Pyle PDWM4122 User guide

with MP3/USB Music Playback,

(2) Rechargeable Handheld Mics

PDWM2120 - PDWM4120 - PDWM4122

Home & Office UHF Wireless Microphone System

Wireless BT PA Public Address Mic System

with Microphone Talk-Over,

Includes (4) Handheld Mics

with Microphone Talk-Over

(4) Beltpacks, (4) Headset Mics

Please read this operation manual in detail in order to understand how to
operate this product properly. This is a wireless microphone, which is suitable
for the TV network K songs, singing, karaoke room, home entertainment and
other occasions.

PDWM2120 Receiver Front Panel

1 2 3 4 5 6 7 8 91011

1. Wired Mic Input

2. Wired Mic Volume Control

3. Wireless Mic A Volume Control

4. Wireless Mic B Volume Control

5. ECHO Knob

6. Music Volume Controll

7. USB input

PDWM2120 Receiver Back Panel

12.3.5mm Audio Input

13.3.5mm Audio Output

14.1/4” (6.35mm) Audio Output

15.Power DC input

16.Power ON/OFF Switch

17.Antenna

www.PyleUSA.com

2

8. NEXT，press and hold to turn up
the volume of music

9. Music Pause/Play

10. PREV，press and hold to turn down
the music volume

11. LED indicators

12 13 141516 17

PDWM4120 Receiver Front Panel

1 2 3 4 5 6 7 8

9

10

1. Wired Mic Input

2. Wired Mic Volume Controll

3. Wireless Mic A Volume Controll

4. Wireless Mic B Volume Controll

5. Wireless Mic C Volume Controll

PDWM4120 Receiver Back Panel

11.3.5mm Audio Input

12.3.5mm Audio Output

13.1/4” (6.35mm) Audio Output

14.Power DC input

15.Power ON/OFF Switch

16.4 Antennas

6. Wireless Mic D Volume Controll

7. ECHO Knob

8. Music Volume Controll

9. RF LED indicator lights

10. AF LED indicator lights

12 13 14 15 1611

www.PyleUSA.com

3

Handheld Transmitters

PDWM2120 Rechargeable Handheld Mics

Metal Grill
& Cartridge

Light Ring

Digital display

ON/OFF Switch

PDWM4120 Handheld Mics

1

2

DC 5V

rechargeable jack

Frequency

Selectable button

1. Metal Grill & Cartridge

2. Digital Display:

Frequency, Battery Volume, Channel

3. ON/OFF Switch: Press for 3 seconds

4. Frequency Selectable button

3

www.PyleUSA.com

4

4

PDWM4122 Belt Pack

1. Audio Jack

2. Volume Controll

3

3. RF antenna

4. Digital Display: Frequency,

Battery Volume, Channel

5. ON/OFF Switch: Press 3 seconds

6. Frequency Selectable button

2

1

4

5

6

System Operation

1. Do not turn ON the transmitter before turning ON receiver. Turn the volume to

minimum level, then press the ON/OFF switch on receiver. The Receiver is ON.

2. Put the batteries correctly on the battery compartment, press ON/OFF switch

for 3 seconds, the transmitter is ON.

3. After turning on the transmitter, the RF indicator is lit, turn the volume to suitable

level.Then speak to the microphone, AF indicator is lit. If there is no sound and

the indicator is not lit, it means the system is working abnormally, please send it

to recondition.

4. The Frequency Selectable Button can adjust the transmitter with dierent

frequency. Press one to change the frequency. The receiver can match the

frequency automatically. Wireless Mic A, B, C, D has dierent frequency.

Transmitters do not interfere with each other. If you need sereval systems to

work at the same time, please adjust the transmitters with dierent frequency.

5. If you will not use it for a long time, please turn OFF the system and take out the

AA batteries.

www.PyleUSA.com

5

Transmitter Setting

1

2

3

Digital Display Introduction

1.Battery Display (BATT): Shows the battery dump energy. When the battery is

low, this icon will ash, please replace with new batteries to ensure the transmitter

is working normally.

2.CHANEL: Show the working channel of transmitter.

3. FREQUENCY: Show the working frequency.

Wireless BT Streaming Connection

1. Turn on Wireless BT of audio sources devices (e.g.Smart phone).

2. Search the Wireless BT name of receiver, named “PYLE”.

3. Comple the pairing of audio sources devices (e.g. Smart phone) and receiver.

4. Then play the music from the source device. You will hear the music come out

from the speaker.

Adjusting Suggestions

1. Wired microphone volume (MIC. VOL): 60%

2. Wireless microphone volume (VOL. A,VOL. B): 60%

3. BASS: 30%

4. TREBLE: 60%

5. ECHO: 60%

www.PyleUSA.com

6

Troubleshooting

Trouble Indicator Lights Status Solution

No Sound

or sound is weak

Transmitter’s display

is not lit

Receiver RF LED

indicator is lit

Receiver RF indicator

is not lit. Transmitter

display is lit

Turn on the transmitter.

Make sure the battery

+/- pole is correct.

Replace new battery

Adjust the volume of

receiver. Check the cable

connection between

receiver and

Amplier/Mixer.

Remove the nearby

metal items from receiver.

Check if there is barrier

between transmitter and

receiver. Make the

transmitter close to the

receiver

Distorsion or Squeal

BATT icon ashing Replace battery

Remove the nearby

interference source (eg.CD

player, PC, Digital device,

in-Ear monitor system).

Receiver RF indicator

is ON

Change the frequency of

the transmitter. Replace

battery. If several systems

are used at same time,

please increase the

frequency space.

www.PyleUSA.com

7

PDWM2120

Home & Oce UHF Wireless Microphone System

Wireless BT PA Public Address Mic System with MP3/USB Music Playback,
(2) Rechargeable Handheld Mics

Features:

• Desktop Wireless Microphone System

• PA Public Address Mic Audio Control Receiver

• Home Theater & Oce Karaoke-Style Vocals

• UHF Narrow Band Audio Transmitter

• Includes (2) Handheld Mics

• Portable Rechargeable Battery Microphones

• Wireless BT Music Streaming Ability

• Convenient Microphone Voice-Over

• Talk-Over Ability via USB/Wireless BT Streaming Music with Microphones

• Digital LCD Display with Selectable Mic Frequency

• Dual Antennas for Extended Wireless Range

• Simple Plug-and-Play Operation

• Built-in Acoustic Pop Filter

• Integrated Low Noise Circuitry

• Ultra-Wide Frequency Response

• Noise-Eliminating SMT Technology

• Crisp Audio Clarity for Vocals & Singing

• Connect & Stream Audio from External Devices

• MP3 Digital Audio File Playback

• USB Flash Drive Reader

• 1/4'' -inch (6.3mm) Wired Microphone Input

• Rear Panel 1/4'' -inch (6.3mm) Unbalanced Mixed Output

• Rear Panel Aux (3.5mm) Audio Input/Output Jacks

• Audio Conguration Echo / Music / Master Vol Adjustment

• Independent Channel Volume Control

• Power ON/OFF Switch

• RF (Radio Frequency) LED Indicator Lights

• Perfect for Professional Audio Stage & Studio Performances

• Directly Connects to Ampliers, Stereos, Audio Processors, DJ Mixers

• Used for Home Karaoke, Classroom, Oce & Business Applications

www.PyleUSA.com

8

Wireless BT Streaming Connectivity:

• Simple & Hassle-Free Pairing

• Instant Wireless Audio Streaming Ability

• Play Music Directly from Your External Device

• Works with Smartphones, Tablets, Laptops, Computers

• Wireless BT Network Name: ‘Pyle’

• Wireless BT Version: 4.2

• Wireless Range: Up to 32’+ ft.

What's in the Box:

• Microphone Receiver Base

• (2) Wireless Handheld Microphones

• RCA-to-Aux (3.5mm) Cable, 4.6’ ft.

• Aux (3.5mm) Audio Cable, 3.3’ ft.

• 1/4'' -inch (6.3mm) Audio Cable, 3.3’ ft.

• USB Charge Cable

• Power Adapter

Technical Specs:

• Wireless Operation: UHF Band Transmitter

• Selectable Frequency Mic Design: 50 Channel

• Microphone Element/Type: Dynamic

• Pickup/Polar Pattern: Uni-Directional

• Wireless Operating Range: Up to 165'+ ft.

• Frequency Stability: <0.002%

• Sensitivity: 2/MV

• S/N Ratio: >95DB

• Transmitted Power: 10mW

• Dynamic Range: >95DB

• Distortion: <1%, 1kHz Modulation

• Frequency Response: 50Hz-18kHz (3±dB)

• Construction Material: Metal Alloy Receiver Base, Zinc Metal Mics

• Mic Rechargeable Battery: 3.7V Li-iOn, 1500mAh - 5.55Wh - 31.2g (Each)

• Power Supply: 120/240V (12V Power Adapter)

• Handheld Mic Size (L x W x H): 9.8’’ x 2.2’’ x 2.2’’ -inches (Each)

• Mic Receiver Base Size (L x W x H): 9.4’’ x 3.6’’ x 1.8’’ -inches

www.PyleUSA.com

9

PDWM4120

Home & Oce UHF Wireless Microphone System

Wireless BT PA Public Address Mic System with Microphone Talk-Over,
Includes (4) Handheld Mics

Features:

• Desktop Wireless Microphone System

• PA Public Address Mic Audio Control Receiver

• Home Theater & Oce Karaoke-Style Vocals

• UHF Narrow Band Audio Transmitter

• Includes (4) Handheld Mics

• Portable Battery-Operated Microphones

• Wireless BT Music Streaming Ability

• Convenient Microphone Voice-Over

• Talk-Over Ability via USB / Bluetooth Streaming Music with Microphones

• Digital LCD Display with Selectable Mic Frequency

• Integrated Antennas for Extended Wireless Range

• Simple Plug-and-Play Operation

• Built-in Acoustic Pop Filter

• Integrated Low Noise Circuitry

• Ultra-Wide Frequency Response

• Noise-Eliminating SMT Technology

• Crisp Audio Clarity for Vocals & Singing

• Connect & Stream Audio to External Devices

• 1/4'' -inch (6.3mm) Wired Microphone Input

• Rear Panel 1/4'' -inch (6.3mm) Unbalanced Mixed Output

• Rear Panel Aux (3.5mm) Audio Input/Output Jacks

• Audio Conguration Echo / Music / Master Vol Adjustment

• Independent Channel Volume Control

• Power ON/OFF Switch

• AF & RF Signal Frequency LED Indicator Lights

• Perfect for Professional Audio Stage & Studio Performances

• Directly Connects to Ampliers, Stereos, Audio Processors, DJ Mixers

• Used for Home Karaoke, Classroom, Oce & Business Applications

www.PyleUSA.com

10

Wireless BT Streaming Connectivity:

• Simple & Hassle-Free Pairing

• Instant Wireless Audio Streaming Ability

• Play Music Directly from Your External Device

• Works with Smartphones, Tablets, Laptops, Computers

• Wireless BT Network Name: ‘Pyle’

• Wireless BT Version: 4.2

• Wireless Range: Up to 32’+ ft.

What's in the Box:

• Microphone Receiver Base

• (2) Wireless Handheld Microphones

• RCA-to-Aux (3.5mm) Cable, 4.6’ ft.

• Aux (3.5mm) Audio Cable, 3.3’ ft.

• 1/4'' -inch (6.3mm) Audio Cable, 3.3’ ft.

• USB Charge Cable

• Power Adapter

Technical Specs:

• Wireless Operation: UHF Band Transmitter

• Selectable Frequency Mic Design: 50 Channel

• Microphone Element/Type: Dynamic

• Pickup/Polar Pattern: Uni-Directional

• Wireless Operating Range: Up to 165'+ ft.

• Frequency Stability: <0.002%

• Sensitivity: 2/MV

• S/N Ratio: >95DB

• Transmitted Power: 10mW

• Dynamic Range: >95DB

• Distortion: <1%, 1kHz Modulation

• Frequency Response: 50Hz-18kHz (3±dB)

• Construction Material: Metal Alloy Receiver Base, Half Engineered ABS, Half

Metal Alloy Mics

• Power Supply: 120/240V (12V Power Adapter)

• Handheld Mic Size (L x W x H): 9.8’’ x 2.2’’ x 2.2’’ -inches (Each)

• Mic Receiver Base Size (L x W x H): 7.5’’ x 3.6’’ x 1.7’’ -inches

www.PyleUSA.com

11

PDWM4122

Home & Oce UHF Wireless Microphone System

Wireless BT PA Public Address Mic System with Microphone Talk-Over (4)
Beltpacks, (4) Headset Mics

Features:

• Desktop Wireless Microphone System

• PA Public Address Mic Audio Control Receiver

• Home Theater & Oce Karaoke-Style Vocals

• UHF Narrow Band Audio Transmitter

• Includes (4) Beltpacks & (4) Headset Mics

• Portable Battery-Operated Headset Bodypacks

• Bluetooth Wireless Music Streaming Ability

• Convenient Microphone Voice-Over

• Talk-Over Ability via USB / Bluetooth Streaming Music with Microphones

• Digital LCD Display with Selectable Mic Frequency

• Integrated Antennas for Extended Wireless Range

• Simple Plug-and-Play Operation

• Integrated Low Noise Circuitry

• Ultra-Wide Frequency Response

• Noise-Eliminating SMT Technology

• Crisp Audio Clarity for Vocals & Singing

• Connect & Stream Audio to External Devices

• 1/4'' -inch (6.3mm) Wired Microphone Input

• Rear Panel 1/4'' -inch (6.3mm) Unbalanced Mixed Output

• Rear Panel Aux (3.5mm) Audio Input/Output Jacks

• Audio Conguration Echo / Music / Master Vol Adjustment

• Independent Channel Volume Control

• Power ON/OFF Switch

• AF & RF Signal Frequency LED Indicator Lights

• Perfect for Professional Audio Stage & Studio Performances

• Directly Connects to Ampliers, Stereos, Audio Processors, DJ Mixers

• Used for Home Karaoke, Classroom, Oce & Business Applications

Wireless BT Streaming Connectivity:

• Simple & Hassle-Free Pairing

• Instant Wireless Audio Streaming Ability

• Play Music Directly from Your External Device

www.PyleUSA.com

12

• Works with Smartphones, Tablets, Laptops, Computers

• Wireless BT Network Name: ‘Pyle’

• Wireless BT Version: 4.2

• Wireless Range: Up to 32’+ ft.

What's in the Box:

• Microphone Receiver Base

• (4) Wireless Beltpack Transmitters

• (4) Headset Microphones

• RCA-to-Aux (3.5mm) Cable, 4.6’ ft.

• Aux (3.5mm) Audio Cable, 3.3’ ft.

• 1/4'' -inch (6.3mm) Audio Cable, 3.3’ ft.

• Power Adapter

Technical Specs:

• Wireless Operation: UHF Band Transmitter

• Selectable Frequency Mic Design: 50 Channel

• Microphone Element/Type: Dynamic

• Pickup/Polar Pattern: Uni-Directional

• Wireless Operating Range: Up to 165'+ ft.

• Frequency Stability: <0.002%

• Sensitivity: 2/MV

• S/N Ratio: >95DB

• Transmitted Power: 10mW

Questions? Issues?

We are here to help!
Phone: [phone]
Email: [e-mail]

• Dynamic Range: >95DB

• Distortion: <1%, 1kHz Modulation

• Frequency Response: 50Hz-18kHz (3±dB)

• Construction Material: Metal Alloy Receiver Base, Engineered ABS Beltpack

• Battery Operated Beltpacks, Require (2) x ‘AA’ Batteries, Not Included (Each)

• Power Supply: 120/240V (12V Power Adapter)

• Beltpack Transmitter Size (L x W x H): 2.6’’ x 1.1’’ x 3.6’’ -inches (Each)

• Mic Receiver Base Size (L x W x H): 7.5'' x 3.6'' x 1.7'' -inches

This product can expose you to a chemical or group of checmicals, which
may include ”Lead(Pb)” which is known in the state of California to cause
cancer, birth defects, or other reproductive harm. For more info, go to
https://www.p65warnings.ca.gov/.

www.PyleUSA.com

13
