PYLE Audio PLMRA620 User Manual
www.pyleaudio.com
amplifiers
Brooklyn, NY 11204
1600 63rd Street
Pyle Service Center
R.A.#
damage.
improperly serviced, or subject to misuse, neglect, or accidental
This warranty will be considered void if the unit was tampered with,
replacement of the defective unit when it is returned to us prepaid.
Our obligation under this warranty is limited to the repair or
expiration date.
handling, and insurance, or provide your Visa/MC number with
• also include a check or money order for $18.00 for return shipping,
and R.A. number
• include in your letter your return address, daytime phone number,
• A brief letter indicating the problem you are experiencing
• A copy of your sales receipt or other proof of purchase
You must also include the following items:
and shipped prepaid to:
When returning a product to us for warranty service it must be carefully packed
relating to your return.
R.A.# must appear on the outside of your package and on all paperwork
number at (718) 236-6948 to obtain a Return Authorization number. This
To obtain warranty service you must first call our Consumer Return Hotline
your unit will be repaired or replaced at the sole discretion of Pyle.
Should the product fail due to factory defects in material or workmanship,
warranty is limited to the original retail purchase.
in material and workmanship for two (2) years from the date of purchase. This
shipment. Products purchased in the USA are warranted to be free of defects
All Pyle products are carefully constructed and thoroughly tested before
limited warranty policy
congratulations...
on your purchase of a Pyle
Marine
Series amplifier. This amplifier
extends the Pyle tradition into a totally new series of amps, designed
from the ground up to deliver the power, performance and flexibility
the modern car audio enthusiast demands.
When you check the list of features offered by the PLMRA620
you’ll
know you made the right choice with a Pyle
Marine
amplifier.
table of contents
general features
features and specifications
PLMRA620
electrical connections
PLMRA620
1/2/3/4 channel input connections
PLMRA620
mono input connections
PLMRA620
speaker connections
PLMRA620
speaker connections
PLMRA620
mounting and installation
2
3-4
5
6
7
8
9
10
protection circuitry and troubleshooting
precautions
11
12
general features
PLMRA620
High Performance 2000 Watt 6 Channel
Bridgeable MOSFET Amplifier
· 100 Watts x 4 Output. +250 Watts x 2 Output.
· 250 W x 4. +500 W x 2 Bridged Output ( 400 W x 2 + 900 W x 1)
· Variable Hi/Lo Electronic Crossover Network ( CH1/CH2/ and CH3/CH4)
· Variable Bass Boost (0 - +18 dB @ 60Hz) ( CH5/CH6)
· Variable Input Level (Gain) Control
· Low and High Pass Filter Controls( CH3/CH4)
· Remote Turn On/Off
· Gold Plated RCA Inputs
· Power ON LED Indicator
· LED Protection Indicator
· S/N Ratio: > 95 dB
· THD: <0.04%
· Thermal Protection
· Overload Protection
· Short Circuit Protection
· Anti-Thump Turn-On
· Blue LED Level Display
