PROJECTOR SCREEN USER MANUAL
PRJSM1006 - 100'' -INCH
PRJSM9406 - 84'' -INCH
PRJSM7206 - 72'' -INCH
INSTALLATION:
Install the screen in an area that can be easily viewed by anyone sitting in the room. Make sure
it is the desired position, angle, and location of the screen before installing it. The screen will be
used for a long time if you place it in the right area. This projector screen can be installed on the
wall or ceiling (optional).
WALL SCREEN
Place the projector on the wall and make
sure it is level; mark the two rings with a
pencil so you know where to put the nails.
Once you have the nail positioning correct,
Hammer the nails in the wall (practice
caution) in the places where you marked
with the pencil; then hang the projector.
CEILING SCREEN
When you are hanging the projector on
the ceiling, follow the same steps for the
wall. It is important to know what you are
nailing into; make sure it has enough
support to handle the weight of the
projector.
Note: Make sure that you install the projector screen with enough height that the entire screen
can be pulled down. After you used the screen, please check the fabric of the screen for dust
and dirt. If it has any, please clean it with a soft brush.
INSTRUCTIONS:
1. Open screen: This projector screen has a self-locking mechanism. Simply pull down the
screen to your desired location and then release softly. Once you release the screen, it will
start to pull up slightly and then lock itself into position. You are ready to project on to the
screen.
2. Close screen: When you wish to close the screen, pull the screen down slowly- at this point
you will hear/feel the self-locking mechanism release. You can then slowly release the screen
(keeping your hand on it) and smoothly guide it back into its position.
