Pyle PPHP1049KT User guide

Download

Page 1

PPHP1049KT

Active + Passive PA Speaker System Kit

Dual Loudspeaker Sound Package, 10'' Subwoofers,

Bluetooth Wireless Streaming, Includes (2) Speaker Stands,

Wired Microphone, Remote Control, 1000 Watt

Page 2

PPHP1049KT

1. LCD screen

2. Mp3 control

MODE: USB/SD/BT/FM convertor : Play / Pause SCAN: Press and hold to auto search under FM radio FOL: Press and hold for 5 seconds to enter the folder option function mode (press the previous/next songs button to choose the folder) : Repeat one / Repeat all / Random : PRE/NEXT under FM mode Press and hold to search lower/ higher station manually : Short press to tune to saved station : Previous Song Press and hold for fast rewind : Next Song Press and hold for fast forward

4 5

6 7

MP3 CONTROL DI GITAL DISPLAY

USB

SD car d

MIC VO L MP3 VO L

MIN MA X

MIC

LINE I N

POWE R SWI TCH

-12 +1 2 -12 +1 2

BASS

AUX

AC:1 20- 240 V 50/60Hz

TREB LE

MIN MA X

MAST ER VO L

8Ω SPEA KER O UT

1 2

3. USB input

4. SD card input

5. Remote control

6. MIC level control

7. MP3 level control

8. Basscontrol

9. Treble control

10. XLR microphone line input

11. Line input

12. AUX input

13. Master volume

14. Speaker out 8Ohm

15. Main power switch

16. Fused IEC mains inlet

www.PyleUSA.com

Page 3

REMOTE CONTROL

1. MODE : USB/SD/BT/FM CONVERTER

2. : In USB/SD : Previous Song, Press and hold for fast rewind In FM : swich to backward

3. VOL + : Increase volume

4. VOL - : Decresse volume

5. : In USB/SD : next Song, Press and hold for fast forward In FM : swich to next channel

6. : Stop Switch the MP3 player o.

7. /SCAN : Play / Pause In FM : Auto search

8. EQ : NORMAL, ROCK, POP, CLASS, JAZZ.

9. REP : Shot press : Random/Single/Order

10. 0-9 : choosing music by numbers

11. MUTE : Mute the sound of the MP3 player

2 7 4 8

www.PyleUSA.com

Page 4

PPHP1049KT

Active + Passive PA Speaker System Kit

Dual Loudspeaker Sound Package, 10'' Subwoofers, Bluetooth Wireless

Streaming, Includes (2) Speaker Stands, Wired Microphone,

Remote Control, 1000 Watt

System Features:

• Dual 10-inch High-Powered Loudspeaker PA Systems

• Includes (1) Active Speaker, (1) Passive Speaker + (2) Stands

• Rugged, Durable & Reliable Sound

• Bluetooth Wireless Music Streaming Ability

• High-Frequency 1.0'' Tweeters

• Compression Driver with Titanium Diaphragm

• 2-Way Full Range Audio Projection

• Built-in Digital Audio Amplier

• XLR Microphone Input

• 1/4’’ SpeakOn (8 Ohm) Input

• 1/4’’ SpeakOn (8 Ohm) Speaker Output

• Aux (3.5mm) Input Jack

• Connect & Stream Audio from External Devices

• USB Flash Drive & SD Memory Card Readers

• Digital LCD Display

• Rear Panel Rotary Dial & Button Control Center

• Master Volume, Mic Volume, Treble, Bass Adjustable

• Integrated Carry Handles

• 35mm Speaker Stand Mount Compatible

• Heavy Duty Engineered ABS Housing

What's in the Box:

• (1) 10'' Active PA Speaker

• (1) 10'' Passive PA Speaker

• (2) Speaker Stands

• Wired Microphone

• Remote Control

• Power Cable

www.PyleUSA.com

Page 5

Bluetooth Wireless Streaming:

• Instantly Stream Music from Your Bluetooth Devices

• Works with All Your Favorite Bluetooth Devices

(iPhone, Android, Smartphone, iPad, Tablet, PC, etc.)

• Bluetooth Version: 4.0

• Bluetooth Wireless Range: 100'+ Feet

• Bluetooth Network Name: 'Pyle’

Speaker Stands:

• Eectively Elevates Speakers for Optimum Sound Performance

• Universal Speaker Compatibility (35mm Insert)

• Easy Setup and Quick Adjustment Control

• Reinforced Steel Support Construction

• Speaker Support Arm Extension

• Rugged and Reliable

• Safety Lock-in Pin

• Foldable for Quick Storage and Transport

• Rubber Capped Tripod Feet Base

• Perfect for On-Stage or Studio Use

• For Professional or Beginner Applications

• Speaker Height Adjustable: 59.1'' to 82.7''

• MAX. Load Capacity: 100 lbs. (50 kgs.) -Each

Technical Specs:

• MAX Power Output: 1000 Watt

• Amplier: Class D

• Impedance: 8 Ohm

• T.H.D.: <1%

• Magnet: 20 oz.

• Sensitivity: 92dB (+/-2dB)

• Mic Input Level: <15mV

• Line Input/Output Level: >250mV

• Frequency Response: 65-18kHz

• Digital Audio File Compatibility: MP3, WMA

• Maximum SD/USB Flash Memory Support: 32GB

• Power: 120/240V

• Single Speaker Weight: 18.08 lbs.

www.PyleUSA.com
