FEATURES

1. Wirelessly transmit phone calls from mobile phone to the car FM stereo system via Bluetooth..

2. With A2DP Bluetooth, wirelessly play music from Bluetooth mobile phone to car stereo via Bluetooth.

3. Built-in microphone.

4. Built-in FM transmitter, full frequency: 87.5-108MHZ.

5. Supports USB disk and Micro SD card.

6. 1/8” (3.5mm) line-input jack supports any external audio devices.

7. USB port for charging smartphones, tablets and other mobile devices. (output: DC 5V/2.1A).

8. Supports 12-24V via car cigarette lighter.

9. Support multiple languages.

10. Sleek, Elegant and Sturdy design w/ LCD screen display

11. Retractable metallic stand adapted for any type of automobile.

12. IR Remote included for operating PBT94

Using FM Transmitter function:

1. Plug the FM transmitter into your vehicle’s cigarette lighter or power port.

2. Tune your radio to an unused FM frequency, then match the unit to the same frequency.

3. USB function: Insert a USB flash drive or Micro SD card containing MP3 files into USB port or memory card slot
of this unit accordingly. It will play and transmit the MP3 files automatically.

Hang up

4. Line-in function: Use the provided audio cable to connect an MP3/MP4 player or another external device to the
AUX input of this unit. When using this function, please stop playback of USB or memory card. All functions are
to be controlled by the external device.

Using Bluetooth function:

1. When using Bluetooth for the first time, you need to pair your mobile phone with this unit. Activate your mobile

phone's bluetooth function, then search for new devices. When the mobile phone detects this unit (named as
"CAR KIT"), please pair and connect by using the original password "0000"

2. In the music playing mode, when there is an incoming call, this unit will automatically switch to telephone mode.

Note: The Bluetooth icon displayed on the unit screen will stop flashing after the Bluetooth connects with your
mobile phone.

Bluetooth calling

1. Press the red "Answer/Hang up" button in the middle of the keyboard to answer the incoming call.

2. Press the red "Answer/Hang up" button in the middle of the keyboard to hang up the call.

3. When making a call, you must dial the phone number on your mobile phone, but once the call is connected, you

can use the handsfree function.

Using USB charger function:

When this unit is powered from the car lighter socket, connect the USB Charger port to your mobile phone using
your USB cable (not included). This unit will serve as a mobile phone charger.

Going From Bluetooth to USB flash drive/ micro SD card

When the unit is playing the music from your mobile phone via Bluetooth, press the “pause” button in the right
bottom of the keyboard. After 5-10 seconds (differs from operating system of Mobile phone), “Press CH key”
appears on the screen, then press “CH” button on the right top of the keyboard. The unit will play the music from
USB/ micro SD card.

MENU Setting:

When the unit is playing from the USB flash drive or Micro SD card, follow the below instructions tochange the
menu settings:

1. Press button to pause playing.

2. Long press "CH" button to get below menu list:

Card folder, Del file, Del all, Language, Contrast, Firmware version, Exit.

Quick Guide:

Operation Guide

On FM transmitter

On Remote Controller

1. Answer / hang up
the call:

Press "answer call" button: answer the call
Press "hang up" button: hang up the call

Press” / ”button

2. Play and Pause the
music:

Press “ ” Button: Play the music
Press “ ” Button again: Pause playing

Press Button

3. Adjust the Volume:

Press and hold “ ” button: Increase Volume
Press and hold “ ” Button: Decrease Volume

Press “+” to increase the Volume；Press
“-” to decrease the Volume；

4.Set frequency:

Press “CH” button first, then
press “ ”: increase the frequency
Press ” ”: decrease the frequency

Press “CH+” button: Increase 0.1MHz
Press “CH-” button: decrease 0.1MHz

Or press the numbers of the frequency,
press “CH+” to confirm.

5. Choose music:

Press “ ” Button: Play the next song
Press “ ” Button: Play the previous song

Press button: Play the next song;
Press button: Play the previous song;
Or press the number of the song then
press to confirm

6. Choose EQ:

Support by remote controller only

Press “EQ” button to choose your favorite
EQ

7. Switch folder:

Press" " button first, then press and hold
"CH" button to get menu list, then choose
wanted folder under card folder menu

Press "folder" button to switch folder

8. Make phone call

Dial from phone

Press button, input mobile number on
remote control, then press button again.
