VIDEO CASSETTE PLAYER
MODEL NO.:PLVCP
OPERA TING INSTRUCTIONS
BEFORE OPERATING THIS UNIT, PLEASE THOROUGHLY READ THIS
MANUAL, AND RETAIN IT FOR FUTURE REFERENCE.
A
N
I
N
D
E
P
E
N
D
E
N
T
L
A
B
O
R
A
T
O
R
Y
•
T
E
S
T
I
N
G
F
O
R
P
U
B
L
I
C
S
A
F
E
T
Y
•
R
This instrument is listed by Underwriter’s
Laboratories, Inc. It is designed and manufactured to
meet rigid U.L. safety standards against X-radiation,
fire, casualty and electrical hazards.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE THE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
DRAWING YOUR ATTENTION
Thank you purchasing this VCP, developed to provide advanced features and functions for high quality performance.
To obtain the best results and to avoid malfunction, PLEASE CAREFULLY READ THE DESCRIPTIONS AND OPERATING
PROCEDURE CONTAINED IN THIS OWNER’S MANUAL PRIOR TO OPERATING THIS VCP.
CAUTION : To prevent electric shock do not use this (polarized) plug with an extension cord, receptacle or other
outlet unless the blades can be fully inserted to prevent blade exposure.
WARNING : TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
The lightning flash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
RISK OF ELECTRIC SHOCKS
DO NOT OPEN
CAUTION
AVERTISSEMENT : POUR PRÉVENIR LES RISQUES D’INCENDIE ET D’ÉLECTROCUTION, NE PEXPOSER CET APPAREIL À LA PLUIE
NI À L’HUMIDITÉ.
ATTENTION : POUR ÉVITER LES CHOCS ÉLECTRIQUES, NE PAS UTILISER CETTE FICHE (POLARISÉE) AVEC UN CORDON
PROLONGATEUR, UNE PRISE DE COURANT OU UNE AUTRE SORITE DE COURANT, SAUF SI LES BROCHES
PEUVENT ÊTRE INSÉRÉES À FOND SANS QU’AUCUNE PARTIE NE RESTE À DECOUVERT.
Note to CATV system installer:
This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines
for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the
building, as close to the point of cable entry as practical.
NOTE:
This equipment has been tested and found to comply with the limit for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with
the instructions may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
1
RECOMMENDED GUIDELINES FOR THE USE OF A VIDEO MONITOR/TV IN A MOTOR VEHICLE
•A VIDEO MONITOR/TV is designed for rear passenger viewing only. This product may only be installed in the rear seat
compartment of the vehicle, out of the driver’s view.
•Installation in any other area of the vehicle, including anywhere within the driver’s view, is illegal in most states,
provinces and countries and may lead to driver distraction resulting in an accident, injury and/or death. If you are unsure
of regulations regarding this, please consult your local laws to determine how this applies to you.
•Users should be aware of the possible noise distraction caused by the use of the product and should carefully monitor
the volume so as not to interfere with the driver’s attention to surrounding traffic conditions.
2
T ABLE OF CONTENTS
NOTE: This Video Cassette Player is compatible with any Video Cassette Player bearing the VHS mark. The VCP is
designed to expand your opportunities for home viewing and not for any usage which might violate the copyright laws.
Save the original shipping carton and packing materials; they will come in handy if you ever have to ship your VCP. For
maximum protection, repack the set as it was originally packed at the factory.
DRAWING YOUR ATTENTION
IMPORTANT SAFEGUARDS......................................................................................................................................................3
VIDEO HEAD CLEANING...........................................................................................................................................................7
IMPORTANT NOTES..................................................................................................................................................................8
FEATURES.................................................................................................................................................................................9
IDENTIFICATION......................................................................................................................................................................10
TO GET STARTED....................................................................................................................................................................18
BASIC OPERATION..................................................................................................................................................................20
SPECIAL OPERATION..............................................................................................................................................................24
BEFORE CALLING SERVICE PERSONNEL................................................................................................................................26
SPECIFICATION.......................................................................................................................................................................29
3
IMPORT ANT SAFEGUARDS
For your protection, please read these safety instructions completely before operating the appliance, and keep this
manual for future reference.
Carefully observe all warnings, precautions, and instructions on the appliance, or the ones described in the operating
instructions and adhere to them.
USE
Power Sources–This set should be operated
only from the type of power source indicated on
the marking label. If you are not sure of the type
of electrical power supply at your home, consult
your dealer or local power company. For those
sets designed to operate from battery power, or
other sources, refer to the operating instructions.
Overloading–Do not overload wall outlets,
extension cords or convenience receptacle
beyond their capacity, since this can result in fire
or electric shock.
Object and Liquid Entry–Never push objects of
any kind into the set through openings as they
may touch dangerous voltage points or short out
parts that could result in a fire or electric shock.
Never spill liquid of any kind on the set.
Attachments–Do not use attachments not
recommended by the manufacturer, as they may
cause hazards.
Cleaning–Unplug the set from the wall outlet
before cleaning or polishing it. Do not use liquid
cleaners or aerosol cleaners. Use a cloth lightly
dampened with water for cleaning the exterior of
the set.
DC 12V?
UNPLUGUNPLUG
4
Water and Moisture–Do not use powerline
operated sets near water-for example, near a
bathtub, washbowl, kitchen sink, laundry tub, in a
wet basement, or near a swimming pool, etc.
Accessories–Do not place the set on an
unstable cart, stand, tripod, bracket, or table. The
set may fall, causing serious injury to a child or
an adult, and serious damage to the set. Use only
a cart stand, tripod, bracket, or table
recommended by the manufacturer.
Ventilation–The slots and openings in the
cabinet are provided for necessary ventilation. To
ensure reliable operation of the set, and to
protect it from overheating, these slots and
openings must never be blocked or covered.
– Never cover the slots and openings with a cloth
or other materials.
– Never block the slots and openings by placing
the set on a bed, sofa, rug or other similar
surface.
Portable Cart Warning–An appliance and cart
combination should be moved with care. Quick
stops, excessive force, and uneven surfaces may
cause the appliance and cart combination to
overturn.
5
–Never place the set in a confined space such as
a bookcase, or built-in cabinet unless proper
ventilation is provided.
Power-Cord Protection–Route the power cord
in order not to be walked on or pinched by items
placed upon or against them, paying particular
attention to the plugs, receptacles, and the point
where the cord exits from the appliance.
–Do not place the set over a radiator or heat
register, or where it is exposed to direct
sunlight.
In the normal temperature, if you pour a cold
liquid into a glass, water vapor in the air will
condense on the surface of the glass. This is
moisture condensation. The moisture
condensation may occur inside of VCPs, if used in
this condition, it will cause damage to the head
and the tape.
In case of moving the VCP from a cold place to
heated place,
Or the temperature of surroundings goes up due
to room heating switched on.
Or moving the VCP suddenly from air conditioned
room to a place of high temperature of humidity
in summer.
may cause the dew indicator to light up. Do not
use in this condition.
When the moisture condensation occurs inside of
the VCP, NEVER insert the cassette into the
cassette compartment. Remove the cassette, if
loaded, by pressing the STOP/EJECT key. Only
operate the VCP after the moisture condensation
has completely dried out. Normally, it takes
about 2 hours.
MOISTURE CONDENSATION
When does the
moisture
condensation occur
inside of the VCP?
6
SERVICE
Damage Requiring Service–Unplug the set
from the wall outlet and refer servicing to
qualified service personnel under the following
conditions:
–When the power cord or plug is damaged or
frayed.
–If liquid has been spilled or objects have fallen
into the set.
–If the set has been exposed to rain or water.
–If the set has been subjected to excessive shock
by being dropped, or the cabinet has been
damaged.
–If the set does not operate normally when
following the operating instructions, adjust only
those controls that are specified in the operating
instructions. Improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician
to restore the set to normal operation.
–When the set exhibits a distinct change in
performance, this indicates a need for service.
Servicing–Do not attempt to service the set
yourself as opening or removing covers may
expose you to dangerous voltage or other
hazards.
Refer all servicing to qualified service personnel.
Replacement of parts–When replacement of
parts is required, be sure the service technician
has used replacement parts specified by the
manufacturer that have the same characteristics
as the original parts. Unauthorized substitutions
may result in fire, electric shock, or other hazards.
Safety Check–Upon completion of any service
or repairs to the set, ask the service technician to
perform routine safety checks (as specified by the
manufacturer) to determine that the set is in safe
operating condition.
SERVICE DEPT
ALL SETS RECEIVE
OUR OK
SAFETY CHECK.
FRAYED OR CUT
DC LINE
CRACKED PLUG
7
VIDEO HEAD CLEANING
VIDEO HEAD CLOGGING
The video heads are the means by which the VCP reads pictures from the tape during playback.
In the unlikely event that they become dirty enough to be clogged, no picture will be playback. This can easily be
determined if, during playback of a known good tape, there is good sound, but the picture is extremely snowy. If this is the
case, have the video cassette player checked by qualified service personnel.
VIDEO HEAD CLEANING
During normal operation of the VCP, the video and audio heads can get dirty over a period of time, especially when using an
old or poor quality tape. When the heads are dirty the picture can get snowy and the tracking control will not adjust the
snow out of the picture. If this condition occurs, head cleaning cartridges may take care of this problem and restore normal
picture. We recommend that head cleaning cartridges be used sparingly due to the fact that they can be very abrasive to
the video heads. If the problem is not resolved with the head cleaning cartridge then the unit needs to be checked by a
qualified service personnel.
NOTE : Video heads may eventually wear out and should be replaced when they fail to reproduce clear pictures. To help prevent
video head clogging, use only good quality VHS tapes. Discard worn out tapes.
8
IMPORT ANT NOTES
• Note that main voltage is supplied to the unit whenever the main plug is connected to the supply socket.
• To avoid the risk of fire or electric shock, do not expose the unit to rain or moisture.
• Do not attempt to open the cabinet. There are no user-serviceable parts inside. Refer all servicing to qualified service personnel.
• Keep the unit away from radiators or other sources of heat.
• Do not operate or store the unit close to strong magnetic fields.
• Do not spill liquid of any kind onto the unit. If liquid is accidentally spilled onto the unit, immediately remove the main plug from the
supply socket, and consult a qualified service engineer.
• Avoid places subjected to strong vibration.
• Do not place anything heavy on the VCP.
• Use the video cassette player in a horizontal (flat) position only.
• Before operating, remove any paper wrapping which may have been affixed to the player during manufacturing.
DO NOT COVER VENTILATION OPENINGS ON TOP AND SIDES OF THE PLAYER DURING OPERATION.
• When a cassette is inserted into the loading compartment, the power is switched on automatically as long as the power cord is
plugged into a DC outlet. DO NOT force a cassette into the compartment when the power cord is unplugged.
• After playing a video cassette, remove it from the player. DO NOT move the player with a cassette in the compartment.
• Store video cassettes in their sleeves or cases and position vertically.
Model Number:
Serial Number:
Date Purchased:
Store’s Name and Address:
For your protection, record the model and serial numbers of your
video cassette player here. In the event your player requires servicing
or is stolen, you may need this information. You may also wish to clip
or staple your sales receipt to this page.
9
FEA TURES
CONGRATULATIONS on your purchase of a new VHS VCP.
This VCP is an exciting, new VCP designed to satisfy all your VHS tape play and recording needs.
And, with proper use and care, your new VCP will offer many years of viewing enjoyment.
Just a few of the features include.
• DIGITAL AUTO TRACKING
This VCP plays clear pictures without special operations.
In the Auto tracking mode, the PLAY indicator lamp will blink.
• SELF PICTURE ADJUSTMENT
Since the HEAD DRUM rotates regularly depending on the voltage change or tape condition, the picture is always stable.
• AUTO START FUNCTION
This VCP will automatically power on and go into PLAY mode when a cassette is inserted.
• 2-HEAD Hi-Fi PLAYBACK
10
FRONT PANEL
IDENTIFICA TION
!
Cassette Compartment
@
Power key
When power is supplied to the set, the power indicator
lamp will always light up in red.
The Power ON and Power OFF mode will be toggled by
pressing this key.
When the POWER is switched on, the power lamp will
light up in red and the other keys will light up in green.
#
Hi-Fi lamps
In the Hi-Fi output mode, the lamp will light up in green.
$
Stop/Eject key
Press this key to stop tape and once more to eject tape.
!
@
#
$
%
^
&
* (
11
IDENTIFICA TION (continued)
%
Rewind/Review key
If this key is pressed in the PLAYBACK mode, the VCP
enters the reverse picture search mode. If pressed in
STOP mode, then the tape will rewind at high speed.
The REW indicator lamp will light up in orange.
^
PLAY key
Press this key to playback a recorded tape, or to release
special operations such as the search modes.
In the playback mode the playback indicator lamp will be
light in orange, and in Auto Tracking mode, this indicator
lamp will blink.
&
Fast Forward/ Cue key
If this key is pressed in the PLAYBACK mode, the VCP
enters the forward picture search mode. If pressed in
STOP mode, then the tape will fast forward at high
speed.
The FF indicator lamp will light up in orange.
*
Cassette-In lamp
When the cassette is inserted, the CST-IN lamp will light
up in red.
(
DEW lamp
This indicator will flash (if power is on) to indicate
excessive moisture has been inside of VCP. This unit will
not operate until it dries out sufficiently (the tape can be
ejected from the unit). When DEW mode has been
activated, leave the unit on to allow it to dry out
completely.
12
IDENTIFICA TION (continued)
REAR PANEL
!
FUSE HOLDER
This main line fuse is accessible with the external fuse
holder simply by unscrewing the cap. If the main line
fuse should blow then replace the fuse with a proper
rated fuse (125V, 2A).
@
RF OUT CHANNEL SELECTION SWITCH
Set to channel 3 or 4, whichever is not being
broadcasted in your area.
#
ANT.IN
Connect the TV antenna to this terminal.
13
IDENTIFICA TION (continued)
$
VIDEO OUT
Connect this terminal to VIDEO IN terminal of your television, using the RCA cord provided.
%
AUDIO OUT L/R
Connect this terminal to AUDIO IN terminal of your television, using the RCA cord provided.
^
DIN JACK
&
RF OUT
Connect this terminal to antenna terminal of your television on using the coaxial cable.
*(
DC JACK IN
Connect this jack to DC source (DC 12V).
NOTE : This VCP is for 12V use only, so do not use it in 24V vehicles.
If you use this set in a 24V vehicle, all the indicator lamps will blink. To avoid the malfunction of this set, please
disconnect the plug from the power source.
1 PIN S.STATUS DATA OUT
2 PIN GND
3 PIN EXT.REMOTE DATA.IN
4 PIN GND
5 PIN GND LEFT RETURN
6 PIN GND RIGHT RETURN
7 PIN VIDEO OUT
8 PIN AUDIO LEFT
9 PIN AUDIO RIGHT
14
IDENTIFICA TION (continued)
REMOTE CONTROL OPERATION RANGE
7m
1. Any object between the remote control and VCP will block the
path of beam when it is being used.
Dark walls, direct sunshine or very bright (incandescent) light
will reduce the remote control sensitivity.
2. Hold the remote control within an angle range of about 30º
from either side of the remote sensor center as shown.
3. When the remote control is vertical to the remote Sensor, it will
work within about 23feet (7m) from the VCP.
4. Point the front of the remote control directly at the front of the
VCP.
30o30
o
15
IDENTIFICA TION (continued)
BATTERY INSTALLATION
1.Remove the battery cover on the reverse side of the remote control.
2.Install 2 batteries (“AAA” size) into the remote control. (Carefully install batteries to match the polarity diagrams)
3.Close the battery cover.
• It is advisable to take batteries out of the remote control when it is not in use for a long time.
16
IDENTIFICA TION (continued)
REMOTE CONTROL BASIC FUNCTIONS
POWER
RE-PLAY
TRACKING -/+
PLAYBACK
REWIND/REVIEW
STOP
PAUSE / STILL FRAME
RETRACKING
FAST FORWARD / CUE
17
IDENTIFICA TION (continued)
WHEN YOU USE THE REMOTE CONTROL
• Do not press two keys at the same time. • Do not expose the remote sensor to the sunshine.
• It causes the VCP not to operate.
• Avoid direct sunshine and strong shock. • Keep the remote control away from dust and moisture.
18
VCP TO VEHICLE CONNECTION
TO GET ST ARTED
• You can apply this method to DC 12V output only.
• Please connect to the vehicle only after making sure of the polarity of the cigarette lighter socket. (negative earth)
19
HOW TO USE THIS METHOD
• You can apply this method to DC 12V output only.If you apply more than 18 volts then the power will automatically turn
off.
• Please connect after making sure of the polarity of the cigarette lighter socket.
• If the polarity is reversed, the unit will not operate.
• Use of this VCP is not recommended in excessive heat. If inside temperature of vehicle is over 100F, do not use VCP.
Allow VCP to cool before use.
20
CASSETTE LOADING/UNLOADING
BASIC OPERA TION
LOADING
UNLOADING
Œ
Push the cassette into the cassette compartment
gently. (Arrow mark at the top)
´
The cassette-in indicator lamp is lit up.
• An inverted cassette cannot be inserted.
• Upon inserting the cassette, the power turns on even if the
power was off as long as the DC power cord is plugged in.
Œ
Press the STOP/EJECT key twice on the VCP (in the
PLAYBACK mode). This first press will stop the tape.
The second press will eject the tape. The cassette-in
indicator lamp will be lit out.
´
Pull the cassette out gently.
•When you press the STOP/EJECT key even if the
power is off, the cassette will be ejected.
21
ERASURE PROTECTION
BASIC OPERA TION (continued)
Video cassettes are equipped with a safety tab to prevent accidental erasure.
When the tab is removed, recording can not be performed.
• TO PREVENT ACCIDENTAL ERASURE
•After recording, break off the safety tab with a
screwdriver if you don’t want to record over the tap.
• TO RECORD AGAIN
• Cover the hole with cellophane tape.
22
BASIC PLAYBACK
BASIC OPERA TION (continued)
Œ
ˇ Ø
ˆ
¨
´
23
BASIC OPERA TION (continued)
Œ
LOADING
The power is on automatically
when the cassette is inserted even
if the power was off.
´
PLAYBACK
Press the PLAY key, then pictures will
appear within approximately 8
seconds.
The tape will rewind automatically to
the beginning after playing to the end.
Press the STOP/EJECT key once.
The tape will stop .
ˇ
STOP
Press the FF key in the STOP
mode.
The tape advances at high speed
without any picture and sound.
¨
FAST FORWARDING
ˆ
REWINDING
Press the REW key in the STOP
mode.
The tape will rewind at high speed
without any picture and sound.
Ø
EJECTING
Press the STOP/EJECT key once
more (in the STOP mode), and the
tape will eject.
24
SPECIAL OPERA TION
Œ
TO VISUALLY SEARCH FORWARD
Press the FF key once in the PLAYBACK mode.
And then the tape advances rapidly with the pictures .
Pressing this key once more makes the VCP advance
more rapidly.
´
TO VISUALLY SEARCH REVERSE
Press the REW key once in the PLAYBACK mode. And
then the tape will rewind rapidly with the pictures.
Pressing this key once more makes the VCP rewound
more rapidly.
ˇ
TO OPERATE RE-AUTO TRACKING
Press the PLAY key during playback.
Then the VCP enters the Re-Auto Tracking mode.
¨
TO SELECT Hi-Fi AUDIO OUTPUT
During the Hi-Fi program playback, Hi-Fi lamp lights up
in green. Press the PLAY key during playback, then VCP
enters autotracking mode. During the autotracking
mode, press the PLAY key once more. Then you can
select audio output as like as below.
“ stereo L R mono stereo “
The VCP enters the playback mode during special operations as soon as the PLAY key is pressed. During special operations,
noise bars and loss of color may affect the picture. This is not a fault with this unit.
25
SPECIAL OPERA TION (continued)
ˆ
AUTO TRACKING ADJUSTMENT
• Since this VCP has the Auto Tracking Adjustment function, it can play clear pictures without special operations.
• Auto Tracking Adjustment operates automatically when the cassette is inserted.
• Playback indicator lamp blinks during auto tracking operation. If the tracking is completed, the playback indicator
lamp lights on.
• If noise bars appear in the picture during playback, press the PLAY key to operate Re-Tracking function.
NOTE : This VCP has Auto Start Feature.
This VCP will automatically power on and go into PLAY mode when a cassette is inserted.
PLAY key
26
BEFORE CALLING SERVICE PERSONNEL
Before calling service personnel, check the following points for a possible cause of the trouble. A minor adjustment on your
part may eliminate the trouble.
SYMPTOMS CAUSE POSSIBLE SOLUTIONS
There is no power to the VCP.
Noise bars on screen.
Operation key does not work.
Cassette is ejected upon inserting.
Audio output does not change to Hi-Fi
mode.
• The power cord is not connected.
• The polarity of power cord is not
correct.
• Tracking is not adjusted.
• If the cassette or the VCP is not in
normal condition, every indicator
LED/LAMP lights up and the VCP
does not work.
• Safety device works to protect the
cassette when it is inserted
incorrectly.
• The cassette is recorded in mono
VCR.
• The first autotracking is executing
until now.
• Check the power cord.
• Change the polarity of power cord.
• Adjust the picture to be clear by
pressing the PLAY key.
• Turn off the power and turn on the
power again by pressing the
POWER cord.
• Unplug and replug the power cord.
• Pull the cassette out (unloading)
and insert it firmly into the cassette
compartment.
• The cassette can not be playback in
Hi-Fi mode.
• Wait for a second.
27
SYMPTOMS CAUSE POSSIBLE SOLUTIONS
No backlighting at power button.
Power indicated with backlightingunit will not operate.
More indicators flashing unit will not operate.
PLAY mode indicated no audio or
video to TV.
• No 12V DC.
• (Unit in dew mode) Dew
feature activated (see
owner’s manual).
• No tape in unit.
• Low voltage.
• Unit in emergency mode.
• VCP connected to A/V Input
jack, RCA patch cables set in
TV mode.
• Check circuit fuse at source of power
(see vehicle/converter manual).
• In-line fuse of power cord (in lighter plug).
• VCP (2 amp* 20X 5mm) fuse located on
rear of unit.
• Power cord unplugged from 12V outlet or
at rear of unit.
• Retain power to player and allow unit for
a time to get rid of moisture. (After 30
minutes if dew indicator is still on,
completely switch power off from unit and
resupply after a minute. This can reset
dew indicator if moisture eliminated.)
• Insert the tape.
• Start the vehicle, if not running.
• Contact dealer for service to player.
• Switch TV to video mode with remote
control or switch behind control door of
TV.
28
SYMPTOMS CAUSE POSSIBLE SOLUTIONS
Play mode indicated no audio or
video to TV. (continued from the
previous page)
Poor video/snowy picture or lines on
screen.
• VCP connected to A/V output jacks.
• Poor connection between VCP
output and TV input.
• Reversed A/V inputs to TV.
• Dirty heads.
• Change connections from A/V
output to A/V input.
• Check connection(a).
• Check connection(b).
• Clean head using tape cartridge
cleaner. We recommend using
cartridge with cloth or paper tape
and cleaning drops included.
• These are readily available at retail
stores.
29
SPECIFICA TION
Design and specifications are subjected to change without notice.
POWER SUPPLY
POWER CONSUMPTION
DIMENSION
WEIGHT APPROX.
VIDEO SIGNAL SYSTEM
VIDEO SIGNAL, OUTPUT (RF) VHS
TAPE TYPE
TAPE SPEED
FF/REW TIME (T-120)
VIDEO SIGNAL OUTPUT (LINE)
AUDIO SIGNAL OUTPUT (LINE)
OPERATING CONDITION HUMIDITY
OPERATING POWER VOLTAGE
DC 12V
12W
265 X 91 X 295 (W X H X D) mm
3.4 kg
NTSC Color
75Ω unbalanced AVX.
VHS Type
SP : 33.35 mm/sec , LP : 22.23 mm/sec, SLP : 11.12 mm/sec
Approx. 5 min
1Vpp 7Ω unbalanced, NEGATIVE SYNC
-5dBm 10KΩ MAX
85% RH max, Temperature : 5˚C ~ 35˚C (41˚F ~ 95˚F)
12~14V
MODEL PLVCP
Loading...
