Pyle PDRMKIT72N User guide

13'' 3-Piece Kids/Junior Drum Set

Visit Our Website

SCAN ME

PyleUSA.com

Metallic Drum Set with Throne, Cymbal, Pedal,

Bass Drum, Tom and Drumsticks

CONTENTS CHECKLIST

First, check the contents of the package

and make sure you have everything you need.

1. Bass Drum Head

2. Drum Mute Mat

3. Cymbal

4. Snare drum

5. Tom Tom

6. Bass drum

7. Accessory Box

8. Pedal

9. Bass Drum Bolts

10. Bass Drum Spur

11. Cymbal Holder

12. Drum Tuning Keys

13. Pedal Heads

14. Throne Pedestal

15. Tom / Snare Drum Holder

16. Drumstick

17. Throne seat

ASSEMBLY INSTRUCTIONS

1. Take out all the parts from the package and remove the packing bags.

4

3

2

www.PyleUSA.com

2

1

6

5

7

2. Take all the accessories from the accessories box 7.

10

9

12

8

13

3. Set up the seat from 14 and 17.

11

17

15

16

14

Seat

Wing bolt

www.PyleUSA.com

3

4. Set up the pedal from 8 and 13.

5. Set up the bass drum: take out the bass drum no. 6, remove one side bolt

and hoop

www.PyleUSA.com

4

Put the washers on the bass drum boles and put the drum head on.

Please pay attention the logo position when you put the drum head on.

Using the tuning key to make the drum head tight. Please pay attention that,

don’t tighten one screw too tight without tightening other screws. The correct

way is tighten one screw a little, and then tighten the opposite screw a little,

then tighten the besides screw a little, then tighten the left screw a little. Then

tighten again by this turn.

www.PyleUSA.com

5

6. Set up the bass drum spur 10. Insert it inside the slot of the bass drum in both

side.

7. Put the bass drum on the oor and adjust the length of the bass drum spur.

www.PyleUSA.com

6

8. Set up the cymbal holder 11 and tom/snare drum holder 15 on the bass drum.

9. Set up the cymbal.

10. Set up the tom drum on the right, snare drum on the left. Put the logo on

drum head in the correct position as picture.

www.PyleUSA.com

7

Set up the pedal on the bass drum hoop by using the screw as below picture.

11. Finish

12. If you are afraid it is too loud to annoy your neighborhood, you could put the

drum mute mat no. 2 on the drum head.

www.PyleUSA.com

8

Setting drum mute mat method as below:

1. For snare drum and tom drum,

you could just put the mute

mat on the drum head.

2. For cymbal, you need to take

the screw and upper felt out,

and put the mute mat instead.

3. Set up the bass drum mute mat. At rst, tear the
adhesive tape and stick it on the bass drum.

4. Finish

Take this upper

felt out
