QNAP TS-863U Technical data
Quad-Core 2.0GHz
4 / 8 / 12-Bay Turbo NAS
High-speed 10GbE connectivity
and optimized encryption
performance
TS-463U
TS-463U-RP
TS-863U
TS-863U-RP
TS-1263U
TS-1263U-RP
Qswitch
Built-in 10GbE SFP+ Port
Designed for file management, sharing and backup of business data with snapshot support
Create multiple virtual machines to run various operating systems on the NAS with the Virtualization Station
Upgradable to dual-port 10GBASE-T or SFP+ by replacing the pre-installed SFP+ NIC
Hardware-accelerated encryption engine for efficient cryptographic performance exceeding 800MB/s
Storage expandable with a 12-bay UX-1200U-RP or an 8-bay UX-800U-RP expansion enclosure
TS-x63U-RP supports hot-swappable redundant power supplies to ensure maximum system uptime
Cost saving with 1GbE to 10GbE
network bridge functionality
4GB DDR3L
Max. 16GB RAM
SATA 6Gb/s
2.5"/3.5"
x 4
Quad
GbE Ports
10GbE
SFP+ Port
SFP+
10GbE
AES-NI
Storage
Expansion
Redundant/
Single PSU
Virtualization
Station
Container
Station
Power / 10GbE / Scalibility
• The power of 64-bit quad-core processor with AES-NI support
The TS-x63U is equipped with a fast 64-bit AMD® x86 quad-core 2.0 GHz processor with 4GB DDR3L-1600 RAM (upgradable to 16GB),
SATA 6Gb/s, and quad Gigabit LAN ports (expandable to 6 x GbE ports or 4 x GbE + 2 x 10GbE ports) for lightning-fast multi-tasking
performance with SSD cache support. The TS-x63U delivers up to 1037 MB/s read & write speeds with 1 x 10GbE port configuration.
The TS-x63U’s hardware-accelerated encryption engine provides unmatched encryption performance in its class, up to 822 MB/s
with AES-256 bit full NAS volume encryption, boosting system performance & security while ensuring the safety of sensitive business
data.
Throughput (1 x 10GbE) AES 256-bit Encrypted Transfer (1 x 10GbE)
1000
1037
750
500
MB/s
250
0
Download Upload Download Upload
TS-1263U-RP : Windows Download / Upload (10GB File)
443
1000
MB/s
822
750
500
250
0
334
• Built-in 10GbE connectivity
The TS-x63U series supports 10 Gigabit high-speed networks
with the included single-port SFP+10GbE network adapter in
addition to the default 4 x Gigabit Ethernet ports. The 10GbEready TS-x63U series delivers lightning-fast data throughput for
businesses that demand higher bandwidth for virtualization and
fast backup/restoration for an ever-growing amount of data.
Users can also upgrade to a two-port 10GBASE-T or SFP+ NIC by
replacing the pre-installed SFP+ NIC.
Tested in QNAP Labs. Figures may vary by environment.
Test Environment
NAS:
OS: QTS 4.2.0
Volume type: RAID 6; 12 x Intel DC S3500 SSDSC2BB240G4 SSD
Network environment: direct connection between NAS and PC, QNAP LAN-10G1SR-U NIC
Client PCs:
Intel® Core™ i7-4770 3.40GHz CPU; DDR3 1600Hz 16GB; WD 1TB WD10EZEX; QNAP NIC;
®
7 Professional 64bit SP1
Windows
• Bridge between 1 & 10GbE to maximize
network accessibility with no extra cost
With Qswitch* the NAS supports bridging 1 Gigabit and 10
Gigabit networks naturally like a network switch. Users can
connect 1GbE devices to the NAS to attain the 10GbE working
environment for data transmission without buying an expensive
1/10Gbps Ethernet switch. The NAS assists in saving money on
10GbE network deployment and maximizes your flexibility and
bandwidth.
Server Room
1 x 10GbE SFP + LAN port
10GbE Switch
Office
Save over
US$300!
10GbE
*Available with QTS 4.2.1
GbE
10GbE
Qswitch
10GbE
DHCP server
Secured and independent
surveillance solutions
• Capacity expansion or backup via QNAP 12-bay UX-1200U-RP or 8-bay UX-800U-RP
The TS-x63U offers a high performance yet affordable storage solution to fulfill the needs of businesses for archiving rapidly-growing
data & large files. The TS-x63U supports capacity expansion by connecting a QNAP expansion enclosure. 8 Bay UX-800U-RP or 12 Bay
UX-1200U-RP with the QNAP scale-up solution, the raw storage capacity can be expanded on demand, making the TS-x63U an ideal file
center for storage-intensive business applications such as video surveillance, data archiving, TV broadcast storage, and more.
High speed USB 3.0 connection
TS-x63U-RP
Note: To expand storage space with an UX expansion unit, please create a separate static volume or storage pool on the UX expansion unit.
12 Bay UX-1200U-RP or 8 Bay UX-800U-RP
• High reliability design ensuring business continuity
The NAS is designed to provide 24/7 operations and services. The support for comprehensive RAID configurations and hot-swapping
allow for replacing hard drives without service interruption. QNAP’s advanced RAID recovery technology also helps if any healthy drives
are mistakenly removed from a degraded RAID volume. The system can be recovered by reinserting the wrongly removed hard drives so
the data can still be accessed. The NAS delivers high reliability and efficiency with a 4 X GbE and one 10GbE LAN ports design for multiple
port-trunking modes including fail-over support. The TS-x63U-RP also features a hot-swappable redundant power supply to ensure
maximum system uptime.
Quad GbE Ports
• QTS 4.2 - Simple and efficient NAS OS
Thanks to the intuitive user interface of QTS 4.2, your NAS
experience is smarter, smoother and more spectacular. Its modern
flat design streamlines loading times, and the intelligent desktop
allows you to quickly find desired functions, create desktop shortcuts
or group shortcuts, monitor important system information on a realtime basis, and multitask by opening multiple application windows
at the same time, bringing greater operating efficiency.
10GbE LAN Port
Redundant PSU Option
• Cross-platform file sharing & centralized
data storage
The TS-x63U supports SMB/CIFS, AFP, and NFS protocols for file
sharing across Windows®, Mac, Linux/UNIX networks. Data, logs
and ISO images of CDs and DVDs can be centrally stored on the
TS-x63U and protected by an integrated antivirus solution. The
Windows AD and LDAP services enable system administrators
to configure user permissions by using an existing Windows
AD server, LDAP server or built-in LDAP service. The TS-x63U
supports SAMBA v4 and can act as a Windows domain controller
to manage privilege settings.
