Pyle PBKSP33BK User guide

Desktop Wireless BT Bookshelf Speakers

HiFi Studio Monitor Computer Desk Stereo

Speaker System, (300 Watt MAX)

Please read all instructions carefully before

use and retain for future reference.

Safety Instructions

1. When using electrical units, basic safety precautions
should always be followed.

2. Children aged from 8 years and people with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge can use this
unit, only if they have been given supervision or
instruction concerning use of the unit in a safe way
and understand the hazards involved.

3. Children should be supervised to ensure that they
do not play with unit.

4. Unless they are older than 8 and supervised,
children should not perform cleaning or user
maintenance.

5. This unit is not a toy.

6. This unit contains no user serviceable parts, if the
unit and any of its accessories are malfunctioning
or it has been dropped or damaged, only a qualied
electrician should carry out repairs, improper
repairs may place the user at risk of harm.

7. Keep the unit out of reach of children.

www.PyleUSA.com2

8. Keep the unit away from heat or sharp edges that
could cause damage.

9. Keep the unit away from heat sources, direct
sunlight, humidity, water and any other liquid.

10. Keep the unit free from dust, lint etc.

11. Do not immerse the unit in water or any other
liquid.

12. Do not operate the unit if it has been exposed to
water, moisture or any other liquid to prevent
against electric shock, explosion and/or injury to
yourself and damage to the unit .

13. Do not use the unit for anything other than its
intended use.

14. Do not store the unit in direct sunlight or in high
humidity conditions.

15. Do not put objects into any of the openings.

16. Do not play music at excessive volume levels as
damage to hearing and/or the equipment may
occur. It is imperative to unplug the adaptor after
the unit has been used, before it is cleaned and
whilst being repaired.

17. To prevent possible hearing damage, do not listen
at high volume levels for long periods of time.

18. Warning: Keep the unit away from ammable
materials.

www.PyleUSA.com 3

Getting Started

1. Remove the unit from the box.

2. Remove any packaging from the unit.

3. Place the packaging inside the box and either
store or dispose of safety.

What’s in the Box:

Active Bookshelf Speaker

•

• Passive Bookshelf Speaker

• RCA Input Cable

Technical Specs:

Power Output: 300 Watt

•

• Power Supply: AC 110V

• Amplier Type: 2-Channel

• Monitor Speaker Driver: 4" -inch

• Tweeter Driver: 1.0’’ -inch Dome

• System Channel Impedance: 4 Ohm

• Frequency Response: 70Hz-20kHz

• Sensitivity: 85dB

• Digital Audio File Support: MP3

• Maximum USB Flash Support: Up to 16GB

• Power Cable Length: 4.9’ ft.

• Power: 110V

• Single Speaker Weight:

Active, 5.1 lbs. (Passive, 4.3 lbs.)

• Single Speaker Size: (W x D x H):

6.4” x 8.9” x 9.7” -inches (Each)

www.PyleUSA.com4

Parts Description

Front panel

1. Bass volume
control

2. Master volume
control

3. Previous track

4. Next track

9. USB card slot

1. Bass volume control

2. Master volume control

3. Previous track

4. Next track

5. Mode

5. Mode

6. Play/Pause

7. Display

8. Micro SD slot

6. Play/Pause

7. Display

8. Micro SD card slot

9. USB card slot

www.PyleUSA.com 5

Back panel Instruction

(Laptop, Mobile, TV etc.)

Left channel output

Aux input

Power Switch

11

Power supply: AC 110V~60Hz

User Instructions

Wireless BT Operation

1. Power ON the speaker, the unit will automatically
activate BT mode turned ON.

2. Search for paring name “PyleUSA” to connect with
the device, there’s a tone when successfully
connected.

3. While playing, press Prev/Next button for previous
or next song, press and hold Prev/Next button to
fast backward or fast forward.

4. Press “Play/Pause”button to pause or play the
music.

www.PyleUSA.com6

USB/MicroSD Operation

1. Insert USB/MicroSD, to play the music automatically.

2. Press “Play/Pause” button to pause or play the
music.

3. While playing, press Prev/Next for previous or
next song, press and hold Prev/Next button to fast
backward or fast forward.

4. When USB/MicroSD is inserted at same time,
MicroSD will be the priority to play.
Please don’t take out USB/MicroSD card while
playing, otherwise USB/MicroSD card will be
damaged.

RCA In Operation
Connect RCA cable with your device to play music.
Press “Play/Pause” button to mute the music.

Bass

Turn the Bass volume knob to increase or decrease
bass eect.

Supplement:

1. Mode Switch Sequence:
BT > RCA > USB > MicroSD

2. Default Mode: BT

www.PyleUSA.com 7
