PYLE Audio PLDVD10M User Manual

10.4” TFT-LCD Monitor

w/Built-in DVD/CD/MP3 Player

PLDVD10M

Operation Manual

Table of Contents

Welcome! ----------------------------------------------------------------------- 2
Precautions ---------------------------------------------------------------------3

Installation

Installation ----------------------------------------------------------------------4

Operation

Monitor Section --------------------------------------------------------------- 5
Adjusting the display setting-------------------------------------------------5
DVD section --------------------------------------------------------------------6
Operate DVD by Remote control--------------------------------------------7

Preparing the Remote Control

Inserting the Batteries--------------------------------------------------------8
Using the Remote Control---------------------------------------------------8

Connections

Connection Diagram ---------------------------------------------------------9

Additional Information

Troubleshooting -------------------------------------------------------------10
Specifications ----------------------------------------------------------------11

1

Welcome!

Thank you for purchasing the 10.4" headrest TFT-LCD Monitor with
DVD Player. For Maximum enjoyment and prolonged life of the
DVD player, we strongly recommend that you read the instruction
manual carefully before attempting to operate the unit. Please store
this manual in a safe place for future reference.
Digital Video Discs are the best source of movies for your life.
The latest digital technology allows compression of an entire movie
onto one disc. DVD's provide greater picture clarity and sound fidelity
than any video player on the market.

* You can select PAL or NTSC system.

* In addition to normal screen mode, full screen and zoom
screen modes are also available.

* The low reflection liquid crystal panel reduces the glare
from outside lighting sources.

* You can manually adjust the brightness of the display according
to the prevailing light conditions of your surroundings.
* The backlighting control produces sharp contrast images
free from reversed or blurred colors.

* This unit has 1 Audio/Video output, for additional connection to
another monitor.

* In addition, this unit has a built-in IR transmitter of IR
wireless headphone. This Convenient feature allows you
to use infrared wireless headphones with this unit.

2

Precautions

To avoid the risk of serious injury or accident. Please read the

following precautions before installing and operating the unit.

On Safety
IMPORTANT: Always comply with your local traffic rules and

regulation.

▓ While driving

●The driver must not watch or operate the monitor. This is
　　 a safety hazard and may cause an accident.

●The driver must not listen to or use the headphones.

It may be distracting and cause an accident.
If the driver wants to watch or operate the monitor at any time,
you must first park the car in a safe place before doing so.

▓ When operating
●Do not hang onto the monitor.

●Do not insert your hands, fingers or foreign objects into

the unit while the monitor is functioning. It may cause
injury or damage to the unit.
●Take care not to bump your head against the unit when
getting up from the back seat.
●Keep small articles, such as DVD Disks or Remote
Controls, out of the reach of children.

On Installation

●Installing this unit requires technical expertise. This unit
should be installed by a qualified technician or service
personnel.

●If you try to install this unit by yourself, do it properly, referring
to the installation and wiring diagrams in this operation manual.
Improper installation may result in a fire or an electric shock.

●Before installation, be sure to turn the ignition switch to the
OFF position or take the key out. Installing this unit with the
ignition on may cause battery drain or a short circuit.

●Do not damage any pipes, tubes, the fuel tank or electric
wiring when installing this unit. This can cause a fire.
If you drill a hole in car panels, make sure that any hidden
car parts will not be damaged.

●Do not use any nuts or bolts for safety devices such as
steering linkage, fuel supply braking systems. This can
cause a fire or an accident.

3
