Pyramid Technologies TimeTrax Mobile User Manual

Time and Attendance System

SERIAL / USB QUICK START GUIDE

PYRAMID TIMETRAX MOBILE SERIAL QUICK START GUIDE

QUICK START GUIDE

Pyramid TimeTrax Mobile

SERIAL / USB MODEL

SOFTWARE MUST BE FULLY INSTALLED PRIOR

TO CONNECTING ANY TERMINAL CABLES

MINIMUM SYSTEM

WHAT’S IN THE BOX?

• Pyramid TimeTrax time recorder

• AC Power supply

• TimeTrax Software CD

• Quick Start Guide

• 7’ communication cable with
RJ45 connectors on both ends

• Diagnostic (loop-back) plug –
DO NOT DISCARD –

Save for future use.

• RJ45 to 9-pin (DB9) serial port
adapter

• USB interface with standard
RS232 adapter

• Employee Swipe Cards

REQUIREMENTS

• PC with a Pentium® class or
faster processor

• 128 megabytes of RAM

• Either: 9-pin (DB9) serial port or
USB port

• 1 gigabyte of free space on the
system’s hard drive

• Windows® XP, 2000, NT or Vista

• Printer (if hard copy reports are
desired)

CUSTOMER SERVICE PHONE NUMBER

[phone]

NEED TO PLACE AN ORDER?

For cable extensions and other supplies,

call Pyramid Technologies, LLC at:

[phone]

©2009 Pyramid Technologies, LLC. All rights reserved.

PYRAMID TIMETRAX MOBILE SERIAL QUICK START GUIDE

INSTALLING THE SOFTWARE

NOTE: Prior to installing the software, it is recommended that you disable
all anti-virus and firewall software so it does not interfere with the
installation. It can be turned back on immediately after the installation.

Place the Pyramid TimeTrax Software
CD into your PC. The software will
AUTORUN. You will then see the below
setup screens. Follow the onscreen
instructions.

Click NEXT to continue

Accept licensing
agreement and click
NEXT to continue

Click NEXT to continue

Enter a User Name and
Organization (optional)
and click NEXT to
continue

Click INSTALL to begin
installation
