XTI100
SERIES
Owner’s Manual
THE PURE SOUND OF LIFE
PURE ACOUSTICS
®
Pure Acoustics, Inc. 18 Fuller Place, Brooklyn,
NY 11215, USA, Tel 718 788 4411
www.pure-acoustics.com
Introduction
Thank you for purchasing Pure Acoustics’ products, and welcome to the Pure Acoustics family of
satisfied customers!
Pure Acoustics was established to fulfill the need for high quality speakers of exceptional design at
an affordable price. After years of research and development, and by manufacturing all parts ourselves
- from the voice-coil to the uniquely-designed crossover - Pure Acoustics is able to offer you speakers
of superior value.
Each speaker component has been designed and engineered with first-rate materials to produce
exceptional sound. Our speakers offer the best of it all – high-quality sound, hand-made solid
construction, and a remarkably stylish appearance.
We welcome you to witness the results. Our team’s dedication to quality, reliability and attractive
design has created some of the best-value speakers you can find today.
Reading this manual fully will help you to set up your speaker properly and reward you with a fine
listening experience. Pure Acoustics distribution centers in Europe, Asia, Australia and the Americas
will be happy to assist you with any questions you may have. Please look for the distributor nearest
you on our web site, www.pure-acoustics.com.
Connections
Make sure all equipment is turned off. When connecting the speakers, be sure to retain the correct
polarity. Most speaker cables will have (+) red sign for positive and (-) black sign for negative.
Connect the speaker cable to the positive (+) front-left speaker terminal on the amplifier and to the
positive (+) terminal on the front-left speaker. Connect the speaker cable to the negative (-) front-left
speaker terminal on the amplifier and to the negative (-) terminal on the front left speaker. Repeat
the same step for the right-side front speaker. This method can be applied to bi-wire terminals as
long as the shorting straps are in place. If your amplifier is equipped with bi-wire output connection,
remove the shorting straps and connect each terminal to the associated terminal in your amplifier.
Connect the speaker cable to the positive (+) center speaker terminal on the amplifier and to the
positive (+) terminal on the center speaker. Connect the speaker cable to the negative (-) center
speaker terminal on the amp and to the negative (-) terminal on the center speaker.
Connect the speaker cable to the positive (+) rear left speaker terminal on the amplifier and to the
positive (+) terminal on the rear-left speaker. Connect the speaker cable to the negative (-) rear-left
speaker terminal on the amplifier and to the negative (-) terminal on the rear-left speaker. Repeat
the same step for the right-side rear speaker.
Position
THE FRONT SPEAKERS should be placed on each side of your TV or in front of your favorite listening
position. As a general guideline the space from the speakers to the listening position should be 1.5
times the distance between the speakers. For example if your listening position is 9ft (2.7m) away from
the speakers, the distance between the speakers should be 6ft (1.8m)
THE CENTER CHANNEL SPEAKER should be on top of or just above your TV.
THE REAR (SURROUND) SPEAKERS should be positioned either to the side of, or behind, your listening
position. Typical placement is on the side walls, slightly above ear level, about two-thirds of the way
back from the front of the room. This allows the surround speakers to aim directly at the listener, placing
you in the middle of a five-speaker sound field.
Set-Up Diagram
Dolby
Left
Surround
Speaker
Left
Front
Speaker
Receiver
Center Speaker
Surround Speaker
REARCENTER
CLR
Right
Front
Speaker
FRONT
LR
Right
Surround
Speaker
Running time and cleaning
The performance of the speakers may change during the initial use due to storage and mechanical
limitations. Please allow 15 hours of use for the temperature effect and mechanical parts to attain their
intended design characteristics.
Make sure to turn all equipment off before cleaning. The cabinet only requires occasional dusting.
Please avoid touching the drive units.
Limited one-year warranty
Pure Acoustics products have been designed and manufactured to the highest quality standards. However,
in the event that something malfunctions, Pure Acoustics and your local authorized distributor warrant
free of charge parts and labor (some exclusions may apply) for a period of one year. This warranty is
only valid for the original owner. This warranty is limited to the repair of the product. This warranty will
not apply to units that were subject to misuse, neglect, abuse, alteration or improper installation. This
warranty will not cover damage due to fire, water, heat, lightning or any other cause beyond the control
of Pure Acoustics. Retention of your original dated recipe is required in order to obtain warranty service
from your local authorized Pure Acoustics Dealer.
Technical Specifications
POWER HANDLING
FREQUENCY RESPONSE (+/-3dB)
SENSITIVITY (+/-3dB)
IMPEDANCE
DRIVER COMPLEMENT
WOOFER
MIDRANGE
TWEETER
CROSSOVER FREQUENCY
DIMENSIONS (HXWXD)
XTI-F XTI-C
250 Watts
38Hz - 22Khz
92db
4 - 8 Ohm
3 way Drav Fig.
Two 6.5” (165-mm) woofer FPC
CON for low frequencies
One 6.5” (165-mm) Mid-Driver
FPC CON for mid frequencies
1” (25-mm) silk SCOS dome
2500 / 3500 Hz
106x20x31 Cm.
150 Watts
60Hz - 150Khz
91db
4 - 8 Ohm
2 way DRAV FIG. magnetic
shielding bass reflex
Two 5.25” (133-mm)
midwoofer- driver FPC CON
1” (25-mm) silk SCOS dome
2700 Hz
17x54x19 Cm
XTI-S
150 Watts
65Hz-150Khz
90db
4 - 8 Ohm
2 way DRAV FIG.
One 5.25” (133-mm)
midwoofer- driver FPC CON
1” (25-mm) silk SCOS dome
3500 Hz
32x17x19 Cm
WEIGHT
FINISH
GRILLE
VIDEO SHIELDING
16 Kg (each)
Black, Silver, Cherry, Beech,
Mahogany, Maple
Black cloth
No
6 Kg (each)
Black, Silver, Cherry, Beech,
Mahogany, Maple
Black cloth
Yes
Design and specifications are subject to change without notice.
www.pure-acoustics.com
9 Kg (pair)
Black, Silver, Cherry, Beech,
Mahogany, Maple
Black cloth
No
