Sedona ShowerSpa
Model # 1041
Specification Sheet
TECHNICAL INFORMATION
• Finishes: Hammered Copper
• Fixtures: Oil-Rubbed Bronze
• GPM: 2.5
• Connection: 1/2” Hot & Cold Supply Lines
PRODUCT FEATURES
• Surface mounted & pre-plumbed
• Universal fit with versatile mounting system allows
you to position ShowerSpa at your desired height
• 180° horizontal pivoting shower arm
• 8 inch rain showerhead with air injection technology
• 6 Silk-Spray™ body jets
• 3-function handshower
• Tub spout/ temperature tester
• Glass shelf
NOTES
• Measure your actual product
for rough-in details
• Install this product according
to the installation instructions
CODE/STANDARDS
• cUPC Approved
WARRANTY
• Lifetime Limited Warranty
22 in. - 560 mm
18.31 in. - 465 mm
16.93 in. - 430 mm
3.94 in. 100 m m
7.87 in. 200 mm
5.75 in. -
51.97 in. - 1320 mm
7.87 in. 200 mm
8.27 in. 210 mm
3.94 in. 90 mm
7.09 in. 180 mm
11.02 in. 280 mm
146 mm
58.46 in. - 1485 mm
16.54 in. - 420 mm
2.58 in. -
65.40 mm
PULSE20 - Rev.B
