PPHP1243B

12'' Portable Wireless BT PA Speaker System

Karaoke Speaker with Latest DJ LED Lights, USB/FM/BT/Aux/Remote Control/Mic Inputs,

Built-in Rechargeable Battery (800 Watt)

Page 2

PLEASE READ THE INSTRUCTION MANUAL CAREFULLY

AND KEEP IT FOR FUTURE REFERENCE

WARNING

1. DO NOT place objects on top of the device, as objects may scratch the device.

2. DO NOT expose the device to dirty or dusty environments.

3. DO NOT insert any foreign objects into the device.

4. DO NOT expose the device to strong magnetic or electrical eld.

Illegal operation may cause personal injury, which could be fatal and may cause damage to property.

5. DO NOT use the device in the rain

6. Please check with your Local Authority or retailer for proper disposaI of electronic products.

7. DO NOT disassemble the device. Only a certied service technician should perform repair.

8. The device has apertures to disperse heat. DO NOT block the device ventilation, the device may become hot and malfunction as a result.

TWS-TRUE WIRELESS STEREO SETUP

1. Turn on two same PA speaker that you’re attempting to pair together and switch both units to Wireless BT mode.

2. Choose one of units to begin to pairing process.

3. Press down on the PLAY button for 3 seconds until you hear a chiming sound; This means the unit is ready to pair with another unit.

4. Move onto the second unit and repeat step 3.

5. Now begin playing your music through Wireless BT enabled mobile device. The speakers will begin to play your music simultaneously.

Control Board Functions

3 6

REMOTE CONTROL Functions

1. STANDBY BUTTON

2. CHOOSE INPUT AUX/FM/BT/USB SIGNAL

3. MUTE BUTTON

4. PLAY/STOP BUTTON ON MP3 MODE,

SCAN FUNCTION ON FM MODE

5. NEXT SONG ON USB/MICRO SD MEMORY CARD, NEXT CHANNEL ON FM MODE

6. PREVIOUS SONG ON USB/MICRO SD MEMORY CARD, LAST CHANNEL ON FM MODE

7. EQ EFFECT ON MP3 MODE

8. INCREASE SPEAKER VOLUME

9. CHOOSE SONG NUMBER DIRECTLY ON MP3 MODE

10. STOP BUTTON

11. DECREASE MUSIC VOLUME

12. REPEAT SONG ON USB/MICRO SD MEMORY CARD

www.PyleUSA.com

Page 3

1. USB Control Board

PPHP1243B

2. USB and Micro SD Memory card Input Jack

3. Master Volume Control Knob

4. 3.5MM AUX Input Jack

5. Short press to choose input signal, press and hold to turn OFF/ON light

6. Turning to the end left is power o, then turn it to the right end is power on

7. Echo Volume Control Knob

8. Microphone Volume Control Knob

9. Charge LED Indicator, RED color is charging mode, BLUE color is full charge

10. DC 5V Input Jack

11. 6.5MM Microphone Input Jack

Troubleshooting and Warning

12'' Portable Wireless BT PA Speaker System

Karaoke Speaker with Latest DJ LED Lights, USB/FM/BT/Aux/Remote

Control/Mic Inputs, Built-in Rechargeable Battery (800 Watt)

Features:

• True Wireless Stereo Function

• Portable PA Speaker System

• High-Powered Loudspeaker Design

• Wireless BT Music Streaming Ability

• Multi-Color Flashing LED Party Lights

• Built-in Rechargeable Battery

• LED Display

• USB/FM/Remote Control/Microphone Inputs

• Master Volume, Mic Volume, and Mic Echo Adjustable

Fault Possible Cause Solution

No sound

Distortion of sound

Karaoke does not work

MP3 does not play

www.PyleUSA.com

1. No input sound source

2. Volume is too low

1. Volume too high

2. Speaker may be damaged

1. Microphone plug is not fully inserted.

2. Microphone switch is not on

3. Microphone volume knob is at the lowest position

1. The song format in the U disc is incorrect

2. Improper operation has caused a process disorder

3. USB disc is disconnected

1. Use a better music signal

2. Adjust volume

1. Turn down the volume

2. If speaker is damaged, Repair or replace it

1. Plug microphone properly into the socket

2. Turn on microphone switch

3. Adjust microphone volume properly

1. Transform song format into Mp3 format

2. Reboot the machine

3. Insert USB disc properly

This products can expose you to a chemical or group of checmicals, which may include ”Lead and lead compounds” which is known in the state of California to cause cancer, birth defects, or other reproductive harm. For more info, go to https://www.p65warnings.ca.gov/.
