PSLSW4 - PSLSW6
Multi-Zone Speaker Selector
Page 2
PSLSW4 - PSLSW6 lets you connect up to four (PSLSW4) or six ( PSLSW6) separate pairs of speakers to your stereo receiver/amplier. The control center is especially convenient if you have speaker sets in dierent rooms and want to turn them on and o independently. You can enjoy the convenience and exibility of listening to multiple speaker pairs simultaneously.
The control center lets you use one to four (PSLSW4) or six (PSLSW6) sets of speakers at a time, and is designed to operate with a stereo receiver/amplier that has a maximum of 100 watts per channel, and with speaker systems that have a minimum impedance of 8 ohms (see “Impedance Chart” on page 6)
PREPARATIONS
Use the PYLE Speaker Selectors only with ampliers rated at 100 watts per
channel or less.
Your PYLE Speaker Selector is designed to accept any size cable up to 14 gauge non-terminated speaker wire. If you're using non-terminated speaker wire, do not use any speaker wire that is larger than 14 gauge. The lower the gauge number, the larger the cable (e. g: 12 gauge is larger in actual physical size than 14 gauge).
Do not hook the outputs of one selector into the inputs of another speaker selector together.
Before you connect the AC power source, make sure you set ALL speakers ON/ OFF to OFF.
Left and right "commons" are isolated to work with all types of ampliers.
Auto transformer impedance protection.
PSLSW4 Front and Back Panels
www.PyleUSA.com
2
Page 3
PSLSW6 Front and Back Panels
OPERATION
1. Speakers ON/OFF Button Press button to turn ON all speaker pairs. Press again button out to turn o.
2. Amplier A/B Selector Button Press button to select amplier A and B
3. Volume Controls Turn the control knob clockwise to increase the volume and counter-clockwise to decrease or o.
4. Speaker Connections The control center divides the power from your receiver/amplier dierently to its speaker terminals. (This is especially noticeable when you connect only one pair of speakers. If you connect more than one pair of speakers, see “Impedance Chart" on page 6 to selector the best terminals to connect. ) For the best performance, make the connections based on how frequently you use each set of speakers.
Cautions: To avoid damaging your speakers or receiver/amplier:
Be sure your receiver/amplier's power is turned o before you make the
connections.
Never let the speaker wire's bare ends touch each other or adjacent terminals
on the control center.
Do not connect more than one pair of speaker to each set of terminals.
www.PyleUSA.com
3
Page 4
5. Amplier Connections Connect the speaker output of your receiver or amplier (100 watts max. ). If you are using a second amplier, connect it to the B amp terminal
Maximum Amplier input
100W RMS
150W AVG
Maximum Output per Speaker
18W RMS
50W AVG
Insert the speakers’ positive (+) wires in the positive terminals, and negative (-) wires into the negative terminals, according to the respective L (left) and R (right) terminals.
100W PEAK
4 or 16 OHM LOAD
PSLSW4
PSLSW6
www.PyleUSA.com
4
Page 5
Insert your receiver / amplier’s positive (+) wires into the positive terminals, and negative (-) wires in the negative terminals.
NOTES:
If your receiver / amplier has more than one set of speaker Terminal (A and B),
connect only one or the other to the Control center.
For the best results, we recommend 14-gauge, two conductor speaker wire (not supplied) for most connections. If you plan to locate the speakers further than 80 feet from the control center, use a heavier gauge of wire.
IMPEDANCE CHART
Impedance is a measurement of the load placed on your receiver/amplier by the speakers. The load placed on your receiver/amplier from the control center will vary depending on how many pairs of speakers you turn on at one time, and on which speakers you turn on. The chart below shows the impedance for all possible combinations of 8-ohm speakers.
PSLSW4
Speaker Sets On Impedance ()
A, B, C or D 8
PSLSW6
A+B, A+C, A+D B+C, B+D, C+D
A+B+C, A+B+D A+C+D, B+C+D
4
3. 1
A+B+C+D 2. 4
Speaker Sets On Impedance ()
A, B, C, D, E or F 8
A+B, A+C, A+D A+E, A+F, B+C B+D, B+E, B+F C+D, C+E, C+F, E+F
4
www.PyleUSA.com
5
Page 6
Speaker Sets On Impedance ()
A+B+C, A+B+D, A+B+E A+B+F, A+C+D, A+C+E A+C+F, A+D+E, A+D+F A+E+F, B+C+D, B+C+E B+C+F, B+D+E, B+D+F C+D+E, C+D+F, D+E+F
A+B+C+D, A+B+C+E A+B+C+F, A+C+D+E A+C+D+F, A+D+E+F B+C+D+E, B+C+D+F C+D+E+F
A+B+C+D+F 1.7
3.1
2.4
PSLSW4  PSLSW6
Multi-Zone Speaker Selector
4 Channel (PSLSW4) 6 Channel (PSLSW6)
Audio Speaker Receiver System
Features:
Convenient Audio Control for Up to 4 Pairs of Speakers (PSLSW4)
or 6 Pairs of Speakers (PSLSW6)
Home Theater Stereo Amplier System Support
Independent Audio Source Channel Volume Controls
Input/Output: Screw Type Connector Terminals
Compact Desktop / Tabletop Receiver Design
Front Panel Button Control Center
Master Power Switch
Built-in Electronic Overload Protection Circuitry
www.PyleUSA.com
6
Page 7
What's in the Box:
Speaker Selector
Technical Specs:
Power Handling: 100 Watt MAX Per Audio/Speaker Channel
Speaker Selector Type: 4-Channel
Speaker Cable Wire Support: Up to 14-Gauge (14 AWG)
Minimum Impedance: <8 Ohm
Frequency Response: 20Hz-20kHz
Dimensions (L x W x D): 16.9'' x 6.3’’ x 3.0'' -inches
Sold as: 1
PSLSW4 Weight: 9.78 lbs.
PSLSW6 Weight: 9.55 lbs.
