Pyle PLDHR924 User guide

PLDHR924

Touchscreen Multimedia Disc Player

Vehicle Headrest Mount Multimedia Entertainment

System (9.4’’ -inch Display)

FRONT PANEL

MULTIMEDIA PLAYER

1. LCD Panel

2. MENU

11

3. RETURN

4. POWER

5. Pre/rewind forward

6. Next/Fast

7. DC 12V

8. AV2 In jack

9. Earphone jack

10. Micro SD Memory Card Slot

11. USB read port

SIDE PANEL

1. Power

2. Earphone/AV2 jack

10

8

9
7

1

2 3 654

3. USB TF port

4. DC 12v Jacket

www.PyleUSA.com

2

1. Main Menu

You can choose DVD disc, USB, Micro SD Memory Card, AV1 and AV2.

2. DVD disc menu

3

www.PyleUSA.com

3. Second main menu, you should touch middle of panel from right to
left to move.

You can simply access all features by tapping on the touch screen buttons.
Tap the icons to enter a desired mode.

Select Language/Beep/Car Logo/Background/Aspect ratio and IR setup

4

www.PyleUSA.com

4. Infrared Setup

5. FM Setup

5

www.PyleUSA.com

6. USB Card Read

7. SD Card Read

www.PyleUSA.com

6

INSTALLATION

1. Take out the machine, remove the bracket.

2. Remove the screws from bracket.

3. Put the plastic bracket parts in between two metal poles ,at the same
time, push 2 screws to x up bracket.

4. Hold up unit, insert the metal plate in black of the unit into plastic bracket
parts, then adjust it to the right angle and x it tightly, at last lower the
orignal car headrest to the appropriate position.

7

www.PyleUSA.com

WIRING

Audio Out Right (Red)
Audio Output Left (White)

Video Output (Yellow)
VIdeo Input (Yellow)

Audio Input Right (Red)
Audio Input Left (White)

DC + 12V (Red)
GND (Black)

Attention

1. Do not put the machine in the rain or damp environment lest outbreak of

re or any damage to machine.

2. Do not repair the machine by youself. Please turn o the machine and

inform us if any problem found, the factory or the agent will arrange

specialized personnel to disassemble and repair the machine for you .

3. Please keep the machine away from dampness, dust, oil and straight

sunlight.

4. Do not use diluents or other chemical cleaner when cleaning the machine.

Please clean the machine by soft cloth with special cleaner.

5. Please keep the machine in a good environment. The storage temperature

for this machine is from 68 °F to 70T and the operating temperature for

this machine is from -10T to 140 °F.

6. This machine supports 1080P and most video le like DIVX/MPEG4 /

MP3/WMAR/JPEG

7. Please prevent the machine from the inuence of other equipment.

8. For your safty,please do not turn or operate this machine when driving as

it may be ileagal in some countries and regions.

9. Safe power supply: DC12V (voltage range:10V-14V)

10. There may be some small and bright spots on the screen. This is a

common technical matter and does not indicate any quality problem of

this machine.

8

www.PyleUSA.com

TROUBLESHOOTING

TROUBLES

No sound

and image

No image

No sound

Black screen

Blurring and

unstable image

Color cast

No power

No image after

loading the disc

Instable sound

caused by

vibration

SOLUTIONS

Power is disconnected;
the machine is not turned ON

signal wire is disconnected

Volume too low or the volume setup is not workable

Incorrect setup of image luminance and contrast;
Undervoltage

Disc is scratched

function menu setup is incorrect; weak signal

Voltage is not accurate: check interconnect circuit;
Fuse is disconnected: change fuse specication

Only audio frequency for the disc;disa is scratched;
disc for format is not supported

DVD is dirty or seriously damaged

Instable sound

even with no

Disc is dirty or scratched clean or replace the disc

vibration

CLEANING

• Do not leave this product submerged in water

• When cleaning the device, use a clean dry cloth to wipe the device clean.

(Do not use solvents).

• Clean only with a clean and dry cloth.

9

www.PyleUSA.com

PLDHR924

Touchscreen Multimedia Disc Player

Vehicle Headrest Mount Multimedia Entertainment System

(9.4’’ -inch Display)

Features:

• Universal Vehicle Headrest Mount Display

• Audio & Video Entertainment System

• Touchscreen Display Panel

• Top-Loading CD/DVD Player

• Hi-Res LCD Wide-Screen Video

• Full HD 1080 Support

• User-Friendly Control Interface

• Built-in Stereo Speakers

• FM Radio Transmitter

• Front Panel Button Controls

• Connect & Stream External Devices

• USB Flash & Micro SD Memory Card Readers

• Digital File Playback: Audio, Image & Video Files

• Headphone Jack, 3.5mm

• RCA (Audio/Video) Wiring Harness

• Convenient Removable Leather Screen Cover

• Built-in IR Transmitter Support for Wireless IR Headphones

• Easily Attaches to Front-Seat / Back-Seat Headrests

• Includes All Necessary Hardware & Cables for Installation

• *Can be Hard-Wired or Powered via Included Plug-in Cigarette

Lighter Power Cable

10

www.PyleUSA.com

What’s in the Box:

• 9.4’’ -inch CD/DVD Player

• Headrest Mounting Bracket

• Remote Control

• Power Wiring Harness Cable

• Cigarette Lighter Power Cable

Technical Specications:

• Display Type: LCD, 9.4’’ -inches

• Video System: PAL / NTSC Compatible Auto Switching

• Aspect Ratio: 16:9

• Screen Resolution: 800 x 480 Pixels

• Contrast Ratio: 300:1

• Brightness: 350 cd/m2

• English OSD Menu

• Maximum USB/SD Card Size: 32GB

• CD/DVD Player Support: DVD/VCD/MP3/JPG/MP4/CD-R/CD-RW

• Digital File Compatibility: MP3, MP4, MP5, JPG, MPEG4, WMA, AVI

• Power Supply: DC 12V

• Dimensions (L x W x H): 9.3'' x 6.2'' x 2.0’’ -inches

• Sold as: 1

11
