OWNER’S MANUAL

PDC21

1. INPUT – 1/4” input connector.

2. PARA OUT – It’s parallel output 1/4” jack for passing the input
signal through to a stage amplifier or monitor system.

3. ATT Switch – input attenuation, switchable(0dB,-20dB,-40dB)

4. BALANCED OUTPUT – Male XLR connector.

5. GROUND – When engaged, the ground from the PDC21 chassis
detaches from the XLR jack.

Front and Rear Panel La

you

t
