Hardware Specification
TS-h2483XU-RP-E2236-128G
CPU Intel® Xeon® E-2236 6-core 3.4 GHz processor (burst up to 4.8 GHz)
CPU Architecture 64-bit x86
Floating Point Unit Yes
Encryption Engine Yes (AES-NI)
System Memory 128 GB UDIMM DDR4 ECC (4 x 32GB)
Maximum Memory 128 GB (4 x 32 GB)
Memory Slot 4 x Long-DIMM DDR4
Flash Memory 5GB (Dual boot OS protection)
Drive Bay 24 x 3.5-inch SATA 6Gb/s, 3Gb/s
Drive Compatibility 3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
Hot-swappable Yes
SSD Cache Acceleration
Support
Yes
Gigabit Ethernet Port
(RJ45)
4
10 Gigabit Ethernet Port 2 x 10GbE SFP+ SmartNIC port, 2 x 10GBase-T port
Wake on LAN (WOL) Yes
Jumbo Frame Yes
PCIe Slot 5
Slot 1: PCIe Gen 2 x4 (PCH)
Slot 2: PCIe Gen 3 x4 (CPU)
Slot 3: PCIe Gen 2 x4 (PCH)
Slot 4: PCIe Gen 3 x8 (CPU)
Slot 5: PCIe Gen 2 x4 (PCH)
USB 3.2 Gen 2 (10Gbps)
Port
2 x Type-C USB 3.2 Gen 2 5V/3A 10Gbps
4 x Type-A USB 3.2 Gen 2 5V/1A 10Gbps
Form Factor 4U Rackmount
LED Indicators HDD 1-24, Status, LAN, storage expansion port status
Buttons Power, Reset
Dimensions (HxWxD) 176.15 × 481.04 × 672.02 mm
Weight (Net) 20.67 kg
Weight (Gross) 28.56 kg
Operating temperature 0 - 40 °C (32°F - 104°F)
Relative Humidity 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit 800W(x2), 100-240V
Power Consumption:
Operating Mode, Typical
168.97 W
Fan System fan: 3 x 80mm, 12VDC
Sound Level 28.7 db(A)
System Warning Buzzer
Max. Number of
Concurrent Connections
(CIFS)
700
Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory
slot, use QNAP modules with identical specifications. Warning: Using unsupported modules may degrade performance, cause errors,
or prevent the operating system from starting.
* Sound Level Test Environment: Refer to ISO 7779; Maximum HDD loaded; Bystander Position; Average data from 1 meter in front
of operating NAS.
Designs and specifications are subject to change without notice.
