Page 1
OWNER’S MANUAL
Read and understand this entire manual before using!
For assistance contact Pyramat. DO NOT RETURN TO STORE.
Item Numbers:
10174440 blue
10174461 pink
Page 2
WARNING: The Pyramat G-Flex is intended for indoor use only. TO REDUCE THE RISK OF FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
• Do not expose to direct sunlight or extreme temperatures.
• Adult supervision is required for set-up.
• Excessive use of audio equipment at high volume may lead to hearing loss. Listen responsibly and use
common sense.
• Do not mix old and new batteries. Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium)
batteries.
• Children under 13 should not use this product without parental supervision.
• DO NOT wash or soak the G-Flex with water. If cover becomes wet, remove batteries immediately and do not use
until totally dry.
The G-Flex is compatible with:
• All gaming consoles (including Xbox 360 and Playstation 3)
• MP3 players
• TVs, DVDs, VCRs
• Portable gaming devices (including Nintendo DS, Nintendo DS Lite, and PSP)
SAFETY WARNINGS
Safety Warnings ............................................................ 1
Before You Begin ........................................................... 2
Features ......................................................................... 2
Set-Up ............................................................................ 3
Connection Methods ................................................ 3 - 4
Troubleshooting Guide ................................................... 5
Warranty ........................................................................ 6
1
Need Help? Visit our website at www.pyramat.com, send an e-mail to [email protected]
or call toll-free at 877-591-1012.
CONTENTS
Congratulations on the purchase of your Pyramat G-Flex Game Booster. The G-Flex is a comfortable, rockable chair
that delivers a powerful audio experience designed to intensify your enjoyment of games, movies, music and more.
To ensure the best results, please read this manual completely before operating your G-Flex, and retain it for future
reference.
Page 3
Remove the G-Flex from the box. Check to make sure you have all the parts shown below and that all items are in good
condition.
BEFORE YOU BEGIN
2
11 ft. red and white
RCA audio cable
3 ft. RCA to mini audio cable
2.5 mm mini
plug adapter
3.5 mm mini plug
to RCA plug adapter
(2) RCA audio cable
extenders
FEATURES
Page 4
Page 5
Page 6
5
Unable to hear sound.
Unable to connect to the
gaming console.
Sound only plays from one
speaker.
No sound will play from the
G-Flex.
Missing or broken cables or
mini adapters.
Problem Possible Cause Solution
The RCA audio cables are not
connected properly.
The batteries are old or not
installed properly.
Cables are incorrectly connected.
Your video game console has a
coaxial cable instead of an RCA
audio cable.
RCA cables are incorrectly
connected.
Audio/video device has a single
MONO audio output (a common
problem when connecting to an
older TV or VCR).
RCA audio cables are incorrectly
connected.
Check the connection on your audio/video device. The RCA cables should be
connected to the AUDIO OUTPUT jacks. Check the connection on your rocker.
The RCA cables (red and white) must be in the input jacks.
Check to make sure the batteries are working. The power light on the control
panel should be on when batteries are installed correctly and have a full
charge.
Check that the console’s RCA audio cables are connected to the G-Flex’s RCA
audio cables (red to red and white to white).
Check that the G-Flex RCA audio cables (red and white) are connected to the
AUDIO INPUT jacks on the rocker.
Check that the console’s RCA video cable (usually yellow) is connected to the
input jack on the TV.
If your video game console has an RCA audio cable, then connect the RCA
audio cable extenders to the red and white audio cables from the video game
console. Connect the supplied RCA audio cable to the video game console’s
red and white audio cables and plug into the input jacks on the G-Flex.
Use the instructions provided by the video game console’s manufacturer to
hook up the video game console to an intermediary device (such as a TV,
DVD, VCR, satellite receiver, etc.). Your intermediary device must have
both a coaxial input jack (the standard jack for cable TV) and an RCA audio
output jack.
Purchase an RCA replacement cable directly from the console manufacturer.
Check that all RCA audio connections are correct – red to red, white to white.
If your audio source is mono only, as found mainly on older model TVs and
VCRs, an RCA “Y” adaptor (1 male to 2 male, not included) is needed to send
the signal to both speakers. Please note: the use of this type of adapter will
not produce a true stereo sound. For optimal performance, it is recommended
that you connect your G-Flex to stereo outputs only.
RCA audio cables (red and white) must be plugged into AUDIO OUTPUT jacks
in the source device (TV, VCR, etc.). If you are plugging the cables into the
jacks in the front of your TV, these are most likely AUDIO INPUT jacks.
Replace items immediately. Replacement cables and mini adapters can be
purchased at your local audio accessory dealer.
Need Help? Visit our website at www.pyramat.com, send an e-mail to [email protected]
or call toll-free at 877-591-1012.
TROUBLESHOOTING GUIDE
Page 7
6
WARRANTY
Pyramat warranties this product and any included
accessories against defects in material and
workmanship for a period of 90 days from the date of
first consumer purchase. This warranty is enforceable
only by the original purchaser. ALL DAMAGED OR
MISSING PARTS MUST BE REPORTED WITHIN 14
DAYS OF PURCHASE.
This warranty covers all defects in materials and
workmanship, but DOES NOT COVER the following:
1. Damage, deterioration or malfunction resulting from:
a. Acts of God, accident, misuse, abuse, negligence,
improper installation, maintenance or operation, or
failure to follow the instructions contained in this
manual.
b. Any shipment of the product (claims must be
presented to the carrier).
c. Repair, attempted repair or modification by anyone
other than the Pyramat Service Center.
2. Any unit which has been altered or on which the
serial number has been defaced, modified or removed.
3. Any unit used for industrial or commercial purposes.
4. Products sold AS IS or WITH ALL FAULTS, or
consumables (such as fuses or batteries).
5. Customer installation, set-up, adjustments or signal
reception problems.
Pyramat will repair or replace (at its discretion) units
covered by this warranty, without charge to the
consumer for labor or materials. CONSUMER IS
RESPONSIBLE FOR ANY INSTALLATION OR REMOVAL
CHARGES AND ANY INITIAL SHIPPING CHARGES.
However, we will pay the return shipping charges to
any destination within the United States if repairs are
covered by the warranty.
G-Flex Game Booster Limited Warranty
REPAIR OR REPLACEMENT AS PROVIDED UNDER
THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE
CONSUMER. PYRAMAT SHALL NOT BE LIABLE FOR
ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES
FOR BREACH OF ANY EXPRESS OR IMPLIED
WARRANTY ON THIS PRODUCT. EXCEPT TO THE
EXTENT PROHIBITED BY APPLICABLE LAW, ANY
IMPLIED WARRANTIES, INCLUDING WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED IN DURATION
TO THE LENGTH OF THIS WARRANTY.
Some states do not allow the exclusion or limitation of
incidental or consequential damages, or allow limitations
on how long an implied warranty lasts, so the above
limitations may not apply to you.
TO OBTAIN WARRANTY SERVICE
For service assistance, product information, or to locate
the dealer nearest you, please call or write:
Pyramat Service Center
877-591-1012
[email protected]
For further information on how to order accessories for
this product or other Pyramat products, please visit our
website at www.pyramat.com.
IMPORTANT
For your records, save your original sales receipt with
this manual and write the serial number here.
––––––––––––––––––––––––––––––––––––––––––––––––––
Page 8
7
Printed in China for:
Pyramat, LLC
PO Box 3610
Cerritos, CA 90703
© Copyright 2006 Pyramat, LLC
071406
If you have problems with your G-Flex,
DO NOT RETURN TO STORE.
Follow instructions in this manual.
Failure to follow these instructions may damage
your G-Flex and void your warranty.
Need Help? Visit our website at www.pyramat.com, send an e-mail to [email protected]
or call toll-free at 877-591-1012.
