PLEASE READ THIS MANUAL CAREFULLY BEFORE OPERATION
Features:
• UHF Band Receiver System
• Quad Frequency 4-Channel Design (Channel 1, 2, 3, 4) Addressable Frequency
• Broad Frequency Response Range & Low Distortion
• High Signal/Noise Ratio Performance
• RF Signal Indicator on LCD Screen
• Radio Frequency Display on LCD Screen
• 1 XLR Output Connector Jacks (as only one receiver)
• Independent Channel Adjustable Frequency Controls
• Universal Portable Microphone System
What's in the Box:
• (4) Wireless Microphone
• (8) 'AA' Battery
• (1) USB to Micro USB Charging Cable
• (4) Plastic Microphone Anti-Drop Rubber Ring
• (4) Microphone Sponge
• (1) Microphone Receiver
• (1) 3.5mm Jack Audio Input Connector
• (1) 18650mA Battery
• (1) Plastic Case
Transmitter Technical Specs:
• Frequency Range: 500-938MHz
• Number of Channels: 16
• Oscillation Mode: DSP Chip Frequency Lock
• Stability: ±10ppm
• RF Power: 10dBm
• Audio Frequency Response: 40-18000Hz
• Distortion Degree: <0.5%
• Battery Type: 1.5V, 'AA' Alkaline Battery
• Battery Life: 4-8 Hours
Receiver Technical Specs:
• Frequency Response: 500-938MHz
• Use LCD Screen Display
• Oscillation Mode: DSP Chip Frequency Lock
• Stability: ±10ppm
• Receiving Sensitivity: -95-72 dBm
• Audio Frequency Response: 40-18000Hz
• Distortion Degree: <0.5%
• Signal To Noise Ratio: >90dB
• Audio Output: 300mv (Maximum)
Pairing (pairing ID code + pairing frequency):
The “Frequency Hopping Mode” is a brandnew operation mode introduced
by this program. The data is sent wirelessly by the hand microphone to the
receiver for pairing. After the pairing is successful, the frequency point of the
hand microphone will switch between these 10 frequency points.
The hand microphone can manually change the frequency at any time.
The receiver will automatically follow and jump to the corresponding frequency.
In this way, it not only solves the crosstalk problem, but also provides the
exibility of frequency setting. Products using frequency hopping have been
widely recognized by the market and meet the requirements of most products.
KTV rooms, hand boxes, teaching, personal entertainment and other occasions
to be applicable.
Performance and Characteristics
1. UHF 500MHz-938MHz frequency band is used.
2. Using one-dimensional code + frequency for data encryption and frequency
(even when the same frequency is used to receive, the internal chip and is
interfered by RF, it will only aect the connection range. If the two receivers
are separated by a certain distance (for example, 10 meters), the frequency
re-use can be considered.
3. With automatic mute and impact elimination circuit, help to avoid the impact
and noise of the mic switch.
www.PyleUSA.com
2
www.PyleUSA.com
3
4. The hand microphone has an LED digital tube display function that can
intuitively display the current frequency.
5. The eective distance of wireless transmission is 50-80 meters.
6. The handheld microphone adopts lithium battery circuit design, with
overcharge and over-discharge protection.
7. The simple operation interface and few adjustable parts can completely
avoid malfunction caused by incorrect operation.
8. The transmitter has a low-voltage detection function.
When the battery voltage drops to 2.2V, the battery character ashes.
9. Extremely high pickup sensitivity and excellent sound quality make it easy
for you to speak or sing.
10. Multiple devices can be used at the same time, no interference and cross-
frequency phenomenon.
11. With power and wireless indicator lights.
Launch Function Indication:
Switch
Paring:
Paring handheld A: When powered ON, press and hold the POWER button for
10 seconds to automatically skip to BCD.
Receiver Function Indication:
Battery cover open from here
Antenna
USB charging port
CHA
frequency switch
on/o button
Switching Frequency:
When powered ON, short press the hidden switch of the battery compartment
to switch one frequency at a time.
www.PyleUSA.com
4
Power/charging indication
Sound Quality
This way of connection can achieve the sound quality eect as using wired
connection, its eect can be very close. No compression or expansion is
needed to preserve the original sound. The frequency response, transience
and linearity of the sound are excellent, very close to the sound quality of the
wired microphone.
Crosstalk
The wireless microphone uses all-digital wireless transmission chip which is
dierent from the tradional modulation and demoduation method which
keeps the sound real. The system’s transmitter and receiver chip uses digital
encryption for transmission even if the same frequency is used.
As long as the ID code is set dierently, there will be no crosstalk.
www.PyleUSA.com
5
