Type of product
Date of purchase
Name Tel
Address
Memo
ERO-M7
ERO-M7
PERFECT WATER SERIES
USER'S MANUAL
Thank you very much for selecting Pure-Pro Water Corp.
In order to bring the best use of your system, please read the user's manual
carefully before installation and follow the regulations.
01 About perfect water
03 Why perfect water is popular
04 Components
05 Cartridge filters
07 Preparation
08 Panel operations and functions
11 Tubing connection diagram
12 Installation diagram
14 Change filters
16 Change membrane
17 Trouble shooting guide
18 FAQ
19 Memo
Page 2
01
PURE-PRO PERFECT WATER SERIES
18
PURE-PRO PERFECT WATER SERIES
P
R
O
P
URE
DRINKING WATER SYSTEM
P
R
O
P
URE
DRINKING WATER SYSTEM
About Perfect Water
FAQ
Q: What is the guarantee on the PurePro system ?
The PurePro system (excluding filters) is guaranteed for 1 year for material and
workmanship. All defective parts will be replaced free within the first year under
natural breakdown. The membrane has one year pro-rated guarantee.
Q: What factors affect the quantity and the quality of the water production?
There are four major variables to consider:
1.Pressure-The greater the water pressure, the better water quantity and
quality it produced. Water pressure of 60 PSI is ideal.
00
2.Temperature-76 F is the ideal water temperature for R.O. 40 F water will
0
cause the production of R.O. water to fall to half of that at 76F. The maximum
0
water temperature recommended is 85 F.
3.Total Dissolved Solids (TDS)-The higher the amount of dissolved
contaminants in the water, the lower the quantity of water produced. A high
level of TOTAL DISSOLVED SOLIDS can be overcome with additional water
pressure.
4.Membrane-Different membranes have different characteristics. Some
produce more water than others; some have better contaminant rejection
capabilities; some have greater resistance to chemical abrasion for longer life.
PurePro system includes NF33-1812-100 The Thin Film Composite (TFC)
membranes combine the best of these characteristics and are considered the
finest membrane in the world.
Q: What is the maintenance schedule for the PurePro system ?
The three pre-filter cartridges should be changed every 6 months. The 5 micron
sediment cartridge filter is the first one; the second is a carbon cartridge filter,
and the third one is a 1 micron sediment filters. (some systems comes with the
Extruded carbon filter.) Failure to change the cartridge every 6 months may
cause chlorine to destroy the membrane.
Q: What does the PurePro series drinking water taste like?
The taste of the PurePro water depends on the amount of contaminants in the
tap water originally. If 95% of dissolved minerals and chemicals are removed,
the R.O. water may taste like distilled water (no minerals), bottled water (low
mineral), or natural spring water (moderate mineral content).
¨PurePro Most Perfect Water System
More and more people understand that the "perfect water" system would combine
the purity of Reverse Osmosis (R/O) and the tremendous benefits provided by
alkaline, ionized water. Historically this has not been easily achieved for a variety
of reasons. Our water technology experts at PurePro have solved the problem of
combining these two phenomenal yet very different water technologies. Now you
can have perfectly clean AND perfectly healthy water by installing RO system with
water ionizer!
¨Features
Four levels of alkaline water.
Two levels of acid water, including super-oxide.
Built-in auto-flushing electrode.
Filter water (non-ionized) - by Reverse Osmosis Water System
Super anti-oxidant water
Alkaline water with pH8.0~10.0
Stainless steel output spout
Unique post-operation automatic and silent cleansing for extended lifespan
Sound confirmation every time you select a different pH level
Filter change required indicator
Easy 1-minute change filter compartment
Hydrogen-rich water (hydrogen gas bubbles in your glass)
High negative ORP water (to fight free radicals)
Smaller molecular clusters
Mineralized with trace minerals
PurePro USA Water Ionizer faucet
Clean, safe, tasty water - straight from your tap
Energizing & Healing water
Model: M800-Alkaline
Membrane: 100 GPD / 378 LPD NF Membrane
With a transformer, available in 110Volt, 220Volt or 240Volt (50/60Hz)
Operation pressure: 50 - 80 PSI
Dimensions: (cm) 30 (L) x 20 (W) x 41 (H) - System
(cm) 28 (L) x 28 (W) x 35 (H)- Tank
Weight: 6 kg - system
4 kg - tank
¨Specifications: (Reverse Osmosis)
Page 3
17 02
P
R
O
P
URE
DRINKING WATER SYSTEM
P
R
O
P
URE
DRINKING WATER SYSTEM
¨Specifications: (Water Ionizer)
About Perfect Water
PURE-PRO PERFECT WATER SERIES
PURE-PRO PERFECT WATER SERIES
Processing rate of water 2./minute:
2
[In-water pressure is 0.1Mpa(about 1kgf/cm )]
Water exit volume 3L/minue:
2
[In-water pressure is 0.2Mpa(about 2kgf/cm )](estimate)
Electrolysis capacity level: Alkaline 3 level; Acidic 1 level
Possible continuous electrolysis duration:
(Level 1~2) about 1 hours (Level 3) about 30
Plate cleaning automatically performs every time being used.
When intensive cleaning is required after a period of time,
Intense cleaning indicator is on.
Automatic back cleaning when tap water is closed after
processing.
0
40 C
Power supply
AC: 220V/50HZ(customized product)110V/60HZ
100-200W
Nanometer titanium alloys electrolysis trough
Power consumption
Electrolysis material
In-water pressure
2
1 ~ 6.5kg/cm
Electrolysis technique
Continuous electrolysis technique (water volume and
temperature gauge built-in)
Machine protection
installation
Fuse 10Aand electrical board: 2A electrical power
overheating protection installed, transformer
temperature protection installed.
Electrolysis
Main machine
dimension
Height 315mm x Width 255mm x Depth 135mm
Machine weight
About 5.5kg
Purifier
Total water flowing volume: about 12000L
Purifying capacity: take away salty particle residue
Remove foul and bad odor
Max.wate temperature
for continuous usage
Power cable length
About 9 feet
Model
JA-703
+500MV ~ -700MV
ORP level
Phenomenon Reason for problems and handling guideline
Power background
light mot on displays
nothing
Ensure power cord is connected to an electrical outlet
Back light is mot on
and nothing get
displayed when
generating
1.Water pressure too low, the machine does not work
correctly, operator installs additional water pump.
2.Check for correct installation of filter cartridge. The
machine does not work when filter cartridge is misplaced.
Unfold the bent part of the water supply hose.
Ionized water or pure
water come out dirtily
1.Maybe it is time to replace filter cartridge? (Filter cartridge
can be bought in distribution agencies)
2.Is the tap only half on? Please let more water flow out from
the tap.
3.Is water supply line frozen? Defrost the water supply line
before using. Is the indicator light for cleaning required on?
Please perform cleaning.
Electrolyzed a lkal ine
water appears to have
white colored stain
Alkaline ionized water is usually white color after being
generated. This is due to the air bubbles formed as a result
of reaction with electrolysis. It will turn into transparent in a
short while and is perfectly safe for drinking.
1.The white floating object is a crystal formation(the solid
form of calcium) which reaction of Calcium ion and Carbon
Dioxide in the air generates. It is perfectly safe for drinking.
2.The thin layer that can be seen is the solid form of Calcium.
Please use vinegar to clean it.
Container for storing
alkaline water shows
white floating object
or develops thin layer
on its inner wall
Not using the ionizer
for long period of time
Alkaline water flowing
out from alkaline
faucet becomes slower
and slower
Maybe gradual formation of Calcium crystal in hose blocks
the water outlet, which makes the water flow-out become
slower and slower. Please consult with a professional to
clean inner hose or purchase special filter cleanser for the
ionizer from our company.
Please ensure the power cord is unplugged. Remove water
separator and filter device from the purifier.
Trouble Shooting Guide
Page 4
03 16
P
R
O
P
URE
DRINKING WATER SYSTEM
P
R
O
P
URE
DRINKING WATER SYSTEM
Why Perfect Water is Popular
Water Ionizer is a medical device in Japan.
Why? Read on . . .
ALKALINE WATER IMPROVES CHRONIC HEALTH CONDITIONS
Research in Japan since the 1950's and testimonials indicate the following
conditions have been improved from drinking alkaline water:
Arthritis
Heartburn
Chronic fatigue
Indigestion
Leg cramps
High blood pressure
Poor circulation
Migraines
Nausea
Obesity
Osteoporeosis
Psoriasis
Stress
Dr. Otto Warberg received the Nobel Prize for discovering the cause of cancer -
this being lack of oxygen which is low alkaline pH. No disease can exist in an
alkaline environment. Japanese medicine has proven this over the last 15 years.
Water ionizer can restore proper alkaline pH within weeks.
PURE-PRO PERFECT WATER SERIES
PURE-PRO PERFECT WATER SERIES
Change Membrane
¨Change membrane: (Reverse Osmosis)
Jaco
PR
O
N
G
W
A
T
E
R
S
YS
T
E
M
4 Loose the Jaco fitting anticlockwise.
5 Remove the membrane housing
cap anticlockwise.
6 Remove the membrane by a pincer.
7 Install the membrane by carefully
pushing the spigot end into the
socket at the far end of the housing
until completely in.
1 Unplug electricity.
To RO system
2 Turn off water source. 3 Switch off water tank.
Page 5
15 04
P
R
O
P
URE
DRINKING WATER SYSTEM
P
R
O
P
URE
DRINKING WATER SYSTEM
Components
Snake hose x 1 Hose clip x 2
Hanging fixture 1 x
PH testing liquid 10ml
Water inlet / Outlet
hose x 2
Suction used to fix
water drain hose
1 2
4
6
3
5
¨Components: (Water Ionizer)
Water storage tank
x 1
Drain saddle x 1
¨Components: (Reverse Osmosis)
Tank ball shut-off
valve x 1
4 5
1 2 3
Water Ionizer faucet
x 1
7
¨Change filters: (Reverse Osmosis)
Change Filters
PURE-PRO PERFECT WATER SERIES
PURE-PRO PERFECT WATER SERIES
Tubing x 1
6
6 Drain out 1 Gallon of water to
purify replacement filters.
2 Turn off water source.
To RO system
4 Loose the Jaco fitting anticlockwise.
Jaco
5 Remove the used filters from clips
and replace with new ones.
3 Switch off water tank.
1 Unplug electricity.
Deliver-valve x 1
Water supply
connector x 1
Page 6
05 14
P
R
O
P
URE
DRINKING WATER SYSTEM
P
R
O
P
URE
DRINKING WATER SYSTEM
Cartridge Filters
¨Cartridge filters: (Water Ionizer)
¨Cartridge filters: (Reverse Osmosis)
Change Filters
¨Change filters: (Water Ionizer)
PURE-PRO PERFECT WATER SERIES
PURE-PRO PERFECT WATER SERIES
Type:
Main parameter:
Water quality:
Water source:
Things to note:
Carbon filter
Filter life 12000L
Water pressure 0.1M pa~0.4M pa
Meet the requirement of "Sanitary safety and criteria of
drinking machine" (2001).
Municipal tap water
Replace filter regularly (The filter life can one year at most.
it is necessary to replace the filter.)
function
water
last for
If clogged,
This 5micron sediment filter is made of 100% pure polypropylene fibers. High
capacity filter removes dusts, particles and rusts. (Service Life: 6 Months)
(Stage 1) 5 Micron Sediment Filter
(Stage 2) GAC Filter
It takes out 99% of the chlorine and organic chemicals. It provides enhanced
reduction of taste, odor, and color. (Service Life: 6 Months)
It takes out 99% of the chlorine and organic chemicals. It provides enhanced
reduction of taste, odor, and color. (Service Life: 6 Months)
(Stage 3) GAC Filter
Page 7
0613
P
R
O
P
URE
DRINKING WATER SYSTEM
P
R
O
P
URE
DRINKING WATER SYSTEM
(Stage 5) Post Carbon Filter
NSF approved. This post carbon filter is designed to improve taste. It removes
any residual impurities and odors from the tank and provides a finer conditioning
of pure water. (Service Life: 1 Years)
(Stage 6) Alkaline Filter
The Alkaline filter changes the acidic RO water into a perfect Natural Alkali
Calcium Ionized Water. The Alkaline filter simply gives back minerals such as
ionized calcium, magnesium, sodium, potassium ion, which were taken away
while purifying the water. (Service Life: 1 Years)
Cartridge Filters
PURE-PRO PERFECT WATER SERIES
PURE-PRO PERFECT WATER SERIES
Installation Diagram
Install faucet :
Input water : Install water tank :
Install drain saddle :
Drill a 1/4" hole into
the drain pipe.
Mount drain
saddle aligning
holes.
Hand tighten
plastic shut-off
valve to tank.
Then connect
color tubing.
To RO system
Tank ball shutoff valve
To RO system
Deliver valve
Water supply connector
To water
source pipe
Nanofiltration membrane has a slightly larger pore size than reverse osmosis
membrane. Thus monovalent salts like sodium chloride (common table salt)
molecules passes through the membrane but large divalent salts of calcium,
magnesium and other metals like iron, heavy metals..etc. are all blocked.
(Service Life: 2 Years)
(Stage 4) NF Membrane
Assemble membrane :
P
R
O
U
R
E
R
I
N
K
I
N
G
W
AT
E
R
S
Y
ST
E
M
Loose the Jaco fitting anticlockwise.
Jaco
Remove the membrane housing cap.
Install the membrane by carefully
pushing the spigot end into the
socket at the far end of the housing
until completely in.
Page 8
07
P
R
O
P
URE
DRINKING WATER SYSTEM
P
R
O
P
URE
DRINKING WATER SYSTEM
12
Preparation
Operation panel
Water drain hose
Alkaline water
Acidic water
Power supply cable
¨Preparation: (Water Ionizer)
¨Preparation: (Reverse Osmosis)
Installation Diagram
Flexible hose :
PURE-PRO PERFECT WATER SERIES
PURE-PRO PERFECT WATER SERIES
RO membrane housing
Post carbon filter
Transformer
Pump
1st stage
3rd stage
2nd stage
Solenoid valve
High pressure protector
Input water
To drain out tube
To the tank
To the faucet
Page 9
Faucet
Tank
Drain
Input water
A
B
C
D
P
R
O
P
URE
DRINKING WATER SYSTEM
P
R
O
P
URE
DRINKING WATER SYSTEM
11 08
PURE-PRO PERFECT WATER SERIES
PURE-PRO PERFECT WATER SERIES
Panel Operations and Functions
Tubing Connection Diagram
CONNECTING THE COLOR TUBING:
A. Connect the WHITE tubing to the water supply connector.
B. Connect the BLUE tubing to the sink top faucet.
C. Connect the BLACK tubing to the drain saddle.
D. Connect the RED tubing to the storage tank.
Page 10
P
R
O
P
URE
DRINKING WATER SYSTEM
P
R
O
P
URE
DRINKING WATER SYSTEM
09 10
PURE-PRO PERFECT WATER SERIES
PURE-PRO PERFECT WATER SERIES
Panel Operations and Functions Panel Operations and Functions
Loading...
