PYLE Audio PSWLE57 User Manual

Page 1
Thank you for choosing our productThank you for choosing our product
Pyle Audio 1600 63rd st , Brooklyn, NY, 11204 (718)236-8000
Warning
This product contains small items that could be a choking hazard if swallowed. Keep these items away from young children
1.Make sure these instructions are read and completely understood before attempting installation. If you are unsure of any part of this installation, contact a professional installer for assistance.
2.The wall or mounting surface must be capable of supporting the combined weight of the mount and the display; otherwise the structure must be reinforced
3.Safety gear and proper tools must be used. A minimum of two people are required for this installation. Failure to use safety gear can result in property damage, serious injury or death.
!
.
INSTALLATION GUIDE
Item No.:
Item No.:
TV Size Range: 36 55
Maximum Weight Capacity: 35kg/77lbs
Locked by safety bolt on the bottom
Balance adjust system is included
This product was designed to be installed on wood stud walls and solid concrete walls. Before installing make sure the supporting surface will support the combined load of the equipment and hardware. Never exceed the Maximum Load Capacity. This product is intended for indoor use only. Use of this product outdoors could lead to product failure or personal injury.
PSWLE57
PSWLE57
"~ "
CAUTION
www pyleaudio com..
-8-
Page 2
Hardware Kit:Hardware Kit:
Part 3-Mounting the flat panel screen
Part 3-Mounting the flat panel screen
3
4
A-H
ID Description
Qty 1 2
3
4
5
A
B
C D
E
Wall plate
1 1
Left bracket Right bracket
1 2
Safety bolt
1
Bubble level
4
M4 mm×12 bolt
4
M4 mm×16 bolt
4
M5× mm16 bolt
4
M6× mm16 bolt
4
M8×16mm bolt
2
Hook the top of brackets onto the top flange of wall plate(1). Then swing the screen down. Tighten the safety screw on each bracket to lock the screen into place.
1
NOTE: Always use an assistant or mechanical lifting equipment to safely lift
NOTE:
and position heavy equipment.
5
JM
ID
K
Qty
4
F
4
G
4
H
4
I J
6
K
6
L
6
M
4
LI
Description M ×36mm5 bolt M6×36mm bolt M ×36mm8 bolt
Square washer Long bolt Wall anchor
Long bolt washer Spacer
Wall
(2,3)
(4)
Wall
2,3
4
1
-2-
-7-
Page 3
Part 2b-Attaching brackets to screen with recessed back
Part 2b-Attaching brackets to screen with recessed back
Part 1a-Wood Stud Mounting
Part 1a-Wood Stud Mounting
Center brackets vertically on back of screen. Select the medium(F or G) or large(H) screws. Attach brackets to screen using four selected screws,four square washers(I) and four spacers(M) at the top and bottom of each bracket. Tighten screws firmly. Do not overtighten.
Square washer(I)
Large hole for M8 screws
Medium hole for M5andM6screws
M
F-H
I
Use wall plate as a template, make sure it is level, and mark mounting holes along the center lines of the wood studs. Drill 3/16
””(5mm)dia holes 2 (50mm) deep. Level wall plate and attach to wall with long bolts(J and washers(L . Tighten screws firmly Do not overtighten
)..
.
)
2 50mm)”(
Φ3/16 (5mm)”
Wood stud
Bubble level
L
J
-6-
-3-
Page 4
Part 1b-Concrete Wall Mounting
Part 1b-Concrete Wall Mounting
Part 2a-Attaching Brackets To Screen With Flat Back
Part 2a-Attaching Brackets To Screen With Flat Back
Level wall plate and use it as a template to mark holes. Drill 3/8 (10mm) dia. holes 2 (50mm) deep. Insert anchors(K) into holes and secure wall plate
”
”
with long bolts(J) and washers(L). Tighten screws firmly. Do not overtighten
2(” 50mm)
Φ3/8 (10mm)”
Concrete Wall
K
Bubble level
J
Center brackets vertically on back of screen. Select the small(A or B),medium (C or D) or large(E) screws. Attach brackets to screen using four selected
.
screws and four square washers(I) at the top and bottomof each bracket. Tighten screws firmly. Do not overtighten
.
Square washer(I)
Large hole for M8 screws
Medium hole for M5 and M6 screws
Small hole for M4 screws
A-E
I
-4-
L
-5-
