Pyronix Paragon Plus User Instructions

RDOC147A issue5

USER INSTRUCTIONS

INSTALLATION COMPANY:

TEL:

ADDRESS:

CONTACT:

PYRONIX LIMITED AUG 1996

®

®

Pyronix Ltd

Unit 2 Braithwell Way

Hellaby Industrial Estate

Hellaby

Rotherham

South Yorkshire

England

S66 8QY

Tel: [phone]

Fax: [phone]

19

RDOC147Missue3

3

18

CONTENTS

1. INTRODUCTION 3

2. ACCESS LEVELS 4

3. FEATURES 4

4. FUNCTIONAL DESCRIPTION 5

5. ZONES 6

6. CONTROLS AND FUNCTIONS 7

7. LIMITED USER FACILITIES 8

8. MASTER USER FACILITIES 10

9. TROUBLESHOOTING 12

QUICK REFERENCE GUIDES:

LIMITED USER FUNCTIONS. 15
MASTER FUNCTIONS. 16

1 INTRODUCTION

The Paragon Plus is a full featured intruder alarm control panel, based around a
microprocessor with 6 fully programmable zones and 3 dedicated '24-hour' zones (Fire
alarm, Personal Attack alarm and a System-Tamper alarm.). It is operated via either a
16-key onboard keypad or up to 5 additional remote keypads (Paragon RKPs) situated
at convenient points around the premises. Each keypad has an arrangement of 8 LEDs
to show the status of the system, and a 7-segment display to show programming data
and events held in the event-log memory.

All features are fully programmable and there are three levels of access to the system.
These are:

Limited User, Master user & Engineer

The Limited User gives access to the basic functions needed for everyday setting and
unsetting of the system.

The Master User level gives access to all setting and unsetting faciliities, but also
allows the changing of code numbers and testing of the system.

The Engineer level gives total access to the system including the ability to reconfigure
the system and reset the system's event-log memory.
(See 'Access Levels' below).

RDOC147Bissue3
