Pyle PLDVRCAM71 User Manual

PLDVRCAM71

DVR DASH CAM

Full HD 1080p Vehicle Dash Camera

Video Recording System

USER MANUAL

INTRODUCTION

PLDVRCAM71 DVR Dash Cam is developed to nd evidence
in case of trac accident.

This camera can also be used in other occasions such as
meetings, monitoring and forensics, location shooting and
video evidence.
This product is a blend of wide dynamic digital industry
leading camera, no leakage of seconds, seamless circular
camera, ultra wide angle shooting, with display real-time
playback, mobile detection camera, parking guard
technology in one; streamline design of unique fashion,
favored by the vast number of consumers.
This manual will detail how to install, operate, product
parameter and matters needing attention. Please read
carefully and keep for future reerence before use.
The specication parameters may be due to upgrade, update
and other reasons do change, refer to the actual product,
without prior notice. The manufacturer reserves without prior
notice, to change the technology of direct rights.

Infringement of copyright or privacy notice

Please note that this product is for personal use only, its use
shall not violate domestic or international copyright / privacy
laws. The image is for personal use only recorded, not foreign
free to publish spread; in addition the product record show,
exhibition or commercial activities of the image may in some
cases infringe copyright or the legal rights and interests.

www.PyleUSA.com

2

INSTALLATION NOTES

This product should be tied together with the original
rear-view mirror. To determine the lens in the windshield
wiper is in range, ensure good vision, and also good in rainy
environments. Don't touch the lens with your ngers, the
nger’s grease may remain in the lens, resulting in camera or
photograph to be unclear, please clean the lens regularly.

Attention

• Please use the original standard charger

• Please do not dismantle the machine to avoid aecting the

scope of warranty.

• Please nd a professional to modify the power line.

PRODUCT STRUCTURE DESCRIPTION

3

www.PyleUSA.com

1. MIC Interface

2. Micro SD Memory Card Slot

3. Knob

4. USB Interface

5. GPS Interface (optional)

6. AV Interface

7. MIC Indicator

8. Power Indicator

9. REC Indicator

10. Screen

11. MIC Button

12. REC Button

13. OK Button

14. Menu Button

15. Power Button

16. Pedestal

17. Reset Button

18. Cable Slot

Description of Button Functions

1. <Power> Button

Function 1: Power ON/OFF

In power-OFF state, press the <Power> button to power ON
DASHCAM. The DASHCAM begins to work automatically. In
power-ON state, press and hold the <Power> button for ve
seconds. Then, the DASHCAM saves the video-recording le
automatically and powers OFF.

FUNCTION 2: TURN ON/OFF SCREEN

In power-ON state, press the <Power> button to disable the
back-light of the screen, and press any button to resume the
back-light of the screen (This function only acts upon the
back-light of the screen without aecting the video recording
function).

2. <Menu> Button

FUNCTION 1: MENU BUTTON

In standby state, press the <Menu> button to enter the
function setting table of the main menu. Press the <REC> or
<MIC> button to select the desired option, and press the
<OK> button to conrm the selected option. After

completing the setting, press the <Menu> button to exit the
menu setting function.

www.PyleUSA.com

4

3. <OK> Button

FUNCTION 1: LOCKING

During the video-recording process, press the <OK> button
to save the video-recording data into a separate folder in the
memory card. The les in the folder will not be overwritten
cyclically.
NOTE: In playback mode, a key-shaped icon in the miniature
icon list indicates that the audio recording is locked.

FUNCTION 2: PHOTOGRAPH

In photograph mode, press the <Record> button to take
photos.

FUNCTION 3: CONFIRMATION

During the menu setting process, press the <OK> to conrm
the settings.

FUNCTION 4: PLAY

In playback mode, press the <OK> button to play video data
and press the <OK> button again to suspend.

FUNCTION 5: ESCAPE

In playback mode, press and hold the <OK> button for ve
seconds to switch the current interface to the recording
interface.

4. <REC> Button

FUNCTION 1: PAGE UP

In the menu setting and playback modes, you can press
<Up>to page up.

FUNCTION 2: FAST BACKWARD

In playback state, press the <REC> button to enter the fast
backward mode.

FUNCTION 3: VIDEO-RECORDING

In standby state, press the <REC> button to begin recording,
and press the <REC> button again to stop.

5

www.PyleUSA.com

5. <MIC> Button

FUNCTION 1: PAGE DOWN

In the menu setting and playback modes, you can press the
<Down> button to page down.

FUNCTION 2: FAST FORWARD

In playback state, press the <MIC> button to enter the fast
forward mode.

FUNCTION 3: MODE SWITCHING

In standby state, press the <MIC> to enter the photograpy
mode, and press the <MIC> again to enter the playback
mode. On the playback interface, you can page up/down and
press the <OK> to select the desired le.

FUNCTION 4: DISABLE THE AUDIO-RECORDING FUNCTION

In recording mode, press the <MIC> button to disable the
audio-recording function. Then, the MIC indicator is turned
o. Press the <MIC> button again to enable the audio

-recording function. Then, the MIC indicator is turned on.

6. <Reset> Button

If the DASHCAM is crashed, press the <Reset> button to
power o the DASHCAM.

INSTALLATION

1. Fixing the camera to the window mount

It is compulsory for window mount to be xed up before
using the device in the car. Make sure that you place the
recorder in an appropriate place, so as not to obstruct the
driver’s view.

2. Connecting charger to the cigarette lighter

Connect only the manufacturer-approved charger supplied
with your device. Use only approved charger specically
designed for your device. Incompatible charger can cause
serious injuries or damage to your device.

www.PyleUSA.com

6

3. Inserting a memory card

You have to insert a memory card before you can start
recording. The recorder supports Micro SD cards with up to
32GB capacity. You are advised to use a Class 10 memory
card with at least 8GB capacity. DO NOT insert or remove
the memory card when operating the device.

OPERATION GUIDE
I. Installing the DASHCAM

1. Power o the automobile engine.

2. Insert the Memory card into the Memory card slot.

NOTE:

a. The 1080P format is adopted for the video-recording
function, and large amount of data will be generated for
the video-recording function. To prevent system crash, you
are recommended to use well-branded high-speed TF card
(Class 10) with a capacity of at least 4 GB. The Memory card
supports a maximum capacity of 32 GB.
b. The data recorder does not support hot plugging of the
Memory card. Be sure to remove the Memory card after
powering o the data recorder.

3. Secure the DASHCAM to the front windshield of the
automobile.
NOTE: Mount the DASHCAM in a safe place with ample light.
Preferably, the DASHCAM should be mounted on both sides
of the rearview mirror. Before pasting and mounting the
DASHCAM, clear the impurities and moisture in the pasting
position by using a clean and soft cloth.

4. Fix the power cable properly by using the cable slot and
cable clip, preventing the line of sight from being aected.

5. Insert the in-vehicle charger into the cigar lighter of the
automobile.

7

www.PyleUSA.com

6. Insert the charging interface of the in-vehicle charger into
the USB interface the data recorder.

7. Adjust the angle of the data recorder, ensuring that the
camera lens keeps level with the ground.

8. Start up the engine and check whether the DASHCAM is
mounted properly.

II. Function Description

1. Automatic Recording

After you start up the automobile engine, the DASHCAM
will automatically start and recording function will be
enabled. In addition, the system indicator and power
indicator are turned on, and the REC indicator on the screen
blinks. After you turn o the automobile engine, the
DASHCAM saves the recorded content automatically and
will be powered o. The recorded images are saved
segment by segment in the Memory card. When the
Memory card saved images is at full capacity, the data
recorder overwrites the early recorded images.
NOTE: You can set the time period of recording in the menu.
The time period can be set to 1 minute, 3 minutes, and 5
minutes. The default time period is 3 minutes.

2. Manual Recording

Press the <Power> button, the DASHCAM is powered on
and begins to record data automatically. Press and hold the
<Power> button for 5 seconds, and then the DASHCAM
saves the recording data automatically and is powered o.

3. Photography Function

In standby state, press the <MIC> button to enter the
photography mode. Then, the icon in the upper left of the
screen is changed from a video camera to a still camera.

www.PyleUSA.com

8

Press the <OK> button to take photos. To switch back to
the video-recording mode, press the <MIC> button and
press and hold the <OK> button for ve minutes.

4. Collision Sensing

The DASHCAM is tted with a built-in collision sensor
(G-sensor). In case of severe vehicle collision, the
DASHCAM locks the image data generated at the time of
the accident, and displays a lock icon in the middle of the
screen. [Prompt] The collision sensor (G-sensor) supports
sensitivity adjustment. By default, sensitivity adjustment is
<O>. You can change the sensitivity settings as needed in
the setting menu.

5. Date and Time Setting

In standby state, press the <Menu> button twice to enter
the system setting menu. Press the <Down> button to
move the cursor to the <Set the date> option. Press the
<OK> button to conrm it, and enter the <Setting> menu.
[Prompt] Press the <Up> and <Down> buttons to select
values, press the <Menu> button to proceed to the next
option, and press the <OK> button to conrm the option
and then exit. [Note] To eectively record the date and
time of obtaining the evidence of the trac accident, set a
correct date and time before using the DASHCAM.

6. USB Mode

Connect the data recorder to the USB interface of a PC by
using a data cable. Then, the screen displays two modes:
memory and camera. Press the <Up> or <Down> button to
select the <Memory> option. Press the <OK> button to
enter the USB ash disk mode.

9

www.PyleUSA.com

[Prompt] When you use a PC to copy a video-recording le,
it is recommended that you use a card reader to copy the
video-recording le in the TF card to the PC.

7. Playback of Recording File

In power-on state, press the <MIC> button twice to enter
the playback mode. Press the <Up> or <Down> button to
nd the desired type of le, and press the <OK> button to
play back the le.

8. PC Camera

Connect the data recorder to the USB interface of a PC by
using a data cable. Then, the screen displays two modes:
memory and camera.
Press the <Up> or <Down> button to select the <Camera>
option. Press the <OK> button to enter the PC camera
mode. After a driver is installed in the PC, <My Computer>
displays the camera icon. Double-click the camera icon to
turn on the camera.

www.PyleUSA.com

10
