Thank you for purchasing this elegant waterproof sports MP3 player from us.
This waterproof sports MP3 player is the latest generation of our MP3 players. With its
compact design and waterproof function, you can enjoy music underwater while you are
swimming or exercising. It offers stereo FM radio with a wide frequency range. What‟s
more, it is also a perfect pedometer.
Before using this product, we commend reading this manual step by step to obtain the
best results with your new waterproof sports MP3 player. We wish you a lot of fun!

Copyright warning

This player is for your personal use only. Unauthorized recording or duplication of
copyrighted material may infringe upon the rights of third parties and may be contrary to
copyright laws.
Back up your data regularly. The manufacturer is not responsible for lost data.
You are cautioned that any change or modifications to the equipment not expressly
approved by the manufacturer could void your warranty.
The user manual is subject to change without notice.

Safety Notice:

To prolong the life of the waterproof sports MP3 player, all the following safety, operating
instructions and maintenance should be read and adhered to before the player is
operated.

1

※ Do not drop the player, and do not damage or take apart the player, otherwise your
warranty will be voided.
※ Do not expose the player to high temperatures and direct sunlight for prolonged
periods of time.
※ Handle the player with care. Avoid contact with sharp objects. Keep device off of
metallic objects.

※ Only use accessories recommended from the manufacturer.
※ Listening at high volume for a long period of time could cause damage to your ears.
※ Do not use the player while driving, as this could result in an accident.
※ Protect the player from vibration or shock.

Usage Notice

Do:

✔ Turn off and unplug the power before cleaning the player.
✔ Use a soft dry chiffon with mild detergent to clean the display housing.
✔ Unplug the power if the product is not used for a long periods of time.
✔ Ensure the operating temperature is within 23°F~104°F

Do not:
✘ Use abrasive cleaners, waxes or solvents to clean the unit.

2

✘ Use under the following conditions:
▷ In extremely hot, cold or humid environments.
▷ In areas susceptible to excessive dust or dirt.
▷ Near any appliance generating a strong magnetic field or electric field.

▷ In direct sunlight.

Connecting to the PC/Notebook via earphone jack

Computer system requirements

Pentium III 500MHz or higher recommended
Windows® XP (service pack 1 or higher) or Windows Vista™ or Windows® 7
Internet access

Windows Media Player 10 or higher
250MB or more free hard disk space for the software
128MB RAM (256MB recommended)
CD drive capable of digital audio extraction
USB port (2.0 recommended)
Sound card

3

Earphone Jack/USB jack

Connect the player to your PC USB port as shown through equipped USB cable. Connect
the PC USB port and the MP3 USB port with the provided USB cable
The player will turn on automatically and display "USB connected" on the display. The
player will appear as a drive letter on your computer, a Mass Storage Class (MSC) device,
and behave as a detachable drive for file transfer in one or both directions.

4

Connect the PC USB port and the MP3 USB port with the provided USB cable.
Add MP3 files/folders to the USB storage„s folder.

Ⅰ. Open files/folders to be transferred on your computer.
Ⅱ. Open My Computer → Removable Disk from the desktop.
Ⅲ. Select the files/folders to be transferred from your computer and drag and drop them

to a folder of your choice in the Removable Disk (you can also transfer files on your PC to
the player using the "Copy" and "Paste" functions).

Delete MP3 files from the removable USB storage (use the "Delete" command).

5

1. Left click the icon on the taskbar at the bottom right corner of the desktop.

2. Click the "Safely remove USB Mass Storage Device – Drive(G:)" column.

3. Disconnect the player from your computer.
CAUTION:

Do not remove the player while files from the USB Mass Storage are being played on
your PC/Notebook.
Do not disconnect the player from your PC/Notebook while transferring file, or it will
cause damage to the player or data loss.

Package Contents

Please check that the package contains the following items:
Waterproof sports MP3 player
USB cable
Waterproof earphone
Quick Start Guide

Product Overview

6

Button Definition:

Menu/
back

Play/
pause/
OK

Vol down/
scroll
down

Next /scroll up

Previous/scroll down

Vol up/
scroll up

Menu Navigation

【M】button: Enter main menu, submenu or return.
Skip button (【 】/【 】): Shift menus.

Play/Pause button (【 】): Play, Pause, or confirm.
Lock/Unlock : When you are walking or running, you can set the player to "Lock" mode,
then all buttons are disabled. To unlock, just long press【M】button until lock icon
disappears.
If the unit freezes and/or is not working properly. Press both【M】and【 】button at the
same time to reset. The unit will reset.
