Pyle PPHP1044B User guide

Download

Page 1

PPHP1044B

Wireless BT Streaming PA Speaker System

Portable Indoor/Outdoor Loudspeaker with

Rechargeable Battery, Flashing Party Lights,

MP3/USB/Micro SD Readers, FM Radio

(10’’ Subwoofer, 600 Watt)

Page 2

WARNING

FEATURES

1. DO NOT place objects on top of the device, as objects may scratch the device.

2. DO NOT expose the device to dirty or dusty environments.

3. DO NOT insert any foreign objects into the device.

4. DO NOT expose the device to strong magnetic or electrical eld.

5. DO NOT use the device in the rain

6. Please check with your Local Authority or retailer for proper disposaI of electronic products.

This system can be used with personal computers, mobile phone, DVD, VCD, CD, LD,

TV, MP3, radio, electronic piano and any devices which have audio output. Amplier

circuit are using high-performance, high-delity design, coupled with high-quality

professional speaker, in order to make the sound eld to get positioned so clear,

distinct levels eect. The sound system is outstanding, with deep and powerful bass

and the treble eect is strong, with clear and bright pitch. The professional electronic

frequency division circuit enhances the machine's crossover point eect.

Using professional design and manufacture of high-capacity batteries, and dedicated

audio power capacitors, to make the speaker's power reserve margin larger, more

stable, better dynamics, higher signal to noise ratio.

BUILT-IN BT FUNCTION

Press "STANDBY/INPUT" button to choose the input signal source as BT channel

when starting the machine. Please ensure the BT devices you want to connect is

open. Then scan and connect the speaker with the device. When the connection is

7. DO NOT disassemble the device. Only a certied service technician should perform repair.

8. The device has apertures to disperse heat. DO NOT block the device ventilation, the device may become hot and malfunction as a result.

Illegal operation may cause personal injury, which could be fatal and may cause damage to property.

www.PyleUSA.com

successful, "tick" tone will prompt. If the speaker can't be connected, please restart

the speaker or the device and try again. After the mobile phone and the BT are

successfully connected, you can play music. To ensure continuous stability of the

music signal, try to keep the BT and the mobile phone facing one another.

This unit supports iPad, iPhone, Samsung, HTC, MOTOROLA, Nokia and other BT

mobile devices wirelessly transmitting audio. It supports stereo playing of A2DP.

The BT of the unit can be used up to 10 meters if there are no barriers.

www.PyleUSA.com

Page 3

BACK PANEL FUNCTIONS

1. USB Control board

2. USB and Micro SD Memory Card Slot

3. Master volume control knob

4. 3.5MM AUX input jack

5. Bass volume control knob

6. Treble volume control knob

7. Echo volume control knob

8. Microphone volume control knob

9. Charge LED indicator, red color is

on charge mode, blue color is full

charge mode

10. DC 9V input jack

11 6.5MM microphone input jack

12. Extra DC 12V input

13. Power switch

14. LED light switch

15. FM antenna

REMOTE CONTROL FUNCTIONS

1. Standby button

2. Choose input AUX/FM/BT/USB signal

3. Mute button

4. Play/Stop button on MP3 mode,

scan function on FM mode.

5. Next song on USB/Micro SD card, next channel on FM mode.

6. Previous song on USB/Micro SD card, last channel on FM mode

7. EQ eect on MP3 mode

8. Increase speaker volume

9. Choose song number directly on MP3 mode

10. Stop button

11. Decrease music volume

12. Repeat song on USB/Micro SD memory card

TROUBLESHOOTING

Fault

No sound

Distortion of sound

1. No input sound source.

2. Volume is too low.

1. Volume too high.

2. Speaker may be damaged

Possible Cause

1. Microphone plug is not fully

Karaoke does not work

inserted.

2. Microphone switch is not on.

3. Microphone volume knob is at the lowest position.

Solution

1. Use a better music signal.

2. Adjust volume.

1. Turn down the volume.

2. If speaker is damaged, repair or replace it.

1. Plug microphone properly into the socket.

2. Turn on microphone switch.

3. Adjust microphone volume properly.

www.PyleUSA.com

MP3 does not play

1. The audio format in the U disc is incorrect.

2. Improper operation has caused a process disorder.

3. USB disc is disconnected.

1. Convert audio format into Mp3 format.

2. Reboot the machine.

3. Insert USB disc properly.

www.PyleUSA.com

Page 4

PPHP1044B

Wireless BT Streaming PA Speaker System

Portable Indoor/Outdoor Loudspeaker with Rechargeable Battery, Flashing Party

Lights, MP3/USB/Micro SD Readers, FM Radio (10’’ Subwoofer, 600 Watt)

Features:

•

High-Powered PA Speaker

• Indoor/Outdoor Loudspeaker System

• Wireless BT Music Streaming Ability

• Multi-Color LED Flashing DJ Party Lights

• Built-in Rechargeable Battery

• FM Radio with Digital Display

• Audio Recording Function

• Microphone Priority ‘Talk-Over’ Button

• Rugged & Durable Housing Construction

• Connect & Stream Audio from External Devices

• USB Flash & Micro SD Memory Card Readers

• MP3 Digital Audio File Support

• Aux (3.5mm) Input

• 1/4’’ -inch Microphone Input

• Rear Panel Button Control Center

• Mic Volume, Treble, Bass, Echo Adjustment

• Full Range Stereo Sound Reproduction

• Vented Enclosure Design for Extended Bass

• Telescoping Handle & Rolling Caster Wheels

• *Optional Power via DC 12V Input

• Used for Backyard Home Karaoke, Stage Performances, Crowd Control

What's in the Box:

•

PA Speaker System

• Remote Control

• Power Adapter

Wireless BT Streaming:

•

Built-in BT for Wireless Music Streaming

• Simple & Hassle-Free Pairing

• Works with All of Today’s Latest Devices

(Smartphones, Tablets, Laptops, Computers, etc.)

• Wireless BT Version: 5.0

• Wireless BT Network Name: ‘PYLEUSA’

• Wireless Range: Up to 32’ ft.

Technical Specs:

• Power Output: 600 Watt MAX

• PA Speaker Type: Molded Cabinet Loudspeaker

• Sound System: 10 '' Subwoofer + 1’’ Tweeter

• Impedance: 4 Ohm

• Frequency Response: 55-20kHz

• S/N Ratio: 60dB +/-3dB

• SPL: 94dB (1W/M)

• T.H.D.: <1%

• USB Interface Type: 2.0

• Digital Media File Compatibility: MP3

• Maximum USB Flash Drive Support: Up to 32GB

• LED Lights Switch, Power ON/OFF

• PA Speaker Rechargeable Battery 7.4V Li-ion, 2200mAh - 16.2Wh

• Battery Powered Remote, Requires (1) x ‘CR-2025’, Included

• Power Supply: 120/240V (9V Power Adapter)

• Total Speaker Size (L x W x H): 11.8’’ x 9.6’’ x 17.7’’ -inches

Questions? Issues?

We are here to help! Phone: (1) 718-535-1800 Email: [email protected]
