Pyle JOVGF2W User guide

WARNING:

• For your own safety, please read and understand these

warnings and keep this user guide for future reference.

• Always make sure the cart is fully extended and locked

before use. Always make sure the cart is folded and locked

properly before lifting or transporting.

• Do not run while using this product.

• Do not use accessories other than those designed for use

with your cart.

• Keep all packing materials away from children and recycle

where possible or where required by law.

MAINTENANCE

• To clean the trolley, wipe with a soft, dry cloth.

• Car polish may be used to maintain nish.

• Lubricate moving parts every 6 months.

WARNING:

• Keep hands and ngers away from moving or sliding parts!

• Always keep control of the Pull Cart - Do not let it run down hills

without full control.

www.PyleUSA.com

2

PARTS LIST

A Foam Handle

B Hand Grip

C Sliding Lock

D Upper Bracket

E Joint

F Left Weight Stabilizer

F1 Right Weight Stabilizer

G Leg Bracket

H 3 Holes Leg Frame

I Anti-Splay Wire

J Left Wheel Mechanism

J1 Right Wheel Mechanism

K Main Frame Tube

L Lower Bracket

M Rear Wheel

A

B

D

C

E

F

F1

G

J

H

J1

M

I

K

L

www.PyleUSA.com

3

ASSEMBLY DETAILS

Fig. 1

Fig. 3

Fig. 2

Lift the handle to
level position as
Fig. 1

Fig. 4

Completely unfolding
and assembly as Fig. 4.

www.PyleUSA.com

4

Move the slide lock downside
and lock to upper bracket as
Fig. 2

FOLDING STEPS

Push the steel piece on the wheel lock mechanism to assemble
the rear wheel as Fig. 3.

Fig. 6

Fig. 5

Move the slide lock toward upper
and fold the handle as Fig. 5.

Fig. 6 shows the
folded position.

FEATURES:

• New Deluxe 2-Wheel AIuminum 2-Wheel Pull Cart

• Lightweight and Foldable Golf Trolley

• Includes Foot Brake for Rear Wheel

• Upper and Lower Bracket with Elastic Strap

• TPE Handle Grip

• Push Button System

• Ergonomic Padded Adjustable Handle

• Simple Quick Braking System

• Durable and Compact Size for Easy Storage and Transportation

• Easy to Fold and Unfold

• Designed for Multiple Pushing Positions

• Umbrella Holder Not Included

• *Assembly Needed

WHAT'S IN THE BOX:

• (1) 2-Wheel Golf Push Cart

TECHNICAL SPECS:

• Construction Material: Steel Frame

• Max. Load Capacity: 28.7 lbs.

• Rear Wheels Size: 9.5'' -inches

• Folded Product Dimension (L x W x H): 13.6’’x 16.7’’ x 34.6’’ -inches

• Unfolded Product Dimension (L x W x H): 40.1’’ x 26.3’’ x 43.3’’ –inches
