User manual
Waterproof Sports Camera 4K Ultra HD
50221
Warning
1. Keep it safe from falling and dropping
2. Keep it distance from any strong magnetic interference objects like electrical machine to avoid
strong radio waves that might be damaging the product and affect the sound or image quality.
3. Don’t expose the product directly to high temperatures and strong Sunlight
4. We recommend using high quality Micro SD Card for the best results.
5. Don’t place your Micro SD card near strong magnetic objects to avoid data error.
6. In case of overheating, unwanted smoke or unpleasant smell from the device, unplug it immediately from the power outlet to prevent hazardous fire.
7. Keep it safety from children while on charging.
8. Stored the device in a cool, dry and dust free location.
Product features
With a water proof casing, allowing you to film 30 meters under water scene.
HD screen display for convenient videos and image playback.
Detachable battery for easy replacement and help extend
product lifespan
Record videos while charging
HD 16 Megapixel wide angle lens
HDMI Output
WebCamera
Supports SD card memory expandable up to 64GB(Maximum)
Supports multiple video recording formats:4K/2K/1080P/720P/ WVGA
Supports MOV recording format
Supports multiple photo shooting modes: Single shot &Snapper
Video encryption enabled
Super lightweight, small in size
Product structure
1.Power/Mode 2.UP/Wi-Fi 3.Down 4.Lens
5.TF card slot 6.USB slot 7.HDMI 8.OK
9.Battery Door 10.Battery Door Latch
Getting started
1. To power ON: Press the Power/Mode Button.
2. To power OFF: Press and hold the Power/Mode Button.
Overview
Turn camera ON and repeatedly press the Power/Mode Button to cycle through camera modes and
settings.The modes will appear in following order:
Settings
Press the OK Button to enter the settings menu. Repeatedly press the Power/Mode Button to cycle
through options and press the OK Button to select desired option.
Record Video
Capture a single photo
Time-lapse video
Playback Video and photo
Adjust camera settings
Video setting
Video Resolution
4K@30fps/2.7K@30 fps /1080P@60 fps /1080P@30 fps /720P@120 fps
Video sound
On/Off
Time-lapse
Off/0.5s/1s/2s/5s/10s/30s/60s
Loop Recording
Off/2min/3 min /5 min
Slow motion
1080P@60 fps /720P@120 fps
Pixel set
16M/12M/8M /5M/2M
Timed
3s/5s/10s/20s/Off
Auto
3S/10S/15S/20S/30S/OFF
Drama shot
3P/S、 5P/S、 10P/S、 20P/S、 OFF
Exposure
-2---+2
White balance
Auto/Sunny/Cloudy/Incandescent
Image Rotation
On/Off
WI-FI
On/Off
Light source
Auto/50Hz/60Hz
LED indicator
On/Off
Auto
10S/20S/30S/Off
Auto shutdown
1min/3min/5min/Off
Time
On/Off
Settings
Video mode
1. To record video,Verify the camera is in Video mode
2. If the Video icon on screen is showing, press the OK key to start video, at the same time
also has“a red icon” flashing.
3. Click the OK button again to stop the video, also the red icon disappear.
Picture mode
1. To take picture,Verify the camera is in picture mode.
2. If the picture icon on screen is showing, press the OK key to take pictures.
Language
English/German/French/Spanish/Italian/Portuguese/traditional/Chinese
simplified/Chinese/Japanese/Russian
Date-time
2015/01/01 12:00:00
Format
Confirmation/cancel
Reset
Confirmation/cancel
Micro SD
4K@30fps /
1080P@60FPS
1080P@30fps
720P@60fps
32GB
120min
240min
320min
16GB
60min
120min
160min
Slow motion
1. To record slow motion video,Verify the camera is in slow motionmode.
2. If the slow motion Video icon on screen is showing, press the OK key to start video, at the
same time also has “a red icon” flashing
Time-lapse
1. Enter the setting menu, open this function, return to video mode.
2. If the slow motion Video icon on screen is showing, press the OK key to start video, at the
same time also has “a red icon”.
Playback
Playing back video and photos
1. verify the camera is in playback menu
2. press up or down button to select file,press OK button to playbackvideo
Battery
1. install and remove the battery
a) down upon battery cover can be open it.
b) according to the battery label plus or minus sign and the direction of the arrow, right put the
battery into the camera, until the installation in position.
c) take out battery, push away the battery cover can take out the battery
2. charge
a) connect the computer or the power adapter can be recharged.
b) directly to the car charger can be recharged in the car.
c) can charge while video function.(inside the function table Settings required to open the car
mode)
d) power off can be charged.
Camera Wi-Fi App
1. Download the APP client and install it to the smart phone, which displays the “XDV” application
icon after installation. Apple WLAN,direct search “XDV”, click install. After the installation of the
mobile phone interface will appear a APP application icon. Click to enter the APP "XDV" interface.
2. The open WI-FI function
a) Select the "WI-FI" menu, press "OK" button to enter, select "open",the screen will show the
WI-FI icon,
SSID:********,
PWA2:********
b) click the UP button to return. At this time to open the phone to set the WI-FI function, to find
a new set of WI-FI name of the network,
c) The connection after entering the new WI-FI password and confirm the connection, the
connection after the success of the LCD on the Connected/ display MAC:************.
d) At this time to open the phone has been installed “XDV” APP client, and search to add the
camera ID code, after the completion of the camera and video operations can be perfor-
med.
Parameter
nTec s.c. Declares that 50221 Waterproof Sports Camera complies with the essential requirements and other relevant provisions of Directive 1999/5 / EC.
Dispose of according to local regulations..
Producent/Producer: WEEE: E0012594WBW
nTec www.ntec.eu
ul. Chorzowska 44B www.qoltec.com
44-100 Gliwice
Poland
LCD
2.0LTPS
LENS
170 degree A + high resolution wide Angle lens
Language
English/German/French/Spanish/Italian/Po
Chinese,simplified Chinese/Japanese/Russia
Video
4K 30fps 2K 30fps
1080P (1920*1080) 60fps
720P (1280*720) 120fps
Video format
MOV
Compression format
H.264
16M/14M/12M/8M/5M
Memory
Micro SD UPTO 64GB
Picture mode
Single/timer / （2S/5S/10s） / Continuous shot
Light source frequency
50Hz/60Hz
USB
USB2.0
Power
5V 1A
Battery
900mAh
Video time
1080P/ 90min
Charge time
About 3 hours
System
Windows XP/Vistaor Above/Win7/Mac os
