Pyle PDWM3360, PDWM3365 User Manual

PDWM3360 PDWM3365

PDWM3360 - PDWM3365

Wireless Microphone System

CATALOG

1. FOREWORD --------------------------------------------------------------------------------------------- 2

3. SYSTEM FEATURES

4. SYSTEM TYPE

5. DUAL CHANNEL RECEIVER FEATURES

6. TRANSMITTER FUNCTION & FEATURES

----------------------------------------------------------------------------------- 2

------------------------------------------------------------------------------------------- 2

------------------------------------------------------- 3

--------------------------------------------------- 4-5

Please read this manual before using this equipment in order to avoid damage
through incorrect operation and to get the best performance from your
purchase. Please keep and store this instruction booklet in a safe place after
reading it for future reference. This series of professional microphone system
uses a super steady PLL-synthesized control circuit that matches a high
ecient, low consumption discharging technique.
We also apply an independently developed mobile frequency compression
and expanding circuit that is chain linked with image frequency lters and
three time checked noise lters in the receiving unit. Every unit passed strict
tests and quality control by the manufacturer.

7. TRANSMITTER BATTERY INSTALLATION

8. BODYPACK TRANSMITTER CONNECTION

9. SYSTEM CONNECTIONS

10. TROUBLESHOOTING

11. SPECIFICATIONS

--------------------------------------------------------------------------- 8

----------------------------------------------------------------------------- 10

----------------------------------------------------------------------------------- 11

----------------------------------------------------- 6

--------------------------------------------------- 7

SYSTEM COMPOSITION

1. Receiver

------------------------------------------------------------------------------------------------ X1

2. Wireless hand-held or body-pack microphone

3. Audio Cable

4. AC power adapter of special receiver

5. Battery 1.5V

6. User guide

------------------------------------------------------------------------------------------ X1

------------------------------------------------------ X1

------------------------------------------------------------------------------------------ X4

-------------------------------------------------------------------------------------------- X1

---------------------------------------- X2

FOREWORD

Your new series of wireless system is designed to give you the best of both
sound reinforcement worlds: the freedom of wireless system, and excellent
quality. This manual covers each of the series system: The Vocal Artist-UHF,

and The Headset-UHF.

SYSTEM FEATURES

1. Adopt the PLL-Synlhesized control technique, 8 selectable UHF channels.

2. The UHF frequency range is 573- 597.8MHz, avoiding the frequency
interruption.

3. LCD information display.

4. Double noise squelch operation circuit and system will be higher ecient
and much more steady.

5. Use the dynamic type and Unidirectional cartridge, clear to show the sound.

6. High ecient and low consumption design.

7. Use the high extension antennas, the operating distance will reach 50m.

SYSTEM TYPE

The Vocal Artist-UHF is a hand-held system designed for singers who desire
the high quality of microphones and the freedom of wireless performance.
The Presenter-UHF is a body-pack system designed for public speakers who
prefer an inconspicuous, hands-free lavalier microphone.
The Headset-UHF is a body-pack system designed for users in physically
active applications, who desire the freedom of hand-free microphone.
The Guitarist-UHF is a body-pack system designed for use with electric
guilars, basses, and other electric instruments.
