PWMA100
WIRELESS RECHARGEABLE
PORTABLE AMPLIFIER
WWW.PYLEAUDIO.COM
USER'S MANUAL
FEATURES
PARTS DESCRIPTION
* Built-in 12V 1.2A Rechargeable Battery
* Built-in One Channel VHF Wireless Receiver
* With One Handheld MIC
* With One Wired MIC Input Jack
* Separate Wired MIC and Wireless MIC Volume Controls
* With REC out Jack
* With Treble, Bass and Echo Controls
* With Power, RF and Charge LED Indicators
* Power Supply: AC 120V/60HZ, DC12~15V
* Power output: 20W
* Frequency Range: 160~270MHz
* Operating Range: Up to 100ft.
CAUTIONS
1. Keep this device away from high temperature. Don't
expose this device to direct sunshine or near the hot
equipment.
2. Don't place the device in the environment of humidity and
dirts.
3. Place the device in the ventilated environment.
4. Don't pull the power cord while unplug the device. Please
hold he plug to unplug.
5. Unplug the device from mains power supply if you will not
use the device for a long time.
6. Your operation must be subjected to the specified voltage
marked on the device and complied with this manual.
7. Don't open chassis! It is very dangerous either open the
chassis or put your hand inside the chassis. If the device is
not working properly, unplug the device at once and
contact your retailer or the nearest distributor.
1. Power switch
2. Wireless volume control
3. RF indicator
4. Power indicator
5. Wired MIC volume control
6. Wired MIC input jack
7. Recording output jack
8. Treble control
11
TREBLE
ECHO
BASS
CHARGELED
MIN
OUT
14
MAX
MIC
MIC VOL
POWER
9. Bass control
10. ECHO control
11. Charge indicator
12. DC input jack
13. Retractable antenna
14. Speaker
15. AC IN jack
13
++
MIN
MAX
W/MIC VOL
POWER
POW
ON
ER
OFF
12
15
-1- -2-
OPERATION
OPERATION
1. POWER SUPPLY
a. AC power: Please confirm your current AC power is
same as the voltage marked on the device.
b.DC power: DC power can be input from DC IN jack. If you
use car battery, the power should be 12V-15V. Please
note the correct polarity.
C. Built-in rechargeable battery: you can also use built-in
rechargeable battery.
2. Turn on power switch of amplifier, power indicator will light.
3. Open the battery cover of the transmitter. Put a 9V battery
into battery compartment and then close the battery cover.
Keep transmitter at least 1M from the receiver to prevent
feedback. Turn on transmitter, RF indicator on receiver will
light. Adjust wireless microphone volume to suitable level.
The wireless system is now ready to use.
4. Wired MIC can connect to MIC in jack and its volume can
be adjusted separately. Wire microphone and wireless
microphone can be used at the same time.
5. Adjust TREBLE/BASS to suitable level. When feed-back
comes from amplifier, please reduce TREBLE. If feedback
still exists, reduce the volume slightly.
6. REC OUT can connect to recorder player or external
amplifier.
Recharging:
1. Connect amplifier to AC power, charge indicator will light.
The unit starts to charge rechargeable battery. DC power
can not charge the battery.
2. During charging you can use the unit at the same time.
3. When using rechargeable battery, if the unit stops
producing sound, this means the rechargeable battery
power is low. Connect AC power to charge the battery.
Charging time is about 8~10 hours.
4. Please charge this device every 2 months if you don't use
the device for a long period of time.
5. Unplug th unit from mains power supply if you are not
going to use this device for a long time or after charging.
-3- -4-
TROUBESHOOTING
SPECIFICATIONS
PROBLEM
1.Push the power switch to "ON"
2.Replace a new battery for transmitter.
RF indicator
does not light
RF indicator
flashes
A howling
noise is heard
from speaker
The charge
indicator
does not light
3.Please check the frequency of transmitter.
Make sure transmitter frequency is same
as main unit.
1.Rechargeable battery power is low. Please
plug in AC power to charge the battery.
2.Transmitter battery power is low. Please
replace new battery.
Reduce microphone volume or move the
microphone away from the speaker. Keep
microphone 1.5-3M from receiverunit.
1. Rechargeable battery may be destroyed.
Please replace a new one. (Contact your
dealer or professionals for battery
replacement)
2. Check the AC power connection.
SOLUTION
AMPLIFIER
Output power: 20W(MAX)
Frequency Range: 160-270MHz
S/N: 60dB
Power supply: AC 120V 60Hz
DC 12V-15V
Output Impedance: 600
Effective Distance: 30M
TRANSMITTER
Frequency Range: 160-270MHz
Dynamic Range: 80dB
No sound
1. Check the transmitter power switch is "ON"
2. Check the W/M volume control or MIC
volume is on.
-5- -6-
Frequency Response: 100-10KHz
Working Temperature: -10 -45
Power supply 9V battery
Battery life 8-10 hours
