STEP
1
IQ TEMP QUICK INSTALL GUIDE
CHOOSE
INSTALLATION
LOCATION
SPECIFICATIONS
SEE REVERSE FOR REMAINING STEPS
Features:
Low Temp and High Temp Warning
•
Low Temp alarm: Temperature drops below 40F,
restores when temperatures rises above 45F
•
High Temp alarm: Temperature rises above 100F,
restores when temperature drops below 95F
Sensor:
•
Cover tamper
•
Unique ID for each function
•
Temperature check every 5 minutes
•
Battery checked every hour
Batteries:
(2) -Panasonic CR2032
-Energizer CR2032
-Duracell DL2032
The IQ Temp is designed to alert you if temperatures drop below 40°F or rise above
100°F. This early warning may help you protect your valuables, pets and home from
extreme heat or cold in the event of a HVAC or thermostat failure.
Mounting Locations
Ideally suited for a wide range of applications including:
•
Bathrooms
•
Laundry Rooms
•
Basements
*NOTE: Avoid areas that may retain heat, such as furnace rooms or near hot water pipes
This is a quick guide for experienced installers only. Refer to http://dealers.qolsys.com (login required)
STEP
2
STEP
3
Document#: IQTEMP-QG-02-17
Revision#: 2/24/17
Issue Date: FEB 2017
Qolsys Product #: QS5515-840
Select “Freeze” as your sensor
type and customize settings as
desired
Click “Add”
REMOVE
BATTERY
TABS
APPLY
ADHESIVE
INSTALL IN
DESIRED
LOCATION
*NOTE: Sensor Type “Freeze” (Sensor Group 52) is used for both Low Temp sensors and High Temp sensors. You can
customize the Sensor Name to differentiate which one you are learning
STEP 4STEP
5
LEARN
INTO
PANEL
Place your panel in
“autolearn" mode
STEP
6A
STEP
6B
Open and close the case
to “tamper” the device
LEARN
AS LOW
TEMP
(40°F)
LEARN
AS HIGH
TEMP
(100°F)
Remove both of
the batteries
Hold the tamper
button while you
insert the batteries
TechSupport@Qolsys.com
Qolsys Inc. proprietary.
Reproduction without permission is not permitted.
FCC ID: 2ABBZ-RF-MDWS
IC: 11817A-RFMDWS
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference
that may cause undesired operation of the device.
Cet appareil est conforme avec Industrie Canada exempts de licence standard RSS (s). Son fonctionnement est soumis aux deux conditions suivantes: (1) cet appareil ne doit pas provoquer d'interférences et (2) cet appareil doit accepter toute
interférence, y compris celles pouvant causer un mauvais fonctionnement de l'appareil.
