User manual
Car recorder Full HD
(50206)
User manual
Product descripction
1) Up 2) Menu 3) Down
4) USB input 5) Camera 6) Speaker
7) OK 8) Mode 9) Power
10) Display 11) Card slot 12) Infrared (IR)
13) Rail handle 14) Reset 15) Microphone
Function:
1) Up
Selecting menu.
Short press this button during recording, let you use “zoom +” features.
2) Menu
Pressing this button will show options.
3) Down
Chose menu option.
Short press this button during recording, it let you use ”zoom -” features.
4) USB input
Connect device to PC for exchanging files.
Connect device to AC charger to load batteries.
5) Camera
Angle of vision – 120°.
6) Speaker
It allows you to listen recorded sound during registration and system sounds.
7) OK button
In record mode press this buttom, for start video recording or press it again for stop
recording.
In photo mode, press short this button to take a photo.
In menu it means recording.
8) Mode
Short press this button allows to switch between function (video, photo, recording).
SOS function: short press this button allows you to record current video while
recording.
9) ON/OFF
Hold to on / off device.
Short press while recording, will turn on infrared light.
10) Display
Preview
11) Card slot.
12) Infrared (IR)
It allows you to record video at night and in low light.
Short press "POWER" button will turn on infrared.
13) Handle mounting rail.
14) Reset
Restarting device.
15) Microphone
Special features description:
G-sensor
When the gravity acceleration reaches 6g (1g=9.80m/s), device saves video files
as secure.
Supports start and stop recording and automatic saving. When connected to car power.
Recording in loop without missing even one second.
SOS
Short press "M" button, forces to save the current video while recording.
Specifications recording / take photos
On / Off
Hold "POWER" button, to turn on device. Device display will show images and
information LEDs light.
To turn off device hold “POWER” button, device will turn off and LED will go off.
NOTE: Device will turn of automatic when battery levels drops. Device will show
message “low battery” and switch off.
Recording video
Short press "M" button will switch to recording mode. In the upper left corner there is an
icon informing us in which mode device currently is.
Short press "OK" button, will start recording. The red LED indicates that recording is in
progress.
Taking photo
Short press "M" button will take you to capture mode. In the upper left corner there is an
icon informing us in which mode device currently is. Short press "OK" button, will take a
photo. One blink of the display indicates that the photo was taken.
Playback video/photo
Short press "M" button, to switch to playback mode. In the upper left corner there is an
icon informing us in which mode device currently is. Use the up and down button to
browse files, to preview the selected track press "OK".
Menu
Double click "menu" button will open the settings.
USB mode
When you connect USB cable to your computer, press the "POWER". Recorder will
show two options to choose:
1: USB Drive
In this mode, you have access to video and photo files.
2: PC Camera
In this mode, you can use the device as webcam.
Battery description
Battery charge indicator：
Full charged Slightly charged Low charged Discharge
There are three ways of charging, in every of them lights up red LED will indicates
charging mode. Total charge time takes approximately 180 minutes. When battery will
be full charge,LED goes off.
1. The use standard AC charger.
2. Connect your device to your computer using a USB cable.
3. Using the car charger.
Coution: Device can only be use by car adapter 5V, otherwise it could be damaged.
Car adapter can only be connected to 12/14V jack.
Note: If device is not working properly, you should use reset button.
Troubleshooting:
Inability to recording and taking photo
Check if card has enough space or is not locked.
Automatic stop while recording
Use SDHC compatibile card.
Error appear during video recording or viewing photos.
Check if memory card is inserted correctly.
Unclear video
Check if display is clean. Clean camera leans.
Black image during video recording water or sky.
High-contarst scenery will affect the camera’s auto exposure function. We
recommended set EV function to improve settings.
Color is not perfect in cloudy day
Set camera white balance on automatic.
Unusual accident
Restart, by press short "RESET" button.
Specification
Attributes Camera HD, video recording HD
G-sensor Build-in (in case of accident video will be saved)
Display size 1.5”LTPS
Camera 120 A + Ultra high resolution and wide field of view
Language Russian, Japanese, French, Italian, German, Spanish,
English, Chinese (simplified), Chinese (traditional),
Korean, Polish
Video fomat AVI
Resolution Max 1080P
Color default
Loop Recording without missing even a second
Automatic on/ off Support automatic turn on/off
Internal storage 64 MB
Photo 5 million
Photo format JPEG
Memory card Max 32GB
Microphone Build-in
Speaker Build-in
Infrared Build-in
Video output Brak
Video format PAL/NTSC
Frequency 50HZ/60HZ
USB function 1:Disk
2:Camera
Charger 5V 800mA
Battery Build-in 240mAh
