Pyle PLMRMP3A, PLMRKT4A User Manual

PLMRKT4A
4 CHANNEL WATERPROOF AMPLIFIED
6.5” MARINE SPEAKER SYSTEM
PLMRMP3A
4 CHANNEL WATERPROOF MARINE POWER AMPLIFIER
www.pyleaudio.com
OWNER’S MANUAL
It’s compact, waterproof design allows for flexible mounting possibilities, and makes it simple to expand the audio system capabilities for vehicle.
PLMRKT4A 4 CHANNEL WATERPROOF AMPLIFIED 6.5” MARINE SPEAKER SYSTEM
Two Pairs 6.5'' 2-Way Marine Speakers:
● 6.5'' High Quality Polypropylene Cone
● Suspension Cloth Surround
● White Plastic Enclosure
● 2” Polymer Cone Tweeter
● 100 Watts RMS / 200 Watts Peak
● Frequency Response: 80-20KHz
● Impedance: 8 Ohms
One Piece PLMRMP3A 4 Channel Waterproof Marine Power Amplifier
● 4 x 100 Watts RMS at 4 Ohms
● 4 x 200 Watts Max at 4 Ohms
● 4 x 300 Watts RMS at 2 Ohms
● Electronic Crossover Network
● 2 Ohms Stereo Stable
● Anti-Thump Turn-On
● Soft Turn On/Off
● Adjustable High Low Level Inputs
● RCA Line Input
● Power Protection Circuitry
● Volume Gain Remote Control
● T.H.D: <0.05%
● S/N Ratio: >95dB
● Channel Separation: >65dB
● Frequency Response: 10Hz- 40kHz
● Fuse : 10A
● Dimensions: 6.10”Lx3.35”Wx1.38”H
Accessories:
● iPod / MP3 Waterproof Poly Bag
● iPod / MP3 Waterproof 3.5mm Stereo to RCA Adaptor
● Remote Control for Volume Gain
1
