Page 1
PLCMDVR54
DASH CAM
Rearview Backup and Driving HD Camera Record Kit 1080p Night Vision Cam Video Recording System
Page 2
CONTENTS
1
2 KEY DEFINITION ......................................................................................................................................... 3
1 DVR POWER ON/OFF ...................................................................................................................................4
2 DRIVING RECORD FUNCTION....................................................................................................................4
3 MOTION DETECTION ...................................................................................................................................5
4 CAMERA FUNCTION ....................................................................................................................................6
5 BROWSER .........................................................................................................................................................7
5.1 REC FILES ......................................................................................................................................................8
5.2 SOS FILES ......................................................................................................................................................9
5.3 MOTION DETECTION ................................................................................................................................9
5.4 PHOTO FILES..............................................................................................................................................10
6 SETTINGS........................................................................................................................................................11
6.1 VIDEO QUALITY.........................................................................................................................................11
6.2 PHOTO SIZE ...............................................................................................................................................12
6.3 LOOP RECORDING...................................................................................................................................13
6.4 SOUND RECORD ..................................................................................................................................... 14
6.5 AUTO OFF....................................................................................................................................................14
6.6 MD SENSITIVITY........................................................................................................................................15
6.7 COLLISION SENSITIVITY ........................................................................................................................16
6.8 COLLISION REC TIME ..............................................................................................................................16
6.9 GSENSOR.................................................................................................................................................. 17
6.10 BUTTON SOUND................................................................................................................................... 17
6.11 VOLUME SETTING................................................................................................................................. 18
6.12 BACKLIGHT TIME .................................................................................................................................. 18
6.13 LIGHT FREQUENCY............................................................................................................................... 19
6.14 SET CLOCK ............................................................................................................................................. 19
6.15 LANGUAGE ............................................................................................................................................ 20
6.16 RESET SETUP........................................................................................................................................... 21
6.17 ABOUT CAR DVR................................................................................................................................... 21
7 FORMAT......................................................................................................................................................... 22
3 INSTALLATION............................................................................................................................................23
4 SYSTEM MESSAGE....................................................................................................................................26
1
www.PyleUSA.com
Page 3
BASIC PARAMETERS
SPECIFICATIONS
ITEMS VALUE
Lens 500 million pixels, 140 degree high resolution wide angle lens
Lens Aperture F/1.8
Optic 6 glass high-level coating lens+ infrared lter
Display 4.3 inch TFT display
Recording Resolution 1920x1080@ 30fps, 1280x720@ 30fps
Memory Card 4GB/8GB/16GB/32GB/64GB/128GB TF High Speed Memory Card
Video Mode Continuous Video, Accident Recording, Parking Video
G-Sensor Built-in three-axis G-Sensor, three sensitivity settings level
Video Encoding H.264, MOV le format
Audio Supports Recording and Loudspeaking
Language
English, Simplied Chinese, Traditional Chinese, Korean, Russian, French, German, Japanese
Loop Recording 1 minute, 2 minutes, 3 minutes
Memory Capacity 1G
Number of Cores Dual Core
Battery Buitl-in Polymer Li-ion Battery
DVR Installation Type Rear View
Number of Lens 3
www.PyleUSA.com
2
Page 4
KEY DEFINITION
BACK UP CAMERA
USB RESET
LCD
Charging Indicator
MIC
MENU
DOWN
Clip on Bracket
POWER
OK Night Lamp
UP
Recording Light
Lens
Micro SD Slot
Speaker
3
www.PyleUSA.com
Page 5
1. DVR POWER ON/OFF
Startup screen Shutdown screen
DVR POWER ON
• Connect external power supply or press to turn on the power
DVR POWER OFF
• Press for 2 seconds, to turn off the power. After setting auto power off time, when
there is no external power supply, the system will start the countdown and will shut down when countdown ends.
• Low battery will cause automatic power off (3.6V).
Notes:
Restore factory settings before your rst use. Rear view camera will close if there is no external power source. Never pull out SD card when recording.
2. DRIVING RECORD FUNCTION
Driving Record Image Recording
FUNCTION DESCRIPTION
• It will start recording automatically after power on. Video icon will keep ashing when
recording.
• Recording will stop if there is no SD card or not inserted properly.
• Loop recording mode will automatically overwrite old les for non-stop recording.
www.PyleUSA.com
4
Page 6
ICONS
Normal Recording
1920x1080@ 30fps
Sound Recording On
Mute
Loop Recording 1 Minute
Connect External Power Supply
Emergency Recording
KEY DEFINITION
1280x720@ 30fps
Sound Recording Off
Prompt Tone On
Loop Recording 2 Minutes
Full Battery
Record Time
Loop Recording 3 Minutes
Key Operation Denition
Shutdown
Turn off backlight
Back to menu
M
Long press for 2 seconds
Short press
Short press
Short press
Short press
Full screen display switch between
front camera and rear camera
Rear camera display switch
Short press
ok
Long press
Take picture
Emergency recording
Exit emergency recording
3. MOTION DETECTION
Motion Detection Recording image
FUNCTION DESCRIPTION
• Video icon will keep ashing when recording.
• Recording will stop if there is no SD card or SD card were not inserted properly.
• If motion detection recording is on when the car stop, the screen display will still be
on when the video screen changes. It will start recording and saving les to the TF card.
5
www.PyleUSA.com
Page 7
ICONS
Normal Recording
1280x720@ 30fps
1920x1080@ 30fps
Sound Recording On
Mute
Motion detection recording 10 seconds
Connect External Power Supply
Emergency Recording
KEY DEFINITION
Sound Recording Off
Prompt Tone On
Full Battery
Record Time
Key Operation Denition
Shutdown
Turn off backlight
Back to menu
M
Long press for 2 seconds
Short press
Short press
Short press
Short press
Full screen display switch between
front camera and rear camera
Rear camera display switch
Short press
ok
Long press
Invalid Operation
Invalid Operation
4. CAMERA FUNCTION
Camera function Camera
FUNCTION DESCRIPTION
• In this mode you can shoot photos of the following sizes: 14MP(4352 x 3264) 12MP(4000 x 3000) 8MP(3264 x 2448) 5MP(2560 x 1920) 3MP(2048 x 1536) 2MP(1920 x 1080)
1.2MP(1280 x 960) VGA(640 x 480)
• If you need to change the size of the photo, go to setting menu and change the setting.
www.PyleUSA.com
6
Page 8
KEY DEFINITION
Key Operation Denition
5. BROWSER
M
ok
Long press for 2 seconds
Short press
Short press
Short press
Short press
Short press
Long press
Shutdown
Turn off backlight
Back to menu
Invalid Operation
Invalid Operation
Take picture
Invalid Operation
FUNCTION DESCRIPTION
The number shows the quanTIty of documents contained in the four project folders 'REC Files', 'SOS Files', 'MD Files', 'Photos Files'.
Folder with les Folder without les
7
www.PyleUSA.com
Page 9
KEY DEFINITION
Key Operation Denition
5.1 REC FILES
M
ok
Long press for 2 seconds
Short press
Short press
Short press
Short press
Short press
Long press
Shutdown
Turn off backlight
Back
Left
Right
Enter Sub-option
Invalid Operation
REC Files File List
FUNCTION DESCRIPTION
• Choose the folder and press 'ok' to enter le list.
• Press 'ok' again to play the video le.
KEY DEFINITION FOR 'REC FILES FOLDER OPERATION'
Key Operation Denition
Long press for 2 seconds
Short press
M
ok
Short press
Short press
Short press
Short press
Long press
Enter the le list of the folder
Invalid Operation
Shutdown
Delete folder
Back to menu
Up
Down
www.PyleUSA.com
8
Page 10
KEY DEFINITION FOR 'FILE LIST'
Key Operation Denition
Long press for 2 seconds
Short press
M
Short press
Short press
Short press
Short press
ok
Long press
KEY DEFINITION WHEN PLAYING VIDEO FILE
Key Operation Denition
Long press for 2 seconds
Short press
M
Short press
Short press
Shutdown
Delete le
Back to REC les folder
Up
Down
Play video le
Invalid Operation
Shutdown
Invalid Operation
Back to le list
Play last video le
Short press
Short press
ok
Long press
5.2 SOS FILES
The operation and key denition is same as 'REC Files'.
5.3 MD
The operation and key denition is same as 'REC Files'.
5.4 PHOTOS FILES
Play next video le
Play/Pause
Invalid Operation
Photos Files File List
9
www.PyleUSA.com
Page 11
FUNCTION DESCRIPTION
• Choose the folder and press 'ok' to enter le list.
• Press 'ok' again to preview the photos..
KEY DEFINITION FOR 'PHOTOS FILES' FOLDER OPERATION
Key Operation Denition
Long press for 2 seconds
Short press
M
Short press
Short press
Short press
Short press
ok
Long press
KEY DEFINITION FOR 'FILE LIST'
Key Operation Denition
Long press for 2 seconds
Short press
M
Short press
Short press
Short press
Shutdown
Delete folder
Back to menu
Up
Down
Enter the le list of the folder
Invalid Operation
Shutdown
Delete folder
Back to previous page
Up
Down
Short press
ok
Long press
KEY DEFINITION WHEN PREVIEWING PHOTOS
Key Operation Denition
Long press for 2 seconds
Short press
M
ok
Short press
Short press
Short press
Short press
Long press
Preview photos
Invalid Operation
Shutdown
Invalid Operation
Back to le list
Last photo
Next photo
Back to le list
Invalid Operation
www.PyleUSA.com
10
Page 12
SETTINGS
KEY DEFINITION
Key Operation Denition
M
ok
6.1 VIDEO QUALITY
Long press for 2 seconds
Short press
Short press
Short press
Short press
Short press
Long press
Shutdown
Turn off backlight
Invalid Operation
Left
Right
Enter Sub-option
Invalid Operation
VIDEO QUALITY
• 1920 X 1080 Frame rate 30fps
• 1280 X 720 Frame rate 30fps
11
www.PyleUSA.com
Page 13
KEY DEFINITION
Key Operation Denition
6.2 PHOTO SIZE
M
ok
Long press for 2 seconds
Short press
Short press
Short press
Short press
Short press
Long press
Shutdown
Turn off backlight
Back to menu
Up
Down
Enter sub-option and change setting
Invalid Operation
Photo Size setting 1 Photo Size setting 2
PHOTO SIZE
14MP(4352 x 3264) 12MP(4000 x 3000)
8MP(3264 x 2448) 5MP(2560 x 1920)
3MP(2048 x 1536) 2MP(1920 x 1080)(Default se�ng)
1.2MP(1280 x 960) VGA(640 x 480)
KEY DEFINITION
Key Operation Denition
Shutdown
Turn off backlight
Back to menu
Down
Enter sub-option
Invalid Operation
M
ok
Long press for 2 seconds
Short press
Short press
Short press
Short press
Short press
Long press
Up
www.PyleUSA.com
12
Page 14
KEY DEFINITION FOR 'PHOTO SIZE SETTING 2'
Key Operation Denition
M
ok
6.3 LOOP RECORDING
Long press for 2 seconds
Short press
Short press
Short press
Short press
Short press
Long press
Shutdown
Turn off backlight
Back to previous menu
Left
Right
Conrm setting
Invalid Operation
Loop recording 1 Loop recording 2
Loop recording time can be set to 1 minute/ 2 minutes/ 3 minutes for each le. Default setting is 1 minute.
KEY DEFINITION
Key Operation Denition
Shutdown
Turn off backlight
Back to menu
Up
Down
Enter sub-option
Invalid Operation
M
ok
Long press for 2 seconds
Short press
Short press
Short press
Short press
Short press
Long press
13
www.PyleUSA.com
Page 15
6.4 SOUND RECORD
FUNCTION DESCRIPTION
• ON: Record video with sound (default setting)
• OFF: Record video without sound.
KEY DEFINITION
Key Operation Denition
6.5 AUTO OFF
M
ok
Long press for 2 seconds
Short press
Short press
Short press
Short press
Short press
Long press
Shutdown
Turn off backlight
Back to menu
Up
Down
Enter sub-option
Invalid Operation
Set auto power off time (10 s, 30 s, 1 minute) when external power source is unplugged.
Choose 'OFF' to close this function.
www.PyleUSA.com
14
Page 16
KEY DEFINITION
Key Operation Denition
M
ok
6.6 MD SENSITIVITY
Long press for 2 seconds
Short press
Short press
Short press
Short press
Short press
Long press
Shutdown
Turn off backlight
Back to menu
Up
Down
Enter sub-option
Invalid Operation
FUNCTION DESCRIPTION
Motion detection sensitivity: HIGH, MIDDLE, LOW.
This DVR is built-in acceleration sensor, which can detect sudden change of acceleration
(collision or emergency braking), and instantly trigger recording before accident happens.
KEY DEFINITION
Key Operation Denition
Shutdown
Turn off backlight
Back to menu
Up
Down
Enter sub-option
Invalid Operation
M
ok
Long press for 2 seconds
Short press
Short press
Short press
Short press
Short press
Long press
15
www.PyleUSA.com
Page 17
6.7 COLLISION SENSITIVITY
Collision sensitivity: OFF(Default setting), HIGH, MIDDLE, LOW.
KEY DEFINITION
Key Operation Denition
M
ok
6.8 COLLISION REC TIME
Long press for 2 seconds
Short press
Short press
Short press
Short press
Short press
Long press
Shutdown
Turn off backlight
Back to menu
Up
Down
Enter sub-option
Invalid Operation
After parking the car, if theres a certain intensity of shaking or vibration, the DVR will turn on automatically and start recording. When image is static again, it will enter countdown and shutdown when countdown ends. If theres still shaking or vibration during countdown, it will continue to record and enter countdown again when image is static.
COLLISION RECORDING TIME SETTING
Under collision recording, set auto power off time (10s, 20s, 30s) after the static image.
www.PyleUSA.com
16
Page 18
KEY DEFINITION
Key Operation Denition
6.9 G-SENSOR
M
ok
Long press for 2 seconds
Short press
Short press
Short press
Short press
Short press
Long press
Shutdown
Turn off backlight
Back to menu
Up
Down
Enter sub-option
Invalid Operation
OFF/HIGH/MIDDLE/LOW sensitivity for different environment. MIDDLE is the Default
setting.
KEY DEFINITION
Same as 'Collision REC Time' setting.
6.10 BUTTON SOUND
• ON: Turn on button sound.
• OFF: Turn off button sound.
17
www.PyleUSA.com
Page 19
KEY DEFINITION
Key Operation Denition
M
ok
6.11 VOLUME SETTING
Long press for 2 seconds
Short press
Short press
Short press
Short press
Short press
Long press
Shutdown
Turn off backlight
Back to menu
Up
Down
Enter sub-option
Invalid Operation
Volume setting on Mute or 5%-100%
KEY DEFINITION
Same as 'Button Sound' setting.
6.12 BACKLIGHT TIME
• ON: Turn on backlight all the time (Default setting).
• 30s: Turn off backlight after no operation for 30s.
• 1 min: Turn off backlight after no operation for 1 minute.
• 5 min: Turn off backlight after no operation for 5 minutes
www.PyleUSA.com
18
Page 20
KEY DEFINITION
Same as above.
6.13 LIGHT FREQUENCY
• 50Hz: Remove light frequency interference of 50Hz (Default setting).
• 60Hz: Remove light frequency interference of 60Hz. NOTE: This function is to remove the interference of indoor uorescent light 50Hz or 60Hz
to system CMOS image.
KEY DEFINITION
Same as above.
6.14 SET CLOCK
Set Clock 1 Set Clock 2
KEY DEFINITION FOR 'SET CLOCK 1'
Key Operation Denition
Long press for 2 seconds
Short press
M
Short press
Short press
Short press
Shutdown
Turn off backlight
Back to menu
Up
Down
ok
Short press
Long press
19
Enter sub-option
Invalid Operation
www.PyleUSA.com
Page 21
KEY DEFINITION FOR 'SET CLOCK 2'
Key Operation Denition
6.15 LANGUAGE
M
ok
Long press for 2 seconds
Short press
Short press
Short press
Short press
Short press
Long press
Shutdown
Turn off backlight
Switch among year, month, date,
hour, minute and second
+
-
Conrm setting
Invalid Operation
The system supports English, Simplied Chinese, Traditional Chinese, Korean, Russian, Deutsch, French and Japanese.
KEY DEFINITION
Key Operation Denition
Shutdown
Turn off backlight
Back to menu
Up
Down
Enter sub-option
Invalid Operation
M
ok
Long press for 2 seconds
Short press
Short press
Short press
Short press
Short press
Long press
www.PyleUSA.com
20
Page 22
6.16 RESET SETUP
Initialize all settings to factory default settings
KEY DEFINITION
Key Operation Denition
M
ok
6.17 ABOUT CAR DVR
KEY DEFINITION
Long press for 2 seconds
Short press
Short press
Short press
Short press
Short press
Long press
Shutdown
Turn off backlight
Back to menu
Up
Down
Enter sub-option
Invalid Operation
Key Operation Denition
Shutdown
Turn off backlight
Back to menu
Up
Down
Enter 'About Car DVR'
Invalid Operation
www.PyleUSA.com
M
ok
Long press for 2 seconds
Short press
Short press
Short press
Short press
Short press
Long press
21
Page 23
7. FORMAT
Format 1 Format 2
KEY DEFINITION FOR 'FORMAT 1'
Key Operation Denition
Long press for 2 seconds
Short press
M
Short press
Short press
Short press
Short press
ok
Long press
KEY DEFINITION FOR 'FORMAT 2'
Key Operation Denition
Long press for 2 seconds
Short press
M
Short press
Short press
Short press
Shutdown
Back to DVR recording
Invalid operation
Left
Right
Enter sub-option
Invalid Operation
Shutdown
Invalid operation
Cancel and back to menu
Left
Right
ok
PRECAUTIONS
• Before formating, pls make sure there is no important data in SD card.
• Format SD card once a week in order to free up space and refresh SD card fragmentation.
• After multiple read and write operation, system will cause huge disc fragmentation
which may lead to the recorded video will not play smoothly. In this case just simply format the SD card then it will work properly.
• Back up all important data to your PC.
www.PyleUSA.com
Short press
Long press
Conrm to format
Invalid Operation
22
Page 24
INSTALLATION
TELESCOPIC BRACKET
Telescopic bracket design, four xed support behind the machine started, alignment rearview mirror
bracket can be xed for each release, Models, simple installa�on and easy disassembly
R
www.PyleAudio.com
HD DVR dual dash cam system
Power input: DC 5V
PL C M D V R 5 2
F
T screen
M
AD
E IN CHIN
A
CONCEALED WIRING
Two dark lines on the left side of the vehicle, from the inner edge of the front windshield above edge access the rearview mirror, the surface showed no traces of external connection, ensure the car's appearance.
23
www.PyleUSA.com
Page 25
BACKUP CAMERA SYSTEMS
Angle Adjustable Camera Lens
Located on the camera housing are 2 screws which
lock the camera lens angle in position.
The screws may be loosened to allow camera lens
angle adjustment
Loosen the screws, adjust the camera lens into the
desired angle. then tighten the screws securely.
Be sure as to not overtighten the screws.
www.PyleUSA.com
24
Page 26
Model: PLCMDVR54
25
www.PyleUSA.com
Page 27
SYSTEM MESSAGE
No SD Card
In video recording or camera mode, if the unit does not detect SD card, this picture and voice prompt will appear on screen. Insert SD card, the prompt will disappear and it can start recording or shootting photos.
SD Card has no storage space
In video recording or camera mode, if SD card has no storage space, this picture and voice prompt will appear on screen and the recording will stop. Clean up SD card. It is suggested to use a special SD card for recording.
Preparing SD Card
Insert SD card, this picture prompt will appear on screen. This prompt will disappear automatically after SD card is ready.
The time for preparing SD card is different due to different SD
card quality. Never pull out SD card when prepairing.
Auto power off countdown Time
After setting auto power off time, if there is no external power
supply, the system will enter countdown and shutdown when the countdown ends. If external power supply is restored during
countdown, the auto power off countdown will be canceled.
SD Card error
When SD card error message appears, try to remove and insert SD card correctly again. If error message still appears after a few times, pls check on PC whether the SD card is good or bad
Collision recording
When DVR turn on and start recording automatically under collision, this picture prompt will appear on screen.
Under collision recording, when image is static for 10s it will enter countdown.
www.PyleUSA.com
26
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
