Page 1
40 Watt Hand-Grip Type Megaphone
With 3.5 mm Aux-in for iPod/MP3 Player Connectivity
USER MANUAL
PMP43iN
Page 2
PMP43iN – Features
• Dry Cell Operation
• Full ABS Body, Sturdy & Lightweight
• Built-in Siren & Microphone
• Clear Sound, Long Range & Efficient Desi gn
• Conveni entl y Loca ted Vol ume Con trols & Swi tch
• Rechargeable Lithium Battery Included
• 3.5mm Aux-i n for i Pod/MP3 Player Connection
Operation
• Open the back cover by pressing down on the ‘Ope n’ Button
• Insert 6 x UM-1 Cells then close back cover until locks into position. Now, you’re megaphone is
ready for operation.
• To activate the megaphone, press the ‘ON/OFF’ button on the back cover.
• When using the megaphone, place your lips as close as possi bl e to the megap hone w he n
speaking. Adjust the ‘Volume Control’ to the desired level without causing any howling or
fee dback.
• Press the ‘Music’ button to activate soft music. Or press the ‘Siren’ button to activate
emergency siren/alarm. To switch off the alarm, press the same button again, or press the
‘ON/OFF’ button.
PRECAUTIONS
Ensure correct polarity of cells used. Insert the batteries in the correct direction by aligning the (-)
marks on the batteries with the spring in the back cover.
Use new batteries/cells whenever possible.
When the megaphone is not in use for a long period of time, remove the dry cells and replace.
Drained cells or rechargeable battery will not give sufficient sound volume.
SPECIFICATIONS:
Power O utpu t: 40 Watts
Voi ce Ra nge: 1,000 Yards
Power Sour c e: 6 x UM – 1 C ells (Not Included)
Ba tter y Li fe: 6 –84 Hours
Microphone: Unidirectional
Di mens i ons: Dia met er : 8” x Len gth: 13 1/8”
Weight: 2.20 LB S.
Desi gn & S pecifica ti ons su bject to chan ge with out pri or notice
Page 3
PMP43iN – Megaphone Controls & Features Diagram
With 3.5 mm Aux-in for iPod/MP3 Player Connectivity
40 Watt Hand-Grip Type Megaphone
PMP43iN
USER MANUAL
