PLD43MU
DVD/RECEIVERCONTROL
OWNER's MANUAL
Mobile Video System
CH1-6
MOD
REL
RESET
VOL-
VOL+
AUX IN
CAR DVD/VCD/CD/MP3 PLAYERWITH MPEG4
DVD/RECEIVERCONTROL
PLAY/PA USE
MUTE
STOP
MO/ST
ANGLE
CLK
EQ
MODE
ENTER
INT
TOP
1
3
2
RDM
5 6
4
8
7
9
GOTO
0
+10
LO/DX
TITLE/ PBC
POWER
REPEAT
MENU
OSD
BAND
A/PS
VOL
VOL
SEL
SETUP
IR
A
Detachable PanelMotorized Slide Down And
4.3 Inch Wide Color Touch Screen Monitor
CAR DVD/VCD/CD/MP3 Player
AM/FM Digital PLL Tuning Radio
MPEG4 Player
USB Connect
TOUCHSCREEN
SEL
P
S
EQ
BND
MU
P
S
I
D
I
Contents
Preautions .....................................
Safety Information.........................
Disc Notes ....................................
Installation ....................................
Detaching the control panel ...........
Changing the control panel ............
Electric Connection ......................
Remote Control ...........................
Control Panel ................................
Touch Panel
Unit Keys ...................................
Basic Operations
TFT Monitor
Rear View Camera
Audio Quality Adjustments
Setting Audio Mode .....................
Scroll Caption Adjustments
Alternate Audio/video Source
Radio Operations ..........................
Listening to the radio ...................
Storing stations in memory ...........
Listening to a preset station .........
DISC Operations ...........................
Basic Operations ........................
Select Playback Mode .................
On-Screen Disc Operations .........
DISC Special Functions ................
Selecting audio languages ...........
Selecting Subtitles .....................
Selecting multi-angle views ........
Title menu function ...................
................................
..........................
Adjustment .............
.....................
............
............
........
Setup .............................................
2
General Setup ...........................
Speaker Setup ...........................
Dolby Digital Setup ....................
Preferences Setup ......................
Defaults Table ............................
Other Main Operations ..................
USB Operations .........................
AUX Operations .........................
MP3/WMA/JPEG Play ................
MPEG4 Play ..............................
Specifications ...............................
Trouble Shooting ..........................
10
12
12
13
16
17
17
17
18
18
18
19
1
1
20
21
21
2
2
2
25
25
25
25
3
4
5
7
8
9
9
9
2
4
5
26
26
28
28
29
30
31
31
31
32
32
33
34
1
Precautions
THANK YOU FOR PURCHASING THIS CAR DVD PLAYER .
Before operating the unit, read this manual thoroughly and keep it handy
for future reference .
To avoid injury or accident , read the following precautions before
installing and operating the unit .
ON INSTALLATION
DO NOT install any receiver in locations where;
- it may obstruct the steering wheel and gearshift lever operations, as this
may result in a traffic accident.
- it may obstruct the operation of safety devices such as air bags, as this
may result in a fatal accident.
- it may obstruct visibility.
DO NOT operate any receiver while manipulating the steering wheel, as
this may result in a traffic accident.
The driver must not watch the monitor while driving.
IF THE DRIVER watches the monitor while driving, it may lead to
carelessness and cause an accident.
IF YOU NEED to operate the receive while driving, be sure to look ahead
carefully or you may be involved in a traffic accident.
IF THE PARKING BRAKE is not engaged.“ ParkingBrake” flashes on the
monitor, and no playback picture will be shown.
- This warning appears only when the parking brake wire is connected to
the parking brake system built in the car ( refer to the electric connection)
ABOUT THE LIQUID CRYSTAL DISPLAY (LCD) PANEL
Do not press on the LCD panel on the unit as doing so can distort the
picture or cause a malfunction . The picture may become unclear , or the
LCD panel may be damaged .
NOTES ON CLEANING
-Clean the LCD panel with a slightly damp soft cloth.
-Do not use solvents such as benzine, thinner, commercially available
cleaners or antistatic spray .
-
Do not use alcohol to clean the screen .
If your car was parked in a cold or hot place, the picture may not be clear .
The monitor is not damaged . The picture will become clear the temperature in your car becomes normal .
2
Safety Information
CAUTION:
THIS DVD PLAYER IS A CLASS I LASER PRODUCT. HOWEVER THIS DVD
PLAYER USES A VISIBLE/INVISIBLE LASER BEAM WHICH COULD CAUSE .
HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE
THE DVD PLAYER CORRECTLY AS INSTRUCTED.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.DO NOT OPEN COVERS AND DO NOT
REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
EQUIPMENT TO RAIN OR MOISTURE.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, AND ANNOYING
INTERFERENCE, USE ONLY THE RECOMMENDED ACCESSORIES.
THIS DEVICE IS INTENDED FOR CONTINUOUS OPERATION.
This product incorporates copyright protection technology that is protected
by method claims of certain U.S. Patents and other intellectual property rights
owned by Macrovision Corporation and other rights owners.Use of this
copyright protection technology must be authorized by Macro vision Corporation,
and is intended for home and other limited viewing uses only unless
otherwise authorized by Macrovision Corporation. Reverse engineering or
disassembly is prohibited.
REGION MANAGEMENT INFORMATION:
This DVD Player is designed and manufactured to respond to the Region
Management Information that is recorded on a DVD disc. If the Region number
described on the DVD disc does not correspond to the Region number of this
DVD Player, this DVD Player cannot play this disc.
3
Disc Notes
M
P
Disc formats supported by this
player
P
3
Audio and Video
Disc size 12 cm
Audio and Video
Disc size 12 cm
Audio
Disc size 12 cm
Audio
Disc size 12 cm
DVD
VCD
CD
MP3
M
CD-RW
Discs which cannot be played
unusable) depending on your handle it
and conditions in the usage environment.
Note these scratches are not an
indication of any problem with the player.
Label side
up
Do not touch
the
underside
of the disc
Do not
bend
with this player
DVD-ROM
DVD-R/DVD-RAM
CDV
CD-G
Handling and Cleaning
Dirt, dust, scratches and warping disc
will cause misoperation.
Do not place stickers or make
scratches on discs.
Do not warp discs.
A disc should always be kept in its
case when not in use to prevent from
damaging.
Do not place discs in the following
places:
1.Direct sunlight
2.Dirty, dusty and damp areas
3.Near car heaters
Preparing New Discs with
Spots
A new disc may have rough edges on
its inside and outside edges.If a disc
with rough edges is used, the proper
setting will not be performed and the
player will not play the disc.Therefore,
remove the rough edges in advance
by using a ball point pen or pencil as
shown on the right.To remove the
rough edges, press the si d e of t h e pen
or pencil against the inside and outside
edges of the disc.
4.On the seats or dashboard
Disc Cleaning
Use a dry soft cloth to wipe the surface.
If the disc is quite dirty, use a soft cloth
slightly moistured with isopropyl (rubbing)
alcohol. Never use solvents such as
benzine, thinner or conventional record
cleaners as they may mar the surface of
the disc.
Note:
A disc may become somewhat scratched
(although not enough to make it
4
Wipe the disc from
center
toward the outside
edge
Rough spots
on
outside edge
Rough spots
on inside
edge
Rough
Ball point pen
or pencil
Installation
NOTES:
Choose the mounting location where the unit will not interfere with the normal
driving function of the driver.
Before finally installing the unit, connect the wiring temporarily and make sure
it is
all connected up properly and the unit and the system work properly.
Use only the parts included with the unit to ensure proper installation. The use
of
unauthorized parts can cause malfunctions.
Consult with your nearest dealer if installation requires the drilling of holes or
other
modifications of the vehicle.
Install the unit where it does not get in the driver s way and cannot injure the
passenger if there is a sudden stop, like an emergency stop.
If installation angle exceeds 30 from horizontal, the unit might not give its
optimum
performance.
'
30
Avoid installing the unit where it would be subject to high temperature, such
as from
subject to dust,
DIN FRONT/REAR-MOUNT
This unit can be properly installed either from "Front"(conventional DIN
Front-mount)
screw holes at the sides of
illustrated installation methods.
direct sunlight, or from hot air, from the heater, or where it would be
dirt or excessive vibration.
or "Rear"(DIN Rear-mount installation, utilizing threaded
the unit chassis). For details, refer to the following
5
Installation
SPRING WASHER
PLAIN WASHER
TAPPING SCREW
DASH BOARD
HEX NUT
METAL MOUNTING
STRAP
CONSOLE
SLIDE BRACKET
HOUSING
HEX BOLT
KEY PLATE
PLASTIC COVER
KEY PLATE
If you want to take CHASSIS out of the SLIDE BRACKET HOUSING,
first remove the PLASTIC COVER of the both sides away, then insert
the two KEY PLATE into left and right side of chassis as above illustration.
6
Installation
How To Remove And Install The Front Panel
When detaching or attaching the control panel, be careful not to damage the
connectors on the back of the control panel and on the panel holder.
Detaching The Front Panel
Before detaching the control panel, be sure to turn off the power.
1). Press the release button and the left hand side of the front panel will release.
(FIG. 1)
2). Pull-off the front panel (FIG. 2) and keep the front panel into the case (FIG. 3)
Attaching The Front Panel
1). First insert the right hand side of the front panel into the hollow of the unit .
2). Gently push the left hand side of the front panel until you feel a “ Click” .
and then press the PWR button (2) briefly to switch the device ON.
FRONT PANEL
RELEASE BUTTON
FIG.1
PROTECTIVE CASE
FRONT PANEL
FIG.2
Attaching The Front Panel
FIG.3
FRONT PANEL
FIG.4
7
Panel Angle Adjustment
CHANGING THE CONTROL PANEL ANGLE
When you want to change the viewing angle of the operating unit to play,
you can touch the section on touch screen (or press the button on
the front panel ) repeatedly to select the desired angle as follows:
Angle 1 Angle 2
Angle 4
Angle 3
Caution:
Do not insert your finger behind the control panel.
8
Electric Connection
WIRING CONNECTION
MAIN UNIT
ANTENNA CONNECTOR
IGNITION
SWITCH(B+)
MEMORY
BACK-UP(B+)
GROUND(B-)
ANTENNA
AUTO
RED
YELLOW
BLACK
BLUE
FRONT
Lch SPK.
REAR
Lch SPK.
CHOKE
BOX
FUSE
WHITE/BLACK
GREEN/BLACK
WHITE
GREEN
WHITE
GREEN
YELLOW
AUX(optional)
RCA CABLE
REAR RCA OUTPUT
CABLE (optional)
FRONT RCA OUTPUT
CABLE
(FOR RCA LINE OUT VERSION ONLY)
GREY
GREY/BLACK
VIOLET
VIOLET/BLACK
FRONT
Rch SPK.
REAR
Rch SPK.
(B+)12V
REAR CAMERA SWITCH
(B-)PARKING BRAKE
REAR CAMERA INPUT
VIDEO IN YELLOW
RCH IN RED
LCH IN WHITE
GREY SUBWOOFER
VIDEO OUT 2 YELLOW
COAXIAL OUT BROWN
RCH RED
LCH WHITE
FRONT RCA RED R
VIDEO OUT 1 YELLOW
FRONT RCA WHITE L
Note:
the earth connection cable (parking brake B-) must be connected in order for DVD
pictures to be played back to the monitor. If the cable has not been correctly
connected, the message “PARKING BRAKE” appears on the monitor.
9
Remote Control
DVD/RECEIVERCONTROL
1. CLK
2. MODE
3. STOP
4. SETUP
5. MO/ST(AUDIO)
6. SUBTITLE
LO/DX
7. REPEAT
8. GOTO
9. /
10. SEL
11. VOL+/VOL-
12. / / /
13.MENU
SUB WOOFER
14.BAND(OSD)
15.POWER
16.PLAY/PAUSE
17.MUTE
18.TITLE/PBC
(A/P)
19.
20.ANGLE
21.EQ
22. /
23.ENTER
24. Radio Preset
25. 0-9
26.+10
15
7
2
6
22
11
4
DVD/RECEIVERCONTROL
PLAY/PA USE
MUTE
POWER
17
REPEAT
19
MENU
13
LO/DX
OSD
BAND
14
TITLE /PBC
A/PS
18
VOL
VOL
SEL
10
SETUP
8
STOP
MO/ST
ANGLE
CLK
EQ
MODE
ENTER
TOP
INT
1
3
2
RDM
5 6
4
8
7
9
GOTO
+10
0
16
3
5
20
1
21
23
9
12
24
26
25
Press it briefly to show/hide the clock, press longer to set the time.
Press it to change between RADIO ,DISC and AUX IN mode.
Press it to stop playback. Press PLAY/PUASE to resume playback .
Press it to open the SETUP menu.
In radio mode, press it to select STEREO or MONO mode (In disc
mode,press it to changing of the AUDIO soundtrack on multiaudio soundtrack DVD disc. Changing of the sound mode of the
VCD/CD disc)
Changing of the SUBTITLE language on multi-subtitle language
DVD disc. In radio mode,.Press this button for distance reception
when you are located at weak signal location, depress it for
stronger signal.
Switch the Repeat mode of DVD/VCD/CD/MP3 disc.
Disc search button, cooperatively used with numeric buttons
Press to skip to the next track & press to skip back one track.
(Note: In DVD mode, press continually the twice to skip back one)
Press it repeatedly to change mode through volume ,bass, treble,
balance, fader ,color, bright, contrast and tint modes.
Press it to adjust volume level
In case of the SETUP MENU mode, / / / buttons served as
cursor buttons to select item left/right,ahead/back.
Press it briefly to display the main menu of the DVD/VCD. Press it
long to switch the SUBWOOFER ON and OFF.
Display statistical disc information during playback (To change
the band in radio stations)
Press it to turn on the unit ,press it again to turn off.
In DISC mode, starting playback, stopping picture/track.
Press it to mute down sound.
Display the TITLE menu that is stored in DVD disc changing
between PBC ON and PBC OFF on the VCD disc.(Auto store
and preset scan function in radio stations .)
Press it to change the view angle of the front panel .
Changing of the view angle on multi-angle DVD disc.
Press it to turn to equalization function.
Press to start forward rapidly & to reverse rapidly.
Confirm the Track/Chapter selected with the number key or
selected with the cursor buttons on TV screen.
Six preset memory buttons.
Numeric buttons.
Tens digit select button, cooperatively used with numeric buttons.
10
Remote Control
Preparing the Remote Control
Installing The Lithium Coin Battery
1.First push to inside as the direction indicated by the arrow (See )And then
Remove the battery holder as the direction indicated by the arrow (See ).
2.Replace the battery Set a new battery property with (+)side up as illustrated
(See ).
3
3.Insert the battery holder. Push in the holder to the original position(See ).
1
2
4
CR2025
Using the Remote Control
Face the remote control towards the player front face IR mark (remote control signal
receiver), make sure there is no obstacle in between .
Operation angle: About 30 degree in each the direction of the front of the IR mark.
Warning :
Do not install any battery other than CR2025 or its equivalent;
otherwise , it may explode .
Store the battery in a place where children cannot reach to avoid risk
of accident .
11
Control Panel
Key Functions
Touch Panel
193
14
SWF LUD DSP CLK MOD
VOLUME- SEL VOLUME+
15
11
13
8
REL
5
RESET
CH1-6
MOD
VOL-
VOL+
12
AUX IN
16
Touch Screen Key :
1.SWF :
2.LUD :
3.DSP :
4.CLK :
5. :
6.MOD:
7.VOLUME+ :
8.SEL :
9.VOLUME- :
10. :
subwoofer function
loud function
EQ function (pop/classic/jazz/rock/flat)
clock function
mute function
select input mode
volume adjustment (+)
select the menu of the Sound/Picture
volume adjustment (-)
panel angle adjustment
CAR DVD/VCD/CD/MP3 PLAYERWITH MPEG4
18
12
IR
TOUCHSCREEN
EQ
SEL
A
BND
MU
P
P
S
S
I
D
I
6
4
7
10
217
Control Panel
Unit Keys :
1
3
1814
15
11
13
6
10
12
REL
RESET
CH1-6
MOD
9
16
VOL-
VOL+
AUX IN
CAR DVD/VCD/CD/MP3 PLAYERWITH MPEG4
IR
TOUCHSCREEN
EQ
BND
SEL
MU
A
P
P
S
S
I
D
I
2
717
1.REL BUTTON
Press this button to release the front panel for removal . Refer to see page 6.
2. (POWER On/Off )BUTTON
Press this button to switch the device on. WELCOME appears in the display.
Press it again to switch the device off. SEE YOU appears in the display.
3.VOL+/ VOL- knob
In normal mode, this knob is used to increase or decrease the volume. It is also
used as an UP/DOWN knob when audio or video settings are being adjusted
when accessed using the SELECT button.
4.SELECT KNOB
To access the available adjustment settings for audio and video, press this knob
repeatedly to cycle through and select them:
5
4
8
Volume Bass Treble Balance Fader
Tint Contrast Bright Color BG Color
5. BAND BUTTON
In Radio mode, press this button repeatedly (or the BAND button on the remote
control) to cycle through and select the desired radio band:
FM MW LW
For 3 Bands (Europe)
FM MW
For 2 Bands (Europe)
FM AM
For 2 Bands (USA)
6. EQ BUTTON
Swing the SEL knob briefly in the EQ direction to turn to equalization function
and to select desired audio mode. There are five kinds of mode as below:
POP ROCK CLASSIC JAZZ FLAT
13
Control Panel
7. APS, DISPLAY FUNCTIONS (using the SELECT knob)
Scan Function
In Radio mode, swing the SEL knob briefly in the APS/DISP direction , the radio
briefly plays all the preset stations of the frequency band .
Automatic Preset Setup
In Radio mode, swing the SEL knob in direction of the APS/DISP for approximately
2 seconds to active automatic station storage. The radio searches within the
current frequency band, e.g. Fm1, for the stronger signal level until the search
cycle has finished . The six strongest stations are then allocated to the corresponding storage locations . Then the station of the first storage location is set .
Display ON/OFF Function:
In Disc mode, swing the SEL knob briefly in the direction of APS/DISP to turn off
the display image (the monitor on the unit only) , the sound will stay on.
(Swing it again to resume the playback picture mode.) You can press SEL knob
briefly to select the “BG COLOR” by repeatedly pressing the SEL knob, then
rotate the VOL+/- to select the background color among of the “AUTO,
BG COLOR: 01........BG COLOR: 11”, in “ AUTO” mode, the monitor of unit will
change the background color automatically.
8. MU (MUTE) BUTTON
Press this button briefly to turn off the audio. Press again to restore the volume to
prior level. You can also disable the MUTE function by turning the VOL +/- knob.
9. ANGLE (Screen position)
This button allows you to change the angle of the screen module in four steps.
Press this button repeatedly to cycle through the different positions.
10. /CH 1-6 BUTTON(RADIO PRESET)
a). In Disc Playback Mode
Press this button to pause playback, press it again to resume playback.
b). In Radio Mode
Press this button repeatedly to preset station. With this system a total of 30
stations can be stored in the memory .
The operation as below:
- store in memory
press and hold the desired memory location for several seconds, the current
listening station will be stored into the number location.
- retrieve a preset station
press it button repeatedly to retrieve a station which had been stored in the
memory in advance the chosen number is shown on display.
11. / BUTTONS (TUNE, SEEK, TRACK, SKIP UP/DOWN)
a) In DISC, USB mode:
if you wish to jump forwards or backwards press the SEL button (4) briefly in
the or direction. (Note: in DVD mode, press the SEL button continually
twice in direction to skip back one track during playback.)
To wind through the tracks keep the SEL button pressed in the or direction
for about 2 seconds. FF X2 appears in the display. Operating the SEL button
again,
14
Control Panel
the speed of rapid forward/reverse changes according to the disc
as follow:
Normal Playback 2x 4x 8x 16x
DVD/VCD/CD/MP3:
b) In Radio Mode:
Move the SEL button in the direction of or in order to set a radio station
manually. Keep the SEL taste pressed down in the or direction in order to
start the search for a radio station automatically.
12. MODE BUTTON
Use this button to select an input mode by pressing repeatedly until the proper
one is found: AUX IN > RADIO > DISC
If you are in USB Playback mode and want to select DISC mode, press the STOP
button and then the GO TO button.
13. (EJECT) button
To insert a disc, press this button. The panel will swing downward, exposing the
slot. Insert the disc, label side facing up, until the mechanism senses its presence
and draws the disc in. The panel will automatically return to its previous position.
14. RESET button
Press this button can return to the original setup .
15. IR sensor
16. AUX INPUT JACK
For information about connecting a AUX device, please see page 31 .
17. USB PORT
For information about connecting a USB device, please see page 31.
18. TFT Display (liquid crystal display)
The operation of the TFT, please see page 17.
15
Basic Operation
Power ON/OFF
Press it button on front panel or
on the remote to switch the
device ON or OFF .
Ejecting The Disc
Use your singer touch the “ ”
range on touch screen , the
control panel of the unit will
swing downwards .Then you can
insert the disc or eject the disc .
(You can also press the “ ” button on
the front panel to eject the disc or insert
the disc to start play . )
Select Sources
Touch the “ MOD ”
MOD
DISC TUNER AUX IN
repeatedly
section on screen the signals
will display in the screen
as follow :
Volume Adjusting
Volume button
A
Revolve : clockwise to increase /
Anticlockwise to decrease .
B
Press the VOL+/- on remote control ,
to change the volume level .
Touch screen
VOLUME+
Touch the screen the
VOLUME+ section to
increase volume level .
VOLUME-
Touch the screen the
VOLUME- section to
decrease volume level .
Mute Function
Use your finger touch the
“ ” section , it will mute
the sound but the disc
continues playing.
Touch it again to resume .
Setting The Clock
CLK
Touch it again, the minute will flash, then
use the VOL+/- to adjust .
Touch the CLK section on the
screen and hold for about 2
seconds the hour will flash ,
rotate the VOL+/- to adjust .
Setting The Buzzer ON/OFF
Buzzer
Touch the SEL section on the
touch screen to select the
BUZZER item, and then touch
the VOL+/- (or rotate the vol+
/vol-) to switch the BUZZER
ON/OFF .
Adjusting the panel angle
Touch section on the
the “ ”
touch screen to
change the viewing angle of
the operating unit .
(You can also press the button on the
front panel to change the angle . Refer
to see page 8 .)
repeatedly
16
Basic Operation
TFT Monitor Adjustment
During DISC playback, use your
SEL
finger touch briefly the SEL
section on the screen (or press
SEL knob on the front panel
to across the Picture
mode
selection menu, by repeatedly touch the
SEL section, and then touch the VOL+/(or rotate the VOL+/-) to adjust the
selected mode .
(The corresponding value will show on
the monitor )
Volume Bass Treble Balance
Tint
Contrast Bright Color
COLOR 16
SWF LUD DSP CLK MOD
VOLUME- SEL VOLUME+
)
FadeBuzzer
Rear View Camera
When connecting the rear view camera.
the mirror image of the rear view through
the rear view camera is automatically
displayed on the monitor when you
change the gear to the back position.
(The monitor on the unit only.)
Audio Quality Adjustment
During DISC playback, use your
SEL
finger touch briefly the SEL
section on the screen (or press
to across the Sound mode selection
menu, by repeatedly touch the SEL
section, and then touch the vol+/(or rotate the vol+/-) to adjust the
selected mode . (The corresponding
value will show on the monitor )
Volume Bass Treble Balance
SEL knob on the front panel )
Tint
Contrast Bright Color
FadeBuzzer
touch to select
touch to adjust
ADJUSTABLE ITEMS:
COLOR: 0 to 32
Adjust the color fo the picture-lighter or
darker.
BRIGHT:0to32
Adjust if the picture is too bright or
too dark.
CONTRAST: 0 to 32
Adjust the contrast of the bright and dark
portion.
TINT:0to32
Adjust the tint if the human skin color is
unnatural.
-Adjustable when NTSC is selected for
NTSC/PAL .
““
““
BASS 03
SWF LUD DSP CLK MOD
VOLUME- SEL VOLUME+
touch to select
touch to adjust
(It`s depend on your habit to setup the data .)
ADJUSTABLE ITEMS:
Volume:
Adjust volume level by using VOL +/-.
Bass:
Adjust bass level by using VOL +/-.
Treble:
Adjust treble level by using VOL +/-.
17
0to32
-14 to +14
-14 to +14
Basic Operation
Balance:
R10 to L10
Adjust sound balance between left
and right speakers by using VOL + / -
Fader:
F10toR10
Adjust sound balance between front and
rear speakers by using VOL + / VOL - .
Setting Audio Modes
Touch the screen the DSP range
DSP
(or press the EQ button on the
front panel ) to select one of the
preset sound modes
(Rock/Pop/Jazz/Classic/Flat) .
The information will display in the
monitor as follow :
POP
ROCK
FLAT
ROCK
SWF LUD DSP CLK MOD
VOLUME- SEL VOLUME+
JAZZ
CLASSIC
front panel to ahead/back (proceed/
cancel) , and then press the SETUP
button briefly to confirm .
.
(Press it button longer again to renew . )
FM1 106.30 MHz
ST
DX
LUD
SWF
POP
DISC
11:08AM
Alternate Audio/video Source
Following the diagram below, to
connect analogue replay devices. Use
this jack to replay sound of other replay
equipment such as DVD players,
computers, etc. Via the loudspeakers.
1).Please connect the external device
with stereo jack(black end) plug the
Aux in socket of the unit .
2).Press the MOD button to select the
AUX IN connection.
3).With the buttons on the external
device to operate the item of the playing.
Headphones port
touch to select
It`s depend on your habit to select the Audio mode .
Scroll Caption Adjustment
In Radio mode:
You can adjust your desired scroll
caption , the method of the operation
as follow:
a). Press and hold the SETUP button
(for about 2 seconds) on the remote
control, the adjustment scroll bar
will display on the screen .
b). Use the VOL+/- to select among of
the “A, B, C ....X, Y, Z, and blank ”,
and use the / button on the
18
Black
( connect cable)
AUX IN
POP
SWF
SWF LUD DSP CLK MOD
VOLUME- SEL VOLUME+
touch to select
DISC
MENU
White
11:08AM
Radio Operation
Listening to the Radio
Switching To Radio Mode
Repeatedly Touch the MOD
MOD
section on the touch screen to
select the RADIO mode.
(You can press the MOD button
on front panel to select the
Radio mode .)
the following information will appears on
the monitor :
FM1 87.5 MHZ
ST
SWF
123 MOD
DISC-IN
DX
POP
64 5 BND
Selecting The Frequency Band
Touch the BND section on the
BND
touch screen repeatedly to
select the band , screen band
will show in turn :
You can also press the BND on front
panel repeatedly to select the band .()
FM1 FM2 FM3
AM2(MW2) AM1(MW1)
Start Searching For a Station
Manual Search
Touch briefly the “ ” section on
the screen (or swing briefly the
SEL knob in direction) to
increase frequency by one step
of channel spacing .
Touch briefly the “ ” section on
the screen (or swing briefly the
SEL knob in direction) to
decrease frequency by one step
of channel spacing .
CH
11:08AM
6
Automatic Search
During Radio mode, swing and hold
(for about 2 seconds )the SELknob in
/ direction (or touch the /
section long) to start search for a radio
station automatically .
Storing Stations In Memory
Setting Memory
Press the /CH 1-6 button repeatedly
on the front panel to preset stations at
radio mode . Or touch the screen the
1/2/3/4/5/6sections()
FM1 98.10 MHZ
ST
SWF
123 MOD
DISC-IN
DX
POP
64 5 BND
Touch to preset station
With this system, a total of 30 stations
can be stored in the memory of six
buttons. Each band stores up to six
preset stations. The stations might be
FM1, FM2, FM3, AM1(MW1), and
AM2(MW2) band.
The operation is as below :
-Store in Memory
Touch and keep the 1-6 sections
(or press and hold the /CH 1-6) for
about 2 seconds, the current listening
station will be stored into the
number location .
-Retrieve a preset station
Touch the 1-6 sections briefly (or press
the /CH1-6 button repeatedly) to
retrieve a station which had been stored
in the memory in advance the chose
number is shown on display .
19
CH
6
11:08AM
Radio Operation
Automatic Memory Storing &
Program Scanning
Automatic Preset Setup
In Radio Mode, Touch the APS
APS
section and keep on the touch
screen(or swing the SEL knob in
direction of the APS/DISP) for
about 2 seconds to active automatic
station storage. The radio searches
within the current frequency band,
e.g. FM1, for the stronger signal level
until the search cycle has finished .
The six strongest stations are then
allocated to the corresponding storage
locations . Then the station of the first
storage location is set .
Scan Function
APS
In Radio mode, touch the APS
section or swing the SEL knob
briefly in the APS/DISP direction ,
the radio briefly plays all the preset
stations of the frequency band .
FM1 98.10 MHZ
ST
DISC-IN
DX
SWF
POP
123 MOD
64 5 BND
CH
11:08AM
6
Mono/Stereo Function
ST
In Radio mode, touch the ST
section on screen (or press MO/ST
button on remote ) to select mono
or stereo mode. you can sometimes
improve reception of distant stations by
selecting mono operation .
Loud Function
Touch the LUD section on the
LUD
touch screen to switch the
LOUND ON or OFF.
EQ Function
Touch the DSP section repeatedly
DSP
on the touch screen to select the
EQ (pop/rock/jazz/classic/flat)
Select Audio Mode
Touch the SEL section repeatedly
SEL
on the touch screen to select the
desired item(volume/bass/treble/
balance/fader)
Select BG Color Function
Touch the SEL section briefly on
SEL
the touch screen to select the
“BG Color” by touching repeatedly
the SEL knob , then touch the
VOL+/- (or rotate the VOL+/- on
the front panel) to select your
desired Background Color .
Touch it to select the other item .
Rock 03
SWF LUD DSP CLK APS
VOLUME- SEL VOLUME+
ST
Mute Function
Use your finger touch the “ ”
section , it will mute the sound
but the disc continues playing.
Touch it again to resume .
Buzzer Function
Touch the SEL section on touch
SEL
screen repeatedly to switch the
Buzzer ON or OFF by using the
VOL+/- .
20
DISC Operation
Basic Operation
During the DISC playback, use the
finger touch the touch screen , it
display will following :
132456
MOD
VOL-
SEL
VOL+
879101112
1.previous
2.next
3.pause
4.stop
5.mute
6.mode
Switching the DVD mode
MOD
Touch the MOD section on the
touch screen (or press MOD
button ) to select the DISC mode,
it display like following :
DVD 11-0:44:36
7.To next page
8.eject
9.vol+(adjustment +)
10.select
11.vol-(adjustment -)
12.panel angle change
VOL-
SEL
VOL+
MOD
Skipping Track
During DISC playback, Touch the
section on the touch screen to
skip to next track. (You can also
swing the SEL knob in direction
to skip to next track.)
During DISC playback, Touch the
section on the touch screen to
skip to back one track .( You can
also swing the SEL knob in
direction to back one track .)
NOTE :
1. In DVD mode, touch the section
continually twice to back one track .
2. For some VCD2.0 disc (PBC-playback
control), above these buttons may be
unavailable .
Rapid Forward/Rapid Reverse
During DISC playback, Touch and
hold (for about 2 seconds )the
/ section on the touch screen
(or swing the SEL knob in /
direction on front panel and hold
for a more than 2 seconds)
the speed of rapid forward/reverse
changes according to the disc as
follow:
DVD/VCD/CD/MP3:
Normal Playback 2x 4x 8x 16x
Function setup
(different the source the display is different)
Stopping Play
Touch the screen the range (or
press the button on remote
control .) To stop the unit playback.
Touch the section or press
button on front panel to start play.
Pause (still picture)
Touch the “ ” section on touch
screen during playback will stop
play temporary, touch it again to
return the normal playback .
Zoom Function
ZOOM
Repeatedly touch the section of
the ZOOM, the displaying rate can
be 1x, 2x, 3x, 1/2, 1/3, 1/4 .
21
DISC Operation
Mute Function
Touch the “ ” section on touch
screen (or press the MU button on
front pane) during playback will
mute sound but the disc continues
playing . Touch it again , sound will
resume .
DVD 11-0:44:36
ENT
Selecting The Play Modes
DVD 11-0:44:36
VOL-
Touch the section , it display will
following as below :
DVD 11-0:44:36
SWF LUD DSP CLK
RDM INT OSD
Touch the section , it display will
following as below :
DVD 11-0:44:36
SUBTITLE
Touch the section , it display will
following as below :
SWF
SWF
GOTO
SWF
POP
VOL+SEL
POP
POP
AUDIO
DISC-IN
11:08AM
MOD
DISC-IN
11:08AM
ZOOM
RPT
DISC-IN
11:08AM
SET
TITLE
Above these operation cursor buttons
for DVD setup.
Touch it for previous .
1). Repeat Function
FOR DVD :
RPT
Touch the screen “ RPT ” section
(or press longer RPT on remote
control) to select REPEAT mode
as follow :
CHAPTER REPEAT ON TITLE REPEAT ON
REPEATALL
FOR VCD/CD/MP3 :
Touch the screen “ RPT ” section
RPT
(or press longer RPT on remote
control) to select REPEAT mode
as follow :
REPEAT ONE REPEATALL
REPEAT OFF
1. Continuously repeat at the current
chapter/track, when selected REPONE mode .
2. Select REP-ALL mode to continuously
repeat all chapter/track on the
current disc .
22
DISC Operation
2). RDM(RANDOM) Function
During DISC playback, Touch the
RDM
RDM section ( press the 4/RDM
button longer on remote control
to play in random. Each playing,
the order is different .
(depend on the disc used for VCD).
3). INT Function
FOR CD :
Touch the screen the INT section
INT
(or long press the 3/INT button on
the remote to play the previous 6
seconds part of each track/chapter
on disc.
FOR VCD :
Touch the screen the INT section
INT
(or long press the 3/INT button on
the remote ).it display will
following menu as below :
(touch it again to cancel this function .)
SELECT DIGEST TYPE:
TRACK DIGEST
DISC INTERVAL
TRACK INTERVAL
Use the UP, DOWN, LEFT and RIGHT
arrows on the touch screen (or on the
remote) to select the item, and then
touch the ENT to confirm .
FOR DVD :
Touch the screen the INT section
INT
(or long press the 3/INT button on
the remote ). it display will
following menu as below :
(touch it again to cancel this function .)
SELECT DIGEST TYPE:
TITLE DIGEST
CHAPTER DIGEST
TITLE INTERVAL
CHAPTER INTERVAL
Use the UP, DOWN, LEFT and RIGHT
arrows on the touch screen (or on the
remote) to select the item, and then
touch the ENT to confirm .
NOTE :
The 3/INT button is not available.
DISC Search (GOTO)
DVD 11-0:44:36
SUBTITLE
GOTO
Touch the GOTO section , it display will
following as below :
Title 01 /01 , Chapter --/15
0
FOR DVD :
GOTO
Touch the screen the GOTO range
(or press GOTO on the remote ).
Twice, the screen will display the
following message :
Title 01/01 Time -:--:--
0:10:36
You can select the item you want to
watch through TIME setting by using
numberic buttons . (E.x. 0:10:36)
FOR VCD (With PBC OFF):
GOTO
Touch the screen the GOTO range
(or press GOTO on the remote ).
Once, the screen will display the
following message :
Use the numberic buttons to input the
time directly (E.x. : 0:00:36)
Note:
Touch and hold the / section on
the touch screen , you can select the
title or chapter of DVD . (Only for the
DVD with title /chapter.)
23
DISC-IN
SWF
POP
8
SET
TITLE
4
9/
AUDIO
GOTO
123
7/
6
Disc Go To -:--:--
0:00:36
7/
11:08AM
5
+10
9/
DISC Operation
ON-SCREEN DISPLAY FUNCTION
During playback, touch the screen
OSD
the OSD section (or press the OSD
on the remote), it will display the
following as below :
1. DVD:
A.Touch or Press for first time:OSD
TITLE ELAPSED
TT 01/01 CH 01/38 0:02:06
Title Number, Total Title Number,
Chapter Number, Total Chapter Number
of this Title of the disc currently being
played will be shown on the screen,
along with the elapsed time.
B.Touch or Press for second time:OSD
TITLE REMAIN
TT 01/01 CH 01/38 3:24:36
C.Touch or Press for hird time:OSD
2.Example for VCD/SVCD/CD:
A.Touch or Press for first time:OSD
SINGLE ELAPSED
TRACK 01/16 0:00:56
B.Touch or Press for second time:OSD
SINGLE REMAIN
TRACK 01/16 0:05:20
C.Touch or Press for hird time:OSD
TOTALELAPSED
TRACK 01/16 0:31:32
D.Touch or Press for fourth time:OSD
TOTALREMAIN
TRACK 01/16 0:36:26
CHAPTER ELAPSED
TT 01/01 CH 01/38 0:02:56
D.Touch or Press for fourth time:OSD
CHAPTER REMAIN
TT 01/01 CH 01/38 0:04:32
E. Touch or Press for fifth time:
OSD
The message on the screen will be
cleared.
E.Touch or Press for the fifth time:
OSD
The message on the screen will be
cleared for SVCD and VCD.
NOTE:
For CD and MP3,the message will
always display on the screen.
3.Example for MP3:
Each time is pressed or touch , the
OSD
message displayed on screen changes
as follows:
SINGLE ELAPSED SINGLE REMAIN
24
DISC Special Functions
DVD/VCD Special Function
DVD 11-0:44:36
SWF
SUBTITLE
GOTO
1. Multi-subtitle Language
Function (for DVD Only)
SUBTITLE
During DVD playback. Touch
the SUBTITLE section on touch
screen(or press the SUBTITLE
on the remote) . Each time the button is
pressed or touch, number of the subtitle
language changes in sequential order.
Notes:
- The language number is different
according to the disc.
- Some discs only contain one subtitle
language.
- When no different subtitle language
are recorded, will be displayed
at screen left top corner.
2. Multi-Audio Language Function
AUDIO
For DVD:
During DVD playback , touch
the AUDIO section on touch
screen (or press the AUDIO
on the remote .) Each time the button is
pressed or touch , number of the audio
soundtrack language changes on
sequential order.
Notes:
- The language number is different
according to the disc.
- Some disc only contain one language
soundtrack
- When no different language
soundtrack are recorded will be
display at screen left top corner.
POP
AUDIO
DISC-IN
11:08AM
SET
TITLE
For VCD/CD:
during playback, touch the
AUDIO
section of the touch screen or Press
AUDIO
on the remote . It is possible to
switch the sound between monaural and
stereo sound.
MONO LEFT MONO RIGHT
STEREO
MIX-MONO
3. Multi-Angle Function
(for DVD Only)
During DVD playback, touch the
section or Press ANGLE button
on the remote . Each time the
button is pressed or touch , number
of the angle changes in sequential
order.
Notes:
- The angle number is different
according to the disc.
- The function only work for disc having
scenes recorded at different angles.
- When no different angle are recorded,
will be displayed at screen left top
corner.
4. Title Menu Function
TITLE
For DVD:
If the DVD has multiple titles
recorded on the disc. It can select
preferred title from the title menu
to start playback.
- During DVD playback, Touch the
section or press TITLE button on the
remote .The title menu is display.
- touch the cursor button shown in TV
screen, select preferred title by the
cursor button and confirmed by touch
ENT button .
ENT
Touch to select
For VCD:
TITLE/PBCPress button on the remote
control while the disc is playing, you can
switch between "PBC on"and "PBC off"
mode.
25
TITLE
Setup
USING THE MENU
DOLBY
....GENERAL SETUP PAGE....
TV Display
Angle Mark
OSD Lang
Spdif Output
Captions
Screen Saver
Last Memory
Go To General Setup Page
1. Touch the section of DVD setup
SET
LB
ON
ENG
SPDIF/RAW
ON
ON
ON
on touch screen (or press the SETUP
on the remote .)
2.The SETUP menu is displayed.
3.Select the preferred item by touch the
/ / / range on the screen
or by using the / / / buttons .
4.Touch the ENT section on screen or
Press ENTER button on remote to
confirm .
The Following Buttons For Entering
The Selection .
ENT
Previous
Enter
Up
Down Left
Right
The buttons of the left and right are for
selection of setting type .
The buttons of the up and down are for
selection of the setting program .
Touchto select
Overview Of The Main Menu
DOLBY
()1 ()2 ()3 ()4
(1).General Settings
(2).Speaker Settings
(3).DOLBY Digital Settings
(4).Preference Settings
GENERAL SETUP
TV Setting
DOLBY
....GENERAL SETUP PAGE....
TV Display
TV Display
Angle Mark
OSD Lang
Spdif Output
Captions
Screen Saver
Last Memory
Set TV Display Mode
16:9
4:3 Pan Scan
1.TV DISPLAY SETUP
This is to select the appropriate TV
aspect (4:3 or 16:9) according to the
connected TV set.
Normal/PS (For 4:3 TV)
Played back in the PAN & SCAN style.
(If connected to wide-screen TV, the
left and right edges are cut off.)
Normal/LB (For 4:3 TV)
Played back in LETTER BOX style.
(If connected to wide-screen TV, black
bands appear at top and bottom of the
screen.)
Wide (For 16:9 TV)
Select when a wide-screen TV set is
connected.
26
Normal/PS
Normal/LB
Normal/LB
Wide
4:3 Letter Box
Setup
GENERAL SETUP
DOLBY
....GENERAL SETUP PAGE....
TV Display
Angle Mark
Angle Mark
OSD Lang
Spdif Output
Captions
Screen Saver
Last Memory
Set Angle Mark
ON
ON
OFF
2.ANGLE MARK DISPLAY SETUP
If it is set to ON, when the multi-angle
DVD disc is playing, (the angle
mark) will appears on the screen; if is
....GENERAL SETUP PAGE....
TV Display
Angle Mark
OSD Lang
OSD Lang
Spdif Output
Spdif Output
Captions
Screen Saver
Last Memory
Setup SPDIF
4.SPDIF OUTPUT
This is to activate the audio output
from SPDIF OFF mode to SPDIF/RAW
mode to SPDIF/PCM mode.
set to OFF, the mark will not appear.
LANGUAGE DISPLAYING SUBTITLES HIDING
DOLBY
....GENERAL SETUP PAGE....
TV Display
English
Angle Mark
OSD Lang
OSD Lang
OSD Lang
Spdif Output
Captions
Screen Saver
Last Memory
English
French
German
Spanish
Italian
Portuguese
....GENERAL SETUP PAGE....
TV Display
Angle Mark
OSD Lang
Spdif Output
Captions
Captions
Screen Saver
Last Memory
DOLBY
SPDIF OFF
SPDIF/OFF
SPDIF/RAW
SPDIF/PCM
DOLBY
ON
ON
OFF
Set OSD language
3.OSD LANG TYPE SETUP
Touch the / section on the touch
screen or press the / button on
the remote to select the preferred
OSD language , then touch the ENT
section to confirm .
Closed Caption
5.CAPTIONS SETUP
Activate the CAPTIONS feature by
selecting ON. And release this feature by selecting OFF.
27
Setup
GENERAL SETUP
DOLBY
....GENERAL SETUP PAGE....
TV Display
Angle Mark
OSD Lang
Spdif Output
Captions
Screen Saver
Screen Saver
Last Memory
Screen Saver
6.SCR SAVER SETUP
Select the SCR SAVER output
ON/OFF.
....GENERAL SETUP PAGE....
TV Display
Angle Mark
OSD Lang
Spdif Output
Captions
Screen Saver
Last Memory
Last Memory
Set Last Memor y State
7.LAST MEMORY SETUP
Select the LAST MEMORY output
ON/OFF.
DOLBY
ON
ON
OFF
ON
ON
OFF
SPEAKER SETUP
.....Speaker Setup Page.....
DOLBY
....Speaker Setup Page....
DOWNMIX
DOWNMIX
Set Downmix Mode
LT/RT
STEREO
STEREO
This is to activate the audio output from
DOLBY AC3 5.1 DOWNMIX to 2 channel
mode. Select the preferred SPEAKER
connection by using the cursor buttons.
Select the LT/RTto activate the Dolby
surround compatible output.
Select the STEREO to activate simple
stereo mode.
DOLBY DIGITAL SETUP
DOLBY
....DOLBY Digital Setup....
FULL
DOWNMIXDYNAMIC
Set DRC OFF
DYNAMIC RANGE CONTROL
Select DRC and adjust the dynamic
range of a Doby Digital encoded
program. There are 8 steps between
full compression and off compression.
6/8
4/8
2/8
OFF
28
Setup
--- PREFERENCES PAGE ---
DOLBY
DOLBY
....Preference Page....
TV Type
TV Type
Audio
OSD Lang
Subtitle
Disc Menu
Parental
Password
Default
Set TV Standard
PAL
AUTO
NTSC
NTSC
1.TV TYPE SETUP
This player can play discs recorded
in either PAL or NTSC format.Select
NTSC format, when you connected to
NTSC TV.Select PAL format, when
you connected to PAL TV.Select AUTO
format, the player TV output format
will according to the DVD disc format..
DOLBY
....Preference Page....
TV Type
Audio
Audio
OSD Lang
Subtitle
Disc Menu
Parental
Password
Default
Preferred Audio Langua ge
English
English
French
German
Spanish
Italian
Portuguese
....Preference Page....
TV Type
Audio
OSD Lang
Subtitle
Subtitle
Disc Menu
Parental
Password
Default
Preferred Subtitle Language
English
French
German
Spanish
Italian
Portuguese
Off
Off
3.SUBTITLE LANGUAGE SETUP
Select the preferred SUBTITLE
language by using the cursor buttons.
DOLBY
....Preference Page....
TV Type
English
Audio
OSD Lang
Subtitle
Disc Menu
Disc Menu
Parental
Password
Default
Preferred Menu Language
English
French
German
Spanish
Italian
Portuguese
2.AUDIO LANGUAGE SETUP
Select the preferred AUDIO soundtrack by using the cursor buttons.
4.DISC MENU LANGUAGE SETUP
Select the preferred DISC MENU
language by using the cursor
buttons.
29
Setup
--- PREFERENCES PAGE ---
Age control
DOLBY
DOLBY
....Preference Page....
TV Type
Audio
OSD Lang
Subtitle
Disc Menu
Parental
Parental
Password
Default
4PG13
5PGR
6R
7NC 17
8ADULT
8ADULT
OFF
Set Parental Control
5.PARENTAL
Select suitable parental guidance by
the cursor buttons and conformed by
pressing ENTER button.
DOLBY
....Preference Page....
TV Type
Audio
OSD Lang
Subtitle
Disc Menu
Parental
Password
Password
Default
Changed Password
CHANGE
CHANGE
6.PASSWORD
Select the change and press ENTER
button. Type the old password (The
initial factory code is ) and key
in 4 characters password now you
want to use, and retype again to
confirm key in correctly.
1379
....Preference Page....
TV Type
Audio
OSD Lang
Subtitle
Disc Menu
Parental
Password
RESET
Default
Default
RESET
Load Factory Setting
7.DEFAULTS
Select reset to become factory initial
setting.
DEFAULTS TABLE
GENERAL SETUP
SPEAKER SETUP
DOLBY DIGITAL
PREFERENCES
TV DISPLAY
ANGLE MARK
OSD LANGUAGE
SPDIF OUPUT
CAPTIONS
SCR SAVER
LAST MEMORY
DOWNMIX
DYNAMIC
TV TYPE
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
NORMAL/LB
ON
ENGLISH
SPDIF/RAM
ON
ON
ON
STEREO
OFF
AUTO
ENGLISH
OFF
ENGLISH
8 ADULT
1379
30
Other Main Operation
USB Operation (17)
Following the diagram below, connect
your USB device to the front panel
USB port . If it is properly connected,
the device will be mounted and start
playing automatically.
USB port
(USB connect line)
you can also select the desired item of
the USB device The buttons on the
remote control, on the device, have the
same functions as the touch buttons
of this touch screen have .
In USB Playback mode
Use the UP, DOWN, RIGHT or LEFT
buttons to navigate to and select files
to play, and press ENTER to begin
playback (or viewing, in the case of
JPEG files). To skip to the next or
last track, touch or press the or .
Press the or buttons for Fast
Forward or Fast Reverse playback.
REPEAT
by repeatedly pushing until
the desired mode is found.
Changing From USB to DISC Playback
Modes
If you are in USB Playback mode and
wish to begin playback of a disc already
in the player, touch the range on the
touch screen or press the STOP on the
remote once. Then touch GOTO range
on the screen or press the GOTO on the
remote and the player will switch to
DVD/VCD/CD/MP3 Playback mode.
Changing From DISC to USB Playback
Modes
If the disc present in the player is an
MP3 disc, touch section on screen
or press the STOP on remote once then
touch or press the GOTO to USB
playback.
.
play modes are also available
REPEAT
If the disc present in the player is an
DVD or VCD or CD disc, touch on
the screen or press STOP twice on the
remote then touch GOTO section on
the screen or press the GOTO button
on the remote to USB playback.
Important Note:
To prevent damage to the USB device,
do not remove or disconnect it during
playback. it is also a good practice to
remove the USB drive during disc
playback.
AUX Operation
To connect analogue replay devices.
Use this jack to replay sound of other
replay equipment such as DVD players,
computers, etc. Via the loudspeakers.
AUXIN
AUX Socket
1). Please connect the external device
with stereo jack plug the Aux in socket .
2). Touch the MOD section on screen
or press the MOD button to select the
AUX IN connection. It will display the
following as below :
AUX IN
POP
SWF
SWF LUD DSP CLK MOD
VOLUME- SEL VOLUME+
Touch to select
3). Touch the volume+/- sections on
touch screen or rotate the VOL+/- on
the remote to adjust the volume level.
31
DISC
11:08AM
Other Main Operation
MP3/WMA/JPEG/MPEG4 DISC PLAY
1.When inserting an MP3/WMA/JPEG/MPEG4 disc.
Ex: When MP3 file is detected.
56
4
3
003/112
2
Mp3
Mp3
1
Mp3
..............
00:56 04:07
K
P
woman
new
ton
Repeat one
1
Touch the screen, it will display the following as below :
when the parking brake is applied .()
1
.Current track(file)(highlighted bar)
.Current track (file) number/total
2
number of tracks(files) in the current
folder.
.Elapsed playing time of the current
3
4
not available for JPEG disc)
track(
.total playing time.
( not available for
JPEG disc)
.Operation mode icon. (Play),
5
(stop), (pause), (forward)
(reverse).
.Selected playback mode
6
MP3 01-0:44:36
VOL-
SWF
POP
DISC-IN
VOL+SEL
11:08AM
MOD
Touch to select
MP3 01-0:44:36
ENT
Touch the / / / sections on touch screen (or Use / / / on remote
control ) to select the item or folder, then touch the ENT section or press ENTER
button on remote to confirm.
Touch the RPT on the touch screen (or Pressing REPEAT button on the remote)
repeatedly can select two kinds of repeat play mode.
REP-ONE:
Play the same song over and over again.
REP ALL:
Play all songs in the discover and over again.
In the playback, touch the or section to skip an item ahead or back.
In the playback, touch and hold the / sections on touch screen for about 2
seconds to rapid forward/reverse .
(You can also swing the SEL knob in the direction of / button on the front
panel and keep more than 2 seconds or short press on the remote control
/
to rapid forward/reverse.)
32
Specification
Supply Voltage: 12V DC (11V-15V)
Current Consumption: Less than10 A
Signal System: Compositive video 1.0Vp-p 75
Discs Played: (1)DVD-VIDEO Disc
5"(12 cm) single-sided, single-layer
5"(12 cm) single-sided, double-layer
(2)Compact Disc (CD-DA, VIDEO CD)
5"(12cm) disc
Audio Signal Output: 2ch&4ch line out
Characteristics: (1)Frequency Response 20 Hz - 20 KHz
(2)S/N Ratio 90 dB (JIS)
(3)Wow and Flutter Below measurable limits
For 3 Bands For 2 Bands For 2 Bands
(Europe) (Europe) (U.S.A.)
FM FM FM
Frequency Coverage: 87.5 to108 MHz 87.5 to108 MHz 87.5 to107.9 MHz
IF: 10.7 MHz 10.7 M z 10.7 MHz
Sensitivity (S/N = 30 dB): 15
Frequency Coverage: 522 to1620 KHz 522 to1620 KHz 530 to1710 KHz
IF: 450 K z 450 KHz 450 KHz
Sensitivity (S/N = 20 dB): 40 dBu 40 dBu 40 dBu
Frequency Coverage: 144 to290 KHz
IF: 450 KHz
Sensitivity (S/N = 20 dB): 45 dBu
dBu 15 dBu 15dBu
MW MW AM
H
LW(Optional)
H
Monitor Screen Size: 4.3 Inch Wide
Number of Pixels: 480 X 3(RGB) X 272 pixels
Color System: NTSC/PAL
NOTE: Specifications and design are subject to modification, without notice,
due to improvements in technology.
33
Trouble Shooting
Before going through the check list, check wiring connection. If any of the problems
persist after check list has been made, consult your nearest service dealer.
SYMPTOM CAUSE SOLUTION
If the power supply is properly
connected to the car accessory
terminal,switch the ignition key
"ACC"
to
Replace the fuse
Remove the disc in the player,
then put a new one
Insert the compact disc with
the label facing upward
Clean the disc or try to play a
new one
Cool off or until the ambient
temperature return to normal
Please switch to correct color
system from menu
Make proper connection
according to wire connection
For safety reasons no television
/video images are displayed while
the vehicle is moving.
Engaging the parking brake will
cause images to be displayed.
Please the television mode of
the choice accommodation
Change the disc
Change the disc
Record JPEG files using a
compliant application
Press the RESET button.
Front panel is not properly fixed
into its place
Insert the antenna cable firmly
Select a station manually
“”
No power
Disc can not be
loaded or ejected
Television/video
imageappears
black-white
No television/video
image appears
No color in picture
JPEG disc can
not be played
back
The operation keys
do not work
The radio does not
work
The car ignition switch is
not on
The fuse is blown
Presence of disc inside the
player.
Inserting the disc in reverse
direction
The disc is extremely dirty
or defective
Temperature inside the car
is too high
The color system is
set incorrectly
The unit is not connected
to the parking brake
detection switch
The parking brake is not
engaged
The disc format is not
accordingto the TV-set
used (PAL/NTSC)
No JPEG files are recorded
on the disc.
JPEG files are not recorded
in a compliant formant
The built-in microcomputer
is not operating properly
due to noise
The antenna cable is not
connected
The signals are too weak
34
Loading...
