PYLE Audio PT502 User Manual

IMPORTANT

Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.

Part No. D22724-028-3

1/2” Impact Wrench
Herramienta

Neumátiaca de Impacto,
de 1/2"

IMPORTANT

Veuillez vous assurer que la personne qui
utilise cet outil lit attentivement et comprend
ces instructions avant de commencer à utiliser
l'outil.

Clé à chocs de 1/2 po

IMPORTANTE

Asegúrese de que la persona que va a usar esta
herramienta lea cuidadosamente y comprenda
estas instrucciones antes de empezar a
operarla.

ESPAÑOL: PÁGINA 9
FRANÇAIS: PAGE 17

Copyright © 2002 Porter-Cable Corporation

Instruction manual

Manual de

Instrucciones

Manuel d'instructions

MODEL PT502

MODÈLE PT502

MODELO

PT502

To learn more about Porter-Cable visit

our website at:

http://www.porter-cable.com

Pour de plus amples renseignements

concernant Porter-Cable, consultez
notre site Web à l'adresse suivante:

http://www.porter-cable.com

Para obtener más información sobre

Porter-Cable, visite nuestro sitio web en:

http://www.porter-cable.com

2- ENG

D22724

• Air powered equipment and power tools are capable of
propelling materials such as fasteners, metal chips, saw
dust, and other debris at high speed, which could result
in serious eye injury.

• Tool attachments can become loose or break and fly
apart propelling particles at the operator and others in
the work area.

• Abrasive tools such as sanders and grinders, rotating
tools such as drills, and impact tools such as nailers,
staplers, wrenches, hammers, and reciprocating saws
are capable of generating sparks which could result in
ignition of flammable materials.

• Never operate tools near flammable substances such
as gasoline, naptha, cleaning solvents, etc.

• Work in a clean, well ventilated area free of combustible
materials.

• Never use oxygen, carbon dioxide or other bottled
gases as a power source for air tools.

HAZARD

WHAT COULD HAPPEN HOW TO PREVENT IT

RISK OF FIRE OR EXPLOSION

• Exceeding the maximum pressure rating of tools or
accessories could cause an explosion resulting in seri­ous injury.

• Use compressed air regulated to a maximum pressure
at or below the rated pressure of any attachments.

• Never connect to an air source that is capable of
exceeding 200 psi.

• Always verify prior to using the tool that the air source
has been adjusted to the rated air pressure range.

Some dust created by power sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known (to the State of California) to cause

cancer, birth defects or other reproductive harm. Some example of these chemicals are:

●●

lead from lead-based paints

●●

crystalline silica from bricks and cement and other masonry products

●●

arsenic and chromium from chemically-treated lumber

Your risk from these exposures varies, depending on how often you do this type of work. To reduce your
exposure to these chemicals: work in a well ventilated area, and work with approved safety equipment,
always wear MSHA/NIOSH approved, properly fitting face mask or respirator when using such tools.

When using air tools, basic safety precautions should always be followed to reduce the risk of personal
injury.

SAFETY GUIDELINES - DEFINITIONS

indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.

indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.

indicates a potentially hazardous situation which, if not
avoided,may result in minor or moderate injury

used without the safety alert symbol indicates potentially
hazardous situation which, if not avoided, may result in
property damage.

This manual contains
information that is
important for you to know and
understand. This information re­lates to protecting YOUR SAFE­TY and PREVENTING
EQUIPMENT PROBLEMS. To
help you recognize this informa­tion, we use the symbols below.
Please read the manual and pay
attention to these sections.

IMPROPER OPERATION OR MAINTENANCE OF THIS PRODUCT COULD RESULT IN
SERIOUS INJURY AND PROPERTY DAMAGE. READ AND UNDERSTAND ALL WARNINGS AND
OPERATING INSTRUCTIONS BEFORE USING THIS EQUIPMENT.WHEN USING AIR TOOLS, BASIC
SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO REDUCE THE RISK OF PERSONAL

INJURY.

SAVE!

IMPORTANT SAFETY INSTRUCTIONS

SAVE!

HAZARD

WHAT COULD HAPPEN HOW TO PREVENT IT

RISK OF EYE OR HEAD INJURY

• Always wear ANSI approved Z87.1 safety glasses with

side shields.

• Never leave operating tool unattended. Disconnect air
hose when tool is not in use.

IMPORTANT SAFETY INSTRUCTIONS

• For additional protection use an approved face shield
in addition to safety glasses.

• Make sure that any attachments are securely
assembled.

• Compressed air can be hazardous. The air stream can
cause injury to soft tissue areas such as eyes, ears, etc.
Particles or objects propelled by the stream can cause
injury.

3- ENG

D22724

• A wrench or a key that is left attached to a rotating part
of the tool increases the risk of personal injury.

• Tools left unattended, or with the air hose attached can
be activated by unauthorized persons leading to their
injury or injury to others.

• Air tools can propel fasteners or other materials
throughout the work area.

• Air tools can become activated by accident during
maintenance or tool changes.

• Remove air hose when tool is not in use and store tool
in secure location away from reach of children and or
untrained users.

• Use only parts, fasteners, and accessories
recommended by the manufacturer.

• Keep work area clean and free of clutter. Keep children
and others away from work area during operation of
the tool.

• Keep work area well lit.

• Remove air hose to lubricate or add grinding
attachments, sanding discs, drills, etc. to the tool.

• Never carry the tool by the hose.

• Avoid unintentional starting. Don't carry hooked-up tool
with finger on trigger.

• Repair servicing should be done only by an authorized
service representative.

• Using inflator nozzles for duster applications can cause
serious injury.

• DO NOT use inflator nozzles for duster applications.

• Remove adjusting keys and wrenches before turning
the tool on.

HAZARD

WHAT COULD HAPPEN HOW TO PREVENT IT

RISK OF INJURY

• Always wear MSHA/NIOSH approved, properly fitting
face mask or respirator when using such tools.

• Long term exposure to noise produced from the opera­tion of air tools can lead to permanent hearing loss.

• Always wear ANSI S3.19 hearing protection.

HAZARD

WHAT COULD HAPPEN HOW TO PREVENT IT

RISK OF LOSS OF HEARING

HAZARD

WHAT COULD HAPPEN HOW TO PREVENT IT

RISK TO BREATHING INHALATION HAZARD

• Always work in a clean, dry, well ventilated area.• Some materials such as adhesives and tar, contain
chemicals whose vapors could cause serious injury
with prolonged exposure.

• Abrasive tools, such as grinders, sanders, and cut-off
tools generate dust and abrasive materials which can
be harmful to human lungs and respiratory system.

• Air tools can cause the workpiece to move upon con­tact leading to injury.

• Loss of control of the tool can lead to injury to self or
others.

• Use clamps or other devices to prevent movement.

• Never operate tool while under the influence of drugs
or alcohol.

• Don't overreach. Keep proper footing and balance at all
times.

• Keep handles dry, clean, and free from oil and grease.

• Stay alert. Watch what you are doing. Use common
sense. Do not operate tool when you are tired.

• Poor quality, improper, or damaged tools such as
grinding wheels, chisels, sockets, drills, nailers,
staplers, etc., can fly apart during operation, propelling
particles throughout the work area causing serious
injury.

• Always use tool attachments rated for the speed of the
power tool.

• Never use tools which have been dropped, impacted or
damaged by use.

• Use only impact grade sockets on an impact wrench.

• Do not apply excessive force to the tool, let the tool
perform the work.

• Fasteners could ricochet or be propelled causing
serious injury or property damage.

• Never point discharge of tool at self or others.

• Do not pull trigger unless tool contact safety device is
against work surface.

• Never attempt to drive fasteners into hard surfaces
such as steel, concrete, or tile.

• Take care to avoid driving a fastener on top of another
fastener.

• Position tool carefully so that fasteners will be delivered
to the proper location.
