PLEASE READ THIS MANUAL CAREFULLY BEFORE OPERATION
Features:
• Loudspeaker PA System
• Rugged, Durable & Reliable Sound
• Wireless BT Streaming Ability
• Wireless BT Music Streaming Ability
• Speaker System: 2x12'' Active and Passive Subwoofer, 4 x 4” woofer,
4 x 1'' Tweeter
• Compression Driver with PEI Diaphragm
• 3-Way Full Range Audio Projection
• Built-in Digital Audio Amplier
• XLR Microphone Input
• 1/4’’ Jack, RCA (L/R) Stereo Line Input
• Connect & Stream Audio from External Devices
• USB Flash Drive & SD Memory Card Readers
• Digital LCD Display
• Rear Panel Rotary Dial & Button Control Center
• Master Volume, Mic Volume, Treble, Bass, Eect Adjustable
• 5 Band Graphic Equalizer
• Integrated Carry Handles
• 35mm Speaker Stand Mount Compatible
What's in the Box:
• 12'' Wireless BT Active Subwoofer Speaker
• 12'' Passive Subwoofer Speaker
• (4) 4” Passive Line Array Speaker
• (2) Stand
• Power Cable
• Audio Cable 98.43'' -inches (Both Sides are 6.35 1/4’’ Jack )
• Audio Cable 236.22'' -inches (Both Sides are 6.35 1/4’’ Jack )
• (2) Audio Cable 11.81'' -inches (Both Sides are 6.35 1/4’’ Jack)
• Audio Cable 196.85'' -inches (Both Sides are SpeakOn)
• Remote Control
Subwoofer:
• Size: 12'' -inch
• Material: Stamped Steel Basket
• Impendence: 8 Ohm
• Voice Coil: 60.6mm, 2.5'' -inch
• Sensitivity: 93dB
• Frequency Response: 45Hz-3kHz
• Magnet: 50 oz.
Woofer:
• Size: 4'' -inch
• Material: Stamped Steel Basket
• Impendence: 8 Ohm
• Voice Coil: 25.5mm, 1'' -inch
• Sensitivity: 88dB
• Frequency Response: 80Hz-8kHz
• Magnet: 10 oz.
Tweeter:
• Size: 1.0'' -inch
• Material: PEI
• Impendence: 8 Ohm
Technical Specs:
• Sensitivity: 104dB
• Voice Coil: Kapton
• Frequency Response: 800Hz-20kHz
• Max Power Output: 1320 Watt
• RMS Power Output: 660 Watt
• Amplier Class: D
• Digital Audio File Compatibility: MP3, WMA
• Maximum SD/USB Flash Memory Support: 32GB
• Inputs/Outputs 1/4" TS/unbalanced and 3.5mm TRS/Stereo Input
with RCA Input
• T.H.D.: 1%
• Crossover Frequency: 120Hz/3.3kHz
• Voltage: AC 110/220V 60/50HZ
• Active Subwoofer Dimensions (L x W x H): 13.78’’ x 184.25’’ x 15.75’’ -inches
• Passive Subwoofer Dimensions (L x W x H): 13.78’’ x 184.25’’ x 15.75’’ -inches
• Passive Line Array Dimensions (L x W x H): 9.25’’ x 4.13’’ x 4.92’’ -inches
Wireless BT Streaming:
• Instantly Stream Music from Your BT Devices
• Works with All Your Favorite BT Devices
(iPhone, Android, Smartphone, iPad, Tablet, PC, etc.)
• Wireless BT Version: 5.0
• Wireless BT Range: 100'+ Feet
• Wireless BT Network Name: 'Pyle'
www.PyleUSA.com
2
www.PyleUSA.com
3
Page 3
Control Panel Functions Connection
5 Band graphic equalizer
Stereo ECA input for iphone, iPad, iPod, Android
Devices, laptop, computer, TV, DVD, CD player etc
Individual Treble/B ass Control
Four Independent
volume controls
and master volume
control
Two XLR inputs for
Mic/Line-level Source
Stereo 6.35mm input for line-level source
MP3 Media Player
with LCD Display
Overload Indicator
Stereo RCA
inputs & outputs
BLUETOOTH
+12
+ 6
0
- 6
-12
PROT
PROT
LEFT
RIGHT
LIMIT
LIMIT
13
MIN MAX
MASTER
VOLUME
83Hz
L
R
MONITOR
OUT
110V 220V
IR
SD
USB
M FD
6
SPEAKER OUT
(R)4/8 OHM
8 OHM
SUBWOOFER OUT
Array Speaker
TREBLE
MIN MAX
BASS
MIN MAX
EFFECT
MIN MAX
VOLUME
MIN MAX
MIC LINE
CH1
SPEAKER OUT
(L)4/8 OHM
TREBLE
+12
+ 6
MIN MAX
0
BASS
- 6
-12
DIGITAL ECHO EFFEC TS
MIN MAX
EFFECT
DEPTH
10
MIN MAX
MIN MAX
VOLUME
VOLUME
MIN MAX
MIN MAX
MIC LINE
LINE
CH2
AC 120/240V 60/5 0Hz POWER
GRAPHIC EQUAL IZER
330Hz 3.3KHz10 KHz1KHz100Hz
SUB VOL
12
MIN MAX
MP3
45Hz
L
R
CH3/4
Assembly
STEP 1: STEP 2:
Connect to another
amplier, monitor
speaker, recorder, etc.
Array Speaker
Passive Subwoofer
Stereo 6.35mm output
array speakers
www.PyleUSA.com
4
Selectable 110V/220V Voltage
Speakon output to
passive subwoofer
Align four identical speakers according
to the number sticked from top to
bottom, the icon of each speaker
should be placed to direction with the
“ ” on the bottom.
Attach the long bracket and short
bracket to the array speaker, secured
with screws and nuts.
www.PyleUSA.com
5
Page 4
Assembly Adjustable Height
STEP 3: STEP 4:
Connect the speakers with 8-in. cables.
Then attach the array speaker to the
stand pole and the subwoofer.
Line Array Speaker
Active Subwoofer with Multifuntional control panel Passive Speaker
Repeat the above steps for the
second set.
Telescoping Speaker Pole
Rotating Knob
for securing
the stand pole
Subwoofer
Two Line
Array Speakers
Rugged MDF Enclosure
www.PyleUSA.com
6
www.PyleUSA.com
7
