Thank you, and Congratulations on your purchase of The PureEffectTM ULTRA-WHW Whole-House
Well Water Filtration System Featuring our: WellGuardTM Well Contaminant Removal & AntiRad-WH
TM
Wide-Spectrum Anti-Radiation Technologies.
INSTALLATION INSTRUCTIONS
(please become familiar with instructions before installing).
_____________________________________________________________________________
IMPORTANT! - BEFORE YOU START:
- CAUTION!! Improper Installation can cause Property Damage, all installation must be done by a licensed and
experienced plumber in compliance with local plumbing and sanitation laws.
- Do not use with water pressure more than 90PSI. Booster pump may be installed if less than 40PSI. (Most
common PSI ranges are between 40-75). Ensure there is a pressure regulator installed and is in proper working
order before proceeding. PureEffectFilters.com assumes no liability for any damage or losses due to excessive
water pressure or improper installation/use. If Hanging on the wall: As a safety precaution: never stand or
place anything of value under the system.
- The system should be installed Indoors and where it is protected from freezing temperatures and direct
sunlight.
- Do not use with water that has not been adequately disinfected, of unknown quality or is not approved for
drinking. By installing/using this system, you agree to hold PureEffectFilters.com (Survive & Prosper, Inc.) and
all it’s owners, agents and employees harmless of any liability, damages and/or losses as a consequence of
improper use/installation, or unforeseen circumstances out of our control (e.g. acts of nature).
_____________________________________________________________________________
Customer Support:
Tel: 1-347-492-4014
Email: info@pureeffectfilters.com
www.PureEffectFilters.com
! Shut-Off Ball Valve
(Water–In)
Housing Caps "
Pressure Gauge
! 20” Housing
! Wall-Mount Bracket
2
Carefully remove and inspect your new filter system for any possible transportation
damage. If any damage is found, please notify us promptly.
1. ❏ Position the system in the best area to connect it to the main cold water service
line of your home & Screw in the Pressure Gauge (Included) into the ¼” port on top
of the system (take care not to overtighten).
Note: If you need to connect water input to the left side of the unit, please first remove
all housings, unscrew the pressure gauge, then unscrew each black housing cap and
reverse their positions so that the arrows near the engraved “IN” and “OUT” indicators
on top of the black caps are facing direction of water flow.
2. ❏ Turn off the main water supply to your home, and open a faucet (for a few
seconds) to release pressure from your plumbing system.
3. ❏ Attach the included Ball-Valve to the “INPUT” port of the system, and then
connect the cold-water service line to it.
Note: The home’s water service line should be first connected directly to the filtration
system BEFORE the water reaches any hot water heater or other system (e.g. Water
Softeners, UV systems, De-scalers, etc.)
4. ❏ Unpack the cartridges, remove Shrink-wrap and insert cartridges in the proper
sequence indicated below (notice the “this end up” indicator on the WellGuard-WH
& AntiRad-WH Cartridges) and screw chambers closed (HAND-TIGHTEN to
prevent Damaging O-Rings. If housings leak, then use wrench to tighten some more).
Note: If the cartridges move inside the closed chambers when shaken, you did not tighten
the housing enough, Use wrench in this case, but just enough until shaking ceases.
#1
Carbon
Block
#2
WellGuard-
WHTM
#3
AntiRad-WHTM
WATER
! INPUT
WATER
OUPUT "
3
CARTRIDGE FLUSH & LEAK TEST
5. ❏ Before connecting unit to output pipe: Flush the carbon fines out of system for 5
minutes, then connect the output of the unit to applicable pipe/s.
Note: You’d need to install a drain/bypass faucet valve right at the output of the system,
so you can easily connect a garden hose for flushing new cartridges and bypassing the
plumbing of your home when necessary. A 2nd such valve can also be installed before
the Input of the filter, in case you want to connect garden hose to wash car, and not use
the filtered water for this. During initial flushing, the output water will be black with
harmless carbon dust, please ensure you catch this water so to avoid it muddying your
place of install.
Note: Carefully check all connection points for any leaks, if none are found, open main
water supply to normal flow and continue checking for leaks.
IMPORTANT! Ensure that the PSI reading on the pressure gauge is not more than
90PSI (install pressure regulator if it’s above this reading). If Pressure is below 45PSI, a
booster pump may be necessary to maintain adequate water pressure in the home.
6. ❏ Once Flush is complete, connect the unit to the appropriate output pipe to send
filtered water to your water heater and whole house.
7. ❏ ❏ Turn on full flow for both hot and cold water in your bathtub and sink faucets
for 15-20 minutes to ensure the cartridges get flushed and primed further and that
the old water from the hot water heater is renewed.
Note: Typical Hot Water Heater stores 40 - 75 gallons of water, so it may take a few
days to a week (depending how much water is used in your household) to fully clear out
old water from hot water heater.
8. ❏ Continue to check on the system everyday for a week and from time to time
thereafter to ensure there are no leaks and that the PSI reading remains below 90.
Note: A leak controller device w/ auto water shut off can be installed for added security.
The system features durable double O-ring seals, and all the O-rings in the housings are
already pre-lubricated with a Premium Food-Grade NSF & FDA Compliant Silicone
Lubricant for improved leak resistance.
Congratulations, your new system is now ready to provide clean water to your entire
home!
THE FILTER SYSTEM IS DESIGNED FOR COOL - COLD WATER USE ONLY.
Do not allow hot water to run through the filter system.
4
FOR CARE & OPTIMAL PERFORMANCE:
** Conserving water will extend filter life. (turn off faucet when brushing teeth, etc.).
1. Always Hand-Tighten the housing chambers closed (wrench can over tighten and damage
rubber O-rings, causing leaks), use wrench only to open housings.
2. IMPORTANT! – Cartridge Replacement (Before opening housing chambers):
a. Shut off the main water supply to home first.
b. Open a faucet in your home to release water pressure.
c. Shut-Off the Ball-Valve on the filter system.
d. Press and hold (for a few seconds) the red pressure release buttons on top of each
chamber housing before opening.
e. Unscrew housing slowly with provided wrench, Hand-Tighten to Close.
CAUTION!! When unscrewing chambers to replace cartridges, place something soft (e.g.
large towel) directly under the chambers, in case they are dropped (weight over 25lbs each
with water), so that they won’t hit the hard floor or hit your hand. It will also help soak
up any water that’s released from the chambers.
*Optimal Cartridge Replacement Schedule:
a. 12 months for a 1 person household.
b. 10 months for a 2 person household.
c. 8 months for a 3 person household.
d. 6 months for a 4 person household.
e. 4 months for a 6 person household.
*If there is high sediment content in your water, your first cartridge (carbon block) may
clog sooner, resulting in reduced water flow and a drop in PSI on your pressure gauge.
This means you need to replace the first cartridge earlier than the other cartridges.
With every cartridge change, we recommend to:
a. Remove & Set aside O-rings and Wash the housing chambers with a towel and warm
water to remove any buildup, and dry.
b. Lubricate the housing rubber o-rings with a Food-Grade, NSF & FDA Compliant
Silicone Lubricant (included). The lubricant can also be applied to housing threading
for added protection from leaks. NEVER USE ANY OTHER LUBRICANT as it may
damage the rubber O-rings.
3. Do not use system if your water pressure is above 90PSI.
5
RETURN / EXCHANGE POLICY
1. If the filter arrived damaged, please call us immediately to get an exchange: 1-347-492-4014
2. If you choose to return the filter for any reason other than damage upon arrival, we will be happy to issue
a full purchase price refund or exchange within: 14 days of delivery date, minus shipping cost. The
return policy applies to water filter systems and any unused (sealed) filter media cartridges. If
cartridge have been used or shrink wrap has been removed, we will deduct the price of the cartridges from
the refund, as they will no longer be re-sellable.
3. If you decide to return past the 14-day return period, we will still accept the item for up to 30 days
from delivery date, however, there will be a reasonable 10% restocking fee applied. Please call us or send
an email to initiate the return process or if you have any further questions.
Once you’ve experienced your new system, feel free to share your positive experience by going to
our website product page and writing a review. ☺ Thank You! - The PureEffect Team
NO-HASSLE, 2-YEAR WARRANTY
SURVIVE & PROSPER, INC. dba PureEffectFilters.com, warrants it's water filter systems to be free of
defects in parts and workmanship for a period of: two (2) years from the date of purchase.
All our systems are made of high-quality components (not made in china) and are designed to last for many
years beyond the warranty period, but if any manufacturing defect is present, it will make itself know well
within the warranty period.
In the rare case that it should become necessary to repair or replace the filtration system or one of it's
components, please take a photo of the damaged part and email it along with your order # and a detailed
description of the defect to: info@pureeffectfilters.com or contact our Customer Service Department at: 1-
888-891-4821. We will handle your claim promptly, and as hassle-free as possible.
This warranty does not apply to defects resulting from action/s of the user such as: misuse, accidents,
improper installation, operation outside of specification (e.g. over the indicated PSI limit, exposure to direct
sunlight, freezing temps, UV light), improper maintenance or repair and unauthorized modification.
Survive & Prosper, Inc.’s total liability is limited solely to repair or replacement of the product. The
warranty set forth above is inclusive and no other warranty, whether written or oral, is expressed or implied.
