Please read all instructions before use for the best performance
of this product. Save these instructions for future reference.
Box Contents
MUTE
VOL+
VOL-
BT OPT
INPUT
COAX
LINE
MOVIE MUSIC
DIALOG
Bookshelf Speaker Remote Cont rol Quick Start
RCA to RCA
audio cable
Stereo RCA to
3.5mm audio c able
Digital Opt ical cable Power Adapter
LED Indicators and Button Introduction
Active Speaker
Infrared receiver
LED I ndicators
www.PyleUSA.com2
Standby BT Optical
Line in Coaxial
Page 3
02
03
01
04
VOLUME
05
06
07
08
EQ
LINE IN
L
COAX
TREB
SPEAKER OU T
BASS
DC IN
09
R
OPT
10
11
Active Speaker
Product Name: Bookshelf Speaker
Model: PBKSR40WT
Input Voltage: DC 18-22V
Power Consumption: 80W
SPEAKER IN
12
Passive Speaker
Know Your Remote
MUTE
VOL+
VOL-
BT OPT
INPUT
LINE
MOVIE MUSIC
COAX
DIALOG
VOL+
OPT
LINE
MOVIE
DIALOG
01. Power switch
02. Input selection
Press in to navigate between audio
sources: BT -> Optical ->
Coaxial -> LINE IN
03. Sound effects
Press in to navigate between audio
sources: Music -> Dialogue -> Movie
04. Volume control
05. Treble control
06. Coaxial input port
07. Bass control
08. Power port
09. Line in input port
10. Optical input port
11. Left speaker audio output
12. Left speaker audio in
Power button
Volume up
MUTE
VOL-
Previous track
Play/pause
Optical mode
Line mode
Movie mode
BT
INPUT
COAX
MUSIC
Dialogue mode
Mute/Unmute
Volume down
Next track
Bluetooth mode
Input mode
Coaxial mode
Music mode
www.PyleUSA.com 3
Page 4
Connection Diagram
TV
a
c
BT Device
BT signal
up to 30 f eet
LINE IN
b
L
COAX
TREB
SPEAKER OUT
BASS
DC IN
Active Speaker Passive Speaker
a
Digital Opt ical cable ( supplied)
c
BT
e
RCA to RCA audio cable (supplied)
www.PyleUSA.com4
EQ
R
OPT
Product Name: Bookshelf Speaker
Model: PBKSR40WT
Input Voltage: DC 18-22V
Power Consumption: 80W
d
e
SPEAKER IN
f
b
Coaxial cable (not supplied)
d
Stereo RCA to 3 .5mm audio cable (supplied)
f
Power Adapter (supplied)
Page 5
Connecting with a TV
Active Speaker
Coaxial cable
C
(not supplied)
A
Method 1. Connecting using an Optical cable.
Select Optical mode and set the TV’s audio output to “PCM”.
(More information on PCM page)
B
Method 2. Connecting using a RCA to 3.5mm cable.
Select RCA mode.
Method 3. Connecting using an Coaxial cable.
C
Select Coaxial mode and set the TV’s audio output to “PCM”.
(More information on PCM page)
Opti cal digital
A
B
(supplied)
cable
RCA to 3. 5mm audio
cable
(supplied)
TV
Setting “PCM” on your TV
When all cables are connected properly, and LED indicator
lights properly, if there is no sound from tv or Soundbar, please
set your tv as below:
www.PyleUSA.com 5
Page 6
1. Press "Menu" on the TV’s remote control.
2. Press the arrow keys on the remote to scroll to "Audio Settings."
3. Press "OK" on the remote control.
4. Scroll to "Advanced Audio" and press "OK". Some televisions
may not have an"Advanced Audio" menu and may list various
audio settings instead.
5. Scroll to "Audio Output Mode" or "Digital Audio Output Mode"
and press "OK".
6. Scroll until "PCM" is displayed as the current audio output.
7. Press "OK" to save the settings.
Connecting a Wireless BT Device
BT
or
BT signal
up to 30 f eet
a. Press the “BT” button on the remote or press the “ ” button
on back panel of the active speaker, the LED indicator blinks blue.
b. Turn on Wireless BT on the BT device.
c. Select “PyleUSA” and connect it. When your BT device is
connected, the LED indicator blinks blue slowly.
d. Play music les from the device, connected via BT, through the
bookshelf speaker.
www.PyleUSA.com6
Page 7
Troubleshooting
No sound
• Check if the power indicator light is ON.
• Try to turn up the volume using either the master volume control
or remote control.
• Ensure the audio cables are rmly connected and the input is
set correctly on the speakers.
• Check if there is signal output from the audio source.
Cannot connect via Wireless BT
• Make sure the speaker is switched to BT input, in other audio
input mode BT can not be paired or connected. Disconnect from
any BT device by press and hold the volume dial in BT mode,
then try again.
• Eective BT transmission range is 10 meters, make sure operation
is within the range.
• Try another BT device for connection.
The PBKSR40WT Bookshelf Speaker does not turn on
Check if mains power is connected or if the wall outlet is switched on.
Specications
Power output:
Signal to noise ratio dB(A):
Input sensitivity:
Frequency response:
Bass unit:
Tweeter unit:
L/R: 40W + 40W
L/R: ≥80dB (A)
LINE IN: R/L: 600±50mV
OPT: R/L: 500±50mFFS
40HZ-20KHZ
4 inch (102mm)
1 inch (25.4mm)
www.PyleUSA.com 7
Page 8
Questions? Comments?
We are here to help!
Phone: (1) 718-535-1800
Email: support@pyleusa.com
