PYLE Audio PLNV35 User Manual

OWNER’S MANUAL

PLNV35

Global Positioning System

www.pyleaudio.com

Contents

Safety Information ......................................................................................................3

Installation...................................................................................................................5

Views............................................................................................................................8

Front View...............................................................................................................8

Back view ...............................................................................................................8

Top/Bottom View ....................................................................................................9

Left/Right View........................................................................................................9

GPS (Global Positioning System) ............................................................................10

Memory Card Quick Installation ...........................................................................10

Software Installation on your PC ..........................................................................10

Contents of the Navigation CDs ...........................................................................11

Installing Microsoft Active Sync............................................................................11

2

SAFETY INFORMATION

Safety Instructions

Please read this section carefully and
follow all the instructions given.
This will help ensure reliable operation
and extend the service life for your
appliance.
Keep the packaging and the user
instructions for future reference or
enquiries at a later date. If you pass the
article on to another person, you must
pass on these instructions.

• Never open up the housing of the
appliance or the power adapter. These
contain no user-serviceable parts. If the
housing is opened there is a danger to
life from electric shock.

• Do not place any objects on the
appliance and do not exert any pressure
on the display. Otherwise there is a
danger that the screen will break.

• To avoid damage, do not touch the
screen with sharp objects. Use only the
stylus provided.

• There is a risk of injury if the display
breaks. If this should occur, use
protective gloves to pack the broken
parts and contact customer support to
arrange for disposal. Then wash your
hands with soap, since there is a
possibility that chemicals may have
escaped.

• Never allow children to play with
electrical equipment unsupervised.
Children do not always correctly
recognize possible danger.

• Remove the power adapter from the
outlet, switch the appliance off
immediately, or do not actually switch
it on, and contact Customer Service …
if the power adapter or the attached
plug become scorched or damaged.
if the housing of the appliance or the
power pack becomes damaged or fluids
leak into it. Components must be
checked by Customer Service in order
to avoid damage!

Data Security

• Every time you update your data make
backup copies on an external storage
medium. The supplier does not assume
liability for data loss or damage to data
storage units, and no claims can be
accepted for damages resulting from
the loss of data or for consequential
damages.

Operating Environment

• Keep your navigation system and all
connected devices away from moisture
and avoid dust, heat and direct sunlight,
especially in the car.

• Make sure you protect your appliance
from getting wet. (e.g. from rain and
hail, at all times.) Please pay attention
that moisture can even build up in a
protective pouch because of
condensation.

• Avoid heavy vibrations and shaking.

• Avoid the device from releasing itself
from its holder, for example when
braking. In stall the device as vertically
as possible.
Failure to follow these instructions
may lead to damage to your appliance.

Ambient Temperature

• The appliance is most reliably operated
at an ambient temperature of between
41°F to 104°F (5°C to 40°C) and at a
relative humidity of between 10% to
90%.

• In the powered down state the appliance
can be stored at between 32°F to 140°F
(0°C to 60°C).

• Store the appliance in a safe location
to avoid high temperatures (e.g. when
parking or from direct sunlight).

Electromagnetic Compatibility

• When connecting additional or other
components the “Electromagnetic
Compatibility Directive”(EMC) must be
adhered to. Please also note that only
screened cable (maximum 10ft) should
be used with this appliance. For optimal
performance, maintain a distance of at
least 3 metres from sources of high­frequency and magnetic interference
(televisions, loudspeaker systems,
mobile telephones and so on.) This will
help avoid malfunctions and loss of
data.

Battery Operation

Your appliance is operated with a
removable battery. In order to prolong the
life and efficiency of your battery and to
ensure safe operation,follow the
instructions below:

• Warning: Danger of explosion if
rechargeable batteries are not charged
properly. Only replace with the same
type of battery or a similar type
recommended by the manufacturer.
Never open the rechargeable battery.

3

SAFETY INFORMATION

Do not throw the rechargeable battery
into fire. Dispose of the used batteries
following the manufacturer’s
instructions.

• Batteries cannot withstand heat. Avoid
the appliance and the integrated battery
becoming overheated. Failure to comply
with this instruction may lead to damage
to and even explosion of the battery.

• Use only the original power pack to
charge the battery or the car adapter
from the optional navigation kit.

• The batteries are special category
waste. When disposing of the appliance
ensure that this is done correctly.
Contact Customer Service for more
details.

Care of the Display

• Avoid scratching the display surface
as this is easily damaged. It is strongly
recommended to use a display
protection mylar to avoid scratches.
Please ask your nearest dealer for this
accessories. The foil on the display at
delivery is purely for protection during
transportation!

• Ensure that no traces of water remain
on the screen. Water can cause
irreversible discoloration.

• Use only a soft , lint-free cloth to clean
the screen.

• Do not expose the screen to either
strong sunlight or ultraviolet radiation.

Transport

If you wish to transport the appliance
follow the instructions below:

• Following transport of the appliance
wait until the unit has acclimatized
before using it.

• In the case of wide fluctuations in
temperature or humidity condensation
or moisture may form inside the
appliance and this can cause an
electrical short-circuit.

• In order to protect the appliance from
dirt, knocks and scratching, use the
protective case.

• Before traveling ensure that you are
aware of the power and
communications provision at your
destination. Before traveling obtain any
power or communications
adapters(modem, LAN, etc.) That may
be needed.

• When shipping your appliance use only
the original packaging and advise the
carrier accordingly.

• When passing through the hand luggage
control at airports, it is recommended
that you pass the appliance and all
magnetic storage media (external hard
drives) through the X-ray system (the
machine on which you place your bags).
Avoid the magnetic detector (the
structure through which you pass) or
the magnetic wand (the hand device
that the security staff use), since this
may corrupt your data.

Connection

When connection your appliance be sure
to correctly observe the following
instructions:

• The outlet must be in the vicinity of the
appliance and must be easily accessible.

• Only use the mains adapter on
grounded sockets at 100-240V~AC,
50/60Hz. If you are unsure about the
power supply to the place of use, ask
the relevant energy supplier.

• Use only the power adapter provided
with your appliance.

• For additional safety, we recommend
the use of a surge protector in order to
protect your appliance from damage
by electricity spikes or lighting strikes
on the power network.

Power Through Car Adapter

• The car adapter should only be
connected to the lighter socket of a car
(car battery =DV12V ,no trucks!). If you
are in any doubt about the power
source in your car, contact your car
manufacturer.

Cabling

• Arrange cables so that no-one can tread
on them or trip over them.

• Do not place any items on the cable.

WARNING

When the unit is not in use for a long time,
please switch the Power On/Off switch
to unlock position and recharge the battery
every other time, otherwise the battery’s
lifetime would be shortened.
