PSUFM1070P
PSUFM1070P
Page 2
Specifications
*
Dual 10" Woofers and Two 3" Piezo Tweeters
*
Heavy Duty Handles for Easy Portability
*
Three Color Flashing DJ lights on Tweeters and Woofers
*
LED Sound Level Indicators
*
Works with Most Amplifiers or With The Disco Jam Active Models
*
Speaker Spring Terminals
*
Ported Enclosure for Added Bass Response
Power Handling: 1500 watts peak /750 Watt RMS @4 Ohms
*
Woofer Magnet Weight: 25 oz.
*
Sensitivity (1w/1m): 90dB
*
Built In Crossover Network: 3.5k Hz
*
Frequency Response: 20 Hz - 20 kHz
*
35mm Speaker Stand Mount
*
Dimensions: 36.8"(H) x 15.2"(W) x 13.6"(D)
*
Weight: 32 lbs
*
Safety Notes
1.Correct power must be used to operate this unit properly,
do not use any other powering options, cords or methods.
2.Carfully handle, plug and unplug the power cable when handling.
Hold the plug with a firm grip and when plugging or unplugging from
sockets.
3.Do not open chassis! Extermely dangerous! Do not put your hands
inside the chassis. If the device begins to malfunction do not
attempt to repair, unplug the unit and contact Pyle immediately.
4.Don't use volatile or dangerous chemical cleaners on the unit
(like toluene, alcohol, gasoline etc.) Use gentle cleaners.
5.Keep the unit in a well ventilated environment and keep away
from, direct sunlight to prevent unit from overheating.
6.Protect the unit from moisture or rain.
www.PyleAudio.com
Page 3
Speaker Board Schematic
1
2
3
7
4
5
6
1
Type of sticker
2
Tweeters
3
Woofer confinement
4
Woofer Speaker
www.PyleAudio.com
5
Vent Hole
6
Speaker machine feet
7
Speaker handle
