Python 1000ESP User Guide
Model 1000 ESP
Owner's Guide
i
©
1999 Directed Electronics, Inc.
Limited Lifetime
Consumer Warranty
Directed Electronics, Inc. ("DEI®") promises to the original purchaser to repair or
replace with a comparable reconditioned model any DEI unit (hereafter the "unit"),
excluding without limitation the siren, the remote transmitters, the associated
sensors and accessories, which proves to be defective in workmanship or material
under reasonable use during the lifetime of the vehicle provided the following conditions are met: the unit was professionally installed and serviced by an authorized
DEI dealer; the unit will be professionally reinstalled in the vehicle in which it was
originally installed by an authorized DEI dealer; and the unit is returned to DEI, shipping prepaid with a legible copy of the bill of sale or other dated proof of purchase
bearing the following information: consumer's name, telephone number and address;
the authorized dealers name, telephone number and address; complete product
description, including accessories; the year, make and model of the vehicle; vehicle
license number and vehicle identification number. All components other than the
unit, including without limitation the siren, the remote transmitters and the associated sensors and accessories, carry a one-year warranty from the date of purchase of
the same. This warranty is non-transferable and is automatically void if: the original
purchaser has not completed the warranty card and mailed it within ten (10) days of
the date of purchase to the address listed on the card; the unit's date code or serial
number is defaced, missing or altered; the unit has been modified or used in a
manner contrary to its intended purpose; the unit has been damaged by accident,
unreasonable use, neglect, improper service, installation or other causes not arising
out of defects in materials or construction. The warranty does not cover damage to
the unit caused by installation or removal of the unit. DEI, in its sole discretion, will
determine what constitutes excessive damage and may refuse the return of any unit
with excessive damage. TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WAR-
RANTIES, INCLUDING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED
WARRANTY, WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE
AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY, ARE
EXPRESSLY EXCLUDED; AND DEI NEITHER ASSUMES NOR AUTHORIZES ANY PERSON
OR ENTITY TO ASSUME FOR IT ANY DUTY, OBLIGATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS. DEI DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY
FOR ANY AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEALERS
OR INSTALLERS. DEI SECURITY SYSTEMS, INCLUDING THIS UNIT, ARE DETERRENTS
AGAINST POSSIBLE THEFT. DEI IS NOT OFFERING A GUARANTEE OR INSURANCE
AGAINST VANDALISM, DAMAGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS; AND HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER,
INCLUDING WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR VAN-
ii
©
1999 Directed Electronics, Inc.
DALISM. THIS WARRANTY DOES NOT COVER LABOR COSTS FOR MAINTENANCE,
REMOVAL OR REINSTALLATION OF THE UNIT OR ANY CONSEQUENTIAL DAMAGES OF
ANY KIND. IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DEI OR ITS SUBSIDIARY, THE PROPER VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF
CALIFORNIA. CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL
APPLY AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY CLAIM
AGAINST DEI SHALL BE STRICTLY LIMITED TO THE AUTHORIZED DEI DEALER'S PURCHASE PRICE OF THE UNIT. DEI SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES
WHATSOEVER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES,
INCIDENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME, LOSS OF EARNINGS,
COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFACTURER DOES OFFER A LIMITED WARRANTY TO
REPLACE OR REPAIR THE CONTROL MODULE AS DESCRIBED ABOVE. Some states do
not allow limitations on how long an implied warranty will last or the exclusion or
limitation of incidental or consequential damages. This warranty gives you specific
legal rights and you may also have other rights that vary from State to State.
This product may be covered by a Guaranteed Protection Plan ("GPP"). See your
authorized DEI dealer for details of the plan or call DEI Customer Service at 1-800876-0800. DEI security systems, including this unit, are deterrents against possible
theft. DEI is not offering a guarantee or insurance against vandalism, damage or theft
of the automobile, its parts or contents; and hereby expressly disclaims any liability
whatsoever, including without limitation, liability for theft, damage and/or vandalism.
DEI does not and has not authorized any person or entity to create for it any other
obligation, promise, duty or obligation in connection with this security system.
Make sure you have all of the following information from your dealer:
A clear copy of the sales receipt, showing the following:
■ Date of purchase
■ Your full name and address
■ Authorized dealer's company name and address
■ Type of alarm installed
■ Year, make, model and color of the automobile
■ Automobile license number
■ Vehicle identification number
■ All security options installed on automobile
■ Installation receipts
1
©
1999 Directed Electronics, Inc.
Table of Contents
Limited Lifetime Consumer Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
Standard Transmitter Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
What Is Included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Important Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
System Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Your Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
FCC/ID Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Transmitter Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Standard Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Using Your System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Multi-Level Security Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Arming While Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
High Security Disarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Disarming Without a Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Silent Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Panic Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Valet
®
Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Remote Valet
®
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Nuisance Prevention Circuitry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Arming Diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Disarming Diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Table of Zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Code-Hopping
™
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
High Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Owner Recognition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Rapid Resume Logic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Power Saver Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Programming Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Installation Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Vehicle Recovery System (VRS®) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Arming the VRS
®
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
VRS
®
Triggered Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Disarming the VRS
®
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Glossary Of Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Security & Convenience Expansions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Quick Reference Guide (Removable) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
2
©
1999 Directed Electronics, Inc.
Standard Transmitter
Configuration
controls the Arm function.
controls the Disarm function.
controls Silent Mode™and an Auxiliary Output.
controls the Panic function.
and pressed simultaneously control an Auxiliary Output.
3
©
1999 Directed Electronics, Inc.
What is Included
■ 3-Channel Receiver
■ A pair of four-button transmitters
■ A Stinger
®
Doubleguard®dual-output shock sensor
■ The Revenger
®
Soft Chirp®six-tone programmable siren
■ The red status LED indicator light
■ A push-button Valet
®
switch
■ Your warranty card
■ Failsafe
®
Starter Kill ready circuitry (may require additional
labor)
Important Information
Congratulations on the purchase of your state-of-the-art vehicle
security system. This system has been designed to provide years of
trouble-free operation. Due to the complexity of this system, it
must be installed by an authorized dealer only. Installation of this
product by anyone other than an authorized dealer voids the war-
ranty. All dealers are provided with preprinted dealer certificates to
verify that they are authorized.
This owner’s guide should help you to get the most out of your
system. Please take the time to read it prior to using the system.
4
©
1999 Directed Electronics, Inc.
The system requires no specific maintenance. Your remote control
is powered by a small, lightweight 3-volt lithium battery that will
last approximately one year under normal use. When the battery
weakens, operating range will be reduced and the LED on the
remote will dim.
Your warranty card must be returned and the bar code serial
number must not be removed. If the warranty card is not returned,
you do not have a warranty. It is also necessary to keep your proof
of purchase, which reflects that the product was installed by an
authorized dealer. Make sure that you receive the warranty card
from your dealer.
This device complies with Part 15 of FCC rules. Operation is subject
to the following two conditions: (1) This device may not cause
harmful interference, and (2) This device must accept any interfer-
ence received, including interference that may cause undesired
operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate this device.
FCC/ID Notice
Your Warranty
System Maintenance
5
©
1999 Directed Electronics, Inc.
Transmitter Functions
The receiver uses a computer-based Learn Routine to learn the
transmitter buttons. This makes it possible to assign any transmit-
ter button to any receiver function. The transmitter initially comes
programmed with Standard Configuration, but may also be
customized by an authorized dealer. The buttons in all of the
instructions in this manual correspond to a Standard Configuration
transmitter.
Button
The arming function is controlled by pressing .
Button
The disarming function is controlled by pressing .
Button
Silent Mode
™
and an optional auxiliary function are controlled by
. (Silent Mode works by pressing for less than one
second before arming or disarming. An optional auxiliary function,
such as trunk release, can be controlled by pressing for 1.5
seconds.)
The auxiliary output controls _____________________________.
Button
The panic feature is controlled by pressing for 1 second.
Standard Configuration
6
©
1999 Directed Electronics, Inc.
and Buttons
An optional auxiliary convenience or expansion function that you
have added to your system can be activated by pressing and
simultaneously.
The auxiliary output controls _____________________________.
Using Your System
The buttons used in the instructions in this manual correspond to
the standard configuration. Remember, this is not the only way
your transmitter may be set up. It can be custom configured to
meet your needs.
You can activate, or arm, the system by pressing on your trans-
mitter for one second. When the system arms, you will hear a short
siren sound, or chirp, and the parking lights will flash once. If the
vehicle’s power door locks have been connected to the system, the
doors will lock.
While the system is armed, the status LED will flash approximately
once per second, indicating that the system is actively protecting
your vehicle. If you hear a second chirp after arming, and see the
status LED flashing in groups, refer to the Diagnostics section of
this guide. This extra chirp is called Bypass Notification.
Arming
7
©
1999 Directed Electronics, Inc.
The system also can be programmed to arm itself automatically
(called passive arming). If the system is programmed for passive
arming, it will automatically arm 30 seconds after the ignition is
turned off and the system "sees" you leave the vehicle by opening
and closing a door. Whenever the system is in its 30-second
passive-arming countdown, the status LED will flash twice as fast
as it does when the system is armed. The siren will chirp one time
20 seconds after the last door has been closed. The system is not
actually armed at that point. The system arms and the doors lock
(if connected and programmed for passive locking) at the 30
second mark, but the siren will not chirp. The early chirp provides
you with a 10-second warning prior to arming.
NOTE: If any protected entry point (such as a door or a switch-protected
trunk or hood) is open, the system will not passively arm (unless forced
passive arming is programmed on.) See Programming Options section of
this guide. Additionally, each time a sensor is triggered during the arming
countdown, the 30-second countdown starts over.
When armed, your vehicle is protected as follows:
■ Light impacts will trigger the Warn Away
®
signal. When trig-
gered, the siren will chirp and the parking lights will flash for
a few seconds.
■ Heavy impacts will trigger the system. The triggered sequence is
between 1-180 seconds of constant siren and flashing parking
lights.
■ If a door is opened, the system will immediately start chirp-
ing the siren and flashing the parking lights. Three seconds
later, the siren output changes to a continuous blast. This
progressive response gives you time to disarm the system with
8
©
1999 Directed Electronics, Inc.
your transmitter if you inadvertently open the door while the
system is armed, while still providing an instant response
(even if the door is immediately closed).
■ Turning on the ignition key will trip the same two-stage
response as opening a door.
■ The optional starter kill prevents the vehicle’s starter from
cranking.
Multi-Level Security Arming allows you to select which of the
security system's inputs or sensors will be active and which will be
bypassed at the time that the system is armed. (See Table of Zones
section.) Pressing again within five seconds of arming the
security system will activate the Multi-Level Security Arming
feature. Each time is pressed again, a different security level
is selected. The different security levels can be selected as follows:
■ Pressing one time: The siren chirps once. The system is
armed.
■ Pressing a second time within five seconds: The siren
chirps twice followed by a long chirp. Zone Two is now
bypassed.
■ Pressing a third time within five seconds: The siren chirps
three times followed by a long chirp. Zone Four is now
bypassed.
■ Pressing a fourth time within five seconds: The siren
chirps four times followed by a long chirp. Zones Two and
Four are now bypassed.
Multi-Level Security Arming
Loading...
