
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK)
REFER SERVICING TO QUALIFIED PERSONNEL
ADVERTISSEMENT: RISQUE DE CHOC ELECTRIQUE-
This symbol indicates that there are important
operating and maintenance instructions in the
literature accompanying this unit.
This symbol indicates that dangerous voltage
constituting a risk of electric shock is present
within this unit.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water. Clean only with dry
cloth.
Do not block any ventilation openings.
Install in accordance with the manufacturer's instructions.
Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
Do not defeat the safety purpose of the polarized or
grounding plug.
A polarized plug has two blades with one wider than
the other. A grounding plug has two blades and a third
grounding prong. The wider blade or the third prong is
provided for your safety. If the provided plug does not fit
into your outlet, consult an electrician for replacement of the
obsolete outlet.
Protect the power cord from being walked on or pinched
particularly at the plugs, convenience receptacles, and at the
point where they exit from the apparatus.
Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or sold
with the apparatus. When a cart or rack is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
Unplug the apparatus during lightning storms or when
unused for long periods of time.
Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
CAUTION: These servicing instructions are for use by
qualified service personnel only. To reduce the risk of
electric shock, do not perform any servicing other than
that contained in the operating instructions unless you are
qualified to do so.
Do not install this equipment in confined or built-in spaces
such as a bookcase or similar unit, and keep well ventilated
DO NOT OPEN
NO USER-REMOVEABLE PARTS INSIDE
NE PAS OUVRIR
in open space. The ventilation should not be impeded
by covering the ventilation openings with items such as
newspaper, table-cloths, curtains etc.
WARNING: Only use attachments/accessories specified or
provided by the manufacturer (such as the exclusive supply
adapter, battery etc.).
WARNING: To reduce the risk of fire or electric shock, do
not expose this apparatus to rain or moisture. The apparatus
shall not be exposed to dripping or splashing and objects
filled with liquids, such as vases, shall not be placed on
apparatus. No naked flame sources, such as lighted
candles, should be placed on the apparatus.
WARNING: Terminals marked with symbol of “ ” may
hold voltage of sufficient magnitude to constitute a risk of
electric shock. The external wiring connected to the terminals
requires installation by qualified personnel or the use of
ready-made leads or cords.
WARNING: Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type.
WARNING: The battery (battery or batteries or battery pack)
shall not be exposed to excessive heat such as sunshine, fire
or the like.
WARNING: Excessive sound pressure from earphones and
headphones can cause hearing loss.
WARNING: Listening to music at high volume level and for
extended duration can damage one’s hearing. In order to
reduce the risk of damage to hearing, one should lower the
volume to a safe, comfortable level, and reduce the amount
of time listening at high level. Headsets should comply with
EN 50332-2 requirements (for GS certification).
WARNING: The mains plug is used as disconnect device;
the disconnect device shall remain readily operable. The
mains switch and circuit breakers are not provided with
the apparatus; The installation shall be carried out in
accordance with all applicable installation rules.
This equipment is a Class II or double insulated electrical
appliance. It has been designed in such a way that it does
not require a safety connection to electrical earth.
IMPORTANT NOTICE TO UK USERS
The appliance cord is terminated with a UK approved mains
plug fitted with a 5A fuse. If the fuse needs to be replaced,
an ASTA or BSI approved BS1362 fuse rated at 5A must be
used. If you need to change the mains plug, remove the fuse
and dispose of this plug safely immediately after cutting it
from the cord.
Connecting a Mains Plug
The wires in the mains lead are coloured in accordance with
the code: Blue: NEUTRAL; Brown: LIVE; Green and Yellow:
EARTH. As these colours may not correspond to the coloured
markings identifying the terminals in your plug, proceed as
follows:
The BLUE wire must be
connected to the terminals
marked with the letter N or
coloured BLUE or BLACK.
The BROWN wire must be
connected to the terminals
marked with the letter L or
coloured BROWN or RED.
BLUE
(NEUTRAL)
FUSE
BROWN
(LIVE)
PA-ONE+ Manual-181031.indd 2 2018/10/31 14:15:35
CONTENTS
IMPORTANT SAFETY INFORMATION ....................................................................... Inside Front Cover
USER GUIDE ...................................................................................................................................... 1
CONTROLS AND CONNECTIONS .................................................................................................... 2
SETUP ................................................................................................................................................ 3
CAUTION ........................................................................................................................................ 3
USING THE USB SOURCE ................................................................................................................ 3
TECHNICAL FEATURES .................................................................................................................... 4
FURTHER ADVICE ............................................................................................................................. 4
SPECIFICATIONS ............................................................................................................................... 5
INTERNATIONAL SERVICE CENTRE ADDRESS ................................................................................... 5
PA-ONE+ Manual-181031.indd 1 2018/10/31 14:15:35
USER GUIDE
INTRODUCTION
The QUAD PA-ONE+ is designed for the music lover. We make no exaggerated performance claims and are content to let
the results speak for themselves. Thank you for purchasing this QUAD equipment. We hope that it will bring you many years of
listening pleasure, and that, like its illustrious predecessor, it will be a treasured possession for you and for future generations of
music lovers.
PRELIMINARIES
The QUAD PA-ONE+ carton contains:
• One QUAD PA-ONE+
• One IEC mains lead fitted with an appropriate mains connector
• Instruction Manual and Warranty Registration form
• One set of packing materials
Consult the dealer from whom you purchased the equipment if any item is missing. Please retain the packing materials for future
transportation of the product.
Please read this manual in full before installing your new amplifier and retain the manual and your purchase receipt for future
reference.
MAINS SUPPLY
The mains operating voltage of the unit is indicated on the rating plate attached to the unit. If this voltage does not match the
mains voltage in your area, consult your QUAD dealer about converting the unit. The fuse rating should be:
220-240V T500mA 20mm
100-120V T1A 20mm
1
